User Manual
Thermal printer controller
PRN607-S
MAN607-S
FOR FUJITSU THERMAL PRINTERS
FTP607MCLXXX SERIES
28-03-2003 Page 1-1 of 53
VERSION HISTORY
Version Date Init Status Description
1.0 030328 BB Released First release
Comments:
List of known missing parts:
1. Details for some ESC sequences are not specified.
2. Connector specification is not updated
3. IRDA specifications are not implemented.
4. Description of installed Font set missing.
Copyright 1999-2003 by I/F-COM A/S.
All rights reserved.
I/F-COM A/S has prepared this manual for use by I/F-COM A/S’ customers.
The information contained herein is the property of I/F-COM A/S and shall
not be reproduced in whole or in part without the prior written approval of
I/F-COM A/S.
I/F-COM A/S reserves the right to make changes without notice to the
specifications and materials contained herein and shall not be responsible
for any damages (including consequential) caused by reliance on the
materials presented, including but not limited to typographical, arithmetic, or
listing errors.
Seiko is a trademark of Seiko Instruments Inc.
Fujitsu is a trademark of Fujitsu Corporation.
APS is a trademark of Advance Printing System.
Centronics is a trademark of Centronics Date Computer Corporation.
ESC/POS is a trademark of EPSON.
Windows is a trademark of Microsoft Inc.
Safety Precautions
• Please read and understand these specifications thoroughly before
using the printer. Please keep the specifications carefully in a place
where they may be easily consulted when the printer is used.
• Please do not modify or service this printer as this may cause
unpredictable faults to occur.
MAN607-S
28-03-2003 Page 1-2 of 53
MAN607-S
• The product is not intended to be installed in devices such as those
used in life-support medical equipment, undersea relays, and aerospace
applications or for nuclear power control, in which extremely high
reliability is required. If you are considering such applications, please
consult our customer service department.
• There is a general possibility of component failure. Every effort has
been made to improve product quality but such failures cannot be
completely excluded. Please assume that such failure may occur
before using this printer.
We would urge that these specifications should be thoroughly understood and the
printer used safely in your company or associated organisation. Please indicate or
describe in your products and in the user manuals those items, which are related to
the prevention or avoidance of danger and draw these to the attention of the eventual
client (the user).
28-03-2003 Page 1-3 of 53
MAN607-S
1 SYSTEM DESCRIPTION.....................................................................................................1-7
2 INSTALLATION ...................................................................................................................2-7
2.1 UNPACKING.......................................................................................................................2-7
2.2 LABELS .............................................................................................................................2-7
2.3 INSTALLATION ..................................................................................................................2-7
2.4 POWER SUPPLY..................................................................................................................2-8
2.5 SETTINGS ..........................................................................................................................2-8
2.6 SERIAL INPUT/OUTPUT....................................................................................................2-11
2.6.1 Serial data transfer.................................................................................................2-11
2.6.1.1 Serial input/output port........................................................................................2-12
2.6.2 Setting functions .....................................................................................................2-12
2.6.3 Thermal Head Control............................................................................................2-13
2.6.4 Thermal Head Drive Operation..............................................................................2-13
2.6.5 Peak power limitation.............................................................................................2-13
2.6.6 Head Control Circuit..............................................................................................2-14
2.6.7 Head temperature measurement circuit .................................................................2-14
2.6.8 Vhead interrupt circuit ...........................................................................................2-14
3 SPECIFICATIONS..............................................................................................................3-15
4 FUNCTION...........................................................................................................................4-16
4.1 GENERAL ........................................................................................................................4-16
4.2 SERIAL COMMUNICATION................................................................................................4-16
4.3 USB COMMUNICATION. ..................................................................................................4-16
4.4 IRDA COMMUNICATION. ................................................................................................4-16
4.5 FIRMWARE UPGRADE.......................................................................................................4-17
4.6 AUTO FORM FEED............................................................................................................4-17
4.7 CHARACTER DESIGN........................................................................................................4-18
4.7.1 Normal Character. .................................................................................................4-18
4.7.2 Low Character........................................................................................................4-18
4.7.3 Underline................................................................................................................4-18
4.7.4 Bold ........................................................................................................................4-18
4.7.5 Reverse ...................................................................................................................4-19
4.7.6 Italic........................................................................................................................4-19
4.7.7 Font sizes................................................................................................................4-19
4.8 PRINTER COMMANDS.......................................................................................................4-20
4.9 I/F-COM SIMPLE COMMAND SET. ...................................................................................4-20
4.9.1 Small Font ..............................................................................................................4-20
4.9.2 Low Font.................................................................................................................4-20
4.9.3 Narrow Font...........................................................................................................4-20
4.9.4 Normal Font...........................................................................................................4-20
4.9.5 Wide Font...............................................................................................................4-21
4.9.6 High Font ...............................................................................................................4-21
4.9.7 Large Font..............................................................................................................4-21
4.9.8 Xlarge Font.............................................................................................................4-21
4.9.9 Line Feed................................................................................................................4-21
4.9.10 Barcode on .............................................................................................................4-21
4.9.11 Feed Forward.........................................................................................................4-22
4.9.12 Reverse off..............................................................................................................4-22
4.9.13 Reverse on ..............................................................................................................4-22
4.9.14 Underline off...........................................................................................................4-22
4.9.15 Underline on...........................................................................................................4-22
4.9.16 Bold off...................................................................................................................4-23
4.9.17 Bold on ...................................................................................................................4-23
4.9.18 Italic off..................................................................................................................4-23
28-03-2003 Page 1-4 of 53
MAN607-S
4.9.19 Italic on...................................................................................................................4-23
4.9.20 Initialise Printer .....................................................................................................4-23
4.9.21 Request Software version........................................................................................4-24
4.9.22 Request Status.........................................................................................................4-24
4.9.23 Request Analog voltage..........................................................................................4-24
4.9.24 Request Temperature..............................................................................................4-25
4.9.25 Sub command set....................................................................................................4-25
4.9.26 Upgrade command.................................................................................................4-25
4.9.27 Set auxiliary output.................................................................................................4-25
4.9.28 Automatic sending status........................................................................................4-26
4.9.29 Stop sending automatic status................................................................................4-26
4.9.30 Color/Grey scale graphic.......................................................................................4-26
4.9.31 Enable saving data.................................................................................................4-26
4.9.32 Save data to board..................................................................................................4-27
4.9.33 Change dot size.......................................................................................................4-27
4.9.34 Change form feed length.........................................................................................4-27
4.9.35 Change baud rate...................................................................................................4-27
4.9.36 Change form feed time............................................................................................4-27
4.9.37 Feed Paper.............................................................................................................4-28
4.9.38 Compensate Burn time............................................................................................4-28
4.9.39 Bar code width setting............................................................................................4-28
4.9.40 Bar code height setting...........................................................................................4-29
4.9.41 Bar code printing....................................................................................................4-29
4.9.42 Black Mark.............................................................................................................4-31
4.9.43 Graphic data – non compressed.............................................................................4-32
4.9.44 Graphic data – compressed....................................................................................4-32
4.9.45 Escape sequences, overview...................................................................................4-33
5 MAINTENANCE .................................................................................................................5-34
5.1 DAILY USE.......................................................................................................................5-34
5.2 STORE/TRANSPORT .........................................................................................................5-34
6 SPECIFICATIONS..............................................................................................................6-35
6.1 ELECTRICAL DATA..........................................................................................................6-35
6.2 MECHANICAL DATA........................................................................................................6-35
6.3 ENVIRONMENTAL DATA..................................................................................................6-35
6.4 EMC & ESC...................................................................................................................6-35
6.5 TEMPERATURE TEST .......................................................................................................6-36
6.6 CONNECTOR PIN ASSIGNMENT........................................................................................6-37
6.6.1 Thermal Head connector........................................................................................6-37
6.6.2 Thermal Head connector........................................................................................6-37
6.6.3 IRDA connector......................................................................................................6-38
6.6.4 AUX input connector..............................................................................................6-38
6.6.5 Power connector.....................................................................................................6-39
6.6.6 USB connector........................................................................................................6-39
6.6.7 AUX connector.......................................................................................................6-39
6.6.8 Cutter connector.....................................................................................................6-40
6.6.9 Serial connector......................................................................................................6-40
6.7 MECHANICAL DRAWINGS................................................................................................6-41
7 APPENDIX...........................................................................................................................7-42
7.1 SEIKO COMPATIBLE COMMAND SET.................................................................................7-42
7.1.1 Escape sequences, overview...................................................................................7-42
7.2 FUJITSU COMPATIBLE COMMAND SET..............................................................................7-43
7.2.1 Escape sequences, overview...................................................................................7-43
7.3 COMMAND LIST DESCRIPTION .........................................................................................7-44
7.3.1 Horizontal tab.........................................................................................................7-44
7.3.2 Line feed.................................................................................................................7-45
28-03-2003 Page 1-5 of 53
MAN607-S
7.3.3 Forms feed..............................................................................................................7-46
7.4 APS COMPATIBLE COMMAND SET...................................................................................7-47
7.4.1 Escape sequences, overview...................................................................................7-47
7.5 ESC/POS COMPATIBLE COMMAND SET...........................................................................7-49
7.6 ESCAPE SEQUENCES, OVERVIEW. ....................................................................................7-49
7.7 OPTIONAL SENSOR DESCRIPTION.....................................................................................7-52
28-03-2003 Page 1-6 of 53
1 SYSTEM DESCRIPTION
This reference manual describes the specifications, functions, and
operating procedures for the PRN607-S Interface Board.
The PRN607-S is an interface board for the FTP607MCLxxx series printer
mechanisms.
This reference manual also describes the print operation of the
FTP607MCLxxx. Read this reference manual thoroughly before using the
PRN607-S. PRN607-S is designed for the following Fujitsu printers:
FTP627MCLxxx
FTP637MCLxxx
PRN607-S consists of an interface board.
The communication is RS232, USB or IRDA.
PRN607-S can print graphic data either compressed or non-compressed.
Burn time can be set to control the printing intensity
Windows 95/98, 2000, NT and CE drivers are available at
http://www.if-com.com, for easy operation by PC. Linux drivers are available
upon request.
MAN607-S
2 INSTALLATION
2.1 Unpacking
Remove the cover observing precautions for Electro Static Discharge
(ESD). Make sure that board is handled with care with respect to
Electrostatic environment.
2.2 Labels
PRN607-S has 3 labels;
Label 1 on backside ex. Ifxxxxxx is a unique ID number. For service and
question based upon 1 particular board please refer to this number.
Label 2 on topside ex. PRN607-S is part number. Please refer to this
number upon reordering. Make sure that software revision is applied at
same time.
Label 3 is an internal code. Please ignore.
2.3 Installation
PRN607-S is fastened in the product by 4 M3.3 screws. The cables (for the
thermal head, the stepper-motor and detector) are placed in the thermal
printer connector on the PCB. 1 Mounting hole is grounded. See drawing
for more details.
28-03-2003 Page 2-7 of 53
MAN607-S
(a) To connect or remove the connector, always turn off the power in
advance. If the connector is connected or removed while the power
to the printer is on, errors may occur.
(b) The connector of each cable must be correctly locked and connected.
The connector at the head side has no lock feature. Check that the
connector at the head side is completely inserted.
(c) To install the interface, carefully check each cable so that excessive
force is not applied to each cable. Especially, carefully check the
head connection cable because it affects the head pressure force. If
the print head connector is not completely connected, overheating or
burning may occur in the print head.
(d) Be sure to add grounding cable from printer body to interface ground.
Make sure that ground is present at any mechanical settings, like
head up and paper out.
2.4 Power supply
Single power supplies for the PRN607-S controller board. Voltage range is
18-26VDC. 5A minimum @ 24V. Make sure that voltages never exceed
26VDC.
(a) The power supply unit that satisfies the specified specifications must
be used. If a power supply unit that does not satisfy the specified
specifications is used, normal operation is not assured and errors
may occur.
(b) To turn on or off the power, a protective circuit must be mounted on
the control board in advance. For safety, the following voltage
change conditions must be satisfied:
2.5 Settings
Following below description can change default settings. Baud rate is
default 115.200, however standard PC´s today cannot handle this Baud
rate. Windows OS does not support speed higher than 115.200 Baud, even
when setup menus can be set to higher speed. In order to obtain higher
28-03-2003 Page 2-8 of 53
MAN607-S
speed you need to install 3rd part utility program on PC. Please visit www.if-
com.com for further information.
1. Turn off power
2. Press Key 1 low while power up. Board is now in setting mode. Text
will be printed on paper for further information
3. By activating key 1 and 2 you can change following parameters:
a. Test printout
b. Select Command set
i. I/F-COM command set (Default)
ii. Seiko compatible command set (Optional)
iii. Fujitsu compatible command set (Optional)
iv. APS compatible command set (Optional)
v. ESC/POS compatible command set (Optional)
c. Baud rate
i. 9600
ii. 19.200
iii. 38.400
iv. 57.600
v. 115.200 (Default)
vi. 230.400
vii. 460.800
d. Parity
i. 0 (Default)
ii. 1
e. Data bit
i. 7
ii. 8 (Default)
f. Stop bit
i. 1
ii. 2
g. Flow control
i. None
ii. Hardware (Default)
iii. Xon/Xoff
h. Dot size of printer
i. 384 dots (Default)
ii. 432 dots
iii. 448 dots
iv. 512 dots
v. 576 dots
vi. 640 dots
vii. 832 dots
viii. 1152 dots
i. Key 1 function
1. Input key (Default)
2. LED output
3. Label detect
28-03-2003 Page 2-9 of 53
MAN607-S
4. Black mark detection
5. Paper near end function
j. Key 2 function
1. Input key
2. LED output
3. Label detect
4. Black mark detection
5. Paper near end function
k. IRDA
i. Enabled (Optional)
ii. Disabled
l. Auto form feed
i. 0 sec.
ii. 1 sec.
iii. 2 sec. (Default)
iv. 3 sec.
v. 4 sec.
vi. 5 sec.
m. Form feed length
i. 0 mm
ii. 1 mm
iii. 2 mm
iv. 5 mm
v. 10 mm
vi. 20 mm
vii. 30 mm
viii. 50 mm (Default)
n. Grey scale printing
i. On (optional)
ii. Off
o. Acceleration
i. Slow
ii. Medium
iii. Fast
iv. Disable (Default)
p. Printing speed
i. 25%
ii. 50%
iii. 75%
iv. 100% Default)
v. Disable
q. Burn strobe dark
i. 0 (Default)
ii. 1
iii. 2
iv. 3
v. 4
28-03-2003 Page 2-10 of 53
vi. 5
vii. 6
viii. 7
ix. 8
x. 9
r. Burn strobe light
i. -1
ii. -2
iii. -3
iv. -4
v. -5
vi. -6
vii. -7
viii. -8
ix. -9
Settings will be effective upon turn off and on.
MAN607-S
2.6 Serial Input/Output
If BUSY control is selected:
When 236 bytes of data have been stored in the input buffer, the SBUSY
signal becomes high to request that the computer temporarily stop sending
data. When the amount of data stored in the input buffer becomes 235
bytes or less, the SBUSY signal changes to low to request that the host
device continue data transfer. Up to 16 bytes of input data are guaranteed
after the SBUSY signal has become high. When an error occurs, the
SBUSY signal becomes high. Data input is prohibited until the error is
cancelled.
If Xon/Xoff control is selected:
When 188 bytes of data has been stored in the input buffer, Xoff (1316) is
output through the TxD terminal to request that the host device temporarily
stops sending data. When the amount of data stored in the input buffer
becomes 124 bytes or less, Xon (1116) is output to request that the
computer continues data transfer. Up to 64 bytes of the input data are
guaranteed after
Xoff has been output. When an error occurs, the Xoff signal is output to
prohibit the data input.
When the error is cancelled, Xon is output.
2.6.1 Serial data transfer
The PRN607-S transfers various data other than the Xon and Xoff codes
which are output when controlling Xon and Xoff.
Regardless of whether the input mode is serial or parallel, the following
data is transferred through the TxD terminal.
(a) Error codes when a hardware error occurs at initialisation
28-03-2003 Page 2-11 of 53
MAN607-S
(b) The data when executing the Vhead voltage response
(c) The data when the error status response is set and an error occurs
(d) The data when executing the execution response request
(e) The data when executing the remaining RAM capacity response
(f) The data when executing the environmental temperature response
At the selection of serial input, data (b) through (f) is transferred according
to the transfer conditions, which are set using the function switches.
However, the hardware error code (a) has the same conditions as those for
parallel input.
When transferring data, data control by SBUSY and Xon/Xoff is not
executed and the data is transferred with no conditions.
All of the transmission conditions of serial data transfer for sending
hardware error codes are fixed at the selection of parallel input as follows:
Baud rate: 115.200bps
Parity: none
Bit length: 8 bit
Stop bit: 1 bit
2.6.1.1 Serial input/output port
Serial data output (TxD)
When Xon/Xoff control is selected, the Xon/Xoff signal is output.
Data is output according to the transmission conditions, which are set
by the function switches.
All response data is output.
Serial data input (RxD)
Data input port
Data is input from the host device according to the transmission
conditions, which are set using the function switches.
Serial busy (SBUSY)
Indicates whether or not the PRN607-S is ready to receive data.
When the SBUSY signal is low, data can be input.
When Xon/Xoff control is selected, SBUSY is always low.
2.6.2 Setting functions
Error processing when receiving serial data
The PRN607-S receives and checks serial data according to the
transmission conditions.
When the PRN607-S has received one byte of data without errors, the data
is stored in the input buffer.
If there are any errors, the following data is stored in the input buffer
according to the type of error.
Error type Error code
Parity error (!: 2116)
28-03-2003 Page 2-12 of 53
Framing error (?: 3F16)
If the input data cannot be printed correctly and instead “!” or “?” is printed,
the transmission conditions between the host device and the PRN607-S
most likely does not match. If this happens, adjust the conditions so that
they match.
2.6.3 Thermal Head Control
Data Transfer to the Thermal Head
The PRN607-S transfers one dot line of data at 4 Mbps synchronized with
the CLOCK signal.
The data is transferred in order to the shift register inside the thermal head
from the left (when facing the paper feed direction).
The transferred data is then transferred by the head latch signal to the latch
register inside the thermal head. Turning on the head strobe signal initiates
printing of one dot line of data on the thermal paper.
MAN607-S
2.6.4 Thermal Head Drive Operation
Generally, when the line thermal head is operating, the line is divided into
several blocks, which are activated one after another in succession.
For the line thermal head of the FTP607MCLxxx printer mechanism, the
line is divided into 3 blocks called physical blocks, 64 dots with each. A
strobe signal (DST1 to DST3) is allocated to each physical block to activate
it. To drive the head, physical blocks are activated in groups. The group of
physical blocks is called a logical block.
For the PRN607-S either dynamic division or fixed division can be selected
as the method of division for logical blocks. This selection is made through
a function. See settings for more information.
2.6.5 Peak power limitation
The PRN607-S counts the number of dots activated in each physical block
and groups the physical blocks into logical blocks to print a single dot line
so that the number does not exceed the specified maximum number of
activated dots. The PRN607-S determines logical blocks each time it prints
a single dot line.
In dynamic division, in order to avoid unclear printing, at the first step of the
motor the thermal head is driven and at the second step the paper is fed.
Also, since the order of the printing blocks and printing speed are changed
in each dot line according to the content of the print data, print quality may
be lower than that in fixed division. If print quality is regarded as important,
printing in fixed division is recommended.
The maximum number of activated dots in the initialisation status is
specified using the function switches.
28-03-2003 Page 2-13 of 53
64 through 256 dots can, however, are set using the command for setting
the number of dynamic division dots.
When the maximum number of activated dots is 128 dots, and all of the
dots are driven, as shown in
2.6.6 Head Control Circuit
The PRN607-S has a function for measuring the resistance of the thermal
head connected to the FTP607MCLxxx.
The PRN607-S measures the resistance of the thermal head and detects
the errors at initialisation.
Based on the measurement, the PRN607-S determines how much energy
to apply. No adjustment is needed for replacing the FTP607MCLxxx to get
the best printing.
2.6.7 Head temperature measurement circuit
The thermistor is mounted on the FTP607MCLxxx to measure the
temperature of the thermal head.
The PRN607-S determines the energy to be applied to the head and also
checks for head temperature errors.
If the temperature of the thermal head is -10 °C or lower, or 80 °C or higher,
the PRN607-S stops driving and puts the printer in head temperature error
status. If the temperature of the thermal head is returned to from -5 °C to 75
°C, the printer goes to printable status.
MAN607-S
2.6.8 Vhead interrupt circuit
This circuit interrupts Vhead to prevent electrolytic corrosion of the thermal
head and to enable the detection of the resistance mentioned above.
Electrolytic corrosion may significantly shorten the life of the thermal head.
Thermal paper ordinarily contains electrolytic material to prevent sheets
from sticking to each other due to static electricity. If there is too much of
this electrolytic material, high temperatures and humidity cause the material
to ionise, resulting in electrolytic corrosion of the thermal head.
The PRN607-S turns the FET off and breaks the Vhead applied to the
thermal head during waiting status to prevent electrolysis corrosion of the
thermal head.
28-03-2003 Page 2-14 of 53
MAN607-S
3 Specifications
Default settings
Interface Serial RS232C, USB or IRDA
115.200 baud, 8 data bit, none parity, 1 stop bit, hardware
Data format serial
Data format USB
Data format IRDA
Command set I/F-COM
Transmission to host Requested status etc.
Printer supply 18V to 24V DC
Power on self test Feed
Voltage compensation Burn time
Current consumption Operating 130mA, Printing up to XA @ 24V (TBD)
Printing speed 100mm/sec FTP629MCLXXX, 100mm/sec FTP639MCLXXX and
Fontset Western (Code 850, char 32-159)
Character size 8x14, 8x28, 16x14, 16x28, 16x56, 32x28, 32x56, 64x112
Character type Normal, Bold, Underline, Italic, Reverse (white on black)
Default font 16x28
Paper detect Digital
Graphics Normal / Compressed
Auto load 80mm
Form feed 50mm
Line feed LF
Maximum dimensions Width 77mm, Depth 50mm, Connected height 15mm
Mounting holes Width 71mm, Depth 44mm, Diameter 3.3mm
Connectors TBD
Weight 25g
Temperature
Shock 100G XYZ
EMC Emission: E-Field EN50081-1-1, Conducted EN50081-1-2
Immunity: E-field EN50082-1-1, Conducted EN50082-1-2, Over voltage EN50082-1-3
ESD Contact discharge 4kV, air discharge 8kV
Drivers Windows 9x, Windows CE, Windows NT, Linux, Windows2000 and Windows XP
Approvals CE, UL
Accessories Serial Interface cable: CBL-002, 9pol SubD, female
Power cable: CBL-025
handshake. Baud rate can be changed by software.
USB Printer class specification.
http://www.usb.org/developers/docs
IRDA (Ircomm specifications)
http://www.irda.org/standards/pubs/ircomm10.pdf
Storage -40ºC to +85ºC 0-90 Operating 0C to +85ºC 10-90%RH
28-03-2003 Page 3-15 of 53
4 Function
4.1 General
Notice, when data is sent from the external equipment to the printer
controller, all data has to be sent as binary file. If data is being sent as a
character file, and some data in the file is equal to EOF, the rest will not be
received.
4.2 Serial communication.
Standard communication is;
Baud rate; 115.200 Baud
Data bits = 8
Stop bits = 1.
Parity = None
Flow control = Hardware handshake
Baud rate can be changed. See setting for more information.
MAN607-S
4.3 USB communication.
Build in USB interface is 100% compliant to USB 1.1 and fully approved by
the USB organisation. For more details please contact I/F-COM.
By plug USB cable - Host system will recognise I/F-COM interface board.
Before connecting USB cable please set USB port as offline. Interface
board will automatically online USB port. Data cannot be send from
interface board to host. USB is not a bi-directional communication.
4.4 IRDA communication.
PRN607-S is prepared for IRDA via connector for IRDA transmission.
Please contact I/F-COM for more information.
28-03-2003 Page 4-16 of 53
4.5 Firmware upgrade.
If firmware needs to be changed, alternative firmware can be downloaded.
Please contact I/F-COM for firmware upgrade or changes.
The steps to download an alternative firmware in DOS are the following.
These steps only work for a serial connection, look further down how to do
it with USB.
1. Power the system off.
2. Disconnect printer.
3. Short circuit the pins “upgrade firmware”
4. Turn on printer
5. Write the following command “mode com1:9600,n,8,1”, this
command ensure that the serial port is at a known state.
6. Write the following command “xmode 1 +”, this command sets the
baud rate to 115.200, the xmode program can be downloaded from
the I/F-COM web site
http://www.if-com.com/data/drivers/xmode.zip
7. Run the following command, “copy “filename” /b com1”. The filename
represents the path and the filename of the new firmware file. This
file can be downloaded from website, or can be emailed by I/F-COM.
I/F-COM also offers a Windows utility program in order to download
firmware through serial port. Visit www.if-com.com for more information.
For further information about downloading with the driver, can be found
in the driver installation guide.
MAN607-S
4.6 Auto form feed
When paper no paper is present, it is possible to form feed new paper
automatic. While thermal head is down, place the paper at the roller.
After 2 seconds (default) the paper will be pulled in automatically.
Form feed wait time is 2 sec (default), but can be changed by a command.
28-03-2003 Page 4-17 of 53
4.7 Character design
The following figures describes the design of different types of characters
(small):
4.7.1 Normal Character.
MAN607-S
4.7.2 Low Character
4.7.3 Underline
When underline characters are printed the last line in the character matrix
will be marked.
4.7.4 Bold
When bold characters are printed the character is or with itself shifted right.
28-03-2003 Page 4-18 of 53
4.7.5 Reverse
When reverse characters are printed the character matrix will be negated.
4.7.6 Italic.
When Italic characters are printed every line will be shifted the following
number of dots to the right:
(Line number from bottom)/4
4.7.7 Font sizes.
Font Width Height
Small Normal Normal
Low Double Normal
Narrow Normal Double
Normal Double Double
Wide Double Quadruple
High Quadruple Double
Large Quadruple Quadruple
Xlarge Octuple Octuple
When the size is normal or greater a build in smooth function will smooth
the characters.
MAN607-S
28-03-2003 Page 4-19 of 53
4.8 Printer commands
I/F-COM simple command set is default command set however optional
command set can be downloaded. See appendix for additional information.
4.9 I/F-COM simple command set.
The following commands are use when communicating with the printer
controller. All other commands is ignored
4.9.1 Small Font
[Name] Small Font (8x12)
[Format] ASCII NUL
Hex 00
Decimal 0
[Description] Chooses small font from the current print position.
MAN607-S
4.9.2 Low Font
[Name] Low Font (16x12)
[Format] ASCII SOH
Hex 01
Decimal 1
[Description] Chooses low font from the current print position.
4.9.3 Narrow Font
[Name] Narrow Font (8x28)
[Format] ASCII STX
Hex 02
Decimal 2
[Description] Chooses narrow font from the current print position.
4.9.4 Normal Font
[Name] Normal Font (16x28)
[Format] ASCII ETX
Hex 03
Decimal 3
[Description] Chooses normal font from the current print position. This is
the default font after power up or reset.
28-03-2003 Page 4-20 of 53
4.9.5 Wide Font
[Name] Wide Font (32x28)
[Format] ASCII EOT
Hex 04
Decimal 4
[Description] Chooses wide font from the current print position.
4.9.6 High Font
[Name] High Font (16x56)
[Format] ASCII ENQ
Hex 05
Decimal 5
[Description] Chooses high font from the current print position.
4.9.7 Large Font
[Name] Large Font (32x56)
[Format] ASCII ACK
Hex 06
Decimal 6
[Description] Chooses large font from the current print position.
MAN607-S
4.9.8 Xlarge Font
[Name] Xlarge Font (64x112)
[Format] ASCII BEL
Hex 07
Decimal 7
[Description] Chooses Xlarge font from the current print position.
4.9.9 Line Feed
[Name] Line Feed
[Format] ASCII LF
Hex 0A
Decimal 10
[Description] When the printer controller receives this byte the text data
4.9.10 Barcode on
[Name] Barcode on
[Format] ASCII VT
Hex 0B
[Type] Barcode 39
[Description] Turns the barcode on until non-barcode character received.
[Barcode char.] Space , $ , % , * , + , - , . , / , 0-9 , A-Z
in the buffer will be printed
Decimal 11
28-03-2003 Page 4-21 of 53
[Notes] The barcode 39 must start and end with the character ‘*’.
4.9.11 Feed Forward
[Name] Feed Forward
[Format] ASCII FF
Hex 0C
Decimal 12
[Description] When this command is received the printer will print
MAN607-S
This character is the start and stop character in barcode 39,
and the ‘*’ can only be used as start and end character.
If the barcode length exceeds the paper size the last
barcode character will not be written as barcode. In that
case the barcode cannot be read because the last
character will not be ‘*’
whatever data it has in the buffer and feed forward 50mm
4.9.12 Reverse off
[Name] Reverse off
[Format] ASCII SO
Hex 0E
Decimal 14
[Description] This command will switch off reverse printing
4.9.13 Reverse on
[Name] Reverse on
[Format] ASCII SI
Hex 0F
Decimal 15
[Description] This command will switch on reverse printing
4.9.14 Underline off
[Name] Underline off
[Format] ASCII DLE
Hex 10
Decimal 16
[Description] This command will switch off underline printing
4.9.15 Underline on
[Name] Underline on
[Format] ASCII DC1
Hex 11
Decimal 17
28-03-2003 Page 4-22 of 53
[Description] This command will switch on underline printing
4.9.16 Bold off
[Name] Bold off
[Format] ASCII DC2
Hex 12
Decimal 18
[Description] This command will switch off bold printing
4.9.17 Bold on
[Name] Bold on
[Format] ASCII DC3
Hex 13
Decimal 19
[Description] This command will switch on bold printing
MAN607-S
4.9.18 Italic off
[Name] Italic off
[Format] ASCII DC4
Hex 14
Decimal 20
[Description] This command will switch off italic printing
4.9.19 Italic on
[Name] Italic on
[Format] ASCII NAK
Hex 15
Decimal 21
[Description] This command will switch on italic printing
4.9.20 Initialise Printer
[Name] Initialise
[Format] ASCII SYN
Hex 16
Decimal 22
[Description] When the printer controller receives this byte a reset of the
printer will be initialised. This command can be treated
even if buffer is full.
28-03-2003 Page 4-23 of 53
4.9.21 Request Software version
[Name] Request software version
[Format] ASCII ETB
Hex 17
Decimal 23
[Description] When the printer controller receives this byte the software
version will be transmitted. This command can be treated
even if buffer is full.
4.9.22 Request Status
[Name] Request status
[Format] ASCII CAN
Hex 18
Decimal 24
[Description] When the printer controller receives this byte a status byte
will be transmitted. This command can be treated even if
buffer is full.
The bit definitions is as follows
Bit Status 0 1
0 Near end Logic level is low Logic level is high
1 Paper Present Absent
2 Temperature Not too hot Head too hot to print
3 Head Closed Open
4 Paper Jam No error Error
5 Rxerror No error Rx error
6 Buffer Not full. Full (less than 16 bytes left)
7 Always 1.
MAN607-S
4.9.23 Request Analog voltage.
[Name] Analog voltage
[Format] ASCII EM
Hex 19
Decimal 25
[Description] When the printer controller receives this byte the digital
value of the head voltage will be transmitted. This
command can be treated even if buffer is full
28-03-2003 Page 4-24 of 53
4.9.24 Request Temperature
[Name] Request Temperature
[Format] ASCII SUB
Hex 1A
Decimal 26
[Description] When the printer controller receives this byte the digital
value of the head temperature will be transmitted. This
command can be treated even if buffer is full
4.9.25 Sub command set
[Name] Sub command set
[Format] ASCII ESC n
Hex 1B n
Decimal 27 n
[Range] n: [-128;127]
[Description] The n is the commands in the sub-set.
MAN607-S
4.9.26 Upgrade command
[Name] Upgrade command
[Format] ASCII ESC Z
Hex 1B 5A
Decimal 27 90
[Description] Only used by the I/F-COM A/S upgrade programs.
4.9.27 Set auxiliary output
[Name] Set auxiliary output
[Format] ASCII ESC p n
[Description] When this command is received then the
If n = 0, then the output will be set to off
Hex 1B 70 n
Decimal 27 112 n
auxiliary output can be set.
If n > 1 and < 254 then the output will be
turned on in n/4.096msec, and then turned
off again.
If n = 255, then the output will be turned on.
28-03-2003 Page 4-25 of 53
4.9.28 Automatic sending status
[Name] Automatic sending status
[Format] ASCII ESC a
Hex 1B 61
Decimal 27 97
[Description] When this command is sent once, then the board
4.9.29 Stop sending automatic status
[Name] Stop sending automatic status
[Format] ASCII ESC b
Hex 1B 62
Decimal 27 98
[Description] When this command is sent then it will turn off
MAN607-S
will transmit the status every time that it change
state.
transmitting status.
4.9.30 Color/Grey scale graphic
[Name] Colour / Grey scale graphic
[Format] ASCII ESC c n
Hex 1B 63 n
Decimal 27 99 n
[Description] When this command is sent then will the board
4.9.31 Enable saving data
[Name] Enable saving data
[Format] ASCII ESC d
Hex 1B 64
Decimal 27 100
[Description] This command will enable that the boards save
not feed. After the next graphic data (both
compression and not). The n is a percent of the
burn ratio, n can be from 0 to 15, and the burn
ratio is 100/15*n. This command is used by the
driver to make colour and grey scales printout.
values to the flash, this is made to ensure that a
wrong transmission not will change settings in
the board, remember to send the command
“Saving data to board”, to actual save the data.
28-03-2003 Page 4-26 of 53
4.9.32 Save data to board
[Name] Save data to board
[Format] ASCII ESC e
Hex 1B 65
Decimal 27 101
[Description] This command saves all settings to flash.
4.9.33 Change dot size
[Name] Change dot size
[Format] ASCII ESC f n
Hex 1B 66 n
Decimal 27 102 n
[Description] If n = 0x01, then the board is set to
MAN607-S
FTP607MCLXXX.
If n = 0x02 then is it set to LTP. The value is
saved to flash,
4.9.34 Change form feed length
[Name] Change form feed length
[Format] ASCII ESC g n
Hex 1B 67 n
Decimal 27 103 n
[Description] N represents the value in mm that is form feeded
4.9.35 Change baud rate
[Name] Change baud rate
[Format] ASCII ESC h n
Hex 1B 68 n
Decimal 27 104 n
[Description] N represents the new baud rate, legal values for
after the feed command is sent. The value is
saved to flash.
n = 1 to 255. The baud rate is calculated as
921600/n = new baud rate.
For instance 921600/8 = 115200baud.
The value is saved to the flash
4.9.36 Change form feed time
[Name] Change form feed time
[Format] ASCII ESC i n
Hex 1B 69 n
Decimal 27 105 n
28-03-2003 Page 4-27 of 53
[Description] N represents the time between that the board
4.9.37 Feed Paper
[Name] Feed Paper
[Format] ASCII GS n
Hex 1D n
Decimal 29 n
[Range] n: [-128;127]
[Description] When the printer controller receives this command the
MAN607-S
registry incoming paper, and to it starts feed the
auto form feed length. The time is calculated as
n * 50msec. The default setting is 2 seconds.
The value is saved to flash. Legal values for n
are between 1 and 255.
paper will be fed n-dot lines. If the value is negative a
reverse form feed will be made.
4.9.38 Compensate Burn time
[Name] Compensate burn time
[Format] ASCII RS n
Hex 1E n
Decimal 30 n
[Range] n: [-15;15]
[Description] When the printer controller receives this command the burn
time will be compensated. If a negative value is send the
printout intensity will be lighter and if a positive value is
send the printout intensity will be darker.
4.9.39 Bar code width setting
[Name] Bar code width setting
[Format] ASCII ESC e m
Hex 1B 65 m
Decimal 27 101 m
[Range] 2<=m
[Default] m=6
[Description] Parameter n is ignored
Parameter m is used to determine the dot width of the
narrow and wide bar lines. The wide bar lines is equal to m
dots and the narrow is equal to m/2 dots (rounded down).
28-03-2003 Page 4-28 of 53
4.9.40 Bar code height setting.
[Name] Bar code height setting
[Format] ASCII ESC h n
Hex 1B 68 n
Decimal 27 104 n
[Range] 1<=n<=255
[Default] n=60
[Description] Parameter n specifies the height of a bar code in dots.
4.9.41 Bar code printing
[Name] Bar code printing
[Format] ASCII ESC k m n d1 to dn
Hex 1B 6B m n d1 to dn
Decimal 27 107 m n d1 to dn
[Description] Parameter m specifies the type of bar codes to be printed.
Parameter n specifies no of barcode characters.
m(dec) Type of
Barcode
65 UPCA 11<=n<=12 48<=d<=57
67 EAN13 12<=n<=13 48<=d<=57
68 EAN8 7<=n<=8 48<=d<=57
69 Code39 Variable Space , $ , % , * , + , - , . , / , 0-9 , A-
72 Code128 Variable 0 to 105
UPCA: if n is 11 then the board calculate the checksum
EAN8: if n is 7 then the board calculate the checksum.
EAN13: if n is 12 then the board calculate the checksum
Code 39: The first and last character must be ‘*’. This is the
syntax for Code 39.
Code128. There is three subset of Code128 (Code128A,
Code128B and Code128C). The start character specifies
which character set to be used. The start character must be
either 103 (subset A), 104 (subset B), 105 (subset C).
The following table shows the value between data (d) and
barcode.
Number of
barcode
characters
MAN607-S
Value of d
Z
28-03-2003 Page 4-29 of 53
Code128 barcode table
‘d’ A B C ‘d’ A B C
0 Space Space 0 52 T T 52
1 ! ! 1 53 U U 53
2 “ “ 2 54 V V 54
3 # # 3 55 W W 55
4 $ $ 4 56 X X 56
5 % % 5 57 Y Y 57
6 & & 6 58 Z Z 58
7 ‘ ‘ 7 59 [ [ 59
8 ( ( 8 60 \ \ 60
9 ) ) 9 61 ] ] 61
10 * * 10 62 ^ ^ 62
11 + + 11 63 _ _ 63
12 , , 12 64 NUL ` 64
13 - - 13 65 SOH a 65
14 . . 14 66 STX b 66
15 / / 15 67 ETX c 67
16 0 0 16 68 EOT d 68
17 1 1 17 69 ENQ e 69
18 2 2 18 70 ACK f 70
19 3 3 19 71 BEL g 71
20 4 4 20 72 BS h 72
21 5 5 21 73 HT i 73
22 6 6 22 74 LF j 74
23 7 7 23 75 VT k 75
24 8 8 24 76 FF l 76
25 9 9 25 77 CR m 77
26 : : 26 78 SO n 78
27 ; ; 27 79 SI o 79
28 < < 28 80 DLE p 80
29 = = 29 81 DC1 q 81
30 > > 30 82 DC2 r 82
31 ? ? 31 83 DC3 s 83
32 @ @ 32 84 DC4 t 84
33 A A 33 85 NAK u 85
34 B B 34 86 SYN v 86
35 C C 35 87 ETB w 87
36 D D 36 88 CAN x 88
37 E E 37 89 EM y 89
38 F F 38 90 SUB z 90
39 G G 39 91 ESC { 91
40 H H 40 92 FS | 92
41 I I 41 93 GS } 93
42 J J 42 94 RS ~ 94
43 K K 43 95 US DEL 95
44 L L 44 96 FNC3 FNC3 96
45 M M 45 97 FNC2 FNC2 97
46 N N 46 98 SHIFT SHIFT 98
MAN607-S
28-03-2003 Page 4-30 of 53
47 O O 47 99 Code C Code C 99
48 P P 48 100 Code B FNC 4 Code B
49 Q Q 49 101 FNC 4 Code A Code A
50 R R 50 102 FNC 1 FNC 1 FNC1
51 S S 51
4.9.42 Black Mark
[Name] Set black mark parameters:
[Format] ASCII RS n
Hex 1E n
Decimal 30 n
[Range] n: [-15;15]
[Description] When Black mark is enabled:
[Format] ASCII ESC+205+3+97+m+n+o
Hex 1B CD 03 61 m n o
Decimal 27 205 3 97 m n o
[Range] m = Page length 1…255
[Description] At printer stop on black mark the paper will be forwarded
MAN607-S
n = Paper offset 1…255
o = Black mark length 1…255
the full length of the black mark. Paper out is detected if full
length of the Black Mark is feeded and sensor does not
detect paper.
At no paper in printer and printing is requested, form feed of
black Mark Length will be executed. At no paper detected
the printer will stop.
FF=0xC Feed paper forward until next Black Mark or rest of
page whatever comes first.
The following values can be set:
PAGE LENGTH (default 150mm) This value is the paper
length
PAPER OFFSET (default 2mm) This value is the length
between Black Mark and start of printing. Value must be
between 2 mm. and Page length – 2mm.
BLACKMARK LENGTH (default 15mm). This is the length
of the Black Marks.
The board can be set to transmit a ’B’ whenever the paper
is not detected at paper detect. This is typical when the
sensor encounters a Black Mark.
The following commands is used for enabling Black Mark
28-03-2003 Page 4-31 of 53
Default:
PAGELENGHT=150mm
PAPEROFFSET=2mm
BLACKMARK=120 (120/8=15mm)
ESC+205+1+98+n
n: Bit 0: if set the board will transmit ’B’ everytime paper is
not detected at the paper detector.
Bit 1: if set the Black Mark function is enable.
Default n = 0.
4.9.43 Graphic data – non compressed
[Name] Graphic data – non-compressed
[Format] ASCII US d1,d2,..,dX
Hex 1F d1,d2,..,dX
Decimal 31 d1,d2,..,dX
[Range] n: [0;255]
X=54 for FTP627MCLxxx, X=72 for FTP637MCLxxx,
[Description] When the printer controller receives this command the X
graphic bytes (d1-dX) will be printed in one dot line. The
MSB in d1 is the left most dot and the LSB in dX is the right
most dot.
MAN607-S
4.9.44 Graphic data – compressed
[Name] Graphic data – compressed
[Format] ASCII Y d1,d2,..,d(-Y)
Hex Y d1,d2,..,d(-Y)
Decimal Y d1,d2,..,d(-Y)
[Range] Y: [-X;-2]
n: [0;255]
X=54 for FTP627MCLxxx, X=72 for FTP637MCLxxx,
[Description] When the printer controller receives a byte that is –Y to –2
(Decimal 256-Y to 254) the following data is compressed
data. The number of compressed graphic bytes is the
negative value.
This means:
If Y = -10 (Decimal 246) the next 10 bytes is compressed
data.
The compressed data is as follows.
When a data byte is 0 (no dots activated) the next byte
received is the number of bytes that are 0. All other data is
send as non compressed.
28-03-2003 Page 4-32 of 53
A very few lines cannot be compressed. These will if you try
to compress them be longer than the non-compressed line.
These must therefore be send as non-compressed data.
4.9.45 Escape sequences, overview.
ESCAPE SEQUENCES,
ASCII FUNCTION
NUL Small Font
SOH Low Font
STX Narrow Font
ETX Normal Font
EOT Wide Font
ENQ High Font
ACK Large Font
BEL Xlarge Font
LF Line Feed
VT Print barcode
FF Forward feed
SO Reverse off
SI Reverse on
DLE Underline off
DC1 Underline on
DC2 Bold off
DC3 Bold on
DC4 Italic off
NAK Italic on
SYN Initialize printer
ETB Request software version
CAN Request status
EM Request analogue voltage
SUB Request temperature
GS+n Feed paper
RS+n Burn compensate
US+d1..dX Print graphic line
ESC+205+3+97+m+n+o Set black mark parameters
ESC e+m Bar code width setting
ESC k+m n+d1 to dn Bar code printing
ESC h+n Bar code height setting
MAN607-S
28-03-2003 Page 4-33 of 53
5 Maintenance
5.1 Daily use
Printer and interface board must be switch off while in idle mode.
5.2 Store/Transport
The product has to be stored under ESD safe conditions, and to be packed
safely during transportation.
MAN607-S
28-03-2003 Page 5-34 of 53
6 Specifications
6.1 Electrical Data
Voltage: 18-26VDC
Current: Maximum head current:Numbers of active dots * Vhead
1.500+/-15%
Maximum motor current: 1.000mA
Power up sequence: max. 10 msec. 10 – 90% Voltage applied
Power down sequence: max. 10 msec. 90 – 10% Voltage applied
6.2 Mechanical Data
Dimensions: Length, width, height: 77 mm* 50 mm * max. 15 mm
Including connectors.
Vibration: 100G XYZ
Shock: 100G XYZ
MAN607-S
6.3 Environmental Data
Operation: Temperature: -20°C- +85°C
Humidity : 10%-99% RH, without condensing
Storage: Temperature: -40°C - +85°C
Humidity: 0%-99% RH, without condensing
Transport: Temperature: -40°C - +85°C
Humidity: 0%-99% RH, without condensing
6.4 EMC & ESC
The printer controller is tested according to:
Emission: E-Field: EN50081-1-1
Conducted: EN50081-1-2
Immunity: E-field: EN50082-1-1
Conducted transients: EN50082-1-2
Over voltage: EN50082-1-3
Medical equipment: IEC601-1-2
ESD: 4 kV contact discharge against parts exposed to contact at normal
use; 8 kV air discharge.
28-03-2003 Page 6-35 of 53
6.5 Temperature Test
Temperature shock: (no voltage applied) -28°C to +100°C at 1 sec. 100
times: no damage.
MAN607-S
28-03-2003 Page 6-36 of 53
6.6 Connector Pin Assignment
6.6.1 Thermal Head connector
Thermal Head connector CN1: CF04301V000
Connector for use with following mechanisms:
FTP627MCLxxx
Pin Function Pin Function
1 PHK 16 GND
2 +5V 17 GND
MAN607-S
3 P1 18 GND
4 GND 19 /ST2
5 SW 20 /ST1
6 VH 21 LAT
7 VH 22 CLK
8 VH 23 NC
9 DI 24 VH
10 /ST3 25 VH
11 +5V 26 VH
12 TI1 27 /MB
13 GND 28 MB
14 GND 29 /MA
15 GND 30 MA
6.6.2 Thermal Head connector
Thermal Head connector CN2: CF04301V000
Connector for use with following mechanisms:
FTP637MCLxxx
28-03-2003 Page 6-37 of 53
Pin Function Pin Function
1 PHK 16 GND
2 +5V 17 GND
3 P1 18 GND
4 GND 19 TI
5 SW 20 /ST2
6 VH 21 /ST1
7 VH 22 LAT
8 VH 23 CLK
9 DI 24 VH
10 /ST3 25 VH
MAN607-S
11 /ST4 26 VH
12 +5V 27 /MB
13 GND 28 MB
14 GND 29 /MA
15 GND 30 MA
6.6.3 IRDA connector
IRDA connector CN3: B4B-ZR
Mating connector part number:
TBA
Pin 1 2 3 4
Function +5V TX RX GND
6.6.4 AUX input connector
AUX input connector CN4: 53324-0710
Mating connector part number: TBA
Pin Function Pin Function
1 LED1+ 4 LED2+
2 INPUT1 5 INPUT2
3 LED cathode 6 LED cathode
7 GND
28-03-2003 Page 6-38 of 53
The paper near end status, can be seen on the LED on the aux connector,
it can be reading through the status command, and if a driver is used, then
it can be reading in the port monitor: If paper jam is used, then will the
printer stop printing if this signal is going low, the value of this bit can be
seen on the LED on the aux output connector, it can be reading by a status
request, or if a driver is used, then it can be reading by the port monitor.
6.6.5 Power connector
Power connector CN6: 43045-0400
Pin 1 2 3 4
Function GND 24VDC GND 24VDC
6.6.6 USB connector
USB connector CN8: UBBR-04SW11
Pin 1 2 3 4
MAN607-S
Function N.C. USB- USB+ GND
6.6.7 AUX connector
Output connector CN8: 53324-0510
Mating connector: TBA
Pin 1 2 3 4 5
28-03-2003 Page 6-39 of 53
MAN607-S
Function GND Vcoil,
6.6.8 Cutter connector
Cutter connector CN5: B4B-KH-A
Mating connector part number:
TBA
Pin 1 2 3 4
Function Sense GND /CUT CUT
Max 24V
Coil,
max 1A
Anode Cathode
The LED will show these conditions
LED Means
Off No Error
Flash 1Hz Paper near end
Flash 2Hz Paper jam
On Both paper jam and near end
6.6.9 Serial connector
Connector type CN10: IDH10S1GN (Taitek)
Mating connector part number: FC10AGN (Taitek)
Pin Function Pin Function
1 NC 2 DSR
3 TX 4 CTS
5 RX 6 RTS
7 DTR 8 NC
9 GND 10 NC
28-03-2003 Page 6-40 of 53
6.7 Mechanical Drawings
MAN607-S
28-03-2003 Page 6-41 of 53
Defined Character Define
7 Appendix
7.1 Seiko compatible command set
7.1.1 Escape sequences, overview.
CR CR Carriage Return
ESC+ ‘ J ’ +n Print and Feed Forward
ESC+ ‘ j ’ +n Print and Feed Backward
ESC+ ‘ 2 ’ 16-dot Line Spacing
ESC+ ‘ 0 ’ 4-dot Line Spacing
ESC+ ‘A’+n or ESC+ ‘3’+n n-dot Line Spacing
ESC+ SP+n Character Spacing
ESC+ ‘ s ’+nl+nr Left/Right Character Spacing
ESC+ ‘ U ’+n Inverse Print
DC2+ ‘ Y’ +n Character Rotation
ESC+ ‘ - ’ +n Underline
SO Double-Width (with automatic reset ) ON
DC4 Double-Width (with automatic reset) OFF
ESC+ ‘ W ’+n Double-Width
ESC+ ‘ w ’+n Double-Height
ESC+ ‘ I ’+n Reverse
DC2+ ‘ F ’+n Font Size Selection
ESC+ ‘ t ’+n Character Set Select
ESC+ ‘ & ’ + s + e+ Font Data Downloaded Character Define
ESC+ ‘ % ’ + n Downloaded Character Select
DC2+ ‘ D ’+n Downloaded Character Area Operation
ESC+ ‘+’ + k1 + k2+ ESC+ ‘+’ + k1 + k2+ Font Data
FS+ ‘ 2 ’ + k1 + k2+ Font Data UserESC+ ‘ K ’ or FS+ ‘ & ’ Kanji Mode Specify
ESC+ ‘ H’ or FS+ ‘. ’ Kanji Mode Clear
DC2+ ‘ G ’+n User Defined Character Area Operation
DC2+ ‘ P ’ + s + e+ x + y + Font Data Option Font Define
DC2+ ‘ O ’+n Option Font Select/Deselect
DC2+ ‘ Q ’ Option Font Clear
DC3+ ‘ A ’ Ruler Line Buffer A
DC3+ ‘ B ’ Ruler Line Buffer B
DC3+ ‘ V ’ + Image Data Ruler Line Image
DC3+ ‘ D ’+nl+nh Define Ruler Line by Dot
DC3+ ‘ L ’+ml+mh+nl+nh Define Ruler Line by Line
DC3+ ‘ F ’+n1+n2 Define Ruler Line with Repeating Pattern
MAN607-S
28-03-2003 Page 7-42 of 53
DC3+ ‘ + ’ Ruler Line ON
DC3+ ‘ - ’ Ruler Line OFF
DC3+ ‘ P ’
DC3+ ‘ C ’ Ruler Line Buffer Clear
DC3+ ‘ (’
7.2 Fujitsu compatible command set
7.2.1 Escape sequences, overview.
HT Horizontal tab
LF Line feed with printing
FF Forms feed
ESC RS: Black-white reversed printing specification
ESC US: Black-white reversed printing cancellation
ESC !+n: Printing mode specification
ESC %+n:
ESC &+y+c1+c2+x+[d]k :
ESC *+m+n1+n2+[d]k : Bit image mode specification
ESC ?+n
ESC 2 1/6-inch line pitch setting
ESC 3+n Minimum-pitch-unit line pitch setting
ESC @ Printer initialisation
ESC A+n Line spacing setting
ESC C+n Page length (number of lines) setting
ESC D+[n]k+NUL Horizontal tab position setting
ESC J+n Printing and minimum-pitch-unit paper feed
ESC K+n Backward paper feed
ESC R+n International character specification
ESC c+1+n Internal processing setting
ESC d+n Printing and n-line feed
ESC e+n Printing and backward n-line feed
ESC s+n Printing speed setting
ESC t+n Character code table selection
ESC {+n Upside-down printing setting/cancellation
FS !+n Kanji printing mode collective specification
FS & Kanji printing mode specification
FS . Kanji printing mode cancellation
MAN607-S
Print One Dot Line after Printing Line
Buffer Data
Continuous Ruler Line Control Code
Input
Download character set
specification/cancellation (valid only when
optional memory is installed)
Download character definition (valid only
when optional memory is installed)
External registration character deletion (valid
only when optional memory is
28-03-2003 Page 7-43 of 53
MAN607-S
FS 9+n Detection function enable/disable setting
FS C+n Kanji code system selection
FS W+n
Kanji double height and width mode
specification/cancellation
GS < Mark detection execution
GS A+m+n
After-mark-detection head detection
distance setting
GS E+n Print quality setting
GS V+n+m Paper cutting
GS e+n+m Bar code width setting
GS h+n Bar code height setting
GS k+m+n+[d]k Bar code printing
GS w+n Bar code width magnification setting
FS *+n1+n2+[n]k
High speed collective image printing
specified
GS &+m+x+y1+y2+[n]k Registration of image data
GS '+m+n Print registered image data
FS E+n Correction of impressed energy
ESC V+n Right rotation 90º
GS a+n
Setting and cancellation of status
transmission.
FS r+n Parameter transmission
ESC EM+n
ESC X+n+m
Setting the amount of the feeding at
automatic paper feed
Setting the turning time of the motor
excitation
7.3 Command list description
Each command is explained using the following conventions:
[Name] Command name
[Function] Function of command
[Code] Control code represented in hexadecimal or decimal
notation.
[X]16 Hexadecimal notation
[X]10 Decimal notation
[Explanation] Explanation of command function
7.3.1 Horizontal tab
[Name] Horizontal tab
28-03-2003 Page 7-44 of 53
MAN607-S
[Function] The HT command moves the printing position to the
tab position.
[Code] [09]16
[09]10
[Explanation]
1. If the next horizontal tab position is not set, the HT command is
ignored.
2. If the next horizontal tab position is outside the printing area, the
printing position is shifted to the proper position by adding 1 to the
printing area width.
3. If an HT command is received when the print head is located at the
position to which the printing has been newly shifted by adding 1 to
the printing area width, buffer-full printing is executed. Then, the
horizontal tab operation is executed from the head of the next line.
4. The horizontal tab position is set with ESC D.
5. If characters are received when the print head is located at the
position to which the printing has been shifted by adding 1 to the
printing area width, buffer-full printing is executed. Then, the print
head moves to the leftmost column on the next line, and the received
characters are processed. When a line feed command such as LF is
received, data is printed and a line is fed. The print head then moves
to the leftmost column on the next line.
6. In backward printing, the tab indicates a position from the rightmost
column.
7.
7.3.2 Line feed
[Name] Line feed
[Function]
The LF command prints the data already contained in the print buffer, then
sets the next-data
receive position at the leftmost column on the next line.
[Code] [0A]16
[Explanation]
1. The LF command prints the data already contained in the print
2. In the initial state, the line spacing is set to approx. 1/8 inch.
3. When there is no data in the print buffer, only a line feed operation is
4. When different-height character typefaces are to be printed on the
[10]10
buffer, then sets the next-data receive position at the leftmost
column on the next line.
executed.
same line, these character typefaces are arranged so that their
bottom ends are aligned at the same level.
28-03-2003 Page 7-45 of 53
5. If line spacing during printing/line-feeding is shorter than the
7.3.3 Forms feed
[Name] Forms feed (new page)
[Function]
The FF command prints the data already contained in the print buffer, then
sets the next-data receive position at the leftmost column on the next page.
[Code] [0C]
[Explanation]
(1) The FF command feeds paper by the specified page length.
(2) In the initial state, the page length is set to approx. 143 mm. (44 lines).
(3) When cut-sheet printing is selected, the FF command executes the
following operations:
1. When the page length is set to 0 (page length cancellation) by using
2. ESC C, the paper is ejected.
3. Paper ejection is checked using the paper-out sensor. When the
4. The maximum paper ejection length is approx. 1m. If the paper-out
5. When paper with mark is selected, the FF command executes the
6. The data contained in the print buffer is printed, and a search is
7. The beginning of a line is set as the next printing position.
8. A paper with mark is selected with ESC c1.
MAN607-S
character height, a length equal to the character height feeds the
paper.
16
[12]10
detection is invalid, the paper ejection is checked.
state is not detected within the span of the 1-meter ejection, the
paper ejection terminates.
following operations:
made for the head of the next label.
28-03-2003 Page 7-46 of 53
7.4 APS compatible command set
7.4.1 Escape sequences, overview.
GS / n Set printing speed / Maximum peak current
GS D n Set print Intensity
ESC v Send printer status
ESC I Send printer identity
ESC @ Resets printer
ESC S Puts the printer in sleep mode
GS B n Serial Communication setting
GS b n Set parallel port Busy line hold time
ESC % n Select internal Character Set
ESC R n Select international character Set
ESC 3 n Set line spacing
ESC SP n Set character spacing
ESC ! n Set print mode
ESC { n Set/reset Rotated character
LF Line feed
CR Carriage return
ESC J n Feed paper (n dot lines) forward
ESC j n Feed paper (n dot lines) backward
CAN Cancel print data buffer (text mode)
ESC * n1 n2 n3 n4 n5 n6, data Print graphics
ESC $ n1,n2 Horizontal dot positioning
ESC V n1,n2,n3 data Horizontal bit image
ESC m Partial cut
ESC i Full cut
GS k n [Start] <data> NUL Print bar code
GS h n Barcode Height
GS w n Barcode magnification
GS H n Text position in Barcode
GS L n Set Mark length
GS T n Se Set TOF position
GS E TOF feed paper
GS X n1 n2 Set Mark to Cut Position
GS x n1 n2 Set Cut Line to Head Dot line Length
GS / n
Description: Set printing speed / Maximum peak current/ Dynamic
division
Format: <1Dh> <2Fh> <n>
MAN607-S
28-03-2003 Page 7-47 of 53
MAN607-S
Comments: n=1 to 32: (Default n=5) Software programmable
consumption (Dynamic division). The
maximum number of black dots which are
simultaneously heated is (n+1) x 8.
In Default Mode, n = 5.
Example: n=5 Maximum black dots heated: (5+1)*8=48.
Printer Peak consumption @5V: (0.3A (Stepper
Motor) + 5*48/160) = 1.8A
160 Ohms is the dot resistance.
GS D n
Description: Set print Intensity
Format: <1Dh> <44h> <n>
Comments: n=8Fh (127d) : (Default). Nominal print intensity
n>8Fh (127d) : Printout becomes darker
n<8Fh (127d) : Printout becomes lighter
(n from 0 to 255 (FFh)).
ESC v
Description: Send printer status
Format: <1Bh> <76h>
Comments: The printer returns a single byte that reflects the
status of the printer in accordance with the following
table:
28-03-2003 Page 7-48 of 53
7.5 ESC/POS compatible command set
7.6 Escape sequences, overview.
ESC c 4 Select Paper Near End Sensors to stop printing
HT Horizontal Tab
LF Print and Line feed
FF Print and return to standard Mode
CR Print and carriage return
DLE EOT n Real Time status transmission
DLE ENQ n Real time request to printer
CAN Cancel print data in page mode
ESC FF Print data in page mode
ESC SP n Set right side character spacing
ESC ! n Select print mode(s)
ESC$ nL nH Set absolute print position
ESC % n Select /cancel user-defined character set
ESC & y c1 c2 [x1
d1…dy * x1]…[xk
Define user defined characters
d1…dy * xk]
ESC * m nL n H [d]k Select bit image mode
ESC - n Turn underline mode on/off
ESC 2 Select 1/6-inch spacing
ESC 3 n Set line spacing
ESC = n Set peripheral device
ESC ? n Cancel user defined characters
ESC @ Initialize printer
ESC [n] k NUL Set horizontal tab position
ESC E n Turn emphasized mode on/off
ESC G n Turn on/off double strike mode
ESC J n Print and feed paper
ESC L Select page mode
ESC R n Select an international character set
ESC S Select standard mode
ESC T n Select print direction in page mode
ESV V n Turn 90°clockwise rotation mode on/off
ESC W xL xH yL yH
dxH dyL dyH
Set printing in page mode
ESC c 5 n Enable/Disable panel buttons
ESC c 3 n Select paper near end sensors to output end signals
ESC a n Select justification
ESC \ nL nH Set relative print position
ESC d n Print and feed n lines
MAN607-S
28-03-2003 Page 7-49 of 53
MAN607-S
ESC i Partial cut
ESC p m t1 t2 Cash drawer Output
ESC t n Select character Code table
ESC u n Transmit peripheral device status
ESC v Transmit paper sensor status
ESC { n Turns on/off upside-down printing mode
GS ! n Select character size
G S $ nL nH Set absolute vertical print position in page mode
GS * x y [d] x*y *8 Define download bit image
GS / m Print downloaded bit image
GS : Start / end macro definition
GS B n Turn white/black reverse printing mode
GS H n Select printing position for HRI characters
GS I n Transmit printer ID
GS L nL nH Set left margin
GS P x y Set horizontal and vertical motion units
GS V m n Select cut mode and cut paper
GS W nL nH Set printing area width
GS \ nL nH Set relative vertical print position page mode
GS ^ r t m Execute macro
GS a n Enable /Disable Automatic Status back
GS b n Turns smoothing mode on/off
GS f n
Select font for Human Readable Interpretation (HRI)
chararacters
GS h n Select bar code height
GS k m d1…dk NUL Print bar code
GS k m n d1…dn Print bar code
GS r n Transmit status
GS w n Set bar code width
28-03-2003 Page 7-50 of 53
MAN607-S
28-03-2003 Page 7-51 of 53
7.7 Optional sensor description
MAN607-S
Top view
PIN1
PIN2
PIN3
Bottom view
Please note that distance from top of sensor to paper must be Min 0,5mm
and Max 1,00mm
28-03-2003 Page 7-52 of 53
MAN607-S
Example showing how to connect PRS600 to AUX Input connector CN5 on PRN607-S
standard board.
RED
RED
WHITE
BLACK
RED
WHITE
BLACK
28-03-2003 Page 7-53 of 53
