Funai SRDV495 User Manual

Download

• Remote control (NB118UD) with two AA batteries

• RF cable (

WPZ

0901TM002)• Audio/Video cables

(WPZ0102TM015 or WPZ0102LT E01)

If you need additional operating assistance after reading this owner’s manual,

please call

TOLL FREE : 1-800-968-3429

Before you use this unit, you need to complete connections. Refer to “Connections” on pages 10-12.

To r ecord a program easily, refer to “Easy DVD recording” on pages

54-55

after connections are completed.

(You CANNOT copy any copyright protected DVD disc with this unit.)

SRDV495

INSTRUCCIONES EN ESPAÑOL INCLUIDAS.

Owner’s Manual

DVD Recorder with Video Cassette Recorder

Supplied Accessory

• Owner’s Manual (1VMN20233)• Quick Use Guide (1VMN20319)• DVD-R Blank Media (3 discs)

Owner's Manual

CHANNEL

OUTPUT SELECT

VCR DVD

DVD RECORD

DVD-RW/-R

VCR RECORD

S-VIDEO VIDEO L - AUDIO - R

OPEN/CLOSE

PLAYREWPOWER F.FWD STOP/EJECT

STOP PLAY

ONE TOUCH

DUBBING

Changing the SETUP menu

Playing discs VCR functions

Before you start

Connections Getting started

Recording Editing Others

Español

Precautions

Before you start

Laser Safety

This unit employs a laser. Only a qualified service person should remove the cover or attempt to service this device, due to possible eye injury.

CAUTION: USE OF CONTROLS OR ADJUSTMENTS OR PERFORMANCE OF PROCEDURES OTHER THAN THOSE SPECIFIED HEREIN

MAY RESULT IN HAZARDOUS RADIATION EXPOSURE.

CAUTION: VISIBLE AND INVISIBLE LASER RADIATION WHEN OPEN AND INTERLOCK DEFEATED. DO NOT STARE INTO BEAM. LOCATION: INSIDE, NEAR THE DECK MECHANISM.

WARNING

TO REDUCE THE RISK OF FIRE OR ELECTRIC SHOCK, DO NOT EXPOSE THIS APPLIANCE TO RAIN OR MOISTURE.

The lightning flash with arrowhead symbol, within an equilateral triangle, is intended to alert the user to the presence of uninsulated “dangerous voltage” within the product’s enclosure that may be of sufficient magnitude to constitute a risk of electric shock to persons.

The exclamation point within an equilateral triangle is intended to alert the user to the presence of important operating and maintenance (servicing) instructions in the literature accompanying the appliance.

CAUTION

TO REDUCE THE RISK OF ELECTRIC SHOCK, DO NOT REMOVE COVER (OR BACK). NO USER SERVICEABLE PARTS INSIDE. REFER SERVICING TO QUALIFIED SERVICE PERSONNEL.

CAUTION

RISK OF ELECTRIC SHOCK

DO NOT OPEN

RADIO-TV INTERFERENCE

This equipment has been tested and found to comply with the limits for a Class B digital device, pursuant to Part 15 of the FCC Rules.These limits are designed to provide reasonable protection against harmful interference in a residential installation.This equipment generates, uses,and can radiate radio frequency energy and, if not installed and used in accordance with the instructions, may cause harmful interference to radio communications. However, there is no guarantee that interference will not occur in a particular installation. If this equipment does cause harmful interference to radio or television reception, which can be determined by turning the equipment off and on, the user is encouraged to try to correct the interference by one or more of the following measures:

1) Reorient or relocate the receiving antenna.

2) Increase the separation between the equipment and receiver.

3) Connect the equipment into an outlet on a circuit different from that to which the receiver is connected.

4) Consult the dealer or an experienced radio/TV technician for help.

This Class B digital apparatus complies with Canadian ICES-003. Cet appareil numérique de la classe B est conforme à la norme NMB-

003 du Canada.

FCC WARNING- This equipment may generate or use radio frequency energy. Changes or modifications to

this equipment may cause harmful interference unless the modifications are expressly approved in the instruction manual.The user could lose the authority to operate this equipment if an unauthorized change or modification is made.

CAUTION:TO PREVENT ELECTRIC SHOCK, MATCH WIDE BLADE OF PLUG TO WIDE SLOT, FULLY

INSERT.

ATTENTION: POUR ÉVITER LES CHOC ÉLECTRIQUES, INTRODUIRE LA LAME LA PLUS LARGE DE LA

FICHE DANS LA BORNE CORRESPONDANTE DE LA PRISE ET POUSSER JUSQU’AU FOND.

A NOTE ABOUT RECYCLING

This product’s packaging materials are recyclable and can be reused. Please dispose of any materials in accordance with your local recycling regulations.

Batteries should never be thrown away or incinerated but disposed of in accordance with your local regulations concerning chemical wastes.

For Customer Use: Read carefully the information located at the back of this unit and enter below the Serial No. Retain this information for future reference.

Model No.

_____________________

Serial No. _____________________

Make your contribution to the environment!!!

• Used up batteries do not belong in the dust bin.

• You can dispose of them at a collection point for used up batteries or special waste. Contact your council for details.

Before you start

Español

Changing the SETUP menu

Playing discs

VCR functionsConnections

Getting started

Recording Editing

Others

Before you start

Important Safeguards

1. Read Instructions - All the safety and operating instructions should be read before the appliance is operated.

2. Retain Instructions- The safety and operating instructions should be retained for future reference.

3. Heed Warnings - All warnings on the appliance and in the operating instructions should be adhered to.

4. Follow Instructions - All operating and use instructions should be followed.

5. Cleaning - Unplug this product from the wall outlet before cleaning. Do not use liquid cleaners or aerosol cleaners. Use a damp cloth for cleaning. EXCEPTION:A product that is meant for uninterrupted service and, that for some specific reason, such as the possibility of the loss of an authorization code for a CATV converter, is not intended to be unplugged by the user for cleaning or any other purpose, may exclude the reference to unplugging the appliance in the cleaning description otherwise required in item

6. Attachments - Do not use attachments not recommended by

the product manufacturer as they may cause hazards.

7. Water and Moisture- Do not use this product near water, for example, near a bath tub, wash bowl, kitchen sink, or laundry tub, in a wet basement, or near a swimming pool, and the like.

8. Accessories - Do not place this product on an unstable cart, stand, tripod, bracket, or table.The product may fall, causing serious injury to a child or adult, and serious damage to the appliance. Use only with a cart, stand, tripod, bracket, or table recommended by the manufacturer, or sold with the product. Any mounting of the appliance should follow the manufacturer's instructions and should use a mounting accessory recommended by the manufacturer. An appliance and cart combination should be moved with care. Quick stops, excessive force, and uneven surfaces may cause the appliance and cart combination to overturn.

9.Ventilation - Slots and openings in the cabinet are provided for ventilation and to ensure reliable operation of the product and to protect it from overheating,and these openings must not be blocked or covered.The openings should never be blocked by placing the product on a bed, sofa, rug, or other similar surface. This product should not be placed in a built-in installation such as a bookcase or rack unless proper ventilation is provided or the manufacturer's instructions have been adhered to.

10. Power Sources - This product should be operated only from the type of power source indicated on the marking label. If you are not sure of the type of power supply to your home, consult your appliance dealer or local power company. For products intended to operate from battery power, or other sources, refer to the operating instructions.

11. Grounding or Polarization - This product is equipped with a polarized alternating-current line plug (a plug having one blade wider than the other). This plug will fit into the power outlet only one way.This is a safety feature. If you are unable to insert the plug fully into the outlet, try reversing the plug. If the plug should still fail to fit, contact your electrician to replace your obsolete outlet. Do not defeat the safety purpose of the polarized plug.

12. Power Cord Protection - Power supply cords should be routed so that they are not likely to be walked on or pinched by items placed upon or against them, paying particular attention to cords at plugs, convenience receptacles, and the point where they exit from the appliance.

13. Outdoor Antenna Grounding - If an outside antenna or cable system is connected to the product, be sure the antenna or cable system is grounded so as to provide some protection against voltage surges and built-up static charges.Article

810 of

the National Electrical Code,ANSI/NFPA No.

70,provides infor-

mation with regard to proper grounding of the mast and sup-

porting structure, grounding of the lead-in wire to an antenna discharge unit, size of grounding conductors, location of antenna-discharge unit, connection to grounding electrodes, and requirements for the grounding electrode. (Fig. A)

14. Lightning - For added protection for this product during a lightning storm, or when it is left unattended and unused for long periods of time, unplug it from the wall outlet and disconnect the antenna or cable system. This will prevent damage to the product due to lightning and power-line surges.

15. Power Lines - An outside antenna system should not be located in the vicinity of overhead power lines or other electric light or power circuits, or where it can fall into such power lines or circuits. When installing an outside antenna system, extreme care should be taken to keep from touching such power lines or circuits as contact with them might be fatal.

16. Overloading - Do not overload wall outlets and extension cords as this can result in a risk of fire or electric shock.

17. Object and Liquid Entry - Never push objects of any kind into this product through any openings as they may touch dangerous voltage points or short-out parts that could result in a fire or electric shock. Never spill liquid of any kind on the product.

18. Servicing - Do not attempt to service this product yourself as opening or removing covers may expose you to dangerous voltage or other hazards. Refer all servicing to qualified service personnel.

19. Damage Requiring Service - Unplug this product from the wall outlet and refer servicing to qualified service personnel under the following conditions:

a.When the power-supply cord or plug is damaged. b. If liquid has been spilled,or objects have fallen into the product. c. If the product has been exposed to rain or water. d. If the product does not operate normally by following the oper-

ating instructions. Adjust only those controls that are covered by the operating instructions as an improper adjustment of other controls may result in damage and will often require extensive work by a qualified technician to restore the product to its normal operation.

e. If the product has been dropped or damaged in any way. f.When the product exhibits a distinct change in performance this

indicates a need for service.

20. Replacement Parts - When replacement parts are required, be sure the service technician has used replacement parts specified by the manufacturer or have the same characteristics as the original part. Unauthorized substitutions may result in fire, electric shock or other hazards.

21. Safety Check - Upon completion of any service or repairs to this product,ask the service technician to perform safety checks to determine that the product is in proper operating condition.

22. Heat - This product should be situated away from heat sources such as radiators, heat registers, stoves, or other products (including amplifiers) that produce heat.

Precautions (cont’d)

FIGURE A

EXAMPLE OF ANTENNA GROUNDING

AS PER NATIONAL ELECTRICAL CODE

GROUND CLAMP

ELECTRIC SERVICE EQUIPMENT

NEC – NATIONAL ELECTRICAL CODE

S2898A

ANTENNA LEAD WIRE

ANTENNA DISCHARGE UNIT (NEC SECTION 810-20)

GROUNDING CONDUCTORS (NEC SECTION 810-21)

GROUND CLAMP

POWER SERVICE GROUNDING ELECTRODE SYSTEM (NEC ART 250, PART H)

Precautions (cont’d)

Before you start

Installation Location

For safety and optimum performance of this unit:

• Install the unit in a horizontal and stable position. Do not place anything directly on top of the unit. Do not place the unit directly on top of the TV.

• Shield it from direct sunlight and keep it away from sources of intense heat. Avoid dusty or humid places. Avoid places with insufficient ventilation for proper heat dissipation. Do not block the ventilation holes on the sides of the unit. Avoid locations subject to strong vibration or strong magnetic fields.

Avoid the Hazards of Electrical Shock and Fire

• Do not handle the power cord with wet hands.

• Do not pull on the power cord when disconnecting it from AC wall outlet. Grasp it by the plug.

• If by accident water is spilled on this unit, unplug the power cord immediately and take the unit to our Authorized Service Center for servicing.

• Do not put your fingers or objects into the unit cassette holder.

Moisture Condensation Warning

Moisture condensation may occur inside the unit when it is moved from a cold place to a warm place, or after heating a cold room or under conditions of high humidity. Do not use this unit at least for 2 hours.

About Copyright

Unauthorized copying, broadcasting, public performance and lending of discs are prohibited. This product incorporates copyright protection technology that is protected by method claims of certain U.S. patents and other intellectual property rights owned by Macrovision Corporation and other rights owners. Use of this copyright protection technology must be authorized by Macrovision Corporation, and is intended for home and other limited viewing uses only unless otherwise authorized by Macrovision Corporation. Reverse engineering or disassembly is prohibited.

Notice for progressive scan output

Consumers should note that not all high definition television sets are fully compatible with this product and may cause artifacts to be displayed in the picture. In case of progressive scan picture problems, it is recommended that the user switch the connection to the interlaced video output.

Symbol in this owner's manual

Many functions of this unit are depending on the disc type or the recording mode. To specify for what disc type or recording mode each function is, we put the following symbols at the beginning of each item to operate.

Maintenance

SERVICING

• Please refer to relevant topics on the Troubleshooting Guide on pages

98-100 before returning the product.

• When this unit becomes inoperative, do not try to correct the problem by yourself.There are no user-serviceable parts inside.Turn off, unplug the power plug, and please call our help line mentioned on the front page to locate an Authorized Service Center.

CLEANING THE CABINET

• Use a soft cloth slightly moistened with a mild detergent solution. Do not use a solution containing alcohol, spirits, ammonia or abrasive.

CLEANING DISCS

• When a disc becomes dirty, clean it with a cleaning cloth.Wipe the disc from the center out. Do not wipe in a circular motion.

• Do not use solvents such as benzine, thinner, commercially available cleaners, detergent, abrasive cleaning agents or antistatic spray intended for analogue records.

CLEANING THE DISC LENS

•

If this unit still does not perform properly although you refer to the relevant sections and to “TROUBLESHOOTING GUIDE” in this Owner’s Manual, the laser optical pickup unit may be dirty. Consult your dealer or an Authorized Service Center for inspection and cleaning of the laser optical pickup unit.

DISC HANDLING

• Handle the discs so that fingerprints and dust do not adhere to the surfaces of the discs.

•

Always store the disc in its protective case when it is not used.

AUTO HEAD CLEANING

• Automatically cleans video heads as you insert or remove a cassette, so you can see a clearer picture.

• Playback picture may become blurred or interrupted while the TV program reception is clear. Dirt accumulated on the video heads after a long period of use, or the usage of rental or worn tapes can cause this problem. If a streaky or snowy picture appears during playback, the video heads in the unit may need to be cleaned.

1. Please visit your local electronics retailer and purchase

a good quality VHS Video Head Cleaner.

2. If a Video Head Cleaner does not solve the problem,

please call our help line mentioned on the front page to locate an Authorized Service Center.

NOTES:

• Remember to read the instructions provided with the video head cleaner before use.

• Clean video heads only when problems occur.

Symbol

DVD-V

DVD-RW

DVD-R

MP3

VCR

First: (Press:)

Video

Description

Available to DVD Video discs

Available to DVD-RW in Video mode

Available to DVD-RW in VR mode

Available to DVD-R discs

Available to Audio CDs

Available to CD-R/RW discs with MP3 files

Available to VHS tapes Use only cassettes marked with this unit.

Indicates that you need to select the DVD

DVD

mode by pressing DVD button on the remote control before proceeding next step.

Indicates that you need to select the VCR

VCR

mode by pressing VCR button on the remote control before proceeding next step.

Before you start

Changing the SETUP menu

Playing discs

VCR functionsBefore you start Connections

Getting started

Recording Editing

Others Español

Features

Recording

This unit is compatible with both DVD-RW, which is rewritable, and DVD-R, which is available for recording once. Also, this unit allows you to record to the video cassette tape. You can choose either one for your convenience.

Up to 8 programs recording:

You can program the unit to record up to 8 programs, up to a year in advance. Daily or weekly program recordings are also available.

One-touch timer recording:

You can easily set a recording time as you prefer. Every time the REC/OTR button on the remote control or the RECORD button on the front panel pressed during recording, the recording time will be increased by 30 minutes up to 8 hours.The recording automatically stops when the recording time you set is reached.

Dubbing mode:

You can copy a DVD disc to a videotape or copy a videotape to a DVD disc.This function will be possible only if the DVD disc and the videotape are not copy protected.

REC MONITOR:

You can confirm the picture quality for recording which you set. If you want to change the recording speed, press REC SPEED button to set the desired recording mode.

Automatic Chapter marker setting:

Chapter markers will be put on recordings as you set in SETUP menu before attempting to record.

Automatic Title menu making:

The unit makes title menus automatically when finalizing the disc which are recorded in Video mode.

Automatic PLAYLIST making (VR mode):

A Playlist will be prepared from an Original list, so that you can edit titles in a Playlist as you prefer. An Original list is kept as it is.

Play

Theater surround sound in your home:

When connecting the unit to an amplifier or a decoder which is compatible with Dolby Digital or DTS, you are able to experience the theater surround sound from discs which contain tracks recorded in Dolby Digital format.

Quick search for what you want to watch:

You can easily find the part you want to watch using the search function. Search for a desired point on a disc by title, chapter or time.

Start to play from Original and Playlist (VR mode):

Title playing is available from either an Original list or Playlist.

Quick search for what you want to watch:

You can easily find the part you want to watch using the Index search/Time search functions. An index mark will be assigned at the beginning of each recordings you make. For Time search function, you can go to a specific point on a tape by entering the exact amount of time you wish to skip.

VCR mode

DVD mode

VCR modeDVD mode

Editing

Setting/Clearing chapter markers:

You can easily add chapter markers anywhere in your recordings for easy editing. (VR mode)

Making your own Playlist:

With the original remaing as it is, you can edit titles on various playlist as you prefer. Putting names on titles. Setting pictures for thumbnails. Setting/clearing chapter markers. Deleting parts of titles, etc.

Protecting titles:

To avoid editing or erasing titles, the protect function is useful when it is ON in the original list.

Compatibility

Available for playing discs recorded in Video mode on a regular DVD player (Video mode):

Discs recorded in the Video mode can be played on regular DVD players, including computer DVD drives compatible with DVD-Video playback*.

* DVD-Video Format (Video mode) is a new format for recording on DVD-R/RW discs that was approved by the DVD Forum in 2000. Adoption of this format is optional for manufactures of DVD playback devices and there are DVD-Video players, DVD-ROM drives or other DVD playback devices that do not play DVD-R/RW discs recorded in the DVD-Video Format.

Others

Progressive Scan system

Unlike conventional interlace scanning, the progressive scan system provides less flickering and a smoother appearance without visible scan lines.

DVD mode

This unit not only plays DVD’s, CDs and VHS tapes but also offers features for you to record to DVD discs and edit them.The following features are offered with this unit.

Manufactured under license from Dolby Laboratories.“Dolby” and the double-D symbol are trademarks of Dolby Laboratories.

Note:

You will need to finalize the discs recorded in Video mode to play in other DVD players.

Note:

You will need to finalize the discs recorded in Video mode to play in other DVD players.

“DTS” and “DTS Digital Out” are trademarks of Digital Theater Systems, Inc.

Ta b le of contents

Before you start

VCR functions . . . . . . . . . . . . . . . . . . .50

Playback . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .50

Recording and One-touch timer recording . . . .50

Recording . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .50

One-touch timer recording . . . . . . . . . . . . . . . . . . . .51

Search . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .51

Index search . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .51

Time search . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .52

Other operations . . . . . . . . . . . . . . . . . . . . . . . .53

Recording . . . . . . . . . . . . . . . . . . . . . . .54

Easy DVD recording . . . . . . . . . . . . . . . . . . . . . .54

Information on DVD recording . . . . . . . . . . . . . .56

Information . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .56

Recording speed . . . . . . . . . . . . . . . . . . . . . . . . . . . .56

Restrictions on recording . . . . . . . . . . . . . . . . . . . . .56

Information on copy control . . . . . . . . . . . . . . . . . . .57

Making discs playable in other DVD player (Finalize) 57

Formatting a disc . . . . . . . . . . . . . . . . . . . . . . . .58

Choosing the recording format of a blank disc . . . . .58

Reformatting a disc . . . . . . . . . . . . . . . . . . . . . . . . . .60

Basic recording . . . . . . . . . . . . . . . . . . . . . . . . . .61

Checking the recording picture quality . . . . . . . . . . .62

One-touch timer recording . . . . . . . . . . . . . . . .63

Timer recording . . . . . . . . . . . . . . . . . . . . . . . . .64

Hints for timer recording . . . . . . . . . . . . . . . . . . . . .66

Settings for an external source . . . . . . . . . . . . . .67

Connection to an external source . . . . . . . . . . . . . .67

Recording from an external source . . . . . . . . . . . . . .68

Dubbing Mode . . . . . . . . . . . . . . . . . . . . . . . . . . .69

Finalizing the discs . . . . . . . . . . . . . . . . . . . . . . .71

Setting a disc to protect . . . . . . . . . . . . . . . . . . .72

Editing . . . . . . . . . . . . . . . . . . . . . . . . .73

Information on disc editing . . . . . . . . . . . . . . . . .73

Guide to a title list . . . . . . . . . . . . . . . . . . . . . . . . . .73

Editing discs in Video mode . . . . . . . . . . . . . . . . . . . .73

Editing discs in VR mode . . . . . . . . . . . . . . . . . . . . . .74

Editing DVD-RW discs in Video mode . . . . . . . .75

Deleting titles . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .75

Putting names on titles . . . . . . . . . . . . . . . . . . . . . . .76

Setting or clearing chapter markers . . . . . . . . . . . . .77

Editing DVD-RW discs in VR mode (Original) . .78

Deleting titles . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .78

Deleting parts of titles . . . . . . . . . . . . . . . . . . . . . . .79

Naming Titles . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .80

Setting or clearing chapter markers . . . . . . . . . . . . .82

Setting pictures for thumbnails . . . . . . . . . . . . . . . . .83

Title Protection . . . . . . . . . . . . . . . . . . . . . . . . . . . . .85

Releasing titles from protection . . . . . . . . . . . . . . . .86

Editing DVD-RW discs in VR mode (Playlist) . . .87

Deleting titles . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .87

Deleting parts of titles . . . . . . . . . . . . . . . . . . . . . . .88

Naming Titles . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .89

Setting or clearing chapter markers . . . . . . . . . . . . .91

Setting pictures for thumbnails . . . . . . . . . . . . . . . . .92

Adding titles to a Playlist . . . . . . . . . . . . . . . . . . . . . .94

Deleting a Playlist . . . . . . . . . . . . . . . . . . . . . . . . . . .95

Editing DVD-R discs . . . . . . . . . . . . . . . . . . . . . .96

Deleting titles . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .96

Naming Titles . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .97

Others . . . . . . . . . . . . . . . . . . . . . . . . .98

Tr oubleshooting . . . . . . . . . . . . . . . . . . . . . . . . .98

Glossary . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .102

Specifications . . . . . . . . . . . . . . . . . . . . . . . . . . .103

Language code . . . . . . . . . . . . . . . . . . . . . . . . .103

Español . . . . . . . . . . . . . . . . . . . . . . . .104

Before you start . . . . . . . . . . . . . . . . . . .2

Precautions . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .2

Features . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .5

Ta b le of contents . . . . . . . . . . . . . . . . . . . . . . . . . .6

Functional overview . . . . . . . . . . . . . . . . . . . . . . .7

Installing batteries in the remote control . . . . . . . . . .9

Using a remote control . . . . . . . . . . . . . . . . . . . . . . . .9

VCR/DVD recorder Switching . . . . . . . . . . . . . . . . . .9

Connections . . . . . . . . . . . . . . . . . . . . .10

Connection to a TV . . . . . . . . . . . . . . . . . . . . . . .10

Connection to a cable box or satellite box . . . .11

Connection to an Audio System . . . . . . . . . . . . .12

Getting started . . . . . . . . . . . . . . . . . . .13

Functional overview . . . . . . . . . . . . . . . . . . . . . .13

SETUP/DISC/CD menu . . . . . . . . . . . . . . . . . . . . . . .13

DISPLAY menu . . . . . . . . . . . . . . . . . . . . . . . . . . . . .14

Channel settings . . . . . . . . . . . . . . . . . . . . . . . . .16

Presetting channels automatically . . . . . . . . . . . . . . .16

Adding/deleting channels . . . . . . . . . . . . . . . . . . . . . .17

Setting the clock . . . . . . . . . . . . . . . . . . . . . . . . .18

Auto Clock Setting . . . . . . . . . . . . . . . . . . . . . . . . . .18

Manual Clock Setting . . . . . . . . . . . . . . . . . . . . . . . .19

Setting the daylight saving time . . . . . . . . . . . . . . . . .21

Selecting the TV aspect ratio . . . . . . . . . . . . . . .22

Selecting TV stereo or SAP . . . . . . . . . . . . . . . .23

RF converter output . . . . . . . . . . . . . . . . . . . . . .24

Changing the SETUP menu . . . . . . . . .25

Tour of the SETUP menu . . . . . . . . . . . . . . . . . .25

Language settings . . . . . . . . . . . . . . . . . . . . . . . .26

Display settings . . . . . . . . . . . . . . . . . . . . . . . . . .28

Audio settings . . . . . . . . . . . . . . . . . . . . . . . . . . .30

Parental control settings . . . . . . . . . . . . . . . . . . .32

Playing discs . . . . . . . . . . . . . . . . . . . . .34

Information on DVD play . . . . . . . . . . . . . . . . . .34

Guide to displays . . . . . . . . . . . . . . . . . . . . . . . . . . . .34

Basic playback . . . . . . . . . . . . . . . . . . . . . . . . . . .35

Playback . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .35

Playing discs using the disc menu . . . . . . . . . . . . . . .37

Playing discs using the title menu . . . . . . . . . . . . . . .38

Special playback . . . . . . . . . . . . . . . . . . . . . . . . .39

Resume play . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .39

Fast forward / Fast reverse . . . . . . . . . . . . . . . . . . . .39

Skipping TV commercials during play . . . . . . . . . . . . .40

Pause . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .40

Step by step playback . . . . . . . . . . . . . . . . . . . . . . . .41

Slow forward / Slow reverse play . . . . . . . . . . . . . . .41

Zoom . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .42

Marker Setup . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .42

Search . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .43

Title/Chapter search . . . . . . . . . . . . . . . . . . . . . . . . .43

Track search . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .44

Time search . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .44

Repeat/Random/Program play . . . . . . . . . . . . . .45

Repeat play . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .45

Random play . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .45

Program play . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .46

Selecting audio and video formats . . . . . . . . . . .47

Switching audio soundtrack . . . . . . . . . . . . . . . . . . . .47

Switching subtitles . . . . . . . . . . . . . . . . . . . . . . . . . . .48

Switching camera angles . . . . . . . . . . . . . . . . . . . . . .49

Reducing block noise . . . . . . . . . . . . . . . . . . . . . . . .49

Functional overview

Before you start

Changing the SETUP menu

Playing discs

VCR functionsBefore you start Connections

Getting started

Recording Editing

Others Español

Front Panel

ONE TOUCH

DUBBING

CHANNEL

VCR RECORD DVD RECORD

DVD -RW/-R

OPEN/CLOSE

PLAYREWPOWER F.FWD STOP/EJECT

OUTPUT SELECT

VCR DVD

STOP PLAY

S-VIDEO VIDEO L - AUDIO - R

222120

17 1215 14 910

534

16 13 8 7 6

1.POWER button / indicator (DVD/VCR)

Press to turn the unit on and off. If timer programmings have been set, press to set the unit in timer-standby mode. Press to cancel the timer standby mode and turn the unit on. The light besides the POWER button lights up when power is on.

2. Cassette compartment (VCR)

Insert a tape here.

3. A OPEN/CLOSE button (DVD)

Press to open or close the disc tray.

4. OUTPUT SELECT button (DVD/VCR)

Press to select the component you wish to operate.

5.Disc tray (DVD)

Place a disc on the disc tray when it’s open.

6.AUDIO input jacks (LINE2) (DVD/VCR)

Use to connect external equipment with standard audio cables.

7. VIDEO input jack (LINE2) (DVD/VCR)

Use to connect external equipment with a standard video cable.

8. S-VIDEO input jack (LINE2) (DVD only)

Use to connect the S-Video output of external equipment with an S-Video cable (not supplied).

9.DVD RECORD button (DVD)

Press once to start recording. Press repeatedly to set the time for One-Touch Recording.

10. PLAY button (DVD)

Press to start or resume play.

11.STOP button (DVD)

Press to stop playback or recording. Press to cancel the proceeding timer recording in DVD.

12.DVD SELECT indicator

This indicator lights up when the DVD output mode is selected.

13. VCR SELECT indicator

This indicator lights up when the VCR output mode is selected.

14. ONE TOUCH DUBBING button (DVD/VCR)

Press to start VCR to DVD or DVD to VCR duplication you set in the SETUP menu.

15. CHANNEL L / K button (DVD/VCR)

Press to change the channel up and down.

16. Display (DVD/VCR)

Refer to “Front Panel Display Guide” on page 15.

17. Remote control sensor (DVD/VCR)

Receive signals from your remote control so that you can control the unit from a distance.

18. VCR RECORD button (VCR)

Press once to start a recording. Press repeatedly to set the time for One-Touch Recording.

19. PLAY button (VCR)

Press to start playback.

20.STOP/EJECT button (VCR) EJECTbutton-

Press to remove the tape from the unit.

STOP button-Press to stop the tape playback. Press to cancel the proceeding timer recording in VCR.

21.F.FWD button (VCR)

Press to rapidly advance the tape, or view the picture rapidly in forward during playback. (Forward Search)

22. REW button (VCR)

Press to rewind the tape, or to view the picture rapidly in reverse during playback mode. (Rewind Search)

Rear Panel

DVD DVD/VCR

ANTENNA

AUDIO OUTAUDIO IN

S-VIDEO

AUDIO

OUT

DIGITAL

AUDIO OUT

COAXIAL

COMPONENT VIDEO OUT

VIDEO OUTVIDEO IN

OUT

634521

1112

1.AC Power Cord (DVD/VCR)

Connect to a standard AC outlet to supply power to this unit.

2.S-VIDEO IN jack (LINE1)

(DVD only)

Use to connect the S-Video output of external equipment with an S-Video cable (not supplied).

COMPONENT VIDEO OUT jacks (DVD only)

Use to connect a TV monitor with component video inputs with component video cables (not supplied).

4.AUDIO IN jacks (LINE1) (DVD/VCR)

Use to connect external equipment with standard audio cables.

5.AUDIO OUT jacks (DVD/VCR)

Use to connect a TV monitor, AV receiver or other equipment with standard audio cables.

6. ANTENNA IN jack (DVD/VCR)

Use to connect an antenna.

7. ANTENNA OUT jack (DVD/VCR)

Use to connect an antenna cable to pass the signal from the ANTENNA IN to your TV monitor.

8. VIDEO OUT jack (DVD/VCR)

Use to connect a TV monitor, AV receiver or other equipment with a standard video cable.

9.VIDEO IN jack (LINE1) (DVD/VCR)

Use to connect external equipment with a standard video cable.

10. S-VIDEO OUT jack (DVD only)

Use to connect the S-Video input of a TV monitor, AV receiver or other equipment with an S-Video cable (not supplied).

11.AUDIO OUT jacks (DVD only)

Use to connect a TV monitor, AV receiver or other equipment with standard audio cables.

12.COAXIAL DIGITAL AUDIO OUT jack (DVD only)

Use to connect an AV receiver, Dolby Digital decoder, DTS decoder or other equipment with a coaxial digital input jack with a digital coaxial cable (not supplied).

Note: Do not touch the inner pins of the jacks on the rear panel. Electrostatic discharge may cause perma-

nent damage to the unit.

•

These jacks are useful only in DVD mode.

Functional overview (cont’d)

Before you start

SETUP button (DVD/VCR)

Press to display the setup menu. During DVD playback, press and hold for more than 3 seconds to switch to the progressive video output or the interlaced.

REC MONITOR button (DVD)

Press to check the recording speed before attempting a recording.

MENU/LIST button (DVD)

Press to display the Disc menu. To change ORIGINAL and PLAYLIST on the TV screen. (VR mode only)

10.

TOP MENU button (DVD)

Press to display the top menu.

11. CLEAR/C.RESET button (DVD/VCR)

• DVD mode Press to clear the password once entered, to cancel the programming for CD, to clear the selected marker number in the marker setup mode or to clear the program once entered in the timer recording setting mode,etc.

• VCR mode Press to reset the tape counter.

12.

SEARCH MODE button (VCR)

To call up the index or time search menu.

13. CM SKIP button (DVD)

During playback, press to advance 30 seconds.

14. REC SPEED button (DVD/VCR)

Press to select the recording speed.

15.

OPEN/CLOSE A button (DVD)

Press to open or close the disc tray.

16.AUDIO button (VCR)

During playback of a HiFi video tape, press to change the AUDIO OUT setting to “HIFI” or “MONO”.

17.

CH K / L buttons (DVD/VCR)

• DVD mode Press to change the channel up and down.

• VCR mode Press to change the channel up and down. Press to adjust tape tracking during playback or in slow motion. In still mode, you can adjust the picture if blurred vertically.

18.

VIDEO/TV button (DVD/VCR)

Press to select VIDEO or TV mode.

POWER button (DVD/VCR)

Press to turn the unit on and off. If timer programmings have been set, press to set the unit in timer-standby mode. Press to cancel the timer standby mode, then turn the unit on.

Number buttons (DVD/VCR)

Press to select channel numbers. Press to select a title/chapter/track on display or a TV channel. Also press to enter values for the settings in the SETUP menu.

DISPLAY button (DVD/VCR)

Press to display or change the on-screen display.

4. VCR button

Press to allow the remote control to operate the VCR. Refer to page 9. Press to select the VCR output mode.

5. E button (DVD/VCR)

• DVD mode During playback, press to play fast reverse or during pause, press to play slow reverse.

• VCR mode Press to rewind the tape or to view the picture rapidly in reverse during playback mode.

REC/OTR button (DVD/VCR)

Press once to start a recording. Press repeatedly to set the time for One-Touch Recording.

19. SLOW button (VCR)

During playback, press to view the video tape in slow motion.

20.PAUSE F button (DVD/VCR)

Press to pause play or recording.

21.DVD button

Press to allow the remote control to operate the DVD. Refer to page 9. Press to select the DVD output mode.

22. PLAY B button (DVD/VCR)

Press to start or resume play.

23. D button (DVD/VCR)

• DVD mode During playback, press to play fast forward. Or when playback is paused, press to play slow forward.

• VCR mode Press to rapidly advance the tape or view the picture rapidly in forward during playback.

24.STOP C button (DVD/VCR)

Press to stop playback or recording.

25. TIMER PROG. button (DVD/VCR)

Press to display the timer program setting menu.

26. ENTER button (DVD/VCR)

Press to confirm or select menu items.

27. K / L / { / B buttons (DVD/VCR)

Press to select items or settings.

28.RETURN button (DVD/VCR)

Press to return to the previously displayed menu screen.

29. ZOOM button (DVD)

During playback, press to enlarge the picture on the screen.

30. SKIP H button (DVD)

During playback, press to skip to the previous chapter or track. Or during playback, press to play reverse step by step.

SKIP G button (DVD)

During playback, press to skip to the next chapter or track. Or during playback, press to play forward step by step.

31. ONE TOUCH DUBBING button (DVD/VCR)

Press to start VCR to DVD or DVD to VCR duplication however you set in the SETUP menu.

Remote Control

POWER

REC SPEED

.@/:

123

GHI JKL MNO

456

PQRS

7809

DISPLAY

REC/OTR

REC MONITOR

MENU/LIST

CLEAR/C.RESET

MODE

OPEN/CLOSE

AUDIO

ABC DEF

TUV WXYZ

SPACE

VCR

DVD

PLAY

STOP

SETUP

TIMER PROG.

ENTER

TOP MENU

ZOOM SKIP SKIP

ONE TOUCH

CM SKIP

VIDEO/TV

SLOW

PAUSE

RETURN

DUBBING

28 29

30 31

Functional overview (cont’d)

Before you start

Changing the SETUP menu

Playing discs

VCR functionsBefore you start Connections

Getting started

Recording Editing

Others Español

Using a remote control

Keep in mind the following when using the remote control:

• Make sure that there is no obstacle between the remote control and the remote sensor on the unit.

• Use within the operating range and angle as shown.

• Remote operation may become unreliable if strong sunlight or fluorescent light is shining on the remote sensor of the unit.

• Remote control for different devices can interfere with each other. Avoid using remote control for other equipment located close to the unit.

• Replace the batteries when you notice a fall off in the operating range of the remote control.

S K I P

R E C

P A U S

E N T

E R

M E N

L A Y L I S

T O P M E

N U /

R I G IN A

F W D

S T O

L A Y

R E

Installing batteries in the remote control

Install two AA batteries (supplied) matching the polarity indicated inside battery compartment of the remote control.

Note:

Incorrect use of batteries can result in hazards such as leakage and bursting. Please observe the following:

• Do not mix new and old batteries together.

• Do not use different kinds of batteries together, although they may look similar, different batteries may have different voltages.

• Make sure that the plus and minus ends of each battery match the indications in the battery compartment.

•Remove batteries from equipment that is not going to be used for a month or more.

• When disposing of used batteries, please comply with governmental regulations or environmental public instruction rules that apply in your country or area.

• Do not recharge, short-circuit, heat, burn or disassemble batteries.

Because this product is a combination of a VCR and a DVD recorder, you must select first which component you wish to operate with the OUTPUT SELECT button.

VCR DVD

OUTPUT SELECT

OUTPUT SELECT button

DVD SELECT indicator

VCR SELECT indicator

POWER

REC SPEED

AUDIO

ZOOM SKIP SKIP

OPEN/CLOSE

TOP MENU

SPACE

VCR

SETUP

CM SKIP

TIMER PROG.

RETURN

123

456

7809

STOP

PLAY

VIDEO/TV

SLOW

PAUSE

.@/:

ABC DEF

GHI JKL MNO

PQRS

REC/OTR

REC MONITOR

MENU/LIST

CLEAR/C.RESET

MODE

ENTER

DISPLAY

TUV WXYZ

DVD

DVD button

VCR button

ONE TOUCH DUBBING

CHANNEL

VCR RECORD DVD RECORD

DVD -RW/-R

OPEN/CLOSE

PLAYREWPOWER F.FWD STOP/EJECT

OUTPUT SELECT

VCR DVD

STOP PLAY

S-VIDEO VIDEO L - AUDIO - R

ONE TOUCH

DUBBING

Press the VCR button on the remote control.

(Verify that the VCR SELECT indicator is lit.)

VCR MODE

Note

•

Pressing only the OUTPUT SELECT button on the front panel DOES NOT switch the mode of the remote control. You MUST select the correct mode on the remote control.

• Pressing the SETUP or the TIMER PROG. button

switches the unit to the DVD mode.

Press the DVD button on the remote control.

(Verify that the DVD SELECT indicator is lit.)

DVD MODE

VCR/DVD recorder Switching

Within about 23feet (7m)

Remote control

60˚

POW

RE W

F .F WD

ST OP

/E JEC

PL A Y

V CR

R EC

OR D

O P EN /C

L OSE

O NE T

OUC D U BBI

C H A

NN EL

S T

LAY

TPU

T S

EL EC

D V D

D V D R

EC O RD

DVD

-V

/-R

IDE

VI D EO

DI O

- R

Connection to a TV

Connections

DVD DVD/VCR

ANTENNA

AUDIO OUTAUDIO IN

S-VIDEO

AUDIO

OUT

DIGITAL

AUDIO OUT

COAXIAL

COMPONENT VIDEO OUT

VIDEO OUTVIDEO IN

OUT

(Back of TV)

Plug in the AC power cord of this unit.

Cable Signal

Connect

Disconnect

Antenna

(Back of this unit)

(Back of TV)

RF Cable (supplied)

Connect

Make one of the following connections, depending on the capabilities of your existing equipment.

DVD DVD/VCR

ANTENNAINAUDIO OUTAUDIO IN

S-VIDEO

AUDIO

OUTT

COMPONENT VIDEO OUT

VIDEO OUTVIDEO IN

OUT

DVD DVD/VCR

ANTENNAINAUDIO OUTAUDIO IN

S-VIDEO

AUDIO OUT

DIGITAL

AUDIO OUT

COAXIAL

COMPONENT VIDEO OUT

VIDEO OUTVIDEO IN

OUT

DVD

DVD/VCR

AUDIO OUT

DVD/VCR

VIDEO OUT

DVD

S-VIDEO

OUT

DVD

COMPONENT VIDEO OUT

AUDIO

OUT

AUDIO IN VIDEO IN

S-VIDEO IN

COMPONENT

VIDEO IN

AUDIO OUT

Audio Connection

Method 2 Method 3

Better picture Best picture

S-VIDEO OUT

COMPONENT VIDEO OUT *Required for progressive

scan display from DVD.

Audio cable

(supplied)

Component Video cables (not supplied)

This unit

Note

• Connect this unit directly to the TV. If the A/V cables are connected to a VCR, pictures may be distorted due to the copy protection system.

• Method 2 and method 3 are only useful in DVD mode.

Method 1

Good picture

VIDEO OUT

Video cable (supplied)

S-Video cable (not supplied)

•

These jacks are useful only in DVD mode.

If your TV is compatible with 480p progressive scanning and you want to enjo

y that high quality picture;

You must select the connection Method 3 above and select progressive scanning mode. To set the mode, press and hold the SETUP button on the remote control for more than 3 seconds during DVD playback, so that “P.SCAN” will appear on the display of this unit.

If your TV is not compatible with progressive scanning;

Press and hold the SETUP button on the remote control for more than 3 seconds during DVD playback, so that “P.SCAN” on the display of this unit will disappear.

TOP MENU

SETUP

TIMER PROG.

RETURN

STOP

PLAY

REC/OTR

REC MONITOR

MENU/LIST

ENTER

more than 3 seconds

during DVD playback

[Interlace mode]

[Progressive scanning mode]

Changing the SETUP menu

Playing discs VCR functions

Before you start

Connections Getting started

Recording Editing Others

Español

Connections

DVD/VCR

ANTENNA

OUT

RF Cable

(supplied)

(Back of this unit)

OUT

(Back of TV)

Cable

Signal

Connection A

(Cable box or

Satellite box)

Connection to a cable box or satellite box

Note to the Cable TV System Installer :

This reminder is provided to call the Cable TV system installer’s attention to Article 820-40 of the National Electrical Code, which provides guidelines for proper grounding - in particular, specifying that the cable ground shall be connected to the grounding system of the building, as close to the point of cable

entry as possible.

Select this connection when you want to view or record a scrambled channel. With this connection, channels cannot be changed on this unit.You can view or record ONLY the channels you have selected on the cable box or the satellite box.

• While you are recording, only the recorded channel can be viewed.

To select channels on the cable box or satellite box

1) Turn on this unit by pressing POWER button.The “POWER” indicator on the front panel will light up. Then, press the CHANNEL buttons to select channel 3 or 4 (the same channel as the output channel of the cable box or satellite box).

• If noise appears on the TV screen

,press VIDEO/TV button on the remote control.

• If you use channel 4,you need to change this unit’s RF output to channel 4. Refer to “RF converter out- put” on page 24.

2) On the TV, select channel 3 or 4 (the same channel as you have selected at step 1).

3) On the cable box or satellite box, select the channel you want to view or record.

DVD/VCR

ANTENNA

OUT

RF Cable (supplied)

RF Cable

(Back of TV)

OUT

(Cable box or

Satellite box)

Cable

Signal

Connection B

(Back of this unit)

Select this connection when you want to change channels on this unit.With this connection, you may watch one channel while recording another.

• You may not view or record a scrambled channel.

To select channels on the cable box or satellite box

1) On the cable box or satellite box, select channel 3 or 4 (the same channel as this unit’s RF output channel.)

• Refer to “RF converter output” on page 24.

2) On the TV, select the same channel as the output channel (3 or 4) of the cable box or satellite box.

3) Turn on this unit by pressing POWER button. The “POWER” indicator on the front panel will light up.

Then select the channel you want to view or record.

• If noise appears on the TV screen, press VIDEO/TV button on the remote control.

To playback a DVD disc or a tape

Before trying to playback DVD or tape you MUST follow step 1) to 2) above.

• Refer to “Playback” on pages 35-36, 50.

To view one channel while recording another

1) While you are recording on this unit, press VIDEO/TV button.

2) On the cable box or satellite box, select the channel you want to view.

Connections

Connection to an Audio System

• Before changing the connections, all devices should be turned off.

• Refer to each owner’s manual for further information on other devices.

DVD/VCR

AUDIO OUT

DVD

AUDIO

OUT

Stereo system

COAXIAL

DVD

DIGITAL

AUDIO OUT

COAXIAL

AUDIO

Method 1

Analog audio input jacks

Digital audio input jack

AUDIO OUT

DIGITAL AUDIO OUT

Method 2

Audio cable

(supplied)

Coaxial Digital

Audio cable

(not supplied)

Note

• If you connect this unit to a receiver with a Dolby Digital decoder and set “Dolby Digital” to “Stream” for the “Digital Out” setting in the SETUP menu. (Refer to pages 30-31.)

• If output is DTS encoded audio, connect to a DTS decoder and set “DTS” to “ON” for the “Digital Out” setting in the SETUP menu. (Refer to pages 30-31.)

• A Dolby Digital 5.1 channel surround format cannot be recorded as digital sound by an MD or DAT deck.

• Unless connected to a receiver with a Dolby Digital decoder or a DTS decoder, set “Dolby Digital” to “PCM” and “DTS” to “OFF” for the “Digital Out” setting in the SETUP menu. Playing a DVD using incorrect settings may generate noise distortion and may also damage the speakers. (Refer to pages 30-

31.)

• Set “Dolby Digital” to “PCM” for the “Digital Out” setting in the SETUP menu for connecting to an MD deck or DAT deck. (Refer to pages 30-31.)

• By hooking this unit up to a receiver with a Multichannel Dolby Digital decoder, you can enjoy highquality Dolby Digital 5.1 channel surround sound as heard in movie theaters.

Receiver with Dolby

Digital Decoder

This unit

(VCR/DVD Sound)

(DVD Sound Only)

(DVD Audio only)

Changing the SETUP menu

Playing discs VCR functions

Before you start

Connections Getting started

Recording Editing Others

Español

Getting started

Functional overview

Guide to On Screen Menus

The unit uses the following types of on screen menus for most operations. SETUP/DISC/CD menu,Title list, and DISPLAY menu, which allows you to change the playing status of disc during play.The DISPLAY menu also gives you some disc information for checking the status of the disc.

SETUP/DISC/CD menu

Press SETUP button to display the setup main menu, then choose either SETUP/DISC/CD by pressing { / B buttons.Then, press ENTER button to display each menu. These menus provide entry to all main functions of the unit.

1.Playback:

To set up the DVD/VCR to your preference.

2. Recording:

To set up the DVD/VCR to record to discs or tapes.

3. Display:

To set up the OSD screen of the DVD/VCR.

4. Select Video: (L1 or L2)

To choose a line input from external video products.

5.Clock:

To set up the clock of the unit as you need.

6. Channel:

To preset the TV channels.

1. Edit:

Turns on a title list, (When a disc with VR mode is inserted, 'Original' or 'PlayList' is available.), which shows the recorded titles on the disc.

2.Format:

Allows you to erase all of the recorded content on the disc. The disc will be completely blank.

3. Finalize:

Allows you to finalize a disc containing recorded titles.

4.Disc Protect (VR mode only) :

Allows you to protect a disc from accidental editing or recording.

1. Random Play:

To activate the random CD tracks playback.

2.Program Play(Audio CD only):

To activate the programmed CD tracks playback feature.

“CD” can only be selected when an Audio CD disc or a CD-R/RW disc with MP3 files is inserted into the unit.

“SETUP” is available only in the Stop mode.

“DISC” is available only when a DVD-R/RW disc is inserted into the unit. When a DVD-Video disc (commercially available), a new DVD-R disc or the finalized DVD-R disc is inserted into the unit, you cannot select “DISC”.

You will need to finalize the discs recorded in video mode to play in other DVD players.

Setup Menu

Setup

1 2 3

4 5 6

Playback Setting

Disc Setting

Disc

Edit

Format

Finalize

Disc Protect OFF ON

1 2 3

CD Playback Mode

Random Play

Program Play

1 2

Getting started

Functional overview (cont’d)

DISPLAY menu

First:

Press DISPLAY button to call up the display menu.This menu will give you the information on the playing disc. Some operations are available while disc is playing.

Details are on page

34.

1. Indicates the disc type and

the format mode.

2. Indicates the recording mode

and possible recording time left.

3. Indicates the current channel

number.

4. Indicates title number, chapter

number and the time elapsed of disc play.

5. Icon Description:

)

DVD mode

First:

Press DISPLAY button to call up the display menu.

1. Playback status of the current

tape.

2. Indicates the current channel

number and an audio status of the program.

3. Indicates the recording speed.

4. Indicates the Tape Counter.

5. Audio status of the current

tape.

VCR mode

Note:

In some descriptions on this manual, only one disc type is

indicated as an example.

DVD

11 00:00:00

DVD-RW

Video mode

SP 1:25 Rem.

CH 1

2 3

: Search

: Audio

: Subtitle

: Angle (except VR mode

: Repeat

: Marker

: Noise Reduction

: Zoom

VCR

0:00:00 HIFISP

CH21

4 53

Changing the SETUP menu

Playing discs VCR functions

Before you start

Connections Getting started

Recording Editing Others

Español

Getting started

Functional overview (cont’d)

Front Panel Display Guide

1. Current status of the unit

: Appears when disc/tape

play is paused.

: Appears when playing a

disc/tape.

: Appears when timer pro-

gramming has been set.

: Appears during recording

process.

: Appears when repeat playback is turned on.

: Appears when a tape is in

the unit.

2. Disc type and Current status of the unit

Appears when an audio CD or a disc with MP3 files is inserted in the DVD/VCR.

Appears when a DVD disc is inserted in the DVD/VCR. Appears when a DVD timer recording is proceeding. Appears when DVD is in the timer recording standby mode.

: Appears when a DVD-R disc is inserted in the DVD/VCR.

: Appears when a DVDRW disc is inserted in the DVD/VCR.

Appears when a VCR timer recording is proceeding. Appears when VCR is in the timer recording standby mode.

: Appears during VCR to DVD duplication process.

: Appears during DVD to VCR duplication process.

Display message

3. Recording speed

Indicates the recording speed of the disc or the tape.

4. Title/Track and Chapter mark

: Appears when indicating

a title/track number.

: Appears when indicating

a chapter number.

5. Displays the following

•Playing time / remaining time

• Current title / chapter / track number

• Recording time

• Clock

• Channel number

• VCR tape counter

•OTR remaining time

6. : Appears when the cur-

rent time is in the ‘pm’ portion of the day.

7. :

Appears when the progressive scan video output is activated.

1. Appears when the disc tray is

opening.

2. Appears when the disc tray is

closing or closed.

3. Appears when a disc is loading

inside the DVD/VCR.

4. Appears when data is record-

ing onto the disc.

Getting started

Channel settings

It is recommend that you preset available channels in your area using “Auto Preset” in the Channel Preset of the SETUP menu.

Presetting channels automatically

Press POWER button to turn on the unit.

Turn the TV on and be sure to select the input to which the DVD/VCR is connected.

Press SETUP button to display SETUP/DISC menu.

SETUP/DISC menu will appear.

Screen:

Select “SETUP” using { / B buttons, then press ENTER button.

SETUP menu will appear.

Select “Channel” using K / L / { / B buttons, then press ENTER button.

Channel Preset menu will appear.

Select “Auto Preset” using K / L buttons, then press ENTER button.

The unit will begin scanning channels available in your area.

This may take a few minutes to complete.

Press SETUP button to exit.

•You can select only the channels memorized in this unit by using the CHANNEL buttons.

Note

• If the auto presetting is cancelled during presetting, some channels not yet preset may not be received.

• The selection will depend on how you receive the TV channels.

To cancel the auto presetting during scanning:

Press RETURN button or SETUP button to cancel.

To select a channel

You can select a channel by directly entering channel using the Number buttons on the remote control.

Notes for using the Number buttons:

• When selecting cable channels

which are higher than 99, enter channel numbers as a three-digit number.(For example:

117,press 1, 1, 7)

• You must precede single-digit

channel numbers with a zero (For example:

02, 03, 04 and

so on).

•

You can select the line input mode (“L1” or “L2”).To select “L1” by pressing [0],[0],[1].To select “L

2” by pressing

[0],[0],[2].Details are on page 68.

POWER

REC SPEED

AUDIO

ZOOM SKIP SKIP

OPEN/CLOSE

TOP MENU

SPACE

VCR

SETUP

CM SKIP

TIMER PROG.

RETURN

123

456

7809

STOP

PLAY

VIDEO/TV

SLOW

PAUSE

.@/:

ABC DEF

GHI JKL MNO

PQRS

REC/OTR

REC MONITOR

MENU/LIST

CLEAR/C.RESET

MODE

ENTER

DISPLAY

TUV WXYZ

DVD

ONE TOUCH

DUBBING

4 5 6

Setup Menu

Setup

Playback Setting

Setup > Channel Preset

Auto Preset

Manual Preset

TV Audio Select

VCR DVD

Stereo

CH 18

Auto Presetting Now

Changing the SETUP menu

Playing discs VCR functions

Before you start

Connections Getting started

Recording Editing Others

Español

Getting started

Channel settings (cont’d)

Select “Manual Preset” using K / L buttons, then press

ENTER button.

Manual Preset menu will appear.

Select the channel number to add or delete.

Press { button to move to a lower channel number.

Press

B button to move to a

higher channel number.

Select “Add” or “Delete” using

K / L buttons, then

press ENTER button.

The channel number will be added or deleted from the channel memory.Then next channel number will appear so that you can continue adding or deleting channels.

Press SETUP button to exit.

Adding/deleting channels

The channels you no longer receive or seldom watch can be deleted from the memory.You also may add channels into memory.

Press SETUP button to display SETUP/DISC menu.

SETUP/DISC menu will appear.

Screen:

Select “SETUP” using { / B buttons, then press ENTER button.

SETUP menu will appear.

Select “Channel” using K / L / { / B buttons, then press ENTER button.

Channel Preset menu will appear.

2 3 4 5

Setup Menu

Setup

Setup > Channel Preset > Manual Preset

CH2

Add Delete

Setup > Channel Preset > Manual Preset

CH18

Add Delete

POWER

REC SPEED

.@/:

ABC DEF

123

GHI JKL MNO

456

PQRS

TUV WXYZ

7809

SPACE

VCR

DISPLAY

PLAY

STOP

SETUP

REC/OTR

REC MONITOR

MENU/LIST

TOP MENU

ZOOM SKIP SKIP

CLEAR/C.RESET

CM SKIP

MODE

AUDIO

ENTER

DVD

OPEN/CLOSE

VIDEO/TV

SLOW

PAUSE

TIMER PROG.

RETURN

ONE TOUCH

DUBBING

Playback Setting

Setup > Channel Preset

Auto Preset

Manual Preset

TV Audio Select

VCR DVD

Stereo

Getting started

Setting the clock

Set the clock before you try timer recording. If a Public Broadcasting Station (PBS) is available in your area, follow Auto Clock Setting below. If not, follow Manual Clock Setting on pages 19-20.

Auto Clock Setting

Make sure

• The antenna/cable TV connections are correct.

• If this unit is connected to a Cable Box or Satellite Box, select the local PBS station on the box to set the clock automatically.

Press SETUP button to display SETUP/DISC menu.

SETUP/DISC menu will appear.

Screen:

Select “SETUP”using

{ / B

but-

tons, then press ENTER button.

SETUP menu will appear.

Select “Clock” using

K / L / { / B

buttons, then press ENTER button.

Clock menu will appear.

Setup > Clock

Clock Setting

Auto Clock Setting

Daylight Saving Time

Auto

VCR DV D

Select “Auto Clock Setting” using

K / L buttons, then

press ENTER button.

Option window will appear.

• If you do not know your PBS channel number, select “Auto” using

K / L buttons, then press ENTER button and proceed to setp 6.

• If you know your PBS channel number, select “Manual” using

K / L buttons, then

press ENTER button.

Enter your PBS channel number using Number or

/ L buttons, then press ENTER button.

Press SETUP button to exit.

Press POWER button to turn off the unit.

This unit will search for the time only when the power is off. Leave it off for several minutes to give this unit time to set the clock on the display of the front panel.

Note : Clock Set

• The clock may set itself automatically after you connect the antenna/cable signal to this unit and plug in the power cord. In this case, the current time will appear on the display on the front panel.

• If the current time is not displayed or the displayed time is not correct, set the clock manually. (See Next Page.)

POWER

REC SPEED

AUDIO

ZOOM SKIP SKIP

OPEN/CLOSE

TOP MENU

SPACE

VCR

SETUP

CM SKIP

TIMER PROG.

RETURN

123

456

7809

STOP

PLAY

VIDEO/TV

SLOW

PAUSE

.@/:

ABC DEF

GHI JKL MNO

PQRS

REC/OTR

REC MONITOR

MENU/LIST

CLEAR/C.RESET

MODE

ENTER

DISPLAY

TUV WXYZ

DVD

ONE TOUCH

DUBBING

2 3 4 5

Setup > Clock

Clock Setting

Auto Clock Setting

Daylight Saving Time

VCR DV D

OFF

Auto

Auto Manual

Off

Setup Menu

Setup

Playback Setting

Setup > Clock

Clock Setting

Auto Clock Setting

Daylight Saving Time

VCR DV D

OFF

Set Channel No.

Auto

CH1

Manual

Off

Changing the SETUP menu

Playing discs VCR functions

Before you start

Connections Getting started

Recording Editing Others

Español

Getting started

Setting the clock (cont’d)

Manual Clock Setting

Press SETUP button to display SETUP/DISC menu.

SETUP/DISC menu will appear.

Screen:

Select “SETUP” using { / B buttons, then press ENTER button.

SETUP menu will appear.

Select “Clock” using K / L / { / B buttons, then press

ENTER button.

Clock menu will appear.

Select “Clock Setting” using K / L buttons, then press

ENTER button.

A clock setting window will appear.

Press ENTER button again.

Default date will appear.

Enter the date (month / day / year) using

K / L buttons.

Press { / B buttons to move the cursor.

Enter the time (hour / minute) using

K / L buttons.

Press { / B buttons to move the cursor.

Note : In Time of Power

Loss

• Your clock setting will be lost if either there is a power failure or this unit has been unplugged for more than

seconds when you set the clock manually.

POWER

REC SPEED

AUDIO

ZOOM SKIP SKIP

OPEN/CLOSE

TOP MENU

SPACE

VCR

SETUP

CM SKIP

TIMER PROG.

RETURN

123

456

7809

STOP

PLAY

VIDEO/TV

SLOW

PAUSE

.@/:

ABC DEF

GHI JKL MNO

PQRS

REC/OTR

REC MONITOR

MENU/LIST

CLEAR/C.RESET

MODE

ENTER

DISPLAY

TUV WXYZ

DVD

ONE TOUCH

DUBBING

2 3 4 5

Instructions continue on page 20.

Setup Menu

Setup

Playback Setting

Setup > Clock

Clock Setting

Auto Clock Setting

Daylight Saving Time

VCR DV D

Auto

- - : - -

VCR DV D

Auto

Setup > Clock

Clock Setting

Auto Clock Setting

Daylight Saving Time

- - - / - - / - - - - ( - - - )

12 : 00AM

VCR DV D

Auto

Setup > Clock

Clock Setting

Auto Clock Setting

Daylight Saving Time

JAN / 12 / 2004 (MON)

Setup > Clock

Clock Setting

Auto Clock Setting

Daylight Saving Time

JAN / 12 / 2004 (MON)

09 : 24 AM

VCR DV D

Auto

Getting started

Setting the clock (cont’d)

Press K / L buttons to select AM or PM, then press ENTER button.

Clock menu will appear, then the settings will be activated.

Press SETUP button to exit.

Although seconds are not displayed, they begin counting from zero.

POWER

REC SPEED

AUDIO

ZOOM SKIP SKIP

OPEN/CLOSE

TOP MENU

SPACE

VCR

SETUP

CM SKIP

TIMER PROG.

RETURN

123

456

7809

STOP

PLAY

VIDEO/TV

SLOW

PAUSE

.@/:

ABC DEF

GHI JKL MNO

PQRS

REC/OTR

REC MONITOR

MENU/LIST

CLEAR/C.RESET

MODE

ENTER

DISPLAY

TUV WXYZ

DVD

ONE TOUCH

DUBBING

ZOOM SKIP SKIP

TOP MENU

SETUP

CM SKIP

TIMER PROG.

RETURN

STOP

PLAY

REC/OTR

REC MONITOR

MENU/LIST

CLEAR/C.RESET

MODE

ENTER

ONE TOUCH

DUBBING

Select “Auto Clock Setting” using

K / L buttons, then

press ENTER button.

Option window will appear.

Repeat steps (1) to (3) in “Manual Clock Setting”.

When “Auto Clock Setting” is selected to “Auto” or “Manual”, change it to “OFF” as follows:

Select “OFF” using K / L buttons, then press ENTER button.

Press SETUP button to exit.

Setup > Clock

Clock Setting

Auto Clock Setting

Daylight Saving Time

VCR DV D

Auto

Setup > Clock

Clock Setting

Auto Clock Setting

Daylight Saving Time

VCR DV D

OFF

Auto

Auto Manual

Off

Changing the SETUP menu

Playing discs VCR functions

Before you start

Connections Getting started

Recording Editing Others

Español

Getting started

Setting the clock (cont’d)

Select “Daylight Saving Time” using

K / L buttons,

then press ENTER button.

Daylight Saving Time options will appear.

Select “ON” or “OFF” using K / L buttons, then press

ENTER button.

Choose “ON” when currently observing the daylight saving time.

Press SETUP button to exit.

Setting the daylight saving time

When Daylight Saving Time is ON, the unit clock will automatically move forward one hour on the first Sunday in April and move back one hour on the last Sunday in October.

Press SETUP button to display SETUP/DISC menu.

SETUP/DISC menu will appear.

Screen:

Select “SETUP” using { / B buttons, then press ENTER button.

SETUP menu will appear.

Select “Clock” using K / L / { / B buttons, then press

ENTER button.

Clock menu will appear.

2 3 4 5

Setup Menu

Setup > Clock

Clock Setting

Auto Clock Setting

Daylight Saving Time

VCR DV D

Auto

ON OFF

POWER

REC SPEED

.@/:

ABC DEF

123

GHI JKL MNO

456

PQRS

TUV WXYZ

7809

SPACE

VCR

DISPLAY

PLAY

STOP

SETUP

REC/OTR

REC MONITOR

MENU/LIST

TOP MENU

ZOOM SKIP SKIP

CLEAR/C.RESET

CM SKIP

MODE

AUDIO

ENTER

DVD

OPEN/CLOSE

VIDEO/TV

SLOW

PAUSE

TIMER PROG.

RETURN

ONE TOUCH

DUBBING

Setup

Playback Setting

Setup > Clock

Clock Setting

Auto Clock Setting

Daylight Saving Time

VCR DV D

Auto

Getting started

Selecting the TV aspect ratio

Yo u can select the TV aspect ratio to match the formats of what you are playing with the unit and your TV screen (

4:3 standard or 16:9 widescreen TV). “

4:3 Letter Box” has been select-

ed as the default.

Press SETUP button to display SETUP/DISC menu.

SETUP/DISC menu will appear.

Screen:

Select “SETUP” using { / B buttons, then press ENTER button.

SETUP menu will appear.

Select “Playback” using K / L / { / B buttons, then press ENTER button.

Playback menu will appear.

Select “TV Aspect” using K / L buttons, then press ENTER

button.

Option window will appear.

Refer to the Note on this page.

Select a desired option using K / L buttons, then press

ENTER button.

Press SETUP button to exit.

Note :TV Aspect

If you have a standard TV:

Select “4:3 Letter Box”, so that black bars appear on the top and bottom of the screen. Select “

4:3 Pan & Scan” for a full height picture with both sides trimmed.

If you have a widescreen TV:

Select “16:9 Wide”.

POWER

REC SPEED

AUDIO

ZOOM SKIP SKIP

OPEN/CLOSE

TOP MENU

SPACE

VCR

SETUP

CM SKIP

TIMER PROG.

RETURN

123

456

7809

STOP

PLAY

VIDEO/TV

SLOW

PAUSE

.@/:

ABC DEF

GHI JKL MNO

PQRS

REC/OTR

REC MONITOR

MENU/LIST

CLEAR/C.RESET

MODE

ENTER

DISPLAY

TUV WXYZ

DVD

ONE TOUCH

DUBBING

2 3 4 5

Setup Menu

Setup

Setup > Playback

TV Aspect

Parental Lock

Disc Menu Language

Audio Language

Subtitle Language

Digital Out

Dynamic Range Control

Fast Forward with Audio

DVD

16:9 Wide

4:3 Letter Box

4:3 Pan & Scan 16:9 Wide

English Original

OFF

Playback Setting

Setup > Playback

TV Aspect

Parental Lock

Disc Menu Language

Audio Language

Subtitle Language

Digital Out

Dynamic Range Control

Fast Forward with Audio

DVD

4:3 Letter Box

All

English

Original

OFF

Selecting TV stereo or SAP

Getting started

Changing the SETUP menu

Playing discs VCR functions

Before you start

Connections Getting started

Recording Editing Others

Español

You can select stereo or SAP. “Stereo” has been selected as the default.

Press SETUP button to display SETUP/DISC menu.

SETUP/DISC menu will appear.

Screen:

Select “SETUP” using { / B buttons, then press ENTER button.

SETUP menu will appear.

2 3 4 5

Select “Channel” using K / L / { / B buttons, then press ENTER button.

Channel Preset menu will appear.

Select “TV Audio Select” using

K / L buttons, then

press ENTER button.

Option window will appear.

Select “Stereo” or “SAP” using K / L buttons, then press ENTER button. Stereo:

Outputs main-audio.

SAP: (Secondary Audio Program)

Outputs second audio channel. Refer to the item in “Glossary” on page 102 for more information.

Press SETUP button to exit.

Notes on TV channel audio

• When you record a TV program which has Stereo and Secondary Audio Programs on a DVD-RW/R or a tape, you have to select the TV channel audio (Stereo or SAP) beforehand. Only the selected channel audio will be recorded. Refer to the following table to check an appropriate setting.

• As can be seen in the table on the right, if your TV channel audio is set to SAP and the recorded TV program has Stereo and Secondary Audio Programs, you can only view the program in the sub-audio.

Selected Broadcast Disc/tape Audio audio audio recording output

Stereo STEREO+SAP STEREO STEREO

STEREO STEREO STEREO MONO+SAP MONO MONO MONO MONO MONO

SAP STEREO+SAP SAP SAP

STEREO STEREO STEREO MONO+SAP SAP SAP MONO MONO MONO

Setup Menu

Setup > Channel Preset

Auto Preset

Manual Preset

TV Audio Select

VCR DVD

Stereo

Setup > Channel Preset

Auto Preset

Manual Preset

TV Audio Select

VCR DVD

Stereo

SAP

POWER

REC SPEED

.@/:

ABC DEF

123

GHI JKL MNO

456

PQRS

TUV WXYZ

7809

SPACE

VCR

DISPLAY

PLAY

STOP

SETUP

REC/OTR

REC MONITOR

MENU/LIST

TOP MENU

ZOOM SKIP SKIP

CLEAR/C.RESET

CM SKIP

MODE

AUDIO

ENTER

DVD

OPEN/CLOSE

VIDEO/TV

SLOW

PAUSE

TIMER PROG.

RETURN

ONE TOUCH

DUBBING

Setup

Playback Setting

RF converter output

Getting started

Change from CH3 to CH4

You can watch TV programs through the tuner of the unit. (Usually channel

3 or 4 of the TV is available for the RF converter setting.) Be

sure to connect the unit to a TV using the RF cable. Refer to page 10.

Select channel 3 on your TV.

• Be sure that the unit is in DVD mode.

Press VIDEO/TV button on the remote control.

• If noise appears, change the RF output channel of the DVD/VCR to CH

4 by pressing VIDEO/TV button for 3 seconds.The RF output

channel will alternate between CH

3 and CH4 as follows.

Press VIDEO/TV button

for more than 3 seconds

Note:

•

RF channel change is available only when the unit is in DVD mode.

POWER

REC SPEED

AUDIO

.@/:

ABC DEF

123

GHI JKL MNO

456

PQRS

TUV WXYZ

7809

SPACE

VCR

DISPLAY

DVD

OPEN/CLOSE

VIDEO/TV

SLOW

PAUSE

(

RF on)

(

RF on)

(

RF on)

3 seconds

CH4

3 seconds

CH3

3 seconds

CH4

3 seconds

REC/OTR

REC MONITOR

MENU/LIST

TOP MENU

CLEAR/C.RESET

CM SKIP

MODE

PLAY

STOP

SETUP

TIMER PROG.

ENTER

RETURN

ZOOM SKIP SKIP

ONE TOUCH

DUBBING

Changing the SETUP menu

Playing discs VCR functions

Before you start

Connections Getting started

Recording Editing Others

Español

Changing the SETUP menu

Tour of the SETUP menu

Note : Setup

• If you change a setting in SETUP menu, the information of contents stays on even when the power is switched off.

The following table shows the settings that are available in the SETUP menu and which are the default settings. Refer to the following table for useful operation.

SETUP menu ContentsItems (highlight is the default)

1.Language setting

Pages 26-27

Disc Menu Language Set the language for disc menu.

English French Spanish

2.Display setting Pages 28-29

3.Audio setting Pages 30-31

4.Parental setting Pages 32-33

Audio Language

Subtitle Language

OSD Background Transparency

OSD Background Color

OSD Language

Screen Saver

Digital Out

Dynamic Range Control

Fast Forward with Audio

Parental Lock

(Change password)

Original English French

OFF English French

100%

35% 25%

1 2 3

English

Français Español

OFF 5 minutes 10minutes

Dolby Digital PCM

Stream PCM

Auto 48kHz 96kHz

DTS ON OFF

ON OFF

ALL level 8 to 1

Enter the current four-digit password

Set the language for audio.

Set the language for subtitle.

Set the background transparency of OSD screen.

Set the OSD screen color. 1 (Green), 2 (Blue), 3 (Red)

Set the language for OSD (On Screen Display).

Set the time at which point the screen saver turn on.

Set the type of sound signal which outputs from the digital audio output jack.

Set whether the sound recorded in 96kHz will be down sampled to 48kHz.

Set whether DTS signal will be output or not.

Compressing the range of sound volume.

Outputting sound during playback in fast forward.

Set the parental level of your DVD discs.

Set and change the password.

Language settings

Changing the SETUP menu

Press SETUP button to display SETUP/DISC menu.

SETUP/DISC menu will appear.

Select “SETUP” using { / B buttons, then press ENTER button.

SETUP menu will appear.

Select “Playback” using K / L /

{ / B

buttons, then press

ENTER button.

Option window will appear.

Select a desired item using K / L buttons, then press ENTER button.

Note : Languages

• Only the languages supported by the disc can be selected.

•Audio Language setting may not be available on some discs.

•You can change or switch off the subtitles on a DVD disc also from the disc menu if it

is available.

Press STOP button if you are playing a disc.

Setup Menu

Setup

Playback Setting

POWER

REC SPEED

.@/:

ABC DEF

123

GHI JKL MNO

456

PQRS

TUV WXYZ

7809

SPACE

VCR

DISPLAY

PLAY

STOP

SETUP

REC/OTR

REC MONITOR

TOP MENU

MENU/LIST

ZOOM SKIP SKIP

CLEAR/C.RESET

CM SKIP

MODE

AUDIO

DVD

ENTER

OPEN/CLOSE

VIDEO/TV

SLOW

PAUSE

TIMER PROG.

RETURN

ONE TOUCH

DUBBING

Setup > Playback

TV Aspect

Parental Lock

Disc Menu Language

Audio Language

Subtitle Language

Digital Out

Dynamic Range Control

Fast Forward with Audio

4:3 Letter Box

All

English

Original

OFF

DVD

Language settings (cont’d)

Changing the SETUP menu

Playing discs VCR functions

Before you start

Connections Getting started

Recording Editing Others

Español

Disc Menu Language (Default : English)

Set the language for Disc Menu.

•

Select a setting using K / L buttons, then press ENTER button.

Your setting will be activated.

•

Select a setting using K / L buttons, then press ENTER button.

Your setting will be activated.

•

Select a setting using K / L buttons, then press ENTER button.

Your setting will be activated.

Audio Language (Default : Original)

Set the Audio language.

Subtitle Language (Default : OFF)

Set the subtitle language.

If “Other” is selected, press 4-digit code using number buttons.

All

•

When you finish entering the code, press ENTER button. Refer to the language code table on page

103.

Press SETUP button to exit SETUP menu.

Setup > Playback

TV Aspect

Parental Lock

Disc Menu Language

Audio Language

Subtitle Language

Digital Out

Dynamic Range Control

Fast Forward with Audio

Setup > Playback

TV Aspect

Parental Lock

Disc Menu Language

Audio Language

Subtitle Language

Digital Out

Dynamic Range Control

Fast Forward with Audio

DVD

4:3 Letter Box

All

English

Original

OFF

DVD

4:3 Letter Box

All

English

Original

OFF

Setup > Playback

TV Aspect

Parental Lock

Disc Menu Language

Audio Language

Subtitle Language

Digital Out

Dynamic Range Control

Fast Forward with Audio

Setup > Playback

TV Aspect

Parental Lock

Disc Menu Language

Audio Language

Subtitle Language

Digital Out

Dynamic Range Control

Fast Forward with Audio

DVD

4:3 Letter Box

All

English

French

Original

Spanish

OFF

Other

OFF

DVD

4:3 Letter Box

All

Original

English

Original

French

OFF

Spanish Other

OFF

Setup > Playback

TV Aspect

Parental Lock

Disc Menu Language

Audio Language

Subtitle Language

Digital Out

Dynamic Range Control

Fast Forward with Audio

DVD

4:3 Letter Box

All

English

Original

OFF

Setup > Playback

TV Aspect

Parental Lock

Disc Menu Language

Audio Language

Subtitle Language

Digital Out

Dynamic Range Control

Fast Forward with Audio

DVD

4:3 Letter Box

All

OFF

English

Original

French

OFF

Spanish Other

OFF

ontrol

English

French

Original

Spanish

OFF

Other

Code Input

- - - -

Changing the SETUP menu

Display settings

Press SETUP button to display SETUP/DISC menu.

SETUP/DISC menu will appear.

Select “SETUP” using { / B buttons, then press ENTER button.

SETUP menu will appear.

Select “Display” using K / L /

{ / B

buttons, then press

ENTER button.

Option window will appear.

Select a desired item using K / L buttons, then press ENTER button.

Press STOP button if you are playing a disc.

Setup Menu

Setup

Playback Setting

POWER

REC SPEED

.@/:

ABC DEF

123

GHI JKL MNO

456

PQRS

TUV WXYZ

7809

SPACE

VCR

DISPLAY

PLAY

STOP

SETUP

REC/OTR

REC MONITOR

TOP MENU

MENU/LIST

ZOOM SKIP SKIP

CLEAR/C.RESET

CM SKIP

MODE

AUDIO

DVD

ENTER

OPEN/CLOSE

VIDEO/TV

SLOW

PAUSE

TIMER PROG.

RETURN

ONE TOUCH

DUBBING

Setup > Display

OSD Background Transparency

OSD Background Color

OSD Language

Screen Saver

35%

English

10 minutes

DVD

Display settings (cont’d)

Changing the SETUP menu

Playing discs VCR functions

Before you start

Connections Getting started

Recording Editing Others

Español

OSD Background Transparency (Default : 35%)

Set the background transparency of OSD screen. You can choose one among 0% through 100%.

•

Select a setting using K / L buttons, then press ENTER button.

Your setting will be activated.

•

Select a setting using K / L buttons, then press ENTER button.

Your setting will be activated.

•

Select a setting using K / L buttons, then press ENTER button.

Your setting will be activated.

OSD Background Color (Default : 1 Green)

Set the OSD screen color. You can choose among the following options 1(Green), 2(Blue), and 3(Red).

OSD Language (Default : English)

Set the OSD language.

•

Select a setting using K / L buttons, then press ENTER button.

Your setting will be activated.

Screen Saver (Default : 10 minutes)

Set the time at which point the screen saver function appears on the TV screen.

Press SETUP button to exit SETUP menu.

Setup > Display

OSD Background Transparency

OSD Background Color

OSD Language

Screen Saver

Setup > Display

OSD Background Transparency

OSD Background Color

OSD Language

Screen Saver

DVD

35%

English

10 minutes

DVD

35%

English

10 minutes

Setup > Display

OSD Background Transparency

OSD Background Color

OSD Language

Screen Saver

Setup > Display

OSD Background Transparency

OSD Background Color

OSD Language

Screen Saver

DVD

100%

35%

85%

70%

English

50%

10 minutes

35% 25% 10% 0%

DVD

35%

1 2

English

10 minutes

Setup > Display

OSD Background Transparency

OSD Background Color

OSD Language

Screen Saver

VCR DVD

35%

English

10 minutes

Setup > Display

OSD Background Transparency

OSD Background Color

OSD Language

Screen Saver

VCR DVD

35%

English

English Français

10 minutes

Español

Setup > Display

OSD Background Transparency

OSD Background Color

OSD Language

Screen Saver

DVD

35%

English

10 minutes

Setup > Display

OSD Background Transparency

OSD Background Color

OSD Language

Screen Saver

DVD

35%

OFF

English

5 minutes 10 minutes

10 minutes 15 minutes 30 minutes

Changing the SETUP menu

Audio settings

Digital Out

Sets the digital audio output for discs when connected through the coaxial digital audio output.

•

Select a setting using K / L buttons, then press ENTER button.

Option window will appear. Proceed to steps A or B.

Press SETUP button to display SETUP/DISC menu.

SETUP/DISC menu will appear.

Select “SETUP” using { / B buttons, then press ENTER button.

SETUP menu will appear.

Select “Playback” using K / L /

{ / B

buttons, then press

ENTER button.

Option window will appear.

Select a desired item using K / L buttons, then press ENTER button.

Press STOP button if you are playing a disc.

Choose the appropriate Audio settings for your equipment.

It will only affect DVD discs during playback.

Note : Dynamic Range

Control

• Dynamic Range Control function is available only on the discs which are recorded in

the Dolby Digital format.

Setup Menu

Setup

Playback Setting

POWER

REC SPEED

.@/:

ABC DEF

123

GHI JKL MNO

456

PQRS

TUV WXYZ

7809

SPACE

VCR

DISPLAY

PLAY

STOP

SETUP

REC/OTR

REC MONITOR

MENU/LIST

TOP MENU

ZOOM SKIP SKIP

CLEAR/C.RESET

CM SKIP

MODE

AUDIO

DVD

ENTER

OPEN/CLOSE

VIDEO/TV

SLOW

PAUSE

TIMER PROG.

RETURN

ONE TOUCH

DUBBING

Setup > Playback

TV Aspect

Parental Lock

Disc Menu Language

Audio Language

Subtitle Language

Digital Out

Dynamic Range Control

Fast Forward with Audio

DVD

4:3 Letter Box

All

English

Original

OFF

Setup > Playback

TV Aspect

Parental Lock

Disc Menu Language

Audio Language

Subtitle Language

Digital Out

Dynamic Range Control

Fast Forward with Audio

DVD

4:3 Letter Box

All

English

Original

OFF

Setup > Playback

TV Aspect

Parental Lock

Disc Menu Language

Audio Language

Subtitle Language

Digital Out

Dynamic Range Control

Fast Forward with Audio

4:3 Letter Box

All

English

Original

OFF

PCM

Dolby Digital DTS

OFF

DVD

Audio settings (cont’d)

Changing the SETUP menu

Playing discs VCR functions

Before you start

Connections Getting started

Recording Editing Others

Español

•

Select a setting using K / L buttons, then press ENTER button.

Your setting will be activated.

•

Select a setting using K / L buttons, then press ENTER button.

Your setting will be activated.

Dynamic Range Control (Default : ON)

Set to ON to compress the range between soft and loud sounds.

Fast Forward with Audio (Default : OFF)

Set to ON to output sound during playback in x2 fast forward.

Press SETUP button to exit SETUP menu.

Settings for PCM (Default :Auto)

•

Select a setting using K / L buttons, then press ENTER button.

Your setting will be activated. Auto : Select “Auto” usually. 48kHz : If your amplifier/receiver is NOT com-

patible with

96kHz PCM, select “48kHz”.

96kHz sound will be output in 48kHz.

96kHz : If your amplifier/decoder is compatible

with

96kHz PCM, select “96kHz”. 96kHz

sound will be output.

Note

When playing disc with copyright protection

• If you select “Auto”, the sound will be down sampled to

48kHz.

• If you select “96kHz”, no digital sound will be output. Select “Auto”, to output 48kHz digital

sound.

Settings for Dolby Digital (Default : Stream)

•

Select a setting using K / L buttons, then press ENTER button.

Your setting will be activated. PCM : Converts Dolby Digital into PCM

(stereo).

When your amplifier/receiver is NOT com-

patible with Dolby Digital, set to “PCM”.

Stream : Outputs Dolby Digital signals.

When your amplifier/receiver is compatible with Dolby Digital, set to “Stream”.

Note

When playing a DVD-RW disc recorded in VR mode

• If the audio source on a disc is Dolby Digital format, set “Dolby Digital” to “PCM” so that you can switch to main (L), sub audio (R), or a mix of both (L/R) with your amplifier/decoder.

Settings for DTS (Default : OFF)

•

Select a setting using K / L buttons, then press ENTER button.

Your setting will be activated. ON : Outputs DTS signals.

When your amplifier/decoder is compatible with DTS, set to “ON”.

OFF : No DTS signal is output.

When your amplifier/decoder is NOT compatible with DTS, set to

“OFF”.

Original

OFF

PCM

ntrol

Dolby Digital DTS

udio

OFF

Auto 48kHz 96kHz

Original

OFF

PCM

ntrol

udio

Dolby Digital

PCM Stream

DTS

OFF

Original

OFF

ntrol

udio

PCM

Dolby Digital

OFF

DTS

OFF

Setup > Playback

TV Aspect

Parental Lock

Disc Menu Language

Audio Language

Subtitle Language

Digital Out

Dynamic Range Control

Fast Forward with Audio

DVD

4:3 Letter Box

All

English

Original

OFF

Setup > Playback

TV Aspect

Parental Lock

Disc Menu Language

Audio Language

Subtitle Language

Digital Out

Dynamic Range Control

Fast Forward with Audio

Setup > Playback

TV Aspect

Parental Lock

Disc Menu Language

Audio Language

Subtitle Language

Digital Out

Dynamic Range Control

Fast Forward with Audio

DVD

4:3 Letter Box

All

English

Original

OFF

Setup > Playback

TV Aspect

Parental Lock

Disc Menu Language

Audio Language

Subtitle Language

Digital Out

Dynamic Range Control

Fast Forward with Audio

DVD

4:3 Letter Box

All

English

Original

OFF

DVD

4:3 Letter Box

All

English

Original

OFF

Changing the SETUP menu

Parental control settings

Press SETUP button to display SETUP/DISC menu.

SETUP/DISC menu will appear.

Select “SETUP” using { / B buttons, then press ENTER button.

SETUP menu will appear.

Select “Playback” using K / L /

{ / B

buttons, then press

ENTER button.

Option window will appear.

Select “Parental Lock” using K / L buttons, then press ENTER button.

Press STOP button if you are playing a disc.

Some DVD-Video discs feature a Parental control setting. Playback will stop if the ratings exceed the levels you set, it will require you to enter a password before the disc will playback. This feature prevents your children from viewing inappropriate material.

Note : Parental Control

• Parental control function may not be available on some DVD discs.

• With some DVDs, it may be difficult to find if they are compatible with parental control. Be sure to check if the parental control function operates in the way that you have set it.

• Record the password in case you forget it.

Setup Menu

POWER

REC SPEED

.@/:

ABC DEF

123

GHI JKL MNO

456

PQRS

TUV WXYZ

7809

SPACE

VCR

DISPLAY

PLAY

STOP

SETUP

REC/OTR

REC MONITOR

MENU/LIST

TOP MENU

ZOOM SKIP SKIP

CLEAR/C.RESET

CM SKIP

MODE

AUDIO

DVD

ENTER

OPEN/CLOSE

VIDEO/TV

SLOW

PAUSE

TIMER PROG.

RETURN

ONE TOUCH

DUBBING

Setup

Playback Setting

Setup > Playback

TV Aspect

Parental Lock

Disc Menu Language

Audio Language

Subtitle Language

Digital Out

Dynamic Range Control

Fast Forward with Audio

DVD

4:3 Letter Box

All

English

Original

OFF

Parental control settings (cont’d)

Changing the SETUP menu

Playing discs VCR functions

Before you start

Connections Getting started

Recording Editing Others

Español

Parental Lock (Default : All)

Set the Parental control level.

•

Change the parental level using K / L buttons, then press ENTER button.

Option window will appear. Proceed to steps A or B.

•

Select “Yes” using s / B buttons, then enter a new password using Number buttons.

Your setting will be activated.

•

Select “Yes” using s / B buttons, then enter a new password using Number buttons.

Your setting will be activated.

Press SETUP button to exit SETUP menu.

A password has been set already

Change the password

• If you

select “No”, proceed

to Step 5.

Ye s

Note : Password Reset

•Press CLEAR/C.RESET button to erase numbers entered incorrectly.

• When you forget the password or you want to clear all settings in Parental lock, enter 4,7,3,7 using Number buttons in option window. Password will be cleared and parental

levels will be set to All.

• If you

select “No”, proceed

to Step 5.

•

Enter the current password

using Number buttons.

A password has not been set yet

Setup > Playback

TV Aspect

Parental Lock

Disc Menu Language

Audio Language

Subtitle Language

Digital Out

Dynamic Range Control

Fast Forward with Audio

DVD

4:3 Letter Box

All

English

Original

OFF

Setup > Playback

TV Aspect

Parental Lock

Disc Menu Language

Audio Language

Subtitle Language

Digital Out

Dynamic Range Control

Fast Forward with Audio

DVD

4:3 Letter Box

All 8

All 7

English 6 Original

5 OFF

4 3 2

ON 1

OFF

Setup > Playback

TV Aspect

Parental Lock

Disc Menu Language

Audio Language

Subtitle Language

Digital Out

Dynamic Range Control

Fast Forward with Audio

DVD

4:3 Letter Box

Change Password?

All

Yes No

All 7

English 6 Original

5 OFF

4 3 2

ON 1

OFF

4:3 Letter Box

All

Password

All

* * * *

7 English

6 Original

5 OFF

4 3 2

ON 1

OFF

DVD

Setup > Playback

TV Aspect

Parental Lock

Disc Menu Language

Audio Language

Subtitle Language

Digital Out

Dynamic Range Control

Fast Forward with Audio

Setup > Playback

TV Aspect

Parental Lock

Disc Menu Language

Audio Language

Subtitle Language

Digital Out

Dynamic Range Control

Fast Forward with Audio

Setup > Playback

TV Aspect

Parental Lock

Disc Menu Language

Audio Language

Subtitle Language

Digital Out

Dynamic Range Control

Fast Forward with Audio

Change Password?

4:3 Letter Box

All

Yes No

All 7

English 6 Original

5 OFF

4 3 2

ON 1

OFF

DVD

4:3 Letter Box

Password

All

- - - -

All 7

English 6 Original

5 OFF

4 3 2

ON 1

OFF

DVD

4:3 Letter Box

Password

All

- - - -

All

English

Original

OFF

4 3 2

OFF

DVD

Setup > Playback

TV Aspect

Parental Lock

Disc Menu Language

Audio Language

Subtitle Language

Digital Out

Dynamic Range Control

Fast Forward with Audio

Information on DVD play

Playing discs

Before you attempt to play DVD discs, read the following information.

Playable discs

This unit is compatible with following discs. To play a DVD, make sure that it meets the requirements for Region Codes and Color Systems as described below. Discs that have the following logos will play on the unit. Other Disc types are not guaranteed to play.

Color systems

DVDs are recorded in different color systems throughout the world.The most common color systems are NTSC (which is used primarily in the United States and Canada), PAL and SECAM. This unit uses NTSC, so DVDs you play must be recorded in the NTSC system.You cannot play DVDs recorded in other color system.

Region codes

This unit has been designed to play DVD discs with Region One (1). DVDs must be labeled for ALL regions or for Region 1 in order to play on this unit. You cannot play DVDs that are labeled for other regions. Look for the symbols below on your DVDs. If these region symbols do not appear on your DVD, you cannot play that DVD in this unit.

The number inside the globe refers to region of the world. Region

1 represents the United States, Canada, Bermuda, the U.S.Virgin Islands and small regions near Australia. A DVD labeled for a specific region can only play on the unit with the same region code.

DVD playback

The contents of a DVD disc are generally divided into titles.Titles may be further subdivided into chapters.

First:

Press DISPLAY button to bring up the display menu.This menu will give you information on the playing disc. Some operations are available while the disc is playing.

1. Indicates a disc type and a

format mode.

2. Indicates a recording speed

and recording time left.

3. Indicates a current channel

number and an audio status of the program.

4. Indicates a title number, chap-

ter number and the time elapsed of disc play.

5. Icon Legend:

)

Guide to displays

Start Rec. Stop/Start Stop Rec.

Title 1 Title 2

Chapter 1 Chapter 1Chapter 2 Chapter 3 Chapter 2

LogoDisc

DVD VIDEO

DVD-RW (VIDEO/VR FORMAT)

DVD-R (VIDEO FORMAT)

CD-DA (AUDIO CD)

CD-R (CD-DA FORMAT, MP3 files)

CD-RW (CD-DA FORMAT, MP3 files)

DVD

11 00:00:00

DVD-RW

Video mode

SP 1:25 Rem.

CH 1

: Search

: Audio

: Subtitle

: Angle (except VR mode

: Repeat

: Marker

: Noise Reduction

: Zoom

Basic playback

Playing discs

Changing the SETUP menu

Playing discs VCR functions

Before you start

Connections Getting started

Recording Editing Others

Español

Note :Title List

•For DVD-R (Video mode) and DVD-RW (Video mode) discs which are already finalized, a title list will be displayed instead of thumbnails.

•You can resume play from where you stopped playing the disc Resume play. Refer to page 39 for details about resume play.

• Some discs may start playing

automatically.

Press POWER button, then press DVD button.

When you are playing a DVD, turn the TV on and be sure to select the input to which the DVD/VCR is connected.

Press OPEN/CLOSE A but- ton to open the disc tray.

The disc tray will open.

Place the disc onto the disc tray with its label facing up and make sure to align the disc to the disc tray guide.

Press TOP MENU button to display the title menu.

You can change “Original” or “Playlist” of VR mode using MENU/LIST button.

Video mode:

VR mode:

MENU/LIST button

Select a desired title using K / L / { / B buttons, then press

ENTER button.

Playback will begin.

Press STOP C button to stop playback.

To eject the disc, press OPEN/CLOSE

A button to open the disc tray, then remove the disc before turning off the DVD/VCR.

This operation may take a few minutes to complete.

2 6

Playback

DVD-R

Video

DVD-RW

Original

1 1 32

JAN/1 12:00AM

JAN/1 3:00AM

JAN/1 1:00AM JAN/1 2:00AM

JAN/1 4:00AM

Playlist

1 1 32

JAN/1 12:00AM

JAN/1 3:00AM

JAN/1 1:00AM JAN/1 2:00AM

JAN/1 4:00AM

POWER

REC SPEED

.@/:

ABC DEF

123

GHI JKL MNO

456

PQRS

TUV WXYZ

7809

SPACE

VCR

DISPLAY

PLAY

STOP

SETUP

REC/OTR

REC MONITOR

MENU/LIST

TOP MENU

ZOOM SKIP SKIP

CLEAR/C.RESET

CM SKIP

MODE

AUDIO

DVD

ENTER

OPEN/CLOSE

VIDEO/TV

SLOW

PAUSE

TIMER PROG.

RETURN

ONE TOUCH

DUBBING

disc tray guide

Title List

1 1 32

JAN/1 12:00AM

JAN/1 3:00AM

JAN/1 1:00AM JAN/1 2:00AM

JAN/1 4:00AM

Title Menu

CH9612:24AMJAN/1

Basic playback (cont’d)

Playing discs

In stop mode, press TOP MENU button to bring up the MP3 menu.

•To exit the menu, press TOP MENU button again.

Press KK/ LLbuttons to select a desired folder (group) or track, then press ENTER button.

When selecting track:

Playback will start.

When selecting the folder:

The files in folder will appear. Press K or L button to select the track or folder you want, then press

ENTER

button.

•Press s button or RETURN button to go to the previous hierarchy.

•Press STOP C button to return to the first item.

Hints for MP3 files:

•Folders are known as Groups, files are known as Tracks.

•

Folders are accompanied by icon.

•

MP3 files are accompanied by icon. Playback will start from the selected track and go to the next one in turn.

•

The system can recognize up to 255 groups (or folders) and up to 255 tracks.

•

The name of group and track can be displayed in up to 32 characters. Unrecognizable characters will be replaced with asterisks.

• If there are no files in the folder, “No Files” will be displayed.

This unit recommends the files recorded under the following circumstances:

•

Sampling frequency: 44.1kHz or 48kHz.

•

Constant bit rate: 112kbps - 320kbps.

Press POWER button, then press DVD button.

When you are playing a DVD or an audio CD, turn the TV on and be sure to select the input to which the DVD/VCR is connected.

Press OPEN/CLOSE A but- ton to open the disc tray.

The disc tray will open.

Place the disc onto the disc tray with its label facing up and make sure to align the disc to the disc tray guide.

Press PLAY B button to start playing.

Playback will start.

If you are playing a DVD-Video disc, a menu may appear. Refer to page 37 for details about a disc menu.

Press STOP C button to stop playing.

Note : Automatic Playback

• Some discs may start playing automatically.

POWER

REC SPEED

AUDIO

ZOOM SKIP SKIP

OPEN/CLOSE

TOP MENU

SPACE

VCR

SETUP

CM SKIP

TIMER PROG.

RETURN

123

456

7809

STOP

PLAY

VIDEO/TV

SLOW

PAUSE

.@/:

ABC DEF

GHI JKL MNO

PQRS

REC/OTR

REC MONITOR

MENU/LIST

CLEAR/C.RESET

MODE

ENTER

DISPLAY

TUV WXYZ

DVD

ONE TOUCH

DUBBING

For MP3 playback

POWER

REC SPEED

AUDIO

ZOOM SKIP SKIP

OPEN/CLOSE

TOP MENU

SPACE

VCR

SETUP

CM SKIP

TIMER PROG.

RETURN

123

456

7809

STOP

PLAY

VIDEO/TV

SLOW

PAUSE

.@/:

ABC DEF

GHI JKL MNO

PQRS

REC/OTR

REC MONITOR

MENU/LIST

CLEAR/C.RESET

MODE

ENTER

DISPLAY

TUV WXYZ

DVD

ONE TOUCH

DUBBING

2 2

Note : MP3 Playback

• The audio source of MP3 files cannot be recorded as digital sound by an MD or DAT deck.

• Files whose extension is other than “.mp3 (MP3)” will not be listed in the MP3 menu.

• Some unplayable folders or tracks may be listed in the MP3 menu due to the recording status.

DVD-V

MP3

List of MP3 Files

DISC NAME

FOLDER NAME 1 FOLDER NAME 2 FOLDER NAME 3 FOLDER NAME 4 FOLDER NAME 5 FOLDER NAME 6 1 FILE NAME 1 2 FILE NAME 2

1/2

Basic playback (cont’d)

Playing discs

Changing the SETUP menu

Playing discs VCR functions

Before you start

Connections Getting started

Recording Editing Others

Español

Note : DVD Disc Menu

• Menus vary among discs.

Refer to the information accompanying the disc for details.

Playing discs using the disc menu

A DVD disc contains a disc menu that describes the contents or allows you to customize the playback. For example, the menu may offer choices for subtitle languages, special features, or chapter selection. Sometimes these are displayed automatically when you start playback, sometimes they only appear when you press MENU/LIST button.

First:

Press MENU/LIST button.

The DVD main menu will appear.

If the feature is not available on the DVD disc, may appear on the TV screen.

Select an item using K/ L/

{ / B buttons, then press

ENTER button to confirm.

Continue this step to set up all the features you want or to start playing the disc from the menu.

MENU/LIST button:

Displays a DVD disc menu which varies with the disc and may be the same as the ‘Title menu.’

K/ L/ { / B buttons:

Moves the cursor around screen.

Enter button:

Selects the currently highlighted menu option.

Number buttons:

Selects a numbered menu option (some discs only). Press ENTER button after.

Press MENU/LIST button to exit the menu.

DVD-V

DVD

POWER

REC SPEED

.@/:

ABC DEF

123

GHI JKL MNO

456

PQRS

TUV WXYZ

7809

SPACE

VCR

DISPLAY

PLAY

STOP

SETUP

REC/OTR

REC MONITOR

MENU/LIST

TOP MENU

ZOOM SKIP SKIP

CLEAR/C.RESET

CM SKIP

MODE

AUDIO

DVD

ENTER

OPEN/CLOSE

VIDEO/TV

SLOW

PAUSE

TIMER PROG.

RETURN

ONE TOUCH

DUBBING

Basic playback (cont’d)

Playing discs

Note : DVD Disc Menu

• The TOP MENU button will

not always active with all DVDs.

• Menus vary among discs.

Refer to the information accompanying the disc for details.

Playing discs using the title menu

Some DVDs have a title menu, which lists the titles available. It allows you to start playback at a specific title.

First:

Press TOP MENU button.

The title menu will appear.

If the feature is not available on the DVD disc, may appear on the TV screen.

Select a title to play using the

K/ L/ { / B buttons, then

press ENTER button.

Playback will begin at the title you selected.

TOP MENU button:

Displays the ‘Title menu’ of a DVD disc which varies with the disc.

K/ L/ { / B buttons:

Moves the cursor around screen.

Enter button:

Selects the currently highlighted menu option.

Number buttons:

Selects a numbered menu option (some discs only). Press ENTER button after.

Press TOP MENU button to exit the title menu.

DVD-V

DVD

POWER

REC SPEED

.@/:

ABC DEF

123

GHI JKL MNO

456

PQRS

TUV WXYZ

7809

SPACE

VCR

DISPLAY

PLAY

STOP

SETUP

REC/OTR

REC MONITOR

MENU/LIST

TOP MENU

ZOOM SKIP SKIP

CLEAR/C.RESET

CM SKIP

MODE

AUDIO

DVD

ENTER

OPEN/CLOSE

VIDEO/TV

SLOW

PAUSE

TIMER PROG.

RETURN

ONE TOUCH

DUBBING

Special playback

Playing discs

Changing the SETUP menu

Playing discs VCR functions

Before you start

Connections Getting started

Recording Editing Others

Español

Resume play

You can resume play from where you stopped playing the disc last.

During playback, press STOP C button.

The resume message will appear.

TV Screen:

Press PLAY B button.

In a few seconds, playback will resume from the point at which it stopped last.You can resume play at the same point even if you turn off the unit.

To cancel the resume play and start playing the disc from the beginning, press STOP

C button the second time while the playback is stopped.

Fast forward / Fast reverse

During playback, press D or E button.

Every time you press D or E button, approximate speed will be changed as follows. (For DVD discs, the sound will be output during playback in fast forward of x2 only if you set “Fast Forward with Audio” to “ON” for the “Playback” setting in the SETUP menu.)

For Audio CDs, approximate speed is set at x

8 with sound. For MP3 files, approximate speed is set at x16. To r eturn to the normal playback, press PLAY

B button.

Note : Slow Speed

•Forward/reverse speed will be indicated with icons as follows. Forward (Approx. Speed) x

2: x20: x

40: Reverse (Approx. Speed) x

5: x

20:

40:

POWER

REC SPEED

AUDIO

OPEN/CLOSE

TOP MENU

SPACE

VCR

SETUP

TIMER PROG.

RETURN

123

456

7809

STOP

PLAY

VIDEO/TV

SLOW

PAUSE

.@/:

ABC DEF

GHI JKL MNO

PQRS

REC/OTR

REC MONITOR

MENU/LIST

ENTER

DISPLAY

TUV WXYZ

DVD

Note : MP3

•For MP3 files, playback will resume from the beginning of the track at which playback

was stopped.

DVD-V

DVD-RW

DVD-R

Video

DVD-RW

MP3

POWER

REC SPEED

.@/:

ABC DEF

123

GHI JKL MNO

456

PQRS

TUV WXYZ

7809

SPACE

VCR

DISPLAY

PLAY

STOP

SETUP

REC/OTR

REC MONITOR

MENU/LIST

TOP MENU

ZOOM SKIP SKIP

CLEAR/C.RESET

CM SKIP

MODE

AUDIO

DVD

ENTER

OPEN/CLOSE

VIDEO/TV

SLOW

PAUSE

TIMER PROG.

RETURN

ONE TOUCH

DUBBING

Resume ON

DVD-V

DVD-R

Video

DVD-RW

MP3

x20

Normal

speed

playback

x2 x20x5 x40x40

Special playback (cont’d)

Playing discs

Skipping TV commercials during play

You can skip TV commercials by pressing CM SKIP button, so that you can enjoy the recorded programs with limited interruption.

During playback, press CM SKIP button.

Normal playback will resume at 30 seconds ahead from the point when you press CM SKIP button. Every time you press CM SKIP button, time will advance

30 seconds ahead. You can press up to

6 times (180

seconds).

e.g. Press CM SKIP button once

(forwarding

30 seconds.)

Playback will resume automatically.

Pause

During playback, press PAUSE

F button.

Playback will pause and sound will be muted.

Press PLAY B button to resume play.

7809

POWER

REC SPEED

AUDIO

ZOOM SKIP SKIP

OPEN/CLOSE

TOP MENU

SPACE

VCR

SETUP

CM SKIP

TIMER PROG.

RETURN

123

456

7809

STOP

PLAY

VIDEO/TV

SLOW

PAUSE

.@/:

ABC DEF

GHI JKL MNO

PQRS

REC/OTR

REC MONITOR

MENU/LIST

CLEAR/C.RESET

MODE

ENTER

DISPLAY

TUV WXYZ

DVD

ONE TOUCH

DUBBING

DVD-R

Video

DVD-RW

CM Skip 30 sec.

DISPLAY

REC/OTR

REC MONITOR

MENU/LIST

CLEAR/C.RESET

MODE

SPACE

VCR

DVD

PLAY

STOP

SETUP

TOP MENU

CM SKIP

TIMER PROG.

ENTER

ZOOM SKIP SKIP

ONE TOUCH

DUBBING

SLOW

PAUSE

RETURN

DVD-V

DVD-RW

DVD-R

Video

DVD-RW

MP3

Special playback (cont’d)

Playing discs

Changing the SETUP menu

Playing discs VCR functions

Before you start

Connections Getting started

Recording Editing Others

Español

Step by step playback

During playback, press PAUSE

F button.

Playback will pause and sound will be muted.

Press SKIP G button repeatedly.

Playback will advance one frame (or step) at a time when you press the skip

button with the

sound muted.

To play step by step backward:

Press SKIP H button repeatedly. Every time you press the button, playback will go backward by one frame.

Press PLAY B button to resume play.

Slow forward / Slow reverse play

During playback, press PAUSE k button, then press D or E button.

Every time you press D or E button, approximate speed will be changed as follows. (The sound will remain mute.)

To r eturn to the normal playback, press PLAY

B button.

Note : Slow Speed

•Forward/reverse speed will be indicated with icons as follows. Forward (Approx. Speed) x1/16: x1/8: x1/2: Reverse (Approx. Speed) x1/16: x1/8: x1/4:

POWER

REC SPEED

AUDIO

OPEN/CLOSE

TOP MENU

SPACE

VCR

SETUP

TIMER PROG.

RETURN

123

456

7809

STOP

PLAY

VIDEO/TV

SLOW

PAUSE

.@/:

ABC DEF

GHI JKL MNO

PQRS

REC/OTR

REC MONITOR

MENU/LIST

ENTER

DISPLAY

TUV WXYZ

DVD

DVD-V

DVD-RW

DVD-R

Video

DVD-RW

DISPLAY

REC/OTR

REC MONITOR

MENU/LIST

CLEAR/C.RESET

MODE

SPACE

VCR

DVD

PLAY

STOP

SETUP

TOP MENU

ZOOM SKIP SKIP

CM SKIP

TIMER PROG.

ENTER

ONE TOUCH

SLOW

PAUSE

RETURN

DUBBING

DVD-V

DVD-R

Video

DVD-RW

x1/8

Pause

x1/16 x1/8x1/16 x1/2x1/4

Special playback (cont’d)

Playing discs

Note : Zoom

•When selecting a smaller factor than the current one, the zoom area will not be displayed.

•To remove the zoom menu, press ZOOM button again at step 1.

•To cancel the zoom function, select x1.0 using { / B buttons,

then press ENTER button.

Zoom

During playback, press ZOOM button.

Zoom menu will appear.

Screen:

There are four options (x

1.0,x1.2,x1.5 and x2.0), these are displayed excluding the current zoom rate.

Select a desired zoom factor using { / B buttons, then press ENTER button.

The zoom area will be displayed.

Select a desired zoom position using

K / L / { / B buttons, then

press ENTER button.

The zoom play will start.

2 3

Marker Setup

This feature allows you to assign a specific point on a disc to be recalled later.

During playback, press DISPLAY button.

The display menu will appear.

Screen:

Select icon using { / B buttons, then press ENTER button.

Marker setup menu will appear.

Screen for DVD:

Screen for CD:

Select a desired marker number using { / B buttons. When reaches the desired point, press ENTER button.

To r eturn to the marker later, select the desired marker number using { / B buttons, then press ENTER button.

Note : Marker

•To clear a marker, select the marker number to be cleared, then press CLEAR/C.RESET button.

• All markers will be erased when you do the following.

– Opening the disc tray. – Turning off the power.

– Recording to a recordable

disc.

–

Changing the mode between Original and Playlist.(VR mode)

•You can mark up to 6 points.

POWER

REC SPEED

AUDIO

ZOOM SKIP SKIP

OPEN/CLOSE

TOP MENU

SPACE

VCR

SETUP

CM SKIP

TIMER PROG.

RETURN

123

456

7809

STOP

PLAY

VIDEO/TV

SLOW

PAUSE

.@/:

ABC DEF

GHI JKL MNO

PQRS

REC/OTR

REC MONITOR

MENU/LIST

CLEAR/C.RESET

MODE

ENTER

DISPLAY

TUV WXYZ

DVD

ONE TOUCH

DUBBING

3 4

DVD-V

DVD-RW

DVD-R

Video

DVD-RW

01:23:45

x1.2 x1.5 x2.0

DVD-V

DVD-RW

DVD-R

DVD-Video

Video

DVD-RW

1101:23:45

1 2 3 4 5 6

DVD-Video

STOP

REC/OTR

REC MONITOR

TOP MENU

MENU/LIST

CLEAR/C.RESET

CM SKIP

MODE

SETUP

TIMER PROG.

ENTER

RETURN

ZOOM SKIP SKIP

ONE TOUCH

DUBBING

1101:23:45

DVD-Video

1 01:23:45

1 2 3 4 5 6

Audio CD

Changing the SETUP menu

Playing discs VCR functions

Before you start

Connections Getting started

Recording Editing Others

Español

Playing discs

Title/Chapter search

Using SKIP H / G buttons

During playback, press SKIP G button to skip the cur-

rent title or chapter and move to the next.

The title or chapter will move forward one at a time.

To go back to the previous title or chapter, press SKIP

H button.The title or chapter will move backward one title at a time.

Using DISPLAY button

During playback, press DISPLAY button.

The display menu will appear.

Screen:

Select icon using { / B buttons, then press ENTER button.

‘T’ for title will be highlighted.

Title: Enter a desired title number to search using

K/ L buttons

or number buttons, then press ENTER button.

Title search will start.

Chapter:

To move to ‘C’ for chapter, press B button.

Enter a desired chapter number to search using

K/ L but-

tons or number buttons, then press ENTER button.

Chapter search will start.

DVD-V

DVD-RW

DVD-R

Video

DVD-RW

1101:23:45

DVD-Video

POWER

REC SPEED

.@/:

ABC DEF

123

GHI JKL MNO

456

PQRS

TUV WXYZ

7809

SPACE

VCR

DISPLAY

PLAY

STOP

SETUP

REC/OTR

REC MONITOR

MENU/LIST

TOP MENU

ZOOM SKIP SKIP

CLEAR/C.RESET

CM SKIP

MODE

AUDIO

DVD

ENTER

OPEN/CLOSE

VIDEO/TV

SLOW

PAUSE

TIMER PROG.

RETURN

ONE TOUCH

DUBBING

Search (cont’d)

Playing discs

Track search

Using SKIP H / G buttons

During playback, press SKIP G button to skip the cur-

rent track and move to the next.

The track will move forward one at a time.

To go back to the previous track, press SKIP

H button.The track will move backward one track at a time.

Using DISPLAY button

During playback, press DISPLAY button.

The display menu will appear.

Screen:

Select icon using { / B buttons, then press ENTER button.

‘T’ for track will be highlighted.

Enter a desired track number to search using

K / L buttons or number buttons, then press ENTER button.

Track search will start.

POWER

REC SPEED

AUDIO

ZOOM SKIP SKIP

OPEN/CLOSE

TOP MENU

SPACE

VCR

SETUP

CM SKIP

TIMER PROG.

RETURN

123

456

7809

STOP

PLAY

VIDEO/TV

SLOW

PAUSE

.@/:

ABC DEF

GHI JKL MNO

PQRS

REC/OTR

REC MONITOR

MENU/LIST

CLEAR/C.RESET

MODE

ENTER

DISPLAY

TUV WXYZ

DVD

ONE TOUCH

DUBBING

Time search

During playback, press DISPLAY button.

The display menu will appear.

Screen for DVD:

Screen for CD:

Select icon using { / B buttons, then press ENTER button.

‘T’ for title or track will be highlighted.

To move to the clock icon , press

B button.

Enter a desired time to search using

K / L buttons or number buttons, then press ENTER button.

Time search will start.

Note :Time Search

• Time search function is available only in the same track or

title.

MP3

1 01:23:45

Audio CD

POWER

REC SPEED

.@/:

ABC DEF

123

GHI JKL MNO

456

PQRS

TUV WXYZ

7809

SPACE

VCR

DISPLAY

PLAY

STOP

SETUP

REC/OTR

REC MONITOR

MENU/LIST

TOP MENU

ZOOM SKIP SKIP

CLEAR/C.RESET

CM SKIP

MODE

AUDIO

DVD

ENTER

OPEN/CLOSE

VIDEO/TV

SLOW

PAUSE

TIMER PROG.

RETURN

ONE TOUCH

DUBBING

DVD-V

DVD-RW

DVD-R

1101:23:45

1 01:23:45

Video

DVD-RW

DVD-Video

Audio CD

Changing the SETUP menu

Playing discs VCR functions

Before you start

Connections Getting started

Recording Editing Others

Español

Repeat/Random/Program play

Playing discs

Note : Repeat

• The A-B Repeat playback can only be set with in the current title (for DVDs), or current track (for Audio CDs).

•To cancel repeat playback, select OFF at step 2.

•You cannot select “Group” during the random playback

of MP3 files.

Repeat play

During playback, press DISPLAY button.

The display menu will appear.

Select icon using {/ Bbuttons, then press ENTER button.

Repeat menu will appear.

Screen:

Select a desired option to repeat using K / L buttons, then press ENTER button.

The selected repeat play will start.

Title:

The current title will be played repeatedly. (DVD only)

Chapter:

The current chapter will be played repeatedly. (DVD only)

All:

The current disc will be played repeatedly. CD, MP3 and DVDRW (VR mode only)

A-B:

The A-B point will be played repeatedly. When pressing ENTER button while A-B is highlighted, the starting point (A) will be decided.

Press ENTER button again to select the ending point (B).

Track:

The current track will be played repeatedly. (CD, MP3 only)

Group:

The current group will be played repeatedly. (MP3 only)

2 3

Note : Stop

•To cancel random playback, press STOP C button twice

during random playback.

Random play

With this function, you can play a disc randomly instead of playing in the order on the disc.

First:

Press SETUP button to display SETUP/CD menu.

SETUP/CD menu will appear.

Screen:

Select “CD” using { / B but- tons, then press ENTER button.

CD Playback Mode menu will appear.

Select “Random Play” using K / L buttons, then press ENTER button.

Random playback will start.

DVD-V

DVD-RW

DVD-R

Video

DVD-RW

MP3

1101:23:45

DVD-Video

1101:23:45

OFF Title Chapter A-B

DVD-Video

POWER

REC SPEED

.@/:

123

GHI JKL MNO

456

PQRS

7809

SPACE

DISPLAY

AUDIO

ABC DEF

TUV WXYZ

VCR

DVD

OPEN/CLOSE

VIDEO/TV

SLOW

PAUSE

PLAY

STOP

SETUP

REC/OTR

REC MONITOR

TOP MENU

MENU/LIST

CLEAR/C.RESET

CM SKIP

MODE

TIMER PROG.

ENTER

RETURN

ZOOM SKIP SKIP

ONE TOUCH

DUBBING

MP3

DVD

Setup Menu

CD Playback Mode

Random Play

Program Play

PLAY

STOP

DVD

ENTER

VIDEO/TV

SLOW

PAUSE

TIMER PROG.

RETURN

ONE TOUCH

DUBBING

PQRS

7809

SPACE

DISPLAY

SETUP

REC/OTR

REC MONITOR

TOP MENU

MENU/LIST

ZOOM SKIP SKIP

CLEAR/C.RESET

CM SKIP

MODE

TUV WXYZ

VCR

Repeat/Random/Program play (cont’d)

Playing discs

Note : Program Playback

•To erase tracks you selected, press CLEAR/C.RESET button.

•You can make up to 50 program settings.

•To cancel program playback, press STOP C button twice during program playback.

•You may also select a desired track using Number buttons

at step 4.

Program play

You can program the disc to play tracks in your desired order.

First:

Press SETUP button to display SETUP/CD menu.

SETUP/CD menu will appear.

Screen:

Select “CD” using { / B but- tons, then press ENTER button.

CD Playback Mode menu will appear.

Select “Program Play” using K / L buttons, then press

ENTER button.

Program play list will appear.

Select a desired track using K / L buttons, then press ENTER button or

B button.

A cursor will move to the next.

Press PLAY B button to start program playback.

Program playback will start.

2 3

DVD

Setup Menu

CD Playback Mode

Random Play

Program Play

CD Playback Mode > Program Play

- - - - - - - - - - - - - - - - - - - -

Total 00:00:00

CD Playback Mode > Program Play

- - - - - - - - - - - - - -- -- -

- -

- - - - - - - - - - - - - -- -- -

- -

- - - - - - - - - - - - - -- -- -

- -

- - - - - - - - - - - - - -- -- -

- -

Total 00:04:30

POWER

REC SPEED

.@/:

ABC DEF

123

GHI JKL MNO

456

PQRS

TUV WXYZ

7809

SPACE

VCR

DISPLAY

PLAY

STOP

SETUP

REC/OTR

REC MONITOR

MENU/LIST

TOP MENU

ZOOM SKIP SKIP

CLEAR/C.RESET

CM SKIP

MODE

AUDIO

DVD

ENTER

OPEN/CLOSE

VIDEO/TV

SLOW

PAUSE

TIMER PROG.

RETURN

ONE TOUCH

DUBBING

Changing the SETUP menu

Playing discs VCR functions

Before you start

Connections Getting started

Recording Editing Others

Español

Selecting audio and video formats

Playing discs

Note : Dual Audio Sound

Tracks

•

Some discs will only allow you to change the soundtrack from the disc’s menu. Press TOP MENU button or MENU/LIST button to display the disc’s menu.

•

On DVD-RW discs recorded in VR mode that may have both a main and a sub audio channel, you can switch to main (L), sub audio (R) or a mix of both (L/R).

You can select an audio or video format as you prefer depending on the contents of the disc you are playing.

Switching audio soundtrack

When playing a DVD-Video disc recorded with two or more soundtracks (these are often in different languages), you can switch between them anytime during playback. On DVD-RW discs recorded in VR mode, you can switch to main (L), sub audio (R) or a mix of both (L/R).

During playback, press DISPLAY button.

The display menu will appear.

Screen:

Select icon using { / B buttons, then press ENTER button.

Audio menu will appear.

<DVD-Video>

<DVD-RW VR mode>

Select a desired audio soundtrack using

K / L buttons,

then press ENTER button.

<DVD-Video>

Audio soundtrack will switch.

<DVD-RW VR mode>

Select a desired audio channel using

K / L buttons, then

press ENTER button.

Audio channel will switch.

Important

•

This unit CANNOT record in both stereo and SAP (Secondary Audio Program) at the same time.

DVD-V

DVD-RW

1100:00:00

1 Dolby Digital Dual L/R 2 Dolby Digital 2ch ----

DVD-RW VR Original

1101:23:45

DVD-Video

L/R L R

DVD-RW VR Original

1100:00:00

1 Dolby Digital Dual 2 Dolby Digital 2ch

POWER

REC SPEED

.@/:

ABC DEF

123

GHI JKL MNO

456

PQRS

TUV WXYZ

7809

SPACE

VCR

DISPLAY

PLAY

STOP

SETUP

REC/OTR

REC MONITOR

MENU/LIST

TOP MENU

ZOOM SKIP SKIP

CLEAR/C.RESET

CM SKIP

MODE

AUDIO

DVD

ENTER

OPEN/CLOSE

VIDEO/TV

SLOW

PAUSE

TIMER PROG.

RETURN

ONE TOUCH

DUBBING

1100:00:00

1 Dolby Digital 5.1ch English 2 Dolby Digital 2ch Japanese

DVD-Video

Selecting audio and video formats (cont’d)

Playing discs

Note : Subtitle

• Some discs will only allow you to change the subtitle from the disc’s menu. Press TOP MENU button or MENU/LIST button to display

the disc’s menu.

When playing Audio CDs or MP3 files you can switch between stereo, just the left channel or just the right channel.

During playback, press DISPLAY button.

The display menu will appear.

Screen:

Select icon using { / B buttons, then press ENTER button.

Audio menu will appear.

Select a desired audio channel using

K / L buttons, then

press ENTER button.

Audio channel will switch.

Switching subtitles

Many DVD Video discs have subtitles in one or more languages. The case usually tells you which subtitle languages are available.

During playback, press DISPLAY button.

The display menu will appear.

Screen:

Select icon using { / B buttons, then press ENTER button.

Subtitle menu will appear.

Select a desired subtitle language using

K / L buttons,

then press ENTER button.

Subtitle will be displayed in the selected language.

When selecting “OFF,” subtitle will disappear.

POWER

REC SPEED

AUDIO

ZOOM SKIP SKIP

OPEN/CLOSE

TOP MENU

SPACE

VCR

SETUP

CM SKIP

TIMER PROG.

RETURN

123

456

7809

STOP

PLAY

VIDEO/TV

SLOW

PAUSE

.@/:

ABC DEF

GHI JKL MNO

PQRS

REC/OTR

REC MONITOR

MENU/LIST

CLEAR/C.RESET

MODE

ENTER

DISPLAY

TUV WXYZ

DVD

ONE TOUCH

DUBBING

2 3

Important

•You can switch subtitle languages anytime during playback.

MP3

1 00:00:00

Audio CD

1 00:00:00

L/R L R

Audio CD

DVD-V

DVD-RW

1101:23:45

DVD-Video

1100:00:00

OFF 1 English 2 Japanese

DVD-Video

OPEN/CLOSE

AUDIO

ABC DEF

PLAY

STOP

DVD

ENTER

VIDEO/TV

SLOW

PAUSE

TIMER PROG.

RETURN

ONE TOUCH

DUBBING

TUV WXYZ

VCR

ZOOM SKIP SKIP

POWER

REC SPEED

.@/:

123

GHI JKL MNO

456

PQRS

7809

SPACE

DISPLAY

SETUP

REC/OTR

REC MONITOR

MENU/LIST

TOP MENU

CLEAR/C.RESET

CM SKIP

MODE

Changing the SETUP menu

Playing discs VCR functions

Before you start

Connections Getting started

Recording Editing Others

Español

Selecting audio and video formats (cont’d)

Playing discs

Switching camera angles

Some DVD Video discs feature scenes shot from two or more angles, check the DVD disc brochure for details: It should be marked with an angle icon if it contains multi-angle scenes.

During playback, press DISPLAY button.

The display menu will appear.

Screen:

Angle icon appears when an additional camera angle is available.

Select icon using { / B buttons, then press ENTER button.

Angle will switch each you press ENTER button.

Reducing block noise

During playback, press DISPLAY button.

The display menu will appear.

Screen:

Select icon using

{ / B buttons, then press ENTER button.

Noise Reduction menu will appear

Select a desired option using K / L buttons, then press ENTER button.

Your setting will be activated. This function reduces noise in the

playback picture.When playing back discs recorded in long time mode such as SLP or SEP mode, select "Type

1" or "Type 2". ("Type 2" is more effective.) When playing back discs with little noise such as prerecorded DVD-Video discs, select "OFF".

POWER

REC SPEED

AUDIO

ZOOM SKIP SKIP

OPEN/CLOSE

TOP MENU

SPACE

VCR

SETUP

CM SKIP

TIMER PROG.

RETURN

123

456

7809

STOP

PLAY

VIDEO/TV

SLOW

PAUSE

.@/:

ABC DEF

GHI JKL MNO

PQRS

REC/OTR

REC MONITOR

MENU/LIST

CLEAR/C.RESET

MODE

ENTER

DISPLAY

TUV WXYZ

DVD

ONE TOUCH

DUBBING

2 3

Important

• It has to be during playback.

DVD-V

1101:23:45

DVD-Video

POWER

REC SPEED

.@/:

ABC DEF

123

GHI JKL MNO

456

PQRS

TUV WXYZ

7809

SPACE

VCR

DISPLAY

PLAY

STOP

SETUP

REC/OTR

REC MONITOR

MENU/LIST

TOP MENU

ZOOM SKIP SKIP

CLEAR/C.RESET

CM SKIP

MODE

AUDIO

DVD

ENTER

OPEN/CLOSE

VIDEO/TV

SLOW

PAUSE

TIMER PROG.

RETURN

ONE TOUCH

DUBBING

DVD-V

DVD-RW

DVD-R

1101:23:45

Video

DVD-RW

DVD-Video

1100:00:00

OFF Type 1 Type 2

DVD-Video

Playback

VCR functions

Recording

Press POWER button on the remote control or the front panel of the unit.

When you are playing a tape, turn the TV on and be sure to select the input to which the DVD/VCR is connected.

Press:

Insert a prerecorded tape, then press PLAY

B button to

begin playback.

During playback, press PAUSE

F button.

Playback will pause and sound will be muted.

Press PLAY B button to resume play.

Press STOP C button to stop playback.

Press STOP/EJECT CAbut- ton on the front panel of the unit to eject the tape.

VCR

Note : No Record Tab

•When a tape without record tab is inserted, the unit will start playback automatically.

•Tracking will be automatically adjusted upon playback.To adjust the tracking manually, press the CHANNEL K/L buttons on the front panel of the unit or CHK/CHL but-

tons on the remote control.

POWER

REC SPEED

AUDIO

OPEN/CLOSE

SPACE

VCR

SETUP

TIMER PROG.

123

456

7809

STOP

PLAY

VIDEO/TV

SLOW

PAUSE

.@/:

ABC DEF

GHI JKL MNO

PQRS

REC/OTR

DISPLAY

TUV WXYZ

DVD

2 4

Recording and One-touch timer recording

Before recording, make sure:

•

The desired channel is selected by pressing Number buttons on the remote control or CHANNEL

K/L

buttons on the front

panel of the unit.

•

There is a tape with a record tab in the DVD/VCR.

•

The desired recording speed is selected in SP (standard play) or SLP (super long play) mode by pressing REC SPEED button on the remote control.

Recording speed:

•

Stereo or SAP is selected.

•

Refer to page 64 for instructions on timer recording.

First:

Press REC/OTR button to begin the recording.

To temporarily stop recording or to resume it, press PAUSE

F button. After the unit has been in Pause mode for

5 minutes, it will stop automatically to protect the tape and the video head from damage.

Press STOP button when the recording is completed.

Note : Record View

channels

•To view one channel while recording another

1) While you are recording on the unit, press VIDEO/TV button.

2) At the cable box or satellite box, select the channel you want to view. If you have connected the unit to a cable box or satellite box, refer to “Connection to a Cable Box or Satellite Box” section on page 11.

• If OTR is finished in VCR during playback or REC mode in DVD, the VCR will be in STOP mode and the DVD keeps the current mode.

SPACE

VCR

SETUP

TIMER PROG.

STOP

PLAY

SLOW

PAUSE

REC/OTR

REC MONITOR

ENTER

DISPLAY

DVD

Ta pe speed

Type of tape T160T120

Recording/Playback Time

T60

2-2/3

hours2hours1hourSP mode

8hours6hours3hoursSLP mode

Accidental erasure prevention

To prevent accidental recording on a recorded cassette, remove its record tab.To record on it later, cover the hole with cellophane tape.

Record tab

VCR

Recording and One-touch timer recording (cont’d)

VCR functions

Changing the SETUP menu

Playing discs VCR functions

Before you start

Connections Getting started

Recording Editing Others

Español

This feature allows you to set the recording length simply by pressing REC/OTR button on the remote control or the front panel of the unit.

First:

During normal recording, press REC/OTR button to begin one-touch timer recording.

You can select a fixed recording length by pressing the REC/OTR button repeatedly.

When one-touch timer recording is finished, the unit will turn off automatically.

To cancel the one-touch timer recording within the specified time, press STOP

C button.

One-touch timer recording

An index mark will be assigned at the beginning of each recording you make.You may skip to a specific marked point by following the steps below.

First:

Press SEARCH MODE button twice so that the index search menu appears.

Enter the number of recordings you wish to skip using Number buttons with in 30 seconds.

Press g/h buttons to start index search.

If you want to go in the forward direction, press

g button.

If you want to go in the reverse direction, press

h button. After index search, the VCR will play the tape automatically.

INDEX SEARCH

Index search

POWER

REC SPEED

AUDIO

ZOOM SKIP SKIP

OPEN/CLOSE

TOP MENU

SPACE

VCR

SETUP

CM SKIP

TIMER PROG.

RETURN

123

456

7809

STOP

PLAY

VIDEO/TV

SLOW

PAUSE

.@/:

ABC DEF

GHI JKL MNO

PQRS

REC/OTR

REC MONITOR

MENU/LIST

CLEAR/C.RESET

MODE

ENTER

DISPLAY

TUV WXYZ

DVD

ONE TOUCH

DUBBING

Note : Index Mark

•Every time a tape is recorded, an index mark is written on

the tape.

Note: OTR

• The remaining recording time will appear on the display panel during an OTR. Press DISPLAY button to see it on the TV screen.

•You cannot pause an OTR.

VCR

(Normal recording)

(0:30) (1:00)

(7:30)(8:00)

DISPLAY

REC/OTR

REC MONITOR

MENU/LIST

SPACE

VCR

SETUP

TOP MENU

PLAY

STOP

DVD

ENTER

SLOW

PAUSE

TIMER PROG.

RETURN

VCR

CURRENT PROGRAM Beginning of tape

Pro. 1 Pro. 2 Pro. 3

02 01 01

Pro. 4 Pro. 5

02 03

INDEX MARK

End of tape

Search (cont’d)

VCR functions

Time search

Note :Tape Search

• These functions are not available during recording.

•Press STOP button to stop the search.

• If the end of the tape is reached during a Search, this unit will cancel the search and rewind the tape.

POWER

REC SPEED

AUDIO

ZOOM SKIP SKIP

OPEN/CLOSE

TOP MENU

SPACE

VCR

SETUP

CM SKIP

TIMER PROG.

RETURN

123

456

7809

STOP

PLAY

VIDEO/TV

SLOW

PAUSE

.@/:

ABC DEF

GHI JKL MNO

PQRS

REC/OTR

REC MONITOR

MENU/LIST

CLEAR/C.RESET

MODE

ENTER

DISPLAY

TUV WXYZ

DVD

ONE TOUCH

DUBBING

This feature allows you to go to a specific point on a tape by entering the exact amount of time you wish to skip in order to reach the point.

First:

Press SEARCH MODE button repeatedly so that the Time search menu appears.

Enter your desired time to skip using Number buttons with in 30 seconds.

Press g/h buttons to start time search.

If you want to go in the forward direction, press

g button.

If you want to go in the reverse direction, press

h button. After time search, the unit will play the tape automatically.

TIME SEARCH

2:50

VCR

Other operations

VCR functions

Changing the SETUP menu

Playing discs VCR functions

Before you start

Connections Getting started

Recording Editing Others

Español

First:

To cue or review picture during playback (Picture Search):

Press g/h buttons during playback. Press it again and the unit will search in super high speed. (in the SLP mode only)

To freeze the picture on TV screen during playback (Still mode):

Press PAUSE F button. Each time you press the button, the picture will be forwarded by one frame.

If the picture begins to vibrate vertically during the still mode, stabilize the picture by pressing the CHANNEL

K/L or CHK/CHL buttons. If the picture is distorted or rolling vertically, adjust the vertical hold control on your TV, if equipped.

Counter Reset:

Press CLEAR/C.RESET button.

To playback in slow motion:

Press SLOW button during playback or the still mode. If the noise bars appear on the TV screen, you can reduce it by pressing CHANNEL

K/L or CHK/CHL buttons.

When you playback a tape recorded in Hi-Fi stereo:

Press AUDIO button on the remote control to select HIFI or MONO for playback sound mode.

• If you have connected a stereo TV to this unit, select “HIFI”.

• If you have connected a monaural TV to this unit, select “MONO”.

Note : Pause Mode

•Still/Slow/Pause mode will be automatically cancelled after 5 minutes to prevent damage to the tape and the video head.

•To return to playback from the Picture Search/Still/Slow mode, press PLAY button.

VCR

Your Selection

Type of recorded tape

non Hi-Fi tapes

Hi-Fi tapes

recorded in

Hi-Fi stereo

Hi-Fi tapes

recorded main

audio program

Hi-Fi tapes

recorded second

audio program

Second audio

Monaural

Main audio

program

HIFI

R-channelL-channel

Monaural

Main audio

program

Second audio

program

MONO

Monaural

L+R

Main audio

program

Second audio

program

Easy DVD recording

Recording

The following will help you to understand easily how to record to DVD discs.

Note:

Make sure batteries are in the remote control and you have connected this unit to the TV correctly.

Step 3:

Select the

Recording speed

Step 1: Choose a disc

type

There are several types of recordable DVD discs to choose from. Choose a recordable DVD disc type based on your playing/recording/editing requirements. See “DVD disc type” below.

This unit can record on the following type of discs only.

(or)

* This unit cannot record on the fol-

lowing discs.

•DVD-R General Ver 2.0 / 8x

•DVD-RW Ver 1.2 / 2-4x CPRM compatible

For example, when you want to record repeatedly on the same disc, or when you want to edit the disc after recording, select the rewritable DVD-RW type disc.

When you want to save recordings without any alteration, a nonrewritable DVD-R can be your choice.

Step 2:

Insert

a blank disc

Remote Control

Open the disc tray

Close the disc tray

Important

Format the disc

Insert the disc in the unit. Then format the disc from SETUP menu.Video format (Video mode) or Video recording format (VR mode) will be available depending on the disc type inserted.

This is necessary to prepare the disc for recording. Details are on pages 58-60.

* When you format, the entire contents on that disc will be erased.

DVD disc types

16 9

Turn on the unit

This operation may take a moment to be recognized.

Select the DVD mode

Select the recording speed

You will need to finalize the discs recorded in Video mode to play in other DVD players.

REC SPEED

ABC DEF

AUDIO

OPEN/CLOSE

POWER

.@/:

123

POWER

REC SPEED

.@/:

123

POWER

REC SPEED

.@/:

ABC DEF

123

GHI JKL MNO

456

PQRS

TUV WXYZ

7809

SPACE

VCR

DISPLAY

PLAY

STOP

OPEN/CLOSE

AUDIO

VIDEO/TV

SLOW

DVD

PAUSE

SP 2:01 Rem.

Easy DVD recording (Cont’d)

Recording

Changing the SETUP menu

Playing discs VCR functions

Before you start

Connections Getting started

Recording Editing Others

Español

Step 5:Press

REC/OTR

Step 4: Select the

desired channel

Step 6: Stop the

Recording

Playing the recorded contents

You can select the title you want to play from the displayed menu and immediately start to play. Recorded contents are very accessible on a disc, the procedure is really simple as you choose a title on a chapter from the menu screen.

What are titles and chapters?

The contents of DVD disc are generally divided into titles. Titles may be further subdivided into chapters.

Editing the recorded disc

You will find editing discs very easy.This unit offers convenient edit functions, which are possible only with DVD-R/RW discs.

You can edit the following from a title list.

• Putting names on titles

• Setting pictures for thumbnails (VR mode)

• Setting/clearing chapter markers

• Deleting parts of titles or scenes (VR mode)

Title Delete :This deletes an entire scene permanently from the disc. Scene Delete :This allows a user to edit within a specific scene (ex. commercials).

Original and Playlist (VR mode)

You can edit the recordings in Playlist without changing the original recordings. A Playlist does not take up much disc space.

What “Original” or “Playlist” is for?

Throughout this manual, you will find Original and Playlist to refer to the actual content and the edited version.

• Original content refers to what’s actually recorded on the disc.

• Playlist content refers to the edited version of the disc; how the Original content is to be played.

This operation may take a few minutes to complete.

Finalizing a Disc

• This will allow a disc that is recorded on our unit to be played back on a different DVD player- without finalization it will not be playable on another player.

•

After finalizing a disc if the recording was in video mode, you can not edit any information that is on that disc.

• If you have recorded in VR mode on DVD-RW disc then editing is still permitted after finalizing.

REC SPEED

ABC DEF

TUV WXYZ

SPACE

VCR

AUDIO

DVD

OPEN/CLOSE

VIDEO/TV

SLOW

PAUSE

CH 1

POWER

.@/:

123

GHI JKL MNO

456

PQRS

7809

DISPLAY

GHI JKL MNO

456

PQRS

TUV WXYZ

7809

SPACE

VCR

DISPLAY

REC/OTR

REC MONITOR

DVD

PLAY

STOP

SETUP

ENTER

VIDEO/TV

SLOW

PAUSE

TIMER PROG.

SPACE

DISPLAY

SETUP

REC/OTR

REC MONITOR

Writing to Disc

SLOW

DVD

VCR

PAUSE

PLAY

STOP

TIMER PROG.

ENTER

58%

Start Rec. Stop/Start Stop Rec.

Title 1 Title 2

Chapter 1 Chapter 1Chapter 2 Chapter 3 Chapter 2

Information on DVD recording

Recording

Information

This unit can record to DVD-R and DVD-RW discs. When recording, you will need to select a recording format between Video mode and VR mode depending on the disc format.The disc format for DVD-R is always “Video format,” so the recording format will be “Video mode”. On the other hand, when recording to DVD-RW, the recording format will be “Video mode” or “VR mode” because a disc format is available between “Video Recording format” and “Video format” for DVD-RW.

* This unit cannot record on the following discs.

•DVD-R General Ver 2.0 / 8x

•DVD-RW Ver 1.2 / 2-4x CPRM compatible

Important

About Video mode and VR (Video Recording) mode

Video mode is the same recording format as prerecorded DVD-Video discs purchased locally, so that you can play in most DVD players.To play in other DVD players, you will need to finalize the disc (see page

71). If not finalized, you can play, record additionally or edit discs recorded in Video mode only with this unit. VR (Video Recording) mode is a basic recording format for DVD-RW.You can record and edit repeatedly.

DVD players which are compatible are capable of playing DVD-RW recorded in VR mode.

Recording speed

You can select a recording speed among 6 options, and the recording time will depend on the recording speed you select as follows.

* This table is designed for a new single-sided 12cm

disc as the standard.The recording time are estimates and actual recording time may differ.

* The audio and video quality gets poorer as the

recording time becomes longer.

Restrictions on recording

You cannot record copy-protected video using this unit. Copy-protected video includes DVD-Video discs and some satellite broadcasts. If copy-protected material is encountered during a recording, the unit will pause or stop automatically and an error message will be displayed on-screen. Video that is “copy-once only” can only be recorded using a DVD-RW disc in VR mode with CPRM (see below). When recording a TV broadcast or through an external input, you can display copy control information on screen.

What is “CPRM”?

CPRM is a copy protection system with scramble system regarding the recording of “copy once” broadcast programs. CPRM stands for Content Protection for Recordable Media. This unit is CPRM compatible, which means that you can record copy-once broadcast programs, but you cannot then make a copy of those recordings. CPRM recordings can only be made on DVD-RW discs formatted in VR mode, and CPRM recordings can only be played on players that are specifically compatible with CPRM.

Logo Attributes

12cm, single-sided, single layer rewritable disc Approx. max. recording time (SEP

DVD-RW

DVD-R

mode): 600 minutes (4.7GB)

12cm, single-sided, single layer disc

Approx. max. recording time (SEP mode): 600 minutes (4.7GB)

Recording speed

XP (1H)

SP (2H)

LP (4H)

EP (6H)

SLP (8H)

SEP (10H)

Recording time *

60 min

120 min

240 min

360 min

480 min

600 min

Video/Sound Quality

(Highest)

(Lowest)

Disc type Disc format

Video mode

Video

DVD-RW

DVD-R

VR mode

DVD-RW

Video mode

DVD-R

Functions

Playing, limited recording, limited editing

Playing, recording, Original/Playlist editing

Playing, limited recording, limited editing

Information on DVD recording (cont’d)

Recording

Changing the SETUP menu

Playing discs VCR functions

Before you start

Connections Getting started

Recording Editing Others

Español

Information on copy control

Some satellite broadcasts include copy-protected information. For recording these, refer to the following.

Important

Making discs playable in other DVD player (Finalize)

After recording you must finalize disc in order to play it on other DVD units.

After finalizing:

• Once DVD-R/RW (Video mode) is finalized, you cannot record additionally or edit.

•Even if DVD-RW (VR mode) is finalized, you can record additionally to or edit.

• When DVD-R/RW (Video mode) is finalized, title menu will be created automatically.

To play in other DVD players, finalize discs recorded on this unit with the following condition.

Note : Recording

• The audio and video quality gets poorer as the Recording time becomes longer.

•

This unit cannot record CD-R or CD-RW discs.

•DVD-R/RW and CD-R/RW discs recorded on a personal computer or a DVD or CD recorder may not play if the disc is damaged or dirty or if there is dirt or condensation on the unit’s lens.

• If you record a disc using a personal computer, even if it is recorded in a compatible format, there are cases in which it may not play because of the settings of the application software used to create the disc. (Check with the software publisher for more detailed information.)

• Discs recorded in Video mode on this unit cannot record additionally using other DVD recorders.

Disc type / format

ver.1.1

DVD-RW

DVD-R

ver.1.1 CPRM compatible

ver.1.1

Video

ver.1.1 CPRM compatible

ver.2.0

Recordable Not Recordable

Copy-free Copy-once

Copyprohibited

Finalizing*

Playable

This Unit DVD player

Not Playable

* You cannot finalize discs in other DVD recorders.

Disc type Mode

DVD-R

ver.2.0

DVD-RW

ver.1.1 ver.1.1 CPRM compatible

Video mode

Video mode VR mode

Formatting a disc

Recording

Choosing the recording format of a blank disc

When inserting a blank disc, the unit will initialize the blank disc. After initialization, you can record to the disc with the recording format selected in SETUP menu. You can select at what length the recorder will create chapter mark on the DVD disc recording.

Press SETUP button to display SETUP/DISC menu.

SETUP/DISC menu will appear.

Screen:

Select “SETUP” using { / B buttons, then press ENTER button.

SETUP menu will appear.

Select “Recording” using K / L / { / B buttons, then press

ENTER button.

Recording menu will appear.

Select “DVD-RW Recording Format” using

K / L buttons,

then press ENTER button.

Option window will appear.

Video mode has been selected as the default.

Select “Video mode” or “VR mode” using

K / L buttons,

then press ENTER button.

The recording mode will be set.

Note :

Disc Error Massage

• When inserting a blank DVD+R or DVD+RW disc, the error message ("Disc Error") will appear.This unit is not compatible with a DVD+R/RW disc.

• PLAYLIST will be created automatically when recording

on DVD-RW in VR mode.

POWER

REC SPEED

AUDIO

ZOOM SKIP SKIP

OPEN/CLOSE

TOP MENU

SPACE

VCR

SETUP

CM SKIP

TIMER PROG.

RETURN

123

456

7809

STOP

PLAY

VIDEO/TV

SLOW

PAUSE

.@/:

ABC DEF

GHI JKL MNO

PQRS

REC/OTR

REC MONITOR

MENU/LIST

CLEAR/C.RESET

MODE

ENTER

DISPLAY

TUV WXYZ

DVD

ONE TOUCH

DUBBING

2 3 4 5

Note : Disc Formatting

• The recording format setting is effective only for DVD-RW discs.You cannot change the recording format on a DVD-R disc. DVD-R discs will always be in Video mode.

•You can not mix disc recording formats on a single DVD discs.

When you load a disc once recorded before, the recording format cannot be changed even if you change it in

SETUP menu.

Video

DVD-RW

Setup > Recording

DVD-RW Recording Format

Auto Chapter

Timer Programming

Dubbing Mode

Video mode

10 minutes

VCR DVD

DVD

Setup Menu

Setup

Playback Setting

Setup > Recording

DVD-RW Recording Format

Auto Chapter

Timer Programming

Dubbing Mode VCR DVD

Video mode DVD Player Compatibility mode. VR mode Editing possibility mode.

DVD

Video mode

VR mode

10 minutes

Formatting a disc (cont’d)

Recording

Changing the SETUP menu

Playing discs VCR functions

Before you start

Connections Getting started

Recording Editing Others

Español

Select “Auto Chapter” using K / L buttons, then press

ENTER button.

Option window will appear.

“

10 minutes” has been selected as

the default.

Select a desired time option using

K / L buttons, then

press ENTER button.

Chapter marks will be placed on the DVD recording at the selected time interval.

Press SETUP button to exit.

POWER

REC SPEED

AUDIO

ZOOM SKIP SKIP

OPEN/CLOSE

TOP MENU

SPACE

VCR

SETUP

CM SKIP

TIMER PROG.

RETURN

123

456

7809

STOP

PLAY

VIDEO/TV

SLOW

PAUSE

.@/:

ABC DEF

GHI JKL MNO

PQRS

REC/OTR

REC MONITOR

MENU/LIST

CLEAR/C.RESET

MODE

ENTER

DISPLAY

TUV WXYZ

DVD

ONE TOUCH

DUBBING

Note

• In Video mode, the actual time interval for chapter mark may be shorter than the selected time for 20 seconds or less.

Setup > Recording

DVD-RW Recording Format

Auto Chapter

Timer Programming

Dubbing Mode VCR DVD

DVD

VR mode

OFF 5 minutes

10 minutes

10 minutes 15 minutes 30 minutes 60 minutes

Formatting a disc (cont’d)

Recording

If you are using a DVD-RW disc, by default it will be Video mode. You can change this to VR mode from SETUP menu.

Place DVD-RW disc into the unit. Press SETUP button to display SETUP/DISC menu.

SETUP/DISC menu will appear.

Screen:

Select “DISC” using { / B but- tons, then press ENTER button.

DISC menu will appear.

* VR mode only

Select “Format” using K / L buttons, then press ENTER button.

Option window will appear.

* VR mode only

Select “Yes” using { / B but- tons, then press ENTER button.

Option window will appear.

* VR mode only

Select “Yes” using { / B but- tons, then press ENTER button.

Formatting will start.

Formatting is complete.

100% will be indicated.

This operation may take a few minutes to complete.

Reformatting a disc

Caution

• When you reformat the disc, the contents of the disc will be erased.

• If you want to cancel format

at step 5, select “No”.

2 3 4 5

Video

DVD-RW

Setup Menu

Disc

Edit

Forma t

Finalize

Disc Protect OFF ON

Yes No

Are you sure?

Yes No

POWER

REC SPEED

.@/:

ABC DEF

123

GHI JKL MNO

456

PQRS

TUV WXYZ

7809

SPACE

VCR

DISPLAY

PLAY

STOP

SETUP

REC/OTR

REC MONITOR

MENU/LIST

TOP MENU

ZOOM SKIP SKIP

CLEAR/C.RESET

CM SKIP

MODE

AUDIO

DVD

ENTER

OPEN/CLOSE

VIDEO/TV

SLOW

PAUSE

TIMER PROG.

RETURN

ONE TOUCH

DUBBING

Disc

Edit

Forma t

Finalize

Disc Protect OFF ON

Disc

Edit

Forma t

Finalize

Disc Protect OFF ON

Yes No

Formatting

100%

Formatting

58%

Basic recording

Recording

Changing the SETUP menu

Playing discs VCR functions

Before you start

Connections Getting started

Recording Editing Others

Español

Note : Recording

• Recording starts immediately and continues until the disc is full or you stop recording.

• When the clock setting has not been made, the space for a date and time of title names in the original or playlist will be blank.

•You cannot mix two formats on one DVD-RW disc. When you load a disc once recorded before, the recording format cannot be changed even if you change it in SETUP menu.

•You cannot change the recording speed during the REC pause mode.

•You can change a channel

during the REC pause mode.

Follow the steps below to record TV programs.

First:

Turn on the unit and load a recordable disc.

Make sure that the TV is set on the DVD/VCR.

Select a recording speed using REC SPEED button.

Refer to “Recording speed” on page 56.

Make sure that the recording format is set to the desired mode.

Refer to “Formatting a disc” on pages 58-60.

When a DVD-RW disc is loaded:

Yo u can choose Video mode or VR mode from SETUP menu. “Video mode” has been selected as the default. Refer to “Choosing the recording format of a blank disc” on pages

58-59.

When a DVD-R disc is loaded:

DVD-R discs will always be in Video mode.

Select a desired channel to record using CH

K / L but-

tons or number buttons.

Press REC/OTR button to start recording.

I mark will be displayed for 5 seconds.

To pause the recording, press PAUSE

F button. Press REC/OTR

button to restart the recording.

Press STOP C button to stop the recording.

This operation may take a few minutes to complete.

DVD

DVD-R

Video

DVD-RW

SP 2:01 Rem.

CH 1

POWER

REC SPEED

.@/:

ABC DEF

123

GHI JKL MNO

456

PQRS

TUV WXYZ

7809

SPACE

VCR

DISPLAY

PLAY

STOP

SETUP

REC/OTR

REC MONITOR

MENU/LIST

TOP MENU

ZOOM SKIP SKIP

CLEAR/C.RESET

CM SKIP

MODE

AUDIO

DVD

ENTER

OPEN/CLOSE

VIDEO/TV

SLOW

PAUSE

TIMER PROG.

RETURN

ONE TOUCH

DUBBING

Basic recording (cont’d)

Recording

Note : Sound Quality

•You cannot check the recording sound quality with the Rec monitor function.

You can confirm the recording picture quality with the recording speed you have selected before attempting to record to a DVD disc.

First:

While the unit is in STOP or REC with a DVD disc inserted, press REC MONITOR button.

The TV program will be on the screen and the recording picture quality with the recording speed you have selected.

If you want to change the recording speed, press REC SPEED button repeatedly.

The recording speed will be changed as you press the button as shown. Refer to “Recording speed” on page

56.

•You cannot change the recording speed during recording.

Press REC MONITOR button again to exit.

Checking the recording picture quality

POWER

REC SPEED

AUDIO

ZOOM SKIP SKIP

OPEN/CLOSE

TOP MENU

SPACE

VCR

SETUP

CM SKIP

TIMER PROG.

RETURN

123

456

7809

STOP

PLAY

VIDEO/TV

SLOW

PAUSE

.@/:

ABC DEF

GHI JKL MNO

PQRS

REC/OTR

REC MONITOR

MENU/LIST

CLEAR/C.RESET

MODE

ENTER

DISPLAY

TUV WXYZ

DVD

ONE TOUCH

DUBBING

DVD-R

Video

DVD-RW

DVD

DVD-RW

XP SP LP

CH 18

Rec Monitor

EPSLPSEP

One-touch timer recording

Recording

Changing the SETUP menu

Playing discs VCR functions

Before you start

Connections Getting started

Recording Editing Others

Español

Note : Automatic Turn Off

• The remaining recording time will appear on the display panel during an OTR. Press DISPLAY button to see it on the TV screen.

•You cannot pause an OTR.

• The unit will turn off automatically under the conditions following.

1)No space remained on the

disc.

2)When a power failure

occurs.

• If OTR is finished in DVD during playback or REC mode in VCR, the DVD will be in STOP mode and the VCR

keeps the current mode.

This is a simple way to set the recording time in blocks of 30 minutes. Check that the disc you are recording onto has enough space for the time you set. When the recording finishes the recorder automatically goes into standby.

First:

Turn on the unit and load a recordable disc.

Make sure that the TV input is set on the DVD/VCR.

Select a recording speed using REC SPEED button.

Refer to "Recording speed" on page

56.

Make sure that the recording format is set to the desired mode.

Refer to "Formatting a disc" on pages 58-60.

When a DVD-RW disc is loaded:

Yo u can choose Video mode or VR mode from SETUP menu. "Video mode" has been selected as the default. Refer to "Choosing the recording format of a blank disc" on pages

58-59.

When a DVD-R disc is loaded:

DVD-R discs will always be in Video mode.

Select a desired channel to record using CH

K / L but-

tons or number buttons.

Press REC/OTR button, then press REC/OTR button repeatedly until a desired recording length (

30 minutes to 8 hours) appears on the TV screen.

Recording will start.

When reaches the specified time, the unit will be turned off automatically.

To cancel the one-touch timer recording within the specified time, press STOP C button.

This operation may take a few minutes to complete.

DVD

DVD-R

Video

DVD-RW

0:30

(Normal Recording)

0:30

1:00

POWER

REC SPEED

.@/:

ABC DEF

123

GHI JKL MNO

456

PQRS

TUV WXYZ

7809

SPACE

VCR

DISPLAY

PLAY

STOP

SETUP

REC/OTR

REC MONITOR

MENU/LIST

TOP MENU

ZOOM SKIP SKIP

CLEAR/C.RESET

CM SKIP

MODE

AUDIO

DVD

ENTER

OPEN/CLOSE

VIDEO/TV

SLOW

PAUSE

TIMER PROG.

RETURN

ONE TOUCH

DUBBING

8:00 7:30

Timer recording

Recording

You can program the DVD/VCR to record up to 8 programs, up to a year in advance. Daily or weekly program recordings are also available.

• Be sure to set the clock before making a timer programming.

• Insert a recordable disc or a videotape with a recording safety tab.

Press SETUP button to display SETUP/DISC menu.

SETUP/DISC menu will appear.

Screen:

Select “SETUP” using { / B buttons, then press ENTER button.

SETUP menu will appear.

Select “Recording” using K / L / { / B buttons, then press

ENTER button.

Recording menu will appear.

Select “Timer Programming” using

K / L buttons, then

press ENTER button.

Timer Programming list will appear.

Select an empty program line using

K / L buttons, then

press ENTER button.

Enter the date using K / L buttons, then press B button.

e.g. January 1st

Enter the time to start and to end using

K / L buttons,

then press

B button.

DVD-R

Note : Clock Setting

• If you have not set the clock yet:

A clock setting window will appear after step

4. Continue

with step

4 in “Auto Clock Setting” on page 18 or “Manual Clock Setting” on pages 19-20 before making a timer programming.

•Press { or B buttons to move the cursor to the left and the right in the timer

programming menu.

2 3 4 5

You can choose the timer programming menu by pressing TIMER PROG. button. In this case, continue with step

When pressing L button at the current date, timer recording mode will change as follows.

DVD-R

VCR

Video

DVD-RW

Setup Menu

Setup

Playback Setting

Setup > Recording

DVD-RW Recording Format

Auto Chapter

Timer Programming

Dubbing Mode

DVD

Video mode

10 minutes

VCR DVD

Setup > Recording > Timer Programming

Date Start End CH Speed

- - -

DVD VCR

Setup > Recording > Timer Programming

Date Start End CH Speed

JAN / 01

- - -

---

- - : - -

DVD VCR

CH8 DVD

JAN/01

Daily

MON-SAT

MON-FRI

SAT

FRI

SUN

DEC/31

Setup > Recording > Timer Programming

Date Start End CH Speed

JAN/12

- - -

- - : - -

10 :00

CH8 DVD

DVD VCR

OPEN/CLOSE

AUDIO

ABC DEF

PLAY

STOP

DVD

ENTER

VIDEO/TV

SLOW

PAUSE

TIMER PROG.

RETURN

ONE TOUCH

DUBBING

TUV WXYZ

VCR

ZOOM SKIP SKIP

POWER

REC SPEED

.@/:

123

GHI JKL MNO

456

PQRS

7809

SPACE

DISPLAY

SETUP

REC/OTR

REC MONITOR

MENU/LIST

TOP MENU

CLEAR/C.RESET

CM SKIP

MODE

Timer recording (cont’d)

Recording

Changing the SETUP menu

Playing discs VCR functions

Before you start

Connections Getting started

Recording Editing Others

Español

Select the channel number to record using K / L buttons, then press B button.

To r ecord from the AV input jacks, L1 or L2.

Select a recording media using K / L buttons, then press B button.

•To record on to a tape, select VCR.

•To record on to a disc, select DVD.

Select a recording speed using K / L buttons.

Refer to “Recording speed” on page 56 for DVD or page 50 for VCR.

Press ENTER button when all information required is entered.

Your program setting will be stored.

•To set another program, repeat steps

5 to 11.

•To exit, press SETUP button.

Press POWER button to turn off.

indicator will appear on the

front display.

Press POWER button so that

indicator disappears from the

front display.

Press TIMER PROG. button.

Timer Programming list will appear.

Check the information on the list.

To clear the timer programming, select your desired program using

K / L buttons, then press

CLEAR/C.RESET button. To correct the timer program-

ming, select your desired program using

K / L buttons, then

press ENTER button.

Next, correct the timer programming using

K/L/{/B buttons.

Finally, press ENTER button again.

Press TIMER PROG. button to exit.

Press POWER button to return to the timer standby mode.

Checking, canceling, or correcting the timer programming information

Note :Timer Programming

•Press TIMER PROG. button to check the timer programming in process. When the timer recording is proceeding, that program will be red highlighted. In this case, you cannot select any other

program.

Note : Automatic Turn On

•After step 12, the unit will be turned on automatically 2 minutes (For VCR recording, 10 seconds) in advance of the recording time.The recording will start at the recording

time you set.

POWER

REC SPEED

AUDIO

ZOOM SKIP SKIP

OPEN/CLOSE

TOP MENU

SPACE

VCR

SETUP

CM SKIP

TIMER PROG.

RETURN

123

456

7809

STOP

PLAY

VIDEO/TV

SLOW

PAUSE

.@/:

ABC DEF

GHI JKL MNO

PQRS

REC/OTR

REC MONITOR

MENU/LIST

CLEAR/C.RESET

MODE

ENTER

DISPLAY

TUV WXYZ

DVD

ONE TOUCH

DUBBING

2 5

Press STOP C button to stop the disc recording or STOP/EJECT CAto stop the tape recording on the front panel of the main unit. STOP C button on the remote control will not work.

To stop the timer recording in process

Setup > Recording > Timer Programming

Date Start End CH Speed

JAN/12

- - -

10:00

10:30

VCR

CH8 DVD

DVD

Setup > Recording > Timer Programming

Date Start End CH Speed

JAN/12

- - -

10:00

10:30

CH8 DVD

DVD VCR

Setup > Recording > Timer Programming

Date Start End CH Speed

JAN/12

- - -

10:00

10:30

DVD VCR

CH8 DVD

AUDIO

ABC DEF

TUV WXYZ

VCR

DVD

PLAY

STOP

ENTER

OPEN/CLOSE

VIDEO/TV

SLOW

PAUSE

TIMER PROG.

RETURN

ONE TOUCH

DUBBING

POWER

REC SPEED

.@/:

123

GHI JKL MNO

456

PQRS

7809

SPACE

DISPLAY

SETUP

REC/OTR

REC MONITOR

TOP MENU

MENU/LIST

ZOOM SKIP SKIP

CLEAR/C.RESET

CM SKIP

MODE

Setup > Recording > Timer Programming

Date Start End CH Speed

JAN/12

- - -

10:00

10:30

DVD VCR

CH8 DVD

Recording

Timer recording (cont’d)

Hints for timer recording

•

If there is a power failure or this unit has been unplugged for more than 30 seconds, the clock setting and all timer settings will be lost.

• If a disc is not on the tray, the DVD indicator on the front panel flashes and timer recording cannot be performed. Please insert a recordable disc.

• If a tape with a record tab is not in the cassette compartment, the VCR indicator on the front panel flashes and timer recording cannot be performed. Please insert a recordable tape.

• When all the timer recording is completed, the indicator flashes.To play or eject the recorded disc (or the tape), press POWER button first and then press PLAY B or OPEN/CLOSE A (or STOP/EJECT CA) button.

• Important The timer recording can not be performed in DVD and VCR at the same time.

If you set two programmings with the same channel and time both in DVD and VCR, the programming that has priority will be recorded (see below for details).

•

During timer recording or timer standby ( indicator is on the front display), any operations on the unit will not be available.To make these operations available, cancel the timer recording or timer standby first ( indicator disappears).

• To cancel the timer standby mode, press POWER button.

• When the Start and the End time are the same, the length of the recording will be set for 24 hours.When the disc reaches at the end during the recording, the unit turns itself off.

• When the programmed Start and End time are earlier than the current time, the recording will be set on the same date in the next year.

•

If your programmed Start time for DVD recording is within 2 minutes from the current time, the power will turn on for recording standby right after you turn the power off. For a videotape recording, the power will turn on shortly before the Start time.

• If a videotape ends during timer recording, the unit will stop, eject the videotape, and turn itself off.

• When two or more programmings are overlapped,“Overlap” will be displayed.

This unit records the programs according to priority if timer programmings are overlapping.The timer programming set first has priority.

A timer recording of lower priority will be canceled, start from the middle or stop on the way. Check the overlapping timer programmings and change the priority if necessary.

The priority of overlapped settings

Note for DVD timer recording

• When the recording time of two programs are overlapped, or the End time of a program and the Start time of another is the same, the first 20-90 seconds of the subsequent program will be cut off.

A programming set previously has priority

When the starting time is same:

A program with a lower program number (PROG.1) has priority.

ex.1

PROG. 1

PROG. 2

Actual recording

When the recording time is partially overlapped:

PROG. 1 will start after PROG. 2 is complete to be recorded.

PROG. 1

PROG. 1 PROG. 2

When some programming have been made at the end time of the programming currently being recorded:

A program with a lower program number (PROG. 2) has priority.

ex. 2

PROG. 1

PROG. 2

PROG. 3

Actual recording

When the recording time is entirely overlapped:

PROG. 1 will not be recorded.

PROG. 1

PROG. 1 PROG. 2

PROG. 2

Actual recording

PROG. 2 PROG. 1

PROG. 2

Actual recording

When the end time of the programming currently being recorded and the program to be recorded sequentially are same:

PROG. 1

PROG. 2

Actual recording

PROG. 2PROG. 1

The first 20-90 seconds will be cut off.

PROG. 2

Recording

Changing the SETUP menu

Playing discs VCR functions

Before you start

Connections Getting started

Recording Editing Others

Español

Settings for an external source

Connect the external source properly to the unit by using input jacks either LINE2 (Front) or LINE1 (Rear). When you want to record to a tape, use either DVD/VCR VIDEO IN jack (Rear) or VIDEO input jack (Front). S-VIDEO input is useful only in DVD mode. Use S-Video or Video cable, and an Audio cable for this connection.

Connection to an external source

1. Press SETUP button to display SETUP/DISC menu.

2. Select “SETUP” using { / B buttons, then press ENTER button.

3. Select “Select Video” using K / L / { / B buttons, then press ENTER button.

4. Select “L2 (Front)” using K / L buttons, then press ENTER button.

5. Select the input jack type to connect using K / L buttons, then press ENTER button.

If you want to use S-VIDEO IN, select “S-Video In”.* If you want to use VIDEO IN (Composite), select “Video In”.

1. Press SETUP button to display SETUP/DISC menu.

2. Select “SETUP” using { / B buttons, then press ENTER button.

3. Select “Select Video” using K / L / { / B buttons, then press ENTER button.

4. Select “L1 (Rear)” using K / L buttons, then press ENTER button.

5. Select the input jack type to connect using K / L buttons, then press ENTER button.

If you want to use S-VIDEO IN, select “S-Video In”.* If you want to use VIDEO IN (Composite), select “Video In”.

S- VIDEO

OUTPUT

VIDEO

AUDIO

Another source

(VCR camcorder etc.)

OUTPUT

VIDEOS -VIDEO AUDIO

S-Video

cable

Video

cable

S-VIDEO VIDEO L - AUDIO - R

To LINE 2 IN To LINE 1 IN

PLAYREWPOWER F.FWD STOP/EJECT

VCR RECORD DVD RECORD

Audio cable

OPEN/CLOSE

ONE TOUCH

STOP PLAY

DUBBING

OUTPUT SELECT

CHANNEL

VCR DVD

S-VIDEO VIDEO L - AUDIO - R

DVD -RW/-R

Front of this unit Rear of this unit

Video In

DVD

Setup > Select Video

L1 (Rear)

L2 (Front)

S-Video

cable

Video

cable

DVD

S-VIDEO

DVDDVD/VCR

S-VIDEO

AUDIO

DIGITAL

OUT

AUDIO OUT

COAXIAL

COMPONENT

OUT

Audio cable

AUDIO IN

VIDEO IN

VIDEO OUT

DVD/VCR

ANTENNINAUDIO OUTAUDIO IN

VIDEO OUTVIDEO IN

OUT

Video In

DVD

Setup > Select Video

L1 (Rear)

L2 (Front)

Video In

Video In S-Video In

Video In

DVD

Setup > Select Video

L1 (Rear)

L2 (Front)

Setup > Select Video

L1 (Rear)

L2 (Front)

DVD

Video In

S-Video In

Video In

Video In S-Video In

Video In

DVD

Setup > Select Video

L1 (Rear)

L2 (Front)

Setup > Select Video

L1 (Rear)

L2 (Front)

DVD

S-Video In

Video In

Recording

Settings for an external source (cont’d)

Before recording from an external source, see the instruction for the connection on page 67.

Recording from an external source

1. Turn the TV and the DVD/VCR on, and be sure to select the input of the TV to which the DVD/VCR is connected.

2. When you want to record to a disc: Press:

Press OPEN/CLOSE

A button to open the disc tray, then

place the disc to record onto, then press open/close again.

When y

ou want to record to a tape: Press: Insert the tape with a safety tab into the cassette compartment.

3. Select the input (L1 or L2) to which the external equipment is connected.

•To use the input jacks on the back of this unit, select “L1” position by pressing [

0],[0],[1] on the remote control or the CH K / L buttons.

•To use the input jacks on the front of this unit, select “L2” position by pressing [

0],[0],[2] on the remote control or the CH K / L but-

tons.

4. Select a recording speed using REC SPEED button.

Refer to

“Recording speed” on page

56 for DVD or page 50 for VCR.

5.Press REC/OTR button on the DVD/VCR to start recording.

6.Press PLAY button on the external source that you are

recording from.

7.For disc: Press STOP C button on the DVD/VCR to stop recording.

For tape:

Press STOP/EJECT CAbutton on the unit to stop recording.

This operation may take a few minutes to complete.

DVD

POWER

REC SPEED

AUDIO

ZOOM SKIP SKIP

OPEN/CLOSE

TOP MENU

SPACE

VCR

SETUP

CM SKIP

TIMER PROG.

RETURN

123

456

7809

STOP

PLAY

VIDEO/TV

SLOW

PAUSE

.@/:

ABC DEF

GHI JKL MNO

PQRS

REC/OTR

REC MONITOR

MENU/LIST

CLEAR/C.RESET

MODE

ENTER

DISPLAY

TUV WXYZ

DVD

ONE TOUCH

DUBBING

DVD-R

Video

DVD-RW

VCR

XP SP LP

SP SLP

SEP

DVD mode

EPSLP

VCR mode

Dubbing Mode

Recording

Changing the SETUP menu

Playing discs VCR functions

Before you start

Connections Getting started

Recording Editing Others

Español

Important

You can copy a DVD disc to a videotape or copy a videotape to a DVD disc.This function will be possible only if the DVD disc or the videotape is not copy protected. Before starting this function, prepare for the recording on the DVD-R/RW disc or the videotape. Refer to pages 50,

61-62.

Make sure:

• Insert a disc and a videotape

with a safety tab.

Note for recording to a tape:

• The videotape's record tab is

intact.

• The videotape has enough time

to record the DVD disc.

Note for recording to a disc:

• The DVD disc is compatible

with the recording mode. Refer to pages

56-57.

Press SETUP button to display SETUP/DISC menu.

SETUP/DISC menu will appear.

Screen:

Select “SETUP” using { / B buttons, then press ENTER button.

SETUP menu will appear.

Select “Recording” using K / L / { / B buttons, then press

ENTER button.

Recording menu will appear.

Select “Dubbing Mode” using K / L buttons, then press

ENTER button.

Option window will appear.

DVD-R

2 3 4

Instructions continue on page 70.

Note :Videotape

tracking control

For VCR to DVD duplication:

•After start VCR to DVD duplication, the picture may be distorted because of the auto tracking function of the videotape. This is not a malfunction. Be advised to playback the tape until the picture is stabilized, then set the starting point which you wish to start recording, and start VCR to

DVD duplication.

DVD-R

VCR

Video

DVD-RW

Setup

Playback Setting

Setup > Recording

DVD-RW Recording Format

Auto Chapter

Timer Programming

Dubbing Mode

DVD

Video mode

10 minutes

VCR DVD

POWER

REC SPEED

.@/:

ABC DEF

123

GHI JKL MNO

456

PQRS

TUV WXYZ

7809

SPACE

VCR

DISPLAY

PLAY

STOP

SETUP

REC/OTR

REC MONITOR

MENU/LIST

TOP MENU

ZOOM SKIP SKIP

CLEAR/C.RESET

CM SKIP

MODE

AUDIO

DVD

ENTER

OPEN/CLOSE

VIDEO/TV

SLOW

PAUSE

TIMER PROG.

RETURN

ONE TOUCH

DUBBING

Setup Menu

Setup > Recording

DVD-RW Recording Format

Auto Chapter

Timer Programming

Dubbing Mode

VCR DVD

Video mode

OFF

VCR DVD

Dubbing Mode (cont’d)

Recording

Select “VCR ⇒ DVD” using K / L buttons, then press

ENTER button.

Press SETUP button to exit SETUP menu.

Make sure to select a recording speed using REC SPEED button.

Press:

7-a

Press PLAY B button on the unit, and then press PAUSE button at the point you wish to start recording.

Press ONE TOUCH DUBBING button on the unit or ONE TOUCH DUBBING button on the remote control.

VCR to DVD duplication will start.

9-a

Press STOP C button on the unit or STOP

C button on

the remote control to stop the recording.

Select “VCR ⇐ DVD” using K / L buttons, then press

ENTER button.

Press SETUP button to exit SETUP menu.

Press:

Make sure to select a recording speed using REC SPEED button.

Press:

7-b

Press PLAY B button on the unit, and then press PAUSE button at the point you wish to start recording.

Press ONE TOUCH DUBBING button on the unit or ONE TOUCH DUBBING button on the remote control.

DVD to VCR duplication will start.

9-b

Press STOP/EJECT CAbut- ton on the unit or STOP

button on the remote control to stop the recording.

DVD

VCR

DVD to VCR

VCR

VCR to DVD

POWER

REC SPEED

AUDIO

ZOOM SKIP SKIP

OPEN/CLOSE

TOP MENU

SPACE

VCR

SETUP

CM SKIP

TIMER PROG.

RETURN

123

456

7809

STOP

PLAY

VIDEO/TV

SLOW

PAUSE

.@/:

ABC DEF

GHI JKL MNO

PQRS

REC/OTR

REC MONITOR

MENU/LIST

CLEAR/C.RESET

MODE

ENTER

DISPLAY

TUV WXYZ

DVD

ONE TOUCH

DUBBING

ONE TOUCH

DUBBING

CHANNEL

VCR RECORD DVD R

DVD

OPEN/CLOSE

PLAYREWPOWER F.FWD STOP/EJECT

OUTPUT SELECT

VCR DVD

STOP PLAY

9-a

9-b

9-a 9-b

7-a 7-b

7-b7-a

Note : Dubbing

• When you turn off the unit after set the Dubbing Mode to , the setting will be set to automatically.

• Dubbing Mode is available only if the tape or disc is not copy protected.

•You cannot change the output mode during VCR to DVD or DVD to VCR duplication.

For VCR to DVD duplication:

•The playback sound mode is followed by the setting of VCR playback sound mode on page 53. Set the playback sound mode to which you wish to record to the DVD.

Setup > Recording

DVD-RW Recording Format

Auto Chapter

Timer Programming

Dubbing Mode

VCR DVD

Video mode

OFF

VCR DVD

VCR DVD VCR DVD

Setup > Recording

DVD-RW Recording Format

Auto Chapter

Timer Programming

Dubbing Mode

VCR DVD

Video mode

OFF

VCR DVD

VCR DVD VCR DVD

Finalizing the discs

Recording

Changing the SETUP menu

Playing discs VCR functions

Before you start

Connections Getting started

Recording Editing Others

Español

Note : Finalizing

• Finalizing discs in Video mode automatically create title menus.

• Once you have finalized a disc recorded in Video mode, you cannot edit or record anything else on that disc. Discs recorded in VR mode can still be recorded and edited on this unit even after finalized.

• When you insert a DVD-RW disc finalized with this unit, “Undo Finalize” will appear instead of “Finalize”.

To r elease the finalizing for the disc, select “Undo Finalize” at step 3.

• If appear when pressing STOP button, you cannot cancel finalizing because the finalizing process is in progress. When selecting “No” and press ENTER or RETURN button, finalizing will be continued.

Important You cannot

cancel finalizing of a DVD-R disc once it has started. *DO NOT power off during finalizing, this will result in malfunction.

Important

You will need to finalize discs recorded in Video mode to play in other DVD players. Finalizing may take several minutes up to an hour. (A disc recorded in Video mode can take up to 15 minutes.A disc recorded in VR mode can take up to 60 minutes.) A shorter recording period on the disc will require a longer time period for finalization. Do not unplug the power cord during finalization. Details are an pages 56-57.

Press SETUP button to display SETUP/DISC menu.

SETUP/DISC menu will appear.

Screen:

Select “DISC” using { / B buttons, then press ENTER button.

DISC menu will appear.

* VR mode only

Select “Finalize” using K / L buttons, then press ENTER button.

Option window will appear.

* VR mode only

Select “Yes” using { / B but- tons, then press ENTER button.

Finalizing will start.

To cancel finalizing, press STOP

button.

Select “Yes” using { / B but- tons, then press ENTER button.

Finalizing is cancelled, then the unit will be in stop mode.

Finalizing is complete.

This operation may take a few minutes to complete.

DVD-R

4 2

3 4

DVD-R

Video

DVD-RW

Setup Menu

Disc

Edit

Forma t

Finalize

Disc Protect OFF ON

Disc

Edit

Format

Finalize

Disc Protect OFF ON

Yes No

Finalizing

58%

Do you want to cancel?

Yes No

Finalizing

58%

Finalizing

100%

AUDIO

ABC DEF

TUV WXYZ

VCR

PLAY

STOP

DVD

ENTER

OPEN/CLOSE

VIDEO/TV

SLOW

PAUSE

TIMER PROG.

RETURN

ONE TOUCH

DUBBING

POWER

REC SPEED

.@/:

123

GHI JKL MNO

456

PQRS

7809

SPACE

DISPLAY

SETUP

REC/OTR

REC MONITOR

MENU/LIST

TOP MENU

ZOOM SKIP SKIP

CLEAR/C.RESET

CM SKIP

MODE

Disc

Edit

Format

Undo Finalize

Setting a disc to protect

Recording

Important

To prevent accidental recording, editing or erasing of titles, you can protect them by going to the DISC menu and following the steps bellow.

Press SETUP button to display SETUP/DISC menu.

SETUP/DISC menu will appear.

Screen:

Select “DISC” using { / B buttons, then press ENTER button.

DISC menu will appear.

Select “Disc Protect OFF ➔ ON” using K / L buttons,

then press ENTER button.

Option window will appear.

Select “Yes” using { / B but- tons, then press ENTER button.

A disc will be protected.

This operation may take a few minutes to complete.

2 3 4

Note : Disc Protect

• The Disc Protect setting is available only when a disc with VR mode is inserted.

•You can select only Disc Protect Menu when a protected disc is inserted.

To cancel the disc protect:

• When you insert a disc protected with this unit,“Disc Protect ON → OFF” will appear instead of “OFF → ON”.

To r elease the protect for the disc, select “Disc Protect ON → OFF” at step 3, then select

“Yes”.

Disc

Edit

Forma t

Finalize

Disc Protect ON OFF

Yes No

DVD-RW

Setup Menu

Disc

Edit

Forma t

Finalize

Disc Protect OFF ON

Yes No

POWER

REC SPEED

.@/:

ABC DEF

123

GHI JKL MNO

456

PQRS

TUV WXYZ

7809

SPACE

VCR

DISPLAY

PLAY

STOP

SETUP

REC/OTR

REC MONITOR

MENU/LIST

TOP MENU

ZOOM SKIP SKIP

CLEAR/C.RESET

CM SKIP

MODE

AUDIO

DVD

ENTER

OPEN/CLOSE

VIDEO/TV

SLOW

PAUSE

TIMER PROG.

RETURN

ONE TOUCH

DUBBING

Disc

Edit

Forma t

Finalize

Disc Protect OFF ON

Writing to Disc

58%

Information on disc editing

Editing

Changing the SETUP menu

Playing discs VCR functions

Before you start

Connections Getting started

Recording Editing Others

Español

Guide to a title list

Title list allows you to easily check the titles recorded on the disc.You can choose a title to play from on this screen and easily edit the titles as you prefer.

1. Titles recorded on the disc can be selected for editting purposes by pressing ENTER button with the cursor on the title.

2. Protect icon will appear if the title has been protected.

3. The selected title thumbnails from the title list.

4. This menu provides you with all the editing

options. The available menu options depend on disc and recorded format type.

5. Details of the title, which can be changed through editing.

6. Time status bar of the title to show length of title.

7. The arrow icon, which means the title list includes a next or a previous page. Press

B or

{ button by following direction of the icon.

8. Playback status of the current disc.

Editing discs in Video mode

You can edit discs in Video mode for the following items. Note that once you edit titles, they will not remain as recorded originally.

• Deleting titles (Refer to page

75)

• Putting names on titles (Refer to pages 76)

• Setting or clearing chapter markers (Refer to page

77)

Note : Disc Editing

•

Once a disc is finalized, then editing the disc or recording to the disc will not be available. (Except DVD-RW discs in VR mode.)

•

A playlist is not available with the DVD-R discs

and DVD-RW discs in Video mode.

Disc > Edit > Original

1 1 32

JAN/1 1:00AM

JAN/1

4:00AM

Disc > Edit > Original

JAN/1 1:00AM CH12 XP

3 4

JAN/1 2:00AM JAN/1 3:00AM

JAN/1

5:00AM

Title Delete

Scene Delete Edit Title Name Chapter Mark Index Picture Set Protect OFF

6 5

JAN/1 6:00AM

0:01:25

Information on disc editing (cont’d)

Editing

Editing original titles

The following items can be used to edit the original titles.

•Deleting titles (Refer to page

78)

• Deleting parts of titles (Refer to pages 79-80)

• Naming Titles (Refer to pages 80-81)

• Setting or clearing chapter markers (Refer to

pages

82-83)

• Setting pictures for thumbnails (Refer to pages

83-84)

• Title protection (Refer to page

85)

•Releasing titles from protection (Refer to page

86)

Editing playlists

You can create a playlist from original titles, so that you can edit as you prefer without losing original titles. The following items you can edit with a playlist.

•Deleting titles (Refer to page

87)

• Deleting parts of titles (Refer to pages 88-89)

• Naming Titles (Refer to pages

89-90)

• Setting or clearing chapter markers (Refer to pages 91-92)

• Setting pictures for thumbnails (Refer to pages 92-93)

•Adding titles to a Playlist (Refer to page 94)

• Deleting a Playlist (Refer to page

95)

Editing discs in VR mode

For discs in VR mode, you can edit from “Original” menu or “Playlist” menu, which is created from the original.

Important : Rearranging Titles

•

Original titles once edited will not remain as recorded originally. When you want to leave the original as it is, edit the playlist as you prefer. (Refer to pages 87-95)

Note : Editing

•

DVD-RW editing possibilities are explained on pages 75-95.

•

DVD-R editing possibilities are explained on pages 96-97.

Editing DVD-RW discs in Video mode

Editing

Changing the SETUP menu

Playing discs VCR functions

Before you start

Connections Getting started

Recording Editing Others

Español

Deleting titles

When the last title in the title list in Video mode is deleted, the disc space available for recording will be increased.

First:

Press SETUP button. Select “DISC” using

{ / B buttons,

then press ENTER button.

DISC menu will appear.

Select “Edit” using K / L but- tons, then press ENTER button.

Titlelist will appear.

Screen:

Select a desired title using K / L / { / B buttons, then press

ENTER button.

Edit menu will appear.

Select “Title Delete” using K / L buttons, then press ENTER button.

Option window will appear.

Select “Yes” using { / B but- tons, then press ENTER button.

Title will be deleted.

After writing to disc is completed, press SETUP button to exit DISC menu.

This operation may take a few minutes to complete.

2 3 4 5

1 6

Important

•

You can delete titles which you do not need anymore.

Caution

•

Be sure to know that titles once deleted, cannot be brought back to the disc.

Video

DVD-RW

DVD

Disc

Edit

Forma t

Finalize

Disc > Edit

JAN/ 1 1:00AM CH12 XP

Title Delete

Edit Title Name Chapter Mark

0:01:25

Disc > Edit

JAN/ 1 1:00AM CH12 XP

Title Delete

Edit Title Name Chapter Mark

Yes No

0:01:25

POWER

REC SPEED

AUDIO

.@/:

ABC DEF

123

GHI JKL MNO

456

PQRS

TUV WXYZ

7809

SPACE

VCR

DISPLAY

PLAY

STOP

SETUP

REC/OTR

REC MONITOR

MENU/LIST

TOP MENU

ZOOM SKIP SKIP

CLEAR/C.RESET

CM SKIP

MODE

DVD

ENTER

OPEN/CLOSE

VIDEO/TV

SLOW

PAUSE

TIMER PROG.

RETURN

ONE TOUCH

DUBBING

Disc > Edit

1 1 32

JAN/1 1:00AM

JAN/1 4:00AM

JAN/1 2:00AM JAN/1 3:00AM

JAN/1 5:00AM

Disc > Edit

JAN/ 1 1:00AM CH12 XP

Writing to Disc

Title Delete

Edit Title Name Chapter Mark

Yes No

Editing DVD-RW discs in Video mode (cont’d)

Editing

You can put title names on titles and change the title names from this menu. The names you put on the titles will be displayed on a titlelist.

First:

Press SETUP button. Select “DISC” using

{ / B buttons,

then press ENTER button.

DISC menu will appear.

Select “Edit” using K / L but- tons, then press ENTER button.

Titlelist will appear.

Screen:

Select a desired title using K / L / { / B buttons, then press

ENTER button.

Edit menu will appear.

Select “Edit Title Name” using K / L buttons, then press ENTER button.

A window for entering a title name will appear.

To enter a title name, follow the steps of "Guide to edit title name" on this page.

character set

area for entering title names

When you finish entering a title name, press ENTER button.

Select “Yes” using { / B but- tons, then press ENTER button.

The name you entered will be activated for the title.

After writing to disc is completed, press SETUP button to exit DISC menu.

This operation may take a few minutes to complete.

Putting names on titles

Video

DVD-RW

DVD

Disc

Edit

Forma t

Finalize

Disc > Edit

1 1 32

JAN/1 1:00AM

JAN/1 4:00AM

JAN/1 2:00AM JAN/1 3:00AM

JAN/1 5:00AM

Disc > Edit

Title Delete

Edit Title Name Chapter Mark

Disc > Edit > Edit Title Name

JAN/ 1 1:00AM CH12 XP

A B C

a b c 1 2 3

@ ! ?

0:01:25

Disc > Edit > Edit Title Name

A B C

a b c 1 2 3

@ ! ?

JAN/ 1 1:00AM CH12 XP

0:01:25

Disc > Edit > Edit Title Name

abc

Writing to Disc

A B C

a b c 1 2 3

@ ! ?

Yes No

AUDIO

ABC DEF

TUV WXYZ

VCR

DVD

PLAY

STOP

ENTER

OPEN/CLOSE

VIDEO/TV

SLOW

PAUSE

TIMER PROG.

RETURN

ONE TOUCH

DUBBING

POWER

REC SPEED

.@/:

123

GHI JKL MNO

456

PQRS

7809

SPACE

DISPLAY

SETUP

REC/OTR

REC MONITOR

MENU/LIST

TOP MENU

ZOOM SKIP SKIP

CLEAR/C.RESET

CM SKIP

MODE

[

Guide to edit title name

[

Step1]: Select a desired character set using K/L

buttons, then press ENTER button.

[

]

Step2

: Press Number buttons following by the list

below.

Select

ABC

Press

<space>

ABC

DEF

GHI

JKL

5 6

MNO

PQRS

7 8

TUV

WXYZ

* Press button, character set will be changed to the " @

• To delete letters, press CLEAR/C.RESET button repeatedly. Holding CLEAR/C.CRESET button to delete all letters.

• To go on to the next entering area for letters, press button.

• You can enter up to 30 letters.

abc

abc

def

ghi

jkl

mno

pqrs

tuv

wxyz

" mode automatically.

123

]

A B C

a b c 1 2 3 @ ! ?

@ ! ?

! ” # $ % & ’ ( ) * + , - . / : ;

1*1 *1

< = > ? @ [ ] ^ _ { | }

JAN/ 1 1:00AM CH12 XP

0:01:25

Editing DVD-RW discs in Video mode (cont’d)

Editing

Changing the SETUP menu

Playing discs VCR functions

Before you start

Connections Getting started

Recording Editing Others

Español

Note : Markers

•You cannot place markers beyond the length of a title.

• When recording at the recording speed other than XP or SEP, the length of chapters may be slightly longer or shorter than the one specified at the step 5.

•A chapter marker may be delayed according to the

recording content.

Setting or clearing chapter markers

You can put chapter markers in each title. Once a chapter is marked, you can use it for the chapter search feature. You can set chapter markers at a specified time you selected for titles which are longer than

minutes.

First:

Press SETUP button. Select “DISC” using

{ / B buttons,

then press ENTER button.

DISC menu will appear.

Select “Edit” using K / L but- tons, then press ENTER button.

Titlelist will appear.

Screen:

Select a desired title using K / L / { / B buttons, then press

ENTER button.

Edit menu will appear.

Select “Chapter Mark” using K / L buttons, then press

ENTER button.

Option window will appear.

Select a desired time using K / L buttons, then press ENTER button.

Option window will appear.

Select “Yes” using { / B but- tons, then press ENTER button.

Chapter markers will be added at a specified time.

After writing to disc is completed, press SETUP button to exit DISC menu.

3 4

5 6

Video

DVD-RW

DVD

Disc > Edit

JAN/ 1 1:00AM CH12 XP

Disc

Edit

Forma t

Finalize

Disc > Edit

JAN/ 1 1:00AM CH12 XP

Title Delete

Edit Title Name Chapter Mark

Title Delete

Edit Title Name Chapter Mark

0:01:25

OFF 5 minutes 10 minutes 15 minutes 30 minutes 60 minutes

0:01:25

POWER

REC SPEED

.@/:

ABC DEF

123

GHI JKL MNO

456

PQRS

TUV WXYZ

7809

SPACE

VCR

DISPLAY

PLAY

STOP

SETUP

REC/OTR

REC MONITOR

MENU/LIST

TOP MENU

ZOOM SKIP SKIP

CLEAR/C.RESET

CM SKIP

MODE

AUDIO

DVD

ENTER

OPEN/CLOSE

VIDEO/TV

SLOW

PAUSE

TIMER PROG.

RETURN

ONE TOUCH

DUBBING

Disc > Edit

1 1 32

JAN/1 1:00AM

JAN/1 4:00AM

JAN/1 2:00AM JAN/1 3:00AM

JAN/1 5:00AM

Disc > Edit

JAN/ 1 1:00AM CH12 XP

Title Delete

Edit Title Name Chapter Mark

OFF 5 minutes 10 minutes 15 minutes 30 minutes 60 minutes

Yes No

0:01:25

Editing DVD-RW discs in VR mode (Original)

Editing

When a title is deleted from an original list in VR mode, the disc space available for recording will be increased.

First:

Press SETUP button. Select “DISC” using { / B buttons, then press ENTER button.

DISC menu will appear.

Select “Edit” using K / L but- tons, then press ENTER button.

Original/PlayList menu will appear.

Screen:

Select “Original” using { / B buttons, then press ENTER button.

Original list will appear.

Select a desired title using K / L / { / B buttons, then press

ENTER button.

Original menu will appear.

Select “Title Delete” using K / L buttons, then press ENTER button.

Option window will appear.

Select “Yes” using { / B but- tons, then press ENTER button.

Title will be deleted.

After writing to disc is completed, press SETUP button to exit DISC menu.

This operation may take a few minutes to complete.

Deleting titles

POWER

REC SPEED

AUDIO

ZOOM SKIP SKIP

OPEN/CLOSE

TOP MENU

SPACE

VCR

SETUP

CM SKIP

TIMER PROG.

RETURN

123

456

7809

STOP

PLAY

VIDEO/TV

SLOW

PAUSE

.@/:

ABC DEF

GHI JKL MNO

PQRS

REC/OTR

REC MONITOR

MENU/LIST

CLEAR/C.RESET

MODE

ENTER

DISPLAY

TUV WXYZ

DVD

ONE TOUCH

DUBBING

3 4

5 6

Important

• Be advised that the titles once deleted cannot be brought

back to the disc.

Caution

•

Once a title has been deleted,

it can not be brought back.

DVD-RW

Disc > Edit > Original

Title Delete

Scene Delete Edit Title Name Chapter Mark Index Picture Set Protect OFF

DVD

Disc

Edit

Forma t

Finalize

Disc Protect OFF ON

Disc > Edit

Original

Disc > Edit > Original

1 1 32

JAN/1 1:00AM

JAN/1 4:00AM

JAN/1 2:00AM JAN/1 3:00AM

JAN/1 5:00AM

JAN/ 1 1:00AM CH12 XP

0:01:25

Disc > Edit > Original

JAN/ 1 1:00AM CH12 XP

Title Delete

Scene Delete Edit Title Name Chapter Mark Index Picture Protect OFF

Yes No

0:01:25

Disc > Edit > Original

JAN/ 1 1:00AM CH12 XP

Writing to Disc

Title Delete

Scene Delete Edit Title Name Chapter Mark Index Picture Protect OFF

Yes No

Editing DVD-RW discs in VR mode (Original) (cont’d)

Editing

Changing the SETUP menu

Playing discs VCR functions

Before you start

Connections Getting started

Recording Editing Others

Español

4 5

Yo u can delete part of a title, the disc space available for recording will be increased.

First:

Press SETUP button. Select “DISC” using { / B buttons, then press ENTER button.

DISC menu will appear.

Select “Edit” using K / L but- tons, then press ENTER button.

Original/PlayList menu will appear.

Screen:

Select “Original” using { / B buttons, then press ENTER button.

Original list will appear.

Select a desired title using K / L / { / B buttons, then press

ENTER button.

Original menu will appear.

Select “Scene Delete” using K / L buttons, then press ENTER button.

Option window will appear.

Select Start-End Point.

Press ENTER button to decide a start point.

Then press ENTER button to decide an end point.

A cursor will move to “Preview.” You can check a preview.

Deleting parts of titles

Important

• Be advised that parts, once deleted, cannot be brought

back to the disc.

Note

• The DVD will begin to play in the window.

POWER

REC SPEED

AUDIO

ZOOM SKIP SKIP

OPEN/CLOSE

TOP MENU

SPACE

VCR

SETUP

CM SKIP

TIMER PROG.

RETURN

123

456

7809

STOP

PLAY

VIDEO/TV

SLOW

PAUSE

.@/:

ABC DEF

GHI JKL MNO

PQRS

REC/OTR

REC MONITOR

MENU/LIST

CLEAR/C.RESET

MODE

ENTER

DISPLAY

TUV WXYZ

DVD

ONE TOUCH

DUBBING

Instructions continue on page 80.

DVD-RW

DVD

Disc

Edit

Forma t

Finalize

Disc Protect OFF ON

Disc > Edit > Original

JAN/ 1 1:00AM CH12 XP

Title Delete

Scene Delete Edit Title Name Chapter Mark Index Picture Set Protect OFF

0:01:25

Disc > Edit > Original

Title Delete

Scene Delete Edit Title Name Chapter Mark Index Picture Protect OFF

Start End Preview Delete

Disc > Edit

Original

Disc > Edit > Original

1 1 32

JAN/1 1:00AM

JAN/1 2:00AM JAN/1 3:00AM

JAN/ 1 1:00AM CH12 XP

0:00:55

Before editing

Edited

Start point End point

JAN/1 4:00AM

JAN/1 5:00AM

Editing DVD-RW discs in VR mode (Original) (cont’d)

Editing

Naming Titles

You can put title names on titles and change the title names from this menu. The names you put on the titles will be displayed on a titlelist.

First:

Press SETUP button. Select “DISC” using

{ / B buttons,

then press ENTER button.

DISC menu will appear.

Select “Edit” using K / L but- tons, then press ENTER button.

Original/PlayList menu will appear.

Screen:

POWER

REC SPEED

AUDIO

ZOOM SKIP SKIP

OPEN/CLOSE

TOP MENU

SPACE

VCR

SETUP

CM SKIP

TIMER PROG.

RETURN

123

456

7809

STOP

PLAY

VIDEO/TV

SLOW

PAUSE

.@/:

ABC DEF

GHI JKL MNO

PQRS

REC/OTR

REC MONITOR

MENU/LIST

CLEAR/C.RESET

MODE

ENTER

DISPLAY

TUV WXYZ

DVD

ONE TOUCH

DUBBING

Note : Marker numbers

greater than 900

•You cannot select “Scene Delete” when the number of chapter markers in the original or playlist is more than 900.

Select “Delete” using K / L buttons, then press ENTER button.

Option window will appear.

Select “Yes” using { / B but- tons, then press ENTER button.

Part of a title will be deleted.

After writing to disc is completed, press SETUP button to exit DISC menu.

This operation may take a few minutes to complete.

Disc > Edit > Original

JAN/ 1 1:00AM CH12 XP

Title Delete

Scene Delete Edit Title Name Chapter Mark Index Picture Protect OFF

Start End Preview Delete

Yes No

0:01:25

Disc > Edit > Original

JAN/ 1 1:00AM CH12 XP

Writing to Disc

Title Delete

Scene Delete Edit Title Name Chapter Mark Index Picture Protect OFF

Start End Preview Delete

Yes No

AUDIO

ABC DEF

TUV WXYZ

VCR

DVD

PLAY

STOP

ENTER

OPEN/CLOSE

VIDEO/TV

SLOW

PAUSE

TIMER PROG.

RETURN

ONE TOUCH

DUBBING

POWER

REC SPEED

.@/:

123

GHI JKL MNO

456

PQRS

7809

SPACE

DISPLAY

SETUP

REC/OTR

REC MONITOR

MENU/LIST

TOP MENU

ZOOM SKIP SKIP

CLEAR/C.RESET

CM SKIP

MODE

DVD-RW

DVD

Disc

Edit

Forma t

Finalize

Disc Protect OFF ON

Disc > Edit

Original

Editing DVD-RW discs in VR mode (Original) (cont’d)

Editing

Changing the SETUP menu

Playing discs VCR functions

Before you start

Connections Getting started

Recording Editing Others

Español

Select “Original” using { / B buttons, then press ENTER button.

Original list will appear.

Select a desired title using K / L / { / B buttons, then press

ENTER button.

Original menu will appear.

Select “Edit Title Name” using

K / L buttons, then

press ENTER button.

A window for entering a title name will appear.

To enter a title name, follow the steps of "Guide to edit title name" on this page.

character set

area for entering title names When you finish entering a title name, press ENTER button.

Select “Yes” using { / B but- tons, then press ENTER button.

The name you entered will be activated for the title.

After writing to disc is completed, press SETUP button to exit DISC menu.

This operation may take a few minutes to complete.

Disc > Edit > Original

1 1 32

JAN/1 1:00AM

JAN/1 4:00AM

JAN/1 2:00AM JAN/1 3:00AM

JAN/1 5:00AM

Disc > Edit > Original

JAN/ 1 1:00AM CH12 XP

Title Delete

Scene Delete Edit Title Name Chapter Mark Index Picture Set Protect OFF

0:01:25

Disc > Edit > Original > Edit Title Name

JAN/ 1 1:00AM CH12 XP

A B C

a b c 1 2 3 @ ! ?

0:01:25

Disc > Edit > Original > Edit Title Name

A B C

a b c 1 2 3 @ ! ?

JAN/ 1 1:00AM CH12 XP

0:01:25

Disc > Edit > Original > Edit Title Name

abc

Writing to Disc

A B C

a b c 1 2 3

@ ! ?

Yes No

AUDIO

ABC DEF

TUV WXYZ

VCR

DVD

PLAY

STOP

ENTER

OPEN/CLOSE

VIDEO/TV

SLOW

PAUSE

TIMER PROG.

RETURN

ONE TOUCH

DUBBING

POWER

REC SPEED

.@/:

123

GHI JKL MNO

456

PQRS

7809

SPACE

DISPLAY

SETUP

REC/OTR

REC MONITOR

MENU/LIST

TOP MENU

ZOOM SKIP SKIP

CLEAR/C.RESET

CM SKIP

MODE

[

Guide to edit title name

[

Step1]: Select a desired character set using K/L

buttons, then press ENTER button.

[

]

Step2

: Press Number buttons following by the list

below.

Select

ABC

Press

<space>

ABC

DEF

GHI

JKL

5 6

MNO

PQRS

7 8

TUV

WXYZ

* Press button, character set will be changed to the " @

• To delete letters, press CLEAR/C.RESET button repeatedly. Holding CLEAR/C.CRESET button to delete all letters.

• To go on to the next entering area for letters, press button.

• You can enter up to 30 letters.

abc

abc

def

ghi

jkl

mno

pqrs

tuv

wxyz

" mode automatically.

123

]

A B C

a b c 1 2 3

@ ! ?

! ” # $ % & ’ ( ) * + , - . / : ;

1*1 *1

< = > ? @ [ ] ^ _ { | }

Editing DVD-RW discs in VR mode (Original) (cont’d)

Editing

Setting or clearing chapter markers

You can put chapter markers in each title. Once a chapter is marked, you can search for it using the chapter search feature. You can put a chapter marker anywhere you want. When the number of chapter markers in the original list comes to

999 in total, you cannot add

any more chapter markers.

First:

Press SETUP button. Select “DISC” using

{ / B buttons,

then press ENTER button.

DISC menu will appear.

Select “Edit” using K / L but- tons, then press ENTER button.

Original/PlayList menu will appear.

Screen:

Select “Original” using { / B buttons, then press ENTER button.

Original list will appear.

Select a desired title using K / L / { / B buttons, then press

ENTER button.

Original menu will appear.

Select “Chapter Mark” using K / L buttons, then press

ENTER button.

Option window will appear.

Select “Add” or “Delete” using

K / L buttons, then

press ENTER button.

Option window will appear.

<Add>:

DVD-RW

DVD

Disc

Edit

Forma t

Finalize

Disc Protect OFF ON

Disc > Edit > Original

JAN/1 1:00AM

JAN/1 4:00AM

Disc > Edit > Original

JAN/ 1 1:00AM CH12 XP

Disc > Edit

Disc > Edit > Original

Chapter 1/1

JAN/ 1 1:00AM CH12 XP

1 1 32

JAN/1 2:00AM JAN/1 3:00AM

JAN/1 5:00AM

Title Delete

Scene Delete Edit Title Name Chapter Mark Index Picture Set Protect OFF

Title Delete

Scene Delete Edit Title Name Chapter Mark Index Picture Protect OFF

0:01:25

Add Delete

0:01:25

AUDIO

ABC DEF

TUV WXYZ

VCR

DVD

PLAY

STOP

ENTER

OPEN/CLOSE

VIDEO/TV

SLOW

PAUSE

TIMER PROG.

RETURN

ONE TOUCH

DUBBING

POWER

REC SPEED

.@/:

123

GHI JKL MNO

456

PQRS

7809

SPACE

DISPLAY

SETUP

REC/OTR

REC MONITOR

MENU/LIST

TOP MENU

ZOOM SKIP SKIP

CLEAR/C.RESET

CM SKIP

MODE

Original

Disc > Edit > Original

Chapter 1/1

JAN/ 1 1:00AM CH12 XP

Title Delete

Scene Delete Edit Title Name Chapter Mark Index Picture Protect OFF

Add Delete

Yes No

0:01:25

Editing DVD-RW discs in VR mode (Original) (cont’d)

Editing

Changing the SETUP menu

Playing discs VCR functions

Before you start

Connections Getting started

Recording Editing Others

Español

<Delete>:

• You cannot delete the first chapter marker of each title.

Select “Yes” using { / B but- tons, then press ENTER button.

A chapter marker will be added.

<Add>:

The chapter marker which you selected will be deleted.

<Delete>:

After writing to disc is completed, press SETUP button to exit DISC menu.

This operation may take a few minutes to complete.

Note :Thumbnail Picture

• When you delete part of a title, the picture you chose to be the thumbnail for that part is deleted.A default picture will then be used by the unit

instead.

Setting pictures for thumbnails

POWER

REC SPEED

AUDIO

ZOOM SKIP SKIP

OPEN/CLOSE

TOP MENU

SPACE

VCR

SETUP

CM SKIP

TIMER PROG.

RETURN

123

456

7809

STOP

PLAY

VIDEO/TV

SLOW

PAUSE

.@/:

ABC DEF

GHI JKL MNO

PQRS

REC/OTR

REC MONITOR

MENU/LIST

CLEAR/C.RESET

MODE

ENTER

DISPLAY

TUV WXYZ

DVD

ONE TOUCH

DUBBING

ZOOM SKIP SKIP

TOP MENU

SPACE

VCR

SETUP

CM SKIP

TIMER PROG.

RETURN

7809

STOP

PLAY

VIDEO/TV

SLOW

PAUSE

PQRS

REC/OTR

REC MONITOR

MENU/LIST

CLEAR/C.RESET

MODE

ENTER

DISPLAY

TUV WXYZ

DVD

ONE TOUCH

DUBBING

1 2

You can use a picture for each title as a thumbnail. It helps you to remember the contents of the title you are playing.The beginning picture has been selected as the default.

First:

Press SETUP button. Select “DISC” using

{ / B buttons,

then press ENTER button.

DISC menu will appear.

Select “Edit” using K / L but- tons, then press ENTER button.

Original/PlayList menu will appear.

Screen:

Instructions continue on page 84.

Disc > Edit > Original

Chapter 2/2

JAN/ 1 1:00AM CH12 XP

Title Delete

Scene Delete Edit Title Name Chapter Mark Index Picture Protect OFF

Add Delete

Yes No

0:01:25

Disc > Edit > Original

Chapter 2/2

JAN/ 1 1:00AM CH12 XP

Writing to Disc

Title Delete Scene Delete Edit Title Name

Add

Chapter Mark

Delete

Index Picture Protect OFF

Yes No

Disc > Edit > Original

Chapter 1/1

JAN/ 1 1:00AM CH12 XP

Writing to Disc

DVD-RW

Disc

Edit

Forma t

Finalize

Disc Protect OFF ON

DVD

Title Delete

Scene Delete Edit Title Name

Add

Chapter Mark

Delete

Index Picture Protect OFF

Yes No

Disc > Edit

Original

Select “Original” using { / B buttons, then press ENTER button.

Original list will appear.

Select a desired title using K / L / { / B buttons, then press

ENTER button.

Original menu will appear.

Select “Index Picture Set” using

K / L buttons, then press ENTER button where you would like to capture the thumbnail image.

Option window will appear.

Select “Yes” using { / B but- tons, then press ENTER button.

A picture for thumbnail will be set.

After writing to disc is completed, press SETUP button to exit DISC menu.

This operation may take a few minutes to complete.

Editing DVD-RW discs in VR mode (Original) (cont’d)

Editing

POWER

REC SPEED

AUDIO

ZOOM SKIP SKIP

OPEN/CLOSE

TOP MENU

SPACE

VCR

SETUP

CM SKIP

TIMER PROG.

RETURN

123

456

7809

STOP

PLAY

VIDEO/TV

SLOW

PAUSE

.@/:

ABC DEF

GHI JKL MNO

PQRS

REC/OTR

REC MONITOR

MENU/LIST

CLEAR/C.RESET

MODE

ENTER

DISPLAY

TUV WXYZ

DVD

ONE TOUCH

DUBBING

3 4 5 6

Note

• The DVD disc will begin to play in a window.

Disc > Edit > Original

1 1 32

JAN/1 1:00AM

JAN/1 4:00AM

JAN/1 2:00AM JAN/1 3:00AM

JAN/1 5:00AM

Disc > Edit > Original

Title Delete

Scene Delete Edit Title Name Chapter Mark Index Picture Set Protect OFF

Disc > Edit > Original

JAN/ 1 1:00AM CH12 XP

Writing to Disc

Title Delete

Scene Delete Edit Title Name Chapter Mark Index Picture Set Protect OFF

Yes No

JAN/ 1 1:00AM CH12 XP

Disc > Edit > Original

JAN/ 1 1:00AM CH12 XP

Title Delete

Scene Delete Edit Title Name Chapter Mark Index Picture Set Protect OFF

0:01:25

Yes No

0:01:25

Editing DVD-RW discs in VR mode (Original) (cont’d)

Editing

Changing the SETUP menu

Playing discs VCR functions

Before you start

Connections Getting started

Recording Editing Others

Español

First:

Press SETUP button. Select “DISC” using { / B buttons, then press ENTER button.

DISC menu will appear.

Select “Edit” using K / L but- tons, then press ENTER button.

Original/PlayList menu will appear.

Screen:

Select “Original” using { / B buttons, then press ENTER button.

Original list will appear.

Select a desired title using K / L / { / B buttons, then press

ENTER button.

Original menu will appear.

Select “Protect OFF ➔ ON” using K / L buttons, then press ENTER button.

Option window will appear.

Select “Yes” using { / B but- tons, then press ENTER button.

After writing to disc is completed, press SETUP button to exit DISC menu.

This operation may take a few minutes to complete.

Title Protection

POWER

REC SPEED

AUDIO

ZOOM SKIP SKIP

OPEN/CLOSE

TOP MENU

SPACE

VCR

SETUP

CM SKIP

TIMER PROG.

RETURN

123

456

7809

STOP

PLAY

VIDEO/TV

SLOW

PAUSE

.@/:

ABC DEF

GHI JKL MNO

PQRS

REC/OTR

REC MONITOR

MENU/LIST

CLEAR/C.RESET

MODE

ENTER

DISPLAY

TUV WXYZ

DVD

ONE TOUCH

DUBBING

1 2 3 4

5 6

Important

•

To prevent accidental editing or erasing the titles, you can protect them from the original

menu.

Protect Disc

To protect a whole disc (DVD-RW VR mode Only):

Select “Disc Protect” from Disc menu, then select “Yes”.

DVD-RW

DVD

Disc

Edit

Forma t

Finalize

Disc Protect OFF ON

Disc > Edit

Original

Disc > Edit > Original

JAN/1 1:00AM

JAN/1 4:00AM

1 1 32

JAN/1 2:00AM JAN/1 3:00AM

JAN/1 5:00AM

Disc > Edit > Original

JAN/ 1 1:00AM CH12 XP

Title Delete

Scene Delete Edit Title Name Chapter Mark Index Picture Set Protect OFF

0:01:25

Disc > Edit > Original

JAN/ 1 1:00AM CH12 XP

Title Delete

Scene Delete Edit Title Name Chapter Mark Index Picture Set Protect OFF

Yes No

0:01:25

Disc > Edit > Original

JAN/ 1 1:00AM CH12 XP

Writing to Disc

Title Delete

Scene Delete Edit Title Name Chapter Mark Index Picture Set Protect OFF

Yes No

Editing DVD-RW discs in VR mode (Original) (cont’d)

Editing

You are allowed to release the titles from protection.

First:

Press SETUP button. Select “DISC” using

{ / B buttons,

then press ENTER button.

DISC menu will appear.

Select “Edit” using K / L but- tons, then press ENTER button.

Original/PlayList menu will appear.

Screen:

Select “Original” using { / B buttons, then press ENTER button.

Original list will appear.

Select a desired title using K / L / { / B buttons, then press

ENTER button.

Original menu will appear.

“Protect ON

➔ OFF” is selected.

Press ENTER button.

Option window will appear.

Select “Yes” using { / B but- tons, then press ENTER button.

After writing to disc is completed, press SETUP button to exit DISC menu.

This operation may take a few minutes to complete.

Releasing titles from protection

POWER

REC SPEED

AUDIO

ZOOM SKIP SKIP

OPEN/CLOSE

TOP MENU

SPACE

VCR

SETUP

CM SKIP

TIMER PROG.

RETURN

123

456

7809

STOP

PLAY

VIDEO/TV

SLOW

PAUSE

.@/:

ABC DEF

GHI JKL MNO

PQRS

REC/OTR

REC MONITOR

MENU/LIST

CLEAR/C.RESET

MODE

ENTER

DISPLAY

TUV WXYZ

DVD

ONE TOUCH

DUBBING

1 2 3 4

5 6

DVD-RW

DVD

Disc

Edit

Forma t

Finalize

Disc Protect OFF ON

Disc Edit > Original

JAN/ 1 2:00AM CH12 XP

Title Delete Scene Delete Edit Title Name Chapter Mark Index Picture Set Protect ON

0:01:25

OFF

Disc > Edit

Original

Disc > Edit > Original

1 1 32

JAN/1 1:00AM

JAN/1 4:00AM

JAN/1 2:00AM JAN/1 3:00AM

JAN/1 5:00AM

Disc Edit > Original

JAN/ 1 2:00AM CH12 XP

Title Delete

Scene Delete Edit Title Name Chapter Mark Index Picture Set Protect ON

Yes No

OFF

0:01:25

Disc Edit > Original

JAN/ 1 2:00AM CH12 XP

Writing to Disc

Title Delete

Scene Delete Edit Title Name Chapter Mark Index Picture Set Protect ON

Yes No

OFF

Editing DVD-RW discs in VR mode (Playlist)

Editing

Changing the SETUP menu

Playing discs VCR functions

Before you start

Connections Getting started

Recording Editing Others

Español

In VR mode, even when a title is deleted from a Playlist, the original title will remain in the Original list.

First:

Press SETUP button. Select “DISC” using { / B buttons, then press ENTER button.

DISC menu will appear.

Select “Edit” using K / L but- tons, then press ENTER button.

Original/PlayList menu will appear.

Screen:

Select “PlayList” using { / B buttons, then press ENTER button.

Playlist will appear.

Select a desired title using K / L / { / B buttons, then press

ENTER button.

Playlist menu will appear.

Select “Title Delete” using K / L buttons, then press ENTER button.

Option window will appear.

Select “Yes” using { / B but- tons, then press ENTER button.

Title will be deleted.

After writing to disc is completed, press SETUP button to exit DISC menu.

This operation may take a few minutes to complete.

Deleting titles

POWER

REC SPEED

AUDIO

ZOOM SKIP SKIP

OPEN/CLOSE

TOP MENU

SPACE

VCR

SETUP

CM SKIP

TIMER PROG.

RETURN

123

456

7809

STOP

PLAY

VIDEO/TV

SLOW

PAUSE

.@/:

ABC DEF

GHI JKL MNO

PQRS

REC/OTR

REC MONITOR

MENU/LIST

CLEAR/C.RESET

MODE

ENTER

DISPLAY

TUV WXYZ

DVD

ONE TOUCH

DUBBING

1 2 3 4

5 6

Note

•

The disc space

available for

recording

will not be increased.

DVD-RW

DVD

Disc > Edit > Playlist

Title Delete

Scene Delete Edit Title Name Chapter Mark Index Picture Set

Disc

Edit

Forma t

Finalize

Disc Protect OFF ON

Disc > Edit

Original

Disc > Edit > Playlist

JAN/1 1:00AM

JAN/1 4:00AM

1 1 32

JAN/1 2:00AM JAN/1 3:00AM

JAN/1 5:00AM

Add New

Delete

Title

Playlist

JAN/ 1 1:00AM CH12 XP

0:01:25

Disc > Edit > Playlist

JAN/ 1 1:00AM CH12 XP

Title Delete

Scene Delete Edit Title Name Chapter Mark Index Picture Set

Yes No

0:01:25

Disc > Edit > Playlist

JAN/ 1 1:00AM CH12 XP

Writing to Disc

Title Delete

Scene Delete Edit Title Name Chapter Mark Index Picture Set

Yes No

Editing DVD-RW discs in VR mode (Playlist) (cont’d)

Editing

Deleting parts of titles

You can delete part of a title. Even when a title is deleted from the playlist, the original title will remain.

First:

Press SETUP button. Select “DISC” using { / B buttons, then press ENTER button.

DISC menu will appear.

Select “Edit” using K / L but- tons, then press ENTER button.

Original/PlayList menu will appear.

Screen:

Select “PlayList” using { / B buttons, then press ENTER button.

Playlist will appear.

Select a desired title using K / L / { / B buttons, then press

ENTER button.

Playlist menu will appear.

Select “Scene Delete” using K / L buttons, then press ENTER button.

Option window will appear.

Select Start-End Point.

Press ENTER button to decide a start point.

Then press ENTER button to decide an end point.

A cursor will move to “Preview”. You can check a preview.

1 2 3 4 5 6

Note

•

The disc space available for recording will not be increased.

Note

•DVD will begin to play in a window.

DVD-RW

DVD

Disc

Edit

Forma t

Finalize

Disc Protect OFF ON

Disc > Edit > Playlist

JAN/ 1 1:00AM CH12 XP

Title Delete

Scene Delete Edit Title Name Chapter Mark Index Picture Set

0:01:25

Disc > Edit > Playlist

Title Delete

Scene Delete Edit Title Name Chapter Mark Index Picture

Start End Preview Delete

POWER

REC SPEED

.@/:

ABC DEF

123

GHI JKL MNO

456

PQRS

TUV WXYZ

7809

SPACE

VCR

DISPLAY

PLAY

STOP

SETUP

REC/OTR

REC MONITOR

MENU/LIST

TOP MENU

ZOOM SKIP SKIP

CLEAR/C.RESET

CM SKIP

MODE

AUDIO

DVD

ENTER

OPEN/CLOSE

VIDEO/TV

SLOW

PAUSE

TIMER PROG.

RETURN

ONE TOUCH

DUBBING

Disc > Edit

Original

Disc > Edit > Playlist

1 1 32

JAN/1 1:00AM

JAN/1 4:00AM

JAN/1 2:00AM JAN/1 3:00AM

Add New

Title

Delete

JAN/1 5:00AM

Playlist

JAN/ 1 1:00AM CH12 XP

0:00:55

Before editing

Edited

Start point End point

Editing DVD-RW discs in VR mode (Playlist) (cont’d)

Editing

Changing the SETUP menu

Playing discs VCR functions

Before you start

Connections Getting started

Recording Editing Others

Español

Select “Delete” using K / L buttons, then press ENTER button.

Option window will appear.

Select “Yes” using { / B but- tons, then press ENTER button.

Part of a title will be deleted.

After writing to disc is completed, press SETUP button to exit DISC menu.

This operation may take a few minutes to complete.

Naming Titles

ZOOM SKIP SKIP

TOP MENU

SPACE

VCR

SETUP

CM SKIP

TIMER PROG.

RETURN

123

456

7809

STOP

PLAY

VIDEO/TV

SLOW

PAUSE

.@/:

ABC DEF

GHI JKL MNO

PQRS

REC/OTR

REC MONITOR

MENU/LIST

CLEAR/C.RESET

MODE

ENTER

DISPLAY

TUV WXYZ

DVD

ONE TOUCH

DUBBING

7 8

POWER

REC SPEED

AUDIO

ZOOM SKIP SKIP

OPEN/CLOSE

TOP MENU

SPACE

VCR

SETUP

CM SKIP

TIMER PROG.

RETURN

123

456

7809

STOP

PLAY

VIDEO/TV

SLOW

PAUSE

.@/:

ABC DEF

GHI JKL MNO

PQRS

REC/OTR

REC MONITOR

MENU/LIST

CLEAR/C.RESET

MODE

ENTER

DISPLAY

TUV WXYZ

DVD

ONE TOUCH

DUBBING

1 2 3

Note : Chapter Markers

•You cannot select “Scene Delete” when the number of chapter markers in the original or playlist is more than 900.

Yo u can title names on the titles and change the names from this menu. The names of the titles will be displayed on a titlelist.

First:

Press SETUP button. Select “DISC” using

{ / B buttons,

then press ENTER button.

DISC menu will appear.

Select “Edit” using K / L but- tons, then press ENTER button.

Original/PlayList menu will appear.

Screen:

Select “PlayList” using { / B buttons, then press ENTER button.

Playlist will appear.

Instructions continue on page 90.

Disc > Edit > Playlist

JAN/ 1 1:00AM CH12 XP

Title Delete

Scene Delete Edit Title Name Chapter Mark Index Picture

Start End Preview Delete

Yes No

0:01:25

DVD-RW

DVD

Disc > Edit > Playlist

JAN/ 1 1:00AM CH12 XP

Writing to Disc

Title Delete

Scene Delete Edit Title Name Chapter Mark Index Picture

Start End Preview Delete

Yes No

Disc > Edit

Disc

Edit

Forma t

Finalize

Disc Protect OFF ON

Original

Disc > Edit > Playlist

1 1 32

JAN/1 1:00AM

JAN/1 4:00AM

JAN/1 2:00AM JAN/1 3:00AM

Add New

Title

Delete

JAN/1 5:00AM

Playlist

Editing DVD-RW discs in VR mode (Playlist) (cont’d)

Editing

Select a desired title using K / L / { / B buttons, then press

ENTER button.

Playlist menu will appear.

Select “Edit Title Name” using

K / L buttons, then

press ENTER button.

A window for entering a title name will appear.

To enter a title name, follow the steps of "Guide to edit title name" on this page.

character set

area for entering title names

When you finish entering a title name, press ENTER button.

Select “Yes” using { / B but- tons, then press ENTER button.

The name you entered will be activated for the title.

After writing to disc is completed, press SETUP to exit DISC menu.

This operation may take a few minutes to complete.

4 5 6 7

Disc > Edit > Playlist

JAN/ 1 1:00AM CH12 XP

Title Delete

Scene Delete Edit Title Name Chapter Mark Index Picture Set

0:01:25

Disc > Edit > Playlist > Edit Title Name

JAN/ 1 1:00AM CH12 XP

A B C

a b c 1 2 3 @ ! ?

0:01:25

Disc > Edit > Playlist > Edit Title Name

A B C

a b c 1 2 3

@ ! ?

JAN/ 1 1:00AM CH12 XP

0:01:25

Disc > Edit > Playlist > Edit Title Name

abc

Writing to Disc

A B C

a b c 1 2 3

@ ! ?

Yes No

POWER

REC SPEED

.@/:

123

GHI JKL MNO

456

PQRS

7809

SPACE

DISPLAY

SETUP

REC/OTR

REC MONITOR

MENU/LIST

TOP MENU

CLEAR/C.RESET

CM SKIP

MODE

[

Guide to edit title name

[

Step1]: Select a desired character set using K/L

buttons, then press ENTER button.

[

]

Step2

: Press Number buttons following by the list

below.

Select

ABC

Press

<space>

ABC

DEF

GHI

JKL

5 6

MNO

PQRS

7 8

TUV

WXYZ

* Press button, character set will be changed to the " @

• To delete letters, press CLEAR/C.RESET button repeatedly. Holding CLEAR/C.CRESET button to delete all letters.

• To go on to the next entering area for letters, press button.

• You can enter up to 30 letters.

" mode automatically.

OPEN/CLOSE

AUDIO

ABC DEF

TUV WXYZ

VCR

ZOOM SKIP SKIP

VIDEO/TV

SLOW

DVD

PAUSE

PLAY

STOP

TIMER PROG.

ENTER

RETURN

ONE TOUCH

DUBBING

abc

123

abc

def

ghi

jkl

mno

pqrs

tuv

wxyz

]

A B C

a b c 1 2 3 @ ! ?

@ ! ?

! ” # $ % & ’ ( ) * + , - . / : ;

1*1 *1

< = > ? @ [ ] ^ _ { | }

Editing DVD-RW discs in VR mode (Playlist) (cont’d)

Editing

Changing the SETUP menu

Playing discs VCR functions

Before you start

Connections Getting started

Recording Editing Others

Español

Setting or clearing chapter markers

POWER

REC SPEED

AUDIO

ZOOM SKIP SKIP

OPEN/CLOSE

TOP MENU

SPACE

VCR

SETUP

CM SKIP

TIMER PROG.

RETURN

123

456

7809

STOP

PLAY

VIDEO/TV

SLOW

PAUSE

.@/:

ABC DEF

GHI JKL MNO

PQRS

REC/OTR

REC MONITOR

MENU/LIST

CLEAR/C.RESET

MODE

ENTER

DISPLAY

TUV WXYZ

DVD

ONE TOUCH

DUBBING

1 2 3 4 5 6

You can put chapter markers in each title. Once a chapter is marked, you can search for them by using the chapter search feature. You can put a chapter marker anywhere you want. When the number of chapter markers in the playlist comes to 999 in total, you cannot add any more chapter markers.

First:

Press SETUP button. Select “DISC” using

{ / B buttons,

then press ENTER button.

DISC menu will appear.

Select “Edit” using K / L but- tons, then press ENTER button.

Original/PlayList menu will appear.

Screen:

Select “PlayList” using { / B buttons, then press ENTER button.

Playlist will appear.

Select a desired title using K / L / { / B buttons, then press

ENTER button.

Playlist menu will appear.

Select “Chapter Mark” using K / L buttons, then press

ENTER button.

Option window will appear.

Select “Add” or “Delete” using

K / L buttons, then

press ENTER button.

Option window will appear.

<Add>:

Instructions continue on page

90.

DVD-RW

DVD

Disc

Edit

Forma t

Finalize

Disc Protect OFF ON

Disc > Edit

Original

Disc > Edit > Playlist

1 1 32

JAN/1 1:00AM

JAN/1 4:00AM

JAN/1 2:00AM JAN/1 3:00AM

Add New

Title

Delete

JAN/1 5:00AM

Playlist

Disc > Edit > Playlist

JAN/ 1 1:00AM CH12 XP

Title Delete

Scene Delete Edit Title Name Chapter Mark Index Picture Set

0:01:25

Disc > Edit > Playlist

Chapter 1/1

JAN/ 1 1:00AM CH12 XP

Title Delete

Scene Delete Edit Title Name Chapter Mark Index Picture Set

Add Delete

0:01:25

Disc > Edit > Playlist

Chapter 1/1

JAN/ 1 1:00AM CH12 XP

Title Delete

Scene Delete Edit Title Name Chapter Mark Index Picture Set

Add Delete

Yes No

0:01:25

Editing DVD-RW discs in VR mode (Playlist) (cont’d)

Editing

<Delete>:

• You cannot delete the first chapter of each title.

elect “Yes” using { / B but-

tons, then press ENTER button.

A chapter marker will be added.

<Add>:

The chapter marker which you selected will be deleted.

<Delete>:

After writing to disc is completed, press SETUP button to exit DISC menu.

This operation may take a few minutes to complete.

Note :Thumbnail

• If a selected picture for a thumbnail is deleted by deleting a part of a title, a default

picture will be selected.

Setting pictures for thumbnails

You can set a picture to each title for a thumbnail. It helps you to remember the contents of the title you are playing.The beginning picture has been selected as the default.

First:

Press SETUP button. Select “DISC” using

{ / B buttons,

then press ENTER button.

DISC menu will appear.

Select “Edit” using K / L but- tons, then press ENTER button.

Original/PlayList menu will appear.

Screen:

POWER

REC SPEED

AUDIO

ZOOM SKIP SKIP

OPEN/CLOSE

TOP MENU

SPACE

VCR

SETUP

CM SKIP

TIMER PROG.

RETURN

123

456

7809

STOP

PLAY

VIDEO/TV

SLOW

PAUSE

.@/:

ABC DEF

GHI JKL MNO

PQRS

REC/OTR

REC MONITOR

MENU/LIST

CLEAR/C.RESET

MODE

ENTER

DISPLAY

TUV WXYZ

DVD

ONE TOUCH

DUBBING

1 2

Disc > Edit > Playlist

Chapter 2/2

JAN/ 1 1:00AM CH12 XP

Title Delete

Scene Delete Edit Title Name Chapter Mark Index Picture Set

Yes No

Add Delete

0:01:25

Disc > Edit > Playlist

Chapter 1/1

JAN/ 1 1:00AM CH12 XP

Writing to Disc

Title Delete

Scene Delete Edit Title Name Chapter Mark Index Picture Set

Yes No

Add Delete

Disc > Edit > Playlist

Chapter 2/2

JAN/ 1 1:00AM CH12 XP

Writing to Disc

Title Delete

Scene Delete Edit Title Name Chapter Mark Index Picture Set

Yes No

Add Delete

POWER

REC SPEED

.@/:

ABC DEF

123

GHI JKL MNO

456

PQRS

TUV WXYZ

7809

SPACE

VCR

DISPLAY

PLAY

STOP

SETUP

REC/OTR

REC MONITOR

MENU/LIST

TOP MENU

ZOOM SKIP SKIP

CLEAR/C.RESET

CM SKIP

MODE

AUDIO

DVD

ENTER

OPEN/CLOSE

VIDEO/TV

SLOW

PAUSE

TIMER PROG.

RETURN

ONE TOUCH

DUBBING

DVD-RW

DVD

Disc

Edit

Forma t

Finalize

Disc Protect OFF ON

Disc > Edit

Original

Editing DVD-RW discs in VR mode (Playlist) (cont’d)

Editing

Changing the SETUP menu

Playing discs VCR functions

Before you start

Connections Getting started

Recording Editing Others

Español

Select “PlayList” using { / B buttons, then press ENTER button.

Playlist will appear.

Select a desired title using K / L / { / B buttons, then press

ENTER button where you would like to capture the thumbnail image.

Playlist menu will appear.

Select “Index Picture Set” using K / L buttons, then press ENTER button where you would like to capture the thumbnail image.

Option window will appear.

Select “Yes” using { / B but- tons, then press ENTER button.

A picture for thumbnail will be set.

After writing to disc is completed, press SETUP button to exit DISC menu.

This operation may take a few minutes to complete.

3 4 5 6

Note

• The DVD will begin to play in a window.

Disc > Edit > Playlist

1 1 32

JAN/1 1:00AM

JAN/1 4:00AM

JAN/1 2:00AM JAN/1 3:00AM

Add New

Title

Delete

JAN/1 5:00AM

Playlist

Disc > Edit > Playlist

Title Delete

Scene Delete Edit Title Name Chapter Mark Index Picture Set

Disc > Edit > Playlist

JAN/ 1 1:00AM CH12 XP

Writing to Disc

Title Delete

Scene Delete Edit Title Name Chapter Mark Index Picture Set

Yes No

POWER

REC SPEED

.@/:

ABC DEF

123

GHI JKL MNO

456

PQRS

TUV WXYZ

7809

SPACE

VCR

DISPLAY

PLAY

STOP

SETUP

REC/OTR

REC MONITOR

MENU/LIST

TOP MENU

ZOOM SKIP SKIP

CLEAR/C.RESET

CM SKIP

MODE

AUDIO

DVD

ENTER

OPEN/CLOSE

VIDEO/TV

SLOW

PAUSE

TIMER PROG.

RETURN

ONE TOUCH

DUBBING

JAN/ 1 1:00AM CH12 XP

0:01:25

Disc > Edit > Playlist

JAN/ 1 1:00AM CH12 XP

Title Delete

Scene Delete Edit Title Name Chapter Mark Index Picture Set

Yes No

0:01:25

Editing DVD-RW discs in VR mode (Playlist) (cont’d)

Editing

You can add or delete a title in the playlist as you prefer. You can add titles to a Playlist up to

99.

First:

Press SETUP button. Select “DISC” using

{ / B buttons,

then press ENTER button.

DISC menu will appear.

Select “Edit” using K / L but- tons, then press ENTER button.

Original/PlayList menu will appear.

Screen:

Select “PlayList” using { / B buttons, then press ENTER button.

Playlist will appear.

Select “Add New Title” using K / L / { / B buttons, then

press ENTER button.

Original list will appear.

Select a desired title using K / L / { / B buttons, then press

ENTER button.

After writing to disc is completed, press SETUP button to exit DISC menu.

To delete a title from Playlist, refer to “Deleting titles” on page

87. To delete a Playlist, refer to “Deleting a Playlist” on page

95.

Adding titles to a Playlist

POWER

REC SPEED

AUDIO

ZOOM SKIP SKIP

OPEN/CLOSE

TOP MENU

SPACE

VCR

SETUP

CM SKIP

TIMER PROG.

RETURN

123

456

7809

STOP

PLAY

VIDEO/TV

SLOW

PAUSE

.@/:

ABC DEF

GHI JKL MNO

PQRS

REC/OTR

REC MONITOR

MENU/LIST

CLEAR/C.RESET

MODE

ENTER

DISPLAY

TUV WXYZ

DVD

ONE TOUCH

DUBBING

1 2 3 4

DVD-RW

DVD

Disc

Edit

Forma t

Finalize

Disc Protect OFF ON

Disc > Edit > Playlist > Add New Title

1 1 32

JAN/12 5:00PM JAN/12 8:00PMJAN/10 10:30AM

Disc > Edit > Playlist > Add New Title

Disc > Edit

Original

Disc > Edit > Playlist

1 1 32

JAN/1 1:00AM

JAN/1 4:00AM

JAN/1 2:00AM JAN/1 3:00AM

JAN/1 5:00AM

Add New

Delete

Title

Playlist

Writing to Disc

Disc > Edit > Playlist

1 1 32

JAN/1 1:00AM

JAN/1 4:00AM

JAN/1 2:00AM

JAN/1 5:00AM

58%

JAN/1 3:00AM

JAN/12 8:00PM

Editing DVD-RW discs in VR mode (Playlist) (cont’d)

Editing

Changing the SETUP menu

Playing discs VCR functions

Before you start

Connections Getting started

Recording Editing Others

Español

Note : Deleting Playlist

•Deleting a Playlist will not increase the available record-

ing time on disc.

First:

Press SETUP button. Select “DISC” using

{ / B buttons,

then press ENTER button.

DISC menu will appear.

Select “Edit” using K / L but- tons, then press ENTER button.

Original/PlayList menu will appear.

Screen:

Select “PlayList” using { / B buttons, then press ENTER button.

Playlist will appear.

Select “Delete Playlist” using K / L / { / B buttons, then

press ENTER button.

Option window will appear.

Select “Yes” using { / B but- tons, then press ENTER button.

Playlist will be erased. After writing to disc is completed, the DVD/VCR will be in stop mode.

Deleting a Playlist

POWER

REC SPEED

AUDIO

ZOOM SKIP SKIP

OPEN/CLOSE

TOP MENU

SPACE

VCR

SETUP

CM SKIP

TIMER PROG.

RETURN

123

456

7809

STOP

PLAY

VIDEO/TV

SLOW

PAUSE

.@/:

ABC DEF

GHI JKL MNO

PQRS

REC/OTR

REC MONITOR

MENU/LIST

CLEAR/C.RESET

MODE

ENTER

DISPLAY

TUV WXYZ

DVD

ONE TOUCH

DUBBING

1 2 3 4 5

Important

•

A Playlist can be deleted if no

longer needed.

Caution

•

If a playlist is deleted it can

not be brought back.

DVD-RW

DVD

Disc > Edit > Playlist

1 1 32

JAN/1 1:00AM

JAN/1 4:00AM

JAN/1 2:00AM JAN/1 3:00AM

Add New

Title

Delete

Playlist

JAN/1 5:00AM

Yes No

Disc

Edit

Forma t

Finalize

Disc Protect OFF ON

Disc > Edit

Original

Disc > Edit > Playlist

JAN/1 1:00AM

JAN/1 4:00AM

1 1 32

JAN/1 2:00AM JAN/1 3:00AM

JAN/1 5:00AM

Add New

Delete

Title

Playlist

Editing DVD-R discs

Editing

You can delete titles which you do not need, however the disc space available for recording on the disc will not be changed.

First:

Press SETUP button. Select “DISC” using

{ / B buttons,

then press ENTER button.

DISC menu will appear.

Select “Edit” using K / L but- tons, then press ENTER button.

Titlelist will appear.

Screen:

Select a desired title using K / L / { / B buttons, then press

ENTER button.

Edit menu will appear.

You cannot select “Chapter Mark”.

Select “Title Delete” using K / L buttons, then press ENTER button.

Option window will appear.

Select “Yes” using { / B but- tons, then press ENTER button.

Title will be deleted.

After writing to disc is completed, press SETUP button to exit DISC menu.

This operation may take a few minutes to complete.

Deleting titles

POWER

REC SPEED

AUDIO

ZOOM SKIP SKIP

OPEN/CLOSE

TOP MENU

SPACE

VCR

SETUP

CM SKIP

TIMER PROG.

RETURN

123

456

7809

STOP

PLAY

VIDEO/TV

SLOW

PAUSE

.@/:

ABC DEF

GHI JKL MNO

PQRS

REC/OTR

REC MONITOR

MENU/LIST

CLEAR/C.RESET

MODE

ENTER

DISPLAY

TUV WXYZ

DVD

ONE TOUCH

DUBBING

1 2 3 4

Important

•

Be sure to know that the titles once deleted cannot be

brought back to the disc.

Caution

•

Once a title has been deleted,

it can not be brought back.

DVD-R

DVD

Disc

Edit

Forma t

Finalize

Disc > Edit

JAN/ 1 1:00AM CH12 XP

Title Delete

Edit Title Name Chapter Mark

0:01:25

Disc > Edit

JAN/ 1 1:00AM CH12 XP

Title Delete

Edit Title Name Chapter Mark

Yes No

0:01:25

Disc > Edit

1 1 32

JAN/1 1:00AM

JAN/1 4:00AM

JAN/1 2:00AM JAN/1 3:00AM

JAN/1 5:00AM

Disc > Edit

JAN/ 1 1:00AM CH12 XP

Writing to Disc

Title Delete

Edit Title Name Chapter Mark

Yes No

Editing DVD-R discs (cont’d)

Editing

Changing the SETUP menu

Playing discs VCR functions

Before you start

Connections Getting started

Recording Editing Others

Español

You can name titles and change the names from this menu. The title names will be displayed on a titlelist.

First:

Press SETUP button. Select “DISC” using { / B buttons, then press ENTER button.

DISC menu will appear.

Select “Edit” using

K / L

but-

tons, then press ENTER button.

Titlelist will appear.

Screen:

Select a desired title using K / L / { / B buttons, then press

ENTER button.

Edit menu will appear.

You cannot select “Chapter Mark”.

Select “Edit Title Name” using K / L buttons, then press ENTER button.

A window for entering a title name will appear.

To enter a title name, follow the steps of "Guide to edit title name" on this page.

character set

area for entering title names

When you finish entering a title name, press ENTER button.

Select “Yes” using { / B but- tons, then press ENTER button.

After writing to disc is completed, press SETUP button to exit DISC menu.

This operation may take a few minutes to complete.

Naming Titles

1 2 3 4

5 6

DVD-R

DVD

Disc

Edit

Forma t

Finalize

Disc > Edit

1 1 32

JAN/1 1:00AM

JAN/1 4:00AM

JAN/1 2:00AM JAN/1 3:00AM

JAN/1 5:00AM

Disc > Edit

JAN/ 1 1:00AM CH12 XP

Title Delete

Edit Title Name Chapter Mark

0:01:25

Disc > Edit > Edit Title Name

JAN/ 1 1:00AM CH12 XP

A B C

a b c 1 2 3

@ ! ?

0:01:25

Disc > Edit > Edit Title Name

A B C

a b c 1 2 3

@ ! ?

JAN/ 1 1:00AM CH12 XP

0:01:25

Disc > Edit > Edit Title Name

abc

Writing to Disc

A B C

a b c 1 2 3

@ ! ?

Yes No

OPEN/CLOSE

AUDIO

ABC DEF

PLAY

STOP

DVD

ENTER

VIDEO/TV

SLOW

PAUSE

TIMER PROG.

RETURN

ONE TOUCH

DUBBING

TUV WXYZ

VCR

ZOOM SKIP SKIP

POWER

REC SPEED

.@/:

123

GHI JKL MNO

456

PQRS

7809

SPACE

DISPLAY

SETUP

REC/OTR

REC MONITOR

MENU/LIST

TOP MENU

CLEAR/C.RESET

CM SKIP

MODE

[

Guide to edit title name

[

Step1]: Select a desired character set using K/L

buttons, then press ENTER button.

[

]

Step2

: Press Number buttons following by the list

below.

Select

ABC

Press

<space>

ABC

DEF

GHI

JKL

5 6

MNO

PQRS

7 8

TUV

WXYZ

* Press button, character set will be changed to the " @

• To delete letters, press CLEAR/C.RESET button repeatedly. Holding CLEAR/C.CRESET button to delete all letters.

• To go on to the next entering area for letters, press button.

• You can enter up to 30 letters.

abc

abc

def

ghi

jkl

mno

pqrs

tuv

wxyz

" mode automatically.

123

]

A B C

a b c 1 2 3 @ ! ?

@ ! ?

! ” # $ % & ’ ( ) * + , - . / : ;

1*1 *1

< = > ? @ [ ] ^ _ { | }

Troubleshooting

Others

Before requesting service for this unit, check the table below for a possible cause of the problem you are experiencing. Some simple corrections may eliminate the problem and restore proper operation.

Symptom Remedy

Power


Sound

The power does not turn on. • Check that the AC power cord is connected securely.

There is no picture.

Picture noise appears.

TV station does not appear

TV program pictures are distorted.

TV channels cannot be changed.

The playback picture or TV program from the equipment connected through the unit is distorted.

There is no sound. • The disc is dirty or flawed.

Sound is noisy.

• Re-connect the connecting cord securely.

• The Setup Display appears. Press SETUP or RETURN button to turn off the display.

• Check the connection to your TV (page 10).

• Check the RF output channel when you view a TV program using RF connection.

• Check if the INTERLACE/PROGRESSIVE mode is set correctly according to your TV. See page 10.

• Switch the input selector on your TV (such as to "LINE1") so that the signal from this DVD/VCR appears on the TV screen.

• Check the antenna/cable wire connections.

• The disc is dirty or flawed.

• Head cleaning for VCR may be necessary. Refer to “AUTO HEAD CLEANING”. If the picture output signal from the unit passes through your VCR

• to get to your TV, or if you are connected to a combination TV/VIDEO player, the copy-protection signal applied to some DVD programs could affect picture quality. If you still experience this problem even when you connect the unit directly to your TV, try connecting the unit to your TV's S-VIDEO input.

• Adjust tracking control for better picture by pressing CHANNEL (o buttons while you are playing a video tape.

• Check the antenna/cable wire connections.

•Try to set the channels with "Auto Preset" in SETUP menu (page 16). Select a channel of any TV program using the CH o / p buttons.

•

•Press VIDEO/TV button if necessary.

• Check the antenna/cable wire connections.

• Adjust TV antenna.

• Adjust the picture (see the TV's instruction manual).

• Place the unit and TV farther apart.

• Place the TV and any bunched antenna cables farther apart.

• Switch the input to TV.

• Connect the antenna cable correctly (page 10).

• If the playback picture output from a DVD player, VCR, or tuner goes through the unit before reaching your TV, the copyprotection signal applied to some programs could affect picture quality. Disconnect the playback equipment in question and connect it directly to your TV.

• Check the antenna/cable wire connections.

• Re-connect all connections securely.

• The connecting cord is damaged.

• Check the connections to the amplifier input.

• The input source setting on the amplifier is incorrect.

• The unit is in pause mode or in Slow-motion Play mode.

• The unit is in fast forward or fast reverse mode.

• If the audio signal does not come through the DIGITAL AUDIO OUT (COAXIAL) jack, check the Audio Setup settings (pages 30-31).

• The disc is dirty or flawed.

p) buttons on this unit or CH ( o / p)

Troubleshooting (cont’d)

Others

Changing the SETUP menu

Playing discs VCR functions

Before you start

Connections Getting started

Recording Editing Others

Español

Symptom Remedy

Playback

The disc does not play.

The disc does not start playback from the beginning.

The unit starts playing from the disc automatically.

Some functions such as Stop, Search, or Slow-motion Play cannot be performed.

The language for the sound track cannot be changed.

The subtitle language cannot be changed or turned off.

The angles cannot be changed.

Recording/Timer recording/Editing

The channel cannot be changed from the channel you are recording.

Recording does not start immediately after you press REC/OTR button.

Nothing was recorded even though you set the timer setting correctly.

Recording does not stop immediately after you press STOP C button.

Timer recording is not complete or did not start from the beginning.

Timer recording is impossible.

• No disc is inserted.

•A blank disc is inserted.

• No cassette tape is inserted. The disc is upside down. Insert the disc with the labeled side facing up.

•

• The disc is not correctly inserted. The unit cannot play certain discs (such as a CD-ROM) (page 34).

•

• The region code on the DVD VIDEO does not match the unit (page 34).

• Moisture has condensed inside the unit. Remove the disc and leave the unit turned on at least for 2 hours until the moisture evaporates (page 4).

• If the disc was recorded on another recorder, the unit cannot play the disc if it was not finalized (page 71).

• Resume play was activated (page 39). Press STOP C button twice.

•You have inserted a disc whose Title menu or DVD menu automatically appears on the TV screen when it is first insert.

• The DVD VIDEO features an auto playback function.

•

Depending on the disc, you may not be able to do some of the operations above. See the instruction manual supplied with the disc.

• Multilingual tracks are not recorded on the DVD VIDEO, DVD-R or DVD-RW being played.

• The DVD VIDEO prohibits the changing of the language for the sound track.

•Try changing the language using the DVD VIDEO's menu.

• Multilingual subtitle are not recorded on the DVD VIDEO.

• The DVD VIDEO prohibits changing of the subtitles.

•Try changing the subtitle using the DVD VIDEO's menu.

• Multi-angles are not recorded on the DVD VIDEO being played.

•You are trying to change the angles when icon does not appear on the TV screen (page 49).

• The DVD VIDEO prohibits changing angles.

•Try changing the angle using the DVD VIDEO's menu.

• Set the TV's input to "TV".

• An unused DVD-R or DVD-RW was inserted. It takes a while for the unit to automatically format a DVD-RW.

• Make sure the tape has a safety tab when you record to a cassette tape. If needed, cover the hole with cellophane tape.

•There was a power failure during recording.

• The units internal clock stopped due to a power failure that lasted for more than 30 seconds. Reset the clock (pages 19-20).

• Disconnect the AC power cord from the AC outlet, and connect it again. The program contains copy protection signals that restricts copying.

•

• The timer setting overlapped with another setting that was set later or has priority.

• It will take a few seconds for the unit to input disc data before recording can stop.

• The timer setting overlapped with another setting that was set later or has priority (page 66).

• Disc space was not enough.

•

Make sure indicator appears on the front display of this unit. If not, press POWER button.

•

Clock has not been set.

100

Others

Troubleshooting (cont’d)

Symptom Remedy

Remote control

The remote control does not function.

Others

The unit does not operate properly. • When static electricity, etc., causes the unit to operate

The disc tray does not open when you press OPEN/CLOSE A button.

"Repairing" appears on the display. •If there is a power failure or unplugging during recording,

Repairing

Disc Error

--- Please eject the disc. --- Playback feature may not be

available on this Disc.

Unplayable disc is inserted in the unit.

• Batteries are weak.

• There are obstacles between the remote control and the unit.

• The remote control is far from the unit.

• There are no batteries in the remote control.

•Turn on the unit.

• The remote control is not pointed at the remote sensor on the unit.

•

Press the DVD or VCR button, whichever you need. Then, try again.

abnormally, unplug the unit and then plug it in again.

• It may take a few seconds for the disc tray to open after you have recorded or edited a disc.

• This is because the unit is adding disc data to the disc.

finalizing, formatting or editing, a Repairing process will begin automatically just after turning the unit on again. It may take several minutes up to about four hours.

CauseError message Solution

Insert the standardized disc which bear the marks on page 34.

Region Error

--- Please eject the disc. --- Playback is not authorized in your

region.

Parental Lock On

--- Please eject the disc. --- The current selected parental level

Prohibits playback.

Recording Error

This program is not allowed to be recorded.

Recording Error

This program is not recordable in Video mode.

Recording Error

Can not record on this disc.

Recording Error

This program is not allowed to be recorded on this disc.

Recording Error

This disc is protected and not recordable.

Playback is not authorized because the region code of the DVD video disc you inserted is different.

The current selected parental level in the SETUP Menu prohibits playback.

The recording function encountered the copy prohibited program.

You are trying to record copyonce program onto the DVD-RW disc in Video mode or the DVD disc.

You are trying to record onto disc which is unrecordable, or the disc status prevents recording.

You are trying to record the copyonce program onto a DVD-RW disc which is not compatible with CPRM.

You are trying to record on to the protected disc which is set in the Disc Setting Menu.

Insert the DVD-Video disc with region codes 1 or ALL.

Check the "Parental Lock" setting (pages 32-33).

You cannot record copy prohibited programs.

Set "DVD-RW Recording Format" to "VR mode" (page 58).

Insert the recordable disc, and ensure the disc status satisfies the recording requirements (pages 56-72).

Insert a ver. 1.1 CPRM compatible DVD-RW disc (page 57).

Release the disc protect setting in the Disc Setting menu (page 72).

Funai SRDV495 User Manual

Specifications and Main Features

Frequently Asked Questions

User Manual
