Fujitsu LifeBook N5010 User Manual
cygnus.book Page 1 Tuesday, September 30, 2003 4:22 PM
Copyright
Copyright
Fujitsu Computer Systems Corporation has made every
effort to ensure the accuracy and completeness of this
document. However, as ongoing development efforts are
continually improving the capabilities of our products, we
cannot guarantee the accuracy of the contents of this
document. We disclaim liability for errors, omissions, or
future changes. Specifications are subject to change
without notice.
Fujitsu, the Fujitsu logo, and LifeBook are registered
trademarks of Fujitsu Limited.
The following are registered trademarks of Microsoft
Corporation: MS, MS-DOS, Windows.
PCMCIA is a trademark of the Personal Computer
Memory Card International Association.
Intel and Pentium are registered trademarks of Intel
Corporation or its subsidiaries in the United States and
other countries.
Adobe Acrobat Reader is a registered trademark of
Adobe System Inc.
Atheros is a registered trademark of Atheros Communications Inc.
Earthlink is a registered trademark of EarthLink
Network, Inc.
Quicken is a registered trademark of Intuit, Inc.
WinDVD is a trademark of InterVideo, Inc.
Netscape 7 is a registered trademark of Netscape
Communications Corporation.
PowerQuest and Drive Image are registered trademarks
of PowerQuest Corp.
Norton AntiVirus is a registered trademark of Symantec
Corporation.
ATI and Radeon are registered trademarks of ATI
Te c hn ol o gi e s, I nc .
The DVD player found in some models of the LifeBook
notebook incorporates copyright protection technology
that is protected by method claims of certain U.S.
patents and other intellectual property rights owned by
Macrovision Corporation and other rights users. Use of
this copyright protection technology must be authorized by Macrovision Corporation, and is intended for
home and other limited viewing uses only unless authorized by Macrovision Corporation. Reverse engineering
or disassembly is prohibited.
Dolby Headphone manufactured under license from
Dolby Laboratories. “Dolby”, “Pro Logic”, and the
double-D symbol are trademarks of Dolby Laboratories.
Confidential Unpublished works. Copyrights 1992-1999
Dolby Laboratories. All rights reserved.
All other trademarks mentioned herein are the property
of their respective owners.
Warning
Handling the cord on this product will expose
you to lead, a chemical known to the State of
California to cause birth defects or other
reproductive harm.
Wash hands after handling.
© Copyright 2003 Fujitsu Computer Systems
Corporation. All rights reserved. No part of this publication may be copied, reproduced, or translated, without
prior written consent of Fujitsu Computer Systems
Corporation. No part of this publication may be stored
or transmitted in any electronic form without the
written consent of Fujitsu Computer Systems
Corporation. B6FH-0351-01EN-00
DECLARATION OF CONFORMITY
according to FCC Part 15
Responsible Party Name: Fujitsu Computer Systems Corporation
Address: 1250 E. Arques Avenue (M/S 122)
Telephone: (408) 982-9500
Declares that product: Model Configuration: LifeBook N5010
This device complies with Part 15 of the FCC rules. Operations are subject to the following two conditions: (1) This
device must not be allowed to cause harmful interference, (2) This device must accept any interference received,
including interference that may cause undesired operation.
Sunnyvale, CA 94085
Complies with Part 15 of the FCC Rules.
cygnus.book Page 2 Tuesday, September 30, 2003 4:22 PM
LifeBook N Series User’s Guide
cygnus.book Page 1 Tuesday, September 30, 2003 4:22 PM
Fujitsu LifeBook® N Series
Table of Contents
Table of Contents
1
PREFACE
Preface
About This Guide . . . . . . . . . . . . . . . . . . . . . . . . .3
Fujitsu Contact Information . . . . . . . . . . . . . . . . .3
Warranty . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .3
2
GETTING TO KNOW
YOUR LIFEBOOK NOTEBOOK
Overview
Unpacking . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .7
Locating the Controls
and Connectors
Top and Front Components . . . . . . . . . . . . . . . . .8
Left-Side Panel Components . . . . . . . . . . . . . . . 10
Right-Side Panel Components . . . . . . . . . . . . . .11
Rear Panel Components. . . . . . . . . . . . . . . . . . .12
Bottom Components . . . . . . . . . . . . . . . . . . . . .13
Status/Volume Indicators
Power Indicator . . . . . . . . . . . . . . . . . . . . . . . . .14
Battery Charging Indicator . . . . . . . . . . . . . . . . .14
Battery Status Indicator . . . . . . . . . . . . . . . . . . .14
Hard Drive Access Indicator . . . . . . . . . . . . . . . .15
Floppy Drive Access Indicator . . . . . . . . . . . . . . .15
Media Player Access Indicator . . . . . . . . . . . . . .15
NumLk Indicator. . . . . . . . . . . . . . . . . . . . . . . . .15
CapsLock Indicator. . . . . . . . . . . . . . . . . . . . . . .15
ScrLk Indicator . . . . . . . . . . . . . . . . . . . . . . . . . .15
Volume Level LEDs. . . . . . . . . . . . . . . . . . . . . . .15
Volume Dial . . . . . . . . . . . . . . . . . . . . . . . . . . . .15
Keyboard
Using the Keyboard . . . . . . . . . . . . . . . . . . . . . . 16
Numeric Keypad. . . . . . . . . . . . . . . . . . . . . . . . .16
Windows Keys . . . . . . . . . . . . . . . . . . . . . . . . . .16
Cursor Keys . . . . . . . . . . . . . . . . . . . . . . . . . . . .17
Function Keys. . . . . . . . . . . . . . . . . . . . . . . . . . .17
Volume Control
Controlling the Volume . . . . . . . . . . . . . . . . . . .18
TouchPad Pointing Device
Clicking . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .19
Double-Clicking . . . . . . . . . . . . . . . . . . . . . . . . .19
Dragging . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .20
Scrolling . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .20
TouchPad Control Adjustment . . . . . . . . . . . . . .20
3
GETTING STARTED
Power Sources
Connecting the AC Adapter . . . . . . . . . . . . . . . .23
Display Panel
Opening the Display Panel . . . . . . . . . . . . . . . . .24
Adjusting Display Panel Brightness . . . . . . . . . . .24
Closing the Display Panel . . . . . . . . . . . . . . . . . .24
Starting Your LifeBook Notebook
Power On. . . . . . . . . . . . . . . . . . . . . . . . . . . . . .25
Boot Sequence . . . . . . . . . . . . . . . . . . . . . . . . . .25
BIOS Setup Utility. . . . . . . . . . . . . . . . . . . . . . . .25
Booting the System . . . . . . . . . . . . . . . . . . . . . .26
Windows Product Activation . . . . . . . . . . . . . . .27
Registering Your LifeBook Notebook . . . . . . . . .27
Installing Click Me!. . . . . . . . . . . . . . . . . . . . . . .27
Power Management
Power and Suspend/Resume Button. . . . . . . . . .28
Suspend Mode . . . . . . . . . . . . . . . . . . . . . . . . . .28
Hibernation (Save-to-disk) Feature . . . . . . . . . . .29
Display Timeout . . . . . . . . . . . . . . . . . . . . . . . . .29
Hard Disk Timeout . . . . . . . . . . . . . . . . . . . . . . .29
Restarting the System. . . . . . . . . . . . . . . . . . . . .29
Power Off . . . . . . . . . . . . . . . . . . . . . . . . . . . . .29
cygnus.book Page 2 Tuesday, September 30, 2003 4:22 PM
LifeBook N Series User’s Guide
4
USER-INSTALLABLE FEATURES
Lithium ion Battery
Recharging the Batteries. . . . . . . . . . . . . . . . . . .33
Replacing the Battery. . . . . . . . . . . . . . . . . . . . . 34
Internal Floppy Disk Drive
Loading a Disk . . . . . . . . . . . . . . . . . . . . . . . . . . 35
Ejecting a Disk . . . . . . . . . . . . . . . . . . . . . . . . . . 35
Preparing a Disk for Use. . . . . . . . . . . . . . . . . . . 35
Optical Drive
Optical Drive Software. . . . . . . . . . . . . . . . . . . . 36
Loading Media. . . . . . . . . . . . . . . . . . . . . . . . . . 36
Removing Media . . . . . . . . . . . . . . . . . . . . . . . . 36
Emergency DVD/CD-ROM Tray Release . . . . . . 37
Using the Optical Player Software . . . . . . . . . . . 37
Using Dolby™ Headphone. . . . . . . . . . . . . . . . . 38
Using the Drive on Battery Power . . . . . . . . . . . 38
Auto Insert Notification Function . . . . . . . . . . . . 38
Memory Stick/Secure Digital Slot
Installing Memory Stick/SD Cards . . . . . . . . . . . 39
Removing A Memory Stick/SD Card . . . . . . . . . 40
5
TROUBLESHOOTING
Troubleshooting
Identifying the Problem . . . . . . . . . . . . . . . . . . . 49
Specific Problems. . . . . . . . . . . . . . . . . . . . . . . . 50
Troubleshooting Table . . . . . . . . . . . . . . . . . . . . 50
Power On Self Test Messages . . . . . . . . . . . . . . 57
Modem Result Codes. . . . . . . . . . . . . . . . . . . . . 58
Restoring Your Pre-installed Software . . . . . . . . 60
Drive Image Special Edition (DISE) . . . . . . . . . . . 60
6
CARE AND MAINTENANCE
Care and Maintenance
LifeBook Notebook . . . . . . . . . . . . . . . . . . . . . . 65
Batteries. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 66
Floppy Disks and Drives. . . . . . . . . . . . . . . . . . . 66
DVDs and CDs. . . . . . . . . . . . . . . . . . . . . . . . . . 66
PC Cards . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 67
Hard Disk Drive
Formatting the Hard Disk Drive . . . . . . . . . . . . . 41
PC Cards
Installing PC Cards. . . . . . . . . . . . . . . . . . . . . . . 42
Removing PC Cards . . . . . . . . . . . . . . . . . . . . . . 42
Memory Upgrade Module
Installing a Memory Module . . . . . . . . . . . . . . . 43
Removing a Memory Upgrade Module . . . . . . . 44
Checking the Memory Capacity . . . . . . . . . . . . .44
Device Ports
Communications Ports . . . . . . . . . . . . . . . . . . . . 45
LAN Port . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 45
IEEE 1394 Jack . . . . . . . . . . . . . . . . . . . . . . . . . . 45
Universal Serial Bus (USB) 2.0 Ports . . . . . . . . . . 45
Microphone Jack . . . . . . . . . . . . . . . . . . . . . . . . 45
S-Video Out Port . . . . . . . . . . . . . . . . . . . . . . . . 45
Optical Digital Audio-Out Connector. . . . . . . . . 45
Headphone Jack. . . . . . . . . . . . . . . . . . . . . . . . . 46
External Monitor Port. . . . . . . . . . . . . . . . . . . . . 46
7
SPECIFICATIONS
Specifications
Configuration Label . . . . . . . . . . . . . . . . . . . . . . 71
Microprocessor . . . . . . . . . . . . . . . . . . . . . . . . . 71
Memory. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 71
Video. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 71
Audio. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 71
Mass Storage Devices . . . . . . . . . . . . . . . . . . . . 71
Features. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 71
Device Ports. . . . . . . . . . . . . . . . . . . . . . . . . . . . 72
Power . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 72
Dimensions . . . . . . . . . . . . . . . . . . . . . . . . . . . . 72
Environmental Requirements . . . . . . . . . . . . . . . 72
Popular Accessories . . . . . . . . . . . . . . . . . . . . . . 72
Pre-Installed Software . . . . . . . . . . . . . . . . . . . . 73
Application Descriptions. . . . . . . . . . . . . . . . . . . 73
cygnus.book Page 3 Tuesday, September 30, 2003 4:22 PM
8
GLOSSARY
Glossary . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .77
Regulatory Information . . . . . . . . . . . . . . . . . . .82
APPENDIX: INTEGRATED
WIRELESS LAN USER’S GUIDE
FCC Regulatory Information . . . . . . . . . . . . . . .87
Before Using the Wireless LAN
For better communications. . . . . . . . . . . . . . . . .89
Stopping transmission. . . . . . . . . . . . . . . . . . . . .90
Starting Transmission . . . . . . . . . . . . . . . . . . . . .90
Table of Contents
Connection using Windows XP
Flow of operations . . . . . . . . . . . . . . . . . . . . . . .91
Preparation for wireless LAN connection . . . . . .91
Connection to the network. . . . . . . . . . . . . . . . .93
Connection using Windows 2000
Flow of operations . . . . . . . . . . . . . . . . . . . . . . .96
Preparation for wireless LAN connection . . . . . .96
Connection to the network. . . . . . . . . . . . . . . . .97
Troubleshooting the WLAN
Troubleshooting . . . . . . . . . . . . . . . . . . . . . . . .100
Wireless LAN Glossary
Glossary . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .103
IP address information
Additional information . . . . . . . . . . . . . . . . . . .105
WLAN Specifications
Specification. . . . . . . . . . . . . . . . . . . . . . . . . . .106
cygnus.book Page 4 Tuesday, September 30, 2003 4:22 PM
LifeBook N Series User’s Guide
cygnus.book Page 1 Tuesday, September 30, 2003 4:22 PM
1
Preface
1
cygnus.book Page 2 Tuesday, September 30, 2003 4:22 PM
LifeBook N Series User’s Guide
2
cygnus.book Page 3 Tuesday, September 30, 2003 4:22 PM
Preface
ABOUT THIS GUIDE
The LifeBook® N5000 notebook from Fujitsu Computer
Systems Corporation provides desktop performance
with a fast Intel® Pentium® 4 processor that supports
Hyper-Threading technology for optimal throughput.
The 16" Crystal View SXGA+ high-resolution screen
displays vibrant colors with pinpoint sharpness. The
high-performance ATI MOBILITY™ RADEON™ 9600
video controller with 64 MB of dedicated VRAM
provides cinema-quality DVD video and quick-response
3D gaming.
This manual explains how to operate your LifeBook
notebook’s hardware and built-in system software. Your
notebook is compatible with the IBM® PC AT.
It comes with Microsoft® Windows® XP Home Edition
or Windows XP Professional pre-installed.
Conventions Used in the Guide
Keyboard keys appear in brackets.
Example: [Fn], [F1], [ESC], [ENTER] and [CTRL].
Pages with additional information about a specific topic
are cross-referenced within the text.
Example: (See page xx.)
On screen buttons or menu items appear in bold
Example: Click OK to restart your LifeBook notebook.
Preface
■
E-mail: 8fujitsu@us.fujitsu.com
■
Web site: www.us.fujitsu.com/computers
Before you place the call, you should have the following
information ready so that the customer support
representative can provide you with the fastest possible
solution:
■
Product name
■
Product configuration number
■
Product serial number
■
Purchase date
■
Conditions under which the problem occurred
■
Any error messages that have occurred
■
Hardware configuration
■
Type of device connected, if any
Fujitsu Online
You can go directly to the online Fujitsu Product catalog
for your LifeBook notebook by clicking on the LifeBook
Accessories Web site URL link, located in the Windows
Start menu.
You can also reach Fujitsu Service and Support online by
clicking on the Fujitsu Service and Support Web site
URL link, located in the Service and Support Software
folder of the Windows Start menu.
You must have an active internet
connection to use the on-line URL links.
DOS commands you enter appear in Courier type.
Example: Shut down the computer?
The information icon highlights
information that will enhance your
understanding of the subject material.
The caution icon highlights information
that is important to the safe operation of
your computer, or to the integrity of your
files. Please read all caution information
carefully.
The warning icon highlights information
that can be hazardous to either you, your
notebook, or your files. Please read all
warning information carefully.
FUJITSU CONTACT INFORMATION
Service and Support
You can contact Fujitsu Service and Support the
following ways:
■
Toll free: 1-800-8Fujitsu (1-800-838-5487)
WARRANTY
Depending upon the configuration of your LifeBook
notebook, your system is backed by either a one-year or
three-year International Limited Warranty. Check the
information that came with your LifeBook notebook for
further warranty terms and conditions.
3
cygnus.book Page 4 Tuesday, September 30, 2003 4:22 PM
LifeBook N Series User’s Guide
4
cygnus.book Page 5 Tuesday, September 30, 2003 4:22 PM
2
Getting to Know
Your LifeBook Notebook
5
cygnus.book Page 6 Tuesday, September 30, 2003 4:22 PM
LifeBook N Series User’s Guide
6
cygnus.book Page 7 Tuesday, September 30, 2003 4:22 PM
Getting to Know Your LifeBook
Figure 2-1. LifeBook N Series
Overview
This section describes the components of your Fujitsu
LifeBook N Series notebook. We strongly recommend
that you read it before using your LifeBook notebook,
even if you are already familiar with notebook
computers.
UNPACKING
When you receive your LifeBook notebook, unpack it
carefully, and compare the parts you have received with
the items listed below.
For a pre-configured model you should have:
■
LifeBook N Series notebook computer (Figure 2-1)
■
Lithium ion battery, pre-installed
■
AC adapter with AC power cord (Figure 2-2)
■
Optical drive
■
Phone/Modem (RJ-11) telephone cable
■
Drivers and Applications Restore CD
■
Getting Started Guide
■
User’s Guide (this guide)
■
International Limited Warranty Brochure
■
Microsoft-associated materials
Depending upon the configuration of your system, one
or more of the following items may also be included in
the box:
■
DVD Player Application CD
■
Additional battery(ies)
Figure 2-2. AC Adapter
7
1
2
3
4
5
6
7
8
9
10
111213
14
15
cygnus.book Page 8 Tuesday, September 30, 2003 4:22 PM
Figure 2-3. LifeBook notebook with display open 1
Locating the Controls
and Connectors
Wireless LAN Switch
2
Embedded Wireless
Antenna Location
3
Display Panel Latch
4
Display Panel
5
System Status/
Volume Indicators
6
Power/Suspend/Resume
Button
7
Volume Control Dial
8
Right Speaker
9
Keyboard
10
Touchpad Pointing Device
11
Battery Latch
12
Media Drive Eject Button
13
Media Drive
14
Scrolling Button
15
Left Speaker
Display Panel Latch
The display panel latch locks and releases the display
panel.
Display Panel
TOP AND FRONT COMPONENTS
The following is a brief description of your LifeBook
notebook’s top and front components.
Wireless LAN Switch
The wireless LAN switch is used to turn on and off the
optional wireless LAN device.
Wireless LAN Antenna
This is the location of the antenna for the optional
wireless LAN device.
The display panel is a color LCD panel with back
lighting for the display of text and graphics.
System Status/Volume Indicators
The System Status Indicators display symbols that
correspond with specific components of your LifeBook
notebook. The volume indicators display the volume
level as selected with the volume dial. (See Status Indi-
cator Panel/Volume LEDs on page 14 for more information)
8
cygnus.book Page 9 Tuesday, September 30, 2003 4:22 PM
Power/Suspend/Resume Button
The Power/Suspend/Resume button allows you to
suspend notebook activity without powering off,
resume your notebook from suspend mode, and power
on your LifeBook notebook when it has been shut
down. (See Power On on page 25 for more information)
and (See Power and Suspend/Resume Button on page 28
for more information)
Volume Control Dial
The volume control dial can be used to manually control
the volume level. (See Controlling the Volume on page 18
for more information).
Stereo Speakers
The built-in dual speakers allow for stereo sound.
Keyboard
A full-size keyboard with dedicated Windows keys.
(See Using the Keyboard on page 16 for more information)
Getting to Know Your LifeBook
Touchpad Pointing Device
The pointing device is a Touchpad that allows you
simple cursor control. (See TouchPad Pointing Device on
page 19 for more information)
Battery Latch
The battery latch is used for releasing the system battery.
(See Replacing the Battery on page 34 for more information)
Media Drive Eject Button
The Media Drive eject button is used to open the disc
tray of the optical drive when the notebook is powered
on.
Media Drive
The media drive bay can accommodate one of the
following devices.
■
Modular DVD/CD-RW combo drive
■
Modular DVD-RW drive
Scrolling Button
The scrolling button lets you navigate quickly through a
document without having to use the window scroll bars.
(See Scrolling on page 20 for more information)
9
1234
cygnus.book Page 10 Tuesday, September 30, 2003 4:22 PM
Figure 2-4. LifeBook notebook left-side panel 12Air Vents
LEFT-SIDE PANEL COMPONENTS
Following is a brief description of your LifeBook notebook’s left-side components.
Air Flow Vents
The air flow vents assist in the proper cooling of the
system.
USB 2.0 Ports
The four USB ports (two on the left side panel and two
on the rear panel) allow you to connect Universal Serial
Bus (USB) 2.0 or USB 1.1 devices. (See Universal Serial
Bus (USB) 2.0 Ports on page 45 for more information)
34Headphone Jack
USB Ports
Microphone Jack
Optical Digital Audio-Out/Headphone Jack
When used as an optical digital audio-out, this jack
allows you to download digital audio onto a MiniDisc
recorder’s SPDIF (Sony Philips Digital Interface) format.
(See Optical Digital Audio-Out Connector on page 45 for
more information). When used as a headphone jack, this
jack allows you to connect headphones or powered
external speakers. (See Headphone Jack on page 46 for
more information)
Microphone Jack
The microphone jack allows you to connect an external
mono microphone. (See Microphone Jack on page 45 for
more information)
10
12
3
4
5
cygnus.book Page 11 Tuesday, September 30, 2003 4:22 PM
Getting to Know Your LifeBook
Figure 2-5. LifeBook notebook right-side panel 1
2
3
RIGHT-SIDE PANEL COMPONENTS
Following is a brief description of your LifeBook notebook’s right-side components.
PC Card Eject Buttons
The PC Card eject buttons are used to eject a PC Card
from the PC Card slot. (See PC Cards on page 42 for more
information)
PC Card Slots
The PC Card Slots allow you to install two Type I or
Type II PC Cards or one Type III PC Card.
(See PC Cards on page 42 for more information)
Internal Floppy Disk Drive
The standard floppy disk drive accommodates 3.5"
floppy disks. (See Internal Floppy Disk Drive on page 35
for more information)
Floppy Disk Eject Button
The floppy disk eject button allows you to remove a
floppy disk from the floppy disk slot. (See Internal
Floppy Disk Drive on page 35 for more information)
PC Card Eject Buttons
PC Card Slots
Internal Floppy Disk Drive
45Floppy Disk Eject Button
Memory Stick/SD Card Slot
Memory Stick/SD Card Slot
The Memory Stick/Secure Digital (SD) card slot allows
you to install a flash memory card for data storage. This
architecture allows you to transfer data between a
variety of different digital devices. (See Installing
Memory Stick/SD Cards on page 39 for more information)
11
1
2
3
4
5
6
7
8
9
cygnus.book Page 12 Tuesday, September 30, 2003 4:22 PM
Figure 2-6. LifeBook notebook back panel 1
REAR PANEL COMPONENTS
Following is a brief description of your LifeBook notebook’s rear panel components.
IEEE 1394 Jack
The IEEE 1394 jack is used to connect Firewire devices
(such as digital cameras) to your LifeBook notebook.
(See IEEE 1394 Jack on page 45 for more information)
USB 2.0 Ports
The four USB ports allow you to connect Universal
Serial Bus 2.0 or USB 1.1 devices. (See Universal Serial
Bus (USB) 2.0 Ports on page 45 for more information)
LAN Port
The LAN port is designed to accept a Local Area
Network (LAN) RJ-45 jack. (See Communications Ports
on page 45 for more information)
Modem Port
The modem port is designed to accept a Modem (RJ-11)
telephone jack for the multi-national internal 56K
modem. (See Communications Ports on page 45 for more
information)
Air Flow Vents
The air flow vents assist in the proper cooling of the
system.
Anti-theft Lock Slot
The anti-theft lock slot allows you to attach an optional
physical lock down device.
IEEE 1394 Jack
2
USB 2.0 Ports
3
LAN Port
4
Modem Port
5
Air Flow Vents
6
Anti-Theft Lock Slot
7
DC Power Jack
8
External Monitor Port
9
S-Video Out Port
DC Power Jack
The DC power jack allows you to plug in the AC adapter
to power your LifeBook notebook and charge the
internal Lithium ion battery.
External Monitor Port
The external monitor port allows you to connect an
external monitor. (See External Monitor Port on page 46
for more information)
S-Video Out Port
The S-Video out port is used to transmit a higher
resolution video signal to a compatible TV or VCR.
(See S-Video Out Port on page 45 for more information)
The internal modem is designed to the
ITU-T V.90 standard. Its maximum speed
of 53000bps is the highest allowed by
FCC, and its actual connection rate
depends on the line conditions. The
maximum upload speed is 33600bps.
The internal modem is not intended for
use with Digital PBX systems. Do not
connect the modem to a digital PBX as it
may cause serious damage to the internal
modem or your LifeBook notebook.
Consult your PBX manufacturer’s
documentation for details. Some hotels
have Digital PBX systems. Be sure to find
out BEFORE you connect your modem.
Third-party hardware is available to allow
modem-to-PBX interface.
12
1
2
3
4
cygnus.book Page 13 Tuesday, September 30, 2003 4:22 PM
Getting to Know Your LifeBook
Figure 2-7. LifeBook notebook bottom panel 1
BOTTOM COMPONENTS
Following is a brief description of your LifeBook notebook’s bottom panel components.
Air Flow Vents
The air flow vents assist in the proper cooling of the
system.
Configuration Label
The configuration label shows the configuration part
number, the Fujitsu part number, and the various
components that make up your LifeBook notebook.
This label provides manufacturer information that you
will need to give your support representative in the event
you find it necessary to contact Fujitsu.
Air Flow Vents
2
Memory Compartment Cover
3
Lithium ion Battery Bay
4
Configuration Label
(approximate location)
Memory Compartment Cover
Your LifeBook notebook comes with high speed
DDR333 SO-DIMM memory. The memory upgrade
compartment allows you to expand the system memory
capacity of your LifeBook notebook, thus improving
overall performance. Note: The memory compartment
cover also covers the location of the optional wireless
LAN device; the memory location is outlined with a
dotted line in the illustration above. (See Memory
Upgrade Module on page 43 for more information)
Lithium ion Battery Bay
The battery bay contains the internal Lithium ion
battery. It can be opened for the removal of the battery
when stored over a long period of time or for swapping
a discharged battery with a charged Lithium ion battery.
(See Lithium ion Battery on page 33 for more information)
13
1 Power
12345678
9
10
2 Battery Charging/Battery Status
3 Hard Drive Access
4 Floppy Drive Access
5 Media Drive Access
6 NumLk
7 CapsLk
8 ScrLk
9 Sound Level LEDs
10 Volume Dial
cygnus.book Page 14 Tuesday, September 30, 2003 4:22 PM
LifeBook N Series User’s Guide
Figure 2-8 Status Indicator Panel/Volume LEDs
Status/Volume Indicators
There are two sets of status indicators on your LifeBook
notebook. The larger array, called the Status Indicator
panel, is located below the left of the display. Within this
panel are symbols that correspond to specific component of your LifeBook notebook. These symbols tell you
how each of those components is operating. (Figure 2-8)
The second set of status indicators is located below the
right of the display, adjacent to the volume dial. These
LEDs indicate the eight volume levels.
POWER INDICATOR
The Power indicator shows whether your system is operating. It has three different states, each of which tells you
what mode your LifeBook notebook is in at that time.
■
Steady On: This means that there is power to your
LifeBook notebook and that it is ready for use.
■
Flashing: This means that your LifeBook notebook is
in Suspend mode.
■
Steady Off: This means that your notebook is either in
Save-to-Disk mode, or it has been turned off with the
power/suspend/resume button.
If you are charging your battery, the Power indicator
remains on even if the notebook is shut off. The Power
indicator will also remain on if you have an adapter
connected and are shut down from Windows, but have
not turned off using the power/suspend/resume button.
BATTERY CHARGING INDICATOR
The Battery Charging indicators display whether or not
the Lithium ion battery is currently being charged.
LED Condition Charging Status of Battery
Green, solid
Orange, solid Being charged
Orange, blinking
Off
Fully charged or no battery
installed.
Charging suspended because battery temperature too high.
Not charging because AC adapter
is not connected.
BATTERY STATUS INDICATOR
This indicators display how much charge is available
within the installed battery.
LCD Condition Battery Charge Level
Green, solid Between 51% and 100% charged
Orange, solid Between 10% and 50% charged
Red, solid Between 0% and 9% charged
Red, blinking There is a problem with the battery
Off
No battery is installed or the system
is shut off.
14
cygnus.book Page 15 Tuesday, September 30, 2003 4:22 PM
Getting to Know Your LifeBook
HARD DRIVE ACCESS INDICATOR
The Hard Drive Access indicator states whether your
internal hard drive is being accessed.
FLOPPY DRIVE ACCESS INDICATOR
The Floppy Drive Access indicator states whether the
internal floppy disk drive is being accessed. This indicator will flash if your software tries to access a disk even
if no floppy disk drive is installed. (See Internal Floppy
Disk Drive on page 35 for more information)
MEDIA PLAYER ACCESS INDICATOR
The media player Access indicator tells you that the
media player drive is being accessed. If the Auto Insert
Notification function is active, the indicator will flash
periodically when your system is checking the media
player drive. If the Auto Insert Notification function is
not active, the indicator will only flash when you access
the media player drive. The default setting is the Auto
Insert Notification function active.
NUMLK INDICATOR
The NumLk indicator states that the internal keyboard is
set in ten-key numeric keypad mode.
CAPSLOCK INDICATOR
The CapsLock indicator states that your keyboard is set
to type in all capital letters.
SCRLK INDICATOR
The ScrLk indicator states that your scroll lock is active.
VOLUME LEVEL LEDS
The eight volume level LEDs correspond to the volume
set with the volume dial.
VOLUME DIAL
The volume dial is a simple way to adjust the volume.
Turn the dial clockwise to raise the volume; counterclockwise to lower the volume.
15
23
1
564
cygnus.book Page 16 Tuesday, September 30, 2003 4:22 PM
LifeBook N Series User’s Guide
Enter
Figure 2-9. Keyboard 1
Keyboard
USING THE KEYBOARD
Your Fujitsu LifeBook notebook has an integrated 84key keyboard. The keys perform all the standard functions of a 101-key keyboard, including the Windows
keys and other special function keys. This section
describes the following keys.
■
Numeric keypad: Your LifeBook notebook allows
certain keys to serve dual purposes, both as standard
characters and as numeric and mathematical keys. The
ability to toggle between the standard character and
numerical keys is controlled through the [NumLk]
key.
■
Cursor keys: Your keyboard contains four arrow
keys for moving the cursor or insertion point to the
right, left, up, or down within windows, applications
and documents.
■
Function keys: The keys labeled [F1] through [F12]
are used in conjunction with the [Fn] key to produce
special actions that vary depending on what program
is running.
■
Windows keys: These keys work with your Windows
operating system and function the same as the
Function Keys
2
[Fn] Key
3
Start Key
4
Numeric Keypad (surrounded by thick gray line)
5
Application Key
6
Cursor Keys
onscreen Start menu button, or the right button on
your pointing device.
NUMERIC KEYPAD
Certain keys on the keyboard perform dual functions as
both standard character keys and numeric keypad keys.
NumLk can be activated and deactivated by pressing the
[NumLk] keys. Once this feature is activated you can
enter numerals 0 through 9, perform addition ( + ),
subtraction ( - ), multiplication ( * ), or division ( / ),
and enter decimal points ( . ) using the keys designated
as ten-key function keys. The keys in the numeric
keypad are marked on the front edge of the key to indicate their secondary functions.
WINDOWS KEYS
Your LifeBook notebook has two Windows keys: a Start
key and an Application key. The Start key displays the
Start menu. This button functions the same as your
onscreen Start menu button. The Application key functions the same as your right mouse button and displays
shortcut menus for the selected item. (Please refer to
your Windows documentation for additional information regarding the Windows keys.)
16
cygnus.book Page 17 Tuesday, September 30, 2003 4:22 PM
Getting to Know Your LifeBook
CURSOR KEYS
The cursor keys are the four arrow keys on the keyboard
which allow you to move the cursor up, down, left and
right in applications. In programs such as Windows
Explorer, it moves the “focus” (selects the next item up,
down, left, or right).
FUNCTION KEYS
Your LifeBook notebook has 12 function keys, F1
through F12. The functions assigned to these keys differ
for each application. You should refer to your software
documentation to find out how these keys are used.
The [Fn] key provides extended functions for the
notebook and is always used in conjunction with
another key.
■
[Fn+F3]: Pressing [F3] while holding [Fn] will toggle
the Audio Mute on and off.
■
[Fn+F4]: Pressing [F4] while holding [Fn] will toggle
the touchpad on and off. (This function key combination only works if the BIOS setting for Advanced ->
Keyboard/Mouse Features -> Internal Pointing Device
is set to Manual Setting.)
■
[Fn+F5]: Pressing [F5] while holding [Fn] allows
you to toggle between video compensation and no
compensation. (Video compensation controls spacing
on the display. When it is enabled, displays with less
than 1024 x 768 or 800 x 600 pixel resolution will still
cover the entire screen.)
■
[Fn+F6]: Pressing [F6] repeatedly while holding [Fn]
will lower the brightness of your display.
■
[Fn+F7]: Pressing [F7] repeatedly while holding [Fn]
will increase the brightness of the display.
■
[Fn+F10]: Pressing [F10] while holding [Fn] allows
you to change your selection of where to send your
display video. Each time you press the combination of
keys you will step to the next choice. The choices, in
order, are: built-in display panel only, both built-in
display panel and external monitor or external
monitor only.
■
[Fn+F11]: Pressing [F11] while holding [Fn] allows
you to send your screen display to a connected SVideo device. Pressing the switch repeatedly toggles
between computer display and S-Video device or
computer display only.
17
cygnus.book Page 18 Tuesday, September 30, 2003 4:22 PM
LifeBook N Series User’s Guide
Volume Control
Your LifeBook notebook has multiple volume controls
which interact with each other.
Software that contains audio files will also
contain a volume control of its own. If you
install an external audio device that has an
independent volume control, the hardware
volume control and the software volume
control will interact with each other. It
should be noted that if you set your software volume to Off, you will override the
external volume control setting.
CONTROLLING THE VOLUME
The volume can be controlled in several different ways:
■
Volume can be set using the volume dial above the
keyboard on the right-hand side. (See Figure 2-8 on
page 14 for location).
■
Volume can be set from within the Volume Control
Properties which are located either in the system tray
or from Sounds, Speech, and Audio Devices in the
Control Panel.
■
Volume can be controlled by many volume controls
that are set within individual applications.
■
Certain external audio devices you might connect to
your system may have hardware volume controls.
Each source discussed above puts an upper limit on the
volume level that must then be followed by the other
sources.
We recommend that you experiment with the various
volume controls to discover the optimal sound level.
18
2
3
1
4
cygnus.book Page 19 Tuesday, September 30, 2003 4:22 PM
Getting to Know Your LifeBook
Figure 2-10. Touchpad Pointing Device 12Cursor Control
TouchPad Pointing Device
The TouchPad pointing device is built into your Fujitsu
LifeBook notebook. It is used to control the movement
of the pointer to select items on your display panel. The
TouchPad is composed of a cursor control, a left and
right button, and an up-and-down scroll button. The
cursor control works the same way a mouse does, and
moves the cursor around the display. It only requires
light pressure with the tip of your finger, and the more
pressure you use, the faster the cursor will move. The left
and right buttons function the same as mouse buttons.
The actual functionality of the buttons may vary
depending on the application that is being used. The upand down scroll buttons allow you to quickly navigate
up and down a screen. (Figure 2-10)
An external mouse can be connected to
the USB port on your LifeBook notebook,
and be used simultaneously with the
TouchPad. However, if you boot the system with an external mouse connected the
TouchPad will be disabled or enabled
depending on your BIOS settings.
BIOS Setup Utility on page 25 for more
information)
(See
34Right Button
Scroll Buttons
Left Button
perform the clicking operation by tapping lightly on the
To u ch Pa d o n ce . (Figure 2-11)
Figure 2-11. Clicking
DOUBLE-CLICKING
Double-clicking means pushing and releasing the left
button twice in rapid succession. This procedure does
not function with the right button. To double-click,
move the cursor to the item you wish to select, press the
left button twice, then immediately release it. You also
have the option to perform the double-click operation
by tapping lightly on the TouchPad twice. (Figure 2-12)
CLICKING
Figure 2-12. Double-clicking
Clicking means pushing and releasing a button. To leftclick, move the cursor to the item you wish to select,
press the left button once, and then immediately release
it. To right-click, move the mouse cursor to the item you
If the interval between clicks is too long,
the double-click will not be executed.
wish to select, press the right button once, and then
immediately release it. You also have the option to
19
cygnus.book Page 20 Tuesday, September 30, 2003 4:22 PM
LifeBook N Series User’s Guide
DRAGGING
Dragging means pressing and holding the left button,
while moving the cursor. To drag, move the cursor to
the item you wish to move. Press and hold the left
button while moving the item to its new location
and then release it. Dragging can also be done using the
TouchPad. First, tap the TouchPad twice over the item
you wish to move making sure to leave your finger on
the pad after the final tap. Next, move the object to its
new location by moving your finger across the
TouchPad, and then release your finger. (Figure 2-13)
Figure 2-13. Dragging
SCROLLING
Using the scroll buttons allows you to scroll up and
down a page easily without using the window scroll bars.
To move up a page, press the upper part of the button.
To move down a page, use the lower part of the button.
(Figure 2-14)
Figure 2-14. Scrolling
TOUCHPAD CONTROL ADJUSTMENT
The Windows Control Panel allows you to customize your
TouchPad with selections made from within the Mouse
Properties dialog box.
20
cygnus.book Page 21 Tuesday, September 30, 2003 4:22 PM
3
Getting Started
21
cygnus.book Page 22 Tuesday, September 30, 2003 4:22 PM
LifeBook N Series User’s Guide
22
1
2
3
4
cygnus.book Page 23 Tuesday, September 30, 2003 4:22 PM
Getting Started
Figure 3-1. Connecting the AC Adapter 12DC Power Jack
Power Sources
Your Fujitsu LifeBook notebook has two possible power
sources: a Lithium ion battery or an AC adapter.
CONNECTING THE AC ADAPTER
The AC adapter provides power for operating your
LifeBook notebook and is used to charge the batteries.
Connecting the AC Adapter
1. Plug the DC output cable into the DC power jack of
your LifeBook notebook.
2. Plug the AC cable into the AC adapter.
3. Plug the AC cable into an AC electrical outlet.
(Figure 3-1)
Switching from AC Adapter Power to Battery Power
1. Be sure that you have a charged battery installed.
2. Unplug the AC adapter.
■
When you run the N Series LifeBook
on battery power, by default, the CPU
will slow down approximately by half
in order to optimize battery life. This
feature can be enabled or disabled in
the BIOS. Use an AC Adapter whenever possible.
■
The Lithium ion battery is not charged
upon purchase. Initially, you will need
to connect the AC adapter to use your
LifeBook notebook.
DC Output Cable
34AC Adapter
AC Cable
23
cygnus.book Page 24 Tuesday, September 30, 2003 4:22 PM
LifeBook N Series User’s Guide
Figure 3-2 Opening the Display Panel
Display Panel
Your Fujitsu LifeBook notebook contains a display panel
that is backlit for easier viewing in bright environments
and maintains top resolution through the use of activematrix technology.
OPENING THE DISPLAY PANEL
1. Slide the display panel latch to the right to release
the locking mechanism.
2. Lift the display panel backwards, being careful not to
touch the screen, until it is at a comfortable
viewing angle.
ADJUSTING DISPLAY PANEL BRIGHTNESS
Once you have turned on your LifeBook notebook, you
may want to adjust the brightness level of the screen to a
more comfortable viewing level. The Function keys on
the keyboard are used to change the brightness level of
the display.
Using the Keyboard to Change Display Brightness
■
[Fn+F6]: Pressing this key combination repeatedly will
lower the brightness of your display.
■
[Fn+F7]: Pressing this key combination repeatedly will
increase the brightness of the display.
CLOSING THE DISPLAY PANEL
1. Holding the edge of your display panel, pull it
forward until it is flush with the body of your
LifeBook notebook.
2. Push down until you hear a click. This will engage
the locking mechanism and prevent your display
panel from opening unexpectedly.
■
If using AC power, your LifeBook notebook’s brightness setting is set to its
highest level by default. If using battery
power, the brightness setting is set to its
middle level by default.
■
The higher the brightness level, the
more power the LifeBook notebook will
consume and the faster your batteries
will discharge. For maximum battery life,
set the brightness level as low as possible.
24
