FUJITSU M3000 User Manual

SPARC Enterprise M3000 Server

Service Manual

Part No.: E26435-01 Manual Code: C120-E540-06EN March 2012

Copyright © 2008, 2012, Fujitsu Limited. All rights reserved. Oracle and/or its affiliates provided technical input and review on portions of this material. Oracle and/or its affiliates and Fujitsu Limited each own or control intellectual property rights relating to products and technolog y described in this

document, and such products, technology and this document are protected by copyright laws, patents, and other intellectual property laws and international treaties.

This document and the product and technology to which it pertains are distributed under licenses restricting their use, copying, distribution, and decompilation. No part of such product or technology, or of this document, may be reproduced in any form by any means without prior written authorization of Oracle and/or its affiliates and Fujitsu Limited, and their applicable licensors, if any. The furnishings of this document to you does not give you any rights or licenses, express or implied, with respect to the product or technology to which it pertains, and this document does not contain or represent any commitment of any kind on the part of Oracle or Fujitsu Limited, or any affiliate of either of them.

This document and the product and technology described in this document may incorporate third-party intellectual property copyrighted by and/or licensed from the suppliers to Oracle and/or its affiliates and Fujitsu Limited, including software and font technology.

Per the terms of the GPL or LGPL, a copy of the source code governed by the GPL or LGPL, as applicab le, is available upon request b y the End User. Please contact Oracle and/or its affiliates or Fujitsu Limited.

This distribution may include materials developed by third parties. Parts of the product may be derived from Berkeley BSD systems, licensed from the University of California. UNIX is a registered trademark in the U.S. and

in other countries, exclusively licensed through X/Open Company, Ltd. Oracle and Java are registered trademarks of Oracle and/or its affiliates. Fujitsu and the Fujitsu logo are registered trademarks of Fujitsu Limited. All SPARC trademarks are used under license and are registered trademarks of SPARC International, Inc. in the U.S. and other countries. Products bearing

SPARC trademarks are based upon architectures developed by Oracle and/or its affiliates. SPARC64 is a trademark of SPARC International, Inc., used under license by Fujitsu Microelectronics, Inc. and Fujitsu Limited. Other names may be trademarks of their respective owners.

United States Government Rights - Commercial use. U.S. Government users are subject to the standard government user license agreements of Oracle and/or its affiliates and Fujitsu Limited and the applicable provisions of the FAR and its supplements.

Disclaimer: The only warranties granted by Oracle and Fujitsu Limited, and/or any affiliate of either of them in connection with this document or any product or technology described herein are those expressly set forth in the license agreement pursuant to which the product or technology is provided. EXCEPT AS EXPRESSLY SET FORTH IN SUCH AGREEMENT, ORACLE OR FUJITSU LIMITED, AND/OR THEIR AFFILIATES MAKE NO REPRESENTATIONS OR WARRANTIES OF ANY KIND (EXPRESS OR IMPLIED) REGARDING SUCH PRODUCT OR TECHNOLOGY OR THIS DOCUMENT, WHICH ARE ALL PROVIDED AS IS, AND ALL EXPRESS OR IMPLIED CONDITIONS, REPRESENTATIONS AND WARRANTIES, INCLUDING WITHOUT LIMITATION ANY IMPLIED WARRANTY OF MERCHANTABILITY, FITNESS FOR A PARTICULAR PURPOSE OR NONINFRINGEMENT, ARE DISCLAIMED, EXCEPT TO THE EXTENT THAT SUCH DISCLAIMERS ARE HELD TO BE LEGALLY INVALID. Unless otherwise expressly set forth in such agreement, to the extent allowed by applicable law, in no event shall Oracle or Fujitsu Limited, and/or any of their affiliates have any liability to any third party under any legal theory for any loss of revenues or profits, loss of use or data, or business interruptions, or for any indirect, special, incidental or consequential damages, even if advised of the possibility of such damages.

DOCUMENTATION IS PROVIDED “AS IS” AND ALL EXPRESS OR IMPLIED CONDITIONS, REPRESENTATIONS AND WARRANTIES, INCLUDING ANY IMPLIED WARRANTY OF MERCHANTABILITY, FITNESS FOR A PARTICULAR PURPOSE OR NON-INFRINGEMENT, ARE DISCLAIMED, EXCEPT TO THE EXTENT THAT SUCH DISCLAIMERS ARE HELD TO BE LEGALLY INVALID.

Please

Recycle

Copyright © 2008, 2012, Fujitsu Limited. Tous droits réservés. Oracle et/ou ses sociétés affiliées ont fourni et vérifié des donn ées tech niques de certaines parties de ce composant. Oracle et/ou ses sociétés affiliées et Fujitsu Limited détiennent et contrôlent chacune des droits de propriété intellectuelle relatifs aux produits et

technologies décrits dans ce document. De même, ces produits, technologies et ce document sont protégés par des lois sur le copyright, des brevets, d’autres lois sur la propriété intellectuelle et des traités internationaux.

Ce document, le produit et les technologies afférents sont exclusivement distribués avec des licences qui en restreignent l’utilisation, la copie, la distribution et la décompilation. Aucune partie de ce produit, de ces technologies ou de ce document ne peut être reproduite sous quelque forme que ce soit, par quelque moyen que ce soit, sans l’autorisation écrite préalable d’Oracle et/ou ses sociétés affiliées et de Fujitsu Limited, et de leurs éventuels bailleurs de licence. Ce document, bien qu’il vous ait été fourni, ne vous confère aucun droit et aucune licence, expresses ou tacites, concernant le produit ou la technologie auxquels il se rapporte. Par ailleurs, il ne contient ni ne représente aucun engagement, de quelque type que ce soit, de la part d’Oracle ou de Fujitsu Limited, ou des sociétés affiliées de l’une ou l’autre entité.

Ce document, ainsi que les produits et technologies qu’il décrit, peuvent inclure des droits de propriété intellectuelle de parties tierces protégés par copyright et/ou cédés sous licence par des fournisseurs à Oracle et/ou ses sociétés affiliées et Fujitsu Limited, y compris des logiciels et des technologies relatives aux polices de caractères.

Conformément aux conditions de la licence GPL ou LGPL, une copie du code source régi par la licence GPL ou LGPL, selon le cas, est disponible sur demande par l’Utilisateur final. Veuillez contacter Oracle et/ou ses sociétés affiliées ou Fujitsu Limited.

Cette distribution peut comprendre des composants développés par des parties tierces. Des parties de ce produit peuvent être dérivées des systèmes Berkeley BSD, distribués sous licence par l’Université de Californie. UNIX est une marque

déposée aux États-Unis et dans d’autres pays, distribuée exclusivement sous licence par X/Open Company, Ltd. Oracle et Java sont des marques déposées d’Oracle Corporation et/ou de ses sociétés affiliées. Fujitsu et le logo Fujitsu sont des marques déposées de

Fujitsu Limited. Toutes les marques SPARC sont utilisées sous licence et sont des marques déposées de SPARC International, Inc., aux États-Unis et dans d’autres pays. Les

produits portant la marque SPARC reposent sur des architectures développées par Oracle et/ou ses sociétés affiliées. SPARC64 est une marque de SPARC International, Inc., utilisée sous licence par Fujitsu Microelectronics, Inc. et Fujitsu Limited. Tout autre nom mentionné peut corresp ondre à des marq ues appartenant à d’autres propriétaires.

Avis de non-responsabilité : les seules garanties octroyées par Oracle et Fujitsu Limited et/ou toute société affiliée de l’une ou l’autre entité en rapport avec ce document ou tout produit ou toute technologie décrits dans les présentes correspondent aux garanties expressément stipulées dans le contrat de licence régissant le produit ou la technologie fournis. SAUF MENTION CONTRAIRE EXPRESSÉMENT STIPULÉE DANS CE CONTRAT, ORACLE OU FUJITSU LIMITED ET LES SOCIÉTÉS AFFILIÉES À L’UNE OU L’AUTRE ENTITÉ REJETTENT TOUTE REPRÉSENTATION OU TOUTE GARANTIE, QUELLE QU’EN SOIT LA NATURE (EXPRESSE OU IMPLICITE) CONCERNANT CE PRODUIT, CETTE TECHNOLOGIE OU CE DOCUMENT, LESQUELS SONT FOURNIS EN L’ÉTAT. EN OUTRE, TOUTE S LES CONDITIONS, REPRÉSENTATIONS ET GARANTIES EXPRESSES OU TACITES, Y COMPRIS NOTAMMENT TOUTE GARANTIE IMPLICITE RELATIVE À LA QUALITÉ MARCHANDE, À L’APTITUDE À UNE UT ILISATION PARTICULIÈRE OU À L’ABSENCE DE CONTREFAÇON, SONT EXCLUES, DANS LA MESURE AU TORISÉE PAR LA LOI APPLICABLE. Sauf mention contraire expressément stipulée dans ce contrat, dans la mesure autorisée par la loi applicable, en aucun cas Oracle ou Fujitsu Limited et/ou l’une ou l’autre de leurs sociétés affiliées ne sauraient être tenues responsables envers une quelconque partie tierce, sous quelque théorie juridique que ce soit, de tout manque à gagner ou de perte de profit, de problèmes d’utilisation ou de perte de données, ou d’interruptions d’activités, ou de tout dommage indirect, spécial, secondaire ou consécutif, même si ces entités ont été préalablement informées d’une telle éventualité.

LA DOCUMENTATION EST FOURNIE « EN L’ÉTAT » ET TOUTE AUTRE CONDITION, DÉCLARATION ET GARANTIE, EXPRESSE OU TACITE, EST FORMELLEMENT EXCLUE, DANS LA MESURE AUTORISÉE PAR LA LOI EN VIGUEUR, Y COMPRIS NOTAMMENT TOUTE GARANTIE IMPLICITE RELATIVE À LA QUALITÉ MARCHANDE, À L’APTITUDE À UNE UTILISATION PARTICULIÈRE OU À L’ABSENCE DE CONTREFAÇON.

Preface xiii

1. Safety Precautions for Maintenance 1–1

1.1 ESD Precautions 1–1

1.2 Server Precautions 1–3

1.2.1 Electrical Safety Precautions 1–3

1.2.2 Equipment Rack Safety Precautions 1–3

1.2.3 Component Handling Precautions 1–4

2. Hardware Overview 2–1

2.1 Name of Each Part 2–1

2.2 Operator Panel 2–5

2.2.1 Operator Panel Overview 2–6

2.2.2 Switches on the Operator Panel 2–7

2.2.3 LEDs on the Operator Panel 2–9

2.3 LED Functions of Components 2–11

2.4 External Interface Port on Rear Panel 2–13

2.5 Labels 2–17

3. Troubleshooting 3–1

3.1 Emergency Power Off 3–1

3.2 Failure Diagnostic Method 3–2

3.3 Checking the Server and System Configuration 3–4

3.3.1 Checking the Hardware Configuration and FRU Status 3–4

3.3.1.1 Checking the Hardware Configuration. 3–5

3.3.2 Checking the Software and Firmware Configurations 3–6

3.3.2.1 Checking the Software Configuration 3–7

3.3.2.2 Checking the Firmware Configuration 3–7

3.3.2.3 Downloading Error Log Information 3–7

3.4 Error Conditions 3–8

3.4.1 Predictive Self-Healing Tools 3–8

3.4.2 Monitoring Output 3–10

3.4.3 Messaging Output 3–10

3.5 Using Troubleshooting Commands 3–11

3.5.1 Using the showhardconf Command 3–11

3.5.2 Using the showlogs Command 3–14

3.5.3 Using the showstatus Command 3–15

3.5.4 Using the fmdump Command 3–16

3.5.4.1 fmdump -V Command 3–16

3.5.4.2 fmdump -e Command 3–17

3.5.5 Using the fmadm Command 3–17

3.5.5.1 Using the fmadm faulty Command 3–17

3.5.5.2 fmadm repair Command 3–18

3.5.5.3 fmadm config Command 3–18

3.5.6 Using the fmstat Command 3–19

3.6 General Oracle Solaris Troubleshooting Commands 3–19

3.6.1 Using the iostat Command 3–20

3.6.1.1 Options 3–20

3.6.2 Using the prtdiag Command 3–21

vi SPARC Enterprise M3000 Server Service Manual • March 2012

3.6.2.1 Options 3–21

3.6.3 Using the prtconf Command 3–23

3.6.3.1 Options 3–24

3.6.4 Using the netstat Command 3–26

3.6.4.1 Options 3–26

3.6.5 Using the ping Command 3–27

3.6.5.1 Options 3–27

3.6.6 Using the ps Command 3–28

3.6.6.1 Options 3–29

3.6.7 Using the prstat Command 3–29

3.6.7.1 Options 3–30

4. FRU Replacement Preparation 4–1

4.1 Tools Required for Maintenance 4–1

4.2 FRU Replacement and Installation Methods 4–2

4.2.1 FRU Replacement 4–2

4.2.2 FRU Installation 4–4

4.3 Active Replacement/Active Addition 4–5

4.3.1 Releasing a FRU from a Domain 4–5

4.3.2 FRU Removal and Replacement 4–6

4.3.3 Configuring a FRU in a Domain 4–6

4.3.4 Verifying the Hardware Operation 4–7

4.4 Hot Replacement/Hot Addition 4–7

4.4.1 FRU Removal and Replacement (Power supply unit/Fan unit) 4–8

4.4.2 Verifying the Hardware Operation (Power supply unit/Fan unit) 4–10

4.4.3 Verifying the Hardware Operation (Hard disk drive) 4–11

4.5 Cold Replacement/Cold Addition 4–12

4.5.1 Powering off the Server 4–12

Contents vii

4.5.1.1 Power-off by Using the XSCF Command 4–12

4.5.1.2 Power off by Using the Operator Panel 4–13

4.5.2 FRU Removal and Replacement 4–13

4.5.3 Powering on the Server 4–13

4.5.3.1 Power-on by Using the XSCF Command 4–13

4.5.3.2 Power-on by Using the Operator Panel 4–14

4.5.4 Verifying the Hardware Operation 4–15

5. Internal Components Access 5–1

5.1 Sliding the Server Into and Out of the Equipment Rack 5–1

5.1.1 Sliding the Server Out from the Equipment Rack 5–1

5.1.2 Sliding the Server into the Equipment Rack 5–3

5.2 Removing and Attaching the Top Cover 5–3

5.2.1 Removing the Top Cover 5–3

5.2.2 Attaching the Top Cover 5–4

5.3 Removing and Attaching the Air Duct 5–4

5.3.1 Removing the Air Duct 5–4

5.3.2 Attaching the Air Duct 5–6

5.4 Removing and Attaching the Fan Cover 5–7

5.4.1 Removing the Fan Cover 5–7

5.4.2 Attaching the Fan Cover 5–8

6. Motherboard Unit Replacement 6–1

6.1 Accessing the Motherboard Unit 6–4

6.2 Removing the Motherboard Unit 6–7

6.3 Mounting the Motherboard Unit 6–8

6.4 Reassembling the Server 6–9

7. Replacement and Installation of Memory 7–1

7.1 Memory Mounting Rules 7–3

viii SPARC Enterprise M3000 Server Service Manual • March 2012

7.1.1 Confirmation of DIMM Information 7–3

7.1.2 Memory Mounting Conditions 7–4

7.2 Accessing the DIMMs 7–7

7.3 Removing the DIMMs 7–8

7.4 Installing the DIMMs 7–9

7.5 Reassembling the Server 7–9

8. Replacement and Installation of PCIe Cards 8–1

8.1 Accessing a PCIe Card 8–3

8.2 Removing a PCIe Card 8–4

8.3 Mounting a PCIe Card 8–5

8.4 Reassembling the Server 8–5

9. Replacement and Installation of a Hard Disk Drive (HDD) 9–1

9.1 Accessing a Hard Disk Drive 9–3

9.1.1 Active Replacement 9–3

9.1.2 Hot Replacement 9–3

9.1.3 Cold Replacement 9–4

9.2 Removing a Hard Disk Drive 9–4

9.3 Installing a Hard Disk Drive 9–6

9.4 Reassembling the Server 9–6

9.4.1 Active Replacement 9–6

9.4.2 Hot Replacement 9–7

9.4.3 Cold Replacement 9–7

10. Replacing the Hard Disk Drive Backplane 10–1

10.1 Accessing the Hard Disk Drive Backplane 10–2

10.2 Removing the Hard Disk Drive Backplane 10–3

10.3 Mounting the Hard Disk Drive Backplane 10–5

10.4 Reassembling the Server 10–6

Contents ix

11. CD-RW/DVD-RW Drive Unit (DVDU) Replacement 11–1

11.1 Identifying the Type of CD-RW/DVD-RW Drive Unit 11–3

11.2 Accessing the CD-RW/DVD-RW Drive Unit 11–4

11.3 Removing the CD-RW/DVD-RW Drive Unit 11–5

11.4 Mounting the CD-RW/DVD-RW Drive Unit 11–6

11.5 Reassembling the Server 11–6

12. Power Supply Unit Replacement 12–1

12.1 Accessing a Power Supply Unit 12–3

12.2 Removing the Power Supply Unit 12–3

12.3 Mounting the Power Supply Unit 12–5

12.4 Reassembling the Server 12–5

13. Fan Unit Replacement 13–1

13.1 Accessing a Fan Unit 13–3

13.2 Removing a Fan Unit 13–4

13.3 Mounting a Fan Unit 13–5

13.4 Reassembling the Server 13–5

14. Fan Backplane Replacement 14–1

14.1 Accessing the Fan Backplane 14–2

14.2 Removing the Fan Backplane 14–5

14.3 Mounting the Fan Backplane 14–6

14.4 Reassembling the Server 14–6

15. Operator Panel Replacement 15–1

15.1 Accessing the Operator Panel 15–3

15.2 Removing the Operator Panel 15–4

15.3 Mounting the Operator Panel 15–5

15.4 Reassembling the Server 15–5

x SPARC Enterprise M3000 Server Service Manual • March 2012

A. Components List A–1

B. FRU List B–1

B.1 Server Overview B–1

B.2 Motherboard Unit B–2

B.2.1 Memory (DIMM) B–3

B.2.2 PCIe Slot B–3

B.2.3 CPU B–4

B.2.4 XSCF Unit B–4

B.3 Drive B–5

B.3.1 Hard Disk Drive B–5

B.3.2 CD-RW/DVD-RW Drive Unit (DVDU) B–6

B.4 Power Supply Unit B–6

B.5 Fan Unit B–7

C. External Interface Specifications C–1

C.1 Serial Port C–2

C.2 UPC Port C–2

C.3 USB Port C–3

C.4 SAS Port C–3

C.5 Connection Diagram for Serial Cable C–4

D. UPS Controller D–1

D.1 Overview D–1

D.2 Signal Cable D–2

D.3 Configuration of Signal Lines D–3

D.4 Power Supply Conditions D–4

D.4.1 Input Circuit D–4

D.4.2 Output Circuit D–5

D.5 UPS Cable D–5

Contents xi

D.6 Connections D–6

E. DC Power Supply Model E–1

E.1 The Server Views E–2

E.2 LED Functions of Power Supply Unit E–4

E.3 Electrical Specifications E–5

E.4 Using the showhardconf Command E–6

F. Reactivating a Hardware RAID Boot Volume F–1

Abbreviations Abbreviations–1

Index Index–1

xii SPARC Enterprise M3000 Server Service Manual • March 2012

Preface

This manual describes how to service SPARC Enterprise M3000 server from Oracle and Fujitsu. This document is written for maintenance providers who have received formal service training. References herein to the M3000 server are reference to the SPARC Enterprise M3000 server.

This preface includes the following sections:

■ “Audience” on page xiii

■ “Related Documentation” on page xiv

■ “Text Conventions” on page xv

■ “Notes on Safety” on page xv

■ “Syntax of the Command-Line Interface (CLI)” on page xvi

■ “Documentation Feedback” on page xvi

Audience

This guide is written for experienced system administrators with working knowledge of computer networks and advanced knowledge of the Oracle Solaris Operating System (Oracle Solaris OS).

xiii

Safety Precautions for Maintenance

This chapter provides safety precautions required for maintenance.

■ Section 1.1, “ESD Precautions” on page 1-1

■ Section 1.2, “Server Precautions” on page 1-3

1.1 ESD Precautions

To ensure that you and bystanders are not exposed to harm and to prevent damage to the system, observe the following safety precautions.

TABLE 1-1 ESD Precautions

Item Precaution

ESD connector/wrist strap Connect the ESD connector to your server and wear the antistatic wrist strap

when handling printed circuit boards. See connection destination.

Conductive mat An approved conductive mat provides protection from static damage when

used with a wrist strap. The mat also cushions and protects small parts that are attached to printed circuit boards.

ESD safe packaging box Place a printed board or component in the ESD safe packaging box after you

remove it.

FIGURE 1-1, for the wrist strap

1-1

FIGURE 1-1 Wrist Strap Connection Destination

■ Hard disk drive or fan unit:

Connect to one of two thumbscrews on the front of the server.

■ FRU* other than hard disk drive and fan unit

Connect to either upper right on the front or upper left on the rear of the server.

* FRU: Field Replaceable Unit

Caution – Do not connect the wrist strap cable to the conductive mat. Connect it

directly to the server.

The wrist strap and FRU must have the same level of potential.

1-2 SPARC Enterprise M3000 Server Service Manual • March 2012

1.2 Server Precautions

When maintaining the server, observe the following precautions for your protection.

■ Follow all cautions, warnings, and instructions marked on the server.

Caution – Do not insert any object in an opening of the server. If any object comes

into contact with a high-voltage part or short-circuits a component, fire or electric shock might result.

■ Refer servicing of the server to the service engineer.

1.2.1 Electrical Safety Precautions

■ Ensure that the voltage and frequency of the power source to be used matches the

electrical rating labels on the server.

■ Wear antistatic wrist straps when handling hard disk drives, motherboard units,

or other printed circuit boards.

■ Use grounded power outlets as described in the SPARC Enterprise M3000 Server

Installation Guide.

Caution – Do not make mechanical or electrical modifications. We are not

responsible for regulatory compliance of modified servers.

1.2.2 Equipment Rack Safety Precautions

■ The equipment racks must be anchored to the floor, ceiling, or to adjacent frames.

■ Some equipment racks are supplied with a Quake-Resistant Options Kit or

stabilizer, which supports the weight of the server when it is extended on its slide rails. This prevents the equipment from toppling over during installation or maintenance.

■ In the following cases, a safety evaluation must be conducted by the service

engineer prior to installation or maintenance work.

■ When no Quake-Resistant Options Kits or stabilizers are attached and the

equipment rack is not anchored to the floor, ensure safety by confirming that the server does not fall over when it is pulled out from the slide rails.

Chapter 1 Safety Precautions for Maintenance 1-3

■ When the equipment rack is mounted on a raised floor, ensure that the raised

floor has sufficient strength to withstand the weight upon it when the server is extended on its slide rails. Fix the equipment rack through the raised floor to the concrete floor below it, using a proprietary mounting kit for this purpose.

Caution – If more than one server is installed in an equipment rack, maintain the

servers one at a time.

For details of equipment racks, see the SPARC Enterprise Equipment Rack Mounting Guide.

1.2.3 Component Handling Precautions

Caution – The server is easily damaged by static electricity. To prevent damage to

printed circuit boards, wear a wrist strap and connect it to the server prior to starting maintenance.

Caution – Do not bend the motherboard unit (MBU) or the components mounted

on circuit boards might be damaged.

To prevent the motherboard unit from being bent, observe the following precautions:

■ Hold the motherboard unit by the handle, where the board stiffener is located.

■ When removing the motherboard unit from the packaging, keep the motherboard

unit horizontal until you lay it on the cushioned conductive mat.

■ Connectors and components on the motherboard unit have thin pins that bend

easily. Therefore, do not place the motherboard unit on a hard surface.

■ Be careful not to damage the small parts located on both sides of the motherboard unit.

Caution – The heat sinks can be damaged by incorrect handling. Do not touch the

heat sinks while replacing or removing motherboard units. If a heat sink is loose or broken, obtain a replacement motherboard unit. When storing or carrying a motherboard unit, ensure that the heat sinks have sufficient protection.

Caution – When removing a cable such as the LAN cable, if your fingers do not

reach the latch lock of the connecter, use a flat head screwdriver to push the latch to disconnect the cable. If you forcibly insert your fingers into the service clearance, the LAN port of the motherboard unit of PCI Express (PCIe) cards may be damaged.

1-4 SPARC Enterprise M3000 Server Service Manual • March 2012

CHAPTER

Hardware Overview

This chapter explains the names of components and also explains the LEDs on the operator panel and rear panel.

■ Section 2.1, “Name of Each Part” on page 2-1

■ Section 2.2, “Operator Panel” on page 2-5

■ Section 2.3, “LED Functions of Components” on page 2-11

■ Section 2.4, “External Interface Port on Rear Panel” on page 2-13

■ Section 2.5, “Labels” on page 2-17

2.1 Name of Each Part

This section explains the names of parts mounted on the M3000 server.

Among these parts, those which can be replaced in the field by a certified field engineer are called Field Replaceable Units (FRU). For information on the actual replacement/expansion procedure for FRUs, see Chapter 6 to Chapter 15.

The server consists of a chassis in which various components are mounted, top cover to protect the mounted components, front panel, and rear panel. An operator panel is located on the front panel, and ports used to connect external interfaces are located on the rear panel. From the LEDs on the operator panel and rear panel, error and other status information can be checked. For details, see Section 2.2, “Operator

Panel” on page 2-5 to Section 2.4, “External Interface Port on Rear Panel” on page 2-13.

2-1

FIGURE 2-1, FIGURE 2-2 and FIGURE 2-3 are the internal view, front view, and rear view

CPU

CD-RW/DVD-RW drive unit (DVDU)

Fan unit (FAN_A)

Memory (DIMM) XSCF unit (XSCFU)

PCIe slot

Power supply unit (PSU)

DC-DC converter

(DDC)

Fan backplane (FANBP_B)

PCIe card (PCIe)

Hard disk drive backplane (HDDBP)

Motherboard unit

of the server, respectively, and they indicate the names and abbreviated names of main components.

FIGURE 2-1 Server (Internal View)

2-2 SPARC Enterprise M3000 Server Service Manual • March 2012

Note – The form of the DC-DC converter may be different depending on the

motherboard unit which is mounted.

FIGURE 2-2 Server (Front View)

12 34

Location Number Component

1 Fan unit (FAN_A)

2 Operator panel (OPNL)

3 Hard disk drive (HDD) (2.5-inch SAS disk)

4 CD-RW/DVD-RW drive unit (DVDU)

Chapter 2 Hardware Overview 2-3

FIGURE 2-3 Server (Rear View) (AC Power Supply Model)

123456 7

Location Number Component

1 Power supply unit (PSU)

2PCIe slot

3RCI port

4 USB port (for XSCF)

5 Serial port (for XSCF)

6 LAN port (for XSCF)

7UPC port

8 Serial Attached SCSI (SAS) port

9 Gigabit Ethernet (GbE) port (for OS)

* For information on whether the RCI function is supported for your server, see the

SPARC Enterprise M3000/M4000/M5000/M8000/M9000 Servers Product Notes.

2-4 SPARC Enterprise M3000 Server Service Manual • March 2012

2.2 Operator Panel

The operator panel has the important function of controlling the power of the server. The operator panel is usually locked with a key to prevent the server from being mistakenly powered off during system operation.

Before starting maintenance work, ask the system administrator to unlock the operator panel.

Chapter 2 Hardware Overview 2-5

2.2.1 Operator Panel Overview

The system administrator or service engineer checks the operating status of the server with LEDs or operates the power supply with the power switch. shows the location of the operator panel.

FIGURE 2-4 Operator Panel Location

FIGURE 2-4

Location Number Component

1 POWER LED

2 XSCF STANDBY LED

3 CHECK LED

4 Power button

5 Mode switch (key switch)

2-6 SPARC Enterprise M3000 Server Service Manual • March 2012

2.2.2 Switches on the Operator Panel

TABLE 2-1 depicts the functions of the switches on the operator panel.

The switches on the operator panel include the mode switch for setting the operation mode and the power switch for turning on and off the server.

TABLE 2-1 Switches (Operator Panel)

Switch Name Description of Function

Mode Switch

(Key Switch)

Power button This button is used to turn on or turn off the power to the

Holding down the button for a short time (less than 4 seconds)

Holding down the button for a long time in Service mode (4 seconds or longer)

* In normal operation, the server is powered on only when the data center environmental conditions satisfy the specified values. Then,

the server remains in the reset state until the operating system is booted.

Locked Normal operation mode

Service Mode for maintenance

This switch is used to set the operation mode for the server. Insert the special key that is under the customer's control, to

switch between modes.

• The system can be powered on with the power button, but it cannot be powered off with the power button.

• The key can be pulled out at this key position.

• The system can be powered on and off with the power button.

• The key cannot be pulled out at this key position.

• To stop and maintain the server, set the mode to Service.

server (a domain). Power on and power off are controlled by pressing this button

in different patterns, as described below.

Regardless of the mode switch setting, the server is powered on.

If set in the XSCF, facility (air conditioners) power-on and warm-up processing is skipped.

• If power to the server is on, OS shutdown processing is executed for all domains before the system is powered off.

• If the server is being powered on, the power-on processing is cancelled, and the server is powered off.

• If the server is being powered off, the operation of the power button is ignored, and the power-off processing is continued.

Chapter 2 Hardware Overview 2-7

TABLE 2-2 shows the function of the mode switch.

TABLE 2-2 Mode Switch Function

Function Mode Switch

Locked Service

Inhibition of Break Signal Reception Enabled Reception of the

Break signal can be enabled or disabled for each domain using

setdomainmode

command.

Power On/Off by power button Only Power On is

enabled.

Disabled

Enabled

2-8 SPARC Enterprise M3000 Server Service Manual • March 2012

2.2.3 LEDs on the Operator Panel

TABLE 2-3 lists the server states displayed with the LEDs on the operator panel.

The three LED indicators on the operator panel indicate the following:

■ General system status

■ System error warning

■ System error location

Besides the states listed in

TAB LE 2 -3, the operator panel also displays various states

of the server using combinations of the three LEDs. are displayed in the course of operation from power-on to power-off of the server.

The blinking interval is 1 second (1 Hz).

TABLE 2-3 LEDs on the Operator Panel

Icon Name Status Description

POWER LED Green Indicates the server power status.

• On: The power to the server (a domain) is on.

• Off: The power to the server is off.

• Blinking: The server is powered off.

XSCF

XSCF STANDBY LED

CHECK LED Amber Indicates that the server has detected an error. This is

Green Indicates the XSCF unit status.

• On: XSCF unit is functioning normally.

• Off: Input power source is off or is just after turned on, and

• Blinking: System initialization is in progress after power

sometimes called a locator.

• On: An error that hinders startup was detected.

• Off: Normal, or power is not being supplied.

• Blinking: Indicates that the unit is a maintenance target.

TAB LE 2 -4 indicates the states that

XSCF unit is stopped.

was turned on.

In service mode, break signals can be suppressed. If the key position is switched to Service, the server will boot into service mode the next time it reboots. Service is selected by default at the initial power-on.

Chapter 2 Hardware Overview 2-9

TABLE 2-4 State Display by Combination of LEDs on the Operator Panel

Name Description

POWER

XSCF STANDBY CHECK

XSCF

Off Off Off Power is not being supplied.

Off Off On Power has been turned on.

Off Blinking Off The XSCF unit is being initialized.

Off Blinking On An error occurred in the XSCF unit.

Off On Off The XSCF unit is in the standby state.

The server is waiting for power-on of the air conditioning facilities in the data center.

On On Off Warm-up standby processing is in progress (power is

turned on after the end of processing). The power-on sequence is in progress. The server is in operation.

Blinking On Off The power-off sequence is in progress.

(The fan units are stopped after the end of processing.)

* READY LED is referred to when the XSCF unit status is indicated.

2-10 SPARC Enterprise M3000 Server Service Manual • March 2012

2.3 LED Functions of Components

This section explains the LEDs of each component. When replacing a FRU, check in advance the states of LEDs.

Normal system state can be confirmed by checking the operator panel. If an error occurs in an individual hardware component in the server, the LEDs of the component containing the hardware component which caused the error will indicate the error location. However, some components such as DIMMs do not have LEDs.

To check the state of a component that has no LEDs, use an XSCF Shell command such as showhardconf in the maintenance terminal. For details, see

TABLE 2-5 describes the component LEDs and their functions.

TABLE 2-5 Component LEDs and Their Functions

Component Name Status Description

Motherboard unit (MBU)

POWER Indicates whether the MBU is operating.

On (green) Indicates that the motherboard is operating. The motherboard

cannot be removed from the server while the POWER LED is on.

Blinking (green)

Off Indicates that the MBU is stopped. The MBU can be

CHECK Indicates the motherboard unit status.

On (amber) Indicates that an error occurred in the MBU.

Off Indicates that the MBU is in the normal state.

Indicates that the MBU is being incorporated into the system or being disconnected from the system.

disconnected and replaced.

TABLE 3-1.

Chapter 2 Hardware Overview 2-11

TABLE 2-5 Component LEDs and Their Functions (Continued)

Component Name Status Description

Hard disk drive (HDD)

Indicates that the hard disk drive can be removed. However, this LED is not used.

CHECK On (amber) Indicates that an error occurred in the HDD. However, this

LED stays on for several minutes (until initialization starts) immediately after power-on. This state does not indicate an error.

Blinking

Indicates that the HDD is ready to be replaced.

(amber)

Off Indicates that the HDD is in the normal state.

READY On (green) Indicates that the HDD is operating. The HDD cannot be

removed (cannot be replaced).

Blinking (green)

Indicates that the HDD is performing communication. The HDD cannot be removed (cannot be replaced).

Off The HDD can be replaced.

Power supply unit (PSU)

DC On (green) Indicates that power is turned on and being supplied.

Off Indicates that power is turned off and not being supplied.

AC On (green) Indicates that input power is being supplied to the power

supply unit.

Off Indicates that input power is not being supplied to the power

supply unit.

CHECK On (amber) Indicates that an error occurred in the PSU.

Blinking

Indicates that the power supply unit is ready to be replaced.

(amber)

Off Indicates that the PSU is in the normal state.

Fan unit (FAN_A) CHECK On (amber) Indicates that an error occurred in the fan unit.

Blinking

Indicates that the fan unit is ready to be replaced.

(amber)

Off Indicates that the fan unit is in the normal state.

2-12 SPARC Enterprise M3000 Server Service Manual • March 2012

TABLE 2-5 Component LEDs and Their Functions (Continued)

Component Name Status Description

LAN port display part

ACTIVE On (green) Indicates that communication is being performed through the

LAN port.

Off Indicates that communication is not being performed through

the LAN port.

LINK SPEED

On (amber) Indicates that the communication speed of the LAN port is 1

Gbps.

On (green) Indicates that the communication speed of the LAN port is

100 Mbps.

Off Indicates that the communication speed of the LAN port is 10

Mbps.

2.4 External Interface Port on Rear Panel

This section shows the location of the external interface ports located on the server rear panel and explains their functions.

Chapter 2 Hardware Overview 2-13

FIGURE 2-5 External Interface Port Locations

12345 6

789101112

2-14 SPARC Enterprise M3000 Server Service Manual • March 2012

TABLE 2-6 External Interface Port Functions

Location Number Component Description

1 RCI port Used to connect the server to a peripheral device

having a RCI connector to enable power interlocking and error monitoring.

For information on whether the RCI function is supported for your server, see the SPARC Enterprise

M3000/M4000/M5000/M8000/M9000 Servers Product Notes.

2 USB port (for XSCF) Exclusive for maintenance personnel. Cannot be

connected to general-purpose USB devices.

3 Serial port (for XSCF) Connects to the XSCF unit through serial

connection to set up and manage the server.

4LAN port 1

(for XSCF)

Accommodates a 100Base-TX LAN cable to set up the server and display status.

• XSCF Shell (command-line interface: CLI):

• XSCF Web (browser user interface: BUI):

5LAN port 0

(for XSCF)

Through CLI or BUI, the user or system administrator monitors the server, displays status, operates domains, and displays information on the console.

6 UPC port 1 By connecting an uninterruptible power supply

(UPS) unit that has the UPS controller (UPC) interface, stable power supply is provided in the event of a failure in the power supply or even a

7UPC port 0

large-scale power failure. If a single power feed is used, connect a UPS cable

to UPC port 0. In a dual power feed, connect UPS cables to UPC ports 0 and 1.

Chapter 2 Hardware Overview 2-15

TABLE 2-6 External Interface Port Functions (Continued)

Location Number Component Description

8 GbE port 0 (for OS) Up to 4 100Base-TX/1000Base-T cables can be

connected to GbE ports. High-capacity data can be transferred at a high

speed.

9GbE port 1 (for OS)

10 GbE port 2 (for OS)

11 GbE port 3 (for OS)

12 SAS port Accommodates external Serial Attached SCSI (SAS)

devices such as a tape drive.

2-16 SPARC Enterprise M3000 Server Service Manual • March 2012

2.5 Labels

This section explains the labels and the card affixed to the server.

Note – The information on the label might differ from that shown on the affixed

labels.

■ The model number, serial number, and hardware version, all of which are

required for maintenance and management, are shown on the system faceplate label.

■ The standards label is affixed close to the system faceplate label and shows the

approval standards.

■ Safety: NRTL/C

■ Radio wave: VCCI-A, FCC-A, DOC-A, MIC

■ Safety and radio wave: CE

A label-affixed card that can be inserted or extracted is provided near the power supply unit at the right side at the rear of the server (see be inserted in such a way that the standards label faces the outside of the server and the system faceplate label faces the inside of the server.

TABLE 2-6). The card should

Chapter 2 Hardware Overview 2-17

FIGURE 2-6 Label Locations

Inside: System faceplate label

Outside: Standards label

2-18 SPARC Enterprise M3000 Server Service Manual • March 2012

CHAPTER

Troubleshooting

This chapter provides the fault diagnosis information and the actions to take for problems.

■ Section 3.1, “Emergency Power Off” on page 3-1

■ Section 3.2, “Failure Diagnostic Method” on page 3-2

■ Section 3.3, “Checking the Server and System Configuration” on page 3-4

■ Section 3.4, “Error Conditions” on page 3-8

■ Section 3.5, “Using Troubleshooting Commands” on page 3-11

■ Section 3.6, “General Oracle Solaris Troubleshooting Commands” on page 3-19

3.1 Emergency Power Off

This section explains how to power off in an emergency.

Caution – In an emergency (such as smoke or flames coming from the server),

immediately stop using the server and turn off the power supply. Regardless of the type of business, give top priority to fire prevention measures.

1. Press the power switch for more than 4 seconds to power off the server.

3-1

2. Remove the power cord clamp and disconnect the cable.

FIGURE 3-1 Power-off Method

3.2 Failure Diagnostic Method

When an error occurs, a message is displayed on the maintenance monitor in many cases. Use the flowchart in failures.

3-2 SPARC Enterprise M3000 Server Service Manual • March 2012

FIGURE 3-2 to find the correct methods for diagnosing

FIGURE 3-2 Diagnostic Method Flowchart

The XSCF

mail function sent an E-mail

message?

Start

Check whether an error message is displayed on the OS console and XSCF console.

The XSCF console displays

an error message?

Check /var/adm/messages in the Oracle Solaris OS.

FMA message?

Can the message

ID be used?

Execute fmadm to display fault information.

Enter the message ID in https://support.oracle.com/ to refer to fault information.

Execute showlogs or fmadm in the XSCF to display fault information.

Make a memo of the displayed fault information.

Contact your service engi neer.

End

YESNO

YES

Has the problem been

solved?

YES

OS panic or performance

error?

Is the power OK or

AC OK LED off?

YES

Check the power supply unit and its connection.

Chapter 3 Troubleshooting 3-3

3.3 Checking the Server and System Configuration

The operating conditions must remain the same before and after maintenance. If an error occurs in the server, save the system configuration and component status information. Confirm that the recovered state after maintenance is the same as that before maintenance.

If an error occurs in the server, one of the following messages is displayed.

■ Oracle Solaris Operating System message file

■ XSCF Shell showhardconf(8) command and showstatus(8) command

■ Management console

■ Service processor log

3.3.1 Checking the Hardware Configuration and FRU Status

To replace a faulty FRU and perform the maintenance on the server, it is important to check and understand the hardware configuration of the server and the state of each hardware component.

The hardware configuration refers to information that indicates to which layer a hardware component belongs.

The status of each hardware component refers to information on the conditions of a standard or optional component in the server: temperature, power supply voltage, CPU operating conditions, and other status information.

To check the hardware configuration and the status of each hardware component, use XSCF Shell commands from the maintenance terminal. See commands used.

TABLE 3-1 Commands for Checking Hardware Configuration

Command Description

showhardconf Displays hardware configuration.

showstatus Displays the status of a component. This command is used only when a

faulty component is checked.

3-4 SPARC Enterprise M3000 Server Service Manual • March 2012

TABLE 3-1 for the

TABLE 3-1 Commands for Checking Hardware Configuration (Continued)

Command Description

showboards Displays information on the system board (XSB).

showdcl Displays the hardware resource configuration information of a domain.

showfru Displays the setting information of a device.

The status of each component can be checked based on the On or blinking state of the component LEDs.

For the component types and LED states, see

TAB LE 2 -3 and TA BLE 2- 5.

For details of commands, see the SPARC Enterprise

M3000/M4000/M5000/M8000/M9000 Servers XSCF User's Guide and the SPARC Enterprise M3000/M4000/M5000/M8000/M9000 Servers XSCF Reference Manual.

3.3.1.1 Checking the Hardware Configuration.

To check the hardware configuration, authority (user account) to log in with the XSCF user account to the XSCF is required. The following procedure can be used to check the hardware configuration from the maintenance terminal.

Ask the system administrator for the required information, such as the user account and password. For details, see the SPARC Enterprise M3000/M4000/M5000/M8000/M9000 Servers XSCF User's Guide.

1. Log in to XSCF Shell.

2. Type showhardconf.

XSCF> showhardconf

The showhardconf command displays hardware configuration information. For details, see the SPARC Enterprise M3000/M4000/M5000/M8000/M9000 Servers XSCF User's Guide.

Chapter 3 Troubleshooting 3-5

3.3.2 Checking the Software and Firmware Configurations

The software and firmware configurations and versions affect the operation of the server. To change the configuration or investigate a problem, check the latest information and check for any problems in the software.

Software and firmware varies according to user conditions.

■ The software configuration and version can be checked in the Oracle Solaris

Operating System. Refer to the Oracle Solaris OS documentation for more information.

■ The firmware configuration and versions can be checked from the maintenance

terminal using XSCF Shell commands. Refer to the SPARC Enterprise M3000/M4000/M5000/M8000/M9000 Servers XSCF User's Guide for more detailed

information.

Check the software and firmware configuration information with assistance from the system administrator. However, if you have received login authority from the system administrator, the following commands can be used from the maintenance terminal

TABLE 3-2 Commands for Checking the Software Configuration

Command Description

showrev(1M) Displays system configuration information and Oracle Solaris OS patch information.

uname(1) Outputs current system information.

for these checks:

TABLE 3-3 Commands for Checking the XSCF Firmware Configuration

Command Description

version(8) Outputs current firmware version information.

showhardconf(8) Outputs information on the components mounted on the server.

showstatus(8) Displays the status of a component. This command is used only when a faulty

component is checked.

showboards(8) Displays XSB information. It can display information on an XSB that belongs to the

specified domain and information on all XSBs mounted. An XSB combines hardware resources on physical system boards. The M3000 server consists of a single physical system board (Uni-XSB).

showdcl(8) Displays the configuration information of a domain (hardware resource information).

showfru(8) Displays the setting information of a device.

3-6 SPARC Enterprise M3000 Server Service Manual • March 2012

3.3.2.1 Checking the Software Configuration

The following procedure can be used to check the software configuration from the domain console.

● Ty pe showrev.

# showrev

The showrev command displays system configuration information on the screen.

3.3.2.2 Checking the Firmware Configuration

Login authority is required to check the firmware configuration. The procedure below can be used to check the configuration from the maintenance terminal.

1. Log in with the account of the XSCF hardware field engineer.

2. Type version.

XSCF> version

The version command displays firmware version information on the screen. For details, see the SPARC Enterprise M3000/M4000/M5000/M8000/M9000 Servers XSCF User's Guide.

3.3.2.3 Downloading Error Log Information

To download error log information, use the XSCF log fetch function. The XSCF unit has an interface with external units so that the authorized service personnel can easily obtain useful maintenance information such as error logs.

Connect the maintenance terminal, and use the XSCF Shell or XSCF Web to download error log information to the maintenance terminal.

Chapter 3 Troubleshooting 3-7

3.4 Error Conditions

This section describes error conditions and relevant corrective actions.

This work is explained in the following sections:

■ Section 3.4.1, “Predictive Self-Healing Tools” on page 3-8

■ Section 3.4.2, “Monitoring Output” on page 3-10

■ Section 3.4.3, “Messaging Output” on page 3-10

Details of the fault information, see the SPARC Enterprise M3000/M4000/M5000/M8000/M9000 Servers XSCF User's Guide.

You can find more detailed descriptions of Oracle Solaris OS Predictive Self-Healing at the website below:

http://www.oracle.com/technetwork/systems/performance/selfheal-

138059.html

Predictive self-healing is an architecture and methodology for automatically diagnosing, reporting, and handling software and hardware error conditions. This new technology reduces the time required to debug a hardware or software problem and provides the administrator and service engineer with detailed data about each error.

3.4.1 Predictive Self-Healing Tools

In the Oracle Solaris OS, Oracle Solaris Fault Manager runs in the background. When an error occurs, the system software recognizes the error and attempts to determine the faulty hardware component. The system software also takes steps to prevent the faulty component from being used until it has been replaced. The system software performs the following activities:

■ Receives telemetry information about errors detected by the system software.

■ Diagnoses the errors.

■ Initiates predictive self-healing activities. For example, Oracle Solaris Fault

Manager can disable faulty components.

■ When possible, causes the faulty FRU to provide an LED indication of the error in

addition to populating system console messages with more details.

3-8 SPARC Enterprise M3000 Server Service Manual • March 2012

TABLE 3-4 shows typical messages generated when an error occurs. Messages are

displayed on your console and are recorded in the /var/adm/messages file.

A message in

TAB LE 3- 4 indicates that the fault has already been diagnosed. If there

was any corrective action that the system could take, the system has already taken it. If your server is still running, the corrective action continues to be taken.

TABLE 3-4 Predictive Self-Healing Messages

Output Displayed Description

Nov 1 16:30:20 dt88-292 EVENT-TIME:Tue Nov 1 16:30:20 PST 2005

Nov 1 16:30:20 dt88-292 PLATFORM:SUNW,A70, CSN:-, HOSTNAME:dt88-292

Nov 1 16:30:20 dt88-292 SOURCE:eft, REV: 1.13 SOURCE: Information on the Diagnosis Engine used to

Nov 1 16:30:20 dt88-292 EVENT-ID:afc7e660-d6094b2f-86b8-ae7c6b8d50c4

Nov 1 16:30:20 dt88-292 DESC: Nov 1 16:30:20 dt88-292 A problem was detected in the

PCI Express subsystem

Nov 1 16:30:20 dt88-292 Refer to http://sun.com/msg/SUN4-8000-0Y for more information.

Nov 1 16:30:20 dt88-292 AUTO-RESPONSE:One or more device instances may be disabled.

Nov 1 16:30:20 dt88-292 IMPACT:Loss of services provided by the device instances associated with this fault.

Nov 1 16:30:20 dt88-292 REC-ACTION:Schedule a repair procedure to replace the affected device.Use Nov 1 16:30:20 dt88-292 fmdump -v -u EVENT_ID to identify the device or contact Sun for support.

EVENT-TIME: The time stamp of the diagnosis

PLATFORM: A description of the server encountering the error

determine the error

EVENT-ID: The Universally Unique event ID for this error

DESC: A basic description of the error

WEB SITE: Where to find specific information and actions for this error

AUTO-RESPONSE: What, if anything, the system did to alleviate any follow-on problems

IMPACT: A description of what is considered to be the impact of the fault

REC-ACTION: A brief description of the corrective action the system administrator should take

Chapter 3 Troubleshooting 3-9

3.4.2 Monitoring Output

To understand error conditions, collect monitoring output information. For the collection of the information, use the commands shown in

TABLE 3-5 XSCF Commands for Checking Monitoring Output

Command Operand Description

showlogs(8) console Displays the console of a domain.

monitor Logs messages that are displayed in the message window.

panic Logs output to the console during a panic.

ipl Collects console data generated during the period of the power-on of a

domain to the completion of the Oracle Solaris OS start.

3.4.3 Messaging Output

To understand error conditions, collect messaging output information. For the collection of the information, use the commands shown in

TABLE 3-6 Commands for Checking Messaging Output

TABLE 3-5.

TABLE 3-6.

Command Operand Description

showlogs(8) env Displays the temperature history log. The environmental temperature

data and power status are indicated in 10-minute intervals. The data is stored for a maximum of six months.

power Displays power and reset information.

event Displays information reported to the system and stored it as event

logs.

error Displays error logs.

fmdump (1M) fmdump(8)

Displays FMA diagnostic results and errors. This command is provided as an Oracle Solaris OS command and XSCF Shell command.

Each error message logged by the predictive self-healing architecture has a message ID and Web address associated with the message. From this message ID and Web address, information on the most up-to-date corrective measures can be retrieved.

For details of predictive self-healing, see the Oracle Solaris OS documents.

3-10 SPARC Enterprise M3000 Server Service Manual • March 2012

3.5 Using Troubleshooting Commands

When any message listed in TABLE 3 -4 is displayed, detailed information on the error may be required. For details on troubleshooting commands, see manual pages of the Oracle Solaris OS or XSCF Shell. This section provides detailed explanations of the following commands:

■ “Using the showhardconf Command” on page 3-11

■ “Using the showlogs Command” on page 3-14

■ “Using the showstatus Command” on page 3-15

■ “Using the fmdump Command” on page 3-16

■ “Using the fmadm Command” on page 3-17

■ “Using the fmstat Command” on page 3-19

3.5.1 Using the showhardconf Command

The showhardconf command displays information on each FRU. The following information is displayed:

■ Current configuration and status

■ Number of mounted units

■ Domain information

■ Name properties of the PCIe card

Chapter 3 Troubleshooting 3-11

XSCF> showhardconf SPARC Enterprise M3000; + Serial:IKK0813023; Operator_Panel_Switch:Locked; + Power_Supply_System:Single; SCF-ID:XSCF#0; + System_Power:On; System_Phase:Cabinet Power On; Domain#0 Domain_Status:OpenBoot Execution Completed;

MBU_A Status:Normal; Ver:0101h; Serial:PP0829045F ; + FRU-Part-Number:CA07082-D902 A1 /541-3302-01 ; + CPU Status:Normal; + Freq:2.520 GHz; Type:32; + Core:4; Strand:2; + Memory_Size:8 GB; MEM#0A Status:Normal; + Code:ce0000000000000001M3 93T2950EZA-CE6 4145-473b3c23; + Type:1A; Size:1 GB; MEM#0B Status:Normal; + Code:7f7ffe00000000004aEBE10RD4AJFA-5C-E 3020-223b2918; + Type:1A; Size:1 GB; MEM#1A Status:Normal; + Code:7f7ffe00000000004aEBE10RD4AJFA-5C-E 3020-223b28af; + Type:1A; Size:1 GB; MEM#1B Status:Normal; + Code:7f7ffe00000000004aEBE10RD4AJFA-5C-E 3020-223b28ab; + Type:1A; Size:1 GB; MEM#2A Status:Normal; + Code:7f7ffe00000000004aEBE10RD4AJFA-5C-E 3020-223b283e; + Type:1A; Size:1 GB; MEM#2B Status:Normal; + Code:7f7ffe00000000004aEBE10RD4AJFA-5C-E 3020-223b2829; + Type:1A; Size:1 GB; MEM#3A Status:Normal; + Code:7f7ffe00000000004aEBE10RD4AJFA-5C-E 3020-223b2840; + Type:1A; Size:1 GB; MEM#3B Status:Normal; + Code:7f7ffe00000000004aEBE10RD4AJFA-5C-E 3020-223b2830; + Type:1A; Size:1 GB; PCI#0 Name_Property:fibre-channel; Card_Type:Other; PCI#1 Name_Property:fibre-channel; Card_Type:Other; PCI#2 Name_Property:pci; Card_Type:Other; PCI#3 Name_Property:pci; Card_Type:Other; OPNL Status:Normal; Ver:0101h; Serial:PP0829045Y ; + FRU-Part-Number:CA07082-D912 A0 /541-3306-01 ;

3-12 SPARC Enterprise M3000 Server Service Manual • March 2012

The showhardconf output continued:

PSU#0 Status:Normal; Serial:EA08260208; + FRU-Part-Number:CA01022-0720 03C /300-2193-03 ; + Power_Status:On; + Type:AC; PSU#1 Status:Normal; Serial:EA08260210; + FRU-Part-Number:CA01022-0720 03C /300-2193-03 ; + Power_Status:On; + Type:AC; FANBP_B Status:Normal; Ver:0101h; Serial:PP082704TD ; + FRU-Part-Number:CA20399-B12X 006AB/541-3304-02 ; FAN_A#0 Status:Normal; FAN_A#1 Status:Normal;

For details, see the showhardconf manual pages.

Chapter 3 Troubleshooting 3-13

3.5.2 Using the showlogs Command

The showlogs command displays information of specified logs in the order of time stamps. The information with the oldest time stamp is displayed first. The showlogs command displays the following logs:

■ Error log

■ Power log

■ Event log

■ Temperature and humidity record

■ Monitoring message log

■ Console message log

■ Panic message log

■ IPL message log

XSCF> showlogs error Date: Jun 17 11:05:32 JST 2008 Code: 80000000-c3ff0000-0173000600000000 Status: Alarm Occurred: Jun 17 11:05:32.522 JST 2008 FRU: /PSU#1 Msg: PSU shortage Date: Jun 17 13:41:46 JST 2008 Code: 80002080-7801c201-0130000000000000 Status: Alarm Occurred: Jun 17 13:41:44.861 JST 2008 FRU: /MBU_A,* Msg: Board control error (MBC link error) Date: Jun 17 13:46:31 JST 2008 Code: 60000000-cd01c701-0164010100000000 Status: Warning Occurred: Jun 17 13:46:31.158 JST 2008 FRU: /OPNL,/FANBP_B Msg: TWI access error XSCF>

3-14 SPARC Enterprise M3000 Server Service Manual • March 2012

3.5.3 Using the showstatus Command

The showstatus command displays information about faulty or degraded units that are among the FRUs composing the server and information on the units on the layers immediately above the layers of the faulty or degraded units. For each of the displayed units, an asterisk (*) indicating that the unit is faulty is displayed with any of the following status indicators, which is displayed after "Status:".

■ Normal: Normal state

■ Faulted: The unit is faulty and is not operating.

■ Degraded: The unit is operating. The unit is partly faulty or degraded and some

error has been detected. Although a faulty state is displayed for the unit, it is operating normally.

■ Deconfigured: There is no problem with the unit itself, but it is degraded due to a

configuration problem, environmental problem, or the degradation of another unit.

■ Maintenance: Maintenance is being performed. replacefru(8) or addfru(8) is

being executed.

XSCF> showstatus FANBP_B Status:Normal; * FAN_A#0 Status:Faulted; XSCF>

Chapter 3 Troubleshooting 3-15

3.5.4 Using the fmdump Command

The fmdump command displays the contents of the log managed by the module called Fault Manager.

This example assumes that only one error exists.

# fmdump TIME UUID SUNW-MSG-ID Nov 02 10:04:15.4911 0ee65618-2218-4997-c0dc-b5c410ed8ec2 SUN4-8000-0Y

3.5.4.1 fmdump -V Command

To get more detailed information you can use the -e option, as shown in the following example.

# fmdump -V -u 0ee65618-2218-4997-c0dc-b5c410ed8ec2 TIME UUID SUNW-MSG-ID Nov 02 10:04:15.4911 0ee65618-2218-4997-c0dc-b5c410ed8ec2 SUN4-8000-0Y 100% fault.io.fire.asic FRU: hc://product-id=SUNW,A70/motherboard=0 rsrc: hc:///motherboard=0/hostbridge=0/pciexrc=0

The output method using the -V option displays at least three additional lines.

■ The first line is the same information shown for console messages above,

including a time stamp, UUID, and message ID.

■ The second line is a declaration of the certainty of diagnosis. In this case we are

100 percent sure the failure is in the ASIC described. If the diagnosis may involve multiple components, you may see two lines here with 50% in each of the two lines.

■ The "FRU" line indicates what component must be replaced to return the server to

a fully operational state.

■ The "rsrc" line indicates the component that has become unusable because of this

error.

3-16 SPARC Enterprise M3000 Server Service Manual • March 2012

3.5.4.2 fmdump -e Command

To get information of the errors that caused this failure you can use the -e option, as shown in the following example.

# fmdump -e TIME CLASS Nov 02 10:04:14.3008 ereport.io.fire.jbc.mb_per

3.5.5 Using the fmadm Command

3.5.5.1 Using the fmadm faulty Command

The fmadm faulty command can be used by administrators and service personnel to view and modify system configuration parameters that are maintained by the Oracle Solaris Fault Manager. The command is primarily used to determine the status of a component involved in a fault, as shown in the following example:

# fmadm faulty STATERESOURCE / UUID

-------- -------------------------------------------------------degraded dev:////pci@1e,600000 0ee65618-2218-4997-c0dc-b5c410ed8ec2 # fmadm repair 0ee65618-2218-4997-c0dc-b5c410ed8ec2

The PCIe slot has been degraded and it is associated with the same UUID as above. Also, the "faulted" status may be displayed.

Chapter 3 Troubleshooting 3-17

3.5.5.2 fmadm repair Command

When the fmadm faulty command displays a fault, the fmadm repair command must be executed to clear the FRU information in the domain after replacement of the motherboard unit that has encountered the error. If the fmadm repair command is not executed, the error message is not cleared.

If the fmadm faulty command displays a fault, clearing the FMA resource cache on the operating system side causes no problem. Data in the cache does not need to match the hardware fault information held by the XSCF.

# fmadm repair STATERESOURCE / UUID

-------- -------------------------------------------------------degraded dev:////pci@1e,600000 0ee65618-2218-4997-c0dc-b5c410ed8ec2

3.5.5.3 fmadm config Command

The fmadm config command output displays the version number and current status of the diagnosis engine that is being used by the server. Whether the latest engine is being used can be determined by consulting the My Oracle Support web site.

# fmadm config MODULE VERSION STATUS DESCRIPTION cpumem-diagnosis 1.6 active CPU/Memory Diagnosis cpumem-retire 1.1 active CPU/Memory Retire Agent disk-transport 1.0 active Disk Transport Agent eft 1.16 active eft diagnosis engine event-transport 2.0 active Event Transport Module fabric-xlate 1.0 active Fabric Ereport Translater fmd-self-diagnosis 1.0 active Fault Manager Self-Diagnosis io-retire 1.0 active I/O Retire Agent snmp-trapgen 1.0 active SNMP Trap Generation Agent sysevent-transport 1.0 active SysEvent Transport Agent syslog-msgs 1.0 active Syslog Messaging Agent zfs-diagnosis 1.0 active ZFS Diagnosis Engine zfs-retire 1.0 active ZFS Retire Agent

3-18 SPARC Enterprise M3000 Server Service Manual • March 2012

3.5.6 Using the fmstat Command

The fmstat command reports statistical information and a set of modules that are associated with the module called Oracle Solaris Fault Manager. By using the fmstat command, statistical information about the diagnostic engine and diagnostic agent that are currently involved in fault management can be displayed.

The following output example shows that the fmd-self-diagnosis DE module (displayed also on the console output) has received accepted events.

# fmstat module ev_recv ev_acpt wait svc_t %w %b open solve memsz bufsz cpumem-diagnosis 0 0 0.0 0.0 0 0 0 0 3.0K 0 cpumem-retire 0 0 0.0 0.0 0 0 0 0 0 0 disk-transport 0 0 0.0 1793.8 0 0 0 0 40b 0 eft 0 0 0.0 0.0 0 0 0 0 1.2M 0 event-transport 0 0 0.0 0.0 0 0 0 0 210b 0 fabric-xlate 0 0 0.0 0.0 0 0 0 0 0 0 fmd-self-diagnosis 0 0 0.0 0.0 0 0 0 0 0 0 io-retire 0 0 0.0 0.0 0 0 0 0 0 0 snmp-trapgen 0 0 0.0 0.0 0 0 0 0 32b 0 sysevent-transport 0 0 0.0 2395.3 0 0 0 0 0 0 syslog-msgs 0 0 0.0 0.0 0 0 0 0 0 0 zfs-diagnosis 0 0 0.0 0.0 0 0 0 0 0 0 zfs-retire 0 0 0.0 0.0 0 0 0 0 0 0

3.6 General Oracle Solaris Troubleshooting Commands

Superuser commands of this type are useful to determine whether there is a problem with the server, network, or another server connected via the network.

This section explains the following commands:

■ “Using the iostat Command” on page 3-20

■ “Using the prtdiag Command” on page 3-21

■ “Using the prtconf Command” on page 3-23

■ “Using the netstat Command” on page 3-26

■ “Using the ping Command” on page 3-27

■ “Using the ps Command” on page 3-28

■ “Using the prstat Command” on page 3-29

Chapter 3 Troubleshooting 3-19

Most of these commands are located in the /usr/bin directory or /usr/sbin directory.

3.6.1 Using the iostat Command

The iostat command repeatedly reports terminal, drive, and I/O activity, as well as CPU utilization.

3.6.1.1 Options

TABLE 3-7 lists the options of the iostat command and how those options can help

troubleshoot the server.

TABLE 3-7 Options for iostat

Option Description How It Can Help

No option Reports status of local I/O devices. A quick three-line output of device status

-c Reports the percentages of time the system has

-e Displays device error summary statistics.

-E Displays all device error statistics. Provides information about devices:

-n Displays names in a descriptive format. The descriptive format helps identify devices.

-x Reports extended drive statistics of each drive.

spent in user mode, in system mode, waiting for I/O, and idling.

Displays the total number of errors, hardware errors, software errors, and transfer errors.

The output is in a tabular form.

information.

Quick report of CPU status

Provides a short table with accumulated errors. Identifies suspect I/O devices.

manufacturer, model number, serial number, size, and errors.

Similar to the -e option, but provides rate information. This helps identify internal devices with poor performance and other I/O devices with poor performance across the network.

3-20 SPARC Enterprise M3000 Server Service Manual • March 2012

The following example shows output for the iostat command:

# iostat -En c0t0d0 Soft Errors: 0 Hard Errors: 0 Transport Errors: 0 Model: ST3120026A Revision: 8.01 Serial No: 3JT4H4C2 Size: 120.03GB <120031641600 bytes> Media Error: 0 Device Not Ready: 0 No Device: 0 Recoverable: 0 Illegal Request: 0 c0t2d0 Soft Errors: 0 Hard Errors: 0 Transport Errors: 0 Vendor: LITE-ON Product: COMBO SOHC-4832K Revision: O3K1 Serial No: Size: 0.00GB <0 bytes> Media Error: 0 Device Not Ready: 0 No Device: 0 Recoverable: 0 Illegal Request: 0 Predictive Failure Analysis: 0

3.6.2 Using the prtdiag Command

The prtdiag command displays system configuration and diagnostic information. The diagnostic information identifies any failed FRU in the system.

The prtdiag command is located in the /usr/platform/platform-name/sbin/ directory.

The prtdiag command may indicate a slot number different from that shown elsewhere in this document. This is normal.

3.6.2.1 Options

TABLE 3-8 lists the options of the prtdiag command and how those options can help

troubleshooting.

TABLE 3-8 Options for prtdiag

Option Description How it can help

No option Lists components. Shows CPU information, memory

configuration, PCIe cards installed, OBP version, status of the mode switch, and CPU operation mode.

-v Verbose mode. Provides the same information as no option.

Additionally, displays the detail information of PCIe cards.

Chapter 3 Troubleshooting 3-21

The following example shows output for the prtdiag command in verbose mode:

# prtdiag -v System Configuration: Sun Microsystems sun4u SPARC Enterprise M3000 Server System clock frequency: 1064 MHz Memory size: 7808 Megabytes

================================== CPUs ===========================

CPU CPU Run L2$ CPU CPU LSB Chip ID MHz MB Impl. Mask

--- ---- ----------------------- ---- --- ----- --- 00 0 0, 1, 2, 3, 4, 5, 6, 7 2520 5.0 7 145

=================== Memory Configuration ==========================

Memory Available Memory DIMM # of Mirror Interleave LSB Group Size Status Size DIMMs Mode Factor

--- ------ ------------ ------- ------ ----- ------- --------- 00 A 4096MB okay 1024MB 4 no 2-way 00 B 3712MB okay 1024MB 4 no 2-way

========================= IO Devices =============================

IO Lane/Frq LSB Type LPID RvID,DvID,VnID BDF State Act,Max Name Model Logical Path

--- ----- ---- --------------- ------- ----- -------- ----------------- ----

------ ----------------------------

00 PCIe 0 aa, 8533, 10b5 2, 0, 0 okay 8, 8 pci-pciex10b5,8533 N/A /pci@0,600000/pci@0 00 PCIe 0 aa, 8533, 10b5 3, 0, 0 okay 4, 8 pci-pciex10b5,8533 N/A /pci@0,600000/pci@0/pci@0 00 PCIe 0 aa, 8533, 10b5 3, 1, 0 okay 4, 4 pci-pciex10b5,8533 N/A /pci@0,600000/pci@0/pci@1 00 PCIe 0 aa, 8533, 10b5 3, 2, 0 okay 4, 4 pci-pciex10b5,8533 N/A /pci@0,600000/pci@0/pci@2 00 PCIe 0 aa, 8533, 10b5 3, 8, 0 okay 0, 8 pci-pciex10b5,8533 N/A /pci@0,600000/pci@0/pci@8 00 PCIe 0 8, 58, 1000 4, 0, 0 okay 4, 8 scsi-pciex1000,58 LSI,1068E /pci@0,600000/pci@0/pci@0/scsi@0 00 PCIx 0 b5, 103, 1166 5, 0, 0 okay 133,133 pci-pciex1166,103 N/A /pci@0,600000/pci@0/pci@1/pci@0 00 PCI 0 a3, 1678, 14e4 6, 4, 0 okay --,133 network-pci14e4,1678 N/A /pci@0,600000/pci@0/pci@1/pci@0/network@4

3-22 SPARC Enterprise M3000 Server Service Manual • March 2012

00 PCI 0 a3, 1678, 14e4 6, 4, 1 okay --,133 network-pci14e4,1678 N/A /pci@0,600000/pci@0/pci@1/pci@0/network@4,1 00 PCIx 0 b5, 103, 1166 7, 0, 0 okay 133,133 pci-pciex1166,103 N/A /pci@0,600000/pci@0/pci@2/pci@0 00 PCI 0 a3, 1678, 14e4 8, 4, 0 okay --,133 network-pci14e4,1678 N/A /pci@0,600000/pci@0/pci@2/pci@0/network@4 00 PCI 0 a3, 1678, 14e4 8, 4, 1 okay --,133 network-pci14e4,1678 N/A /pci@0,600000/pci@0/pci@2/pci@0/network@4,1 00 PCIe 1 aa, 8533, 10b5 2, 0, 0 okay 8, 8 pci-pciex10b5,8533 N/A /pci@1,700000/pci@0 00 PCIe 1 aa, 8533, 10b5 3, 0, 0 okay 0, 8 pci-pciex10b5,8533 N/A /pci@1,700000/pci@0/pci@0 00 PCIe 1 aa, 8533, 10b5 3, 8, 0 okay 0, 8 pci-pciex10b5,8533 N/A /pci@1,700000/pci@0/pci@8 00 PCIe 1 aa, 8533, 10b5 3, 9, 0 okay 0, 8 pci-pciex10b5,8533 N/A /pci@1,700000/pci@0/pci@9 ==================== Hardware Revisions ====================

System PROM revisions:

----------------------

OBP 4.24.8 2008/04/23 15:15

=================== Environmental Status ===================

The prtdiag output continued:

Mode switch is in LOCK mode

=================== System Processor Mode ===================

SPARC64-VII mode

3.6.3 Using the prtconf Command

Similar to the show-devs command executed at the ok prompt, the prtconf command displays the devices that are configured.

The prtconf command identifies hardware that is recognized by the Oracle Solaris OS. If software applications are having problems with hardware but the hardware is not suspected of being faulty, the prtconf command can be used to check whether the Oracle Solaris software recognizes the hardware and whether a driver for the hardware is loaded.

Chapter 3 Troubleshooting 3-23

3.6.3.1 Options

TABLE 3-9 lists the options of the prtconf command and how those options can help

troubleshooting.

TABLE 3-9 Options for prtconf

Option Description How it can help

No option Displays the device tree of devices recognized

by the operating system.

-D Similar to the output of no option, but device driver names are listed.

-p Similar to the output of no option, yet is abbreviated.

-V Displays the version and date of the OpenBoot PROM firmware.

The following example shows output for the prtconf command:

# prtconf System Configuration: Sun Microsystems sun4u Memory size: 7616 Megabytes System Peripherals (Software Nodes):

If a hardware device is recognized, then it is considered to be functioning properly. If the message "(driver not attached)" is displayed for the device or sub-device, then the driver for the device is corrupt or missing.

Lists the drivers needed or used by the operating system to enable the device.

Provides a brief list of the devices.

Useful for a quick check of the firmware version.

SUNW,SPARC-Enterprise scsi_vhci, instance #0 packages (driver not attached) SUNW,probe-error-handler (driver not attached) SUNW,builtin-drivers (driver not attached) deblocker (driver not attached) disk-label (driver not attached) terminal-emulator (driver not attached) obp-tftp (driver not attached) ufs-file-system (driver not attached) chosen (driver not attached) openprom (driver not attached) client-services (driver not attached) options, instance #0 aliases (driver not attached) memory (driver not attached) virtual-memory (driver not attached) pseudo-console, instance #0

3-24 SPARC Enterprise M3000 Server Service Manual • March 2012

The prtconf output continued:

nvram (driver not attached) pseudo-mc, instance #0 cmp (driver not attached) core (driver not attached) cpu (driver not attached) cpu (driver not attached) core (driver not attached) cpu (driver not attached) cpu (driver not attached) core (driver not attached) cpu (driver not attached) cpu (driver not attached) core (driver not attached) cpu (driver not attached) cpu (driver not attached) pci, instance #0 ebus, instance #0 flashprom (driver not attached) serial, instance #0 scfc, instance #0 panel, instance #0 pci, instance #0 pci, instance #0 pci, instance #1 scsi, instance #0 tape (driver not attached) disk (driver not attached) sd, instance #1 sd, instance #0 pci, instance #2 pci, instance #0 network, instance #0 network, instance #1 (driver not attached) pci, instance #3 pci, instance #1 network, instance #2 (driver not attached) network, instance #3 (driver not attached) pci, instance #4 pci, instance #1 pci, instance #5 pci, instance #6 pci, instance #7 pci, instance #8 os-io (driver not attached) iscsi, instance #0

Chapter 3 Troubleshooting 3-25

The prtconf output continued:

pseudo, instance #0 #

3.6.4 Using the netstat Command

The netstat command displays the network status and protocol statistics.

3.6.4.1 Options

TABLE 3-10 lists the options of the netstat command and how those options can

TABLE 3-10 Options for netstat

Option Description How It Can Help

help troubleshooting.

-i Displays the interface status. The information includes packets in/out, errors in/out, collisions, and queues.

-i interval Repeats the setstat command in the intervals of as many seconds as specified after the -i option.

-p Displays the media table. Provides the MAC address for hosts on the

-r Displays the routing table. Provides routing information.

-n Replaces host names with IP addresses and

displays them.

Provides a quick overview of the network status.

Identifies intermittent or long duration network events. By piping setstat output to a file, overnight activity can be viewed all at once.

subnet.

Used when an IP address is more useful than a host name.

3-26 SPARC Enterprise M3000 Server Service Manual • March 2012

The following example shows the output for the netstat -p command:

# netstat -p Net to Media Table: IPv4 Device IP Address Mask Flags Phys Addr

------ -------------------- --------------- -------- --------------bge0 san-ff1-14-a 255.255.255.255 o 00:14:4f:3a:93:61 bge0 san-ff2-40-a 255.255.255.255 o 00:14:4f:3a:93:85 sppp0 224.0.0.22 255.255.255.255 bge0 san-ff2-42-a 255.255.255.255 o 00:14:4f:3a:93:af bge0 san09-lab-r01-66 255.255.255.255 o 00:e0:52:ec:1a:00 sppp0 192.168.1.1 255.255.255.255 bge0 san-ff2-9-b 255.255.255.255 o 00:03:ba:dc:af:2a bge0 bizzaro 255.255.255.255 o 00:03:ba:11:b3:c1 bge0 san-ff2-9-a 255.255.255.255 o 00:03:ba:dc:af:29 bge0 racerx-b 255.255.255.255 o 00:0b:5d:dc:08:b0 bge0 224.0.0.0 240.0.0.0 SM 01:00:5e:00:00:00 #

3.6.5 Using the ping Command

The ping command sends an ICMP ECHO_REQUEST packet to a network host. Depending on how the ping command is configured, troublesome network links or nodes can be identified from the displayed output. The destination host is specified in the variable hostname.

3.6.5.1 Options

TABLE 3-11 lists the options of the ping command and how those options can help

troubleshooting.

TABLE 3-11 Options for ping

Option Description How it can help

hostname The probe packet is sent to hostname and

returned.

-g hostname Forcibly routes the probe packet through a specified gateway.

-i interface Specifies through which interface to send and receive the probe packet.

Veri fie s th at a ho s t i s active on the network.

By sending the probe packet through different routes to the target host, individual routes can be tested for quality.

Enables a simple check of secondary network interfaces.

Chapter 3 Troubleshooting 3-27

TABLE 3-11 Options for ping (Continued)

Option Description How it can help

-n Replaces host names with IP addresses and displays them.

-s Continues to repeat ping at intervals of 1 second. Pressing After it is stopped, statistics are displayed.

-svR Displays the route the probe packet followed in 1-second intervals.

CTRL-C stops the execution.

Used when an IP address is more useful than a host name.

Helps identify intermittent or long duration network events. By piping ping output to a file, overnight activity can be viewed all at once.

Indicates the probe packet route and number of hops. Comparing multiple routes can identify bottlenecks.

The following example shows output for the ping -s command:

# ping -s san-ff2-17-a PING san-ff2-17-a: 56 data bytes 64 bytes from san-ff2-17-a (10.1.67.31): icmp_seq=0. time=0.427 ms 64 bytes from san-ff2-17-a (10.1.67.31): icmp_seq=1. time=0.194 ms ^C

----san-ff2-17-a PING Statistics---2 packets transmitted, 2 packets received, 0% packet loss round-trip (ms) min/avg/max/stddev = 0.172/0.256/0.427/0.102 #

3.6.6 Using the ps Command

The ps commands lists the status of processes. If no option is specified, the ps command outputs information about the processes that have the same execution user ID as the user who is executing this command and are controlled from the same control terminal as this command.

If any option is specified, the output information is controlled according to the specified option.

3-28 SPARC Enterprise M3000 Server Service Manual • March 2012

3.6.6.1 Options

TABLE 3-12 lists the options of the ps command and how those options can help

TABLE 3-12 Options for ps

Option Description How It Can Help

-e Displays information for every process. Identifies the process ID and the executable

-f Generates a full listing. Provides the following process information:

-o option Enables configurable output. The pid, pcpu,

troubleshooting.

files.

user ID, parent process ID, time when executed, and the paths to the executable files.

Provides only most important information. pmem, and comm options display process ID, percent CPU consumption, percent memory consumption, and the relevant executable file, respectively.

Knowing the percentage of resource

consumption helps identify processes that are

affecting performance and might be hung.

The following example shows output for the ps command:

# ps PID TTY TIME CMD 101042 pts/3 0:00 ps 101025 pts/3 0:00 sh #

When using sort with the -r option, the column headings are output so that the value in the first column is equal to zero.

3.6.7 Using the prstat Command

The prstat utility repeatedly examines all the active processes in the system and reports statistics based on the selected output mode and sort order. The prstat command provides output similar to the ps command.

Chapter 3 Troubleshooting 3-29

3.6.7.1 Options

TABLE 3-13 lists the options of the prstat command and how those options can help

TABLE 3-13 Options for prstat

Option Description How It Can Help

No option Displays a list of the processes sorted in

-n number Limits the number of output lines. Limits the amount of data displayed and

-s key Enables the sorting of list contents by key

-v Verbose mode Displays additional parameters.

# prstat -n 5 -s size PID USERNAME SIZE RSS STATE PRI NICE TIME CPU PROCESS/NLWP 100463 root 66M 61M sleep 59 0 0:01:03 0.0% fmd/19 100006 root 11M 9392K sleep 59 0 0:00:09 0.0% svc.configd/16 100004 root 10M 8832K sleep 59 0 0:00:04 0.0% svc.startd/14 100061 root 9440K 6624K sleep 59 0 0:00:01 0.0% snmpd/1 100132 root 8616K 5368K sleep 59 0 0:00:04 0.0% nscd/35 Total: 52 processes, 188 lwps, load averages: 0.00, 0.00, 0.00 #

troubleshooting.

Output identifies the process ID, user ID, used descending order of consumption amount of CPU resources. The list is limited to the height of the terminal window and the total number of processes. Output is automatically updated every 5 seconds. Pressing execution.

parameter.

CTRL-C stops the

amount of memory, state, CPU consumption,

and command name.

displays processes consuming many resources.

Useful keys are cpu (default), time, and size.

The following example shows output for the prstat command:

3-30 SPARC Enterprise M3000 Server Service Manual • March 2012

CHAPTER

FRU Replacement Preparation

This chapter explains the method of preparing for the safe replacement of FRUs.

■ Section 4.1, “Tools Required for Maintenance” on page 4-1

■ Section 4.2, “FRU Replacement and Installation Methods” on page 4-2

■ Section 4.3, “Active Replacement/Active Addition” on page 4-5

■ Section 4.4, “Hot Replacement/Hot Addition” on page 4-7

■ Section 4.5, “Cold Replacement/Cold Addition” on page 4-12

4.1 Tools Required for Maintenance

The actual maintenance work described in Chapter 5 to Chapter 15 requires maintenance software to confirm that the server and other components are operating correctly and to collect status information and log data on the server and components. Work for mounting, removing, or replacing a specific component requires special tools, including screwdrivers and an antistatic wrist strap. These items are generally named maintenance tools and are listed in

TABLE 4-1 Maintenance Tools

Item Part Name Use

1 Phillips screwdriver (No. 2)

2 Wrist strap For electrostatic control

3 Conductive mat For electrostatic control

4 Oracle VTS Test program

TABLE 4-1.

4-1

4.2 FRU Replacement and Installation Methods

This section explains how to replace and install FRUs.

4.2.1 FRU Replacement

There are three methods of replacing FRUs, as follows:

■ Active replacement

A target FRU is operated while the Oracle Solaris OS of the domain to which the FRU belongs is operating.

The target FRU is operated by using Oracle Solaris OS commands or XSCF commands.

Because the power supply unit (PSU) and fan unit (FAN) do not belong to any domain, they are operated by using XSCF commands regardless of the operating state of the Oracle Solaris OS.

Note – The hard disk drive will have a redundant configuration by setting the

mirroring.

Note – ■ If a hard disk drive is a nonmirrored boot device, it must be replaced

according to the cold replacement procedure.

■ If a hard disk drive is in a mirrored configuration, active replacement can be

performed on the failed drive because the mirrored hard disk drive continues to be online and functioning. The hard disk replacement procedure varies by the mirroring configuration method. When it is configured with hardware RAID, see the SPARC Enterprise M3000/M4000/M5000/M8000/M9000 Servers Administration Guide. When it is configured with software RAID, see the manuals for the software in use.

Note – Hardware RAID is available only on the M3000 server with the SPARC64

VII+ processors.

Note – To activate a hardware RAID boot volume after replacing the MBU of an

M3000 server with SPARC64 VII+ processors, see Appendix F.

4-2 SPARC Enterprise M3000 Server Service Manual • March 2012

■ Hot replacement

A target FRU is operated while the domain to which the FRU belongs is stopped.

Depending on the target FRU, there are two cases as follows:

■ Power supply unit/Fan unit: operated with XSCF commands.

■ Hard disk drive: operated directly, not by using XSCF commands.

■ Cold replacement

After all the domains are stopped and then the server is powered off, a FRU is operated.

Note – Do not operate a target FRU while the OpenBoot PROM is running (the ok

prompt is displayed). After stopping the relevant domain (power-off) or starting the Oracle Solaris OS, operate the target FRU.

TABLE 4-2 lists the access locations and applicable replacement methods for each

FRU.

TABLE 4-2 FRU Access Locations and Replacement Methods

FRU

Motherboard unit

Access Location

Top Yes No No Chapter 6

Cold Replacement

Hot Replacement

Active Replacement

Where to Find the Procedure

(MBU_A, MBU_A_2, MBU_A_3, MBU_A_4, MBU_A_5, MBU_A_6)

Memory (DIMM) Top Yes No No Chapter 7

PCIe card (PCIe) Top Yes No No Chapter 8

Hard disk drive (HDD) Front Yes Yes

Yes

‡

Chapter 9

Hard disk drive backplane (HDDBP) Top Yes No No Chapter 10

CD-RW/DVD-RW drive unit

Front/top Yes No No Chapter 11

(DVDU)

Power supply unit (PSU) Rear Yes Yes

Fan unit (FAN_A) Top Yes Yes

†

Yes

†

Chapter 12

Chapter 13

Fan backplane (FANBP_B) Top Yes No No Chapter 14

Operator panel (OPNL) Front/top Yes No No Chapter 15

* The FRU is operated directly, without using XSCF commands. † The FRU is operated with XSCF commands.

Chapter 4 FRU Replacement Preparation 4-3

‡ ■ The hard disk drive will have a redundant configuration by setting the mirroring.

■ If a hard disk drive is a nonmirrored boot device, it must be replaced according to the cold replacement procedure.

■ If a hard disk drive is in a mirrored configuration, active replacement can be performed on the failed drive because the mirrored

hard disk drive continues to be online and functioning. The hard disk replacement procedure varies by the mirroring configuration method. When it is configured with hardware RAID, see the SPARC Enterprise M3000/M4000/M5000/M8000/M9000 Servers Adminis- tration Guide. When it is configured with software RAID, see the manuals for the software in use.

4.2.2 FRU Installation

For empty slots without hard disk drives or PCIe cards, the number of mounted FRUs can be changed from 1 to the maximum number as required. There are some components that are tentatively mounted physically in the server. If such a component is a hard disk drive, it is called an HDD dummy, and if such a component is a PCIe card, it is called a PCIe slot cover. These components are necessary to protect the server from noise and to properly cool the server.

The same methods as those used for replacement are used for installation.

Note – When installing a new FRU in an empty slot, remove the HDD dummy or

PCIe slot cover and then install a new FRU.

TABLE 4-3

FRU

Motherboard unit

TABLE 4-3 lists the access location and applicable installation methods for each FRU.

FRU Access Locations and Installation Methods

Access Location Cold Addition Hot Addition

Active Addition

TopNoNoNo (MBU_A, MBU_A_2, MBU_A_3, MBU_A_4, MBU_A_5, MBU_A_6)

Memory (DIMM) Top Yes No No Chapter 7

PCIe card (PCIe) Top Yes No No Chapter 8

Hard disk drive (HDD) Front Yes Yes

Ye s

Hard disk drive backplane (HDDBP) Top No No No

CD-RW/DVD-RW drive unit

Front/top No No No (DVDU)

Power supply unit (PSU) Rear No No No

Fan unit (FAN_A) Top No No No

Fan backplane (FANBP_B) Top No No No

Where to Find the Procedure

†

Chapter 9

4-4 SPARC Enterprise M3000 Server Service Manual • March 2012

TABLE 4-3

FRU Access Locations and Installation Methods (Continued)

FRU

Operator panel (OPNL) Front/top No No No

* The FRU is operated directly, without using XSCF commands. † The FRU is operated with XSCF commands.

Access Location Cold Addition Hot Addition

Active Addition

Where to Find the Procedure

4.3 Active Replacement/Active Addition

In active replacement, the target FRU is operated while the Oracle Solaris OS of the domain to which the FRU belongs is operating.

The target FRU is operated using Oracle Solaris OS commands or XSCF commands.

Because the power supply unit (PSU) and fan unit (FAN) do not belong to any domain, they are operated by using XSCF commands regardless of the operating state of the Oracle Solaris OS.

Active replacement has the following four stages:

■ “Releasing a FRU from a Domain” on page 4-5

■ “FRU Removal and Replacement” on page 4-6

■ “Configuring a FRU in a Domain” on page 4-6

■ “Verifying the Hardware Operation” on page 4-7

For active installation, see Section 4.3.3, “Configuring a FRU in a Domain” on

page 4-6 and "Section 4.3.4, “Verifying the Hardware Operation” on page 4-7.

4.3.1 Releasing a FRU from a Domain

Note – ■ If a hard disk drive is a nonmirrored boot device, it must be replaced

according to the cold replacement procedure.

■ If a hard disk drive is in a mirrored configuration, active replacement can be

performed on the failed drive because the mirrored hard disk drive continues to be online and functioning.

Chapter 4 FRU Replacement Preparation 4-5

1. From the Oracle Solaris OS, type the cfgadm command to obtain the FRU

status.

# cfgadm -a

2. Stop the application from using the FRU and disconnect the FRU from the Oracle Solaris OS.

The READY LED (green) of the HDD goes off.

3. Type the cfgdevice -c unconfigure command to disconnect the FRU from the Oracle Solaris OS.

# cfgadm -c unconfigure Ap_Id

4. Type the cfgadm -x command to confirm that the CHECK LED blinks.

# cfgadm -x led=fault, mode=blink Ap_Id

The Ap_Id is shown in the output of cfgadm (for example, disk#0). The CHECK LED (amber) of the HDD blinks.

5. Type the cfgadm command to verify that the FRU has been disconnected.

# cfgadm -a

The disconnected FRU is displayed as being unconfigured.

4.3.2 FRU Removal and Replacement

After the disconnection of a FRU from a domain, the same procedure as that for Hot Replacement/Hot Addition applies. See Section 4.4, “Hot Replacement/Hot

Addition” on page 4-7.

4.3.3 Configuring a FRU in a Domain

This section explains the procedure for active replacement/installation by using Oracle Solaris OS commands. For information on using the XSCF command, see

Section 4.4, “Hot Replacement/Hot Addition” on page 4-7.

4-6 SPARC Enterprise M3000 Server Service Manual • March 2012

1. Type the cfgdevice -c unconfigure command from the Oracle Solaris OS

to integrate the FRU into the Oracle Solaris OS.

# cfgadm -c configure Ap_Id

The Ap_Id is shown in the output of cfgadm (for example, disk#0).

2. Type the cfgadm -x command to confirm that the CHECK LED is off.

# cfgadm -x led=fault, mode=off Ap_Id

The Ap_Id is shown in the output of cfgadm (for example, disk#0). The CHECK LED (amber) of the HDD is turned off.

3. Type the cfgadm command to verify that the FRU has been configured.

# cfgadm -a

The configured FRU is displayed as being configured. The READY LED (green) of the HDD goes on.

4.3.4 Verifying the Hardware Operation

■ Confirm the status of the LED indicators.

For information on the LED status, see

TABLE 2-3 and TABLE 2-5.

4.4 Hot Replacement/Hot Addition

In hot replacement, the target FRU is operated while the domain to which the FRU belongs is stopped.

Depending on the target FRU, there are two cases as follows:

■ Power supply unit/Fan unit: operated with XSCF commands. See Section 4.4.1,

“FRU Removal and Replacement (Power supply unit/Fan unit)” on page 4-8.

■ Hard disk drive: operated directly, not by using XSCF commands.

For hot addition, do the same operation as that for hot replacement.

Chapter 4 FRU Replacement Preparation 4-7

4.4.1 FRU Removal and Replacement (Power supply unit/Fan unit)

● Ty pe t h e replacefru command from the XSCF Shell prompt.

The replacefru command is a menu-driven interactive command.

XSCF> replacefru

---------------------------------------------------------------------Maintenance/Replacement Menu Please select a type of FRU to be replaced.

1. FAN (Fan Unit)

2. PSU (Power Supply Unit)

---------------------------------------------------------------------Select [1,2|c:cancel] :1

---------------------------------------------------------------------Maintenance/Replacement Menu Please select a FAN to be replaced.

No. FRU Status

--- --------------- ------------------

1. FAN_A#0 Normal

2. FAN_A#1 Normal

---------------------------------------------------------------------Select [1,2|b:back] :1

You are about to replace FAN_A#0. Do you want to continue?[r:replace|c:cancel] :r

Please confirm the Check LED is blinking. If this is the case, please replace FAN_A#0. After replacement has been completed, please select[f:finish] :f

4-8 SPARC Enterprise M3000 Server Service Manual • March 2012

The replacefru command automatically tests the status of the FRU after the completion of removal and replacement.

Diagnostic tests for FAN_A#0 have started. [This operation may take up to 3 minute(s)] (progress scale reported in seconds)

0..... 30..done

---------------------------------------------------------------------Maintenance/Replacement Menu Status of the replaced FRU.

FRU Status

------------- -------FAN_A#0 Normal

---------------------------------------------------------------------The replacement of FAN_A#0 has completed normally.[f:finish] :f

---------------------------------------------------------------------Maintenance/Replacement Menu Please select a type of FRU to be replaced.

1. FAN (Fan Unit)

2. PSU (Power Supply Unit)

---------------------------------------------------------------------Select [1,2|c:cancel] :c

Note – The display may vary depending on the XCP version

When the tests are complete, the program displays the original menu again. To return to the XSCF Shell prompt, select cancel.

For details, see the manual pages of replacefru.

Chapter 4 FRU Replacement Preparation 4-9

4.4.2 Verifying the Hardware Operation (Power supply unit/Fan unit)

1. Type the showhardconf command to confirm that the new FRU has been

installed.

MBU_A Status:Normal; Ver:0101h; Serial:PP082202QX ; + FRU-Part-Number:CA07082-D901 A1 /541-3302-01 ; + CPU Status:Normal; + Freq:2.520 GHz; Type:32; + Core:4; Strand:2; + Memory_Size:8 GB; MEM#0A Status:Normal; + Code:ce0000000000000001M3 93T2950EZA-CE6 4145-473b3c23; + Type:1A; Size:1 GB; MEM#0B Status:Normal; + Code:7f7ffe00000000004aEBE10RD4AJFA-5C-E 3020-223b2918; + Type:1A; Size:1 GB; MEM#1A Status:Normal; + Code:7f7ffe00000000004aEBE10RD4AJFA-5C-E 3020-223b28af; + Type:1A; Size:1 GB; MEM#1B Status:Normal; + Code:7f7ffe00000000004aEBE10RD4AJFA-5C-E 3020-223b28ab; + Type:1A; Size:1 GB; MEM#2A Status:Normal; + Code:7f7ffe00000000004aEBE10RD4AJFA-5C-E 3020-223b283e; + Type:1A; Size:1 GB; MEM#2B Status:Normal; + Code:7f7ffe00000000004aEBE10RD4AJFA-5C-E 3020-223b2829; + Type:1A; Size:1 GB; MEM#3A Status:Normal; + Code:7f7ffe00000000004aEBE10RD4AJFA-5C-E 3020-223b2840; + Type:1A; Size:1 GB; MEM#3B Status:Normal; + Code:7f7ffe00000000004aEBE10RD4AJFA-5C-E 3020-223b2830; + Type:1A; Size:1 GB; PCI#0 Name_Property:fibre-channel; Card_Type:Other; PCI#1 Name_Property:fibre-channel; Card_Type:Other; PCI#2 Name_Property:pci; Card_Type:Other; PCI#3 Name_Property:pci; Card_Type:Other;

4-10 SPARC Enterprise M3000 Server Service Manual • March 2012

The showhardconf output continued:

OPNL Status:Normal; Ver:0101h; Serial:PP082202R8 ; + FRU-Part-Number:CA07082-D911 A1 /541-3306-01 ; PSU#0 Status:Normal; Serial:EA08210127; + FRU-Part-Number:CA01022-0720 02B /300-2193-02 ; + Power_Status:On; + Type:AC; PSU#1 Status:Normal; Serial:EA08210131; + FRU-Part-Number:CA01022-0720 02B /300-2193-02 ; + Power_Status:On; + Type:AC; FANBP_B Status:Normal; Ver:0101h; Serial:PP0821031E ; + FRU-Part-Number:CA20399-B12X 004AA/541-3304-01 ; FAN_A#0 Status:Normal; FAN_A#1 Status:Normal; XSCF>

For details, see the manual pages of showhardconf.

2. Confirm the state of the status LEDs of the FRU.

For information on the LED status, see

TAB LE 2- 3 and TA BLE 2-5 .

4.4.3 Verifying the Hardware Operation (Hard disk drive)

● Ty pe t h e probe-scsi-all command to confirm that the new hard disk drive

has been installed.

Chapter 4 FRU Replacement Preparation 4-11

4.5 Cold Replacement/Cold Addition

In cold replacement, all business operations must be stopped. When accessing the server, power off the server and disconnect the power cord to ensure safety.

For cold addition, do the same operation as that for cold replacement.

4.5.1 Powering off the Server

This section explains how to power off the server.

4.5.1.1 Power-off by Using the XSCF Command

1. Notify users that the server is being powered off.

2. Back up the system files and data to tape, if necessary.

3. A user with platadm or fieldeng authority must log in to the XSCF Shell and enter the poweroff command.

XSCF> poweroff -a

The following activity is executed when the poweroff command is used:

■ The Oracle Solaris OS shuts down completely.

■ The server is powered off and the server enters standby mode. (The power to

the XSCF unit remains on.)

For details, see the SPARC Enterprise M3000/M4000/M5000/M8000/M9000 Servers XSCF User's Guide.

4. Verify that the POWER LED on the operator panel is off.

5. Disconnect all the power cords from the power outlets.

Caution – There is a risk of electrical failure if the power cords are not

disconnected. All the power cords must be disconnected to completely cut the power to the server.

4-12 SPARC Enterprise M3000 Server Service Manual • March 2012

4.5.1.2 Power off by Using the Operator Panel

1. Notify users that the server is being powered off.

2. Back up the system files and data to tape, if necessary.

3. Turn the mode switch on the operator panel to the Service position.

4. Press the power switch on the operator panel for 4 seconds or more.

5. Verify that the POWER LED on the operator panel is off.

6. Disconnect all the power cords from the power outlets.

Caution – There is a risk of electrical failure if the power cords are not

disconnected. All the power cords must be disconnected to completely cut the power to the server.

4.5.2 FRU Removal and Replacement

In cold replacement, a FRU is removed and replaced while the power is turned off. After the FRU replacement, power on the server.

4.5.3 Powering on the Server

This section explains how to power on the server.

4.5.3.1 Power-on by Using the XSCF Command

1. Verify that the server has enough power supply units to operate in the desired configuration.

2. Connect all the power cords to power outlets.

3. Verify that the XSCF STANDBY LED on the operator panel is on.

4. Turn the mode switch on the operator panel to the desired mode position (Locked or Service).

Chapter 4 FRU Replacement Preparation 4-13

5. A user with platadm or fieldeng authority must log in to the XSCF Shell and type the poweron command.

XSCF> poweron -a

Soon, the following activity is executed:

■ The POWER LED on the operator panel is turned on.

■ The power-on self-test (POST) is executed.

Then, the server is completely powered on.

Note – If automatic startup of the Oracle Solaris OS is specified, use the sendbreak

-d domain_id command of the XSCF Shell to display the ok prompt after the

display console banner is displayed but before the system starts booting the Oracle Solaris OS.

For details, see the SPARC Enterprise M3000/M4000/M5000/M8000/M9000 Servers XSCF User's Guide.

4.5.3.2 Power-on by Using the Operator Panel

1. Verify that the server has enough power supply units to operate in the desired configuration.

2. Connect all the power cords to power outlets.

3. Verify that the XSCF STANDBY LED on the operator panel is on.

4. Turn the mode switch on the operator panel to the desired mode position (Locked or Service).

5. Press the power button on the operator panel.

Soon, the following activity is executed:

■ The POWER LED on the operator panel is turned on.

■ The power-on self-test (POST) is executed.

Then, the server is completely powered on.

Note – If automatic startup of the Oracle Solaris OS is specified, use the sendbreak

-d domain_id command of the XSCF Shell to display the ok prompt after the

display console banner is displayed but before the system starts booting the Oracle Solaris OS.

4-14 SPARC Enterprise M3000 Server Service Manual • March 2012

4.5.4 Verifying the Hardware Operation

1. In response to the ok prompt, press the ENTER key and enter ”#” (default value) and then press the ”.” (period) key.

The domain console is switched to the XSCF console.

2. Use the showhardconf command to confirm that the new FRU has been installed.

Chapter 4 FRU Replacement Preparation 4-15

The showhardconf output continued:

PCI#2 Name_Property:pci; Card_Type:Other; PCI#3 Name_Property:pci; Card_Type:Other; OPNL Status:Normal; Ver:0101h; Serial:PP082202R8 ; + FRU-Part-Number:CA07082-D911 A1 /541-3306-01 ; PSU#0 Status:Normal; Serial:EA08210127; + FRU-Part-Number:CA01022-0720 02B /300-2193-02 ; + Power_Status:On; + Type:AC; PSU#1 Status:Normal; Serial:EA08210131; + FRU-Part-Number:CA01022-0720 02B /300-2193-02 ; + Power_Status:On; + Type:AC; FANBP_B Status:Normal; Ver:0101h; Serial:PP0821031E ; + FRU-Part-Number:CA20399-B12X 004AA/541-3304-01 ; FAN_A#0 Status:Normal; FAN_A#1 Status:Normal; XSCF>

For details, see the manual pages of showhardconf.

3. Type the console command to switch from the XSCF console to the ok prompt

(domain console) again:

XSCF> console -d 0

4. From the ok prompt, type the show-devs command to confirm that all the

PCIe cards are mounted.

{0} ok show-devs /pci@1,700000 /pci@0,600000 /pci@8,4000 /cmp@400,0 /pseudo-mc@200,200 /nvram /pseudo-console /virtual-memory /memory@m0 /aliases /options /openprom /chosen /packages

4-16 SPARC Enterprise M3000 Server Service Manual • March 2012

The show-devs output continued:

/pci@1,700000/pci@0 /pci@1,700000/pci@0/pci@9 /pci@1,700000/pci@0/pci@8 /pci@1,700000/pci@0/pci@0 /pci@1,700000/pci@0/pci@9/pci@0 /pci@1,700000/pci@0/pci@9/pci@0/FJSV,e2ta@4,1 /pci@1,700000/pci@0/pci@9/pci@0/FJSV,e2ta@4 /pci@1,700000/pci@0/pci@8/pci@0 /pci@1,700000/pci@0/pci@8/pci@0/FJSV,e2ta@4,1 /pci@1,700000/pci@0/pci@8/pci@0/FJSV,e2ta@4 /pci@1,700000/pci@0/pci@0/pci@0 /pci@1,700000/pci@0/pci@0/pci@0/FJSV,e2ta@4,1 /pci@1,700000/pci@0/pci@0/pci@0/FJSV,e2ta@4 /pci@0,600000/pci@0 /pci@0,600000/pci@0/pci@8 /pci@0,600000/pci@0/pci@2 /pci@0,600000/pci@0/pci@1 /pci@0,600000/pci@0/pci@0 /pci@0,600000/pci@0/pci@8/pci@0 /pci@0,600000/pci@0/pci@8/pci@0/FJSV,e2ta@4,1 /pci@0,600000/pci@0/pci@8/pci@0/FJSV,e2ta@4 /pci@0,600000/pci@0/pci@2/pci@0 /pci@0,600000/pci@0/pci@2/pci@0/network@4,1 /pci@0,600000/pci@0/pci@2/pci@0/network@4 /pci@0,600000/pci@0/pci@1/pci@0 /pci@0,600000/pci@0/pci@1/pci@0/network@4,1 /pci@0,600000/pci@0/pci@1/pci@0/network@4 /pci@0,600000/pci@0/pci@0/scsi@0 /pci@0,600000/pci@0/pci@0/scsi@0/disk /pci@0,600000/pci@0/pci@0/scsi@0/tape /pci@8,4000/ebus@1 /pci@8,4000/ebus@1/panel@14,280030 /pci@8,4000/ebus@1/scfc@14,200000 /pci@8,4000/ebus@1/serial@14,400000 /pci@8,4000/ebus@1/flashprom@10,0 /cmp@400,0/core@3 /cmp@400,0/core@2 /cmp@400,0/core@1 /cmp@400,0/core@0 /cmp@400,0/core@3/cpu@1 /cmp@400,0/core@3/cpu@0 /cmp@400,0/core@2/cpu@1 /cmp@400,0/core@2/cpu@0 /cmp@400,0/core@1/cpu@1 /cmp@400,0/core@1/cpu@0

Chapter 4 FRU Replacement Preparation 4-17

The show-devs output continued:

/cmp@400,0/core@0/cpu@1 /cmp@400,0/core@0/cpu@0 /openprom/client-services /packages/obp-tftp /packages/terminal-emulator /packages/disk-label /packages/deblocker /packages/SUNW,builtin-drivers /packages/SUNW,probe-error-handler {0} ok

5. Type the probe-scsi-all command to confirm that the storage devices are

mounted.

{0} ok probe-scsi-all /pci@0,600000/pci@0/pci@0/scsi@0

MPT Version 1.05, Firmware Version 1.24.00.00

Target 0 Unit 0 Disk FUJITSU MAY2073RC 3701 143374738 Blocks, 73 GB SASAddress 500000e0197292c2 PhyNum 0 Target 1 Unit 0 Disk FUJITSU MAY2073RC 3701 143374738 Blocks, 73 GB SASAddress 500000e019728f22 PhyNum 1 Target 2 Unit 0 Disk FUJITSU MAY2073RC 3701 143374738 Blocks, 73 GB SASAddress 500000e019729002 PhyNum 2 Target 3 Unit 0 Disk FUJITSU MAY2073RC 3701 143374738 Blocks, 73 GB SASAddress 500000e019729302 PhyNum 3 Target 4 Unit 0 Removable Read Only device MATSHITADVD-RAM UJ875AS 1000 SATA device PhyNum 4

{0} ok

6. Type the boot command to start the Oracle Solaris OS.

ok boot

4-18 SPARC Enterprise M3000 Server Service Manual • March 2012

CHAPTER

Internal Components Access

This chapter explains how to access internal components.

■ Section 5.1, “Sliding the Server Into and Out of the Equipment Rack” on page 5-1

■ Section 5.2, “Removing and Attaching the Top Cover” on page 5-3

■ Section 5.3, “Removing and Attaching the Air Duct” on page 5-4

■ Section 5.4, “Removing and Attaching the Fan Cover” on page 5-7

5.1 Sliding the Server Into and Out of the Equipment Rack

This section explains how to slide the server out from the equipment rack and how to push it into the equipment rack.

For details of equipment racks, see the SPARC Enterprise Equipment Rack Mounting Guide.

5.1.1 Sliding the Server Out from the Equipment Rack

Caution – To prevent the equipment rack from tipping over, you must deploy the

antitilt feature, if applicable, before you slide the server out of the equipment rack.

Note – If cable management arms are not attached, remove the cable ties securing

the PCI cables to the rear of the server and slide the server out.

5-1

Caution – To ensure that you and bystanders are not exposed to harm and to

prevent damage to the system, observe the ESD safety precautions. See Section 1.1,

“ESD Precautions” on page 1-1.

1. If the equipment rack is supplied with a Quake-Resistant Options Kit or stabilizer, be sure to install it.

2. Slide the server out as far as possible.

When the server is drawn out completely, the server is automatically locked in the predetermined position.

3. Loosen the two screws at the front of the server (

FIGURE 5-1 Pulling the Server Out from an Equipment Rack

FIGURE 5-1).

4. Slide the server out.

5-2 SPARC Enterprise M3000 Server Service Manual • March 2012

5.1.2 Sliding the Server into the Equipment Rack

Rear Front

1. Push the server back into the equipment rack.

2. Tighten the two screws at the front of the server to secure it in the equipment

FIGURE 5-1).

rack (

3. If the equipment rack is supplied with a Quake-Resistant Options Kit or stabilizer, return to its original position.

5.2 Removing and Attaching the Top Cover

5.2.1 Removing the Top Cover

1. Before removing the top cover, pull out the server from the equipment rack.

For details see Section 5.1, “Sliding the Server Into and Out of the Equipment

Rack” on page 5-1.

2. Loosen the three screws at the top rear of the server.

3. To remove the top cover, slide it toward the rear side and raise it (

FIGURE 5-2 Removing the Top Cover

FIGURE 5-2).

Chapter 5 Internal Components Access 5-3

5.2.2 Attaching the Top Cover

1. Align the top cover.

2. Tighten the three screws at the top rear of the server to secure the top cover in the predetermined position.

3. Push the server back into the equipment rack.

For details, see "Section 5.1.2, “Sliding the Server into the Equipment Rack” on

page 5-3.

5.3 Removing and Attaching the Air Duct

5.3.1 Removing the Air Duct

Caution – Before the air duct is removed, the top cover must be removed. For

details, see Section 5.2, “Removing and Attaching the Top Cover” on page 5-3.

■ Hold the air duct and lift it upwards.

5-4 SPARC Enterprise M3000 Server Service Manual • March 2012

FIGURE 5-3 Removing the Air Duct

Chapter 5 Internal Components Access 5-5

5.3.2 Attaching the Air Duct

1. Set the tab at the front of the air duct in place and then lower the air duct

FIGURE 5-4).

(

Prevent cables from interfering each other.

FIGURE 5-4 Attaching the Air Duct

2. Attach the top cover.

For details, see Section 5.2.2, “Attaching the Top Cover” on page 5-4.

5-6 SPARC Enterprise M3000 Server Service Manual • March 2012

5.4 Removing and Attaching the Fan Cover

5.4.1 Removing the Fan Cover

Caution – Before the fan cover is removed, the server must be pulled out from the

equipment rack. For the procedure for pulling the server out from the equipment rack, see "Section 5.1, “Sliding the Server Into and Out of the Equipment Rack” on

page 5-1.

1. Loosen one screw at the right of the fan cover.

2. Raise the right end of the fan cover and remove it (

FIGURE 5-5 Removing the Fan Cover

FIGURE 5-5).

Chapter 5 Internal Components Access 5-7

5.4.2 Attaching the Fan Cover

1. Align the tab on the left end of the fan cover in the predetermined position and then secure the fan cover in position.

2. Tighten the one screw on the right side of the fan cover.

3. Push the server back into the equipment rack.

For details, see Section 5.1.2, “Sliding the Server into the Equipment Rack” on

page 5-3.

5-8 SPARC Enterprise M3000 Server Service Manual • March 2012

CHAPTER

Motherboard Unit Replacement

This chapter explains how to replace the motherboard unit.

■ Section 6.1, “Accessing the Motherboard Unit” on page 6-4

■ Section 6.2, “Removing the Motherboard Unit” on page 6-7

■ Section 6.3, “Mounting the Motherboard Unit” on page 6-8

■ Section 6.4, “Reassembling the Server” on page 6-9

The motherboard unit is a cold replacement component. The server must be completely powered off, the power cords must be disconnected, and all DIMMs and PCIe cards must be removed, before the motherboard unit is replaced. See Chapter 7, Replacement and Installation of Memory and Chapter 8, Replacement and Installation of PCIe Cards.

Note – There are two types of motherboard units for the M3000 server: the

motherboard unit mounted with the CPU consisting of two-core processors and the motherboard unit mounted with the CPU consisting of four-core processors. When replacing a motherboard unit, the replacement unit must contain the same type of processor. For example, do not replace a motherboard unit that has two-core processors with one that contains four-core processors.

Note – When replacing the motherboard unit, use the same type of FRU as the FRU

mounted on the previous motherboard unit. If you use a different type of FRU, it may not work properly.

Note – Do not replace the motherboard unit and the operator panel at the same

time. Otherwise, the system may not operate correctly. Use the showhardconf command or showstatus command to verify that the replacement unit of the first replaced FRU is fully operational, before replacing the other FRU.

6-1

Note – When replacing the motherboard unit, attach connection destination labels

to each of the LAN cable and UPS cable connected to the XSCF unit before removing these cables.

Note – When mounting the motherboard unit, connect the LAN cable and UPS

cable to the XSCF unit.

Note – After the replacement of the motherboard unit is completed, the system

clock must be reset. For details of the setting method, see the SPARC Enterprise M3000/M4000/M5000/M8000/M9000 Servers XSCF User’s Guide.

Note – After the replacement of the motherboard unit is completed, the versions of

the XCP and Oracle Solaris OS must be checked. For details of version number checking and other such tasks, see the SPARC Enterprise M3000/M4000/M5000/M8000/M9000 Servers XSCF User’s Guide.

Note – To activate a hardware RAID boot volume after replacing the MBU of an

M3000 server with SPARC64 VII+ processors, see Appendix F.

Because the XSCF unit is mounted on the motherboard unit, it cannot be replaced singly. For details of the XSCF unit, see the Appendix B.2.4.

6-2 SPARC Enterprise M3000 Server Service Manual • March 2012

FIGURE 6-1 indicates the location of the motherboard unit.

FIGURE 6-1 Motherboard Unit Location

Chapter 6 Motherboard Unit Replacement 6-3

FIGURE 6-2 indicates the locations of DIMMs, PCIe cards, and shutter unit.

FIGURE 6-2 Locations of DIMMs, PCIe Cards, and Shutter Unit

Location Number Component

1 Memory (DIMM)

2PCIe card

3 Shutter unit

6.1 Accessing the Motherboard Unit

Caution – There is a risk of electrical failure if the power cords are not

disconnected. All the power cords must be disconnected to completely cut the power to the server.

6-4 SPARC Enterprise M3000 Server Service Manual • March 2012

Caution – To ensure that you and bystanders are not exposed to harm and to

prevent damage to the system, observe the ESD safety precautions. See Section 1.1,

“ESD Precautions” on page 1-1.

1. Power off the server.

This procedure includes the steps of turning the mode switch on the operator panel to the Service position, verifying that the POWER LED is off, and disconnecting the power cord. For details, see Section 4.5.1, “Powering off the

Server” on page 4-12.

2. Remove all the cables from the external interface block on the rear panel.

3. Pull the power supply unit out several centimeters to the rear side.

4. Slide the server out from the equipment rack.

For details, see Section 5.1.1, “Sliding the Server Out from the Equipment Rack”

on page 5-1.

Caution – To prevent the equipment rack from tipping over, you must deploy the

antitilt feature, if applicable, before you slide the server out of the equipment rack.

Note – When the cable management arm is not mounted, remove the cable ties that

secure the PCI cable to the rear of the server, and slide the server out.

5. Remove the top cover.

For details, see Section 5.2.1, “Removing the Top Cover” on page 5-3.

6. Remove the PCIe cards.

For details, see Section 8.2, “Removing a PCIe Card” on page 8-4.

7. Remove the air duct.

For details, see Section 5.3.1, “Removing the Air Duct” on page 5-4.

8. Disconnect all the cables from the motherboard unit.

9. Loosen the two screws securing the shutter unit, and slide the securing bracket on the power supply unit.

Chapter 6 Motherboard Unit Replacement 6-5

10. Remove the shutter unit.

FIGURE 6-3 Removing the Shutter Unit

6-6 SPARC Enterprise M3000 Server Service Manual • March 2012

FUJITSU M3000 User Manual

Specifications and Main Features

Frequently Asked Questions

User Manual

Contents

Preface

Safety Precautions for Maintenance

1.1 ESD Precautions

1.2 Server Precautions

1.2.1 Electrical Safety Precautions

1.2.2 Equipment Rack Safety Precautions

1.2.3 Component Handling Precautions

Hardware Overview

2.1 Name of Each Part

2.2 Operator Panel

2.2.1 Operator Panel Overview

2.2.2 Switches on the Operator Panel

2.2.3 LEDs on the Operator Panel

2.3 LED Functions of Components

2.4 External Interface Port on Rear Panel

2.5 Labels

Troubleshooting

3.1 Emergency Power Off

3.2 Failure Diagnostic Method

3.3 Checking the Server and System Configuration

3.3.1 Checking the Hardware Configuration and FRU Status

3.3.1.1 Checking the Hardware Configuration.

3.3.2 Checking the Software and Firmware Configurations

3.3.2.1 Checking the Software Configuration

3.3.2.2 Checking the Firmware Configuration

3.3.2.3 Downloading Error Log Information

3.4 Error Conditions

3.4.1 Predictive Self-Healing Tools

3.4.2 Monitoring Output

3.4.3 Messaging Output

3.5 Using Troubleshooting Commands

3.5.1 Using the showhardconf Command

3.5.2 Using the showlogs Command

3.5.3 Using the showstatus Command

3.5.4 Using the fmdump Command

3.5.4.1 fmdump -V Command

3.5.4.2 fmdump -e Command

3.5.5 Using the fmadm Command

3.5.5.1 Using the fmadm faulty Command

3.5.5.2 fmadm repair Command

3.5.5.3 fmadm config Command

3.5.6 Using the fmstat Command

3.6 General Oracle Solaris Troubleshooting Commands

3.6.1 Using the iostat Command

3.6.1.1 Options

3.6.2 Using the prtdiag Command

3.6.2.1 Options

3.6.3 Using the prtconf Command

3.6.3.1 Options

3.6.4 Using the netstat Command

3.6.4.1 Options

3.6.5 Using the ping Command

3.6.5.1 Options

3.6.6 Using the ps Command

3.6.6.1 Options

3.6.7 Using the prstat Command

3.6.7.1 Options

FRU Replacement Preparation

4.1 Tools Required for Maintenance

4.2 FRU Replacement and Installation Methods

4.2.1 FRU Replacement

4.2.2 FRU Installation

4.3 Active Replacement/Active Addition

4.3.1 Releasing a FRU from a Domain

4.3.2 FRU Removal and Replacement

4.3.3 Configuring a FRU in a Domain

4.3.4 Verifying the Hardware Operation

4.4 Hot Replacement/Hot Addition

4.4.1 FRU Removal and Replacement (Power supply unit/Fan unit)

4.4.2 Verifying the Hardware Operation (Power supply unit/Fan unit)

4.4.3 Verifying the Hardware Operation (Hard disk drive)

4.5 Cold Replacement/Cold Addition

4.5.1 Powering off the Server

4.5.1.1 Power-off by Using the XSCF Command

4.5.1.2 Power off by Using the Operator Panel
