SPARC EnterpriseTMT5120 and
T5220 Servers Overview Guide
Manual Code C120-E460-03EN
Part No. 875-4196-12
July 2009, Revision A
Copyright ©2009 Sun Microsystems, Inc., 4150Network Circle,Santa Clara,California 95054, U.S.A.All rightsreserved.
FUJITSU LIMITEDprovided technicalinput and review on portionsof thismaterial.
Sun Microsystems,Inc. andFujitsu Limited eachown orcontrol intellectualproperty rights relating to products and technologydescribed in
this document,and such products, technology andthis documentare protectedby copyright laws, patents andother intellectual property laws
and internationaltreaties. Theintellectual propertyrights of SunMicrosystems, Inc.and Fujitsu Limited in suchproducts, technologyand this
document include,without limitation, one or moreof theUnited States patentslisted athttp://www.sun.com/patentsand one or more
additional patentsor patent applications in theUnited States or other countries.
This documentand the product and technologyto whichit pertains are distributed underlicenses restrictingtheir use, copying, distribution,
and decompilation.No part of such productor technology, orof thisdocument, may bereproduced inany formby any meanswithout prior
written authorizationof Fujitsu Limited and SunMicrosystems, Inc.,and their applicablelicensors, ifany.The furnishingof this documentto
you doesnot give you any rightsor licenses, express or implied,with respectto theproduct or technology to whichit pertains,and this
document doesnot contain or representany commitment ofany kindon the partof FujitsuLimited or SunMicrosystems, Inc.,or anyaffiliate of
either ofthem.
This documentand the product and technologydescribed inthis document mayincorporate third-partyintellectual propertycopyrighted by
and/or licensedfrom suppliersto Fujitsu Limitedand/or SunMicrosystems, Inc.,including software and font technology.
Per theterms of the GPL orLGPL, a copy of thesource codegoverned by the GPL orLGPL, as applicable, is availableupon requestby the End
User.Please contactFujitsu Limited orSun Microsystems,Inc.
This distributionmay include materials developed bythird parties.
Parts ofthe productmay be derivedfrom BerkeleyBSD systems,licensed from the University ofCalifornia. UNIX is a registered trademark in
the U.S.and in other countries, exclusivelylicensed throughX/Open Company, Ltd.
Sun™, SunMicrosystems™, theSun logo
SunSolveSM, CoolThreads™,and J2EE™,are trademarksor registeredtrademarks of SunMicrosystems, Inc.or itssubsidiaries in theU.S. and
other countries.
©
, Java™,Netra™, Solaris™, Sun StorageTek™, docs.sun.comSM, OpenBoot™,SunVTS™, Sun Fire™,
Fujitsu andthe Fujitsu logo are registered trademarks ofFujitsu Limited.
All SPARC trademarksare usedunder license andare registered trademarks ofSPARCInternational, Inc.in the U.S.and othercountries.
Products bearingSPARCtrademarks arebased uponarchitecture developedby Sun Microsystems, Inc.
SPARC64 is atrademark of SPARC International, Inc., usedunder license by Fujitsu Microelectronics, Inc. andFujitsu Limited.
SSH isa registeredtrademark ofSSH Communications Securityin theUnited States andin certainother jurisdictions.
The OPENLOOK and Sun™ Graphical UserInterface was developed by SunMicrosystems, Inc.for its users and licensees.Sun acknowledges
the pioneeringefforts ofXerox inresearching anddeveloping the conceptof visualor graphical userinterfaces forthe computer industry.Sun
holds anon-exclusive license from Xeroxto the Xerox Graphical UserInterface, which license also coversSun’s licensees who implement OPEN
LOOK GUIsand otherwise comply with Sun’swritten license agreements.
United StatesGovernment Rights - Commercial use.U.S. Governmentusers aresubject to thestandard governmentuser license agreements of
Sun Microsystems,Inc. andFujitsu Limited andthe applicableprovisions ofthe FARand itssupplements.
Disclaimer: Theonly warranties granted by FujitsuLimited, Sun Microsystems, Inc. orany affiliateof eitherof them inconnection withthis
document orany productor technology described herein are those expressly set forthin thelicense agreementpursuant to whichthe productor
technology isprovided.
EXCEPT ASEXPRESSLYSET FORTHIN SUCHAGREEMENT, FUJITSULIMITED, SUNMICROSYSTEMS, INC. ANDTHEIR AFFILIATES
MAKE NOREPRESENTATIONS OR WARRANTIES OFANY KIND(EXPRESS OR IMPLIED)REGARDING SUCHPRODUCT OR
TECHNOLOGY ORTHIS DOCUMENT, WHICH AREALL PROVIDEDAS IS, ANDALL EXPRESSOR IMPLIED CONDITIONS,
REPRESENTATIONS ANDWARRANTIES,INCLUDING WITHOUT LIMITATIONANY IMPLIEDWARRANTYOF MERCHANTABILITY,
FITNESS FORA PARTICULAR PURPOSEOR NON-INFRINGEMENT, ARE DISCLAIMED,EXCEPT TOTHE EXTENT THAT SUCH
DISCLAIMERS AREHELD TOBE LEGALLY INVALID.
Unless otherwiseexpressly setforth in suchagreement, tothe extentallowed by applicablelaw,in noevent shall FujitsuLimited, Sun
Microsystems, Inc.or anyof their affiliates have anyliability toany third party under anylegal theory for any lossof revenuesor profits,loss of
use ordata, or business interruptions, orfor anyindirect, special, incidental or consequentialdamages, even if advised ofthe possibilityof such
damages.
DOCUMENTATION ISPROVIDED “AS IS”AND ALLEXPRESS OR IMPLIEDCONDITIONS, REPRESENTATIONSAND WARRANTIES,
INCLUDING ANYIMPLIED WARRANTY OF MERCHANTABILITY, FITNESS FORA PARTICULAR PURPOSE OR NON-INFRINGEMENT,
ARE DISCLAIMED,EXCEPT TOTHE EXTENT THAT SUCHDISCLAIMERS ARE HELD TO BELEGALLYINVALID.
Please
Recycle
Copyright ©2009 Sun Microsystems, Inc., 4150Network Circle,Santa Clara,California 95054, Etats-Unis.Tousdroits réservés.
Entrée etrevue tecnicalfournies par FUJITSULIMITED surdes parties dece matériel.
Sun Microsystems,Inc. etFujitsu Limited détiennentet contrôlenttoutes deux desdroits depropriété intellectuellerelatifs auxproduits et
technologies décritsdans ce document. De même,ces produits,technologies et cedocument sontprotégés pardes lois surle copyright,des
brevets, d’autres lois surla propriétéintellectuelle et destraités internationaux.Les droitsde propriété intellectuelle de SunMicrosystems, Inc.
et FujitsuLimited concernant ces produits, cestechnologies etce document comprennent, sans quecette listesoit exhaustive, unou plusieurs
des brevetsdéposés auxÉtats-Unis et indiquésà l’adressehttp://www.sun.com/patentsde mêmequ’un ou plusieursbrevets ouapplications
brevetées supplémentaires aux États-Uniset dans d’autres pays.
Ce document,le produitet les technologiesafférents sont exclusivement distribuésavec des licences qui enrestreignent l’utilisation,la copie,la
distribution etla décompilation. Aucune partie dece produit,de ces technologiesou dece document ne peut êtrereproduite sousquelque
forme quece soit, par quelque moyenque ce soit, sans l’autorisationécrite préalablede Fujitsu Limitedet deSun Microsystems, Inc., et deleurs
éventuels bailleursde licence. Ce document, bienqu’il vous ait été fourni,ne vousconfère aucun droit et aucunelicence, expressesou tacites,
concernant leproduit oula technologie auxquelsil serapporte. Par ailleurs,il necontient ni ne représente aucunengagement, dequelque type
que cesoit, de la part deFujitsu Limited ou de SunMicrosystems, Inc.,ou des sociétés affiliées.
Ce document,et le produit et lestechnologies qu’ildécrit, peuvent inclure des droits de propriétéintellectuelle departies tierces protégés par
copyright et/oucédés sous licence par desfournisseurs à Fujitsu Limited et/ouSun Microsystems,Inc., y compris des logicielset des
technologies relativesaux policesde caractères.
Par limitesdu GPL ou du LGPL,une copie du code sourcerégi parle GPL ou LGPL, commeapplicable, est sur demande versla fin utilsateur
disponible; veuillezcontacter Fujitsu Limted ou SunMicrosystems, Inc.
Cette distributionpeut comprendredes composantsdéveloppés par destierces parties.
Des partiesde ce produit pourrontêtre dérivées des systèmes BerkeleyBSD licenciés par l’Université deCalifornie. UNIX est une marque
déposée auxEtats-Unis et dans d’autres payset licenciéeexclusivement par X/OpenCompany, Ltd.
Sun™, SunMicrosystems™, lelogo Sun
SunSolveSM, CoolThreads™,et J2EE™sont des marques de fabriqueou desmarques déposées de Sun Microsystems,Inc. ,ou ses filialesaux
Etats-Unis etdans d’autrespays.
©
, Java™,Netra™, Solaris™, Sun StorageTek™, docs.sun.comSM, OpenBoot™,SunVTS™, Sun Fire™,
Fujitsu etle logo Fujitsu sont desmarques déposéesde Fujitsu Limited.
Toutes les marquesSPARCsont utiliséessous licence etsont desmarques defabrique ou desmarques déposéesde SPARC International, Inc.
aux Etats-Uniset dans d’autres pays. Lesproduits portantles marquesSPARCsont basés sur une architecture développée parSun
Microsystems, Inc.
SPARC64 est unemarques déposéede SPARC International, Inc.,utilisée sousle permis parFujitsu Microelectronics,Inc. etFujitsu Limited.
SSH estune marquedéposée registrede SSH Communications Security auxEtats-Uniset dans certaines autres juridictions.
L’interfaced’utilisation graphiqueOPEN LOOK etSun™ aété développée parSun Microsystems,Inc. pourses utilisateurs etlicenciés. Sun
reconnaît lesefforts depionniers deXerox pour la recherche et le développementdu conceptdes interfaces d’utilisationvisuelle ougraphique
pour l’industriede l’informatique. Sun détient unelicense non exclusive de Xeroxsur l’interfaced’utilisation graphique Xerox, cette licence
couvrant égalementles licenciésde Sun quimettent enplace l’interfaced’utilisation graphique OPENLOOK etqui, en outre, se conforment aux
licences écritesde Sun.
Droits dugouvernement américain- logiciel commercial. Les utilisateursdu gouvernementaméricain sont soumisaux contratsde licence
standard deSun Microsystems,Inc. etde Fujitsu Limitedainsi qu’auxclauses applicables stipuléesdans leFAR et ses suppléments.
Avis de non-responsabilité:les seulesgaranties octroyées par Fujitsu Limited,Sun Microsystems,Inc. ou toute société affiliéede l’uneou l’autre
entité enrapport avec ce document outout produitou toute technologiedécrit(e) dansles présentes correspondent aux garantiesexpressément
stipulées dansle contrat de licence régissantle produitou la technologiefourni(e).
SAUF MENTIONCONTRAIRE EXPRESSÉMENT STIPULÉE DANS CECONTRAT, FUJITSU LIMITED,SUN MICROSYSTEMS,INC. ET LES
SOCIÉTÉS AFFILIÉESREJETTENT TOUTEREPRÉSENTATION OU TOUTE GARANTIE, QUELLEQU’EN SOIT LA NATURE(EXPRESSE
OU IMPLICITE)CONCERNANT CE PRODUIT, CETTETECHNOLOGIE OUCE DOCUMENT, LESQUELS SONTFOURNIS EN L’ÉTAT.EN
OUTRE, TOUTESLES CONDITIONS,REPRÉSENTATIONS ET GARANTIESEXPRESSES OUTACITES, Y COMPRIS NOTAMMENT TOUTE
GARANTIE IMPLICITERELATIVEÀ LA QUALITÉMARCHANDE, ÀL’APTITUDE À UNE UTILISATION PARTICULIÈRE OUÀ
L’ABSENCEDE CONTREFAÇON, SONT EXCLUES,DANS LAMESURE AUTORISÉEPARLA LOI APPLICABLE.
Sauf mentioncontraire expressémentstipulée dansce contrat, dansla mesureautorisée par la loi applicable,en aucun cas Fujitsu Limited,Sun
Microsystems, Inc.ou l’unede leurs filialesne sauraientêtre tenuesresponsables envers une quelconque partietierce, sousquelque théorie
juridique quece soit, de tout manqueà gagner ou de pertede profit,de problèmesd’utilisation ou deperte dedonnées, ou d’interruptions
d’activités, oude tout dommage indirect, spécial,secondaire ouconsécutif, mêmesi ces entitésont étépréalablement informées d’unetelle
éventualité.
LA DOCUMENTATIONEST FOURNIE “ENL’ETAT”ET TOUTESAUTRES CONDITIONS, DECLARATIONS ETGARANTIES EXPRESSES
OU TACITES SONTFORMELLEMENT EXCLUES, DANSLA MESUREAUTORISEE PAR LALOI APPLICABLE, YCOMPRIS NOTAMMENT
TOUTE GARANTIEIMPLICITE RELATIVE A LA QUALITE MARCHANDE,A L’APTITUDE A UNEUTILISATIONPARTICULIERE OU A
L’ABSENCEDE CONTREFACON.
Contents
Preface vii
Understanding Server Features 1
Server Highlights 2
Features at a Glance 4
Additional Feature Information 8
Chip-Multithreaded Processor and Memory Technology 8
Performance Enhancements 9
Preinstalled Solaris Operating System 9
Hardware-Assisted Cryptography 10
Support for Virtualization Through
Logical Domains (LDoms) 10
Remote Manageability With ILOM 11
High Levels of System Reliability, Availability, and Serviceability 12
Hot-Pluggable and Hot-Swappable Components 13
Power Supply Redundancy 13
Environmental Monitoring 14
Support for RAID Storage Configurations 15
Error Correction and Parity Checking 15
Fault Management and Predictive Self Healing 16
Rackmountable Enclosure 16
v
vi SPARC Enterprise T5120 and T5220 Servers Overview Guide • July 2009
Preface
This guide provides an overview of the SPARC Enterprise™ T5120 and T5220 servers
features.
For Safe Operation
This manual contains important information regarding the use and handling of this
product. Read this manual thoroughly. Use the product according to the instructions
and information available in this manual. Keep this manual handy for further
reference.
Fujitsu makes every effort to prevent users and bystanders from being injured or
from suffering damage to their property. Use the product according to this manual.
vii
Related Documentation
The latest versions of all the SPARC Enterprise Series manuals are available at the
following Web sites:
Global Site
(http://www.fujitsu.com/sparcenterprise/manual/)
Japanese Site
(http://primeserver.fujitsu.com/sparcenterprise/manual/)
Title Description Manual Code
SPARC Enterprise T5120 Server
Getting Started Guide
SPARC Enterprise T5120 Server
Getting Started Guide For Models
That Run on DC Input Power
SPARC Enterprise T5220 Server
Getting Started Guide
SPARC Enterprise T5220 Server
Getting Started Guide For Models
That Run on DC Input Power
SPARC Enterprise T5120 and
T5220 Servers Product Notes
Important Safety Information for
Hardware Systems
SPARC Enterprise T5120 and
T5220 Servers Safety and
Compliance Guide
SPARC Enterprise/
PRIMEQUEST Common
Installation Planning Manual
SPARC Enterprise T5120 and
T5220 Servers Site Planning
Guide
SPARC Enterprise T5120 and
T5220 Servers Overview Guide
SPARC Enterprise T5120 and
T5220 Servers Installation Guide
Minimum steps to power on and boot the
server for the first time
Minimum steps to power on and boot the
server that run on DC input power for the
first time
Minimum steps to power on and boot the
server for the first time
Minimum steps to power on and boot the
server that run on DC input power for the
first time
Information about the latest product
updates and issues
Safety information that is common to all
SPARC Enterprise series servers
Safety and compliance information that is
specific to the servers
Requirements and concepts of installation
and facility planning for the setup of
SPARC Enterprise and PRIMEQUEST
Server specifications for site planning C120-H027
Product features C120-E460
Detailed rackmounting, cabling, power on,
and configuring information
C120-E518
C120-E552
C120-E519
C120-E553
C120-E458
C120-E391
C120-E461
C120-H007
C120-E462
viii SPARC Enterprise T5120 and T5220 Servers Overview Guide • July 2009
Title Description Manual Code
SPARC Enterprise T5120 and
T5220 Servers Service Manual
SPARC Enterprise T5120 and
T5220 Servers Administration
Guide
Integrated Lights Out Manager
2.0 User’s Guide
Integrated Lights Out Manager
2.0 Supplement for SPARC
Enterprise T5120 and T5220
Servers
Integrated Lights Out Manager
(ILOM) 3.0 Concepts Guide
Integrated Lights Out Manager
(ILOM) 3.0 Getting Started Guide
Integrated Lights Out Manager
(ILOM) 3.0 Web Interface
Procedures Guide
Integrated Lights Out Manager
(ILOM) 3.0 CLI Procedures Guide
Integrated Lights Out Manager
(ILOM) 3.0 SNMP and IPMI
Procedures Guide
Integrated Lights Out Manager
(ILOM) 3.x Feature Updates and
Release Notes
Integrated Lights Out Manager
(ILOM) 3.0 Supplement for
SPARC Enterprise T5120 and
T5220 Servers
External I/O Expansion Unit
Installation and Service Manual
External I/O Expansion Unit
Product Notes
How to run diagnostics to troubleshoot the
server, and how to remove and replace
parts in the server
How to perform administrative tasks that
are specific to the servers
Information that is common to all
platforms managed by Integrated Lights
Out Manager (ILOM) 2.0
How to use the ILOM 2.0 software on the
servers
Information that describes ILOM 3.0
features and functionality
Information and procedures for network
connection, logging in to ILOM 3.0 for the
first time, and configuring a user account
or a directory service
Information and procedures for accessing
ILOM 3.0 functions using the ILOM web
interface
Information and procedures for accessing
ILOM 3.0 functions using the ILOM CLI
Information and procedures for accessing
ILOM 3.0 functions using SNMP or IPMI
management hosts
Enhancements that have been made to
ILOM firmware since the ILOM 3.0 release
How to use the ILOM 3.0 software on the
servers
Procedures for installing the External I/O
Expansion Unit on the SPARC Enterprise
T5120/T5140/T5220/T5240/T5440 servers
Important and late-breaking information
about the External I/O Expansion Unit
C120-E463
C120-E464
C120-E474
C120-E465
C120-E573
C120-E576
C120-E574
C120-E575
C120-E579
C120-E600
C120-E577
C120-E543
C120-E544
Preface ix
Note – Product Notes are available on the website only. Please check for the recent
update on your product.
Conventions for Alert Messages
This manual uses the following conventions to show alert messages, which are
intended to prevent injury to the user or bystanders as well as property damage, and
important messages that are useful to the user.
Warning – This indicates a hazardous situation that could result in death or serious
personal injury (potential hazard) if the user does not perform the procedure
correctly.
Caution – This indicates a hazardous situation that could result in minor or
moderate personal injury if the user does not perform the procedure correctly. This
signal also indicates that damage to the product or other property may occur if the
user does not perform the procedure correctly.
Alert Messages in the Text
An alert message in the text consists of a signal indicating an alert level followed by
an alert statement. A space of one line precedes and follows an alert statement.
Caution – The following tasks regarding this product and the optional products
provided from Fujitsu should only be performed by a certified service engineer.
Users must not perform these tasks. Incorrect operation of these tasks may cause
malfunction.
x SPARC Enterprise T5120 and T5220 Servers Overview Guide • July 2009
Product Handling
Maintenance
Warning – Certain tasks in this manual should only be performed by a certified
service engineer. User must not perform these tasks. Incorrect operation of these
tasks may cause electric shock, injury, or fire.
■ Installation and reinstallation of all components, and initial settings
■ Removal of front, rear, or side covers
■ Mounting/de-mounting of optional internal devices
■ Plugging or unplugging of external interface cards
■ Maintenance and inspections (repairing, and regular diagnosis and maintenance)
Caution – The following tasks regarding this product and the optional products
provided from Fujitsu should only be performed by a certified service engineer.
Users must not perform these tasks. Incorrect operation of these tasks may cause
malfunction.
■ Unpacking optional adapters and such packages delivered to the users
■ Plugging or unplugging of external interface cards
Remodeling/Rebuilding
Caution – Do not make mechanical or electrical modifications to the equipment.
Using this product after modifying or reproducing by overhaul may cause
unexpected injury or damage to the property of the user or bystanders.
Preface xi
Fujitsu Welcomes Your Comments
If you have any comments or requests regarding this document, or if you find any
unclear statements in the document, please state your points specifically on the form
at the following URL.
For Users in U.S.A., Canada, and Mexico:
(https://download.computers.us.fujitsu.com/)
For Users in Other Countries:
(http://www.fujitsu.com/global/contact/computing/sparce_index.ht
ml)
xii SPARC Enterprise T5120 and T5220 Servers Overview Guide • July 2009
Understanding Server Features
These topics describe the features of the SPARC Enterprise T5120 and T5220 servers.
The following topics are covered:
■ “Server Highlights” on page 2
■ “Features at a Glance” on page 4
■ “Additional Feature Information” on page 8
Related Information
■ SPARC Enterprise T5120 and T5220 Servers Product Notes
■ SPARC Enterprise T5120 and T5220 Servers Getting Started Guide
■ SPARC Enterprise T5120 and T5220 Servers Getting Started Guide (DC)
■ SPARC Enterprise T5120 and T5220 Servers Site Planning Guide
■ SPARC Enterprise T5120 and T5220 Servers Installation Guide
■ SPARC Enterprise T5120 and T5220 Servers Administration Guide
■ Integrated Lights Out Manager (ILOM) software documentation
■ Integrated Lights Out Manager (ILOM) 3.0 Supplement for SPARC Enterprise T5120
and T5220 Servers
■ Logical Domains (LDoms) software
documentation (http://docs.sun.com/app/docs/prod/ldoms)
■ SPARC Enterprise T5120 and T5220 Servers Service Manual
■ Solaris OS
documentation (http://docs.sun.com/app/docs/prod/solaris)
1
Server Highlights
The SPARC Enterprise T5120 (FIGURE: SPARC Enterprise T5120 Server on page 3)
and T5220 (FIGURE: SPARC Enterprise T5220 Server on page 3) servers are scalable,
reliable, high-performance, entry-level servers, optimized for enterprise data centers.
These servers offer the following key features:
■ The UltraSPARC T2 multicore processor with CoolThreads technology for
high-throughput and energy savings.
■ High levels of system uptime through the processor and memory
reliability-availability-serviceability (RAS) features, coupled with redundancy of
some systems components, support for hardware RAID (0+1), and the Predictive
Self-Healing features of the Solaris 10 Operating System (Solaris OS).
■ Both servers come in a space efficient, rack-optimized form factor chassis, 1U for
the SPARC Enterprise T5120 server, and 2U for the SPARC Enterprise T5220
server.
■ Investment protection with SPARC V9 binary application compatibility and the
Solaris 10 OS. The Solaris 10 OS also provides features such as Solaris Predictive
Self-Healing, Solaris Dynamic Tracing, and support across UltraSPARC platforms.
■ Unified server management though the use of the Integrated Lights Out Manager
(ILOM) interface. ILOM integrates and manages CoolThreads and x64 platforms
with the same tool set, and in heterogeneous environments, using industry
standard element management tools and enterprise frameworks.
The following figure shows the SPARC Enterprise T5120 server chassis as viewed
from the front and top.
2 SPARC Enterprise T5120 and T5220 Servers Overview Guide • July 2009
FIGURE: SPARC Enterprise T5120 Server
The following figure shows the SPARC Enterprise T5220 server chassis as viewed
from the front and top.
FIGURE: SPARC Enterprise T5220 Server
Related Information
■ SPARC Enterprise T5120 and T5220 Servers Product Notes
■ SPARC Enterprise T5120 and T5220 Servers Administration Guide
■ Integrated Lights Out Manager (ILOM) software documentation
Understanding Server Features 3
■ Integrated Lights Out Manager (ILOM) 3.0 Supplement for SPARC Enterprise T5120
and T5220 Servers
■ Solaris OS
documentation (http://docs.sun.com/app/docs/prod/solaris)
Features at a Glance
The following table describes in summary form the main features of the SPARC
Enterprise T5120 and T5220 servers.
TABLE: Summary of Features
Feature Description
Chassis dimensions
and rackmounting
hardware
Processor One UltraSPARC T2 multicore processor with one of the following
Memory
Slots/Capacity
*
T5120: 1 rack unit (1U)
• Width: 425 mm (16.75 in.)
• Height: 44 mm (1.75 in.)
• Depth: 714 mm (28.13 in.)
T5220: 2 rack units (2U)
• Width: 425 mm (16.75 in.)
• Height: 88 mm (3.49 in.)
• Depth: 714 mm (28.125 in.)
number of cores:
• 4 cores (32 threads); 1.2 GHz
• 8 cores (64 threads); 1.2, 1.4, or 1.6 GHz
Sixteen FBDIMM slots supporting 2-, 4-, and 8-Gbyte modules
(maximum capacity of 128 Gbytes of system memory)
4 SPARC Enterprise T5120 and T5220 Servers Overview Guide • July 2009
TABLE: Summary of Features (Continued)
Feature Description
Internal Hard
*
Drives
T5120:
Up to eight 73-Gbyte, 146-Gbyte, or 300-Gbyte 2.5 inch SAS hard
drives (hot-pluggable)
Up to four solid-state drives can be used in conjunction with
disk-based hard drives for a total of eight hard drive storage units.
Integrated hard drive controller supports RAID 0 and RAID 1.
T5220:
Up to sixteen 73-Gbyte or 146-Gbyte, or 300-Gbyte 2.5 inch SAS
hard drives (hot-pluggable).
Up to eight solid-state drives can be used in conjunction with
disk-based hard drives for a total of sixteen hard drive storage
units.
Integrated hard drive controller supports RAID 0 and RAID 1.
Note - Some T5120 models only support up to four hard drives.
Some T5220 models only support up to eight hard drives.
Optical Media Device One, slot-loading, slimline DVD drive, supporting CD-R/W,
DVD-R/W, DVD+R/W
Power Supplies Two hot-swappable power supply units providing N+1 redundancy
Cooling
*
T5120: Four to seven hot-swappable fan modules (two fans per
module)
T5220: Three to four hot-swappable fan modules (two fans per
module)
Ethernet Ports Four 10/100/1000 Mbps Ethernet, RJ-45-based, autonegotiating
ports (on two separate controllers)
Note - 10-Gbit Ethernet ports are available by adding XAUI cards to
the I/O expansion slots. For each XAUI card added, one onboard
1-Gbit Ethernet port is disabled.
Understanding Server Features 5
TABLE: Summary of Features (Continued)
Feature Description
PCI Express Interfaces*T5120:
Three low-profile PCI Express slots with the following slot
designated specifications
†
:
• One slot – PCIe, 8-lane
• Two slots – PCIe 4-lane (alternatively, these slots can be used for
10-Gbit Ethernet by adding XAUI cards)
• Up to 5 additional PCIe slots are available using an External I/O
Expansion Unit
T5220:
Six low-profile PCI Express slots with the following slot designated
specifications
†
• Two slots – PCIe, 8-lane
• Two slots – PCIe, 4-lane
• Two slots – PCIe 4-lane (alternatively, these slots can be used for
10-Gbit Ethernet by adding XAUI cards)
• Up to 10 additional PCIe slots are available using up to two
External I/O Expansion Units
Note - All PCIe cards are installed using supplied riser boards
USB Ports Four USB 2.0 ports (2 forward, 2 rear facing).
Additional Ports The following connectors are located on the rear of the server:
• One RJ-45 serial management port (SER MGT) – the default
connection to the service processor
• One 10/100 Mbps Ethernet network management port (NET
MGT) – connection to the service processor
• One DB-9 serial port – connection to the host
Remote Management Onboard Integrated Lights Out Manager (ILOM), with two
command sets:
• ILOM
• ALOM CMT compatibility shell (legacy command set)
Both command sets are accessible through the RJ-45 serial and
10/100 Mbps Ethernet interfaces.
6 SPARC Enterprise T5120 and T5220 Servers Overview Guide • July 2009
TABLE:
Feature Description
Summary of Features (Continued)
Cryptography Processor-integrated, cyptographic acceleration that supports
industry-standard security ciphers
Refer to the server product notes for information on the minimum
version of supported OS and required patches
Operating System Solaris 10 OS preinstalled on disk 0
Refer to the server product notes for information on the minimum
version of supported OS and required patches.
Other Software • Java Enterprise System
• Logical Domains Manager
• Sun Studio
Refer to the server product notes for details about specific versions
of the preinstalled software.
* This symbol marks a feature specification that differs between the two servers models.
† PCI-e and PCI-X specifications described in this table list the physical requirements for PCI cards. Additional
support capabilitiesmust also beprovided (suchas device drivers)for aPCI card tofunction in the server. Refer
to the specifications and documentation for a given PCI card todetermine if the required drivers are provided
that enable the card to function in this server.
Related Information
■ SPARC Enterprise T5120 and T5220 Servers Product Notes
■ SPARC Enterprise T5120 and T5220 Servers Site Planning Guide
■ SPARC Enterprise T5120 and T5220 Servers Getting Started Guide
■ SPARC Enterprise T5120 and T5220 Servers Getting Started Guide (DC)
■ SPARC Enterprise T5120 and T5220 Servers Installation Guide
■ Integrated Lights Out Manager (ILOM) software documentation
■ Integrated Lights Out Manager (ILOM) 3.0 Supplement for SPARC Enterprise T5120
and T5220 Servers
■ Logical Domains (LDoms) software
documentation (http://docs.sun.com/app/docs/prod/ldoms)
■ SPARC Enterprise T5120 and T5220 Servers Service Manual
■ Solaris OS
documentation (http://docs.sun.com/app/docs/prod/solaris)
Understanding Server Features 7
Additional Feature Information
■ “Chip-Multithreaded Processor and Memory Technology” on page 8
■ “Performance Enhancements” on page 9
■ “Preinstalled Solaris Operating System” on page 9
■ “Hardware-Assisted Cryptography” on page 10
■ “Support for Virtualization Through Logical Domains (LDoms)” on page 10
■ “Remote Manageability With ILOM” on page 11
■ “High Levels of System Reliability, Availability, and Serviceability” on page 12
■ “Fault Management and Predictive Self Healing” on page 16
■ “Rackmountable Enclosure” on page 16
Chip-Multithreaded Processor and Memory Technology
The UltraSPARC T2 multicore processor is the basis of the SPARC Enterprise T5120
and T5220 servers. The UltraSPARC T2 processor is based on chip multithreading
(CMT) technology that is optimized for highly threaded transactional processing. The
UltraSPARC T2 processor improves throughput while using less power and
dissipating less heat than conventional processor designs.
Depending on the model purchased, the processor has four, six, or eight UltraSPARC
cores. Each core equates to a 64-bit execution pipeline capable of running eight
threads. The result is that the 8-core processor handles up to 64 active threads
concurrently.
Additional processor components, such as L1 cache, L2 cache, memory access
crossbar, memory controllers, and the I/O interface have been carefully tuned for
optimal performance.
Related Information
■ SPARC Enterprise T5120 and T5220 Servers Product Notes
■ SPARC Enterprise T5120 and T5220 Servers Installation Guide
■ SPARC Enterprise T5120 and T5220 Servers Administration Guide
■ SPARC Enterprise T5120 and T5220 Servers Service Manual
8 SPARC Enterprise T5120 and T5220 Servers Overview Guide • July 2009
Performance Enhancements
The SPARC Enterprise T5120 and T5220 servers running the Solaris 10 OS provide
several new performance enhancing technologies with its sun4v architecture and
multicore, multithreaded UltraSPARC T2 processor.
Some of these enhancements are:
■ A floating point unit (FPU) for each core
■ Four independent dual-channel memory controllers that use the latest fully
buffered memory technology
■ Processor-integrated cyptographic acceleration
■ Large page optimization
■ Reduction on TLB misses
■ Optimized block copy
■ Support for 10-Gbit Ethernet with the addition of XAUI cards
Related Information
■ SPARC Enterprise T5120 and T5220 Servers Product Notes
■ SPARC Enterprise T5120 and T5220 Servers Installation Guide
■ SPARC Enterprise T5120 and T5220 Servers Administration Guide
■ SPARC Enterprise T5120 and T5220 Servers Service Manual
Preinstalled Solaris Operating System
The SPARC Enterprise T5120 and T5220 servers are preinstalled with the Solaris 10
OS, and offer the following Solaris OS features:
■ Stability, high performance, scalability, and precision of a mature 64-bit operating
system.
■ Support for over 12,000 leading technical and business applications.
■ Solaris Containers – Isolate software applications and services using flexible,
software-defined boundaries.
■ DTrace – A comprehensive dynamic tracing framework for tuning applications
and troubleshooting systemic problems in real time.
■ Predictive Self-Healing – Capability that automatically diagnoses, isolates, and
recovers from many hardware and application faults.
■ Security – Advanced security features designed to protect the enterprise at
multiple levels.
Understanding Server Features 9
■ Network Performance – Completely rewritten TCP/IP stack dramatically
improves the performance and scalability of your networked services.
You can use the preinstalled Solaris 10 OS, or reinstall a supported version of the
Solaris 10 OS from your network, CD, or downloaded copy. Refer to the SPARC
Enterprise T5120 and T5220 Servers Product Notes for information on the supported OS
releases for your server.
Related Information
■ SPARC Enterprise T5120 and T5220 Servers Product Notes
■ Solaris OS
documentation (http://docs.sun.com/app/docs/prod/solaris)
Hardware-Assisted Cryptography
The UltraSPARC T2 multicore, multithreaded processors provide hardware-assisted
acceleration of symmetric, asymmetric, hashing and random number generation
cryptographic operations as follows:
■ Asymmetric algorithms – RSA, DSA, Diffie Hellman, and Elliptic Curve
cryptography
■ Symmetric algorithms – AES, 3DES, and RC$
■ Hashing algorithms – SHA1, SHA256, and MD5
The Solaris 10 OS provides the multithreaded device driver that supports the
hardware-assisted cryptography.
Related Information
■ SPARC Enterprise T5120 and T5220 Servers Product Notes
■ Solaris OS
documentation (http://docs.sun.com/app/docs/prod/solaris)
Support for Virtualization Through Logical Domains (LDoms)
The SPARC Enterprise T5120 and T5220 servers support the use of Logical Domains
(LDoms) technology. Through the use of the Solaris OS and the built-in server
firmware, and by installing the Logical Domains Manager software, you can
virtualize the compute services that run on your server.
10 SPARC Enterprise T5120 and T5220 Servers Overview Guide • July 2009
A logical domain is a discrete, logical grouping with its own operating system,
resources, and identity within a single computer system. Each logical domain can be
created, destroyed, reconfigured, and rebooted independently, without requiring a
power cycle of the server.
You can run a variety of applications software in different logical domains and keep
them independent for performance and security purposes.
Each logical domain can be managed as an entirely independent machine with its
own resources, such as:
■ Kernel, patches, and tuning parameters
■ User accounts and administrators
■ Network interfaces, MAC addresses, and IP addresses
Each logical domain can interact only with those server resources made available to
it. The configuration is controlled using the Logical Domains Manager.
Related Information
■ SPARC Enterprise T5120 and T5220 Servers Product Notes
■ Logical Domains (LDoms) software
documentation (http://docs.sun.com/app/docs/prod/ldoms)
Remote Manageability With ILOM
The Integrated Lights Out Manager (ILOM) feature is a service processor that is built
into the server, and enables you to remotely manage and administer the server.
The ILOM software is preinstalled as firmware, and initializes as soon as you apply
power to the system.
ILOM enables you to monitor and control your server over an Ethernet connection
(supports SSH), or by using a dedicated serial port for connection to a terminal or
terminal server. ILOM provides a command-line interface and a browser-based
interface that you can use to remotely administer geographically distributed or
physically inaccessible machines. In addition, ILOM enables you to run diagnostics
(such as POST) remotely that would otherwise require physical proximity to the
server’s serial port.
You can configure ILOM to send email alerts of hardware failures and warnings, and
other events related to the server. The ILOM circuitry runs independently of the
server, using the server’s standby power. Therefore, ILOM firmware and software
continue to function when the server operating system goes offline or when the
server is powered off. ILOM monitors the following SPARC Enterprise T5120 and
T5220 server conditions:
Understanding Server Features 11
■ CPU temperature conditions
■ Hard drive status
■ Enclosure thermal conditions
■ Fan speed and status
■ Power supply status
■ Voltage conditions
■ Solaris watchdog, boot time-outs, and automatic server restart events
In addition to the ILOM CLI and browser interface, you can set up the server to use
the ALOM CMT compatibility CLI. The ALOM CMT compatibility CLI provides
commands that approximate the ALOM CMT UI that was provided on some
previous servers.
Related Information
■ SPARC Enterprise T5120 and T5220 Servers Product Notes
■ Integrated Lights Out Manager (ILOM) software documentation
■ Integrated Lights Out Manager (ILOM) 3.0 Supplement for SPARC Enterprise T5120
and T5220 Servers
High Levels of System Reliability, Availability, and Serviceability
Reliability, availability, and serviceability (RAS) are aspects of a system’s design that
affect its ability to operate continuously and to minimize the time necessary to
service the system. Reliability refers to a system’s ability to operate continuously
without failures and to maintain data integrity. System availability refers to the ability
of a system to recover to an operational state after a failure, with minimal impact.
Serviceability relates to the time it takes to restore a system to service following a
system failure. Together, reliability, availability, and serviceability features provide
for near-continuous system operation.
To deliver high levels of reliability, availability, and serviceability, the SPARC
Enterprise T5120 and T5220 servers offer the following features:
■ Ability to disable individual threads and cores without rebooting
■ Lower heat generation, reducing hardware failures
■ Hot-pluggable hard drives
■ Redundant, hot-swappable power supplies (two)
■ Redundant N+1 hot-swappable fan modules
■ Environmental monitoring
12 SPARC Enterprise T5120 and T5220 Servers Overview Guide • July 2009
■ Internal hardware drive mirroring (RAID 1)
■ Error detection and correction for improved data integrity
■ Easy access for most component replacements
Related Information
■ “Hot-Pluggable and Hot-Swappable Components” on page 13
■ “Power Supply Redundancy” on page 13
■ “Environmental Monitoring” on page 14
■ “Support for RAID Storage Configurations” on page 15
■ “Error Correction and Parity Checking” on page 15
Hot-Pluggable and Hot-Swappable Components
SPARC Enterprise T5120 and T5220 server hardware is designed to support
hot-plugging of the chassis-mounted hard drives, and hot-swapping of fan units, and
power supplies. By using the proper software commands, you can install or remove
these components while the system is running. Hot-swap and hot-plug technology
significantly increases the system’s serviceability and availability by providing the
ability to replace hard drives, fan units, and power supplies without service
disruption.
Related Information
■ SPARC Enterprise T5120 and T5220 Servers Product Notes
■ SPARC Enterprise T5120 and T5220 Servers Administration Guide
■ Integrated Lights Out Manager (ILOM) software documentation
■ Integrated Lights Out Manager (ILOM) 3.0 Supplement for SPARC Enterprise T5120
and T5220 Servers
■ SPARC Enterprise T5120 and T5220 Servers Service Manual
■ SPARC Enterprise T5120 and T5220 Servers Safety and Compliance Guide
Power Supply Redundancy
The SPARC Enterprise T5120 and T5220 servers provide two hot-swappable power
supplies, enabling the system to continue operating should one of the power supplies
fail or if a power source fails.
Understanding Server Features 13
Related Information
■ SPARC Enterprise T5120 and T5220 Servers Product Notes
■ SPARC Enterprise T5120 and T5220 Servers Administration Guide
■ SPARC Enterprise T5120 and T5220 Servers Service Manual
Environmental Monitoring
The SPARC Enterprise T5120 and T5220 servers feature an environmental monitoring
subsystem that protects the server and its components against:
■ Extreme temperatures
■ Lack of adequate airflow through the system
■ Power supply failures
■ Hardware faults
Temperature sensors are located throughout the system to monitor the ambient
temperature of the system and internal components. The software and hardware
ensure that the temperatures within the enclosure do not exceed predetermined safe
operation ranges. If the temperature observed by a sensor falls below a
low-temperature threshold or rises above a high-temperature threshold, the
monitoring subsystem software lights the amber Service Required LEDs on the front
and back panels. If the temperature condition persists and reaches a critical
threshold, the system initiates a graceful system shutdown. In the event of a failure
of the service processor, backup sensors protect the system from serious damage, by
initiating a forced hardware shutdown. The Service Required LEDs remain lit after
an automatic system shutdown to aid in problem diagnosis.
The power subsystem is monitored in a similar fashion by monitoring power
supplies and reporting any fault in the front and rear panel LEDs.
Related Information
■ SPARC Enterprise T5120 and T5220 Servers Product Notes
■ SPARC Enterprise T5120 and T5220 Servers Administration Guide
■ Integrated Lights Out Manager (ILOM) software documentation
■ Integrated Lights Out Manager (ILOM) 3.0 Supplement for SPARC Enterprise T5120
and T5220 Servers
■ SPARC Enterprise T5120 and T5220 Servers Service Manual
14 SPARC Enterprise T5120 and T5220 Servers Overview Guide • July 2009
Support for RAID Storage Configurations
Using the on-board SAS controller, you can set up hardware RAID 1 (mirroring) and
hardware RAID 0 (striping) configurations for any pair of internal hard drives,
providing a high-performance solution for hard drive mirroring.
Additional RAID levels are supported by installing the StorageTek SAS HBA
(internal PCIe card). This option requires a different set of internal cables.
By attaching one or more external storage devices to the SPARC Enterprise T5120 and
T5220 servers, you can use a redundant array of independent drives (RAID) software
application such as Solstice DiskSuite or VERITAS Volume Manager
system drive storage in a variety of different RAID levels.
Related Information
■ SPARC Enterprise T5120 and T5220 Servers Product Notes
■ SPARC Enterprise T5120 and T5220 Servers Administration Guide
■ SPARC Enterprise T5120 and T5220 Servers Service Manual
■ Solaris OS
documentation (http://docs.sun.com/app/docs/prod/solaris)
■ Documentation for your hardware
1
to configure
Error Correction and Parity Checking
The UltraSPARC T2 multicore processor provides parity protection on its internal
cache memories, including tag parity and data parity on the D-cache and I-cache. The
internal L2 cache has parity protection on the tags, and ECC protection on the data.
Related Information
■ SPARC Enterprise T5120 and T5220 Servers Product Notes
■ SPARC Enterprise T5120 and T5220 Servers Administration Guide
■ SPARC Enterprise T5120 and T5220 Servers Service Manual
1. Software RAID applications such asVERITASVolumeManager arenot included with this server. You must
obtain andlicense them separately.
Understanding Server Features 15
Fault Management and Predictive Self Healing
The SPARC Enterprise T5120 and T5220 servers provide the latest fault management
technologies. The Solaris 10 OS architecture provides a means for building and
deploying systems and services capable of Predictive Self-Healing. Self-healing
technology enables systems to accurately predict component failures and mitigate
many serious problems before they actually occur. This technology is incorporated
into both the hardware and software of the SPARC Enterprise T5120 and T5220
servers.
At the heart of the Predictive Self-Healing capabilities is the Solaris Fault Manager, a
new service that receives data relating to hardware and software errors, and
automatically and silently diagnoses the underlying problem. Once a problem is
diagnosed, a set of agents automatically responds by logging the event, and if
necessary, takes the faulty component offline. By automatically diagnosing problems,
business-critical applications and essential system services can continue
uninterrupted in the event of software failures or major hardware component
failures.
Related Information
■ SPARC Enterprise T5120 and T5220 Servers Product Notes
■ SPARC Enterprise T5120 and T5220 Servers Administration Guide
■ SPARC Enterprise T5120 and T5220 Servers Service Manual
■ Solaris OS
documentation (http://docs.sun.com/app/docs/prod/solaris)
Rackmountable Enclosure
The SPARC Enterprise T5120 and T5220 servers use a space-saving 1U or 2U-high
rackmountable enclosure that can be installed into a variety of industry standard
racks.
Related Information
■ SPARC Enterprise T5120 and T5220 Servers Product Notes
■ SPARC Enterprise T5120 and T5220 Servers Getting Started Guide
■ SPARC Enterprise T5120 and T5220 Servers Getting Started Guide (DC)
■ SPARC Enterprise T5120 and T5220 Servers Site Planning Guide
■ SPARC Enterprise T5120 and T5220 Servers Installation Guide
■ SPARC Enterprise T5120 and T5220 Servers Service Manual
16 SPARC Enterprise T5120 and T5220 Servers Overview Guide • July 2009
■ SPARC Enterprise T5120 and T5220 Servers Safety and Compliance Guide
Understanding Server Features 17
18 SPARC Enterprise T5120 and T5220 Servers Overview Guide • July 2009
Loading...
