AMILO Pa 2510

Perform at your peak

Pages 3

Enjoy personal independence with the AMILO Pa 2510. With a battery life of up to 3 hours, you can watch DVDs in the
garden or send e-mails in your favourite coffee shop without the worry of looking for power. The great built in speakers
mean that you can enjoy your favourite music on the move.

The AMILO Pa 2510 is designed for home users who demand performance and mobility without compromising on
price.

Features

 Latest processor technology from AMD:

Mobile AMD Turion64  X2 Mobile Technology or
Mobile AMD Sempron Processor

 Enjoy the crystal-clear picture quality of the 15.4 “TFT

LCD WXGA display

- High brightness

- Resolution of 1280 x 800

 Connect to all your external peripherals through the

various interfaces that come as standard

 Integrated Wireless LAN to get online when and where

you want

 Graphic power with the PCI graphic card

ATI Radeon™ X1200 with up to 256MB shared VGA
memory

 Store your data comfortably on the move with the built-in

DVD drive (Dual Double Layer with up to 8.5GB
capacity)

 Fast response times with up to 2GB DDR2 memory
 Enjoy tranquillity whilst writing e-mails, surfing the

Internet or watching your latest DVD with the silent
mode functionality

 Windows Vista™ Home Premium
and Application Software

Issue May 2007

Data Sheet Issue: May 2007AMILO Pa 2510 Page 2 / 3

Operating system

Windows Vista™ Home Premium

Fujitsu Siemens Computers recommends
Windows Vista™ Home Premium

Optional Application Software

Microsoft® Works
Vista DVD Playback Pack
Nero 7 Essentials
Adobe Reader
Norton Internet Security Suite
Country specific Internet Service Providers

Quick Start Guide, Manual (on DUDVD), Safety Guide and
Warranty Guide

Drivers and Utility

Drivers and Utility DVD included.
Updates downloadable at:
http://www.fujitsu-siemens.co.uk

System, processors, architecture

Chipset: AMD M690V + SB600
CPU: AMD Turion64 X2 Mobile Technology
up to TL-60
Mobile AMD Sempron up to 3600+

Memory

2 SO-DIMM memory slots (no memory on board)
512-2048MB DDR2 RAM
512 (533/667MHz), 1024MB (667MHz) memory modules

Storage devices/drives
HDD:

80, 120, 160GB SATA hard disk (5400rpm)

ODD:

8x Multi-format DVD Burner DL (Double Layer)
Read speed: CD-ROM 24x, DVD-ROM 8x
Write speed: CD-R 24x, CD-RW20x, DVD+R6x,
DVD-R 6x, DVD+RW 4x, DVD-RW 4x,
DVD+R DL (Double Layer 8.5GB) 2,4x

Display

15.4” TFT WXGA, BrilliantView
Brightness (typ.) 180cd/m

²

ACPI functions

S1 standby (LCD off)
S3 save to RAM
S4 save to disk
S5 complete off
Silent Mode

Graphics

PCI graphic card: ATI Radeon™ X1200
up to 256MB shared VGA memory1

I/O Interfaces

3x USB 2.0 ports
1x CRT, 1x modem, 1x LAN, 1x WLAN
1x ExpressCard slot (34/54mm)
1x line in shared with microphone in,
1x headphone out shared with SPDIF
1x power supply
1x 4-in-1 card reader SD/MS/MMC/MSPRO

Communications

Built-in 56K, V.92 fax modem
10/100Mbps LAN
Integrated Wireless LAN (WLAN) solution 802.11b/g:

- speeds up to 54Mbps

- industry standard wireless LAN security support

- wide range for in-house use
For use in AT, BE, CZ, CY, DK, EE, FI, FR, DE, EL, HU,
IE, IT, LV, LT, LU, MT, NL, PL, PT, SK, SI, ES, SE, UK IS,
NO, CH, LI

Audio

7.1 SPDIF, 2 built-in speakers (1.5W), microphone in
shared with line in, headphone out combined with SPDIF
support

Launch Keys

2 Launch Keys located on top of the keyboard enabling the
user to launch the following applications:

- Media player

- Silent mode (reduce noise level / fan speed, by
reducing the CPU & VGA performance)
(Office applications, Internet and DVD playback
are not affected)

Contrast (typ.) 300:1
Resolution (physic.) 1280x800
ISO 13406-2 class II
