Fujitsu PDP:V5350M0002GB User Manual

Operating manual

FUJITSU Tablet STYLISTIC V535

System

Congratulations on your pu

product from Fujitsu.

rchase of an innovative

The latest information about our products, tips, updates etc. can be found
on the Internet at: "

You can find driver updates at: "http://s upport.ts.fujitsu.com /download"

Should you have any technical questions, please contact:

• our Hotline/Service Desk (see the Service Desk list or visit:

"

http://support.ts.fujitsu.com/contact/servicedesk")

• Your sales partner

• Your sales office

We hope you enjoy working with your new Fujitsu system!

http://www.fujitsu.com/fts/"

Published by / Contact address in the EU

chnology Solutions GmbH

Fujitsu Te

Mies-van-der-Rohe-Straße 8

80807 Munich, Germany

www.fujitsu.com/fts/"

http://

"

Copyright

u Technology Solutions GmbH 2015. All rights reserved.

©Fujits

Publication Date

04/2015

Order No.: A26391-K411-Z320-1-7619, edition 1

FUJITSU Tablet STYLISTIC V535

Operating m anual

Innovative technology 7

Ports and controls 9

Important notes 12

First-time setup of your device 17

WorkingwiththeTabletPC 20

Accessories for your Tablet PC
(optional) 41

Security functions 59

Connecting external devices 62

Settings in BIOS Setup Utility 65

Troubleshooting and tips 66

Technical data 73

Manufacturer’s notes 76

Index 83

Remarks

Information on the product description meets the design specifications of Fujitsu and
is provided for comparison purposes. Several factors may cause the actual results to
differ. Technical data is subject to change without prior notification. Fujitsu rejects any
responsibility with regard to technical or editorial mistakes or omissions.

Trademarks

Fujitsu, the Fujitsu logo and STYLISTIC are registered trademarks of Fujitsu Limited or
its subsidiaries in the United States of America and other countries.

Microsoft and Windows are trademarks or registered trad emarks of the Microsoft
Corporation in the United States and/or other countries.

Adobe Reader is a trademark of Adobe Systems Incorporated.

All other trademarks specified here are the property of their respective owners.

Copyright

No part of this publication may be copied, reproduced or translated without
the prior written consent of Fujitsu.

No part of this publication may be saved or transferred by any electronic means
without the written approval of Fujitsu.

Contents

Contents

Innovativetechnology ................................................................. 7

Furtherinformation ...................................................................... 7

Notational conventions .................................................................. 8

Ports and controls ..................................................................... 9

Important notes ........................................................................ 12

Safetynotes ............................................................................ 12

Additional safety notes for devices with radio components . . . . . ............................. 12

Protecting the display screen ............................................................ 13

Energysaving .......................................................................... 13

Energy saving u nder Windows ....................................................... 13

Travelling withyour TabletPC ............................................................ 14

Beforeyou travel ................................................................... 14

Transporting the Tablet PC ........................................................... 14

Splashproof/dustproof ................................................................... 15

Cleaning theTabletPC .................................................................. 16

Further information on cleaning the Tablet PC ......................................... 16

Cleaning withdisinfectantwipes .......................................................... 16

First-time setu

Unpacking and ch
Selectingaloc
Mains adapter
Switchingont

Working withthe TabletPC ............................................................ 20

Battery charging indicator ................................................................ 20

Switching onthe Tablet PC .............................................................. 21

Programmingthe ON/OFF switch ..................................................... 21

Switching theTabletPC off .............................................................. 21

Handwriting recognition .................................................................. 22

Touchscreen ............................................................................ 23

Selectdisplayorientation(portrait or landscape orientation) ................................. 24

Using fingers . .......................................................................... 24

Actions with one finger (Windows 8.1 Modern) . ........................................ 25

Actions with one finger (Windows 8.1 Desktop) ........................................ 27

Actions with two fingers (Windows 8.1 Desktop) . . . .................................... 28

Tablet buttons .......................................................................... 30

Webcam ............................................................................... 30

Rechargeablebattery ................................................................... 31

Charging, caring for and maintaining the battery ....................................... 31

Removing andinstalling thebattery ................................................... 31

Using the power-management features ................................................... 35

Memorycards .......................................................................... 35

Supported formats .................................................................. 35

Inserting the memory card ........................................................... 36

Removing thememory card .......................................................... 37

SIM card(optional) ...................................................................... 38

Inserting the SIM card ............................................................... 38

Removing theSIM card .............................................................. 38

Wireless LAN / Bluetooth /LTE (optional) /NFCradio components .......................... 39

pofyour device .........................................................

eckingthe device ......................................................

ation .....................................................................

connecting . . . . ...........................................................

he device for the first time ..................................................

17

17
18
18
19

Fujitsu 3

Contents

Switching the wire less components on and off ......................................... 39

Setting up WLAN access ............................................................ 39

NFC (Near Field Communication) ..................................................... 39

Access via LTE (optional) ............................................................ 39

Ethernet and LAN (only multifunctional cradle) ............................................. 40

GPS ................................................................................... 40

Accessories for your Tablet PC (optional) . ............................................. 41

Your multifunctional cradle / your charging cradle (optional) . . . .............................. 42

Cradle components . . ................................................................ 42

Setting up thecradle ................................................................ 43

Adapterfor thecradle ............................................................... 44

Connecting the Tablet PC to the cradle . . . ............................................. 45

Disconnecting the Tablet PC from the cradle . . ......................................... 46

Smart Shell with holder for chip card reader (optional) . . . . .................................. 47

Smart Shell with magnetic strip reader (optional) . . ......................................... 49

Smart Shell with SmartCardreader(optional) ............................................. 51

Rugged frame (optional) . ................................................................ 53

Hand strap (optional) . . . . ................................................................ 55

Shoulder strap (optional) ................................................................ 57

Security functions ..................................................................... 59

Using the security lock (optional) . ........................................................ 59

Configuringpasswordprotection inBIOS Setup Utility ...................................... 60

SmartCard reader (optional) . ............................................................ 60

Installing the SmartCard reader . . . . . . ................................................. 60

Inserting the SmartCard ............................................................. 61

Connecting externaldevices ........................................................... 62

Connecting an external monitor . . ........................................................ 62

HDMI port (multifunctional cradle only) ................................................ 62

Connecting USB devices (Tablet PC or multifunctional cradle) .............................. 63

How to remove USB devices correctly ................................................ 63

Headphone port . ....................................................................... 64

Settings in BIOS Setup Utility . . ........................................................ 65

Starting theBIOS Setup Utility ........................................................... 65

Troubleshooting and tips .............................................................. 66

Forcedshut down ....................................................................... 66

Help ifproblems occur ................................................................... 67

The TabletPC’s date or time is incorrect .................................................. 67

Battery indicatordoes notilluminate ...................................................... 67

The TabletPC’s touchscreen remainsdark ................................................ 67

The display on the Tablet PC’s touchscreen is difficultto read. .............................. 68

The externalmonitorremainsblank ...................................................... 68

The externalmonitorisblank orthe image is unstable ..................................... 68

The Tablet PC does not start after switch on . . ............................................. 69

The TabletPCstops working ............................................................. 69

The printer does not print ................................................................ 69

The radio connection to a network doe s not work . ......................................... 70

The battery discharges too quickly ........................................................ 70

SmartCard reader is not recognise d. . . . . . ................................................. 70

SmartCard PINforgotten ................................................................ 70

4 Fujitsu

Contents

User and/or supervisor SmartCard lost ................................................... 71

SmartCard lost ......................................................................... 71

Error messages on thescreen ........................................................... 72

Technical data ......................................................................... 73

Tablet PC .............................................................................. 73

Rechargeablebattery ................................................................... 74

Mains adapter .......................................................................... 74

Mains adapter only for the TabletPC(10 W) ........................................... 74

Mains adapter for operation with the multifunctional or ch arging cradle (60 W, optional) . . . . 74

Multifunctional cradle (optional) . . . ....................................................... 75

Smart Shell w ith magnetic strip reader (optional) . . . ........................................ 75

Smart Shell with SmartCard reader (optional) . ............................................ 75

Rugged frame (optional) . . . . . . ........................................................... 75

Manufacturer’s notes .................................................................. 76

Disposal andrecycling .................................................................. 76

Declarationsof Conformity ............................................................... 76

CE marking ............................................................................ 76

Other certification markings .............................................................. 77

Regulatory notices ...................................................................... 77

Regulatory information for Tablet PCs without radio device . ............................. 77

DOC (IndustryCANADA)notices ..................................................... 78

FCC Regulatory information for Tablet PCs with radio device . . . ......................... 80

Index .................................................................................. 83

Fujitsu 5

Contents

6 Fujitsu

Innovative technology

Innovative technology

... and ergonomic design make your device a reliable and convenient companion.

The device boots very quickly, is ready for immediate use and offers a particularly
long operating time because of its high capacity battery.

The user-friendly "BIOS Setup Utility" offers powerful password prote ction functions which can be
used to control your Tab let PC’s hardware and protect your system better against unauthorised use.

Information on the connections and controls for your Tablet PC can be
found in chapter "

Ports and controls", Page 9.

Further information

The Windows drivers for your device can be found on our Internet site.
The factory installation of your device does not support any other operating
system. Fujitsu Technology Solutions accepts no liability whatsoever
if any other operating system is used.

Software oriented components of the se instructions refer to Microsoft products,
if they come within the scope of the delivery.

If you install other software products, pay attention to the operating
instructions of the manufacturer.

Fujitsu 7

Innovative technology

Notational conventions

Pay particular attention to text marked with this symbol. Failure to observe
these warnings could pose a risk to h ealth, damage the device or lead
to loss of data. The warra nty will be invalidated if the device becomes
defective throu gh failure to observe these warnings.

Indicates important informa

tion for the proper use of the device.

►



This font

This font

This font

"This font"

Key

This font

Indicates an activity that must be performed

Indicates a result

indicates data entered
the command line, e.g.
start a program (star

indicates information that is displayed on the screen by a program, e.g.:

Installation is complete.

indicates

• terms and texts used in a software interface, e.g.: Click on Save

• names of programs or files, e.g. Windows or setup.exe.

indicates

• cross-references to another section, e.g. "Safety information"

• cross-references to an external source, e.g. a web address: For more
information, go to "

• Names of CDs, DVDs and titles or designations for other materials,
e.g.: "CD/DVD Drivers & Utilities" or "Safety/Regulations" manual

indicates a key on the keyboard, e.g:

indicates terms and texts that are emphasised or highlighted, e.g.: Do

not switch off the device

using the keyboard in a program dialogue or at

your password (Name123) or a command used to

t.exe)

http://www.fujitsu.com/fts/"

F10

8 Fujitsu

Ports and controls

Ports and controls

This chapter presents the ind ividual hardware components of your device. It gives you
an overview of the device’s indicators and connections. Please familiarise yourself with
these components before you start to work with the device.

Front

1

2

3

4

5

7

10

9

8

7

6

1 = Ambient light sensor
2 = Microphone
3 = Webcam
4 = WebCam LED
5 = Ba ttery charging indicator

At the top on the device

1 2 3

1 = I ncrease volume button
2 = Decrease volume button

Fujitsu 9

6 = Port cover
7 = Loudspeaker
8 = Docking port cover
9 = Docking port for cradle
10 = W indows key

3 = ON/OFF switch

Ports and controls

Right side (with closed and open covers)

1

1

2 3 4

2 4

3

1 = Memory card slot (micro SD)
2 = Ch arging port (only for connection

of the mains adapter)

3 = USB port (USB 2.0)
4 = Headph one port

10 Fujitsu

Rear

Ports and controls

1

2

1

3

1

7

6

5

4

1

1 = Mounting points (scre w holes) for securing

hand or shoulder strap

2 = Battery compartment with cover, SIM card

slot (optional) under the battery

3 = O pen ing for easy remo val of the

battery cover

Fujitsu 11

4 = NF C (Near Field Communication)
5 = Microphone
6 = Camera light
7 = Webcam

Important notes

Important notes

ImportantnotesNotes

Safety notes

SafetynotesNotes

This chapter conta ins essential safety information which must be followed when working
with your Tablet PC. The other notes provide useful information on your Tablet PC.

Please follow the safety notes provided in the "Safety/Regulations" manual
as well as the safety notes given below.

Please pay special attention to the sections in the manual marked
with the symbol on the left.

When connecting and disconnecting cables, observe the relevant
notes in this operating manual.

Read the information on the ambient conditions i n the "
chapter and the information in the "First-time setup of your device", Page 17 chapter
before preparing your Tablet PC for use and switching it on for the first time.

When cleaning the device, please observe the relevant notes in the
section "

Pay attention to the additional safety notes for devices with radio components
provided in the "Safety/Regulations" manual.

Cleaning the Tablet PC", Page 16.

Technical data", Page 73

This Tablet PC c
If you have que
environment,

omplies with the relevant safety regulations for data processing equipment .

stions as to whether you can set up the Tablet PC in the intended

please contact your sales point or our hotline/help desk.

Additional safety notes for devices with radio com ponents

Radiocomponent:WirelessLAN:Bluetooth,safetynotes

If a radio component (Wireless LAN/ Bluetooth, UMTS/LTE) is integra ted in your Tablet PC, you
must be sure to observe the following safety precautions when using your Tablet PC:

• Switch off the radio components when you are in an aircra ft or driving in a car.

• Switch off the radio components when y ou are in a hospital, an operating room or near a medical
electronics system. The transmitted radio waves can impair the operation of medical devices.

• Switch off the radio components when you let the device get near flammable
gases or into hazardous environments (e.g. petrol station, paintshops), as the
transmitted radio waves can cause an explosion or a fire.

For information on how to switch radio components on and off, see chapter

Switching the wirele ss components on and off", Pa ge 39.

"

12 Fujitsu

Important notes

Protecting the display screen

Depending on your device configuration, your device may not be waterproof. If this
is the ca se, do not pour liquids on the device, and do not clean it with a wet cloth.
Do not place items on the top of the d isplay, or damage may occur.

The warranty does not cover a scratched screen.

Energy saving

NotesEnergyEnergysaving

If you will not be using your Tablet PC, switch it off. Switch off any connected external devices
when they are not in use. If you use the energy saving functions, the Tablet PC uses less
power. You will then be able to work for longer be fore having to recharge the ba ttery.

Power efficiency is increased and environmental pollution reduced. You
save money and help protect the environment.

Energy saving under Windows

► Make use of the power management features (see ""Using the power-management features",

Page 35").

Your tablet PC is equipped with an eMMC memory. Please note that this
technology does not support Hibernate mode.

Fujitsu 13

Important notes

Travelling with your Tablet PC

MobileoperationNotesTransportationTabletPC

Please observe the points listed below when travelling with your Tablet PC.

Before you travel

► Back up important data stored on your hard disk.

Tablet PCTravel,TabletPC

► Switch off the radio comp

connection, it is also po

onent for data security reasons. With data traffic via a wireless

ssible for unauthorised third parties t o receive data.

Information on activat
for your radio componen

► If you wish to use your Tablet PC during a flight, check with the airline whether this is allowed.

ing data encryption is provided in the documentation

t.

When travelling in other countries

► If you are travelling abroad, check that the mains adapter can be operated with the

local mains voltage. If this is not the case, obtain the appropriate mains adapter
for your Tablet PC. Do not use any other voltage converter!

► Check whether the local mains voltage and the power cable are compatible. If this is

not the case, buy a power cable that matches the local conditions.

► Enquire with the corresponding government office of the country you will be

travelling in as to whether you may operate the radio component integrated in
your Tablet PC there (also see "

Transportin

► Switch off the Tablet PC.
► Unplug the mains adapter and all external devices from the power socket.
► Disconnect the mains adap ter cable and the data cables for all external devices.
► To protect against damaging jolts and bumps, use a Tablet PC carrying

case to transport your Tablet PC.

g the Tablet PC

Protect the Tablet PC from severe shocks and extreme temperatures
(e.g., direct sunlight in a car).

CE marking", Page 76).

14 Fujitsu

Splashproof/dustproof

Your Tablet PC is certified according to IP65. However, the slot covers m u st be
securely sealed in the event of contact with water or dust.

It is important to know that your warranty does not cover defects caused
by improper use of your device, including use in environment s where the
relevant IP rating limitations are exceeded.

Important notes

Protection class IP65 st
with water for at least 3
rate of 12.5 l water per m

To ma ke sure that the de
covers of the device mu
penetrate the Tablet

If the Tablet PC come
mud, it must be wipe

Note that accessories may not be splashproof and dustproof.

ipulates that the tablet can be operated normally after it has been sprayed

minutes through an opening of 6.3 mm / 0.25" diameter and a flow

inute at a distance of approximately 3 m / 118.11".

vice remains splashproof and dustproof, all

st always remain closed. Otherwise, water could

PC and cause a malfunction.

s into contact with salt water, soft drinks or

d off immediately.

Fujitsu 15

Important notes

Cleaning the Tablet PC

Always switch your Tablet PC off for cleaning.

Your Tablet PC is protected against splash water and dust, but you should
nonetheless prevent water or dirt from penetrating the Tablet PC and
prevent accessories from becoming wet or dusty.

The mains adapter, cradle and other accessories are neither wate rproof nor dustproof. D o
not use them in a bathroom, in a very moist environment or in places where it may rain.

Only use cleaning products designed for computers. Conventional household cleaners
and polishes can damage the lettering on the Tablet PC, the paint or the Tablet PC itself.

Only clean the display surface with a very soft, slightly damp cloth. Rough
rubbing with a dry cloth can damage the screen. Residual water drops
or dirt on the screen can cause spots.

If the Tablet PC is cleaned with alcohol, thinners, petrol or solvent, the
lettering may become illegible and the paint may blister.

Thecasingsurface
useadampclothso

Do not clean the re

Further inform

The Tablet PC do es not float.

If the Tablet PC is exposed to water or other liquids with its connections open, liquid can
penetrate the Tablet PC and cause a malfunction. Do not continue to use the Tablet
PC. Switch it off and contact our hotline/our service desk (see enclosed list of service
desks or go to our website at: "

s can be cleaned with a dry cloth. If the Tablet PC is particularly dirty,

aked in water with a mild cleaning agent, and well wrung out.

cesses d irectly with cotton buds.

ation on cleaning the Tablet PC

http://support.ts.fujitsu.com/contact/servicedesk").

Cleaning with disinfectant wipes

For proper use of the disinfectant wipes, please also rea d the manufacturer’s instructions.

Before use, please test the disinfectant wipe on a small area of the Tablet
PC. Some medical disinfectant wipes may leave residue on the Tablet PC
which is difficult to remove again, or dry out quickly. Therefore dispose of
the wipes after one use and do not reuse them.

16 Fujitsu

First-time setup of your device

First-time setup of your devic

First-timesetu pGettingstarted

On delivery, the battery can be found in the battery compartment or in the accessories kit.
The battery must be charged if you want to operate your device using the battery.

When used on the move, the built-in battery pro vides the device with the necessary po wer. You
can increase the operating time by using the available energy-saving functions.

For instructions on how to connect external devices (e.g. mouse, printer) to your Tablet
PC, please refer to the operating manual for your device.

Unpacking and

► Unpack all the individual parts.

► Check your

Please read the chapter "Important notes", Page 12.

If your device is equipped with a Windows operating system, the necessary
hardware drivers and supplied software are already pre-installed.

Beforeyouswitchonthedeviceforthefirst time, connect it to the mains voltage
using the mains adapter, see "
adapter must be connected during the entire installation process.

A system test is performed when your device is first switched on. Various messages
can appear. The display may remain dark for a short time o r may flicker.

Please follow the instructions on the screen.

NEVER switch off your device during the first-time setup process.

Mains adapter connecting", Page 18.Themains

checking the device

Should you discover any damage that occurred during transportation,
notify your local sales outlet immediately!

PackagingTransport

device for any visible damage which may have occurred during tra nsp ortation.

e

You m a y n e

Fujitsu 17

ed the packaging in the future, if you need to transport your device.

First-time setup of your device

Selecting a location

SelectingalocationDeviceMainsadapt er

Select a suitable location for the device before setting it up. Follow
the instructions below when doing so:

• Never place the device or the mains adapter on a heat-sensitive surface.
The surface could be dama ged as a result.

• Never place the device on a s oft surface (e. g. carpeting, upholstered furniture,
bed). This can result in damage caused by overheating.

• The underside of the device heats up during normal operation. Prolonged contact
with the skin may become unpleasant or even result in burns.

• Place the device on a stable, flat, non-slippery surface. Please note that the
rubber feet of the device may mark certain types of delicate surfaces.

• Keep other objects at least 100 mm / 3.9 7" away from the device and
its mains adapter to ensure adequate ventilation.

• Do not expose the device to extreme environmental conditions. Protect
the device against dust, moisture and heat.

Mains adapter connecting

PreparingforoperationMainsadapter

Observe the safet

The supplied pow
which you purcha
for use in the co

y notes in the enclosed "Safety/Regulations" m an ual.

er cable conforms to the requirements of the country in

sed your device. Make sure that the po wer cable is approved

untry in which you intend to use it.

3

2

1

► Open the cover of the charging port as shown.
► Connect the charging connector of the power supply cable (1) to the Tablet PC.
► Connect the connector of the power supply cable (2) to the mains adapter.
► Plug the m ains adapter into the mains socket (3).

18 Fujitsu

First-time setup of your device

Switching on the device for the first time

Switchingonforthefirsttime

When you switch on the device for the first time, the supplied software is
installed and configured. Because this procedure must n ot be interrupted,
you should set aside enough time for it to be fully completed and connect
the device to the mains using the mains adapter.

During the installation process, DO NOT restart the device unless
you are requested to do so!

To make it easier to use yo
is pre-installed on the

ur device for the first time, the operating system

hard disk.

1

► Press the ON/OFF button (1) for about one second to switch the device on.
► During installation, follow the instructions on screen.

If a Window s operating system is installed on your device, you will find more information
on the system and drivers, help programmes, updates, manuals etc. on the device. This
information can also be found on the Internet at "

http://www.fujitsu.com/fts/support/".

You can find information and help on the Windows operating system functions
on the Internet at "

http://windows.microsoft.com".

If a Windows 8.1 operating system is installed on your Tablet PC, a tutorial is
automatically started when a new user logs on for the first time, which shows
you how to use the new fu nctions of Windows 8.1.

Fujitsu 19

Working with the Tablet PC

Working with the Tablet PC

TabletPC,operationTabletPC

This chapter describes the basics for ope rating your Tablet PC. You can find instructions
on how to connect external devices (e.g. mouse, flash memory) to the Tablet PC
in the chapter "

Battery charging indicator

StatusindicatorsSymbols

The ba ttery charging indicator (1) provides information on th e status of the power supply.

Connecting external devices", Page 62.

Please refer to the notes in "Important notes", Page 1 2.

1

Status / colour Description

Off The Tablet

Green The battery is fully charged, the Tablet PC is connected to the mains voltage.

Orange

Red

20 Fujitsu

The battery is being charged.

A fault h

PC is not connected to the mains voltage.

as occurred. The battery cannot be charged.

Working with the Tablet PC

Switching on the Tablet PC

TabletPC:switchingonPower-onindicatorSuspend/Resumebutton

1

► Press the ON/OFF button (1) for about one second to switch the device on.

Programming the ON/OFF switch

You can program th

Operating system Menu

Windows 8.1

e ON/OFF switch:

Windows 8.1 Desktop - Control Panel - Hardware
and Sound - Power Options

If you have ass
do so, in order
found in the c

igned a password, you must enter this when requested to

to start the operating system. Detailed information can be

hapter "

Security functions", Page 59.

Switching the Tablet PC off

Back up your data and close all applications before you switch off your
device. Otherwise data might be lost.

► Shut down the operating system correctly.

Ausschalten

or

► To change to connected standby mode, press the ON/OFF button for < 2 seconds.

or

► To d i s p

or

► If the Tablet PC does not switch off automatically, press the ON/OFF button

Fujitsu 21

lay the popup "Wipe downwards to switch off", press the ON/ OF F

n for > 2 seconds to < 10 seconds.

butto

for about 10 seconds (forced shutdown).

Working with the Tablet PC

Handwriting recognition

For detailed information on handwriting re cognition, see the documentation on your operating system.

Under Windows 8.1 you can set the required language under ControlPanel–
Time, Language and Region – Language.

22 Fujitsu

Working with the Tablet PC

Touchscreen

Touchsc reenNotes

High-quality LCD screens (T FT ) are installed in Fujitsu Tablet PCs. For technical reasons,
these screens are manufactured for a certain resolution. An optimum and sharp image can
only be ensured with the resolution intended for the particular screen. A screen resolution
which differs from the specification can result in an unclear image.

The screen resolution of your Tablet PC’s touchscreen is optima lly set at the factory.

Current production techno logy cannot guarantee an absolutely fault-free screen display. A few
isolated constantly lit or unlit pixels (picture elements) may be present. The maximum permitted
number of faulty pixels is stipulated in th e international standard ISO 9241-307 (Class 2).

Example:

A screen with a resolution of 1280 x 800 has 1280 x 800 = 1024000 pixels. Each pixel consists of
three subpixels (red, green and blue), so there are almost 3 million subpixels in total. According to ISO
9241-307 (class 2), a maximum of 2 light and 2 dark pixels and in addition 5 light or 10 dark subpixels
or an equivalent mix (1 light subpixel counts as 2 dark subpixels) are allowed to be defective.

Pixel

Subpixel

Cluster A cluster contain

Background lighting

LCD screens are operated with background lighting. The luminosity of the background
lighting ca n decrease over the period of use of the Tablet PC. H ow ever, you can
set the brightness of your screen individually.

A pixel consists of 3 subpixels, normally red, green and
blue. A pixel is th e smallest element that ca n be generated
by complete functionality of the display.

A subpixel is a separately addressable internal structure
within a pixel that enhances the pixel function.

s two or more defective pixels or

subpixels in a 5 x

5 pixel block.

Ambient light sensor

If your Tablet PC was shipped with the Windows operating system, the screen brightness
is regulated by the ambient light sensor according to the particular light conditions. This
results in optimum readability and longer battery life at the same time.

If your Tablet PC was shipped w ith Windows 8.1, the adaptive brightness setting is disabled. To
change the ambient light sensor settings, select Control Panel - System and Security - Power Options -
Change plan settings - Chan ge advanced power settings - Display - Ac tiva te adaptive brightness setting..

Select On to activate the adaptive brightness setting with the help of the ambient light sensor.

Synchronising the display on the touchscreen and an external monitor

In Windows 8.1 wipe your finger over the screen from the right-hand edge. The setting
Charms - Devices - Second screen opens. Select the desired output type.

Fujitsu 23

Working with the Tablet PC

Select display orientation (portrait or landscape orientation)

LandscapeorientationPortraitorientationDisplayorientation

You can choose to use either portrait or landscape orientation for the display.

Windows 8.1

You can change these settings und er Windows 8.1 Desktop - Control Panel ­Hardware and Sound - Windows Mob ility Center / Rotate screen.

To disable the automatic change betw een portrait and landscape formats, select Control
Panel – Appearance and Personalization – Display – Screen resolution.

Using fingers

You can execute certain commands by using your finger tip on the touchscreen o f your device.

24 Fujitsu

Working with the Tablet PC

Actions with one finger (Windows 8.1 Modern)

Action Description

Wipe your finger over the screen from the
right-hand edge.

► Open the Charms with system command s

(equivalent to pressing the Windows button +

C

button).

► Working with the mouse: Position the mouse

pointer at the bottom right-hand edge of the
screen.

Wipe your finger over the screen from the
left-hand edge.

Wipe your finger over the screen from the top
or bottom edge.

► Switch between the most recently used

applications (equivalent to pressing the
Windows button +

► Working with the mouse: Position the mouse

pointer at the bottom left-hand edge of the
screen.

► Open the App commands (equivalent to

pressing the Windows button +
Wipe from the top to the bottom of the screen
to dock or connect the current App.

► Working

Apptod

with the mouse: Right-click on the

isplay the App commands.

Ctrl

+ Space).

Z

button).

Fujitsu 25

Working with the Tablet PC

Action Description

Press and hold

► Keep your finger pressed on an object on the

screen to display a menu with further options.

► Workingwiththemouse:Movethemouse

pointer over the object to display a menu with
further options.

Taponanobject

► Tap your finger on an o

to open an App or a lin

bject on the screen
k or to execute a

command.

► Working with the mouse: Left-click on the

object.

Scroll / Move object / Swivel object ► Use this fun ction to scroll through lists or

websites or to swivel or move an object.

► Working with the mouse: Left-click on the

object, keep the mouse button pressed and
move / swivel the o bject or scroll.

26 Fujitsu

Working with the Tablet PC

Actions with one finger (Windows 8.1 Desktop)

Action Description

Selecting objects (click with the left mouse
button)

Starting programs (double-click with the left
mouse button)

Moving objects/windows (drag with left mouse
button pressed, Drag & Drop)

Opening a context menu (click with the right
mouse button)

Moving the cur

sor

► With your finger, tap once brieflyonthe

object.

► With your fi nger, tap twice briefly in quick

succssion on the program icon.

► Place your finger on the object/window,

keep your fingertip pressed against
the touchscreen and move the desired
object/window.

► Tap your finger on the desired item.

Keep your fingertip pressed against the
touchscreen.

The context me

► Position one finger on the touchscreen and

move your fingers in the desired direction.

nu appea rs.

Fujitsu 27

Working with the Tablet PC

Actions with two fingers (Windows 8.1 Desktop)

Action Description

Scrolling

► Position two fingers on the touchscreen.
► Move your fingers upwa

or

► Move your fingers downwards to scroll

down.

Rotating

rds to scroll up.

► Position your thumb on the touchscreen and

rotate the image clockwise or anticlockwise
using your index finge r.

28 Fujitsu

Action Description

Enlarge or reduce the view (zoom)

► Position two fingers on the touchscreen and

move them apart to increase the view.

or

► Place two fingers on the touch screen and

move them together to reduce the view /
zoom.

Blocking context-sensitive menus

► With two fingers, tap twice briefly in quick

succession on the touchscreen.

Working with the Tablet PC

Fujitsu 29

Working with the Tablet PC

Tablet buttons

Your Tablet PC is equipped with three tablet buttons.

1 2 3

No. Description Functions

1 Increase volume button Increase the volume

2 Decrease volume button Decrease the volume

3

ON/OFF switch Switching the dev

Webcam

Webcam

Your device has two WebCams: one on the front side of the device and one on the rear.

You may not be able to use the rear webcam cannot when a smart
shell accessory is mounted.

ice on and off

The WebCam has its own status indicator. The indicator lights up when the WebCam is switched o n.

Depending on the software used, you can use your Webcam to take p ictures,
record video clips or take part in web chats.

• The picture quality depends on the lighting conditions and the software being used.

• You can only operate the webcam with a particular application (e.g. a n Internet telephony
program or a video conferencing program which supports a webcam).

• When using the webcam the Tablet PC support must not wobble.

• The webcam automatically adjusts itself to the current light level. For this reason
the touchscreen may flicker while the light level is adjusted.

Further information on using the webcam and on the additional settings
which are possible for your webcam can be found in the help function
of the program which uses the webcam.

30 Fujitsu

Working with the Tablet PC

Rechargeable battery

RechargeablebatteryBatteryLife,batteryRechargeablebatteryRechargeablebattery

For mobile use, the built-in battery provides the Tablet PC with the necessary power.
You can increase the life of the battery by caring for the battery properly. The average
battery life is around 500 charge/discharge cycles.

You can extend the battery life by taking advantage of the available energy saving functions.

Charging, caring for and maintaining the ba ttery

BatteryBattery

The Tablet PC battery can only be charged when the ambient temperature is
between 5°C / 41°F and max. 35°C / 95°F.

You can charge the battery by connecting the Tablet PC to the mains adapter

Mains adapter connecting", Page 18).

(see "

If t he battery is running low you will see a warning message. If you do not connect the mains
adapter within a few minutes, your Tablet PC will switch off automatically.

Monitoring the battery charging level

er

BatteryBatterystatusmet

Windows also has a "Battery status meter" in the taskbar, for monitoring th e b attery status. When you
place the mouse pointer on the battery symbol, the system displays the state of charge of the battery.

Battery storage

BatteryBatterySelf-discharge,batteryChargingcapacity,battery

Store battery packs in a dry environ m ent at a temperature between 0°C / 32°F and 30°C / 86°F. The
lower the temperature at which the batteries are stored, the lower the rate of self-discharge.

If you will be storing batteries for a longer period (lon ger than two months),
the battery charge level should be approx. 30 %. To prevent exhaustive
discharge which would permanently damage the battery, check the level
of charge of the battery at regular intervals.

To be able to make use of the optimal charging capacity of the batteries, the battery
should be completely discharged and then fully recharged.

If you do not use the batteries for long periods, remove the m from the
device. Never store the batteries in the device.

The device cannot be operated without the battery.

Removing and installing the battery

Only use

Never u s

Make su

Never s
can mak

Fujitsu 31

batteries approved by Fujitsu for your tablet PC.

e fo rce when fitting or removing a battery.

re that no foreign bodies get into the battery connections.

tore a battery for longer periods in the discharged state. This

e it impossible to recharge.

Working with the Tablet PC

Removing the battery

► Turn the device over and place it on a stable, flat and clean surface. If necessary, lay an

anti-slip cloth on this surface to prevent the device from being scratched.

1

a

► Reach into the opening (a) with one finger and take off the battery cover

in the direction of the a rrow (1).

32 Fujitsu

Working with the Tablet PC

b

2

► Pull on the pulling aid (b) and lift the battery out of the battery compartment

in the direction of the a rrow (2).

Installing the battery

1

► Position the battery at the edge of the battery compartment and insert the

battery in the battery compartment (1).

Fujitsu 33

Working with the Tablet PC

2

► Insert the catches of the battery cover into the ope nings on the device.
► Close the battery compartment cover (2).

34 Fujitsu

Working with the Tablet PC

Using the power-management features

PowerPowerBattery

The Tablet PC uses less power when the power management features are enabled. You will
then be able to work longer when using the battery before having to recharge it.

Power efficiency is increased and environmental pollution reduced. By
choosing the best power options, you can make significant savings and
at the s ame time help protect the environment.

► Select the power managem

ent functions in your Control Panel.

► Select the Screen Saver in your Control Panel.

or

► Keep a finger pressed on the desktop to display the context menu. Configure the screen

saver under Change screen saver.

If you need further information about an option, you can get help with most settings by

?

pressing the

symbol in the up per right of the screen to open the Microsoft Help.

If you d o not intend to use you r Tablet PC for a long period of time:

► Exit the power saving mode if necessary via touching the screen or by switching on the

Tablet PC.

► Close all opened programs and completely shut down the Tablet PC.

Memory cards

Slot

Your Tablet PC is equipped with an integrated memory card reader. You can use
memory cards to increase the storage of your Tablet PC.

Observe the manufacturer’s instructions when handling the memory cards.

Memorycard

Supported formats

It suppor

•MicroSe

•MicroSDHC

•MicroSD

ts the following formats:

cure Digital (SD

TM

XC

Card)

Fujitsu 35

Working with the Tablet PC

Inserting the memory card

2

1

► Open the slot co

ver (1).

► Carefully slide the memory card into the slot (2). The label must be facing upward. Do not

apply any force, otherwise the delicate contact surfaces could be damaged.

Memorycard

► Close the slot

cover.

36 Fujitsu

Removing the memory card

Memorycard

To avoid any loss of data, always follow the correct procedure for removing the
card (see the documentation for your operating system).

► Open the slot cover.

Working with the Tablet PC

1

3

2

► Press the edge of the memory card so that the me mory card jumps (1) slightly out of the slot.
► Pull the memory card out of the slot i n the direction of the arrow (2).
► Close the slot cover (3).

Fujitsu 37

Working with the Tablet PC

SIM card (optional)

A SIM Card (Subscriber Identity Module) is a chip card which is inserted in a
mobile telephone or Tablet PC and, together with an integrated LTE module
(optional), enables access to a mobile radio network.

Please follow the instructions supplied by the provider when handling
the SIM card . If you do not feel the SIM card engage as you insert it,
use a pointed object to insert the SIM card.

Inserting the SIM card

► Remove th e battery, s ee "Removing t he b attery", Page 3 2.

► Insert the S IM card into the slot (1) as

shown and with the chip downwards.

1

► Install the battery again, see "

Installing the battery", Page 33.

Removing the SIM card

► Remove th e battery, s ee "Removing t he b attery", Page 3 2.

► Press the edge of the SIM card so that the

SIM card jumps (1) slightly out o f the slot.

► Pull the SIM card out of the slot in the

direction of the arrow (2).

2

1

► Install the battery again, see "

38 Fujitsu

Installing the battery", Page 33.

Working with the Tablet PC

Wireless LAN / Bluetooth / LTE (optional)
/ NFC radio components

The installation of radio components not approved by Fujitsu will invalidate
the certifications issued for this device.

Switching the wireless components on and off

The radio components are switched on and off via the corresponding functions of the operating system.

► To switch radio components on and off individually, select Settings – Change

PC settings – Network – Airplane mode.

Setting up WLAN access

• Requirement: A WLAN must be available and you must have the
corresponding access information.

Information on config uring the WLAN access c an be found in the
documentation for your operating system.

NFC (Near Field Communication)

Your Tablet PC is equipped with an integrated NFC chip. Near field communication is used
for contact-free data exchange by radio o ver short distances (a few centimetres).

Access via L

If you ordered an integrated LTE module with your system, you can enjoy optimum
reception and maximum energy efficiency without awkward cables or antennas. The
optional LTE module is ready for use straight a way.

You w i l l find information on establishing the connection with the LTE network in the
documentation for the hardware you plan to use.

Your device can connect with the Internet via LTE. To do this, use one of
the following types of connection:

• Integrated LTE module (depending on your model variant)

•aUSBd

• a mobile end-device (e.g. mobile phone with Bluetooth or cable connection)

Fujitsu 39

ongle (a USB stick with your mobile phone provider’s SIM card)

TE (optional)

Working with the Tablet PC

Ethernet and LAN (only multifunctional cradle)

EthernetLAN

1

2

► Connect the network cable to the LAN port

of the m ultifunctional cradle (1).

► Connect the ne twork cable to your

network connection (2).

GPS

GPS

Your network admini

The network cable is
cable can be obtain

strator can help you to configure and use the LAN connections.

not included in the delivery scope. This type of

ed from a specialist dealer.

Whether or not your device has this function depends on the
selected device expansion stage.

40 Fujitsu

Accessories for your Tablet PC (opti

onal)

Accessories for your Tablet PC

The following accessories are available for your Tablet PC:

• Multifunctional cradle (docking station)

• Charging cradle

• Smart Shells can be mounted on the rear of the device. The following
types are available as options:

• Smart Shell with holder for chip card reader

• Smart Shell with magnetic strip reader

• Smart S hell with SmartCard reader (also see "

• Rugged frame

• Hand strap

• Shoulder strap

The following sections provide more information on handling the accessories.

SmartCard reader (optional)", Page 60)

(optional)

Fujitsu 41

Accessories for your Tablet PC (opti

onal)

Your multifunctional cradle / your charging cradle (optional)

Your charging cradle is a device with which you can quickly charge your Tablet PC.

As well as providing rapid charging, your multifunctional cradle is a device which helps you to
quickly connect your Tablet PC to your peripheral d evices, such as a monitor, keyboard, mouse,
etc. You only need to dock the Tablet PC in order to work with your peripheral devices.

Cradle components

PortsPortsCradle

Front

1

2

1 = Connector on the cradle for the docking

port of the Tablet PC

42 Fujitsu

2 = Release for removal of the docked

Tablet PC

Rear

Accessories for your Tablet PC (opti

3

4

4

5

6

7

onal)

3 = DC input jack (DC IN)
4 = USB 3.0 port (only multifunctional cradle)
5 = HDMI port (only multifunctional cradle)

Setting up

• Placethecradleonaflat, stable, nonslippery surface.

• Never place the cradle and the mains adapter on a heat-sensitive surface.

• Do not expose the cradle to extreme environmental conditions.

• Protect the cradle from dust, humidity and heat.

the cradle

Select a suitable location for the cradle before setting it up. Follow
the instructions below when doing so:

6 = LAN port (only multifunctional cradle)
7 = Security Lock fixture

Fujitsu 43

Accessories for your Tablet PC (opti

onal)

Adapter for the cradle

When using the rugged frame (optional), you must first remove the adapter from the cradle
before you can connect the Tablet PC in the rugged frame to the cradle.

1

► Remove the ada

44 Fujitsu

pter from the cradle ( 1).

Accessories for your Tablet PC (opti

Connecting the Tablet PC to the cradle

If the Tablet PC is connected to the cradle, you must connect the
mains adapter to the cradle.

cradle

1

2

onal)

4

3

► Open the docking port cover on the Tablet PC and keep it slightly pulled

back to facilitate the docking process.

► Position the Tablet PC so that it lies on the surface of the tray on the cradle.
► Press the Tablet PC in the direction of the arrow (1) onto the cradle until

you feel it engage on the connector.

► Plug the DC output connector on the mains adapter into t he DC input

connector (DC IN) on the cradle (2).

► Connect the power cable to the mains adapter (3).
► Plug the power cable into the mains socket (4).

Fujitsu 45

Accessories for your Tablet PC (opti

onal)

Disconnecting the Tablet PC from the cradle

It is possible to separate the Tablet PC from the cradle during operation. Anyway
we recommend that you switch the Tablet PC off first or that you execute the
appropriate undocking function provided by th e operating system.

► Switch off the Tablet PC.

2

1

► Keep the release pressed (1).
► Lift the Tab let PC from the cradle in the direction of the arrow (2), while

holding the lower area of the cradle.

46 Fujitsu

Accessories for your Tablet PC (opti

onal)

Smart Shell with holder for chip card reader (optional)

The Smart Shell kit with holder for the chip card reader comprises the following
components: Smart Shell with holder for chip card reader, 4 screws.

• Use a suitable tool of the correct size when fitting the screws.

• Keep the screws out of the reach of children.

Removing the battery", Page 32).

► Remove the battery cove

r (see "

The battery itself is n

► Remove the cover (1) in the battery compartment.

ot removed.

1

Fujitsu 47

Accessories for your Tablet PC (opti

3

onal)

2

3

3

3

► Position the Smart Shell on the Tablet PC as shown (2).
► Secure the Smart Shell with the screws (3).

48 Fujitsu

Accessories for your Tablet PC (opti

Smart Shell with magnetic strip reader (optional)

The Smart Shell kit with magnetic strip reader comprises the following components:
Smart Shell with magnetic strip reader, 2 screws, 2 seals.

• Use a suitable tool of the correct size when fitting the screws.

• Keep the screws out of the reach of children.

Removing the battery", Page 32).

► Remove the battery cove

r (see "

onal)

The battery itself is n

► Remove the cover (1) in the battery compartment.

ot removed.

1

Fujitsu 49

Accessories for your Tablet PC (opti

onal)

2

3

3

4

4

► Position the Smart Shell on the Tablet PC as shown (2).
► Secure the Smart Shell with the screws (3).
► Secure the seals (4).

50 Fujitsu

Accessories for your Tablet PC (opti

Smart Shell with SmartCard reader (optional)

The Smart Shell kit with SmartCard reader comprises the following components:
Smart Shell with SmartCard reader, 1 screw, 1 seal.

For information on the security functions of the SmartCard reader, a lso

SmartCard reader (optional)", Page 60.

see "

onal)

• Use a suitable tool of the

• Keep the screws out of the reach of children.

► Remove the battery cover (see "

The battery itself is not removed.

► Remove the cover (1) in the battery compartment.

correct size when fitting the screw s.

Removing the battery", Page 32).

1

Fujitsu 51

Accessories for your Tablet PC (opti

2

1

4

onal)

3

► Position the Smart Shell on the Tablet PC as shown (2).
► Secure the Smart Shell with the screw (3).
► Secure the seal (4).

52 Fujitsu

Rugged frame (optional)

When using the rugged frame tog ether with a cradle variant (optional), you must
first remove the adapter from the cradle before you can conne ct the Tablet PC in
the rugged frame to the cradle, see "

Accessories for your Tablet PC (opti

Adapter for the cradle", Page 44

1

onal)

2

2

► Position the Tablet PC on the lower part of the rugged frame (1) as shown.
► Place the upper part onto the lower part (2) as shown.

Fujitsu 53

Accessories for your Tablet PC (opti

3

3

3

3

onal)

3

3

3

3

3

3

3

1

4

► Connect the upper and lower parts using the screws (3).
► If necessary, remove the covers (4) to be able to access the ports and controls below them.

3

4

54 Fujitsu

Hand strap (optional)

The hand strap kit includes the following components: hand strap, 2 screw s
of type M2.5x8, 2 spacers and 4 covering stickers.

• Use a suitable tool of the correct size when fitting the screws.

• Keep the screws out of the reach of children.

• Do not shake the device too much when you hold it by the hand
strap, otherwise it could fall down.

1

1

5

Accessories for your Tablet PC (opti

1

1

2

2

onal)

2

2

4

5

3

► Rem

Fujitsu 55

ove the covers from the screw holes on the rear of the tablet PC (1).

3

Accessories for your Tablet PC (opti

onal)

► Apply the covering stickers in the openings as shown (2).
► Position the spacers between the Tablet PC and th e hand strap (3).
► Put the hand strap in position on the Tablet PC (4). Make sure that th e screw holes of

the hand strap and the Tablet PC line up exactly above one another.

► Secure the hand strap with the screws (5).

56 Fujitsu

Shoulder strap (optional)

The shoulder strap kit includes the following components: Shoulder strap with
2 brackets, 2 screws of type M2.5x8 and 2 spacers.

• Use a suitable tool of the correct size when fitting the screws.

• Keep screws and mountings out of the reach of children.

1

Accessories for your Tablet PC (opti

1

onal)

4

3

2

4

3

2

► Remove the covers from the screw holes on the rear of the tablet PC (1).

Fujitsu 57

Accessories for your Tablet PC (opti

onal)

► Put the shoulder strap in position on the Tablet PC (2). Make sure that the openings in the

shoulder strap and the screw holes of the Tablet PC line up exactly above on e another.

► Position the spacers (3) on the screw holes.
► Secure the shoulder strap with the screws (4).

58 Fujitsu

Security functions

Security functions

Securityfunctions

Your Tablet PC has several security features that you can use to secure your
system from unauthorised access.

This chapter explains how to use each function, and what the benefits are.

Please remember that in some cases, for example, forgetting your password,
you may be locked out and unable to access your data. Therefore,
please note the following information:

• Back up your data on external data carriers at regular intervals.

• Some security functio
of the passwords and ke

If you forget your passwords you will need to contact the our Service
Desk. Deletion or resetting of passwords is not co vered by your warranty
and a charge will be made for assistance.

Using the security lock (optional)

Your multifunctional cradle or charging cradle (optional) comes with a security lock fixture for the
Kensington Lock cable. Using the Kensington Lock with its strong steel cable, you can protect your
Tab let PC and the cradle against theft. The Kensington Lock cable is available as an accessory.

Fujitsu recommends the use of a combination lock.

ingtonLockCable

ckup

otection
UsingtheKens

SecurityLockMechanicalba

Anti-theftpr

ns need you to choose passwords. Make a note

eptheminasafeplace.

► If the Tablet P C is connected to the cradle

(optional): Fit the Kensington Lock cable
to the fixture on your cradle.

Fujitsu 59

Security functions

Configuring password protection in BIOS Setup Utility

Before using the various options for password protection in the BIOS Setup ut ility
to increase data security, please observe the following:

Make a note of the passwords a nd keep them in a safe place. If you forget your
supervisor password you will no t be able to access your Tablet PC. Deletion of the
password is not covered by your warranty and a charge will be made for assistance.

Passwordprotection

Your password can be up to
No distinction is made be

32 characters long and contain letters and numbers.

tween uppercase and lowercase.

SmartCard reader (optional)

Securityfunctions,Securityfunctions

SmartCards are not supplied as standard equipment. You can use all SmartCards that comply with
the ISO standard 7816-1, -2 or -3. These SmartCards are available from v arious manufacturers.

With the appropriate software you can use your SmartCard as an alternative to password protection,
but also as a digital signature, for encrypting your e-mails or for home banking.

We recommend that you always use two SmartCards. Always keep one of the SmartCard s
in a safe place if you are carrying the other SmartCard with you.

In order to be able to take advantage of all the security features of your Tablet
PC, you will need a CardOS SmartCard from Fujitsu.

For information on i

"

Smart Shell with Sm

nstallation of the Smart Shell with SmartCard reader, see

artCard reader (o ptional)", Page 51.

The SmartCard can only be used with a PIN, offering maximum protection even if
you lose the SmartCard. In order to maximise your security, the CardOS SmartCard
is disabled if three incorrect attempts are made to enter the PIN.

When you use the CardOS SmartCard for the first time, you will either need to enter the
preset PIN "12345678" or the PIN given to you by your systems administrator.

Installing the SmartCard reader

Install the SmartCard reader as described in section "Smart Shell with

SmartCard reader (optional)", Page 51.

60 Fujitsu

Inserting the SmartCard

Do not use force when inserting and removing the SmartCard.

Make sure that foreign o bjects do not fall into the SmartCard reader.

Security functions

► Turn the Tablet PC over.
► Push the SmartCard into the SmartCard reader with the chip facing downwards.

Fujitsu 61

Connecting external devices

Connecting external devices

Under all circumstances, please observe the safety notes provided in the

Important notes", Page 12 chapter before co nnecting or disconnecting

"

any devices to or from your Tablet PC.

Always read the documentation supplied with the device you wish to connect.

Never connect or disconnect cables during a thunderstorm.

Never pull at a cable when disconnecting it. Always grasp the plug.

With some devices, such as USB devices, it is not necessary to switch off
the Tablet PC and the device before conne cting/disconnecting. For more
information about whether or not devices need to be switched off, please refer
to the documentation supplied with the external device.

Some of the external devices require special drivers (see the o perating
system and external device documentation).

Connecting an external monitor

HDMI port (multifunctional cradle only)

HDMIport

The HDMI port of the multifunctional cradle can be used to connect an external
amplifier, LCD TV or a plasma TV with an HDMI port.

► Connect the data cable to the

external device.

► Connect the da ta cable to the HDMI port

of the multifunctional crad le.

Some LCD televisions have only two loudspeakers/loudspeaker ports and
therefore cannot reproduce Dolby Digital. To play back HDMI sound, you
must change the HDMI sound settings accordingly.

You can find the settings unde r Control Panel - Hardware and Sound. Disable the
settings for Dolby Digital to enable playback of HDMI sound.

62 Fujitsu

Connecting external devices

Connecting USB devices (Tablet PC or multifunctional cradle)

USBports

On the USB ports, you can connect external devices that also have a USB port
(e.g. a DVD drive, a printer, a scanner or a modem).

Do not connect any external devices to the micro USB port, this port is
only used for the power supply for the Tablet PC.

USB devices are hot-pluggable. This means yo u can connect and disconnect
devices while your operating system is running.

USB 1.x has a maximum data transfer rate of 12 Mbit/s.

USB 2.0 has a data transfer rate of up to 480 Mbit/s.

USB 3.0 has a data transfer rate of up to 5 Gbit/s.

Additional information can be found in the documentation for the USB devices.

► Connect the data cable to the

external device.

► Connect the data cable to a USB

port of the Tablet PC.

or

► Connect the data cable to a USB port

of the multifunctional cradle.

Device drivers

USB devices will be automatically reco gnised and installed by your operating system.

How t o remove USB devices correctly

Always c
to ensu

► Tap the symbol for safe removal of the hardware.
► Sele
► Tap OK.



Fujitsu 63

ct the device which you want to shut down and remove.

for the dialogue box which tells you that it is now safe to remove the device.

Wait

orrectly remove the device according to the rules described below,

re that none of your data is lost.

Connecting external devices

Headphone port

ConnectingaudiodevicesAudioportsConnectingheadphones

Via the headphone port, you can conn ect either a headphone or an external speaker to your Tablet PC.

1

2 3 4

2 4

1

► Open the cover of the headphone port (4) on the right side of the device.

3

► Connect the aud

external devic

► Connect the audio cable to the headphone

port of the Tablet PC.
The internal l



iocabletothe

e.

oudspeakers are disabled.

If you purchase a cable from a retailer, please note the following information:

The headphone port on your Tablet PC is a "3.5 mm jack socket".

If you want to connect headphones or a speaker you will need a "3.5 mm jack plug".

64 Fujitsu

Settings in BIOS Setup Utility

Settings in BIOS Setup Utility

BIOSSetupUtilitySystemsettings,BIOSSetup UtilityConfiguration,BIOSSetupUtilitySetupSystemconfigurationHardwareconfiguration

The BIOS Setup Utility allows you to set the s ystem functions and the hardware
configuration for the Tablet PC.

When it is delivered, the Tablet PC is set to factory default settings. You can
change these settings in BIOS Setup Utility. Any changes you make take effect as
soon as you save and exit the BIOS Setup Utility.

The BIOS Setup Utility program contains the following menus:

Info

System

Advanced

Security

Boot

Exit

Starting the BIOS Setup Utility

► Press and hold the volume button and switch on the tablet PC.

► If a password has been assigned, enter the password and press the Enter key.

To navigate in the BIOS Setup Utility, you have to use an external USB keyboard.

Displays information relating to the BIOS, processor and Tablet PC

Advanced system settings

Configuration of various hardw are com ponents

Password settings and security fu nctions

Configuration of the start-up sequence

Exits the BIOS Setup Utility

BIOSSetupUtility

If you have forgotten the password, contact your system administrator
or contact our customer service centre.

The BIOS Setup Utility starts.

Fujitsu 65

Troubleshooting and tips

Troubleshooting and tips

TroubleshootingTipsFaultTroubleshooting

If a fault occurs, try to correct it as described. If you fail to correct the problem, proce ed as follows:

► Make a note of the steps and the circumstances that led to the fault. Also

► Switch the Tablet PC off.
► Please contact the Hotline/Service Desk.

Follow the safety notes in the "Safety/Regulations" manual when
connecting or disconnecting cables.

make a note of any error messages displayed.

You c a n find the telephone numbers in the service desk list. Please have
the following information ready when you call:

• The model name and serial number of the Tablet PC. The serial number
is located on a sticker on the underside of the Tablet PC.

• Notes of any messages that appear on the screen and information on acoustic signals.

• Any changes you have made to the hardware or software after
receiving the Tablet PC.

• Any changes you have made to the BIOS Setup settings af ter receiving the Tablet PC.

• Your system configuration and all peripheral devices connected to your system.

• Your sales contract.

Our Tablet PCs
means that con
in terms of we
configuratio
compared to a
games with i
been appro
losses or m
versions c

Forced sh

► Keep the ON/OFF button pressed for at least 10 seconds.

The device will shut down. You can then restart it.



66 Fujitsu

ut down

have been designed primarily with mobile applications in mind. This

siderable effort has been made to optimise component s and equipment

ight, space and energy requirements. Depending on the particular

n you have purchased, it is possible that functionality may be slightly reduced

desktop PC if you are running processor-intensive gaming software, e.g.

ntensive 3D graphics. Updating your hardware with drivers which have not
ved by Fujitsu Technology Solutions may result in performance losses, data
alfunction of the equipment. A list of approved drivers and current BIOS

an be downloaded from: "

http://support.ts.fujitsu.com/Download/Index.asp"

Troubleshooting and tips

Help if problems occur

Should you encounter a problem with y our computer that you cannot resolve yourself:

► Note the ID number of your device. The ID number is found on the type rating

plate on the back or underside of the casing.

► For furthe r clarification of the problem, contact the Service Desk for your country (see the

Service Desk list or visit the Internet at

http://support.ts.fujitsu.com/contact/servicedesk/ServiceDeskNumber_Int.asp"). When you

"

do this, please have ready the ID number and serial number of your system.

The Tablet PC’s date or time is incorrect

SummertimeTime,day lightsavingsTimenotcorrectTimenotcorrectIncorrectdate /timeDateisincorrectBufferbattery,load

Cause Troubleshooting

Time and date are incorrect. ► With the BIOS-Setup-Utility, you can set the

Date and time are still set incorrectly after
switchingontheTabletPC.

date and time in the main menu.

► Please contact your sales outlet or our

Hotline/Service Desk.

Battery indicator does not illuminate

Cause

The b attery is fully discharged. ► Connect the mains adapter to the Tablet PC

Fault elimination

to charge the battery.

or

► Keep the ON/OFF button pressed for

at least 10 se conds and the n connect
the mains adapter to the Tablet P C to
charge the battery.

The Tablet PC’s touchscreen remains dark

Touchsc reentouchscreenistoo dark

Cause Troubleshooting

Touchscreen is switched off. ► Press a key (external keyboard) or tap on

External monitor or television set connected.

Fujitsu 67

the touchscreen.

► Check wh

rect or whether an external monitor

are cor
has bee

rator Drive r for mobile".

Accele

ether the graphics driver settings

n detected in "Intel Graphics Media

Troubleshooting and tips

The display on the Tablet PC’s touchscreen
is difficult to read.

Touchsc reenTouc hscre en

Cause Troubleshooting

Reflected glare ► Move the Tablet PC into a different position.

► Increase the brightness of the screen.

The external monitor remains blank

Monitor

Cause Troubleshooting

Monitor is switched off

Power saving has been activated (monitor is
blank).

Brightness is set to dark.

Screen output is se
touchscreen.

The external mo n
cable is not conn

.

t on the Tablet PC’s

itor’s power cable or data

ected properly.

► Switch the external mon

► Press a key (external keyboard) or tap on

the touchscreen.

► Adjust the brightness of the mo nitor.

► Check whether the g

are correct or whet
has been detected
Accelerator Driv

► Switch off the Tablet PC and the external

monitor.

► Check whether the power cable is plugged

properly into the external monitor and into
the power socket.

► Check whether the data cable is properly

connected to the Tablet PC and the external
monitor (if it is plugged in with a connector).

► Switch on the Tablet PC and the external

monitor.

itor on.

raphics driver settings

her an external monitor

in "Intel Graphics Media

er for mobile".

The external monitor is blank or the image is unstable

ScreenMonitor

Cause Troubleshooting

The wrong external monitor has been selected
or the wrong scre en resolution has been set for
the application program.

68 Fujitsu

► Terminate the application program in

Windows. If the error persists after
terminating the program, use the key
combination for switching the screen output
in order to switch to the touchscreen of the
tablet PC. Change the following setting:

► Set the screen resolution: Set the screen

resolution as described in the documentation
foryouroperatingsystem.

► Select monitor: Select monitor 1 or 2 as

described in the documentation for your
operating system.

Troubleshooting and tips

The Tablet PC does not start after switch on

TheTabletPC

Cause Troubleshooting

The battery is not installed correctly.

► Check whether the battery is installed

correctly in its compartment.

► Switch on the Tablet PC.

The battery is dead.

► Charge the battery.

or

► Insert a charged battery.

or

► Connect the mains adapter to the Tablet

PC.

The power adapter is not connected correctly.

► Check whether the mains adapter is

connected correctly to the Tablet PC.

► Switch on the Tablet PC.

The Tablet PC stops working

TheTabletPCEnergy savingmode

Cause Troubleshooting

The Tablet PC is in energy saving mode.

An application programme has caused the
malfunction.

The battery is dead.

► Leave energy saving mode.

► Close the application program or restart

the Tablet PC (by restarting the operating
system or switching the device off and back
on again).

► Charge the battery.

or

► Connect the mains adapter to the Tablet

PC.

The print

doesnotprint

Printer

Cause Troubles

The prin

inter is not connected correctly.

The pr

er does not print

ter is not switched on.

hooting

► Make sur

on and re
docume

e that the printer is switched

ady for operation (refer to the

ntation supplied with the printer).

► Check that the data cable connecting

the Table PC to the printer is properly
connected.

The printer driver is faulty or n ot correctly
installed, or it is the wrong printer driver.

► Check that the data cable connecting

the Tablet PC to the printer is properly
connected.

► Check whether the correct printer driver is

loaded (refer to the printer documentation).

Fujitsu 69

Troubleshooting and tips

The radio connection to a networ

Theradioconnectiontoanetwork doesnotwork

Cause Troubleshooting

The wireless component is disa

The wireless component is enabled. Despite
this, the wireless connection to a network does
not work.

The battery discharges

Battery:

Cause

The battery is either
case the battery indi

You may have an application running that
consumes a great deal of power due to frequent
accessing of the hard disk or optical drive.

The maximum brightness may have been set
for the screen.

too hot or too cold. In this

cator flashes.

bled.

► Switch the radio component on (see

► Check whether the radio connection is

► Further information on using the radio

too quickly

Troubleshooting

► Bring the Tablet PC up/down to a normal

► If the operating time of the battery life is

► Use the mains adapter as frequently as

► Reduce the brightness of the screen to

kdoesnotwork

"

Switching the wireless components on and

off", Page 39).

switched on via the software.

component can be found in the help files.

temperature again.

extremely short, the battery is probably too
old. Replace battery if necessary.

possible.

lower energy consumption: You will find the
setting under Control Panel – Hardware and
Sounds – Windows Mobility Center.

SmartCard re

Cause

Chip card inserted incorrectly.

ader is not recognised.

Troubleshooting

► Make sure yo

SmartCard
with the ch
(device-d

► Check whether the SmartCard you are using

is supported. Your SmartCard must comply
with the ISO standard 7816-1, -2, -3 and -4.

into the SmartCard reader

ip facing upwards/downwards

ependent).

u have inserted your

SmartCard PIN forgotten

eshooting

Cause

PIN forgotten ► If you work in a network, contact your

70 Fujitsu

Troubl

system administrator, who can unlock your
Tablet PC with a su pervisor PIN.

Troubleshooting and tips

User and/or supervisor SmartCard lost

Cause

User and/or supervisor SmartCard lost ► If you have lost your User SmartCard, you

Troubleshooting

can continue working with the Supervisor
SmartCard and initialise a ne w User
SmartCard or deactivate the SystemLock
function.

► If you have lost the Supervisor SmartCard,

you can continue working, bu t you no longer
have all your rights and can no longer
initialise a Supervisor SmartCard.

► IfyouhavelostbothSmartCards,youcan

no longer boot your system. Please contact
our Service Desk. You must provide proof of
ownership for the device. Then the Service
Desk will refer you t o our service partner,
who will unlock your device (for a charge).

SmartCard lost

Cause

SmartCard lost ► If you work in a network, contact your

Troubleshooting

system administrator, wh o can boot your
Tablet PC with a Supervisor SmartCard.

Fujitsu 71

Troubleshooting and tips

Error messages on the screen

ErrormessagesonthescreenErrormessage:

This section describes the error messages generated by the BIO S Setup. Error messages displayed
by the operating system or programme s are described in the relevant documentation.

If the error message appears repeatedly, des pite troubleshooting measures, please
contact the place of purchase or our customer service cen tre.

Error message/cause Resolution

System CMOS checksum bad - d efault configuration
used

The system configuration information is
incorrect.

Keyboard controller error

Keyboard error

nn Stuck key

Operating system not found

Press <F1> to resume, <F2> to SETUP

This error message appears if an error occurs
during the self-test before starting the operating
system.

Real time clock error

nnnnK Shadow RAM failed at offset: xxxx Failing
Bits: zzzz

System battery is dead - Replace and run SETUP

System cache error - Cache disabled

System timer error

► Switch off the Tablet PC.
► Switch on the Tablet PC.
► Keep the volume – button a

button pressed and swit
If you keep the volume –
you can switch into th

nd the shortcut

ch the Tablet PC on.

button pressed,

e BIOS Setup-

► In the BIOS Setu p , select the Exit menu.
► Select the entry Loa

d Setup Defaults.

► Select OK and press the Enter key.

► Switch off your Tablet PC with the ON/OFF

switch.

► Wait 3 - 5 seconds and sw itch on the Tablet

PC again.

If you are using an external keyboard:

► Check the connection and reboot the Tablet

PC.

► Make sure that no key is pressed.

► Check in the B

disk has been

IOS Setup whether your hard
set correctly.

► Make sure that the operating system is

installed on the corresponding drive.

Alt

► Press the

key on the Tablet PC to boot

the operating system

► Contact your sales outlet or our customer

service centre.

► Contact your sales outlet or our customer

service centre.

► Contact your sales outlet or our customer

service centre.

► Contact your sales outlet or our customer

service centre.

► Contact your sales outlet or our customer

service centre.

72 Fujitsu

Technical data

Technical data

Tablet PC

General

Processor

Main memory

Electrical data

Safety regulations complied with CE

Protection class II

Maximum power consumption (when the Tablet
PC is switched on and the battery is charged):

Touchscreen

Size 8.3” / 21 cm

Resolution

Pixel class II

Brightness control 12 levels

Technology Wide-View High-Bright display with LED

Digitizer and glass panel

Cameras

Graphics card

Chip

Maximum resolution on external display:

ions

Dimens

x depth x height

Width

Weight depending on configuration 540 g / 1.19 lbs

Input devices

Tab let buttons 3 keys

ots

Sl

emory card slot

M

SIM card slot (optional) 1 x standard SIM card

Ports

Headphone port 3.5 mm stereo mini jack

Docking port 1 x

USB (Universal S erial Bus) 1 x USB 2.0

Environmental conditions

Environment class DIN IEC 721

Mechanism class DIN IEC 721

Intel Atom (TM) Z 3795 or Z3745 Quad-core

4GB RAM & 64GB or 128 GB SSD eMMC

Max. 11.6 W

1920 x 1200 pixels / 16 million colours

background lighting

Glare capacitive touch panel

• Front: 2 Megapixels

•Back:8meg

Intel HD graphics

1920 x 1

227.8 x 150.1 x 12.5 mm / 8.97 x 5.91 x 0.49 in.

1xMicroSDCard

7K1

7M2

apixels, autofocus, m obile light

080 (1080p)

Fujitsu 73

Technical data

Operating temperature -10 °C to +50 °C / 14 °F to 122 °F

Transport temperature (2K2) -20 °C to +60 °C / -4 °F .... 140 °F

Rechargeable battery

You c an find information on the batteries u sed in your device on the
Internet at "

Rated voltage 3.8 V

Typical rated capacity 16.8 Wh

http://fujitsu.com/fts/support".

Mains adapter

Technicaldata

An additional mains adapter or p ower cable can be ordered at any time.

Mains adapter only for the Tablet PC (10 W)

Rated voltage 5 V

Max. rated current 2 A

Mains adapter for operation with the multifunctional
or charging

Rated voltage 12 V

Max. rated current 5 A

Make certa in that you always use the correct mains adapter for operation
with or without the cradle in each case!

cradle (60 W, optional)

74 Fujitsu

Technical data

Multifunctional cradle (optional)

Electrical data

Safety regulations complied with CE

Protection class II

Ports

HDMI 1 x

USB (Universal S erial Bus) 3 x USB 2.0

Docking port 18-pin

LAN port 1 x

Environmental conditions

Environment class

Mechanism class DIN IEC 721

Operating temperature -10 °C to +50 °C / 14 °F to 122 °F

Transport temperature

DIN IEC 721

7K1

7M2

-20 °C to +60 °C /

-4 °F .... 140 °F

Smart Shell with magnetic strip reader (optional)

Dimensions

Width x Depth x Height 143.7 x 134.0 x 22.0 mm

5.66 x 5.28 x 0.87 inch

Weight

65 g / 0.14 lbs

Smart Shell with SmartCard reader (optional)

Dimensions

Width x Depth x Height 143.7 x 121.6 x 16.2 mm

5.66 x 4.79 x 0.64 inch

Weight

78 g / 0.17 lbs

Rugged frame (optional)

Dimensions

Width x Depth x Height 243.9 x 166.2 x 21.5 mm

9.60 x 6.54 x 0.85 inch

Weight

Fujitsu 75

245 g / 0.54 lbs

Manufacturer’s notes

Manufacturer’s notes

Disposal and recycling

Notes

You ca n fi nd information on this subject on your Tablet PC or on our website

http://www.fujitsu.com/fts/about/fts/environment-ca r e/").

("

Declarations of Conformity

Declarationofconformity

The "Declarations of Co

"

http://globalsp.ts

Fujitsu Technology So
essential requireme

CE marking

CEmarkingCEmarkingNotesElectromagneticcompatibilityLowvoltagedirective

The shipped version of this device complies with the requirements of EU directives 2004/108/EC
"Electromagnetic compatibility", 2006/95/EC "Low voltage directive", 2011/65/EC "RoHS directive"
and 2009/125/EC "ecodesign directive".

CE marking for devices with radio component

This equipment complies with the requirements of Directive 1999/5/EC of the European Parliament
and Commission from 9 March, 1999 governing Radio and Telecommunications Equipment
and mutual recognition of conformity.

CE nnnn (!) ; nnnn: For digits and exclamation mark (!), s ee label on th e product.

You c a n find more information and declarations of conformity on the Internet at:

http://globalsp.ts.fujitsu.com/sites/certificates".

"

This equ ipment can be used in the following countries:

Belgium Bulgaria Denmark

Estonia Finland France

UK Ireland Iceland Italy

Latvia Liechtenstein Lithuania Luxembourg

Malta Netherlands Norway Austria

Poland Portugal Rumania

Switzerland Slovakia Slovenia Spain

Czech Republic

Turkey

Contact the corresponding government office in the respective country for current information on
possible op erating restrictions. If y our country is not included in the list, then please contact
the corresponding supervisory authority as to whether the use of this product is permitted in
your country.

nformity" for the device can be found on the Internet at:

.fujitsu.com/sites/certificates/default.a spx".

lutions hereby declares that your device is in compliance with the

nts and other relevant provisions of Directive 1999/5/EC.

Germany

Greece

Sweden

Hungary

Cyprus Croatia

76 Fujitsu

Manufacturer’s notes

Other certification marking s

Certificationmarkings

Any other certification markings are listed in the "Manual Appendix ­Additional Certifications" supplement.

If such markings are available, you can find the s upplement on the Internet at

http://support.ts.fujitsu.com/Manuals/" with the Operating M anual for your device.

"

Regulatory notices

If there is no FCC logo and also no FCC ID on the device then this device is
not approved by the Federal Communications Commission (FCC) of the USA.
Although it is not explicitly forbidden to travel in the US trading area ca rrying this
device, to avoid trouble at customs clearance, Fujitsu Technology Solutions GmbH
recommends not to bring this device into the US trading area.

Regulatory information for Tablet PCs without radio device

Regulatoryinformation

NOTICE:

Changes or modifications not expressly approved by Fujitsu Technology S olutions
could void this user’s authority to operate the equipment.

Notice to Users of Radios and Television

These limits are designed to provide reasonable protection against harmful interference in a
residential installation. This equipment generates, uses, and can radiate radio frequency energy
and, if not installed and used in accordance with the instructions, may cause harmful interference
to radio communications. However, there is no guarantee that interference will not occur in a
particular installation. If this equipment does cause harmful interference to radio or television
reception, which can be determined by turning the equipment off and on, the user is encouraged
to try to correct the interference by one or more of the following measures:

• Reorient or relocate the receiving ant enna.

• Increase the separation between the equipment and receiver.

• Connect the equipment into an outlet that is on a different circuit than the receiver.

• Consult the dealer or an experienced radio/T V technician for help.

Notice to Users of the US Telephone Network

Your Tablet PC may be supplied w ith an internal modem which complies with Part 68 of the
FCC rules. On this Tablet PC is a label that contains the FCC Registration Number and the
Ringer Equivalence Number (REN) for this equipment among other information. If requested,
the user must provide their telephone company with the following information:

1. The telephone number to which the Tablet PC is connected.

2. The Ringer Equivalence Number (REN) for this equipment.

3. The equipment requires a standard modular jack type USO C RJ-11C
which is FCC Part 68 compliant.

4. The FCC Registration Number.

This equipment is designed to be connected to the te lephon e network or premises wiring using
a standard modular jack type USOC RJ-11C which is FCC Part 68 compliant and a line cord
between the modem and the telephone network with a minimum of 26AWG.

Fujitsu 77

Manufacturer’s notes

The REN is used to determine the number of devices that you may connect to your telephone
line and still have all of those devices ring when you r number is called. Too many devices
on one line may result in failure to ring in response to an incoming call. In most, but not all,
areas the sum of the RENs of all of the devices should not exceed five (5). To be certain
of the number of devices you may connect to your line, as determined by the RENs, contact
your local telephone company. If this equipment causes harm to the telephone network, your
telephone company may discontinue your service temporarily. If possible, they will notify you
in advance. If advance notice is not practical they will notify you as soon as possible. You
will also be advised of your right to file a complaint with the FCC.

This fax modem also complies with fax branding re quirements per FCC Part 68.

Your telephone company will probably ask you to disconnect this equipment from the telephone
network until the problem is corre cted and you are sure that the equipment is not malfunctioning.
This equipment may not be u sed on coin-operated telephones provided by your telephone
company. Connection to party lines is subject to state tariffs. Contact your state’s public utility
commission, public service commission or corporation commission for more information.

This equipment includes automatic dialing capability. When programming and/or
making test calls to emergency numbers:

• Remain on the line and briefly explain to the dispatcher the r eason for the call.

• Perform such activities in off-peak hours, such as early morning or late evening.
FCC rules prohibit the use of non-hearing aid compa tible telephones in the

following locations or applications:

• All public or semi-public coin-operated or credit card telephones.

• Elevators, highways, tunnels (automobile, subway, railroad or pedestrian) where a
person with impaired hearing might be isolated in an emergency.

• Places where telephones are specifically installed to alert emergency authorities
such as fire, police or medical assistance personnel.

• Hospital rooms, residential health care facilities, convalescent homes and prisons.

• Hotel, motel or apartment lobbies.

• Stores where telephones are used by patrons to order merchandise.

• Public transportation terminals where telephones are used to call taxis or
to reserve lodging or rental cars.

• In hotel an d motel rooms as at least ten percent of the rooms must contain hearing
aid-compatible telephones or jacks for plug-in hearing aid compa tible telephones which
will be provided to hearing impaired customers on request.

DOC (Industry CANADA) notices

DOC(INDUSTRYCANADA)NOTICES

to Users of Radios and Television

Notice

ass B digital apparatus meets all requirements of Canadian Interference-Causing Equipment

This Cl

tions.

Regula

pareil numérique de la class B respecte toutes les exigence du Réglement

CET ap

matérial brouilleur du Canada.

sur le

ce to Users of the Canadian Telephone Network

Noti

CE:

NOTI

78 Fujitsu

Manufacturer’s notes

This equipment meets the applicable Industry Canada Terminal Equipment Technical
Specifications. This is confirmed by the registration number. The abbreviation, IC, before
the registration number signifies that registration was performed based on a Declaration of
Conformity indicating that Industry Canada technical specifications were met. It does not
imply that Industry C anada approved the equipment. Before connecting this equipment to
a telephone line the user should ensure that it is permissible to connect this equipment to
the local telecommunication facilities. The user should be aware that compliance with the
certification standards does not prevent service degradation in some situations.

Repairs to telecommunication equipment should be made by a Canadian authorised
maintenance facility. Any repairs or alterations not expressly approved by Fujitsu or
any equipment failures may give the telecommunication company cause to request the
user to disconnect the equipment from th e telephone line.

NOTICE:

The Ringer Equivalence Number (REN) for this terminal equipment is 0.0. The REN assigned
to each terminal equipment provides an indication of the maximum number of terminals
allowed to be connected to a telephone interface. The termination on an interface may
consist of any combination of devices subject only to the requirement that the sum of the
Ringer Equivalence Numbers of all the devices does not exceed five.

CAUTION:

For safety, users should ensure that the electrical ground of the power u tility, the
telephone lines and the metallic water pipes are connected together. Users should NOT
attempt to m ake such conn ections the m selves but should conta ct the appropriate electric
inspection authority or electrician. This may be particularly important in rural areas.

Avis Aux Utilis

AVI S : Le pré s e
applicables a
Le sigle IC, p
conformémen
d’Industrie

Avant de con
s’il est pe
locales. L
peut dan s c

Les répar
maintena
approuvé
télécom

AVI S : L

é à chaque dispositif terminal indique le nombre m aximal de terminaux qui peuvent

assign

ccordés à une interface téléphonique. La terminaison d’une interface peut consister

être ra
en une

ivalence de la sonnerie de tous les dispositifs n’excède pas 5 .

d’équ

ateurs Du Réseau Téléphonique Canadien

nt matériel est conform e aux spécifications techniques d’Industrie Canada

u matériel terminal. Cette conformité est confirmée par le numéro d’enregistrement.

lacé devant le numéro d’enregistrement, signifie que l’enregistrement s’est effectué

t à une déclaration de conformité et indique que les spécifications techniques

Canada ont été respectées. Il n’implique pas qu’Industrie Canada a approuvé le matériel.

necter cet équipement à une ligne téléphonique, l’utilisateur doit vérifier
rmis de connecter c et équipement aux installations de télécommunications
’utilisateur est averti que même la conformité aux normes de certification ne

ertains cas empêcher la dégradation du service.

ations de l’équipement de télécommunications doivent être effectuées par un service de
nce agréé au Canada. Toute réparation ou modification, qui n’est pas expressément
e par Fujitsu, ou toute défaillance de l’équipement p eut entraîner la compagnie de

munications à exiger que l’utilisateur déconnecte l’équipement de la ligne téléphonique.

’indice d’équivalence de la sonnerie (IES) du présent matériel est de 0.0. L’IES

combinaison quelconque de dispositifs, à la seule condition que la somme d’indices

Fujitsu 79

Manufacturer’s notes

AVERTISSEMENT:

Pour assurer la sécurité, les utilisateurs doivent vérifier que la prise de terre du service
d’électricité, les lignes télphoniques et les conduites d’eau métalliques sont connectées
ensemble. Les utilisateurs NE doivent PAS tenter d’établir ces connexions eux-mêmes,
mais doivent contacter les services d’inspection d’installations électriques appropriés
ou un électricien. Ceci peut être particulièrement important en régions rurales.

UL Notice

This unit requires an AC ad
The correct output ratin
below for the correct AC A

apter to operate. Only use a UL Listed Class 2 adapter.

g is indicated on th e AC adapter label. Refer to the illustration

dapter output polarity:

CAUTION:

To reduce the risk of fire, use only 26AWG or larger telecommunications line cord.

For Authorized Repa ir Technicians Only

CAUTION:

For continued protection against risk of fire, replace only with the
same type and rating fuse.

WARNING :

Danger of explosion if Lithium (CMOS) battery is incorrectly replaced. Replace only
with the same or equivalent t ype recommended by the ma nufacturer.

Dispose of used batteries according to the manufacturer’s instructions.

FCC Regulatory information for Tablet PCs with radio device

Regulatoryinformation

Federal Communications Commission statement

This device complies with Part 15 of FCC Rules. Operation is subject to the following
two conditions: (1) this device may not cause interference, and

(2) this device must accept any interference, including interference that may
cause undesired operation of this device.

FCC Interference Statement

This equipment has been tested and found to comply with the limits for a Class B digital
device, pursuant to Part 15 of the FCC Rules. These limits are designed to provide re asonable
protection against harmful interference in a residential installation. This equipment generates,
uses, and can radiate radio frequency energy. If not installed and used in accordance with
the instructions, it may cause harmful interference to radio c ommunications.

However, there is no guarantee that interfere nce will not occur in a particular installation.

80 Fujitsu

Manufacturer’s notes

If this equipment does cause harmful interference to radio or television rece ption, which
can be determined by turning the equipment off and on, the user is encouraged to try to
correct the interference by one or more of the following measures:

1. Reorient or relocate the receiving antenna.

2. Increase the distance between the equipment and the receiver.

3. Connect the equipment to an outlet on a circuit different from the one the receiver is connected to.

4. Consult the dealer or an experienced radio/TV technician for help.
Please note the following regulatory information related to the optional radio device.

FCC Radio Frequency Exposure statement

This radio device has been evaluated under FCC Bulletin OET 65C and found compliant with the
requirements as set forth in CFR 47 Sections 2.1091, 2.1093, and 15.247 (b) (4) addressing RF
Exposure from radio frequency devices. The radiated output power of this radio device is far below
the FCC radio frequency exposure limits. Nevertheless, this device shall be used in such a manner
that the potential for human contact during normal operation is minimized. When using this device, a
certain separation distance between antenna and nearby persons must be maintained to ensure RF
exposure comp liance. In order to comply with RF exposure limits established in the ANSI C95.1
standards, the distance between the antennas and the user should not be less than 20 cm (8 inches).

Regulatory Notes and Statements

Radio device, health and authorisation f or use

Radio-frequency electromagnetic energy is emitted from the wireless devices. The energy levels
of these emissions, however, are far much less t han the electromagnetic energy emissions from
wireless device s such as mobile phones. Radio devices are safe for use by consumers because
they operate within the guidelines found in radio frequency safety standards and recommendations.

The use of the radio devices may be restricted in some situations or environments, su ch as:

• on board an airplane, or

• in an explosive environment, or

• in situations where the interference risk to other devices or services is
perceived or identified as harmfu l.

In cases in which the policy regarding use of r adio devices in specific environments is not
clear (e.g., airports, hospitals, c hemical/oil/gas industrial plants, private buildings), obtain
authorization to use these devices prior to operating the equipment.

Regulatory Inform ati on/Disclaimers

Installation and use of this radio device must be in strict accordance with the instructions included
in the user documentation provided with the produ ct. Any changes or modifications made to this
device that are not expressly approved by the manufacturer may void the user’s authority to operate
the equipment. The manufacturer is not responsible for any radio or television interference caused
by unauthorized modification of this device, or the substitution or attachment of connecting cables
and equipm ent other than those specified by the manufacturer. It is the responsibility of the user
to correct any interference caused by such unauthorized modification, substitution or attachment.
The manufacturer and its authorized resellers or distributors will assume no liability for any damage
or violation of government regulations arising from failure to comply with these guidelines.

Export restrictions

This product or software contains encryption c ode which may not be exported or
transferred from the US or Canada without an approved US Department of Commerce

Fujitsu 81

Manufacturer’s notes

export license. This device complies with Part 15 of FCC Rules, as well as ICES 003 B
/ NMB 003 B. Operation is subject to the following two conditions:

(1) this device may not cause harmful interference, and

(2) this device must accept any interference received, including interference
that may cause undesirable operation.

Modifications not expressly authorised by Fujitsu Technology Solutions may
invalidate the user’s right to operate this equipment.

82 Fujitsu

Index

Index

A

Anti-theft protection 59
Audio ports 64
Ausschalten

Tablet PC 21

B

Battery

battery life 31
caring for and maintaining 31
charge level 31, 35
charging 31
self-discharge 31
storage 3 1

Battery status meter 31
Battery:

discharges too quickly 70

BIOS Setup Utility

calling 65
settings 65

Bluetooth, safety notes 12
Buffer battery, load 67

C

CE marking 76
Certification markings 77
Charging capacity, battery 31
Configuration, BIOS Setup Utility 65
Connecting audio devices 64
Connecting headphones 64
cradle

Connecting a Tablet PC 45

Cradle 42

energy saving 13
Energy saving 13
Energy saving mode

leaving 69
Error message:

on the screen 72
Error messages on the screen 72
Ethernet LAN 40

F

Fault

correction 66
First-time setup 17

G

Getting started 17
GPS 40

H

Hardware configuration 65
HDMI port 62

I

Important notes 12
Incorrect date/time 67

L

Landscape orientation

screen 2 4
Life, battery 31
Low voltage directive 76

D

Date is incorrect 67
Declaration of conformity 76
Device

setting up 18

Display orientation

selecting 24

DOC (INDUSTRY CANADA) NOTICES 78

E

Electromagnetic compatibility 76
Energy

Fujitsu 83

M

Mains adapter

connecting 18

setting up 18
Mechanical backup 59
Memory card

handling 35

inserting 36

removing 37
Mobile operation 14
Monitor

drifting display 68

remains blank 68

Index

N

Notes 12

CE marking 76
disposal / recycling 76
energy saving 13
Safety 12
touchscreen 23
transport 14

P

Packaging 17
Password protection 60
Portrait orientation

screen 24
Ports 42
Power

power consumption 35

power-management features 35
Power-on indicator 21
Preparing for operation 18
Printer does not print 69

R

Radio component:

safety notes 12
Rechargeable battery 31

see Battery 31
Regulatory information

Tablet PCs with radio device 80

Tablet PCs without radio device 77

S

Safety notes 12
Screen

no screen display 68
Security functions 59

SystemLock 60
Security functions,

SmartCard 60
Security Lock 59
Selecting a location 18
Self-discharge, battery 31
Setup

see B IO S Setup Utility 65
Slot

Memory cards 35
Status indicators 20

Summer time 67
Suspend/Resume button 21
Switchingonforthefirst time 19
Symbols

indicators 20
System configuration 65
System settings, BIOS Setup Utility 65

T

Tablet PC

before you travel 14

transporting 14

using 20
Tablet PC, operat ion 20
Tablet PC: switching on 21
Technical data

Mains adapter 74
The radio connection to a network does

not work 70
The Tablet PC

cannot be started 69

doesn’t work. 69
Time not correct 67
Time, daylight savings 67
Tips 66
Touch scree n

difficult to read 68

notes 23

reflected glare 68

remains blank 67
touchscreen is too dark 67
Transport

Transport damage 17
Transportation 14
Travel, Tablet PC 14
Troubleshooting 66

U

USB ports 63
Using the Kensington Lock Cable 59

W

Webcam 30
Wireless LAN:

safety notes 12

84 Fujitsu
