Fujitsu Stylistic
FUJITSU COMPUTER SYSTEMS CORPORATION
ST6000 Series
BIOS Guide
Stylistic Series Model:
ST6012
Document Date: 12/01/2008
Document Part Number: FPC65-4369-01
1
Stylistic ST Series BIOS
ST Series BIOS
BIOS SETUP UTILITY
The BIOS Setup Utility is a program that sets up the
operating environment for your Tablet PC. Your BIOS
is set at the factory for normal operating conditions,
corner of the display), or press [F2] on an external
keyboard to launch BIOS Setup.
The system starts the BIOS Setup Utility and the BIOS
Setup Info menu is displayed.
Options and settings for menus in BIOS Setup are
described in tables appearing later in this chapter.
therefore there is no need to set or change the BIOS
environment to operate your Tablet PC.
The BIOS Setup Utility configures:
■
Device control feature parameters, such as changing
I/O addresses and boot devices.
■
System Data Security feature parameters, such
as passwords.
Entering the BIOS Setup Utility
To start BIOS Setup, restart your system and when the
message “Tap, Click, or Enter for System Utilities” is
displayed in the status bar at the bottom of the screen,
tap anywhere on the screen with your tablet pen. Select
“BIOS Setup” from the pop-up menu that appears. You
can also press the [Alt] button (the button closest to the
If you want to... Do one of these...
Select a BIOS Setup menu
from the menu bar
Select a BIOS option To highlight an option in the list of items for a given menu, do one of the following:
Change the setting of a
selected BIOS option
Access a pop-up menu with
a list all possible settings for
a given BIOS option
To move left and right to highlight the menu and display a list of menu options, do one of
the following:
• Press either side of the lower navigation button (the one that is farthest from the
application buttons)
• Tap on the menu name in the menu bar
• Tap on the right or left side of the Select Menu field in the command bar
• Use the right or left arrow keys on an external keyboard
• Press either side of the upper navigation button (the one that is closest to the
application buttons)
• Tap on the setting field for the option
• Tap on the right or left side of the Select Item field in the Command Bar
• Use the up and down arrow keys on an external keyboard
To cycle through the list of possible settings, do one of the following:
• Tap directly on the setting field
• Tap on the highlighted commands to the right or left of Change Values in the
command bar
• Use the -, +, and space keys on an external keyboard
• Press the Display Orientation button (third button from the right)
Tap on the [option], then press the [Ent] application button. Tap on the setting of your
choice to select it. You can also hold the pen barrel button while tapping to bring up the
pop-up menu.
Navigating through the Setup Utility
Instructions for selecting and changing BIOS options
and navigating BIOS Setup menus appear in the table
below.
Exiting BIOS Setup
Once you have finished making changes in BIOS Setup,
you must exit BIOS Setup and allow the system to boot
to apply your configuration changes. You can exit BIOS
Setup by selecting options in the Exit menu. The Exit
menu includes options that allow you to load default
BIOS settings, load previous settings, discard your
changes, save your changes, and exit BIOS Setup. For
details on Exit menu options, see “Exit Menu – Leaving
the Setup Utility” on page 27.
2
If you want to... Do one of these...
Select and enter a submenu To select and enter a submenu, do one of the following:
• Tap on the submenu name, then tap again to activate it.
• Select the submenu using the up and down arrow keys on an external keyboard and
press Enter, or press the [Ent] application button.
View Item-Specific Help for
a BIOS option
View General Help for
BIOS Setup
Select the option. Item-specific help is displayed in the Item Specific Help panel on the
right-hand side of the screen.
Tap on Help in the command bar or press F1 on your external keyboard. The BIOS Setup
help screen is displayed giving general instructions for using BIOS Setup
Exit BIOS Setup To exit the BIOS Setup Utility, do one of the following:
• Choose the appropriate option from the Exit menu
• Tap Save and Exit in the command bar
• Press F10 on an external keyboard.
Load factory default
settings for all BIOS options
To load the factory BIOS default settings, do one of the following:
• Press F9 on an external keyboard
• Select Setup Defaults from the command bar
• Select Load Setup Defaults from the Exit menu
Figure 1. Navigating the BIOS Setup
Info Menu
3
Stylistic ST Series BIOS
Phoenix SecureCore(tm) Setup Utility
F1 Help
ESC Exit
Select Item
Select Menu
-/Space Change Values
Enter Select Sub-Menu
F9 Setup Defaults
F10 Save and Exit
Info System Advanced Security Boot Exit
Product Name: Stylistic ST6012
Serial Number: XXXXXXXX
BIOS Version: 1.0X (XX/XX/2008)
Processor Type: Intel(R) Core(TM)2 Duo CPU U9400 @ 1.40GHz
L2 Cache: 3072 KB
Total Memory: 1024 MB
Memory Slot 1: 1024 MB DDR3 SDRAM
Memory Slot 2: None
Onboard MAC Address: 00-XX-XX-XX-XX-XX
UUID: 00000000-0000-0000-0000-XXXXXXXXXXXX
Panel ID: XXXXXXXXX
▲
INFO MENU - DISPLAYS BASIC SYSTEM INFORMATION
The Info Menu is a display only screen that provides the
configuration information for your Tablet PC.
those fields. These fields are for information purposes
only, and cannot be modified by the user.
The following table shows the names of the menu fields
for the Info menu and the information displayed in
The information, including CPU type and
speed, and total memory, displayed on this
screen varies according to the unit you
purchased.
Table 2: Fields, Options and Defaults for the Info Menu
Menu Field Default Menu Field Default
Note that all of the fields on this screen are display only and are for reference.
Note that the parameters listed may be different for your system, depending upon the system configuration.
Product Name: Stylistic ST6012 Memory Slot 1: 1024 MB DDR3 SDRAM
Serial Number: XXXXXXXX Memory Slot 2: None
BIOS Version: 1.0 (XX/XX/2008) Onboard MAC Address: XX-XX-XX-XX-XX-XX
Processor Type: Intel(R) Core(TM)2 Duo CPU U9400 @
L2 Cache: 3072 KB Panel ID: XXXXXXXXX
Total Memory: 1024 MB
4
1.4GHz
Figure 2. Info Menu
UUID: 00000000-0000-0000-0000....
Phoenix SecureCore(tm) Setup Utility
F1 Help
ESC Exit
Select Item
Select Menu
-/Space Change Values
Enter Select Sub-Menu
F9 Setup Defaults
F10 Save and Exit
▲
Info System Advanced Security Boot Exit
Item Specific Help
Adjust calendar clock.
<Tab>, <Shift-Tab>, or
<Enter> selects field.
▲
System Time: [14:57:01]
System Date: [12/02/2008]
Drive0 [FUJITSU MHZ2080BH G2]
Language: [English (US)]
System Menu
SYSTEM MENU – SETTING STANDARD SYSTEM PARAMETERS
The System Menu allows you to set or view the current
system parameters. (See Options and settings for menus in
BIOS Setup are described in tables appearing later in this
chapter. on page 2 for more information.)
The following tables show the names of the menu fields
for the System menu and its submenus, all of the options
for each field, the default settings and a description of
the field’s function and any special information needed
to help understand the field’s use.
System Time and System Date can also be
set from your operating system without
using the setup utility. Use the Date and
Time icon on your Windows Control panel
or type time or date from the MS-DOS
prompt.
Table 3: Fields, Options and Defaults for the System Menu
Note that the parameters listed in the following table may vary depending upon your system’s configuration.
Menu Field Options Default Description
System Time: –— –— Sets and displays the current time. Time is in a 24 hour format
System Date: –— –— Sets and displays the current date. Date is in a month/day/year numeric
Figure 3. System Menu
of hours:minutes:seconds with 2 digits for each. (HH:MM:SS). Example:
16:45:57. You may change each segment of the time separately. Move
between the segments with the [Tab] key and/or [Shift] + [Tab] keys.
format with 2 digits each for month and day and 4 digits for year. (MM/
DD/YYYY) for example: 03/20/2007. You may change each segment of
the date separately. Move between the segments with the [Tab] key and/
or [Shift] + [Tab] keys.
5
Stylistic ST Series BIOS
Table 3: Fields, Options and Defaults for the System Menu
Note that the parameters listed in the following table may vary depending upon your system’s configuration.
Menu Field Options Default Description
Drive0 Selects the Drive0
Serial ATA drive
submenu
■
Language:
English (US)
■
Japanese (JP)
The product
number of the
hard drive.
Display the type of device on this ATA/IDE interface. Pressing the Enter
key selects the Serial ATA Drive0 submenu allowing additional device
configuration options for this interface.
[English (US)] The default setting differs between the US/European and the Japanese
model. Selects the display language for the BIOS.
6
Drive0 Submenu of the System Menu
Phoenix SecureCore(tm) Setup Utility
F1 Help
ESC Exit
Select Item
Select Menu
-/Space
Enter
F9 Setup Defaults
F10 Save and Exit
Change Values
Select Sub-Menu
Item Specific Help
[Disabled]
The drive is disabled.
[Enabled]
The drive is enabled.
Drive0 [FUJITSU MHY2080BH]
Drive0: [Enabled]]
Type: Hard Disk
Model: FUJITSU MHZ2080BH
Capacity: 80GB
(80,026,361,856 Bytes)
▲
Info System Advanced Security Boot Exit
The Drive0 submenu identifies what ATA devices are installed.
System Menu
Figure 4. Drive0 Master Submenu
Table 4: Fields, Options and Defaults for the Drive0 Submenu of the System Menu
Menu Field Options Default Description
Drive0:
Typ e:
Models:
Capacity:
Exiting from System Menu
When you have finished setting the parameters on this menu, you can either exit from the setup utility, or move to
■
Disabled
■
Enabled
---
---
---
[Enabled] Allows you to enable or disable the hard disk drive.
--- The type of drive identified as Drive0.
--- The model of your hard disk
--- The maximum capacity of your hard disk
another menu. If you wish to exit from the setup utility, press the [Esc] key or use the cursor keys to go to the Exit
menu. If you wish to move to another menu, use the cursor keys.
7
Stylistic ST Series BIOS
ADVANCED MENU – SETTING DEVICE FEATURE CONTROLS
The Advanced Menu allows you to:
■
Set the keyboard and mouse features.
■
Select between the display panel and an external
display.
■
Enable or disable the ATA, Bluetooth, LAN, Wireless
LAN and IEEE1394 controllers.
■
Configure CPU and USB features in your system.
Phoenix SecureCore(tm) Setup Utility
Info System Advanced Security Boot Exit
▲ ▲ ▲ ▲ ▲
IrDA Port Configurations
Keyboard Features
Video Features
Internal Device Configurations
CPU Features
▲ ▲ ▲ ▲
USB Features
Miscellaneous Configurations
Intel(R) Active Management Technology
Event Logging
(See Options and settings for menus in BIOS Setup are
described in tables appearing later in this chapter. on page
2 for more information.)
The following tables show the names of the menu fields
for the Advanced Menu and its submenus, all of the
options for each field, the default settings and a description of the field’s function and any special information
needed to help understand the field’s use.
Item Specific Help
Configures keyboard/
mouse features.
F1 Help
ESC Exit
Select Item
Select Menu
-/Space
Enter
Figure 5. Advanced Menu
Change Values
▲
Select Sub-Menu
F9 Setup Defaults
F10 Save and Exit
Table 5: Fields, Options and Defaults for the Advanced Menu
Menu Field Description
IrDA Port Configurations: When selected, opens the IrDA Port Configurations submenu, which allows setting the IrDA
Keyboard Features When selected, opens the Keyboard Features submenu, which allows turning NumLock on and off.
Video Features When selected, opens the Video Features submenu, which allows setting of the display parameters,
Internal Device Configurations When selected, opens the Internal Device Configuration submenu, which allows enabling or dis-
8
features.
including routing of video signals to different displays.
abling the ATA, IDE, Bluetooth, Modem, LAN, and WLAN Controllers.
Table 5: Fields, Options and Defaults for the Advanced Menu
Menu Field Description
Advanced Menu
CPU Features When selected, opens the CPU Features submenu to allow you to change the CPU speed for bat-
USB Features When selected, opens the USB Features submenu to allow you to enable or disable legacy USB
Miscellaneous Configurations When selected, opens the Miscellaneous Configurations submenu to allow you to enable or disable
Intel(R) Active Management
Technology
Event Logging When selected, opens the event logging submenu.
tery life optimization.
devices and SCSI SubClass support.
the power button, Wake Up On LAN, and control volume settings.
When selected, opens the Intel Active Management Technology submenu to allow you to enable or
disable Intel Active Management Technology features.
9
IrDA Port Configurations Submenu of the Advanced Menu
The IrDA Port Configurations submenu is for setting the parameters of the infrared port.
Phoenix SecureCore(tm) Setup Utility
Info System Advanced Security Boot Exit
IrDA Port Configurations
Infrared Port:
Mode:
I/O Address:
Interrupt:
DMA Channel:
[Enabled]
[FIR]
[2E8 - 2EF]
[IRQ 6]
[DMA 3]
Item Specific Help
[Disabled]
The port is disabled.
[Enabled]
The port is enabled
with user configuration.
[Auto]
Plug & Play OS
configure the port.
F1 Help
ESC Exit
Select Item
Select Menu
-/Space
Enter
Change Values
Select Sub-Menu
Figure 1. IrDA Port Configurations Submenu
▲
F9 Setup Defaults
F10 Save and Exit
Table 1: Fields, Options and Defaults for the IrDA Port Configurations Submenu of the Advanced Menu
Menu Field Options Default Description
Infrared Port:
Mode:
I/O Address:
Interrupt:
DMA Channel:
■
Disabled
■
Enabled
■
Auto
■
IrDA
■
FIR
■
3F8 - 3FF
■
2F8- 2FF
■
3E8 - 3EF
■
2E8 - 2EF
■
IRQ 3
■
IRQ 6
■
IRQ 10
■
IRQ 11
■
DMA 1
■
DMA 3
[Enabled] Configures the infrared port using either no configuration (Disabled), a
user defined configuration (Enabled), or by allowing the BIOS or OS to
choose the configuration (Auto).
[FIR] When the infrared port is enabled this option is available allowing the
user to set the mode for the infrared port.
[2E8 - 2EF] Allows user to set the infrared port I/O address when the infrared port is
Enabled.
[IRQ 6] Allows user to set the interrupt number when the infrared port is
Enabled.
[DMA 3] Allows user to set the infrared port DMA Channel when the infrared
port is Enabled.
10
Keyboard Features Submenu of the Advanced Menu
F1 Help
ESC Exit
Select Item
Select Menu
-/Space
Enter
F9 Setup Defaults
F10 Save and Exit
Change Values
Select Sub-Menu
▲
Item Specific Help
[On] or [Off]
Numlock is On or Off.
* Windows XP or later
OS preserves Numlock
state when the user
logs off.
Keyboard Features
Numlock: [Off]
Phoenix SecureCore(tm) Setup Utility
Info System Advanced Security Boot Exit
The Keyboard Features submenu is for setting the numlock feature on and off.
Advanced Menu
Figure 6. Keyboard Features Submenu
Table 6: Fields, Options and Defaults for the Keyboard Submenu of the Advanced Menu
Menu Field Options Default Description
■
Numlock:
On
■
Off
[Off] Sets the NumLock function state when the computer completes boot-
ing. When [On] or [Off], Numlock is on or off.
Windows XP (or later OS) preserves Numlock state when the user logs
off.
11
Stylistic ST Series BIOS
Video Features Submenu of the Advanced Menu
The Video Features submenu is for setting the display parameters.
Phoenix SecureCore(tm) Setup Utility
Info System Advanced Security Boot Exit
Video Features
Display: [Auto]
Item Specific Help
Select display terminal.
* This setting is not
effective after
operating system
starts up.
F1 Help
ESC Exit
Select Item
Select Menu
Figure 7. Video Features Submenu
-/Space
Enter
Change Values
▲
Select Sub-Menu
F9 Setup Defaults
F10 Save and Exit
Table 7: Fields, Options and Defaults for the Video Features Submenu of the Advanced Menu
Menu Field Options Default Description
Display:
■
Internal Flat Panel
■
External
■
Auto
[Auto] Selects where the video signal will be routed. Note that this setting is
overridden after Windows starts up.
12
Advanced Menu
Internal Device Configurations Submenu of the Advanced Menu
The Internal Device Configuration submenu allows the user to enable or disable IDE, Bluetooth, LAN, Wireless LAN,
and IEEE 1394 Controllers.
Phoenix SecureCore(tm) Setup Utility
Info System Advanced Security Boot Exit
Internal Device Configurations
Serial ATA Controller: [Enabled]
AHCI Configuration: [Enabled]
Intel(R) Turbo Memory: [Enabled]
Bluetooth(R): [Enabled]
LAN Controller: [Enabled]
Wireless LAN: [Enabled]
Internal Camera: [Enabled]
F1 Help
ESC Exit
Select Item
Select Menu
-/Space
Enter
Change Values
Select Sub-Menu
▲
Item Specific Help
[Disabled]
Serial ATA port is
disabled.
[Enabled]
Serial ATA port is
enabled.
F9 Setup Defaults
F10 Save and Exit
Figure 8. Internal Device Configuration Submenu
Table 8: Fields, Options and Defaults for the Internal Device Configuration Submenu of the Advanced Menu
Menu Field Options Default Description
Serial ATA Controller:
AHCI Configuration:
Intel(R) Turbo Memory:
Bluetooth(R):
LAN Controller:
Wireless LAN:
Internal Camera:
■
Disabled
■
Enabled
■
Disabled
■
Enabled
■
Disabled
■
Enabled
■
Disabled
■
Enabled
■
Disabled
■
Enabled
■
Disabled
■
Enabled
■
Disabled
■
Enabled
[Enabled] Enables or disables the Serial ATA port.
[Enabled] Enables or disables the selected Advanced Host Controller Interface
(AHCI).
[Enabled] Enables or disables the Intel(R) Turbo Memory feature.
[Enabled] Enables or disables the Bluetooth device.
[Enabled] Enables or disables the LAN controller.
[Enabled] Enables or disables the Wireless LAN controller.
[Enabled] Enables or disables the built-in web cam.
13
Stylistic ST Series BIOS
F1 Help
ESC Exit
Select Item
Select Menu
-/Space
Enter
F9 Setup Defaults
F10 Save and Exit
Change Values
Select Sub-Menu
▲
Item Specific Help
Select Core
Multi-Processing
enabled or disabled.
CPU Features
Core Multi-Processing:
SpeedStep(R) Technology: [Enabled]
XD Bit functionality: [Enabled]
Virtualization Technology: [Disabled]
Intel(R) VT-d: [Disabled]
Intel(R) TXT: [Disabled]
[Enabled]
Phoenix SecureCore(tm) Setup Utility
Info System Advanced Security Boot Exit
CPU Features Submenu of the Advanced Menu
The CPU Features submenu provides options for configuring the Intel Core Multi-Processing and SpeedStep power
management features of the CPU.
Figure 9. CPU Features Submenu
Table 9: Fields, Options and Defaults for the CPU Features Submenu of the Advanced Menu
Menu Field Options Default Description
Core MultiProcessing:
SpeedStep(R)
Technology:
XD Bit
functionality:
Virtualization
Technology:
Intel(R) VT-d:
Intel(R) TXT:
14
■
Enabled
■
Disabled
■
Disabled
■
Enabled
■
Enabled
■
Disabled
■
Disabled
■
Enabled
■
Disabled
■
Enabled
■
Disabled
■
Enabled
[Enabled] Enables or disables the Intel Core Multi-Processing features.
[Enabled] Enables or disables the SpeedStep(R) Technology features. When dis-
[Enabled] Enables or disables the Execute Disable Bit feature.
[Disabled] Enables or disables Virtualization Technology, an Intel technology which
[Disabled] This item is selectable only when Virtualization Technology is enabled.
[Disabled] This item is selectable only when Virtualization Technology is enabled,
abled, On Battery and On AC are disabled.
includes hardware enhancements to improve upon software-based virtualization technologies.
Enables and disables the Virtualization Technology functionality for
directed input/output.
Intel VT-d is enabled, and Current TPM State is enabled and activated.
Enables and disables the Trusted Execution technology.
Advanced Menu
USB Features Submenu of the Advanced Menu
The USB Features submenu provides options for enabling or disabling the USB devices.
Phoenix SecureCore(TM) Setup Utility
Exit Submenu
USB Features
Legacy USB Support: [Enabled]
SCSI SubClass Support: [Enabled]
Item Specific Help
[Disabled]
The feature is disabled.
[Enabled]
Legacy USB Emulation
is enabled and USB
devices are available
without USB aware OS.
F1 Help
ESC Exit
Select Item
Select Menu
Figure 10. USB Features Submenu
-
Change Values
Enter
Select Sub-Menu
Space
▲
F9 Setup Defaults
F10 Save and Exit
Table 10: Fields, Options and Defaults for the USB Features Submenu of the Advanced Menu
Menu Field Options Default Description
Legacy USB Support:
SCSI SubClass Support:
■
Disabled
■
Enabled
■
Disabled
■
Enabled
[Enabled] When Enabled is selected, Legacy USB Emulation is enabled
and the USB devices are available without a USB-aware OS.
When Disabled is selected, Legacy USB support is disabled.
[Enabled] When Enabled is selected, USB devices that belong to the
SCSI subclass in the mass storage class (e.g., USB Memory
Key) are enabled. Note that enabling this feature may cause
the system to hang during POST, depending on the device
that is connected.
15
Stylistic ST Series BIOS
F1 Help
ESC Exit
Select Item
Select Menu
-/Space
Enter
F9 Setup Defaults
F10 Save and Exit
Change Values
Select Sub-Menu
▲
Item Specific Help
Configures the power
button.
*ACPI OS ignores this
setting.
Miscellaneous Configurations
Power Button:
Wake up on LAN:
On Battery:
Force LAN Boot:
Resume on LAN:
Auto Save To Disk:
Volume Setting:
Hardware Power Management:
Low Power Mode:
[Disabled]
[Disabled]
[Enabled]
[Disabled]
[Always Enabled]
[On]
[Middle]
[Enabled]
[Enabled]
Phoenix SecureCore(tm) Setup Utility
Info System Advanced Security Boot Exit
Miscellaneous Configurations Submenu of the Advanced Menu
The Miscellaneous Configurations submenu provides options for enabling or disabling the power button and the
Wake Up On LAN feature, and setting the volume and video memory size.
Figure 11. Miscellaneous Configurations Submenu
Table 11: Fields, Options and Defaults for the Miscellaneous Configurations Submenu of Advanced Menu
Menu Field Options Default Description
Power Button:
Wake up on LAN:
On Battery:
Force LAN Boot:
Resume on LAN:
Auto Save to Disk:
16
■
Disabled
■
Power Off
■
Disabled
■
Enabled
■
Disabled
■
Enabled
■
Disabled
■
Enabled
■
On AC
mode only
■
Always
enabled
■
Off
■
On
[Disabled] Selecting [Disabled] disables the power button. Selecting [Power Off] allows you
to turn off system power with the power button.
[Disabled] [Enabled] allows the system to wake up when the internal LAN device receives a
specific signal while in power-off state. Selecting [Disabled] disables this feature.
[Enabled] When disabled, the [Wake up on LAN] feature is enabled only when an AC
[Disabled] This feature is active only when [Wake up on LAN] is enabled. When enabled, in
[Always
enabled]
Adapter is connected.
the event of a system wake-up on LAN, the system will try to first boot from the
LAN before attempting to boot from any other device, regardless of the BIOS boot
priority settings or disabling of the Preboot Execution Environment.
When [On AC mode only] is selected, [Wake up on LAN] from sleep or hibernate
modes is enabled only when an AC Adapter is connected. Enabling [Wake up on
LAN] from sleep or hibernate modes depends on the OS settings.
[On] Allows you to turn on or off the Auto Save to Disk feature.When this feature is
turned on, a suspended system that reaches low battery state will save its state
and power off.
Advanced Menu
Table 11: Fields, Options and Defaults for the Miscellaneous Configurations Submenu of Advanced Menu
Menu Field Options Default Description
■
Volume Setting:
Hardware Power
Management:
Low Power Mode:
Off
■
Minimum
■
Middle
■
Maximum
■
Disabled
■
Enabled
■
Disabled
■
Enabled
[Middle] Selects the initial volume setting for the system.
[Enabled] Allows you to enable or disable the Hardware Power Management technology.
[Enabled] Allows you to enable or disable the Low Power Mode.
17
Stylistic ST Series BIOS
F1 Help
ESC Exit
Select Item
Select Menu
-/Space
Enter
F9 Setup Defaults
F10 Save and Exit
Change Values
Select Sub-Menu
▲
Item Specific Help
[Disabled]
Disables Intel(R) Active
Management Technology.
[Enabled]
Enables Intel(R) Active
Management Technology.
Active Management Technology:
Management Engine BIOS Extensions: [Disabled]
[Disabled]
Intel(R)
Active Management Technology
Info System Advanced Security Boot Exit
Phoenix SecureCore(tm) Setup Utility
Intel(R) Active Management Technology Submenu of the Advanced Menu
The Intel(R) Active Management Technology submenu provides options for enabling or disabling the Active Management Technology and Management Engine BIOS Extension features.
Figure 12. Intel(R) Active Management Technology Submenu
Table 12: Fields, Options and Defaults for the Intel Active Management Technology Submenu of the
Advanced Menu
Menu Field Options Default Description
Active Management
Technology:
Management Engine BIOS
Extensions:
18
■
Disabled
■
Enabled
[Disabled] When enabled, the Intel(R) Active Management Technology
■
■
Disabled
Enabled
[Disabled] When enabled, the Intel Management Engine BIOS Exten-
features are enabled. Note that this must be enabled in
order for [Management Engine BIOS Extensions] to be
enabled.
sion screens are displayed
Event Logging Submenu of the Advanced Menu
The Event Logging submenu configures event logging features for DMI events.
Phoenix SecureCore(tm) Setup Utility
Info System Advanced Security Boot Exit
Advanced Menu
Event Logging
Event Log Capacity: Space Available
Event Log Validity: Valid
Item Specific Help
Press <Enter> key to
view the contents of
the event log.
View Event Log: [Enter]
Event Logging: [Enabled]
System Boot Event: [Disabled]
Clear All Event Logs: [No]
Mark Events as Read: [Enter]
F1 Help
ESC Exit
Select Item
Select Menu
Figure 13. Event Logging Submenu
-/Space
Enter
Change Values
▲
Select Sub-Menu
F9 Setup Defaults
F10 Save and Exit
Table 13: Fields, Options and Defaults for the Event Logging Submenu of the Advanced Menu
Menu Field Options Default Description
Event Log Capacity: Space Available Display only
Event Log Validity: Valid Display only
View Event Log:
Event Logging:
System Boot Event:
Clear All Event Logs:
Mark Events as Read:
■
Enter [Enter] Allows you to view content of event log
■
Disabled
■
Enabled
■
Disabled
■
Enabled
■
No
■
Yes
■
Enter [Enter] Lets you mark all events currently in the event log as having been read.
[Enabled] Turns event logging on and off for all DMI events.
[Disabled] Turns event logging on and off for DMI system boot events.
[No] When set to [Yes] all event logs will be cleared at next boot.
19
Stylistic ST Series BIOS
Security Menu
SECURITY MENU – SETTING THE SECURITY FEATURES
The Security menu allows you to set up the data security
features of your Tablet PC to fit your operating needs
and to view the current data security configuration. (See
Options and settings for menus in BIOS Setup are
described in tables appearing later in this chapter. on page
2 for more information.)
The following tables show the names of the menu fields
for the Security Menu and its submenus, all the options
for each field, the default settings and a description of
the field's function and any special information needed
to help understand the field's use. The default condition
is no passwords required and no write protection.
Remember your passwords! If you set and
forget your User and Master hard disk
passwords, Fujitsu Computer Systems will
not be able to reset it. You may lose data
and have to replace your system board or
hard disk drive.
Info System Advanced Security Boot Exit
Supervisor Password Is: Clear
User Password Is: Clear
Set Supervisor Password [Enter]
Set User Password [Enter]
Minimum User Password Length: [0]
Password on Boot: [Disabled]
On Automatic Wake up: [Disabled]
Boot from Removable Media: [All]
Flash Write: [Enabled]
Smartcard PC Lock: [Disabled]
▲ ▲
Hard Disk Security
Owner Information
▲
TPM (Security Chip) Setting
Phoenix SecureCore(tm) Setup Utility
■
Entering a password incorrectly 3 times in
a row causes the keyboard and mouse to
be locked out and the warning [System
Disabled] to be displayed. If this happens, restart the computer by turning off
and on the power with the power switch
and use the correct password on reboot.
■
If you make an error when re-entering
the password a Warning will display on
the screen. To try again press [Enter],
then retype the password. Press [Esc] to
abort the password setting process.
■
If the Security Panel on Resume is
Enabled and the Password on Boot is Disabled you will not have to type your
password upon resuming the system
from the Suspend or Save-to-Disk
modes. Power Management Security will
work only if Password boot is enabled.
Item Specific Help
Press <Enter> key to
set Supervisor Password
to enable any password
features.
Then password entry is
required to enter BIOS
Setup.
F1 Help
ESC Exit
20
Select Item
Select Menu
-/Space
Enter
Figure 14. Security Menu
Change Values
▲
Select Sub-Menu
F9 Setup Defaults
F10 Save and Exit
Security Menu
Table 14: Fields, Options and Defaults for the Security Menu
Menu Field Options Default Description
Supervisor
Password is:
User Password is: –— Clear A display-only field. Set is displayed when the general user
Set Supervisor
Password
Set User Password –— [Enter] This field can only be accessed if the Supervisor Password is set. Sets, changes
Minimum User Password Length:
Password on Boot:
On Automatic
Wake up:
Boot from
Removable Media:
Flash Write:
Smartcard PC Lock:
Hard Disk Security: –— –— Configures hard disk security features
Owner Information: –— –— Sets Owner information.
TPM (Security Chip)
Setting
–— Clear A display-only field. Set is displayed when the system supervisor password is
set and Clear when it is not.
password is set, and Clear when it is not.
–— [Enter] Sets, changes or cancels the Supervisor Password. The Supervisor Password
may be up to seven characters long and must include only letters or numbers
(no symbols). Passwords are NOT case-sensitive. To cancel a password press
the Enter key instead of entering characters in the Enter New Password field
and in the Re-enter New Password field. When a Supervisor Password is set it
must be used to access the BIOS setup utility.
NOTES: If your system has the Pre-Boot Authentication (PBA) feature, you
cannot log in as a supervisor using your fingerprint. Note, also, that on fingerprint-enabled PBA systems, when the supervisor password is cleared, the BIOS
will display a message asking you to acknowledge that the BIOS fingerprint
data will be cleared as well.
or cancels the User Password. A User Password may be up to seven characters
long and must include only letters or numbers (no symbols). Passwords are
NOT case-sensitive. To cancel a password press [Enter] key instead of entering
characters in the Enter New Password field and in the Re-enter New Password
field. When a User Password is set it must be used to access the BIOS setup
utility.
–— [0] Supervisor can set password length (0 to 8) for user password. User cannot set
■
Disabled
■
First Boot
■
Every Boot
■
Disabled
■
Enabled
■
All
■
Supervisor only
■
Disabled
■
Enabled
■
Disabled
■
Enabled
[Disabled] When set to First Boot, a password (User or Supervisor) is required just once
[Disabled] When disabled, password entry is not required when the system wakes up
[All] Supervisor only allows access to boot the computer to removable media after
[Enabled] When disabled, the BIOS Flash memory will be write protected.
[Disabled] When enabled, the system is locked using Smartcard security. A personal iden-
a password shorter than the minimum length.
after the Power On Self Test (POST) before the operating system will be read
from a disk. When set to Every Boot, a password (User or Supervisor) is
required every time after the Power On Self Test (POST) before the operating
system will be read from a disk. When set to Disabled no password is required.
NOTE: If your system has the Pre-Boot Authentication (PBA) feature, this field
must be set to [Every Boot] to ensure that the PBA window appears.
automatically. When enabled, password entry is required upon wake up.
the Supervisor Password is entered.
tification number (PIN) is required to enter the BIOS Setup Utility and before
OS boot.
___ ___ Opens the Trusted Platform Module (TPM) Security Chip Setting submenu to
configure the Security Chip.
Exiting from the Security Menu
When you have finished setting the parameters on the Security Menu, you can either exit from setup utility or move to
another menu. If you wish to exit from setup utility, press the [Esc] key to go to the Exit Menu. If you wish to move to
another menu, use the cursor keys.
21
Stylistic ST Series BIOS
F1 Help
ESC Exit
Select Item
Select Menu
-/Space
Enter
F9 Setup Defaults
F10 Save and Exit
Change Values
Select Sub-Menu
▲
Item Specific HelpHard Disk Security
Drive0: Clear
Set Master Password [Enter]
Set User Password [Enter]
Password Entry on Boot: [Enabled]
Phoenix SecureCore(tm) Setup Utility
Info System Advanced Security Boot Exit
Hard Disk Security Submenu of the Security Menu
The Hard Disk Security submenu is for configuring hard disk security features.
Figure 15. Hard Disk Security Submenu
Table 15: Fields, Options and Defaults for the Hard Disk Security Submenu of the Security Menu
Menu Field Options Default Description
Drive0:
Set Master
Password
Set User
Password
___
___
___
Password Entry on
Boot:
22
■
Disabled
■
Enabled
Clear Display-only. Default is Clear. When the Drive0 Password has been set, the field
[Enter] Sets, changes or cancels the Master Password. The Master Password may be up to
[Enter] Sets, changes or cancels the User Password. The User Password may be up to seven
[Enabled] When set to disabled, entry of a Hard Disk Password is not required before OS boot.
changes to Set. When this password is set, the primary hard disk drive cannot be
used in another system unless the password is entered.
seven characters long and must include only letters or numbers (no symbols). Passwords are NOT case-sensitive. When a Master Password is set, it must be used to
access the hard drive if it is used in another system. Note that the password will not
take effect until the system has been rebooted.
characters long and must include only letters or numbers (no symbols). Passwords
are NOT case-sensitive. When a User Password is set, it must be used to access the
hard drive if it is used in another system. Note that the password will not take effect
until the system has been rebooted.
(The hard disk is still password-protected without password entry.)
F1 Help
ESC Exit
Select Item
Select Menu
-/Space
Enter
F9 Setup Defaults
F10 Save and Exit
Change Values
Select Sub-Menu
▲
Item Specific HelpOwner Information
Owner Information Is: Clear
Set Owner Information [Enter]
Foreground Color: [Gray]
Background Color: [Black]
Phoenix SecureCore(tm) Setup Utility
Info System Advanced Security Boot Exit
Security Menu
Owner Information Submenu of the Security Menu
The Owner Information submenu is for setting owner information. Note that the owner information cannot be set
without having entered a Supervisor Password.
Figure 16. Owner Information Submenu
Table 16: Fields, Options and Defaults for the Owner Information Submenu of the Security Menu
Menu Field Options Default Description
Owner Information Is: –— Clear Display only.
Set Owner Information: –— [Enter] Field to write owner
Foreground Color:
Background Color:
■
Black
■
Blue
■
Green
■
Cyan
■
Red
■
Magenta
■
Black
■
Blue
■
Green
■
Cyan
■
Red
■
Magenta
■
■
■
■
■
■
■
■
■
■
Brown
White
Gray
Light Blue
Light Green
Brown
White
Gray
Light Blue
Light Green
■
Light Cyan
■
Light Red
■
Light Magenta
■
Yellow
■
Bright White
■
Light Cyan
■
Light Red
■
Light Magenta
■
Yellow
■
Bright White
information, (i.e., name).
[Gray] Set foreground color.
[Black] Set background color.
23
Stylistic ST Series BIOS
F1 Help
ESC Exit
Select Item
Select Menu
-/Space
Enter
F9 Setup Defaults
F10 Save and Exit
Change Values
Select Sub-Menu
▲
Item Specific HelpTPM (Security Chip) Setting
Security Chip: [Enabled]
Current TPM State: Disabled and Deactivated
Change TPM State: [No Change]
Clear Security Chip: [Enter]
Info System Advanced Security Boot Exit
Phoenix SecureCore(tm) Setup Utility
TPM (Security Chip) Setting Submenu of the Security Menu
The TPM (Security Chip) Setting submenu is used to enable or disabled the embedded security chip.
Figure 17. TPM (Security Chip) Setting Submenu
Table 17: Fields, Options and Defaults for TPM (Security Chip) Submenu of Security Menu
Menu Field Options Default Description
Security Chip:
Current TPM State: –— –— Indicates the current state of the TPM chip.
Change TPM State:
Clear Security Chip
24
■
Disabled
■
Enabled
■
No Change
■
Disable and
Deactivate
■
Enter [Enter] Allows you to clear the Security Chip. Note that this does
[Enabled] Allows you to enable or disable the security chip. Note
[No Change] Allows you to enable or disable the TPM chip when the
that this is only active if a Supervisor Password has been
entered. A reboot is required after exit to configure the
Security Chip correctly. Clear Security Chip option
becomes selectable after reboot.
Supervisor Password has been set.
not allow you to access already-encrypted data.
F1 Help
ESC Exit
Select Item
Select Menu
Item Specific Help
[Disabled]
Display the logo screen
during boot.
[Enabled]
Display the diagnostic
screen during boot.
Boot Time Diagnostic Screen:
Boot Menu: [Enabled]
Preboot Execution Environment: [Enabled]
Boot Device Priority
▲
-/Space
Enter
F9 Setup Defaults
F10 Save and Exit
Change Values
Select Sub-Menu
▲
[Disabled]
Info System Advanced Security Boot Exit
Phoenix SecureCore(tm) Setup Utility
Boot Menu
BOOT MENU – SELECTING THE OPERATING SYSTEM SOURCE
The Boot Menu is used to select the order in which the
BIOS searches sources for the operating system. Follow
the instructions for Navigating Through the Setup
Utility to make any changes. (See Options and settings for
menus in BIOS Setup are described in tables appearing
later in this chapter. on page 2 for more information.)
The following tables show the names of the menu fields
for the Boot menu and its submenu, all of the options
for each field, the default settings and a description of
the field's function and any special information needed
to help understand the field's use.
Table 18: Fields, Options and Defaults for the Boot Menu
Menu Field Options Default Description
Boot-time
Diagnostic Screen:
Boot Menu:
Preboot Execution
Environment:
Boot Device
Priority
■
■
■
■
■
■
— — This menu allows setting up the source for the operating system.
Disabled
Enabled
Disabled
Enabled
Disabled
Enabled
[Disabled] Turns on and off display of test results instead of Fujitsu logo screen
[Enabled] When Disabled, the Boot Menu is disabled and the [F12] key is
[Enabled] Turns on and off the preboot execution environment feature.
Figure 18. Boot Menu
during Power On Self Test.
ignored. When Enabled, the Boot Menu is enabled.
See “The Boot Device Priority Submenu” in the following section.
25
Stylistic ST Series BIOS
F1 Help
ESC Exit
Select Item
Select Menu
Item Specific Help
Keys used to view or
configure devices:
<+>/<Space> or <->
moves the device up or
down.
<x> exclude or include
the device to boot.
Boot priority order:
1: Floppy Disk Drive
2: Drive0 HDD: FUJITSU MHZ2080BH
3: CD/DVD Drive
4: NETWORK: Intel LAN
5:
6:
7:
8:
Excluded from boot order:
: USB MEMORY: None
: USB HDD: None
-/Space
Enter
F9 Setup Defaults
F10 Save and Exit
Change Values
Select Sub-Menu
▲
Boot Device Priority
Phoenix SecureCore(tm) Setup Utility
Info System Advanced Security Boot Exit
Boot Device Priority Submenu of the Boot Menu
The Boot Device Priority submenu is for setting the order of checking of sources for the operating system.
■
Be careful of the operating environment when booting from a CD or you may overwrite files by mistake.
■
A bootable CD-ROM has either a floppy disk format or a hard drive format. When the bootable CD-ROM
is used, the drive allocations change automatically without changing the BIOS setup. If a floppy disk format is used, the CD-ROM becomes Drive A. The CD-ROM will only take drive C: (hard drive format) if
the internal hard drive is not present or is disabled. The bootable CD-ROM can never use a C: designation
if a formatted internal hard drive is present since the C: designator is always reserved for the internal hard
drive.The boot sequence ignores the new drive designations, however, your application software will use
the new designations.
Figure 19. Boot Device Priority Submenu
Table 19: Fields, Options and Defaults for the Boot Device Priority Submenu of the Boot Menu
Menu Field Description
Boot priority order:
1: Floppy Disk Drive
2: Drive0:
3: CD/DVD Drive
4: NETWOR
5:
6:
7:
8:
Excluded from boot order:
: USB MEMORY:
: USB HDD:
Exiting from Boot Menu
When you have finished setting the boot parameters with the Boot Menu, you can either exit from the setup utility or
The boot selections determine the order in which the BIOS searches for the operating system during a
startup sequence. To change the order, highlight one source by using the [up] or [down] cursor keys and
then press the [+] or [-] key to change the order number. Tapping [x] removes from the list a device that is
not installed. Tapping [x] on an item in the Excluded list adds the device to the Boot priority list. Be sure to
save your changed order when you exit the BIOS setup utility.
NOTE: Be aware that if you use the CD-ROM drive as the first boot device, certain files may be
overwritten, depending upon your operating environment.
move to another menu. If you wish to exit from the setup utility press the [Esc] key to go to the Exit Menu. If you wish
to move to another menu, use the cursor keys.
26
EXIT MENU – LEAVING THE SETUP UTILITY
F1 Help
ESC Exit
Select Item
Select Menu
-/Space Change Values
Enter Select Sub-Menu
F9 Setup Defaults
F10 Save and Exit
Item Specific Help
Exit System Setup and
save your changes to
CMOS.
Exit Saving Changes
Exit Discarding Changes
Load Setup Defaults
Discard Changes
Save Changes
Save Changes and Power Off
▲
Info System Advanced Security Boot Exit
Phoenix SecureCore(tm) Setup Utility
Exit Menu
The Exit Menu is used to leave the setup utility. Follow
the instructions for Navigating Through the Setup
Utility to make any changes. (See Options and settings for
Figure 20. Exit Menu
Table 20: Fields, Options and Defaults for the Exit Menu
menus in BIOS Setup are described in tables appearing
later in this chapter. on page 2 for more information.)
Menu Field Description
Exit Saving
Changes
Exit Discarding
Changes
Load Setup
Defaults
Discard
Changes
Save Changes Selecting Save Changes will cause the new settings in all menus to be written to the BIOS memory. The message Save
Save Changes
and Power Off
Exit Saving Changes and Exit will store all the entries on every menu of the setup utility to the BIOS memory, then exit
the utility. A confirmation message Save Configuration changes and exit now? [Yes][No] is displayed.
Selecting Exit Discarding Changes and Exit will exit the setup utility with out writing to the BIOS memory. When the
BIOS recognizes this selection it will load the operating system and begin operation.
Selecting Load Setup Defaults will load the factory preset default values for all menu fields, then display the message
Load default configuration now? [Yes] [No]. When confirmed the setup utility will return to the Exit
Menu. To return to another menu follow the directions in the Navigating Through the Setup Utility Section.
Selecting Discard Changes will load the previous values in BIOS memory for all menu fields. The message Load
previous configuration now? [Yes] [No] will be displayed. When confirmed the setup utility will return to
the Exit menu. To return to another menu, follow the directions in the Navigating Through the Setup Utility Section.
configuration changes now? [Yes] [No] will be displayed. When confirmed, the setup utility will return to
the Exit menu. To return to another menu, follow the directions in the Navigating Through the Setup Utility section.
Selecting Save Changes and Power Off will cause the new settings in all menus to be written to the BIOS memory. The
message Save configuration changes and power off now? [Yes] [No] will be displayed. When confirmed, the system will shut down. If No is selected, the system will return to the Exit menu. To return to another menu,
follow the directions in the Navigating Through the Setup Utility section.
27
Loading...
