Fujitsu T5440 User Manual

SPARC Enterprise
TM
T5440 Server
Administration Guide
Manual Code C120-E511-01EN Part No. 875-4390-10
July 2009, Revision B
Copyright ©2009 Sun Microsystems, Inc., 4150Network Circle,Santa Clara,California 95054, U.S.A.All rightsreserved. FUJITSU LIMITEDprovided technicalinput and review onportions of this material. Sun Microsystems,Inc. andFujitsu Limited eachown orcontrol intellectualproperty rights relating to products andtechnology described in
this document,and such products, technology andthis documentare protectedby copyright laws, patents andother intellectualproperty laws and internationaltreaties. Theintellectual property rights of SunMicrosystems, Inc.and Fujitsu Limited in suchproducts, technologyand this document include,without limitation, one or moreof theUnited States patentslisted athttp://www.sun.com/patentsand one or more additional patentsor patent applications in theUnited States or other countries.
This documentand the product and technologyto whichit pertains are distributed underlicenses restrictingtheir use,copying, distribution, and decompilation.No part of such productor technology,or of this document, maybe reproducedin anyform by anymeans withoutprior written authorizationof Fujitsu Limited and SunMicrosystems, Inc.,and their applicable licensors, ifany.The furnishingof this documentto you doesnot give you any rightsor licenses, express or implied, with respectto theproduct ortechnology to whichit pertains,and this document doesnot contain or representany commitment ofany kindon the partof FujitsuLimited or SunMicrosystems, Inc.,or anyaffiliate of either ofthem.
This documentand the product and technologydescribed inthis document may incorporate third-partyintellectual propertycopyrighted by and/or licensedfrom suppliersto Fujitsu Limitedand/or SunMicrosystems, Inc.,including software and font technology.
Per theterms of the GPL orLGPL, a copy of thesource codegoverned by the GPL orLGPL, as applicable, is availableupon requestby the End User.Please contactFujitsu Limited orSun Microsystems,Inc.
This distributionmay include materials developed bythird parties. Parts ofthe productmay be derivedfrom BerkeleyBSD systems,licensed from the University ofCalifornia. UNIX is a registered trademarkin
the U.S.and in other countries, exclusivelylicensed throughX/Open Company, Ltd. Sun™, SunMicrosystems™, theSun logo
SunSolveSM, CoolThreads™,and J2EE™,are trademarksor registeredtrademarks of SunMicrosystems, Inc.or itssubsidiaries in theU.S. and other countries.
©
, Java™,Netra™, Solaris™, Sun StorageTek™, docs.sun.comSM, OpenBoot™,SunVTS™, Sun Fire™,
Fujitsu andthe Fujitsu logo are registered trademarksof FujitsuLimited. All SPARCtrademarks areused under licenseand areregistered trademarksof SPARC International, Inc. inthe U.S. and other countries.
Products bearingSPARCtrademarks arebased uponarchitecture developedby Sun Microsystems, Inc. SPARC64 isa trademark ofSPARCInternational, Inc.,used under license by FujitsuMicroelectronics, Inc.and FujitsuLimited. SSH isa registeredtrademark ofSSH Communications Securityin theUnited States andin certainother jurisdictions. The OPENLOOK and Sun™ Graphical UserInterface was developed by SunMicrosystems, Inc.for its users and licensees.Sun acknowledges
the pioneeringefforts ofXerox inresearching anddeveloping the conceptof visualor graphical userinterfaces forthe computer industry.Sun holds anon-exclusive license from Xeroxto the Xerox GraphicalUser Interface, whichlicense alsocovers Sun’s licensees who implementOPEN LOOK GUIsand otherwise comply with Sun’swritten license agreements.
United StatesGovernment Rights - Commercial use.U.S. Governmentusers aresubject to thestandard governmentuser license agreements of Sun Microsystems,Inc. andFujitsu Limited andthe applicableprovisions ofthe FARand itssupplements.
Disclaimer: Theonly warranties granted by FujitsuLimited, Sun Microsystems, Inc. or any affiliateof eitherof them inconnection withthis document orany productor technology described herein are those expressly setforth inthe license agreement pursuantto whichthe product or technology isprovided.
EXCEPT ASEXPRESSLYSET FORTHIN SUCHAGREEMENT, FUJITSULIMITED, SUNMICROSYSTEMS, INC. AND THEIR AFFILIATES MAKE NOREPRESENTATIONS ORWARRANTIESOF ANYKIND (EXPRESS ORIMPLIED) REGARDINGSUCH PRODUCT OR TECHNOLOGY ORTHIS DOCUMENT, WHICHARE ALLPROVIDED AS IS,AND ALLEXPRESS OR IMPLIEDCONDITIONS, REPRESENTATIONSAND WARRANTIES, INCLUDINGWITHOUT LIMITATIONANY IMPLIEDWARRANTYOF MERCHANTABILITY, FITNESS FORA PARTICULARPURPOSE OR NON-INFRINGEMENT, AREDISCLAIMED, EXCEPTTO THE EXTENT THATSUCH DISCLAIMERS AREHELD TOBE LEGALLY INVALID.
Unless otherwiseexpressly setforth in suchagreement, tothe extentallowed by applicablelaw,in noevent shall FujitsuLimited, Sun Microsystems, Inc.or anyof their affiliates haveany liability to any thirdparty underany legal theory for anyloss of revenues or profits, lossof use ordata, or business interruptions, orfor anyindirect, special, incidental or consequentialdamages, even if advised ofthe possibilityof such damages.
DOCUMENTATIONIS PROVIDED “ASIS” ANDALL EXPRESS ORIMPLIED CONDITIONS,REPRESENTATIONS ANDWARRANTIES, INCLUDING ANYIMPLIED WARRANTY OFMERCHANTABILITY,FITNESS FORA PARTICULARPURPOSE OR NON-INFRINGEMENT, ARE DISCLAIMED,EXCEPT TOTHE EXTENT THATSUCH DISCLAIMERS ARE HELD TOBE LEGALLYINVALID.
Please
Copyright ©2009 Sun Microsystems, Inc., 4150Network Circle,Santa Clara,California 95054, Etats-Unis.Tousdroits réservés. Entrée etrevue tecnicalfournies par FUJITSULIMITED surdes parties de ce matériel. Sun Microsystems,Inc. etFujitsu Limited détiennentet contrôlenttoutes deux des droits depropriété intellectuellerelatifs auxproduits et
technologies décritsdans ce document. De même,ces produits,technologies et ce document sontprotégés pardes lois surle copyright,des brevets, d’autres loissur la propriété intellectuelle etdes traitésinternationaux. Les droits depropriété intellectuellede Sun Microsystems, Inc. et FujitsuLimited concernant ces produits, cestechnologies etce document comprennent, sansque cette liste soit exhaustive,un ouplusieurs des brevetsdéposés auxÉtats-Unis et indiquésà l’adressehttp://www.sun.com/patentsde mêmequ’un ou plusieursbrevets ouapplications brevetées supplémentaires auxÉtats-Unis et dans d’autres pays.
Ce document,le produitet les technologiesafférents sont exclusivement distribuésavec des licences qui enrestreignent l’utilisation,la copie,la distribution etla décompilation. Aucune partie dece produit,de ces technologies ou dece document ne peut êtrereproduite sous quelque forme quece soit, par quelque moyenque ce soit, sans l’autorisationécrite préalablede Fujitsu Limitedet deSun Microsystems, Inc., et deleurs éventuels bailleursde licence. Ce document, bienqu’il vous ait été fourni,ne vousconfère aucun droit et aucunelicence, expressesou tacites, concernant leproduit oula technologie auxquelsil serapporte. Par ailleurs, il necontient ni ne représente aucunengagement, dequelque type que cesoit, de la part deFujitsu Limited ou de SunMicrosystems, Inc.,ou des sociétés affiliées.
Ce document,et le produit et lestechnologies qu’ildécrit, peuvent inclure des droits depropriété intellectuellede parties tierces protégéspar copyright et/oucédés sous licence par desfournisseurs à Fujitsu Limited et/ouSun Microsystems,Inc., y compris des logicielset des technologies relativesaux policesde caractères.
Par limitesdu GPL ou du LGPL,une copie du code source régipar le GPLou LGPL,comme applicable, estsur demandevers la fin utilsateur disponible; veuillezcontacter Fujitsu Limted ou SunMicrosystems, Inc.
Cette distributionpeut comprendredes composantsdéveloppés par destierces parties. Des partiesde ce produit pourrontêtre dérivées des systèmes BerkeleyBSD licenciés par l’Université deCalifornie. UNIX est une marque
déposée auxEtats-Unis et dans d’autres payset licenciéeexclusivement par X/OpenCompany, Ltd. Sun™, SunMicrosystems™, lelogo Sun
SunSolveSM, CoolThreads™,et J2EE™sont des marques defabrique ou des marques déposéesde SunMicrosystems, Inc., ou sesfiliales aux Etats-Unis etdans d’autrespays.
©
, Java™,Netra™, Solaris™, Sun StorageTek™, docs.sun.comSM, OpenBoot™,SunVTS™, Sun Fire™,
Fujitsu etle logo Fujitsu sont desmarques déposéesde Fujitsu Limited. Toutes lesmarques SPARC sont utilisées souslicence et sont des marques defabrique ou desmarques déposéesde SPARC International, Inc.
aux Etats-Uniset dans d’autres pays. Lesproduits portantles marquesSPARCsont basés sur une architecture développéepar Sun Microsystems, Inc.
SPARC64 estune marquesdéposée de SPARCInternational, Inc., utilisée sous lepermis par Fujitsu Microelectronics,Inc. et FujitsuLimited. SSH estune marquedéposée registrede SSH Communications Security auxEtats-Uniset dans certaines autres juridictions. L’interfaced’utilisation graphiqueOPEN LOOK etSun™ aété développée parSun Microsystems,Inc. pourses utilisateurs etlicenciés. Sun
reconnaît lesefforts depionniers deXerox pour la recherche et le développementdu conceptdes interfaces d’utilisationvisuelle ougraphique pour l’industriede l’informatique. Sun détient unelicense non exclusive de Xeroxsur l’interfaced’utilisation graphique Xerox, cette licence couvrant égalementles licenciésde Sun quimettent enplace l’interfaced’utilisation graphique OPENLOOK etqui, en outre, se conforment aux licences écritesde Sun.
Droits dugouvernement américain- logiciel commercial. Lesutilisateurs du gouvernement américain sontsoumis auxcontrats de licence standard deSun Microsystems,Inc. etde Fujitsu Limitedainsi qu’auxclauses applicables stipuléesdans leFAR et ses suppléments.
Avis denon-responsabilité: lesseules garanties octroyées parFujitsu Limited, SunMicrosystems, Inc.ou toutesociété affiliée de l’une oul’autre entité enrapport avec ce document outout produitou toute technologie décrit(e) dansles présentes correspondent aux garantiesexpressément stipulées dansle contrat de licence régissantle produitou la technologie fourni(e).
SAUF MENTIONCONTRAIRE EXPRESSÉMENT STIPULÉE DANS CECONTRAT, FUJITSULIMITED, SUNMICROSYSTEMS, INC. ETLES SOCIÉTÉS AFFILIÉESREJETTENT TOUTEREPRÉSENTATION OUTOUTE GARANTIE,QUELLE QU’EN SOIT LA NATURE (EXPRESSE OU IMPLICITE)CONCERNANT CE PRODUIT, CETTETECHNOLOGIE OUCE DOCUMENT, LESQUELSSONT FOURNIS EN L’ÉTAT. EN OUTRE, TOUTESLES CONDITIONS,REPRÉSENTATIONS ETGARANTIES EXPRESSES OU TACITES,Y COMPRISNOTAMMENT TOUTE GARANTIE IMPLICITERELATIVEÀ LA QUALITÉMARCHANDE, ÀL’APTITUDE À UNE UTILISATIONPARTICULIÈREOU À L’ABSENCEDE CONTREFAÇON, SONTEXCLUES, DANSLA MESURE AUTORISÉE PARLA LOI APPLICABLE.
Sauf mentioncontraire expressémentstipulée dansce contrat, dansla mesureautorisée par la loi applicable,en aucun cas Fujitsu Limited,Sun Microsystems, Inc.ou l’unede leurs filialesne sauraientêtre tenuesresponsables envers une quelconque partietierce, sousquelque théorie juridique quece soit, de tout manqueà gagner ou de pertede profit,de problèmesd’utilisation ou deperte dedonnées, ou d’interruptions d’activités, oude tout dommage indirect, spécial,secondaire ouconsécutif, mêmesi ces entitésont étépréalablement informées d’unetelle éventualité.
LA DOCUMENTATION ESTFOURNIE “EN L’ETAT”ET TOUTESAUTRES CONDITIONS, DECLARATIONS ETGARANTIES EXPRESSES OU TACITES SONT FORMELLEMENT EXCLUES,DANS LAMESURE AUTORISEEPARLA LOI APPLICABLE,Y COMPRISNOTAMMENT TOUTE GARANTIEIMPLICITE RELATIVE ALA QUALITEMARCHANDE, A L’APTITUDE AUNE UTILISATION PARTICULIERE OUA L’ABSENCEDE CONTREFACON.

Contents

Preface ix
Basic Administrative Tasks 1
Initial System Setup 1
Communicating With the System 2
ILOM Overview 2
Log In to ILOM 3
Log In to the System Console 4
Display the ok Prompt 4
Display the ILOM ->Prompt 5
System Console Output Options 5
Access the System Console Through a Local Graphics Monitor 6
Performing Common Tasks 7
Power On the System 7
Power Off the System 7
Reset the System 8
Update the Firmware 9
Manage Disk Volumes 13
Hardware RAID Support 13
Creating RAID Volumes 14
Create a Hardware Mirrored Volume 14
Create a Hardware Mirrored Volume of the Default Boot Device 15
v
Create a Hardware Striped Volume 17
Configure and Label a Hardware RAID Volume for Use in the Solaris
Operating System 18
Disk Slot Numbers 20
Removing Hardware RAID Volumes 21
Delete a Hardware RAID Volume 21
Hot-Plug a Mirrored Disk 23
Hot-Plug a Nonmirrored Disk 24
Manage the System 27
Searching for Faults 27
Log In to ILOM 28
Display System Faults 28
Run Full POST Diagnostics on Reset 29
Locate the System 30
Bypassing Minor Faults 31
Automatic System Recovery 31
Enable Automatic System Recovery 31
Disable Automatic System Recovery 32
View Components Affected by ASR 33
Clearing Faults 33
Clear Component Fault Messages 34
Managing Devices 34
Unconfigure a Device Manually 34
Configure a Device Manually 35
Devices and Device Identifiers 35
Use Logical Domains Software 37
Understanding Logical Domains Software 37
Logical Domain Software Overview 38
vi SPARC Enterprise T5440 Server Administration Guide • July 2009
Logical Domain Configurations 39
Logical Domains Software Requirements 39
Operating the Solaris OS With Logical Domains 40
OpenBoot Firmware Not Available After Solaris OS Has Started if
Domaining Is Enabled 40
Power-Cycle a Server 40
Save Your Current Logical Domain Configurations to the SC 41
Result of an OpenBoot power-off Command 41
Result of Solaris OS Breaks 41
Results From Halting or Rebooting the Control Domain 41
Additional Documentation 43
ALOM-to-ILOM Command Reference 45
ILOM and ALOM CMT Command Comparison 45
Index 53
Contents vii
viii SPARC Enterprise T5440 Server Administration Guide • July 2009

Preface

This manual is for experienced system administrators. This manual includes general descriptive information about the SPARC Enterprise™ T5440 server, and detailed instructions for configuring and administering the server. To use the information in this document, you must have working knowledge of computer network concepts and terms, and advanced familiarity with the Solaris™ Operating System (Solaris OS).
Note – For information about changing the hardware configuration of your server,
or about running diagnostics, see the service manual for your server.
For Safe Operation
This manual contains important information regarding the use and handling of this product. Read this manual thoroughly. Use the product according to the instructions and information available in this manual. Keep this manual handy for further reference.
Fujitsu makes every effort to prevent users and bystanders from being injured or from suffering damage to their property. Use the product according to this manual.
ix
Structure and Contents of This Manual
This manual is organized as described below:
“Basic Administrative Tasks” on page 1
Describes how to communicate with the server, and perform basic administrative tasks.
“Manage Disk Volumes” on page 13
Describes how to manage internal disk volumes.
“Manage the System” on page 27
Describes how to manage the system remotely.
“Use Logical Domains Software” on page 37
Introduces logical domains software.
“ALOM-to-ILOM Command Reference” on page 45
Lists and describes ALOM CMT compatibility shell equivalents for ILOM commands.
x SPARC Enterprise T5440 Server Administration Guide • July 2009
Related Documentation
The latest versions of all the SPARC Enterprise™ Series manuals are available at the following Web sites:
Global Site
(http://www.fujitsu.com/sparcenterprise/manual/)
Japanese Site
(http://primeserver.fujitsu.com/sparcenterprise/manual/)
Title Description Manual Code
SPARC Enterprise T5440 Server Getting Started Guide
SPARC Enterprise T5440 Server Product Notes
Important Safety Information for Hardware Systems
SPARC Enterprise T5440 Server Safety and Compliance Guide
SPARC Enterprise/ PRIMEQUEST Common Installation Planning Manual
SPARC Enterprise T5440 Server Site Planning Guide
SPARC Enterprise T5440 Server Installation and Setup Guide
SPARC Enterprise T5440 Server Service Manual
SPARC Enterprise T5440 Server Administration Guide
Integrated Lights Out Manager
2.0 User’s Guide
Integrated Lights Out Manager
2.0 Supplement for SPARC Enterprise T5440 Server
Minimum steps to power on and boot the server for the first time
Information about the latest product updates and issues
Safety information that is common to all SPARC Enterprise series servers
Safety and compliance information that is specific to the server
Requirements and concepts of installation and facility planning for the setup of SPARC Enterprise and PRIMEQUEST
Server specifications for site planning C120-H029
Detailed rackmounting, cabling, power on, and configuring information
How to run diagnostics to troubleshoot the server, and how to remove and replace parts in the server
How to perform administrative tasks that are specific to the server
Information that is common to all platforms managed by Integrated Lights Out Manager (ILOM) 2.0
How to use the ILOM 2.0 software on the server
C120-E504
C120-E508
C120-E391
C120-E509
C120-H007
C120-E510
C120-E512
C120-E511
C120-E474
C120-E513
Preface xi
Title Description Manual Code
Integrated Lights Out Manager (ILOM) 3.0 Concepts Guide
Integrated Lights Out Manager (ILOM) 3.0 Getting Started Guide
Integrated Lights Out Manager (ILOM) 3.0 Web Interface Procedures Guide
Integrated Lights Out Manager (ILOM) 3.0 CLI Procedures Guide
Integrated Lights Out Manager (ILOM) 3.0 SNMP and IPMI Procedures Guide
Integrated Lights Out Manager (ILOM) 3.x Feature Updates and Release Notes
Integrated Lights Out Manager (ILOM) 3.0 Supplement for SPARC Enterprise T5440 Server
External I/O Expansion Unit Installation and Service Manual
External I/O Expansion Unit Product Notes
Information that describes ILOM 3.0 features and functionality
Information and procedures for network connection, logging in to ILOM 3.0 for the first time, and configuring a user account or a directory service
Information and procedures for accessing ILOM 3.0 functions using the ILOM web interface
Information and procedures for accessing ILOM 3.0 functions using the ILOM CLI
Information and procedures for accessing ILOM 3.0 functions using SNMP or IPMI management hosts
Enhancements that have been made to ILOM firmware since the ILOM 3.0 release
How to use the ILOM 3.0 software on the server
Procedures for installing the External I/O Expansion Unit on the SPARC Enterprise T5120/T5140/T5220/T5240/T5440 servers
Important and late-breaking information about the External I/O Expansion Unit
C120-E573
C120-E576
C120-E574
C120-E575
C120-E579
C120-E600
C120-E587
C120-E543
C120-E544
Note – Product Notes are available on the website only. Please check for the recent
update on your product.
xii SPARC Enterprise T5440 Server Administration Guide • July 2009
UNIX Commands
This document might not contain information on basic UNIX®commands and procedures such as shutting down the system, booting the system, and configuring devices. Refer to the following for this information:
Software documentation that you received with your system
Solaris™ Operating System documentation, which is at
(http://docs.sun.com)
Text Conventions
Typeface* Meaning Examples
AaBbCc123 The names of commands, files,
and directories; on-screen computer output
AaBbCc123 What you type, when
contrasted with on-screen computer output
AaBbCc123 Book titles, new words or terms,
words to be emphasized. Replace command-line variables with real names or values.
Edit your .login file. Use ls -a to list all files.
% You have mail.
% su Password:
Read Chapter 6 in the User’s Guide. These are called class options. To delete a file, type rm filename.
* The settings on your browser might differ from these settings.
Preface xiii
Prompt Notations
The following prompt notations are used in this manual.
Shell Prompt Notations
C shell machine-name%
C shell superuser machine-name#
Bourne shell and Korn shell $
Bourne shell and Korn shell superuser #
ILOM service processor ->
ALOM compatibility shell sc>
OpenBoot PROM firmware ok
Fujitsu Welcomes Your Comments
If you have any comments or requests regarding this document, or if you find any unclear statements in the document, please state your points specifically on the form at the following URL.
For Users in U.S.A., Canada, and Mexico:
(https://download.computers.us.fujitsu.com/)
For Users in Other Countries:
(http://www.fujitsu.com/global/contact/computing/sparce_index.ht ml)
xiv SPARC Enterprise T5440 Server Administration Guide • July 2009

Basic Administrative Tasks

This section contains information about common tasks used to manage your system after initial setup.
Description Links
Refer to your systems’ installation and setup guide for initial setup instructions.
Access the system using ILOM, or configure alternate ways to communicate with the system.
Perform common tasks. “Power On the System” on page 7
“Initial System Setup” on page 1
“ILOM Overview” on page 2 “Log In to ILOM” on page 3 “Log In to the System Console” on page 4 “Display the ok Prompt” on page 4 “System Console Output Options” on page 5 “Access the System Console Through a Local
Graphics Monitor” on page 6
“Power Off the System” on page 7 “Reset the System” on page 8 “Update the Firmware” on page 9

Initial System Setup

For directions on initial system setup, see the installation guide for your server. That book contains the following information:
Installing the Server Hardware
Configuring the Service Processor
Setting Up the Operating System Software
1

Communicating With the System

This section contains:
“ILOM Overview” on page 2
“Log In to ILOM” on page 3
“Log In to the System Console” on page 4
“Display the ok Prompt” on page 4
“Display the ILOM ->Prompt” on page 5
“System Console Output Options” on page 5
“Access the System Console Through a Local Graphics Monitor” on page 6

ILOM Overview

Integrated Lights Out Manager (ILOM) is a low-level system management tool used to monitor and manage system components, diagnose problems, and manage the service processor. The service processor card acts independently of the host system, and is available when the main system power is shut down.
By default, the service processor is the gateway to the system, through its two ports: network management (NET MGT) and serial management (SER MGT). After initial installation, typically you connect an Ethernet cable from the network management port to your management network. This setup enables remote access to ILOM, which you can manage from either the command-line interface or the web interface.
For more information about ILOM, see the Integrated Lights Out Management
Supplement for the SPARC Enterprise T5440 Server and the Integrated Lights Out Manager (ILOM) 3.0 Concepts Guide.
If you are familiar with the ALOM CMT, see the “ILOM and ALOM CMT Command
Comparison” on page 45 section to see how ILOM commands map to common
ALOM commands.
Related Information
“Log In to ILOM” on page 3
“Display the ILOM ->Prompt” on page 5
“Log In to the System Console” on page 4
2 SPARC Enterprise T5440 Server Administration Guide • July 2009

Log In to ILOM

This procedure assumes the default configuration of the service processor as described in your server’s installation guide. To set up the default service processor configuration, see your server’s installation guide.
Open an SSH session and connect to the service processor by specifying its IP
address.
The ILOM default username is root and the default password is changeme.
% ssh root@xxx.xxx.xxx.xxx ... Are you sure you want to continue connecting (yes/no) ? yes
... Password: password (nothing displayed) Waiting for daemons to initialize...
Daemons ready
Integrated Lights Out Manager
Version 2.0.0.0
Copyright 2008 Sun Microsystems, Inc. All rights reserved. Use is subject to license terms.
->
You are now logged into ILOM. Perform tasks as needed. For more information about ILOM, refer to the ILOM supplement for your server
and the following documents:
Integrated Lights Out Manager (ILOM) 3.0 Concepts Guide
Integrated Lights Out Manager (ILOM) 3.0 Getting Started Guide
Note – In order to provide optimum system security, change the default system
password.
Related Information
“ILOM Overview” on page 2
“Log In to the System Console” on page 4
Basic Administrative Tasks 3

Log In to the System Console

1. Log in to ILOM.
See “Log In to ILOM” on page 3.
2. To access the system console from ILOM, type:
-> start /SP/console Are you sure you want to start /SP/console (y/n) ? y Serial console started. To stop, type #. . . .
You are logged in to the system console. Perform tasks as needed.
Related Information
“Display the ok Prompt” on page 4
“Display the ILOM ->Prompt” on page 5
Display the ok Prompt
This procedure assumes the default system console configuration.
1. Decide which method you need to use to reach the ok prompt.
Caution – When possible, reach the ok prompt by performing a graceful shutdown
of the OS. Any other method used may result in the loss of system state data.
2. Use the appropriate shutdown method from the following table.
System State What To Do
OS Running and Responsive
4 SPARC Enterprise T5440 Server Administration Guide • July 2009
• From a shell or command tool window, issue an appropriate command (for example, the shutdown or init 0 command) as described in Solaris system administration documentation.
• From the ILOM -> prompt, type:
-> Stop /SYS
• Use the system Power button.
System State What To Do
OS Unresponsive From the ILOM -> prompt, type the set /HOST send_break_action=
break command provided the operating system software is not running and the server is already under OpenBoot firmware control. Then issue the start /SP/console command.
OS Unresponsive and Need to Prevent auto-boot
From the ILOM -> prompt, type:
-> set /HOST/bootmode script=”setenv auto-boot? false” Press Enter. Then type:
-> reset /SYS
-> start /SP/console
Related Information
“Display the ILOM ->Prompt” on page 5

Display the ILOM ->Prompt

Use one of the following ways to get to the ILOM -> prompt:
From the system console, type the ILOM escape sequence (#.).
Log in to ILOM directly from a device connected to the serial management port
or network management port. See “Log In to ILOM” on page 3.
Related Information
“ILOM Overview” on page 2
“Display the ok Prompt” on page 4

System Console Output Options

On your sever, the system console comes preconfigured to allow input and output only by means of the ILOM service processor. In the default configuration, ILOM alerts and system console output are interspersed in the same window.
You can separate the service processor system console output and the ILOM output by opening an ILOM session in one window, then opening the system console session in a second window. Or, you can redirect the system console to the graphics frame buffer. For more information, see “Access the System Console Through a Local
Graphics Monitor” on page 6.
Basic Administrative Tasks 5
Access the System Console Through a Local
Graphics Monitor
After initial system installation, you can install a local graphics monitor and configure it to access the system console. You cannot use a local graphics monitor to perform initial system installation, nor can you use a local graphics monitor to view power-on self-test (POST) messages.
To install a local graphics monitor, you must have the following items:
Supported PCI-based graphics accelerator card and software driver
Monitor with appropriate resolution to support the frame buffer
Supported USB keyboard
Supported USB mouse
1. Install the graphics card into the appropriate PCI slot.
Installation must be performed by a qualified service provider. For more information, see your server’s Service Manual.
2. Attach the monitor’s video cable to the graphics card’s video port.
3. Connect the monitor’s power cord to an AC outlet.
4. Connect the USB keyboard cable to one USB port. Connect the USB mouse cable to another USB port on the server.
5. Get to the ok prompt.
See “Display the ok Prompt” on page 4.
6. Set OpenBoot input output configuration variables appropriately.
From the existing system console, type:
ok setenv input-device keyboard ok setenv output-device screen
7. To cause the changes to take effect, type:
ok reset-all
Related Information
“System Console Output Options” on page 5
6 SPARC Enterprise T5440 Server Administration Guide • July 2009

Performing Common Tasks

This section contains:
“Power On the System” on page 7
“Power Off the System” on page 7
“Reset the System” on page 8
“Update the Firmware” on page 9

Power On the System

1. Log in to ILOM.
See “Log In to ILOM” on page 3.
2. At the ILOM -> prompt, type:
-> start /SYS Are you sure you want to start /SYS (y/n) ? y Starting /SYS
->
Note – To force a power-on sequence, use the start -script /SYS command.
Related Information
“Power On the System” on page 7
“Reset the System” on page 8

Power Off the System

1. Shut down the Solaris OS.
At the Solaris prompt, type:
# shutdown -g0 -i0 -y # svc.startd: The system is coming down. Please wait. svc.startd: 91 system services are now being stopped.
Basic Administrative Tasks 7
Jun 12 19:46:57 wgs41-58 syslogd: going down on signal 15 svc.stard: The system is down. syncing file systems...done Program terminated r)eboot o)k prompt, h)alt?
2. Switch from the system console prompt to the service processor console prompt. Type:
ok #.
->
3. From the ILOM -> prompt, type:
-> stop /SYS Are you sure you want to stop /SYS (y/n)? y Stopping /SYS
->
Note – To perform an immediate shutdown, use the stop -force -script /SYS
command. Ensure that all data is saved before entering this command.
Related Information
“Power On the System” on page 7
“Reset the System” on page 8

Reset the System

It is not necessary to power the system off and on to perform a reset.
To reset the system, from the Solaris prompt, type:
# shutdown -g0 -i6 -y
Related Information
“Power On the System” on page 7
“Power Off the System” on page 7
8 SPARC Enterprise T5440 Server Administration Guide • July 2009

Update the Firmware

1. Ensure that the ILOM service processor network management port is configured.
See the server’s installation guide for instructions.
2. Open an SSH session to connect to the service processor.
% ssh root@xxx.xxx.xxx.xxx ... Are you sure you want to continue connecting (yes/no) ? yes
... Password: password (nothing displayed) Waiting for daemons to initialize...
Daemons ready
Integrated Lights Out Manager
Version 2.0.0.0
Copyright 2008 Sun Microsystems, Inc. All rights reserved. Use is subject to license terms.
->
3. Power off the host. Type:
-> stop /SYS
4. Set the keyswitch_state parameter to normal. Type:
-> set /SYS keyswitch_state=normal
5. Type the load command with the path to the new flash image.
The load command updates the service processor flash image and the host firmware. The load command requires the following information:
IP address of a TFTP server on the network that can access the flash image
Full path name to the flash image that the IP address can access
The command usage is as follows:
load [-script] -source tftp://xxx.xxx.xx.xx/pathname
where:
Basic Administrative Tasks 9
-script - Does not prompt for confirmation and acts as if yes was specified
-source - Specifies the IP address and full path name (URL) to the flash
-> load -source tftp://129.168.10.101/pathname NOTE: A firmware upgrade will cause the server and ILOM to be reset. It is recommended that a clean shutdown of the server be done prior to the upgrade procedure. An upgrade takes about 6 minutes to complete. ILOM will enter a special mode to load new firmware. No other tasks can be performed in ILOM until the firmware upgrade it complete and ILOM is reset. Are you sure you want to load the specified file (y/n)?y Do you want to preserve the configuration (y/n)? y
.................................................................
Firmware update is complete. ILOM will now be restarted with the new firmware. Update Complete. Reset device to use new image.
->
After the flash image has been updated, the system automatically resets, runs diagnostics, and returns to the login prompt on the serial console.
U-Boot 1.1.1 (May 23 2007 - 21:30:12) *** POST cpu PASSED POST ethernet PASSED Hit any key to stop autoboot: 0 ## Booting image at fe080000 ***
IP Protocols: ICMP, UDP, TCP, IGMP
Checking all file systems... fsck 1.37 (21-Mar-2005) Setting kernel variable ... ... done. Mounting local filesystems... Cleaning /tmp /var/run /var/lock.
Identifying DOC Device Type(G3/G4/H3) ... OK
Configuring network interfaces....Internet Systems Consortium DHCP
Client V3.0.1 Copyright 2007 Internet Systems Consortium All rights reserved. For info, please visit http://www.isc.org/products/DHCP
10 SPARC Enterprise T5440 Server Administration Guide • July 2009
eth0: config: auto-negotiation on, 100FDX, 100HDX, 10FDX, 10HDX. Listening on LPF/eth0/00:14:4f:3f:8c:af Sending on LPF/eth0/00:14:4f:3f:8c:af Sending on Socket/fallback DHCPDISCOVER on eth0 to 255.255.255.255 port 67 interval 6 eth0: link up, 100Mbps Full Duplex, auto-negotiation complete. DHCPDISCOVER on eth0 to 255.255.255.255 port 67 interval 15 Hostname: hostname Starting portmap daemon: portmap. Initializing random number generator...done. INIT: Entering runlevel: 3 Starting system log daemon: syslogd and klogd. Starting periodic command scheduler: cron.
Starting IPMI Stack........ Done.
Starting OpenBSD Secure Shell server: sshd. Starting Servicetags listener: stlistener. Starting FRU update program: frutool.
hostname login:
Related Information
“Display the ILOM ->Prompt” on page 5
“Display the ok Prompt” on page 4
Basic Administrative Tasks 11
12 SPARC Enterprise T5440 Server Administration Guide • July 2009

Manage Disk Volumes

This section contains information about creating and removing RAID volumes.
Description Links
Learn about Hardware RAID support on this system.
Create RAID volumes then configure RAID volumes for use with Solaris.
Delete or hot-plug a RAID volume. “Delete a Hardware RAID Volume” on page 21
“Hardware RAID Support” on page 13
“Create a Hardware Mirrored Volume” on page 14 “Create a Hardware Mirrored Volume of the Default
Boot Device” on page 15 “Create a Hardware Striped Volume” on page 17 “Configure and Label a Hardware RAID Volume for
Use in the Solaris Operating System” on page 18 “Disk Slot Numbers” on page 20
“Hot-Plug a Mirrored Disk” on page 23 “Hot-Plug a Nonmirrored Disk” on page 24

Hardware RAID Support

On the SPARC Enterprise T5440 server, the SAS controller supports mirroring and striping using the Solaris OS raidctl utility.
The onboard disk controller of the server provides supports up to two hardware RAID volumes. The controller supports either two-disk RAID 1 (integrated mirror, or IM) volumes, or up to two-disk RAID 0 (integrated strip, or IS) volumes.
RAID volumes created using the hardware controller must be configured and labeled using format(1M)prior to use with the Solaris OS. See “Configure and Label a
Hardware RAID Volume for Use in the Solaris Operating System” on page 18.
13

Related Information

“Creating RAID Volumes” on page 14
“Removing Hardware RAID Volumes” on page 21

Creating RAID Volumes

This section contains:
“Create a Hardware Mirrored Volume” on page 14
“Create a Hardware Mirrored Volume of the Default Boot Device” on page 15
“Create a Hardware Striped Volume” on page 17
“Configure and Label a Hardware RAID Volume for Use in the Solaris Operating
System” on page 18
“Disk Slot Numbers” on page 20

Create a Hardware Mirrored Volume

1. Verify which hard drive corresponds with which logical device name and
physical device name, using the raidctl command.
# raidctl No RAID volumes found.
See “Disk Slot Numbers” on page 20to locate the correct disk number.
2. Type the following command:
# raidctl -c primary secondary
A message appears asking you to confirm the operation. For example:
# raidctl -c c0t0d0 c0t1d0 Creating RAID volume c0t0d0 will destroy all data on member disks, proceed (yes/no)?
14 SPARC Enterprise T5440 Server Administration Guide • July 2009
3. Type yes to confirm creating the RAID volume.
# raidctl -c c0t0d0 c0t1d0 Creating RAID volume c0t0d0 will destroy all data on member disks, proceed (yes/no)? yes Volume ‘c0t0d0” created
When you create a RAID mirror, the secondary drive (in this case, c0t1d0) disappears from the Solaris device tree.
4. To verify creation of the RAID volume, type:
# raidctl RAID Volume RAID RAID Disk Volume Type Status Disk Status
------------------------------------------------------­c0t0d0 IM OK c0t0d0 OK
c0t1d0 OK
If a mirrored disk fails, see “Removing Hardware RAID Volumes” on page 21.
Related Information
“Disk Slot Numbers” on page 20
“Configure and Label a Hardware RAID Volume for Use in the Solaris Operating
System” on page 18
“Hardware RAID Support” on page 13
Create a Hardware Mirrored Volume of the
Default Boot Device
Due to the volume initialization that occurs on the disk controller when a new volume is created, the volume must be configured and labeled using the format(1M)utility prior to use with the Solaris OS. See “Configure and Label a
Hardware RAID Volume for Use in the Solaris Operating System” on page 18.
Because of this limitation, raidctl(1M) blocks the creation of a hardware RAID volume if any of the member disks currently have a file system mounted.
This section describes the procedure required to create a hardware RAID volume containing the default boot device. Since the boot device always has a mounted file system when booted, an alternate boot medium must be employed, and the volume
Manage Disk Volumes 15
created in that environment. One alternate medium is a network installation image in single-user mode (refer to the Solaris 10 Installation Guide for more information about configuring and using network-based installations).
1. Determine which disk is the default boot device.
From the OpenBoot ok prompt, type the printenv command, and if necessary, the devalias command, to identify the default boot device. For example:
ok printenv boot-device boot-device = disk
ok devalias disk disk /pci@0/pci@0/pci@2/scsi@0/disk@0,0
2. Type the boot net -s command.
ok boot net -s
3. Once the system boots, use the raidctl(1M) utility to create a hardware
mirrored volume, using the default boot device as the primary disk.
See “Create a Hardware Mirrored Volume” on page 14.
# raidctl -c -r 1 c0t0d0 c0t1d0 Creating RAID volume c0t0d0 will destroy all data on member disks, proceed (yes/no) ? yes Volume c0t0d0 created #
4. Install the volume with the Solaris OS using any supported method.
The hardware RAID volume c0t0d0 appears as a disk to the Solaris installation program.
Note – The logical device names might appear differently on your system,
depending on the number and type of add-on disk controllers installed.
5. To configure the volume for use with Solaris, see “Configure and Label a
Hardware RAID Volume for Use in the Solaris Operating System” on page 18.
Related Information
“Disk Slot Numbers” on page 20
“Hardware RAID Support” on page 13
16 SPARC Enterprise T5440 Server Administration Guide • July 2009

Create a Hardware Striped Volume

1. Identify the hard drives to be used in the RAID volume.
To verify which hard drive corresponds with which logical device name and physical device name, see “Disk Slot Numbers” on page 20.
Note – The logical device names might appear differently on your system,
depending on the number and type of add-on disk controllers installed.
2. To create the striped RAID volume, type:
# raidctl -c -r disk1disk2
The creation of the RAID volume is interactive by default. For example:
# raidctl -c -r 0 c0t1d0 c0t2d0 c0t3d0 Creating RAID volume c0t1d0 will destroy all data on member disks, proceed (yes/no) ? yes Volume ‘c0t1d0’ created #
3. To check the status of a RAID striped volume, type:
# raidctl RAID Volume RAID RAID RAID Volume Type Status Disk Status
----------------------------------------------------------------­c0t1d0 IS OK c0t1d0 OK
c0t2d0 OK c0t3d0 OK
The example shows that the RAID striped volume is online and functioning.
Caution – Under RAID 0 (disk striping) there is no replication of data across drives.
The data is written to the RAID volume across all member disks in a round-robin fashion. If any one disk is lost, all data on the volume is lost. For this reason, RAID 0 cannot be used to ensure data integrity or availability, but can be used to increase write performance in some scenarios.
For more information, see the raidctl(1M)manpage.
Manage Disk Volumes 17
Related Information
“Hardware RAID Support” on page 13
“Configure and Label a Hardware RAID Volume for Use in the Solaris Operating
System” on page 18
Configure and Label a Hardware RAID Volume
for Use in the Solaris Operating System
After creating a RAID volume using raidctl, use format(1)to configure and label the volume before attempting to use it in a Solaris operating system.
1. Start the format utility:
# format
The format utility might generate messages about corruption of the current label on the volume, which you are going to change. You can safely ignore those messages.
2. Specify the disk that represents the RAID volume that you configured.
In this example, c0t2d0 is the logical name of the volume, and its corresponding number is 2.
# format Searching for disks...done AVAILABLE DISK SELECTIONS:
0. c0t0d0 <SUN72G cyl 14084 alt 2 hd sec 424> /pci@0/pci@0/pci@2/scsi@0/sd@0, 0
1. c0t1d0 <SUN72G cyl 14084 alt 2 hd sec 424> /pci@0/pci@0/pci@2/scsi@0/sd@1, 0
2. c0t2d0 <SUN72G cyl 14084 alt 2 hd sec 424> /pci@0/pci@0/pci@2/scsi@0/sd@2, 0
Specify disk (enter its number): 2 selecting c0t2d0 [disk formatted] FORMAT MENU:
disk - select a disk type - select (define) a disk type partition - select (define) a partition table current - describe the current disk format - format and analyze the disk
fdisk - run the fdisk program
repair - repair a defective sector label - write label to the disk
18 SPARC Enterprise T5440 Server Administration Guide • July 2009
analyze - surface analysis defect - defect list management
backup - search for backup labels
verify - read and display labels save - save new disk/partition definitions inquiry - show vendor, product and revision volname - set 8-character volume name volname - execute <cmd>, then return quit
3. Type the type command at the format> prompt, then select 0 (zero) to
autoconfigure the volume.
format> type
AVAILABLE DRIVE TYPES:
0. Auto configure
1. DEFAULT
2. SUN72G
3. SUN72G
4. other Specify disk type (enter its number) [3]: 0 c0t2d0: configured with capacity of 68.23GB <LSILOGIC-LogicalVolume-3000 cyl 69866 alt 2 hd 16 sec 128> selecting c0t2d0 [disk formatted]
4. Use the partition command to partition, or slice, the volume according to
your desired configuration.
See the format(1M)man page for additional information.
5. Write the new label to the disk using the label command.
format> label Ready to label disk, continue? yes
Manage Disk Volumes 19
6. Verify that the new label has been written by printing the disk list using the
disk command.
format> disk AVAILABLE DISK SELECTIONS:
0. c0t0d0 <SUN72G cyl 14084 alt 2 hd sec 424> /pci@0/pci@0/pci@2/scsi@0/sd@0, 0
1. c0t1d0 <SUN72G cyl 14084 alt 2 hd sec 424> /pci@0/pci@0/pci@2/scsi@0/sd@1, 0
2. c0t2d0 <LSILOGIC-LogicalVolume-3000 cyl 69866 alt 2 hd
16 sec 128>
/pci@0/pci@0/pci@2/scsi@0/sd@2, 0
Specify disk (enter its number) [2]:
Note that c0t2d0 now has a type indicating it is an LSILOGIC-LogicalVolume.
7. Exit the format utility.
The volume can now be used in the Solaris OS.
Related Information
“Disk Slot Numbers” on page 20
“Hardware RAID Support” on page 13

Disk Slot Numbers

To perform a disk hot-plug procedure, you must know the physical or logical device name for the drive that you want to install or remove. If your system encounters disk errors, you can find messages about failing disks in the system console or in the /var/adm/messages files.
These error messages typically refer to a failed hard drive by its physical device name (for example, /devices/pci@1f,700000/scsi@2/sd@1/0) or by its logical device name (for example, c0t1d0). In addition, some applications may report a disk number (Disk0 through Disk3).
20 SPARC Enterprise T5440 Server Administration Guide • July 2009
Use TABLE: Disk Slot Numbers, Logical Device Names, and Physical Device Names
on page 21 to map internal disk slot numbers with the logical and physical device
names for each hard drive.
TABLE: Disk Slot Numbers, Logical Device Names, and Physical Device Names
Disk Slot Numbers Logical Device Names Physical Device Names
Slot 0 c0t0d0s0 /devices/pci@0/pci@1/scsi@0/sd@0,0
Slot 1 c0t1d0s0 /devices/pci@0/pci@1/scsi@0/sd@1,0
Slot 2 c0t2d0s0 /devices/pci@0/pci@1/scsi@0/sd@2,0
Slot3 c0t3d0s0 /devices/pci@0/pci@1/scsi@0/sd@3,0
Related Information
“Hardware RAID Support” on page 13
“Creating RAID Volumes” on page 14
“Removing Hardware RAID Volumes” on page 21

Removing Hardware RAID Volumes

This section contains:
“Delete a Hardware RAID Volume” on page 21
“Hot-Plug a Mirrored Disk” on page 23
“Hot-Plug a Nonmirrored Disk” on page 24

Delete a Hardware RAID Volume

1. Verify which hard drive corresponds with which logical device name and physical device name.
See “Disk Slot Numbers” on page 20.
Manage Disk Volumes 21
2. To determine the name of the RAID volume, type:
# raidctl RAID Volume RAID RAID Disk Volume Type Status Disk Status
------------------------------------------------------------­c0t0d0 IM OK c0t0d0 OK
c0t0d0 OK
In this example, the RAID volume is c0t0d0.
3. To delete the volume, type:
# raidctl -d mirrored-volume
For example:
# raidctl -d c0t0d0 RAID Volume ‘c0t0d0’ deleted
If the RAID volume is an IS volume, the deletion of the RAID volume is interactive, for example:
# raidctl -d c0t0d0 Deleting volume C0t0d0 will destroy all data it contains, proceed (yes/no)? yes Volume ‘c0t0d0’ deleted. #
The deletion of an IS volume results in the loss of all data that it contains. As an alternative, you can use the-f option to force the deletion if you are sure you no longer need the IS volume, or the data that it contains. For example:
# raidctl -f -d c0t0d0 Volume ‘c0t0d0’ deleted. #
4. To confirm that you have deleted the RAID array, type:
# raidctl No RAID volumes found.
22 SPARC Enterprise T5440 Server Administration Guide • July 2009
Related Information
“Creating RAID Volumes” on page 14

Hot-Plug a Mirrored Disk

1. Verify which hard drive corresponds with which logical device name and physical device name.
See “Disk Slot Numbers” on page 20.
2. To confirm a failed disk, type:
# raidctl
If the Disk Status is FAILED, then the drive can be removed and a new drive inserted. Upon insertion, the new disk should be OK and the volume should be RESYNCING.
For example:
# raidctl RAID Volume RAID RAID RAID Volume Type Status Disk Status
----------------------------------------------------------------­c0t1d0 IM DEGRADED c0t1d0 OK
c0t2d0 FAILED
This example indicated that the disk mirror has degraded due to a failure in disk c0t2d0.
3. Remove the hard drive as described in your server’s service manual.
There is no need to issue a software command to bring the drive offline when the drive has failed.
4. Install a new hard drive as described in your server’s service manual.
The RAID utility automatically restores the data to the disk.
Manage Disk Volumes 23
5. To check the status of the RAID rebuild, type:
# raidctl
For example:
# raidctl RAID Volume RAID RAID RAID Volume Type Status Disk Status
----------------------------------------------------------------­c0t1d0 IM RESYNCING c0t1d0 OK
c0t2d0 OK
This example indicated that RAID volume c0t1d0 is resynchronizing. If you issue the command again once synchronization is complete and the disk is back online, the RAID status changes from RESYNCING to OK.
Related Information
“Hot-Plug a Nonmirrored Disk” on page 24
“Delete a Hardware RAID Volume” on page 21

Hot-Plug a Nonmirrored Disk

1. Verify which hard drive corresponds with which logical device name and physical device name.
See “Disk Slot Numbers” on page 20.
Caution – To avoid data corruption or loss, ensure that no applications or processes
are accessing the hard drive.
24 SPARC Enterprise T5440 Server Administration Guide • July 2009
2. Type:
# cfgadm -al
For example:
# cfgadm -al Ap_Id Type Receptacle Occupant Condition c0 scsi-bus connected configured unknown c0::dsk/c0t0d0 disk connected configured unknown c0::dsk/c0t1d0 disk connected configured unknown c0::dsk/c0t2d0 disk connected configured unknown c0::dsk/c0t3d0 disk connected configured unknown c1 scsi-bus connected configured unknown c1::dsk/c1t0d0 CD-ROM connected configured unknown usb0/1 unknown empty unconfigured ok usb0/2 unknown empty unconfigured ok #
The -al options return the status of all SCSI devices, including buses and USB devices.
3. Remove the hard drive from the device tree. Type:
# cfgadm -c unconfigure Ap-Id
For example:
# cfgadm -c unconfigure c0::dsk/c0t3d0
This example removes c0t3d0 from the device tree. The blue OK-to-Remove LED lights.
4. Verify that the device has been removed form the device tree. Type:
# cfgadm -al Ap_Id Type Receptacle Occupant Condition c0 scsi-bus connected configured unknown c0::dsk/c0t0d0 disk connected configured unknown c0::dsk/c0t1d0 disk connected configured unknown c0::dsk/c0t2d0 disk connected configured unknown c0::dsk/c0t3d0 disk unavailable configured unknown c1 scsi-bus connected configured unknown c1::dsk/c1t0d0 CD-ROM connected configured unknown
Manage Disk Volumes 25
usb0/1 unknown empty unconfigured ok usb0/2 unknown empty unconfigured ok #
5. Remove the hard drive as described in your server’s service manual.
6. Install a new hard drive as described in your server’s service manual.
7. Configure the new hard drive. Type:
# cfgadm -c configure Ap-Id
For example:
# cfgadm -c configure c1::dsk/c0t3d0
The green Activity LED flashes as the new disk at c0t3d0 is added to the device tree.
8. Verify that the new hard drive is in the device tree. Type:
# cfgadm -al Ap_Id Type Receptacle Occupant Condition c0 scsi-bus connected configured unknown c0::dsk/c0t0d0 disk connected configured unknown c0::dsk/c0t1d0 disk connected configured unknown c0::dsk/c0t2d0 disk connected configured unknown c0::dsk/c0t3d0 disk connected configured unknown c1 scsi-bus connected configured unknown c1::dsk/c1t0d0 CD-ROM connected configured unknown usb0/1 unknown empty unconfigured ok usb0/2 unknown empty unconfigured ok #
Note that c0t3d0 is now listed as configured.
Related Information
“Hot-Plug a Mirrored Disk” on page 23
“Delete a Hardware RAID Volume” on page 21
26 SPARC Enterprise T5440 Server Administration Guide • July 2009

Manage the System

This section contains information about basic fault management and managing devices.
Description Lilnks
Use ILOM to view system faults and set diagnostic levels.
Configure your system to resume operation when encountering nonfatal faults.
Clear component fault messages manually.
Manage devices manually. “Unconfigure a Device Manually” on page 34
“Log In to ILOM” on page 3 “Display System Faults” on page 28 “Run Full POST Diagnostics on Reset” on page 29 “Locate the System” on page 30
“Automatic System Recovery” on page 31 “Enable Automatic System Recovery” on page 31 “Disable Automatic System Recovery” on page 32 “View Components Affected by ASR” on page 33
“Clear Component Fault Messages” on page 34
“Configure a Device Manually” on page 35 “Devices and Device Identifiers” on page 35

Searching for Faults

This section contains:
“Log In to ILOM” on page 3
“Display System Faults” on page 28
“Run Full POST Diagnostics on Reset” on page 29
“Locate the System” on page 30
27

Log In to ILOM

This procedure assumes the default configuration of the service processor as described in your server’s installation guide.
Open an SSH session and connect to the service processor by specifying its IP
address.
The ILOM default username is root and the default password is changeme.
% ssh root@xxx.xxx.xxx.xxx ... Are you sure you want to continue connecting (yes/no) ? yes
... Password: password (nothing displayed) Waiting for daemons to initialize...
Daemons ready
Integrated Lights Out Manager
Version 2.0.0.0
Copyright 2007 Sun Microsystems, Inc. All rights reserved. Use is subject to license terms.
->
You are now logged into ILOM. Perform tasks as needed. For more information about ILOM, refer to the ILOM’s user’s guide and the
ILOM supplement for your server.
Note – In order to provide optimum system security, change the default system
password.

Display System Faults

1. Log in to ILOM.
See “Log In to ILOM” on page 28.
28 SPARC Enterprise T5440 Server Administration Guide • July 2009
2. At the ILOM -> prompt, type:
-> show /SP/faultmgmt
This command displays the fault ID, the faulted FRU device, and the fault message to standard output. The show /SP/faultmgmt command also displays POST results.
For example:
-> show /SP/faultmgmt
/SP/faultmgmt
Targets:
0 (/SYS/PS1)
Properties:
Commands:
cd show
->
Related Information
“Clearing Faults” on page 33
“Bypassing Minor Faults” on page 31
“Managing Devices” on page 34
“Locate the System” on page 30

Run Full POST Diagnostics on Reset

Running full POST diagnostics can take a significant amount of time at system reset. Use this diagnotic setting for troubleshooting purposes, then return to your normal diagnostic setting for regular operation.
1. Log in to ILOM.
See “Log In to ILOM” on page 28.
Manage the System 29
2. At the ILOM -> prompt, type:
-> set /SYS keyswitch_state=diag
The system is set to run full POST diagnostics on system reset.
3. To return to your normal diagnostic settings after running POST, type:
-> set /SYS keyswitch_state=normal
Related Information
“Clearing Faults” on page 33
“Bypassing Minor Faults” on page 31
“Managing Devices” on page 34
“Locate the System” on page 30

Locate the System

1. Log in to ILOM.
See “Log In to ILOM” on page 28.
2. To easily find your system in a data center or server room, use the Locator LED as described below.
To turn on the Locator LED, from the ILOM -> prompt, type:
-> set /SYS/LOCATE value=Fast_Blink
To turn off the Locator LED, from the ILOM -> prompt, type:
-> set /SYS/LOCATE value=off
To display the state of the locator LED, from the ILOM -> prompt, type:
-> show /SYS/LOCATE
For more information on LEDs, see your server’s service manual.
Related Information
“Configure a Device Manually” on page 35
“Clear Component Fault Messages” on page 34
30 SPARC Enterprise T5440 Server Administration Guide • July 2009

Bypassing Minor Faults

This section contains:
“Automatic System Recovery” on page 31
“Enable Automatic System Recovery” on page 31
“Disable Automatic System Recovery” on page 32
“View Components Affected by ASR” on page 33

Automatic System Recovery

Automatic system recovery (ASR) functionality enables the system to resume operation after experiencing certain non-fatal hardware faults or failures. Once you enable ASR, the system’s diagnostic firmware automatically detects failed hardware components. The autoconfiguring capability designed into the system firmware enables the system to unconfigure failed components and restore system operation. As long as the system is capable of operating without the failed component, the ASR features enable the system to reboot automatically, without operator intervention.
The system provides ASR for failures in CPU cores or threads, memory modules, and PCIE slots.
Related Information
“Enable Automatic System Recovery” on page 31
“Disable Automatic System Recovery” on page 32

Enable Automatic System Recovery

To enable Automatic System Recovery, you must change system parameters in two places: at the ILOM -> prompt, and at the ok prompt.
1. Log in to ILOM.
See “Log In to ILOM” on page 28.
Manage the System 31
2. At the ILOM -> prompt, type:
-> set /HOST/diag mode=normal
-> set /HOST/diag level=max
-> set /HOST/diag trigger=power-on-reset error-reset
3. At the ok prompt, type:
ok setenv auto-boot? true ok setenv auto-boot-on-error? true
4. To cause the parameter changes to take effect, type:
ok reset-all
The systems permanently stores the parameter changes and boots automatically when the OpenBoot configuration variable auto-boot? is set to true (its default value).
Related Information
“Display the ok Prompt” on page 4
“Disable Automatic System Recovery” on page 32
“Automatic System Recovery” on page 31

Disable Automatic System Recovery

1. Log in to ILOM.
See “Log In to ILOM” on page 28
2. Display the ok prompt.
See “Display the ok Prompt” on page 4.
3. At the ok prompt, type:
ok setenv auto-boot-on-error? false
32 SPARC Enterprise T5440 Server Administration Guide • July 2009
4. To cause the parameter change to take effect, type:
ok reset-all
The system permanently stores the parameter change. After you disable the ASR feature, it is not activated again until you re-enable it.
Related Information
“Enable Automatic System Recovery” on page 31
“Automatic System Recovery” on page 31

View Components Affected by ASR

1. Log in to ILOM.
See “Log In to ILOM” on page 28.
2. At the ILOM -> prompt, type:
-> show /SYS/component component_state
In the show /SYS/component component_state command output, any devices marked disabled have been manually unconfigured using the system firmware. The command output also shows devices that have failed firmware diagnostics and have been automatically unconfigured by the system firmware.
Related Information
“Disable Automatic System Recovery” on page 32
Unconfigure a Device Manually
“Configure a Device Manually” on page 35

Clearing Faults

This section describes clearing fault messages using ILOM. For detailed troubleshooting information, see the system’s service manual.
Manage the System 33

Clear Component Fault Messages

1. Log in to ILOM.
See “Log In to ILOM” on page 28.
2. At the ILOM -> prompt, type:
-> set /SYS/component clear_fault_action=true
Related Information
“View Components Affected by ASR” on page 33
“Display System Faults” on page 28
“Devices and Device Identifiers” on page 35

Managing Devices

This section contains:
“Unconfigure a Device Manually” on page 34
“Configure a Device Manually” on page 35
“Devices and Device Identifiers” on page 35

Unconfigure a Device Manually

1. Log in to ILOM.
See “Log In to ILOM” on page 28.
2. At the ILOM -> prompt, type:
-> set Device_Identifier component_state=disabled
Related Information
“Devices and Device Identifiers” on page 35
“Clear Component Fault Messages” on page 34
“Configure a Device Manually” on page 35
34 SPARC Enterprise T5440 Server Administration Guide • July 2009

Configure a Device Manually

1. Log in to ILOM.
See “Log In to ILOM” on page 28.
2. At the ILOM -> prompt, type:
-> set Device_Identifier component_state=enabled
Related Information
“Devices and Device Identifiers” on page 35
“Unconfigure a Device Manually” on page 34

Devices and Device Identifiers

The device identifiers are case sensitive.
TABLE:
Device Devices Identifiers
System fan (0-3) /SYS/MB/FTn
Hard disk drive (0-3) /SYS/HDDn
DVD-ROM /SYS/DVD
Power supply (0-3) /SYS/PSn
Ethernet port (0-3) /SYS/MB/NETn
Network management port /SYS/MB/NETMGT
Serial management port /SYS/MB/SERMGT
USB port (0-3) /SYS/MB/USBn
PCI-E slot (0-7) /SYS/MB/PCIEn
XUAI 10GbE slot (0-1) /SYS/MB/XUAIn
DB-9 serial port /SYS/TTYA
Related Information
“Unconfigure a Device Manually” on page 34
“Configure a Device Manually” on page 35
Manage the System 35
36 SPARC Enterprise T5440 Server Administration Guide • July 2009

Use Logical Domains Software

SPARC Enterprise servers support the Logical Domains (LDoms) 1.0.3 software that is used to create and manage logical domains. The software comprises LDoms-enabling code in the Solaris 10 11/06 OS, LDoms-enabling code in System Firmware 6.4, and the Logical Domains Manager, which is the command-line interface.
Description Links
Learn about Logical Domains software, configurations and requirements.
Operate the Solaris OS with Logical Domains.
“Logical Domain Software Overview” on page 38 “Logical Domain Configurations” on page 39 “Logical Domains Software Requirements” on
page 39
“OpenBoot Firmware Not Available After Solaris OS Has Started if Domaining Is Enabled” on page 40
“Power-Cycle a Server” on page 40 “Save Your Current Logical Domain Configurations
to the SC” on page 41 “Result of an OpenBoot power-off Command” on
page 41 “Result of Solaris OS Breaks” on page 41 “Results From Halting or Rebooting the Control
Domain” on page 41 “Additional Documentation” on page 43

Understanding Logical Domains Software

This sections includes:
“Logical Domain Software Overview” on page 38
37
“Logical Domain Configurations” on page 39
“Logical Domains Software Requirements” on page 39

Logical Domain Software Overview

Logical Domains (LDoms) software enables you to allocate the system resources of your server (such as a boot environment, CPUs, memory, and I/O devices) into logical domains. By using a logical domains environment, you can increase resource usage, improve scaling, and gain greater control of security and isolation
LDoms software enables you to create and manage as many as 128 logical domains, depending on the hardware configuration of the server on which the Logical Domains Manager has been installed. You can virtualize resources and define network, storage, and other I/O devices as services that can be shared between domains.
A logical domain is a discrete logical grouping with its own operating system, resources, and identity within a single computer system. Applications software can run in logical domains. Each logical domain can be created, destroyed, reconfigured, and rebooted independently. There are several roles that logical domains can perform as shown in the following table.
TABLE: Logical Domain Roles
Domain Role Description
Control domain Domain in which the Logical Domains Manager runs, enabling you to
create and manage other logical domains and allocate virtual resources to other domains. There can be only one control domain per server. The initial domain created when installing LDoms software is a control domain and is named primary.
Service domain Domain that provides virtual device services to other domains, such as a
virtual switch, a virtual console concentrator, and a virtual disk server.
I/O domain Domain that has direct ownership of and direct access to physical I/O
devices, such as a network card in a PCI Express controller. Shares the devices with other domains in the form of virtual devices. You can have a maximum of two I/O domains, one of which also must be the control domain.
Guest domain Domain that is managed by the control domain and uses services from the
I/O and service domains.
38 SPARC Enterprise T5440 Server Administration Guide • July 2009

Logical Domain Configurations

The Logical Domain configurations are stored on the service processor (SP). Using Logical Domains Manager CLI commands, you can add a configuration, specify a configuration to be used, and list the configurations on the service processor. You can also use the ILOM set /HOST/bootmode config=configfile command to specify an LDoms boot configuration. For further information about /HOST/bootmode, see your server’s ILOM supplement.

Logical Domains Software Requirements

The following software is required or recommended for LDoms on the SPARC Enterprise T5440 server:
(Required) Solaris 10 11/06 OS – Refer to the Solaris 10 Collection for more
information.
(Required) Solaris 10 11/06 OS patches:
124921-02, which contains updates to the Logical Domains 1.0 drivers and
utilities. Logical Domains networking will be broken without this patch.
125043-01, which contains updates to the console (qcn) drivers. This patch
depends on KU 118833-36, so if this is not already updated on your system, you will need to do so.
For further information about patches, see the product notes for your server.
(Required) System firmware version 6.4.x – Refer to your server’s documentation
for more information.
(Required) Logical Domains Manager 1.0.x software.
(Recommended) Solaris Security Toolkit 4.2 software – Refer to the Solaris Security
Toolkit 4.2 Administration Guide and Solaris Security Toolkit 4.2 Reference Manual for more information
Note – During the boot process, domains that use virtual boot devices must wait for
their service domains to come online first. This can prolong the boot process.
Use Logical Domains Software 39

Operating the Solaris OS With Logical Domains

This section describes the changes in behavior in using the Solaris OS that occur once a configuration created by the Logical Domains Manager is instantiated; that is, after domaining is enabled.
Note – Any discussion about whether domaining is enabled pertains only to
UltraSPARC T1–based platforms. Otherwise, domaining is always enabled.
“OpenBoot Firmware Not Available After Solaris OS Has Started if Domaining Is
Enabled” on page 40
“Power-Cycle a Server” on page 40
“Result of an OpenBoot power-off Command” on page 41
“Result of Solaris OS Breaks” on page 41
“Results From Halting or Rebooting the Control Domain” on page 41
“Additional Documentation” on page 43

OpenBoot Firmware Not Available After Solaris OS Has Started if Domaining Is Enabled

If domaining is enabled, the OpenBoot firmware is not available after the Solaris OS has started, because it is removed from memory.
To reach the ok prompt from the Solaris OS, you must halt the domain. You can use the Solaris OS halt command to halt the domain.

Power-Cycle a Server

Whenever performing any maintenance on a system running LDoms software that requires power-cycling the server, you must save your current logical domain configurations to the SC first.
40 SPARC Enterprise T5440 Server Administration Guide • July 2009
Save Your Current Logical Domain Configurations to
the SC
Use the following command.
# ldm add-config config-name

Result of an OpenBoot power-off Command

The OpenBoot power-off command does not power down a system. To power down a system while in OpenBoot firmware, use your system controller’s or system processor’s poweroff command. The OpenBoot power-off command displays the following message:
NOTICE: power-off command is not supported, use appropriate NOTICE: command on System Controller to turn power off.

Result of Solaris OS Breaks

If domaining is not enabled, the Solaris OS normally goes to the OpenBoot prompt after a break is issued. The behavior described in this section occurs in two situations:
1. You press the L1-A key sequence when the input device is set to keyboard.
2. You enter the send break command when the virtual console is at the telnet prompt.
If domaining is enabled, you receive the following prompt after these types of breaks.
c)ontinue, s)ync, r)eboot, h)alt?
Type the letter that represents what you want the system to do after these types of breaks.

Results From Halting or Rebooting the Control Domain

The following table shows the expected behavior of halting or rebooting the control (primary) domain.
Use Logical Domains Software 41
Note – The question in TABLE: Expected Behavior of Halting or Rebooting the
Control (primary) Domain on page 42 regarding whether domaining is enabled
pertains only to the UltraSPARC T1 processors. Otherwise, domaining is always enabled.
TABLE: Expected Behavior of Halting or Rebooting the Control (primary) Domain
Command
Domaining Enabled?
Other Domain Configured? Behavior
halt Disabled N/A For UltraSPARC T1 Processors:
Drops to the ok prompt.
Enabled No For UltraSPARC T1 Processors:
See message in 02.
For UltraSPARC T2 Processors:
Host powered off and stays off until powered on at the SC.
Enabled Yes Soft resets and boots up if the variable
auto-boot?=true. Soft resets and halts at ok prompt if the variable auto-boot?=
false.
reboot Disabled N/A For UltraSPARC T1 Processors:
Powers off and powers on the host.
Enabled No For UltraSPARC T1 Processors:
Powers off and powers on the host.
For UltraSPARC T2 Processors:
Reboots the host, no power off.
Enabled Yes For UltraSPARC T1 Processors:
Powers off and powers on the host.
For UltraSPARC T2 Processors:
Reboots the host, no power off.
shutdown -i 5 Disabled N/A For UltraSPARC T1 Processors:
Powers off the host.
Enabled No Host powered off, stays off until powered on
at the SC.
Enabled Yes Soft resets and reboots.
42 SPARC Enterprise T5440 Server Administration Guide • July 2009

Additional Documentation

For more information on LDoms software, see the following documents:
1. The Logical Domains (LDoms) 1.0 Documentation
(http://www.sun.com/products-n-solutions/hardware/docs/Softwar e/enterprise_computing/systems_management/ldoms/ldoms1_0/index .html)
2. The Beginners Guide to LDoms: Understanding and Deploying Logical Domains
(http://www.sun.com/blueprints/0207/820-0832.html)
Use Logical Domains Software 43
44 SPARC Enterprise T5440 Server Administration Guide • July 2009

ALOM-to-ILOM Command Reference

ILOM and ALOM CMT Command Comparison

The following table provides a command-by-command comparison between the command sets of ALOM CMT and the default ILOM CLI command set. Only the supported ALOM CMT command options are listed in the tables. Where there are ALOM CMT command-line arguments that have no corresponding ILOM properties, those ALOM CMT arguments have been omitted. The command set of the ALOM compatibility shell provides a close approximation of the equivalent commands and arguments (where supported) in ALOM CMT.
45
Note – By default, when displaying information ALOM CMT commands limit their
output to a terse format, offering more verbose output if a –v flag is supplied with the command. ILOM’s show commands do not have a terse output format. They always provide verbose output.
TABLE: ALOM CMT Shell Configuration Commands
ALOM CMT Command Summary Comparable ILOM Command
password Changes the login password of the
current user.
restartssh Restarts the SSH server so that new
host keys generated by the
ssh-keygen command are reloaded.
setdate [[mmdd]HHMM
|mmddHHMM[cc]yy][.SS]
setdefaults
setdefaults –a
setkeyswitch [normal|stby|diag| locked]
setsc [param][value] Sets the specified ALOM CMT
Sets ALOM CMT date and time. set /SP/clock datetime=value
Resets all ALOM CMT configuration parameters totheir default values. The –a option resets the user information to the factory default (one admin account only).
Sets the status of the virtual keyswitch. Setting the virtual keyswitch to standby (stby) powers off the server. Before powering off the host server, ALOM CMT asks for a confirmation.
parameter to the assigned value.
set /SP/users/username password
set /SP/services/ssh restart_sshd_action=true
set /SP reset_to_defaults=
configuration
set /SP reset_to_defaults= all
set /SYS keyswitch_state=
value
set target property=value
setupsc Runs the interactive configuration
script. This script configures the ALOM CMT configuration variables.
showplatform [–v] Displays information about the host
system’s hardware configuration, and whether the hardware is providing service. The –v option displays verbose information about the displayed components.
showfru Displays information about the
field-replaceable units (FRUs) in a host server.
46 SPARC Enterprise T5440 Server Administration Guide • July 2009
No equivalent in ILOM
show /HOST
No equivalent in ILOM
TABLE: ALOM CMT Shell Configuration Commands (Continued)
ALOM CMT Command Summary Comparable ILOM Command
showusers
Displays a list of users currently
show /SP/sessions
logged in to ALOM CMT. The display for this command has a similar format to that of the UNIX command who. The –g option pauses the display after the number of lines you specify for
showusers –g lines
lines.
No equivalent in ILOM
showhost
Displays version information for
show /HOST
host-side components.
showhost version
The version option displays the same information as the showhost command with no option.
showkeyswitch Displays status of virtual keyswitch. show /SYS keyswitch_state
showsc [param] Displays the current non-volatile
show target property
random access memory (NVRAM) configuration parameters.
showdate Displays the ALOM CMT date. ALOM
show /SP/clock datetime
CMT time is expressed in Coordinated Universal Time (UTC) rather than local time. The Solaris OS and ALOM CMT time are not synchronized.
ssh-keygen –l
ssh-keygen –r
Generates Secure Shell (SSH) host keys and displays the host key fingerprint on the SC.
show /SP/services/ssh/keys rsa|dsa
set /SP/services/ssh
ssh-keygen –t {rsa|dsa}
generate_new_key_action= true
set /SP/services/ssh generate_new_key_type= [rsa|dsa]
usershow [username] Displays a list of all user accounts,
show /SP/users
permission levels, and whether passwords are assigned.
useradd username Adds a user account to ALOM CMT. create /SP/users/username
ALOM-to-ILOM Command Reference 47
TABLE: ALOM CMT Shell Configuration Commands (Continued)
ALOM CMT Command Summary Comparable ILOM Command
userdel username
Deletes a user account from ALOM
delete /SP/users/username
CMT. The –y option enables you to
userdel –y username
skip the confirmation question.
delete –script /SP/users/username
userpassword [username] Sets or changes a user password. set /SP/users/username
password
userperm [username][c][u][a]
[r]
Sets the permission level for a user account.
set /SP/users/username role= permissions
(where permissions are Administrator or Operator)
TABLE: ALOM CMT Shell Log Commands
ALOM CMT Command Summary Comparable ILOM Command
showlogs [–b lines|–e lines|–v]
[–g lines][-p logtype[r|p]]
Displays the history of all events logged in the ALOM CMT RAM event log, or major and critical events in the
show /SP/logs/event/list
persistent log. The –p option selects whether to display entries only from the RAM event log (logtype r) or the
No equivalent in ILOM
persistent event log (logtype p).
consolehistory [–b lines|–e lines|–v]
Displays the host server console output buffers.
No equivalent in ILOM
[–g lines][boot|run]
48 SPARC Enterprise T5440 Server Administration Guide • July 2009
TABLE: ALOM CMT Shell Status and Control Commands
ALOM CMT Command Summary Comparable ILOM Command
showenvironment Displays the environmental status of
the host server. This information
show –o table –level all /SYS
includes system temperatures, power supply status, front panel LED status, hard disk drive status, fan status, voltage, and current sensor status.
showpower [–v] Displays power metrics for the host
show /SP/powermgmt
server.
shownetwork [–v] Displays the current network
show /SP/network
configuration information. The –v option shows additional information about your network, including information about your DHCP server.
console
Connects to the host system console.
start /SP/console
The –f option forces the console write
console –f
lock from one user to another.
No equivalent in ILOM
break –c
break –D
bootmode [normal] [reset_nvram] [config=
configname][bootscript = string]
flashupdate –s IPaddr –f pathname [–v]
Drops the host server from running the Solaris OS software into OpenBoot PROM or kmdb depending upon the mode in which the Solaris software was booted.
Controls the host server OpenBoot PROM firmware method of booting.
Downloads and updates system firmware (both host firmware and ALOM CMT firmware). For ILOM, ipaddr must be a TFTP server. If DHCP is used, ipaddr can be replaced by the name of the TFTP host.
set /HOST send_break_action=break
set /HOST send_break_action=dumpcore
set /HOST/bootmode property=
value
[where property is state, config, or script]
load –source tftp://ipaddr/pathname
ALOM-to-ILOM Command Reference 49
TABLE: ALOM CMT Shell Status and Control Commands (Continued)
ALOM CMT Command Summary Comparable ILOM Command
reset [–c]
Attempts to gracefully reset the
reset /SYS
system. If that fails, this option
reset [–y][–c]
forcefully reset the system.
reset -script /SYS
reset –f
reset –d
reset [–d][–f]
reset [–d][–n]
reset [–d][–f][–n]
powercycle [–y] [–f]
powercycle –y
powercycle -f
Forcefully resets the system.
Attempts to gracefully reset the control domain. If that fails, this option forcefully reset the control domain.
Forcefully resets the control domain.
When resetting the control domain, this option may automatically boot (this is the default behavior when the auto-boot option is not specified).
When resetting the control domain, this option does not automatically boot and stays at the OpenBoot ok prompt. This option overrides all reboot variables and stops the control domain at the OpenBoot ok prompt after host reset. The auto-boot? option remains unchanged, thus subsequent reset commands automatically reboot host if the
auto-boot? option is set to true.
poweroff followed by poweron. The –f option forces an immediate poweroff, otherwise the command
attempts a graceful shutdown.
reset -f /SYS
reset /HOST/domain/control
reset - f /HOST/domain/control
set /HOST/domain/control
auto-boot=disable reset /HOST/domain/control
set /HOST/domain/control auto-boot=disable reset -f /HOST/domain/control
stop /SYS start /SYS stop –script /SYS start –script /SYS stop –force /SYS start –force /SYS
50 SPARC Enterprise T5440 Server Administration Guide • July 2009
TABLE: ALOM CMT Shell Status and Control Commands (Continued)
ALOM CMT Command Summary Comparable ILOM Command
poweroff
Removes the main power from the
stop /SYS
host server. The –y option enables you
poweroff –y
poweroff –f
to skip the confirmation question. ALOM CMT attempts to shut the server down gracefully. The –f option forces an immediate shutdown.
stop –script /SYS
stop –force /SYS
poweron Applies the main power to the host
start /SYS
server or FRU.
setlocator [on/off] Turns the Locator LED on the server
set /SYS/LOCATE value=value
on or off.
showfaults [–v] Displays current valid system faults. show /SP/faultmgmt
clearfault UUID Manually repairs system faults. set /SYS/component
clear_fault_action=true
showlocator Displays the current state of the
show /SYS/LOCATE
Locator LED as either on or off.
TABLE: ALOM CMT Shell FRU Commands
ALOM CMT Command Summary Comparable ILOM Command
setfru –c data The –c option enables you to store
information (such as inventory codes)
set /SYS customer_frudata=
data
on all FRUs in a system.
[showfru –g lines]
[–s|–d][FRU]
removefru [–y][FRU] Prepares a FRU (for example, a power
Displays information about the FRUs in a host server.
supply) for removal. The –y option enables you to skip the confirmation
No equivalent in ILOM
set /SYS/PS0 prepare_to_remove_action= true
question.
ALOM-to-ILOM Command Reference 51
TABLE: ALOM CMT Shell Automatic System Recovery (ASR) Commands
ALOM CMT Command Summary Comparable ILOM Command
enablecomponent
asr-key
disablecomponent
asr-key
showcomponent asr-key Displays system components and
clearasrdb Removes all entries from the asr-db
Removes a component from the asr-db blacklist.
Adds a component to the asr-db blacklist.
their test status (ASR state).
set /SYS/component component_state=enabled
set /SYS/component component_state=disabled
show /SYS/component component_state
No equivalent in ILOM
blacklist.
TABLE: ALOM CMT Shell Miscellaneous Commands
ALOM CMT Command Summary Comparable ILOM Command
help [command] Displays a list of all
help
ALOM CMT commands with their syntax and a brief description of how each command works. Specifying a command name as an option enables you to view the help for that command.
resetsc
Reboots ALOM CMT. The
reset /SP
–y option enables you to
resetsc –y
skip the confirmation question.
reset –script /SP
userclimode Sets the type of shell to
set /SP/users/username cli_mode=shelltype
shelltype, where shelltype is
default or alom.
logout Logs out from an ALOM
exit
CMT shell session.
52 SPARC Enterprise T5440 Server Administration Guide • July 2009
