Funai SP120C User Manual

IMPORTANT

SAFEGUARDS

PRECAUTIONSDESCRIPTION

OF CONTROLS

DISPLAYSTATUS

DISPLAY

PREPARATION

FOR USE

PLAYBACK

FUNCTION

TROUBLESHOOTING

GUIDE

WARRANTY

INSTRUCCIONES

EN ESPAÑOL

MAINTENANCE

SPECIFICATIONS

OWNER’S
MANUAL

VIDEO CASSETTE
RECORDER

If you need additional
operating assistance after
reading this owner's manual
or to order replacement
accessories, please call
TOLL FREE : 1-800-242-7158.

SP120C

CAUTION: TO REDUCE THE RISK OF ELECTRIC
SHOCK, DO NOT REMOVE COVER (OR BACK).
NO USER SERVICEABLE PARTS INSIDE. REFER
SERVICING TO QUALIFIED SERVICE PERSONNEL.

The caution marking is located on the rear of the cabinet.

The lightning flash with arrowhead symbol, within
an equilateral triangle, is intended to alert the user
to the presence of uninsulated "dangerous voltage"
within the product's enclosure that may be of suffi­cient magnitude to constitute a risk of electric
shock to persons.

The exclamation point within an equilateral triangle
is intended to alert the user to the presence of impor­tant operating and maintenance (servicing) instruc­tions in the literature accompanying the product.

CAUTION

RISK OF ELECTRIC SHOCK

DO NOT OPEN

WARNING:

TO REDUCE THE RISK OF FIRE OR ELECTRIC SHOCK,
DO NOT EXPOSE THIS APPLIANCE TO RAIN OR MOISTURE.

IMPORTANT SAFEGUARDS

1. Read Instructions- All the safety and operating instructions should be

read before the appliance is operated.

2. Retain Instructions- The safety and operating instructions should be

retained for future reference.

3. Heed Warnings- All warnings on the appliance and in the operating

instructions should be adhered to.

4. Follow Instructions- All operating and use instructions should be

followed.

5. Cleaning- Unplug this video product from the wall outlet before

cleaning. Do not use liquid cleaners or aerosol cleaners. Use a
damp cloth for cleaning.
EXCEPTION: A product that is meant for uninterrupted service and, that
for some specific reason, such as the possibility of the loss of an
authorization code for a CATV converter, is not intended to be
unplugged by the user for cleaning or any other purpose, may exclude
the reference to unplugging the appliance in the cleaning description
otherwise required in item 5.

6. Attachments- Do not use attachments not recommended by the video

product manufacturer as they may cause hazards.

7. Water and Moisture- Do not use this video product near water, for

example, near a bath tub, wash bowl, kitchen sink, or laundry tub, in a
wet basement, or near a swimming pool, and the like.

8. Accessories- Do not place this video product on an unstable cart,

stand, tripod, bracket, or table. The video product may fall, causing
serious injury to a child or adult, and serious damage to the
appliance. Use only with a cart, stand, tripod, bracket, or
table recommended by the manufacturer, or sold with the
video product. Any mounting of the appliance should follow
the manufacturer's instructions and should use a mounting
accessory recommended by the manufacturer. An
appliance and cart combination should be moved with
care. Quick stops, excessive force, and uneven surfaces
may cause the appliance and cart combination to overturn.

9. Ventilation- Slots and openings in the cabinet are provided for

ventilation and to ensure reliable operation of the video product and to
protect it from overheating, and these openings must not be blocked or
covered. The openings should never be blocked by placing the video
product on a bed, sofa, rug, or other similar surface. This video product
should not be placed in a built-in installation such as a bookcase or rack
unless proper ventilation is provided or the manufacturer's instructions
have been adhered to .

10. Power Sources- This video product should be operated only from the

type of power source indicated on the marking label. If you are not sure
of the type of power supply to your home, consult your appliance dealer
or local power company. For products intended to operate from battery
power, or other sources, refer to the operating instructions.

11. Grounding or Polarization- This video product is equipped with a

polarized alternating-current line plug (a plug having one blade wider
than the other). This plug will fit into the power outlet only one way. This
is a safety feature. If you are unable to insert the plug fully into the outlet,
try reversing the plug. If the plug should still fail to fit, contact your
electrician to replace your obsolete outlet. Do not defeat the safety
purpose of the polarized plug.

12. Power Cord Protection- Power supply cords should be routed so that

they are not likely to be walked on or pinched by items placed upon or
against them, paying particular attention to cords at plugs, convenience
receptacles, and the point where they exit from the appliance.

13. Outdoor Antenna Grounding- If an outside antenna or cable system is

connected to the video product, be sure the antenna or cable system is
grounded so as to provide some protection against voltage surges and
built-up static charges. Article 810 of the National Electrical Code,
ANSI/NFPANo. 70, provides information with regard to proper
grounding of the mast and supporting structure, grounding of the lead-in
wire to an antenna discharge unit, size of grounding conductors, location
of antenna-discharge unit, connection to grounding electrodes, and
requirements for the grounding electrode. (Fig. A)

14. Lightning- For added protection for this video product during a lightning

storm, or when it is left unattended and unused for long periods of time,
unplug it from the wall outlet and disconnect the antenna or cable
system. This will prevent damage to the video product due to lightning
and power-line surges.

15. Power Lines- An outside antenna system should not be located in the

vicinity of overhead power lines or other electric light or power circuits, or
where it can fall into such power lines or circuits. When installing an
outside antenna system, extreme care should be taken to keep from
touching such power lines or circuits as contact with them might be fatal.

16. Overloading- Do not overload wall outlets and extension cords as this

can result in a risk of fire or electric shock.

17. Object and Liquid Entry- Never push objects of any kind into this video

product through any openings as they may touch dangerous voltage
points or short-out parts that could result in a fire or electric shock. Never
spill liquid of any kind on the video product.

18. Servicing- Do not attempt to service this video product yourself as

opening or removing covers may expose you to dangerous voltage or
other hazards. Refer all servicing to qualified service personnel.

19. Damage Requiring Service- Unplug this video product from the wall

outlet and refer servicing to qualified service personnel under the
following conditions:

a. When the power-supply cord or plug is damaged.
b. If liquid has been spilled, or objects have fallen into the video product.
c. If the video product has been exposed to rain or water.
d. If the video product does not operate normally by following the operating

instructions. Adjust only those controls that are covered by the operating
instructions as an improper adjustment of other controls may result in
damage and will often require extensive work by a qualified technician to
restore the video product to its normal operation.

e. If the video product has been dropped or damaged in any way.

f. When the video product exhibits a distinct change in performance-this

indicates a need for service.

20. Replacement Parts- When replacement parts are required, be sure the

service technician has used replacement parts specified by the
manufacturer or have the same characteristics as the original part.
Unauthorized substitutions may result in fire, electric shock or other
hazards.

21. Safety Check- Upon completion of any service or repairs to this video

product, ask the service technician to perform safety checks to
determine that the video product is in proper operating condition.

22. Heat- This video product should be situated away from heat sources

such as radiators, heat registers, stoves, or other products (including
amplifiers) that produce heat.

FIGURE A

EXAMPLE OF ANTENNA GROUNDING

AS PER NATIONAL ELECTRICAL CODE

GROUND
CLAMP

ELECTRIC
SERVICE
EQUIPMENT

NEC – NATIONAL ELECTRICAL CODE

S2898A

GROUNDING CONDUCTORS
(NEC SECTION 810-21)

GROUND CLAMP

POWER SERVICE GROUNDING
ELECTRODE SYSTEM
(NEC ART 250, PART H)

ANTENNA
LEAD
WIRE

ANTENNA
DISCHARGE UNIT
(NEC SECTION 810-20)

– 2 –

EN

INSTALL LOCATION

For safety and optimum performance of your VCP:

• Install the VCP in a horizontal and stable position.
Do not place anything directly on top of the VCP.
Do not place the VCP directly on top of the TV.

• Shield it from direct sunlight and keep it away from
sources of intense heat. Avoid dusty or humid
places. Avoid places with insufficient ventilation for
proper heat dissipation. Do not block the ventilation
holes on the sides of the VCP. Avoid locations
subject to strong vibration or strong magnetic fields.

AVOID THE HAZARDS OF
ELECTRICAL SHOCK AND FIRE

• Do not handle the power cord with wet hands.

• Do not pull on the power cord when disconnecting
it from AC wall outlet. Grasp it by the plug.

• If, by accident, water is spilled on your VCP, unplug
the power cord immediately and take the unit to our
Authorized Service Center for servicing.

• Do not put your fingers or objects into the VCP
cassette holder.

MOISTURE CONDENSATION WARNING

Moisture condensation may occur inside the unit
when it is moved from a cold place to a warm place,
or after heating a cold room or under conditions of
high humidity. Do not use the VCP at least for 2
hours until its inside is dry.

FCC WARNING

This equipment may generate or use radio frequency
energy. Changes or modifications to this equipment
may cause harmful interference unless the
modifications are expressly approved in the
instruction manual. The user could lose the authority
to operate this equipment if an unauthorized change
or modification is made.

PRECAUTIONS

IMPORTANT COPYRIGHT
INFORMATION

Unauthorized recording or use of broadcast
television programming, video tape, film or other
copyrighted material may violate applicable copyright
laws. We assume no responsibility for the
unauthorized duplication, use, or other acts which
infringe upon the rights of copyright owners.

A NOTE ABOUT RECYCLING

This product's packaging materials are recyclable

and can be reused. Please dispose of any materials

in accordance with your local recycling regulations.

Batteries should never be thrown away or
incinerated but disposed of in accordance with your
local regulations concerning chemical wastes.

Note to the Cable TV System Installer:

This reminder is provided to call the Cable TV
system installer’s attention to Article 820-40 of the
National Electrical Code, which provides guidelines
for proper grounding – in particular, specifying that
the cable ground shall be connected to the
grounding system of the building, as close to the
point of cable entry as possible.

CAUTION:
TO PREVENT ELECTRIC SHOCK, MATCH WIDE
BLADE OF PLUG TO WIDE SLOT, FULLY
INSERT.

ATTENTION:
POUR ÉVITER LES CHOC ÉLECTRIQUES,
INTRODUIRE LA LAME LA PLUS LARGE DE LA
FICHE DANS LA BORNE CORRESPONDANTE
DE LA PRISE ET POUSSER JUSQU’AU FOND.

PRECAUTIONS

0:12:34

PLAY MODE

REWIND MODE

FAST FORWARD MODE

EJECT MODE

STOP MODE

<OFF mode>

<STATUS mode>

<COUNTER mode>

5 SECONDS

Press

once

Press once

– 3 –

EN

1. POWER button

2. DISPLAY button

3. REW button

4. STOP button

5. STILL button

6. F.FWD button

7. PLAY button

8. COUNTER RESET button

9. AUTO REPEAT button

10. PICTURE SELECT button

11. TRACKING buttons

12. EJECT button

12. AC Power Cord

13. AUDIO OUT jack

14. ANT. IN jack

15. VIDEO OUT jack

16. CH3/CH4 selector switch

17. ANT. OUT jack

18.

DC13.2V (12V) supply jack

19.

REMOTE CONTROL jack

20.

TV REMOTE LINK jack

Front Panel

POWER

AUTO

REPEAT

SELECT

POWER

AUTO REPEAT

REW F.FWD PLAY

STOP/EJECT

9 6 8 7 10 11 3 5 4 2 1

Remote Control

POWER

TRACKING

DISPLAY

REW

PLAY

STOP

F.FWD

EJECT

COUNTER

RESET


SELECT

AUTO

REPEAT

1

11

3

4

5

6

2

8

12

STILL

7

9

10

Rear Panel

ANT OUT

ANT IN

AUDIO

CH3

CH4

VIDEO

OUTPUT

TV LINK
REMOTE

REMOTE
CONTROL

DC 13. 2V

12

18

1519

20

16

17 14

13

Install two AA batteries matching
the polarity indicated inside the
battery compartment.

1. Cassette Compartment

2. STOP/EJECT button

3. REW button

4. PLAY button

5. F.FWD button

6. AUTO REPEAT button

7. PICTURE SELECT

8. Remote Sensor

9. POWER button

10. POWER indicator

11. AUTO REPEAT indicator

DESCRIPTION OF CONTROLS

To insert the batteries

STATUS DISPLAY

When you press the function buttons or turn on the VCP,
the status display will appear on the TV screen for 5
seconds.

DISPLAY

Press [DISPLAY] to display the tape status, real time tape
counter, and other information on the TV screen. (only on
the remote control)
Each time you press this button, TV screen will change as
shown.

DESCRIPTION

OF CONTROLS

DISPLAYSTATUS

DISPLAY

0:12:34 0:12:34
