Fujitsu Stylistic Q552 User Guide

Fujitsu STYLISTIC

FUJITSU AMERICA, INC.

Q Series

BIOS Guide

STYLISTIC Q Series Model:

Q552

Document Date: 5/25/2012

Document Part Number: FPC58-3061-01

®

1

STYLISTIC Q552 BIOS

Q Series BIOS

BIOS SETUP UTILITY

The BIOS Setup Utility is a program that sets up the
operating environment for your tablet. Your BIOS
is set at the factory for normal operating conditions,
therefore there is no need to set or change the BIOS
environment to operate your tablet.

The BIOS Setup Utility configures:

• Device control feature parameters, such as

changing
I/O addresses and boot devices.

• System Data Security feature parameters, such as

passwords.

Entering the BIOS Setup Utility

To enter the BIOS Setup Utility, do the following:

1. Turn on or restart your tablet.

2. Press the [Alt] button when the Fujitsu logo
appears on the screen. This will open the Boot/
Application Menu window.

3. From the Application Menu tab, tap on “BIOS
Setup”; the BIOS Setup utility will open with the
current settings displayed.

3. Tap the setup menu names in the menu bar at the
top of the screen to review or alter the current
settings of the various screens.

Navigating through the Setup Utility

The BIOS setup utility consists of six menus: Info,
System, Advanced, Security, Boot, and Exit. This docu­ment explains each menu in turn, including all
submenus and setup items.

The following procedures allow you to navigate the
setup utility menus:

1. Single tapping on a menu item in the menu bar
(the 2nd line) selects the menu item.

2. Single tapping on a selection item in the setup
window (the left half rectangular area) opens a
selection list popup menu if the item already has
the focus (with reversed text), similar to pressing
the < Enter > key. If the item is not yet focused, a
single tap just moves the focus to the item.

3. Single tapping on an item in the selection list

popup menu selects the item if the item already
has the focus (with bright white text), similar to
pressing the <Enter> key. If the item is not yet
focused, single tap just moves the focus on the
item.

4. Single tap on a sub menu item in the setup
window selects the sub menu if the item already
has the focus (with brown text), like pressing the
<Enter> key. If the item is not yet focused, single
tap just moves the focus on the item.

5. On some character and numerical items (e.g.,
Time, Date, Password), software key pad is
available and appears in the item.

6. By single tapping on the <Shift> key, the following

two keyboards are toggled. Note that tap on keys
that can not be used as password/value is ignored
as with the real keyboard.

7. Single tap on the key name in the key help panel

(the bottom two-line area) performs the key’s func­tion.

8. Single tap on the title bar in sub menus ends the

sub menu, like pressing <Esc> key.

 Selecting a field causes a help message

about that field to be displayed on the
right-hand side of the screen.

 Tapping the [+] with the highlight on a

selection that is not a submenu or auto
selection will cause a list of all options for
that item to be displayed. Tapping the
item in the list will select the highlighted
choice. Tapping the [-] will close the list.

7. Tapping “Load Setup Defaults” from the Exit menu
resets all items in the BIOS to the default values.

8. Tapping “Exit Saving Changes” from the Exit menu
saves the current configuration and exits the BIOS
Setup Utility. You will be asked to verify this selec­tion before it is executed.

9. Tapping [F1] at the bottom of the screen gives you
a general help screen.

Entering the Setup Utility After a Configuration Change or System Failure

If there has been a change in the system configuration
that does not agree with the parameter settings stored
in your BIOS memory, or there is a failure in the

2

system, the system beeps and/or displays an error
message after the Power On Self Test (POST). If the
failure is not too severe, it will give you an opportunity
to modify the setup utility settings, as described in the
following steps:

1. When you turn on or restart the computer there is
a beep and/or the following message appears on
the screen:
Error message - please run SETUP program Press
<F1>/[Ctrl+Alt+Del] button to continue, or <F2>/
[Rotation] button to enter SETUP

2. If an error message is displayed on the screen, and
you want to continue with the boot process and
start the operating system anyway, press the [F1]
key or the [Ctrl+Alt+Del] button.

 If your tablet emits a series of beeps that

sounds like a code and the display is
blank, please refer to the Troubleshoot­ing Section in the system User’s Guide.
The Troubleshooting Section includes a
list of error messages and their meanings.

 If your data security settings require it,

you may be asked for a password before
the operating system will be opened.

Info Menu

3. If an error message is displayed on the screen, and
you want to enter the setup utility, press the [F2]
key or [Rotation] button.

5. The system will then display the Info Menu with
current parameters values.

3

STYLISTIC Q552 BIOS

Phoenix SecureCore(tm) Tiano Setup

F1 Help
ESC Exit

Select Item
Select Menu

-/Space Change Values
Enter Select ► Sub-Menu

F9 Setup Defaults
F10 Save and Exit

Info System Advanced Security Boot Exit

Product Name: STYLISTIC Q552
Configuration ID: XXXXXXXXXXXXXXXX
Serial Number: XXXXXXXX
BIOS Version: X.XX (XX/XX/2012)

Processor Type: Intel(R) Atom(TM) CPU M2600 @ 1.60GHz

Total Memory: 2048 MB
Onboard: 2048 MB DDR3 SDRAM

UUID: XXXXXXXX-XXXX-XXXX-XXXX-XXXXXXXXXXXX
Panel ID: XXXXXXXX

/

/

INFO MENU - DISPLAYS BASIC SYSTEM INFORMATION

The Info Menu is a display-only screen that provides
the configuration information for your tablet.

The following table shows the names of the menu
fields for the Info menu and the information displayed
in those fields. These fields are for information
purposes only, and cannot be modified by the user.

The information, including CPU type and
speed, and total memory, displayed on this
screen varies according to the unit you
purchased.

Figure 1. Info Menu

Table 1: Fields, Options and Defaults for the Info Menu

Menu Field Default Menu Field Default

Note that all of the fields on this screen are display only and are for reference.
Note that the parameters listed may be different for your system, depending upon the system configuration.

Product Name: STYLISTIC Q552 Total Memory: XXXX MB

Configuration Number: XXXXXXXXXXXXXXXX Onboard: XXXX MB DDR3 SDRAM

Serial Number: XXXXXXXX UUID: XXXXXXXX-XXXX-XXXX-

BIOS Version: X.X (XX/XX/20XX) Panel ID: XXXXXXXX

Processor Type: Intel(R) Atom(TM) CPU M2600

@ 1.60GHz

4

XXXXXXXXXXXX

Phoenix SecureCore(tm) Tiano Setup

F1 Help
ESC Exit

Select Item
Select Menu

-/Space Change Values
Enter Select ► Sub-Menu

F9 Setup Defaults
F10 Save and Exit

Info System Advanced Security Boot Exit

/

/

Item Specific Help

Adjust calendar clock.

<Tab>, <Shift-Tab>, or
<Enter> selects field.

System Time: [14:57:01]

System Date: [06/02/2012]

Drive Configurations

Language: [English (US)]

System Menu

SYSTEM MENU – SETTING STANDARD SYSTEM PARAMETERS

The System Menu allows you to set or view the current
system parameters. (See Navigating through the Setup

Utility on page 2 for more information.)

The following tables show the names of the menu
fields for the System menu and its submenus, all of
the options for each field, the default settings and a

description of the field’s function and any special
information needed to help understand the field’s use.

System Time and System Date can also be
set from your operating system without
using the setup utility. Use the Date and
Time icon on your Windows Control panel
or type time or date from the MS-DOS
prompt.

Table 2: Fields, Options and Defaults for the System Menu

Note that the parameters listed in the following table may vary depending upon your system’s configuration.

Menu Field Options Default Description

System Time: –— –— Sets and displays the current time. Time is in a 24 hour format

Figure 2. System Menu

of hours:minutes:seconds with 2 digits for each. (HH:MM:SS).
Example: 16:45:57. You may change each segment of the
time separately. Move between the segments with the [Tab]
key and/or [Shift] + [Tab] keys.

5

STYLISTIC Q552 BIOS

Table 2: Fields, Options and Defaults for the System Menu

Note that the parameters listed in the following table may vary depending upon your system’s configuration.

Menu Field Options Default Description

System Date: –— –— Sets and displays the current date. Date is in a month/day/

year numeric format with 2 digits each for month and day and
4 digits for year. (MM/DD/YYYY) for example: 02/20/2011. You
may change each segment of the date separately. Move
between the segments with the [Tab] key and/or [Shift] +
[Tab] keys.

Drive Configurations --- --- Opens the Drive Configurations submenu to allow you to

enable or disable the installed drives.

Language:

 English (US)
 Japanese (JP)

[English (US)] The default setting differs between the US/European and the

Japanese model. Selects the display language for the BIOS.

6

Drive Configurations Submenu of the System Menu

Phoenix SecureCore(tm) Tiano Setup

Item Specific Help

Configures SATA Drive.

Drive Configurations

Drive0: [TOSHIBA THNSFB062GMSF - 62GB ]

[Enabled]

System

F1 Help
ESC Exit

Select Item
Select Menu

-/+ Change Values
Enter Select ► Sub-Menu

Shift + 1 Enable or disable(!)
F10 Save and Exit

/

/

The Drive Configurations submenu identifies the installed S-ATA drive.

System Menu

Figure 3. Drive Configurations Submenu

Table 3: Fields, Options and Defaults for the Drive0 Submenu of the System Menu

Menu Field Options Default Description

Drive0:

Exiting from System Menu

---

[Enabled] Identifies the installed SATA drive.

When you have finished setting the parameters on this menu, you can either exit from the setup utility, or move to
another menu. If you wish to move to another menu, tap the desired menu name at the top of the screen.

7

STYLISTIC Q552 BIOS

Phoenix SecureCore(tm) Tiano Setup

Item Specific Help

Drive Configurations

Info System Advanced Security Boot Exit

Boot Configurations
Keyboard Features
Internal Device Configurations
CPU Features
USB Features
Miscellaneous Configurations

Configures Boot
features.










Event Logging

F1 Help
ESC Exit

Select Item
Select Menu

-/Space Change Values
Enter Select ► Sub-Menu

F9 Setup Defaults
F10 Save and Exit

/

/

ADVANCED MENU – SETTING DEVICE FEATURE CONTROLS

The Advanced Menu allows you to:

• Set Boot configurations

• Set the keyboard features.

• Enable or disable the Bluetooth, WLAN, WWAN,

front camera, rear camera, and SD card slot.

• Configure CPU and USB features in your system.

• Configure the volume setting.

(See Navigating through the Setup Utility on page 2 for
more information.)

The following tables show the names of the menu
fields for the Advanced Menu and its submenus, all of
the options for each field, the default settings and a
description of the field’s function and any special
information needed to help understand the field’s use.

Figure 4. Advanced Menu

Table 4: Fields, Options and Defaults for the Advanced Menu

Menu Field Description

Boot Configurations When selected, opens the Boot Configurations submenu, which allows enabling or disabling

Keyboard Features When selected, opens the Keyboard Features submenu, which allows setting NumLock param-

Internal Device
Configurations

CPU Features When selected, opens the CPU Features submenu to allow you to enable/disable SpeedStep(R)

8

various Boot features.

eters (On or Off).

When selected, opens the Internal Device Configuration submenu, which allows enabling or
disabling the Bluetooth, WLAN, WWAN, camera controllers, and SD card slot.

Techn olog y.

Advanced Menu

Table 4: Fields, Options and Defaults for the Advanced Menu

Menu Field Description

USB Features When selected, opens the USB Features submenu to allow you to enable or disable legacy USB

devices and SCSI SubClass support.

Miscellaneous Configura­tions

Event Logging When selected, opens the event logging submenu.

When selected, opens the Miscellaneous Configurations submenu to allow you to select
settings.

9

STYLISTIC Q552 BIOS

Phoenix SecureCore(tm) Tiano Setup

F1 Help
ESC Exit

Select Item
Select Menu

-/Space
Enter

F9 Setup Defaults
F10 Save and Exit

Change Values
Select Sub-Menu

Item Specific HelpBoot Configurations

Info System Advanced Security Boot Exit



[Disabled]
All diagnostic tests
will be done.

[Enabled]
Some diagnostic tests
may be skipped while
booting to speed up.

Quick Boot:
Boot Time Diagnostics Screen: [Disabled]

[Disabled]

Boot Configurations Submenu of the Advanced Menu

The Boot Configurations submenu is for setting a variety of Boot features.

Figure 5. Boot Configurations Submenu

Table 5: Fields, Options and Defaults for the Boot Configurations Submenu of the Advanced Menu

Menu Field Options Default Description

Quick Boot:

Boot Time
Diagnostic Screen:

10

 Disabled
 Enabled

 Disabled
 Enabled

[Disabled] When disabled, all of the diagnostic test will be performed during boot

up. If enabled, certain test may be skipped in order to speed up the
booting process.

[Disabled] When disabled, the logo screen is displayed during boot up. If enabled,

the diagnostic screen is displayed during the boot up.

Phoenix SecureCore(tm) Tiano Setup

Item Specific Help

Advanced

[On] or [Off]
Numlock is On or Off.

* Windows XP or later
OS preserves Numlock
state when the user
logs off.

Keyboard Features

Numlock:

[Off]

F1 Help
ESC Exit

Select Item
Select Menu

-/Space Change Values
Enter Select ► Sub-Menu

F9 Setup Defaults
F10 Save and Exit

/

/

Advanced Menu

Keyboard Features Submenu of the Advanced Menu

The Keyboard Features submenu is for setting the parameters of the integrated and external mouse and keyboard.

Figure 6. Keyboard Features Submenu

Table 6: Fields, Options and Defaults for the Keyboard Submenu of the Advanced Menu

Menu Field Options Default Description

Numlock:

 On
 Off

[Off] Sets the NumLock function state when the computer completes boot-

ing. When [On] or [Off], Numlock is on or off. Windows preserves Num­lock state when the user logs off.

11

STYLISTIC Q552 BIOS

Internal Device Configurations Submenu of the Advanced Menu

The Internal Device Configuration submenu allows the user to enable or disable ATA, Bluetooth, LAN, Wireless
LAN, Internal Camera, and SD Card slot controllers.

Phoenix SecureCore(tm) Tiano Setup

Advanced

Internal Device Configurations

Bluetooth(R): [Enabled]
Wireless LAN: [Enabled]
WWAN Device: [Enabled]
Front Camera: [Enabled]
Rear Camera: [Enabled]
SD Card Slot: [Enabled]

F1 Help
ESC Exit

/

Select Item
Select Menu

/

-/Space Change Values
Enter Select ► Sub-Menu

F9 Setup Defaults
F10 Save and Exit

Item Specific Help

[Disabled]
Bluetooth(R) is
disabled.

[Enabled]
Bluetooth(R) is
enabled.

Figure 7. Internal Device Configuration Submenu

Table 7: Fields, Options and Defaults for the Internal Device Configuration Submenu of the Advanced Menu

Menu Field Options Default Description

Bluetooth:

Wireless LAN:

WWAN Device:

Front Camera:

Rear Camera:

SD Card Slot:

 Disabled
 Enabled

 Disabled
 Enabled

 Disabled
 Enabled

 Disabled
 Enabled

 Disabled
 Enabled

 Disabled
 Enabled

[Enabled] Enables or disables the Bluetooth device.

[Enabled] Enables or disables the Wireless LAN controller.

[Enabled] Enables or disables the Wireless WAN controller.

[Enabled] Enables or disables the front camera.

[Enabled] Enables or disables the rear camera.

[Enabled] Enables or disables the SD card slot.

12

Phoenix SecureCore(tm) Tiano Setup

Item Specific Help

Advanced

Select Enhanced
Intel(R) SpeedStep(R)
Technology enabled or
disabled.

CPU Features

[Enabled]

SpeedStep(R) Technology:

F1 Help
ESC Exit

Select Item
Select Menu

-/Space Change Values
Enter Select ► Sub-Menu

F9 Setup Defaults
F10 Save and Exit

/

/

Advanced Menu

CPU Features Submenu of the Advanced Menu

The CPU Features submenu provides options for configuring the SpeedStep power management features of the
CPU.

Figure 8. CPU Features Submenu

Table 8: Fields, Options and Defaults for the CPU Features Submenu of the Advanced Menu

Menu Field Options Default Description

SpeedStep(R)
Technology:

 Disabled
 Enabled

[Enabled] If [Disabled], CPU speed is fixed to highest speed and

SpeedStep applet does not start.

13

STYLISTIC Q552 BIOS

Phoenix SecureCore(tm) Tiano Setup

Item Specific Help

Advanced

[Disabled]
The feature is disabled.

[Enabled]
Legacy USB Emulation
is enabled and USB
devices are available
without USB aware OS.

Legacy USB Support
SCSI SubClass Support: [Enabled]

[Enabled]

USB Features

F1 Help
ESC Exit

Select Item
Select Menu

-/Space Change Values
Enter Select ► Sub-Menu

F9 Setup Defaults
F10 Save and Exit

/

/

USB Features Submenu of the Advanced Menu

The USB Features submenu provides options for enabling or disabling the USB devices.

Figure 9. USB Features Submenu

Table 9: Fields, Options and Defaults for the USB Features Submenu of the Advanced Menu

Menu Field Options Default Description

Legacy USB Support:

SCSI SubClass Support:

14

 Disabled
 Enabled

[Enabled] When Enabled is selected, Legacy USB Emulation is enabled

 Disabled
 Enabled

[Enabled] When Enabled is selected, USB devices that belong to the SCSI

and the USB devices are available without a USB-aware OS.
When Disabled is selected, Legacy USB support is disabled and
SCSI SubClass Support is greyed out.

subclass in the mass storage class (e.g., USB Memory Key) are
enabled. Note that enabling this feature may cause the sys­tem to hang during POST, depending on the device that is con­nected.

Advanced Menu

Miscellaneous Configurations Submenu of the Advanced Menu

The Miscellaneous Configurations submenu provides options for enabling or setting the volume

Phoenix SecureCore(tm) Tiano Setup

Advanced

Miscellaneous Configurations

Auto Save to Disk:
Volume Setting: [Middle]
Hardware Power Management:
CPU Power Saving on idle
state (Battery): [Long Battery Life]

F1 Help
ESC Exit

/

Select Item
Select Menu

/

[On]

[Enabled]

-/Space Change Values
Enter Select ► Sub-Menu

F9 Setup Defaults
F10 Save and Exit

Item Specific Help

Turn on or off
the Auto Save to
Disk feature.
When Auto Save to
Disk is turned on,
at low battery
state the system
that is in suspend
mode will save
its state to disk
and then power
off.

Figure 10. Miscellaneous Configurations Submenu

Table 10: Fields, Options and Defaults for the Miscellaneous Configurations Submenu of Advanced Menu

Menu Field Options Default Description

Auto Save to Disk:

Volume Setting:  Off

Hardware Power
Management:

CPU Power Saving on
idle state (Battery)

 Off
 On

 Minimum
 Middle
 Maximum

 Disabled
 Enabled

 Long Battery Life
 Low Power
 Normal

[On] Enables and disables the Auto Save to Disk feature.

[Middle] Selects the initial volume setting for the system.

[Enabled] Enables and disables the Hardware Power Management

feature.

[Long Battery
Life]

Selects the CPU power saving mode while in idle state
under battery power.

15

STYLISTIC Q552 BIOS

Phoenix SecureCore(tm) Tiano Setup

Item Specific Help

Info System Advanced Security Boot Exit

Press <Enter> key to
view the contents of
the event log.

Event Logging

Event Log Capacity: Space Available
Event Log Validity: Valid

View Event Log: [Enter]

Event Logging: [Enabled]

Clear All Event Logs: [Enter]

Mark Events as Read: [Enter]

F1 Help
ESC Exit

Select Item
Select Menu

-/Space Change Values
Enter Select ► Sub-Menu

F9 Setup Defaults
F10 Save and Exit

/

/

Event Logging Submenu of the Advanced Menu

The Event Logging submenu configures event logging features for DMI events.

Figure 11. Event Logging Submenu

Table 11: Fields, Options and Defaults for the Event Logging Submenu of the Advanced Menu

Menu Field Options Default Description

Event Log Capacity: --- Display only

Event Log Validity: --- Display only

View Event Log:

Event Logging:

Clear All Event Logs:

Mark Events as
Read:

16

 Enter

 Disabled
 Enabled

 Enter

[Enter] Allows you to view content of event log

[Enabled] Turns event logging on and off for all DMI events.

[Enter] After clicking [Enter], a Setup Notice appears prompting you to select

[Yes] or [No] to confirm. When set to [Yes] all event logs will be
cleared at next boot.

 Enter

[Enter] After clicking [Enter], a Setup Notice appears prompting you to select

[Yes] or [No] to confirm. When set to [Yes] all event in the events log
will be marked as having been read.

Phoenix SecureCore(tm) Tiano Setup

Item Specific Help

Info System Advanced Security Boot Exit

Press <Enter> key to
set Supervisor Password
to enable any password
features.

Then password entry is
required to enter BIOS
Setup.

Supervisor Password Is: Clear
User Password Is: Clear

Set Supervisor Password [Enter]
Set User Password [Enter]
Minimum User Password Length: [0]
Password on Boot: [Disabled]
Boot from Removable Media: [All]
Flash Write: [Enabled]
Boot Menu: [Enabled]
Hard Disk Security
Owner Information
TPM (Security Chip) Setting







F1 Help
ESC Exit

Select Item
Select Menu

-/Space Change Values
Enter Select ► Sub-Menu

F9 Setup Defaults
F10 Save and Exit

/

/

Security Menu

SECURITY MENU – SETTING THE SECURITY FEATURES

The Security menu allows you to set up the security features of your tablet to fit operating needs and to view the
current data security configuration. (See Navigating through the Setup Utility on page 2 for more information.)

The following tables show the names of the menu fields for the Security Menu and its submenus, all the options
for each field, the default settings and a description of the field's function and any special information needed to
help understand the field's use. The default condition is no passwords required and no write protection.

 Remember your passwords! If you set and forget your User and Master hard disk passwords, Fujitsu

America will not be able to reset it. You may lose data and have to replace your system board or hard disk
drive.

 WARNING. VERY IMPORTANT if your hard disk drive is protected using a Full Disk Encryption (FDE)

"engine". FDE encrypts all data as it is written to the hard drive. When data is retrieved from the hard
drive, it is decrypted by the same engine. If you forget your hard disk security password on a system with

FDE, all data and applications on the hard drive will remain encrypted and will effectively be lost. Be

sure to remember your hard disk password.

 Entering a password incorrectly 3 times in a row causes the keyboard and mouse to be locked out and

[System Disabled] to be displayed. If this occurs, restart the computer by turning off and on the power
with the power switch and use the correct password on reboot.

 If you make an error when re-entering the password a Warning will be displayed. To try again press

[Enter], then retype the password, or press [Esc] to abort the password process.

 If the Security Panel on Resume is Enabled and the Password on Boot is Disabled you will not have to

type your password upon resuming the system from the Suspend or Save-to-Disk modes. Power Man­agement Security will work only if Password boot is enabled.

Figure 12. Security Menu

17

STYLISTIC Q552 BIOS

Table 12: Fields, Options and Defaults for the Security Menu

Menu Field Options Default Description

Supervisor
Password is:

User Password is: –— Clear A display-only field. Set is displayed when the general user

Set Supervisor
Password

Set User Password –— [Enter] This field can only be accessed if the Supervisor Password is set. Sets,

Minimum User
Password Length:

Password on Boot:

Boot from
Removable Media:

Flash Write:

Boot Menu:

Hard Disk Security: –— –— Configures hard disk security features

Owner
Information:

TPM (Security
Chip) Setting

–— Clear A display-only field. Set is displayed when the system supervisor pass-

word is set and Clear when it is not.

password is set, and Clear when it is not.

–— [Enter] Sets, changes or cancels the Supervisor Password. A Supervisor Pass-

word may be up to seven characters long and must include only letters
or numbers (no symbols). Passwords are NOT case-sensitive. To cancel
a password press the Enter key instead of entering characters in the
Enter New Password field and in the Re-enter New Password field.
When a Supervisor Password is set it must be used to access BIOS setup
utility.

changes or cancels the User Password. A User Password may be up to
seven characters long and must include only letters or numbers (no
symbols). Passwords are NOT case-sensitive. To cancel a password press
[Enter] key instead of entering characters in the Enter New Password
field and in the Re-enter New Password field. When a User Password is
set it must be used to access the BIOS setup utility.

–— [0] Supervisor can set password length (0 to 32) for user password. User

cannot set a password shorter than the minimum length.

 Disabled

 First Boot

 Every Boot

[Disabled] When set to First Boot, a password (User or Supervisor) is required just

once after the Power On Self Test (POST) before the operating system
will be read from a disk. When set to Every Boot, a password (User or
Supervisor) is required every time after the Power On Self Test (POST)
before the operating system will be read from a disk. When set to Dis­abled no password is required.

 All

 Supervisor only

 Disabled

 Enabled

 Disabled

 Enabled

[All] Supervisor only allows access to boot the computer to removable media

after the Supervisor Password is entered.

[Enabled] When disabled, the BIOS Flash memory will be write protected.

[Enabled] When disabled, the Boot Menu is disabled and cannot be opened using

the [F12] key.

–— –— Sets Owner information.

___ ___ Sets the TPM (Security Chip) settings

Exiting from the Security Menu

When you have finished setting the parameters on the Security Menu, you can either exit from setup utility or
move to another menu. If you wish to exit from setup utility, press the [Esc] key to go to the Exit Menu. If you wish
to move to another menu, use the cursor keys.

18

Hard Disk Security Submenu of the Security Menu

Phoenix SecureCore(tm) Tiano Setup

Item Specific Help

Security

Configure hard disk

Hard Disk Security

Drive0: Clear
Set Master Password [Enter]
Set User Password [Enter]

Password Entry on Boot: [Enabled]

security feature.

F1 Help
ESC Exit

Select Item
Select Menu

-/Space Change Values
Enter Select ► Sub-Menu

F9 Setup Defaults
F10 Save and Exit

/

/

The Hard Disk Security submenu is for configuring hard disk security features.

Security Menu

Figure 13. Hard Disk Security Submenu

Table 13: Fields, Options and Defaults for the Hard Disk Security Submenu of the Security Menu

Menu Field Options Default Description

Drive0:

Set Master
Password

Set User Password

Password Entry on
Boot:

___

___

----

 Disabled
 Enabled

Clear Display-only. Default is Clear. When the Drive0 Password has been set,

the field changes to Set. When this password is set, the primary hard disk
drive cannot be used in another system unless the password is entered.

[Enter] Sets, changes or cancels the Master Password. The Master Password may

be up to seven characters long and must include only letters or numbers
(no symbols). Passwords are NOT case-sensitive. When a Master Password
is set, the hard disk is locked with the password. Data in the locked disk

cannot be read on other systems.

[Enter] Sets, changes or cancels the User Password. The User Password may be up

to seven characters long and must include only letters or numbers (no
symbols). Passwords are NOT case-sensitive. When a User Password is set,
the hard disk is locked with the password. Data in the locked disk cannot

be read on other systems.

[Enabled] When set to disabled, entry of a Hard Disk Password is not required before

OS boot. (The hard disk is still password-protected without password
entry.)

19

STYLISTIC Q552 BIOS

Phoenix SecureCore(tm) Tiano Setup

Item Specific Help

Info System Advanced Security Boot Exit

Owner Information

Owner Information Is: Clear

Set Owner Information [Enter]

Foreground Color: [Gray]
Background Color: [Black]

Set owner information.

F1 Help
ESC Exit

Select Item
Select Menu

-/Space Change Values
Enter Select ► Sub-Menu

F9 Setup Defaults
F10 Save and Exit

/

/

Owner Information Submenu of the Security Menu

The Owner Information submenu is for setting owner information. Note that the owner information cannot be set
without having entered a Supervisor Password.

Figure 14. Owner Information Submenu

Table 14: Fields, Options and Defaults for the Owner Information Submenu of the Security Menu

Menu Field Options Default Description

Owner Information
Is:

Set Owner
Information:

Foreground Color:

Background Color:

20

–— Clear Display only.

–— [Enter] Field to write owner informa-

tion, (i.e., name).

 Black
 Blue
 Green
 Cyan
 Red
 Magenta

 Black
 Blue
 Green
 Cyan
 Red
 Magenta

 Brown
 White
 Gray
 Light Blue
 Light Green

 Brown
 White
 Gray
 Light Blue
 Light Green

 Light Cyan
 Light Red
 Light

Magenta

 Yel low
 Bright White

 Light Cyan
 Light Red
 Light

Magenta

 Yel low
 Bright White

[Gray] Set foreground color.

[Black] Set background color.

Security Menu

TPM (Security Chip) Setting Submenu of the Security Menu

The Trusted Platform Module (TPM) Security Chip Setting submenu is used to enable or disabled the embedded
security chip.

Phoenix SecureCore(tm) Tiano Setup

Security

TPM (Security Chip) Setting

Security Chip: [Enabled]

Item Specific Help

Configure Security Chip.

Current TPM State: Disabled and Deactivated
Change TPM State: [No Change]
Clear Security Chip: [Enter]

F1 Help
ESC Exit

/

Select Item
Select Menu

/

-/Space Change Values
Enter Select ► Sub-Menu

F9 Setup Defaults
F10 Save and Exit

Figure 15. TPM (Security Chip) Setting Submenu

Table 15: Fields, Options and Defaults for the TPM (Security Chip) Setting Submenu of the Security Menu

Menu Field Options Default Description

Security Chip:

 Disabled
 Enabled

[Enabled] Allows you to enable or disable the Trusted Platform Module

(TPM) chip. Note that this is only active if a Supervisor Password
has been entered. A reboot is required after exit to configure the
Security Chip correctly. Clear Security Chip option becomes select­able after reboot.

Current TPM State: –— Disabled and

Deactivated

Change TPM State:

 No Change
 Disable and

[No Change] Allows you to enable or disable the TPM chip when the Supervisor

Deactivate

Clear Security Chip:

 Enter [Enter] Allows you to clear the Security Chip. Note that this does not

Indicates the current state of the TPM chip.

Password has been set.

allow you to access already-encrypted data.

21

STYLISTIC Q552 BIOS

BOOT MENU – SELECTING THE OPERATING SYSTEM SOURCE

The Boot Menu is used to select the order in which the
BIOS searches sources for the operating system. (See

Navigating through the Setup Utility on page 2 for mor e
information.)

 Be careful of the operating environment when booting from a CD or you may overwrite files by mistake.

 A bootable CD-ROM has either a floppy disk format or a hard drive format. When the CD-ROM is used, drive

allocations change automatically without changing the BIOS setup. If a floppy disk format is used, the CD­ROM becomes Drive A. The CD-ROM will only take drive C: (hard drive format) if the internal hard drive is not
present or disabled. The bootable CD-ROM can never use a C: designation if a formatted internal hard drive is
present since the C: designator is always reserved for the hard drive.The boot sequence ignores the new drive
designations, but your application software will use the new designations.

Info System Advanced Security Boot Exit

Boot Priority Order:

1: Floppy Disk Drive
2: Drive0 HDD:
3: NETWORK:
4: USB HDD:
5: USB CD/DVD:

Phoenix SecureCore(tm) Tiano Setup

The following table shows devices associated with
your tablet and the order in which they will be
searched for the boot device

Item Specific Help

Configures order of
Boot Device.

Keys used to view or
configure devices.

‘' and '': Select a
device:
’+’ and ‘-’: Move the
device up or down.
‘Shift + 1’: Enables or
disables(!) a device.

.

F1 Help
ESC Exit

/

Select Item
Select Menu

/

-/Space Change Values
Enter Select ► Sub-Menu

F9 Setup Defaults
F10 Save and Exit

Figure 16. Boot Device Priority Submenu

Table 16: Fields, Options and Defaults for the Boot Device Priority Submenu of the Boot Menu

Menu Field Description

Boot priority order:
1: Floppy Disk Drive
2: Drive0:

3. NETWORK
4: USB HDD:
5: USB CD/DVD:

22

The boot selections determine the order that the BIOS searches for the operating system during the
startup sequence. To change the order, highlight one source by using the [up] or [down] cursor keys
and then press the [+] or [-] key to change the order number. Tapping [x] removes from the list a
device that is not installed. Tapping [x] on an item in the Excluded list adds the device to the Boot
priority list. Be sure to save the changed order when you exit the BIOS utility by either going to the
Exit Menu and choosing Exit Saving Changes, or pressing F10 and choosing Yes to Save and Exit.
NOTE: Be aware that if you use the CD-ROM drive as the first boot device, certain files may be over­written, depending upon your operating environment.

Boot Menu

Exiting from Boot Menu

When you have finished setting the boot parameters with the Boot Menu, you can either exit from the setup utility
or move to another menu. If you wish to exit from the setup utility press the [Esc] key to go to the Exit Menu. If you
wish to move to another menu, use the cursor keys.

23

STYLISTIC Q552 BIOS

EXIT MENU – LEAVING THE SETUP UTILITY

The Exit Menu is used to leave the setup utility. Follow
the instructions for Navigating Through the Setup
Utility to make any changes. (See Naviga ting through

the Setup Utility on page 2 for more information.)

Phoenix SecureCore(tm) Tiano Setup

Info System Advanced Security Boot Exit

Exit Saving Changes
Exit Discarding Changes
Load Setup Defaults
Discard Changes
Save Changes
Save Changes and Power Off

F1 Help
ESC Exit

/

Select Item
Select Menu

/

-/+ Change Values
Enter Select ► Sub-Menu

Figure 17. Exit Menu

The following table shows the names of the menu
fields for the Exit menu, the default settings and a
description of the field's function and any special
information needed to help understand the field's use.

Item Specific Help

Exit System Setup and
save your changes to
NVRAM.

Shift + 1 Enable or disable(!)
F10 Save and Exit

Table 17: Fields, Options and Defaults for the Exit Menu

Menu Field Description

Exit Saving
Changes

Exit Discard­ing Changes

Load Setup
Defaults

Discard
Changes

24

Exit Saving Changes and Exit will store all the entries on every menu of the setup utility to the BIOS memory,
then exit the utility. A confirmation message Save Configuration changes and exit now?
[Yes][No] is displayed.

Selecting Exit Discarding Changes and Exit will exit the setup utility without writing to the BIOS memory.
When the BIOS recognizes this selection it will reboot, load the operating system and begin operation.

Selecting Load Setup Defaults will load the factory preset default values for all menu fields, then display the
message Load default configuration now? [Yes] [No]. When confirmed the setup utility
will return to the Exit Menu. To return to another menu follow the directions in the Navigating Through the
Setup Utility Section.

Selecting Discard Changes will load the previous values in BIOS memory for all menu fields. The message

Load
previous configuration now? [Yes] [No] will be displayed. When confirmed the setup utility

will return to the Exit menu. To return to another menu, follow the directions in the Navigating Through the
Setup Utility Section.

Boot Menu

Table 17: Fields, Options and Defaults for the Exit Menu

Menu Field Description

Save Changes Selecting Save Changes will cause the new settings in all menus to be written to the BIOS memory. The mes-

sage Save configuration changes now? [Yes] [No] will be displayed. When confirmed, the
setup utility will return to the Exit menu. To return to another menu, follow the directions in the Navigating
Through the Setup Utility section.

Save Changes
and Power Off

Selecting Save Changes and Power Off will cause the new settings in all menus to be written to the BIOS
memory. The message Save configuration changes and power off now? [Yes] [No]
will be displayed. When confirmed, the system will shut down. If No is selected, the system will return to the
Exit menu. To return to another menu, follow the directions in the Navigating Through the Setup Utility sec­tion.

25
