AIR CONDITIONER
AUU18RGLX
AUU24RGLX
AUU30RGLX
AUU36RGLX
AUU42RGLX
AUU48RGLX
OPERATING MANUAL
Cassette type
MODE D’EMPLOI
Type cassette
MANUAL DE FUNCIONAMIENTO
Tipo casete
English
Français
Español
KEEP THIS MANUAL FOR FUTURE REFERENCE
CONSERVEZ CE MANUEL POUR RÉFÉRENCE
ULTÉRIEURE
CONSERVE ESTE MANUAL PARA FUTURA
REFERENCIA
PART No. 9381622061-02
OPERATING MANUAL
PART No. 9381622061-02
Air Conditioner (Cassette type)
CONTENTS
SAFETY PRECAUTIONS ...................................................... 1
NAME OF PARTS .................................................................. 2
CLEANING AND CARE ......................................................... 2
OPERATING TIPS ................................................................. 3
TROUBL ESHO OTING ........................................................... 5
SAFETY PRECAUTIONS
To prevent personal injury, or property damage, read this
section carefully before you use this product, and be sure to
comply with the following safety precautions.
Incorrect operation due to failure to follow the instructions
may cause harm or damage, the seriousness of which is
classifi ed as follows:
WARNING
CAUTION
This mark denotes an action that is PROHIBITED.
This mark denotes an action that is COMPULSORY.
•
This product contains no user-serviceable parts.
Always consult authorized service personnel for repairing, installation, and relocation of this product.
Improper installation or handling will cause leakage, electric shock, or fi re.
• In the event of a malfunction such as burning smell,
immediately stop operation of the air conditioner,
and disconnect all the power supply by turning off
the electrical breaker or disconnecting the power
plug. Then consult authorized service personnel.
• Take care not to damage the power supply cable.
If it is damaged, it should only be replaced by
authorized service personnel.
• In the event of refrigerant leakage, be sure to
keep away from fi re or any fl ammables, and con-
sult authorized service personnel.
• In the event of a thunder storm or any prior sign
of a lightning strike, turn off the air conditioner via
the remote controller, and refrain from touching
the product or the power source to prevent any
electrical hazards.
• This appliance is not intended for use by persons
(including children) with reduced physical, sensory or mental capabilities, or lack of experience
and knowledge, unless they have been given
supervision or instruction concerning use of the
appliance by a person responsible for their safety.
Children should be supervised to ensure that they
do not play with the appliance.
This mark warns of death or serious injury.
This mark warns of injury or damage
to property.
WARNING
• Do not start or stop the operation of this product
by turning on or off the circuit breaker.
• Do not use fl ammable gases near this product.
• Do not expose yourself directly to the cooling
airfl ow for many hours.
• Do not insert your fi ngers or any other objects
into the outlet port or inlet port.
• Do not operate with wet hands.
CAUTION
• Provide occasional ventilation during use.
• Always operate this product with air fi lters installed.
• Ensure that any electronic equipment is at least
40 in (1 m) away from either the indoor unit or
outdoor unit.
• Disconnect all the power supply when you are not
using this product for extended periods.
• After a long period of use, ensure to get the
mounting of the indoor unit checked to prevent
this product from falling down.
• The airfl ow direction and the room temperature
should be carefully considered when you use this
product in a room with infants, children, elderly or
sick persons.
• Do not direct the airfl ow at fi replaces or heating
apparatus.
• Do not block or cover the inlet port and the outlet
port.
• Do not apply any heavy pressure to radiator fi ns.
• Do not climb on, place objects on, or hang objects from this product.
• Do not place any other electrical products or
household belongings under this product.
Dripping condensation from this product might
get them wet, and may cause damage or malfunction of your property.
• Do not expose this product directly to water.
• Do not use this product for preservation of food,
plants, animals, precision equipment, art work, or
other objects. This may cause quality deterioration of those items.
• Do not expose animals or plants to the direct
airfl ow.
• Do not drink the drainage from the air conditioner.
• Do not pull the power supply cable.
• Do not touch the aluminum fi ns of heat exchanger
built-in this product to avoid personal injury when
you maintain the unit.
• Do not stand on unstable steps when operating
or cleaning this product. It may overturn and can
cause injury.
En-1
NAME OF PARTS
Indoor unit
1
Cleaning the air fi lter
Push the intake grille push
1
buttons (two places) and
open the intake grille.
Pull out the air fi lter from the
2
intake grille.
2-[1]
2-[2]
3
2-[4]
1
Air fi lter (in air intake grille)
2
Airfl ow direction outlet
Individual airfl ow direction control: [1][2][3][4]
3
Air intake grille
4
Remote controller *
*: For detailed instructions on how to operate, please refer to
the Operating manual of the remote controller.
2-[3]
CLEANING AND CARE
CAUTION
• Before cleaning the unit, be sure to stop the unit
and disconnect the power supply.
• Turn off the electrical breaker.
• The fan operates at high speed inside the unit,
and could result in personal injury.
• Be careful not to drop the intake grille.
• As fi lter cleaning involves work in high places,
please consult authorized service personnel.
• Do not expose the unit to liquid insecticides or
hair sprays.
• When used for extended periods, the unit may accumulate
dirt inside, reducing its performance. We recommend that
the unit be inspected regularly, in addition to your own
cleaning and care. For more information, consult authorized service personnel.
• When cleaning the unit, do not use water hotter than 104°F
(40°C), harsh abrasive cleansers, or volatile agents like
benzene or thinner.
• If the unit will not be operated for a period of 1 month or
more, be sure to allow the inner parts of the unit to dry
thoroughly, in advance, by operating the unit in Fan mode
for half a day.
Clean the air fi lter.
3
Remove the dust from the air fi lter by vacuuming or
washing it. After washing, allow the air fi lter to dry thor-
oughly in an area protected from sunlight.
• Dust can be cleaned from the air fi lter either with a
vacuum cleaner, or by washing the air fi lter in a solu-
tion of mild detergent and warm water. If you wash the
air fi lter, be sure to allow it to dry thoroughly in a shady
place before reinstalling.
• If dirt is allowed to accumulate on the air fi lter, airfl ow
will be reduced, lowering operating effi ciency and
increasing noise.
Re-attach the air fi lter to the
4
intake grille.
1 Replace the air fi lter into its
holder.
2 Make sure that the air fi lter
makes contact with the fi lter
stopper when it is replaced
into its holder.
Close the intake grille.
5
NOTES
Filter sign
Select appropriate intervals for displaying the fi lter sign on
the indoor unit according to the estimated amount of dust in
the air of the room.
Please consult authorized service personnel when using this
function.
For detailed instructions on how to operate, please refer to
the Operating manual of the remote controller.
En-2
OPERATING TIPS
Instructions relating to heating (*) are applicable only to
Heating and Cooling model (Reverse Cycle).
Heating performance*
• This air conditioner operates on the heat-pump principle,
absorbing heat from outdoor air and transferring that heat
indoors. As a result, the operating performance is reduced
as outdoor air temperature drops. Also, please consult with
your installation technician to ensure the unit is correctly
sized for the room space required.
• Heat-pump air conditioners heat your entire room by recirculating air throughout the room, with the result that some
time may be required after fi rst starting the air conditioner
until the room is heated.
When indoor and outdoor temperatures are high*
When both indoor and outdoor temperatures are high during use
of the Heating mode, the outdoor unit’s fan may stop at times.
Microcomputer-controlled automatic defrosting*
• When using the Heating mode under conditions of low
outdoor temperature and high humidity, frost may form on
the outdoor unit, reducing the operating performance.
In order to prevent this reduced performance, this product
is equipped with a microcomputer-controlled automatic
defrosting function. During the defrost cycle, the indoor fan
will shut down, and the defrost mode will be indicated. It
will take maximum of 15 minutes before the air conditioner
starts up again.
• After Heating operation stops, if frost forms on the outdoor
unit, the unit will start Automatic defrosting operation.
At this time, the outdoor unit will automatically stop after
operating for a few minutes.
Flow direction setting
Vertical air direction adjustment
Airfl ow direction setting:1, 2, 3, 4: During cooling/heating/dry mode
NOTES
• Attempting to move up/down air direction fl aps manu-
ally could result in improper operation; in this case, stop
operation and restart. The louvers should begin to operate
properly again.
• When used in a room with infants, children, elderly or sick
persons, the air direction and room temperature should be
considered carefully when making settings.
Horizontal air direction adjustment
The function cannot be used.
Swing operation
The type of operation Range of swing
Cooling/Heating/Dry/Fan
The swing operation may stop temporarily when the air conditioner’s fan is not operating, or when operating at very low
speeds.
Hot start*
The indoor unit prevents cold drafts when Heating operation
begins.
The indoor unit fan will not operate or it will operate at a very low
speed until the heat exchanger reaches the set temperature.
Low ambient cooling
When the outdoor temperature drops, the outdoor unit’s fans
may switch to low speed, or one of the fans may stop intermittently.
Mode operation
Auto
Cooling model:
• When AUTO (auto changeover) operation fi rst selected,
the fan will operate at very low speed for about a few
minutes, during which time the indoor unit detects the
room conditions and selects the proper mode.
Room temperature is higher than the defi ned temperature
in temperature setting → Cooling mode
Room temperature is close to or lower than the defi ned
temperature in temperature setting → Monitor operation
to
1
4
• The vertical airfl ow direction is set automatically as shown,
in accordance with the type of operation selected.
During cooling/dry mode: Horizontal fl ow 2
During heating mode*:
Downward fl ow 4(36 type or smaller capacity model)
3(42 type or larger capacity model)
• During AUTO mode operation, for the fi rst minute after
beginning operation, airfl ow will be horizontal 2; the air
direction cannot be adjusted during this period.
Even if the fl ow direction is set, it may operate at a dif-
ferent position at the start of heating operation, during
defrost, or when AUTO(auto changeover) is selected.
En-3
Cooling mode
Defi ned tem-
perature in
temperature
setting
• When the indoor unit has adjusted your room’s temperature to near the temperature setting, it will begin monitor
operation. In the monitor operation mode, the fan will
operate at low speed. If the room temperature subsequently changes, the indoor unit will once again select
the appropriate operation (cooling) to adjust the temperature to the value set in the temperature setting.
• If the mode automatically selected by the unit is not what
you wish, select one of the mode operation (Cooling,
Dry, Fan).
Monitor operation
Heating and Cooling model (Reverse cycle):
• When AUTO (auto changeover) is selected, the air conditioner selects the appropriate operation mode (Cooling or
Heating) according to your room’s present temperature.
• When Auto mode is fi rst selected, the fan will operate at
low speed for about a few minutes, during which time the
indoor unit detects the room conditions and selects the
proper operation mode.
Room temperature is higher than the defi ned tempera-
ture in temperature setting → Cooling mode
Room temperature is close to the defi ned temperature in
temperature setting → Determined by outdoor temperature
Room temperature is lower than the defi ned temperature
in temperature setting → Heating mode
Cooling mode
Fan
Use to circulate the air throughout your room.
NOTES
*During Heating mode:
Set the thermostat to a temperature setting that is higher
than the current room temperature. The Heating mode will
not operate if the thermostat is set lower than the actual
room temperature.
During Cooling/Dry mode:
Set the thermostat to a temperature setting that is lower than
the current room temperature. The Cooling and Dry modes will
not operate if the thermostat is set higher than the actual room
temperature (in Cooling mode, the fan alone will operate).
During Fan mode:
You cannot use the unit to heat or cool your room.
Defi ned temper-
ature in temperature setting
Determined by
outdoor temperature
Heating mode
• When the air conditioner has adjusted your room’s
temperature to near the thermostat setting, it will begin
monitor operation. In the monitor operation mode, the
fan will operate at low speed. If the room temperature
subsequently changes, the air conditioner will once again
select the appropriate operation (Heating, Cooling) to adjust the temperature to the value set in the thermostat.
If the mode automatically selected by the unit is not what
you wish, select one of the mode operation (Heating,
Cooling, Dry, Fan).
Heat*
• Use to warm your room.
• When Heating mode is selected, the air conditioner will
operate at very low fan speed for about 3 to 5 minutes,
after which it will switch to the selected fan setting. This
period of time is provided to allow the indoor unit to warm
up before beginning full operation.
• When the room temperature is very low, frost may form
on the outdoor unit, and its performance may be reduced. In order to remove such frost, the unit will automatically enter the defrost cycle from time to time. During
Automatic defrosting operation, the Heating operation
will be interrupted.
• After the start of Heating operation, it takes sometime
before the room gets warmer.
Cool
Use to cool your room.
Dry
• Use for gently cooling while dehumidifying your room.
• You cannot heat the room during Dry mode.
• During Dry mode, the unit will operate at low speed; in
order to adjust room humidity, the indoor unit’s fan may
stop from time to time. Also, the fan may operate at very
low speed when adjusting room humidity.
• The fan speed cannot be changed manually when Dry
mode has been selected.
Fan speed
Controls the fan speed.
AUTO HIGH QUIETMED LOW
When AUTO is selected, the fan speed is automatically adjusted according to the operation mode.
Heating*: The fan will operate at very low speed when the
temperature of the air issued from the indoor unit
is low.
Cooling: As the room temperature approaches that of the
set temperature, the fan speed becomes slower.
Fan: The fan runs at medium fan speed.
Auto restart
In Event of Power Interruption
• Should the power supply to the air conditioner be interrupted by a power failure, the air conditioner will restart
automatically in the previously selected mode once the
power is restored.
• Use of other electrical appliances (electric shaver, etc.) or
nearby use of a wireless radio transmitter may cause the
air conditioner to malfunction. In this event, temporarily
disconnect the power supply, reconnect it, and then use
the remote controller to resume operation.
If only the following remote controller is connected, auto
restart is not performed.
UTY-R*RY
Multiple remote controller (optional)
An additional remote controller can be added up to the
maximum of two remote controllers. Either remote controller
can control the air conditioner. However, the timer functions
cannot be used at the secondary unit.
Group control
One remote controller can control up to 16 air conditioners.
All of the air conditioners will be operated with the same settings.
En-4
Notices
• During use of the Heating mode, the outdoor unit will
*
occasionally commence the defrost operation for brief
periods. During the defrosting operation, if the user sets
the indoor unit for heating again, the defrosting mode
will continue, and the Heating operation will begin after
completion of defrosting, with the result that some time
may be required before warm air is emitted.
*
• During use of the Heating mode, the top of the indoor
unit may become warm, but this is due to the fact that
coolant is circulated through the indoor unit even when it
is stopped; it is not a malfunction.
TROUBLESHOOTING
Instructions relating to heating (*) are applicable only to
Heating and Cooling model (Reverse Cycle).
WARNING
In the following events, immediately stop operation of the air conditioner, and disconnect all the
power supply by turning off the electrical breaker
or disconnecting the power plug. Then consult your
dealer or authorized service personnel.
As long as the unit is connected to the power supply, it is not insulated from the power supply even if
the unit is turned off.
• Unit smells of something burning or emits smoke
• Water leaks from the unit.
Before requesting service, perform the following checks:
NORMAL FUNCTION
Does not operate immediately
• If the unit is stopped and then immediately started again,
the compressor will not operate for about 3 minutes, in
order to prevent fuse blowouts.
• Whenever the electrical breaker is turned off then on
again, the protection circuit will operate for about 3 minutes, preventing unit operation during that period.
Noise is heard
• During operation and immediately after stopping the unit,
the sound of water fl owing in the air conditioner’s piping
may be heard. Also, noise may be particularly noticeable
for about 2 to 3 minutes after starting operation (sound
of coolant fl owing).
• During operation, a slight squeaking sound may be
heard. This is the result of minute expansion and contraction of the front cover due to temperature changes.
* • During Heating operation, a sizzling sound may be heard
occasionally. This sound is produced by the Automatic
defrosting operation.
Smells
• Some smell may be emitted from the indoor unit. This
smell is the result of room smells (furniture, tobacco,
etc.) which have been taken into the air conditioner.
Mist or steam are emitted
• During Cooling or Dry operation, a thin mist may be
seen emitted from the indoor unit. This results from the
sudden cooling of room air by the air emitted from the air
conditioner, resulting in condensation and misting.
* • During Heating operation, the outdoor unit’s fan may
stop, and steam may be seen rising from the unit. This is
due to the Automatic defrosting operation.
Humidity does not drop
In the case of Dry operation.
• In some conditions of the room, the humidity does not
drop.
• In order to lower the humidity, set a lower room temperature.
Airfl ow is weak or stops
• Indoor unit fan may start later than the outdoor unit fan,
or it may stop when the outdoor unit fan is not operating.
This is due to the Indoor unit fan control for energy saving operation.
• To disable this function, refer to the operation manual of
the remote controller. (This function cannot be disabled
in Auto fan mode.)
* • When Heating operation is started, fan speed is tempo-
rarily very low, to allow internal parts to warm up.
* • During Heating operation, if the room temperature rises
above the thermostat setting, the outdoor unit will stop,
and the indoor unit will operate at very low fan speed. If
you wish to warm the room further, set the thermostat to
a higher setting.
* • During Heating operation, the unit will temporarily stop
operation (maximum of 15 minutes) as the Automatic
defrosting mode operates. During the Automatic defrosting operation, the defrost mode will be indicated.
<<See operating manual of Remote controller.>>
• The fan may operate at very low speed during Dry operation or when the unit is monitoring the room’s temperature.
• During Quiet operation, the fan will operate at very low
speed.
• In the monitor Auto operation, the fan will operate at very
low speed.
The fl ow direction does not change according to the
setting or does not change at all
• Even if the fl ow direction is set, it may operate temporar-
ily at a different position at the start of heating operation, during defrost, or when AUTO (auto changeover) is
selected.
Water is produced from the outdoor unit
* • During Heating operation, water may be produced from
the outdoor unit due to the Automatic defrosting operation.
En-5
CHECK ONCE MORE
Does not operate at all
• Has the circuit breaker been turned off?
• Has there been a power failure?
• Has a fuse blown out, or a circuit breaker been tripped?
• Is the timer operating?
Poor cooling (or heating*) performance
• Is the air fi lter dirty?
• Are the air conditioner’s intake grille or outlet port
blocked?
• Did you adjust the room temperature settings (thermostat) correctly?
• Is there a window or door open?
• In the case of Cooling operation, is a window allowing
bright sunlight to enter? (Close the curtains.)
• In the case of Cooling operation, are there heating apparatus and computers inside the room, or are there too
many people in the room?
• Is the unit set for Quiet operation?
• Is the air conditioner in Economy mode?
If the problem persists after performing these checks, or
if you notice burning smells, stop operation immediately,
disconnect the power supply, and consult with authorized
service personnel.
En-6
Loading...
