Fujitsu FLASH-CAN-64P-350-PMC User Manual

Fujitsu Microelectronics Europe
User Guide
FMEMCU-UG-960008-10
F²MC-16LX/FX FAMILY
EVALUATION BOARD
FLASH-CAN-64P-350-PMC
USER GUIDE
FLASH-CAN-64P-350-PMC
Revision History
UG-960008-10 - 2 - © Fujitsu Microelectronics Europe GmbH
Revision History
Date Issue
20.06.2007 V1.0, DGo, First Release
This document contains 29 pages.
FLASH-CAN-64P-350-PMC
Warranty and Disclaimer
© Fujitsu Microelectronics Europe GmbH - 3 - UG-960008-10
Warranty and Disclaimer
To the maximum extent permitted by applicable law, Fujitsu Microelectronics Europe GmbH restricts its warranties and its liability for the FLASH-CAN-64P-350 Board and all its deliverables (eg. software include or header files, application examples, target boards, evaluation boards, engineering samples of IC’s etc.), its performance and any consequential damages, on the use of the Product in accordance with (i) the terms of the License Agreement and the Sale and Purchase Agreement under which agreements the Product has been delivered, (ii) the technical descriptions and (iii) all accompanying written materials. In addition, to the maximum extent permitted by applicable law, Fujitsu Microelectronics Europe GmbH disclaims all warranties and liabilities for the performance of the Product and any consequential damages in cases of unauthorised decompiling and/or reverse engineering and/or disassembling.
Note: The FLASH-CAN-64P-350 Board and all its deliverables are intended and must only be used in an evaluation laboratory environment.
1. Fujitsu Microelectronics Europe GmbH warrants that the Product will perform substantially in accordance with the accompanying written materials for a period of 90 days form the date of receipt by the customer. Concerning the hardware components of the Product, Fujitsu Microelectronics Europe GmbH warrants that the Product will be free from defects in material and workmanship under use and service as specified in the accompanying written materials for a duration of 1 year from the date of receipt by the customer.
2. Should a Product turn out to be defect, Fujitsu Microelectronics Europe GmbH´s entire liability and the customer’s exclusive remedy shall be, at Fujitsu Microelectronics Europe GmbH´s sole discretion, either return of the purchase price and the license fee, or replacement of the Product or parts thereof, if the Product is returned to Fujitsu Microelectronics Europe GmbH in original packing and without further defects resulting from the customer’s use or the transport. However, this warranty is excluded if the defect has resulted from an accident not attributable to Fujitsu Microelectronics Europe GmbH, or abuse or misapplication attributable to the customer or any other third party not relating to Fujitsu Microelectronics Europe GmbH.
3. To the maximum extent permitted by applicable law Fujitsu Microelectronics Europe GmbH disclaims all other warranties, whether expressed or implied, in particular, but not limited to, warranties of merchantability and fitness for a particular purpose for which the Product is not designated.
4. To the maximum extent permitted by applicable law, Fujitsu Microelectronics Europe GmbH´s and its supplier’s liability are restricted to intention and gross negligence.
NO LIABILITY FOR CONSEQUENTIAL DAMAGES
To the maximum extent permitted by applicable law, in no event shall Fujitsu Microelectronics Europe GmbH and its suppliers be liable for any damages whatsoever (including but without limitation, consequential and/or indirect damages for personal injury, assets of substantial value, loss of profits, interruption of business operation, loss of information, or any other monetary or pecuniary loss) arising from the use of the Product.
Should one of the above stipulations be or become invalid and/or unenforceable, the remaining stipulations shall stay in full effect
FLASH-CAN-64P-350-PMC
Chapter 1 Contents
UG-960008-10 - 4 - © Fujitsu Microelectronics Europe GmbH
1 Contents
REVISION HISTORY............................................................................................................ 2
WARRANTY AND DISCLAIMER ......................................................................................... 3
1 CONTENTS...................................................................................................................... 4
2 OVERVIEW...................................................................................................................... 5
2.1 Abstract................................................................................................................... 5
2.2 Features.................................................................................................................. 5
2.3 General Description.................................................................................................6
3 INSTALLATION ............................................................................................................... 7
4 JUMPERS AND SWITCHES............................................................................................ 8
4.1 Jumper Overview .................................................................................................... 8
4.2 Operating-Mode (S2)............................................................................................. 10
4.3 Power Supply Voltage (JP: 29, 34)........................................................................ 11
4.4 Analogue Power Supply Voltage (JP: 11, 13, 15) .................................................. 12
4.5 Subclock (JP: 36, 37) ............................................................................................ 13
4.6 UART”A” (JP: 1, 2, 31) .......................................................................................... 14
4.7 UART”B” (JP: 6, 8, 32) .......................................................................................... 14
4.8 LIN”A” (JP: 17, 18) ................................................................................................ 15
4.9 LIN”B” (JP: 9, 10, 38, 39)....................................................................................... 15
4.10 CAN“A” (JP: 25, 26) .............................................................................................. 16
4.11 CAN“B” (JP: 27, 28) .............................................................................................. 16
4.12 Reset-Generation (JP: 3, 4, 5, 24, 35)................................................................... 17
4.13 Buttons INT10, INT11, TIN1, IN0, IN1, Reset (JP: 7, 12, 14, 16, 20, 23) ............... 18
5 PROGRAMMING THE INTERNAL FLASH.................................................................... 19
5.1 Asynchronous Mode.............................................................................................. 19
5.2 Synchronous Mode ............................................................................................... 21
6 CONNECTORS.............................................................................................................. 22
6.1 Power connector (X12).......................................................................................... 22
6.2 Edge connector (X1, X2) ....................................................................................... 22
6.3 UART”A”, UART”B” connector (X3, X5)................................................................. 22
6.4 LIN”A”, LIN”B” Interface connector (X6, X8) .......................................................... 23
6.5 CAN”A”, CAN”B” Interface connector (X10, X11)................................................... 23
6.6 USER-LEDs & LC-Display (optional)..................................................................... 23
6.7 VG96 connector (X4)............................................................................................. 24
7 SILK-PLOT OF THE BOARD ........................................................................................ 26
8 RELATED PRODUCTS ................................................................................................. 27
9 INFORMATION IN THE WWW....................................................................................... 28
FLASH-CAN-64P-350-PMC
Chapter 2 Overview
© Fujitsu Microelectronics Europe GmbH - 5 - UG-960008-10
2 Overview
2.1 Abstract
The FLASH-CAN-64P-350-PMC is a multifunctional evaluation board for the Fujitsu 16-Bit Flash microcontroller MB90350 and MB96350 Series.
It can be used stand alone for software development and testing or as a simple target board to work with the emulator system.
The board allows the designer immediately to start with the software development before his own final target system is available.
2.2 Features
< Supports FPT-64P-M09 / M23 package
< MB90350 Series: MB90V350, MB90F35x
< MB96350 Series: MB96V300, MB96F35x
< 9-12 V unregulated external DC power supply usable
< 3.3 V and 5 V internal power supply, Power-LED
< In-Circuit serial Flash programming
< All resources available for evaluation
< All 64 pins routed to connectors
< 4 MHz main-crystal, 32 kHz subclock-crystal (selectable by jumpers)
< Two UART Interfaces
< Two LIN-Transceivers
< Two High-Speed CAN Transceiver
< 8 User LEDs, optional: alphanumeric standard LC-Display connectable instead of LEDs
< Reset-Button, Reset-LED
< 5 User-buttons configurable for INT10, INT11, TIN1, IN0 and IN1
< 96 pin VG connector
This board must only be used for test applications
in an evaluation laboratory environment.
FLASH-CAN-64P-350-PMC
Chapter 2 Overview
UG-960008-10 - 6 - © Fujitsu Microelectronics Europe GmbH
2.3 General Description
The FLASH-CAN-64P-350-PMC supports 16-Bit Flash microcontrollers of the MB90350 Series and MB96350 Series.
It can be used as a stand alone evaluation board or as a target board for emulator debugger.
The evaluation board supports the following package: FPT-64P-M09 / M23
The board is supplied with a socketed 4 MHz crystal as the main oscillation clock. Using the internal PLL of the IC, internal clock rates up to 56 MHz can be achieved.
Additionally a 32 kHz crystal is mounted for use as a subclock, if this is supported by the device type.
Two separate RS232 transceivers are available to connect the on-chip UART2 and UART3 to 9-pin D-Sub connectors (X3, X5). The transceivers generate the adequate RS232 levels for the receive (RXD) and transmit (TXD) lines. Either the DTR line or the CTS line can be selected with jumpers (JP3, JP4, JP5) to generate a system reset. The RTS signal can be shortcut to CTS using the jumpers JP31 and JP32.
In-circuit-programming (asynchronous) can be done via UART3 (UART”B”, X5) using the Burn-In Bootloader of the microcontroller.
Two single-wire LIN-transceivers (TLE6259) are available to connect the on-chip UART2 and UART3 to 9-pin D-Sub connectors (X6, X8). The transceivers generate the adequate levels to drive the bus line in LIN-systems for automotive and industrial applications.
Two high-speed CAN-transceiver (PCA82C250) are available to connect the on-chip CAN­controller to 9-pin D-Sub connectors (X10, X11). The transceivers provides differential transmit and receive capability between CAN-controller and CAN-bus.
If the board is used as an emulator target board, the microcontroller must be removed from the socket and the corresponding probe cable has to be used:
Probe Cable:
MB90350 Series MB2147-540
MB96350 Series MB2198-504
Header Socket: NQPACK64SB + HQPACK64SB140
All pins of the microcontroller are connected to the edge connectors X1 and X2 and are directly available to the user. Furthermore, the most important signals are available on the VG96 connector (X4).
The on-board voltage regulator allows the user to connect an unregulated DC input voltage between +9 V to +12 V. In case of any modifications of the board, care should be taken that the total power consumption will not damage the regulator.
There are six push button switches on the board, used for Reset, External Interrupts INT10 and INT11, Trigger for Reload-Timer1 (TIN1), Input-Capture IN0 and IN1.
Eight user-LEDs are connected via a 1K pull up resistor network to Port P30-P37. If these LEDs are not required, than the resistor network can be removed to disconnect the LEDs and to free the port.
Further, take care that the Portpins P00 and P01 are pulled down by N3 (10K). That is important for in-circuit serial programming!
The operating mode of the microcontroller can be selected by the Dip-switch S2.
FLASH-CAN-64P-350-PMC
Chapter 3 Installation
© Fujitsu Microelectronics Europe GmbH - 7 - UG-960008-10
3 Installation
Remove carefully the board from the shipping carton.
Check first if there are any damages before power on the evaluation board.
For the power supply a DC input voltage of 9 V – 12 V is recommended. The positive voltage (+) must be connected to the centre, and ground (GND) must be connected to the shield of the connector X12!
After power-on, the green power-on LED (D16) should be on. If the LED does not light switch off the power supply and check the default jumper settings.
By default, the evaluation board is equipped with a MB96F356 and the device has been programmed with a test program. So after power-on a running light for the eight user LEDs can be seen. Furthermore, a welcome string is output with 9600 baud on both UART channels (UART”A” / UART”B”). Please use 1:1 cable for the PC-connection.
The in-circuit programming allows the user to program it’s own application into the Flash­memory. How to program the Flash memory is described in chapter 4.
If the board is used as an emulator target board, switch off the power supply and remove the microcontroller from the socket. Now the probe cable can be mounted into the socket. Take care of pin 1 marking onto the socket and fix the probe cable with screws.
Do not use other probe cable than MB2198-504 or MB2147-540 only!
Connect the probe cable to the emulation pod. Check all DIP-switch-settings of the evaluation board and the emulation pod.
For the power on sequence the emulator system must be switched on first, after that, switch on the evaluation board. Please look at the corresponding user manuals for the emulator how to set up the emulator system. After the power on the ‘Reset’-LED of the emulator must be off and the ‘Vcc’-LED must be on.
If the Reset LED is still lighting, check the DIP-switch-settings of the emulator system and the power supply of the evaluation board.
Note:
Some customers experience connectivity problems when connecting the MCU into the socket adapter. Only the small red screwdriver available in your box should be used to connect the cover (HQPACK) onto the socket (NQPACK).
If the four screws are not tightening equally, then it may cause a poor contact.
Do not screw the cover too tight (max 0.054 Nm). If you have connectivity problems then please loosen the screws and tighten again the screws equally.
Do not clean NQPACK, YQPACK, and YQSOCKET with steam. Cleaning material will contaminate inside of connector.
FLASH-CAN-64P-350-PMC
Chapter 4 Jumpers and Switches
UG-960008-10 - 8 - © Fujitsu Microelectronics Europe GmbH
4 Jumpers and Switches
This chapter describes all jumpers and switches which can be modified on the evaluation board. The default setting is shown with a grey shaded area. All jumpers and switches are named directly on the board, so it is very easy to set the jumpers according to the features.
4.1 Jumper Overview
Jumper
Description / Function
Type
Default
Coordinates
JP1 UART A (TXD) / LIN A (TXD) Jumper 3 pol
1-2
H15
JP2 UART A (RXD) / LIN A (RXD) Jumper 3 pol
1-2
H15
JP3 DTR/RTS A Jumper 3 pol
open
D5
JP4 RESET UART A/B Jumper 3 pol
open
E11
JP5 DTR/RTS B Jumper 3 pol
open
D9
JP6 UART B (RXD) Jumper 2 pol
closed
F13
JP7 Reset Direct / Delay solder-Jumper
1-2
C12
JP8 UART B (TXD) Jumper 2 pol
closed
F12
JP9 LIN B enable Jumper 2 pol
open
H14
JP10 Master-Mode B Jumper 2 pol
open
E5
JP11 AVcc Jumper 2 pol
closed
E24
JP12 SW INT10 Jumper 2 pol
closed
G11
JP13 AVcc=AVRH Jumper 2 pol
closed
E24
JP14 SW INT11 Jumper 2 pol
closed
G11
JP15 AVss Jumper 2 pol
closed
F24
JP16 SW TIN1 Jumper 2 pol
closed
F11
JP17 LIN A enable Jumper 2 pol
open
H15
JP18 Master-Mode A Jumper 2 pol
open
H4
JP20 SW IN0 Jumper 2 pol
closed
F11
JP23 SW IN1 Jumper 2 pol
closed
F11
JP24 RESET Jumper 2 pol
closed
C15
JP25 CAN A (TXD) Jumper 2 pol
closed
J15
JP26 CAN A (RXD) Jumper 2 pol
closed
J15
JP27 CAN B (TX) / LED D4 Jumper 3 pol
1-2
K15
JP28 CAN B (RX) / LED D3 Jumper 3 pol
1-2
K15
JP29 int/ext VCC Jumper 3 pol
1-2
J19
JP30 5V/3V3 Jumper 3 pol
1-2
J19
JP31 RTS-CTS A Jumper 2 pol
closed
D5
JP32 RTS-CTS B Jumper 2 pol
closed
D9
JP33 C-Pin to MCU VCC sold-Jumper
open
F21
JP34 MCU_VCC Jumper 2pol
closed
J19
JP35 Reset inverter Jumper 3 pol
open
D12
JP36 X0A select Jumper 3 pol
1-4
J23
JP37 X1A select Jumper 3 pol
1-2
J22
JP38 LIN B (RXD) Jumper 2 pol
open
F13
JP39 LIN B (TXD) Jumper 2 pol
open
F13
JP40 C-Pin Jumper 2 pol
closed
E21
JP45 LIN VBAT B Jumper 2 pol
open
D5
JP46 LIN VBAT A Jumper 2 pol
open
G5
JP47 Power Jumper 2 pol
closed
L14
JP48 CAN transceiver A VCC 3V3 / 5V solder-Jumper
1-2
J12
JP49 CAN transceiver B VCC 3V3 / 5V solder-Jumper
1-2
J13
JP52 LIN TLE6259 (2-3) / TLE7259 (1-2) solder-Jumper
1-2
J13
JP53 LIN TLE6259 (2-3) / TLE7259 (1-2) solder-Jumper
1-2
G13
FLASH-CAN-64P-350-PMC
Chapter 4 Jumpers and Switches
© Fujitsu Microelectronics Europe GmbH - 9 - UG-960008-10
A B C D E F G H J K L M N
1
1
2
2
3
3
4
4
5
5
6
6
7
7
8
8
9
9
10
10
11
11
12
12
13
13
14
14
15
15
16
16
17
17
18
18
19
19
20
20
21
21
22
22
23
23
24
24
25
25
26
26
27
27
28
28
29
29
30
30
A B C D E F G H J K L M N
UART A
CAN A
LIN A
LIN B
UART B
CAN B
FLASH-CAN-64P-350-PMC
Chapter 4 Jumpers and Switches
UG-960008-10 - 10 - © Fujitsu Microelectronics Europe GmbH
4.2 Operating-Mode (S2)
The DIP-switch S2 is used to set the operating mode of the IC.
Ensure that the mode pin settings correspond to the operation-mode of the application.
For more detailed information please check the Hardware-Manual of the microcontroller.
DIP switch Setting Logical value
ON (closed) 0 (low)
S2/1 (MD0)
OFF (open) 1 (high)
ON (closed) 0 (low)
S2/2 (MD1)
OFF (open) 1 (high)
ON (closed) 0 (low)
S2/3 (MD2)
OFF (open) 1 (high)
S2/4 not connected (OFF)
S2/5 not connected (OFF)
S2/6 not connected (OFF)
ON (closed) 1 (high)
S2/7 (P01)
OFF (open) 0 (low)
ON (closed) 1 (high)
S2/8 (P00)
OFF (open) 0 (low)
Default: MD0, 1, 2 = 1 1 0 P00, P01 = 0 0
By default, the Single Chip Run-Mode is selected.
Dip-Switch S2
(default setting)
ON
OFF
1 2 3 4 5 6 7 8
MD0 MD1 MD2 nc nc nc P01 P00
FLASH-CAN-64P-350-PMC
Chapter 4 Jumpers and Switches
© Fujitsu Microelectronics Europe GmbH - 11 - UG-960008-10
4.3 Power Supply Voltage (JP: 29, 34)
Vcc and GND (Vss) are both connected to the edge-connector (X4) in order to supply additional circuitry. However, if the current requirements exceed the maximum ratings of the on board voltage regulator LM317T, the board also can be powered externally via the edge­connector. In that case, take care of the input-voltage. Neither a voltage regulation nor an over-voltage-protection does exist for an external power-supply.
JP29 Power Supply selection In case that the board is powered via the VG-connector (X4),
a regulated 5 V power source has to be used.
JP34 This Jumper is used to connect the Vcc supply voltage to the IC.
Connecting an Ampere-meter allows measuring of the power-supply-current of the microcontroller (Icc).
Jumper Setting Description
1 - 2 On-board voltage regulation
JP29 (Vcc)
2 - 3 External power-supply from X4 pin 1
ON (closed) Power supply Vcc connected to IC
JP34 (MCUVcc)
OFF (open) Disconnected from Power supply Vcc
Default: JP29 = 1-2, JP34 = closed,
By default, the on-board Voltage regulation is used and the microcontroller is powered.
FLASH-CAN-64P-350-PMC
Chapter 4 Jumpers and Switches
UG-960008-10 - 12 - © Fujitsu Microelectronics Europe GmbH
4.4 Analogue Power Supply Voltage (JP: 11, 13, 15)
The power supply as well as the positive reference voltage for the A/D-converter can be provided internally or externally.
JP11, JP15 connect power supply voltages (AVcc and AVss)
JP13 connect reference voltages (AVRH to AVcc)
Jumper Setting Description
ON (closed) AVcc is connected to Vcc
JP11 (AVcc)
OFF (open) AVcc is disconnected from Vcc
ON (closed) AVRH is connected to AVcc
JP13 (AVRH)
OFF (open) AVRH defined by resistor network
*1
ON (closed) AVss is connected to GND
JP15 (AVss)
OFF (open) AVss is disconnected from GND
*1
By default the resistor network (R11 and R23) is not mounted on the board
Default: JP11, JP13 and JP15 are closed
By default, the A/D-converter supply and reverence voltage is +5 V.
Note:
If JP11 and J15 are open, the user has to supply an adequate analogue voltage supply (AVcc and AVss) to the A/D-converter.
If JP13 is open, the resistors R11 and R23 define AVRH.
By default the resistor network (R11 and R23) is not mounted on the board.
FLASH-CAN-64P-350-PMC
Chapter 4 Jumpers and Switches
© Fujitsu Microelectronics Europe GmbH - 13 - UG-960008-10
4.5 Subclock (JP: 36, 37)
Some devices like e.g. MB90F352 support a 32 kHz subclock (X0A, X1A), other devices like MB90FxxxS do not support a subclock but will offer additional port-pins (P40, P41) instead.
Please check the related datasheet.
JP36: defines usage of Pin 19 (X0A/P40)
JP37: defines usage of Pin 20 (X1A/P41)
Jumper Setting Description
1-4 Pin 19 is connected to the 32kHz Subclock (X0A)
2-4
Pin 19 is used as P40 and is connected to X1-19 and X4-A16
JP36 (X0A/P40)
3-4
Pin 19 is connected to GND (in case that subclock­device is used, but no 32kHz crystal is connected)
1-2 Pin 20 is connected to the 32kHz Subclock (X1A)
JP37 (X1A/P41)
2-3 Pin 20 is used as P41
and is connected to X1-20 and X4-A17
Default: JP36: 1-4, JP37: 1-2
By default, the 32 kHz subclock-crystal is connected to the microcontroller.
2
4 31
Pin-out JP36:
FLASH-CAN-64P-350-PMC
Chapter 4 Jumpers and Switches
UG-960008-10 - 14 - © Fujitsu Microelectronics Europe GmbH
4.6 UART”A” (JP: 1, 2, 31)
One RS232-transceiver can be connected to UART2.
JP1, JP2 connects UART2 to the RS232-transceiver (U1, X3)
or to the LIN-transceiver (U5, X8)
JP31 Some Flash-programming-Tools needs a connection between CTS and RTS
Jumper Setting Description
1-2 SOT2 is connected to RS232-transceiver
JP1 (UART”A”TxD)
2-3 SOT2 is connected to LIN-transceiver A
1-2 SIN2 is connected to RS232-transceiver
JP2 (UART”A”RxD)
2-3 SIN2 is connected to LIN-transceiver A
ON (closed) RTS and CTS is shortcut on X3
JP31 (RTS-CTS)
OFF (open) RTS and CTS is not shortcut on X3
Default: JP1=1-2, JP2=1-2, JP31 = closed
By default, UART2 is used as UART”A”.
4.7 UART”B” (JP: 6, 8, 32)
One RS232-transceiver can be connected to UART3.
JP6, JP8 connects UART3 to the RS232-transceiver (U3, X5)
JP32 Some Flash-programming-Tools needs a connection between CTS and RTS
Jumper Setting Description
ON (closed) SIN3 is connected to RS232-Transceiver
JP6 (UART”B”RxD)
OFF (open) SIN3 is disconnected from RS232-Transceiver
ON (closed) SOT3 is connected to RS232-Transceiver
JP8 (UART”B”TxD)
OFF (open) SOT3 is disconnected from RS232-Transceiver
ON (closed) RTS and CTS is shortcut on X5
JP31 (RTS-CTS)
OFF (open) RTS and CTS is not shortcut on X5
Default: JP6=closed, JP8=closed, JP32 = closed
By default, UART3 is used as UART”B”.
FLASH-CAN-64P-350-PMC
Chapter 4 Jumpers and Switches
© Fujitsu Microelectronics Europe GmbH - 15 - UG-960008-10
4.8 LIN”A” (JP: 17, 18)
One LIN-transceiver can be used with UART2. (Also refer to section 4.6)
JP17 enable LIN-Transceiver A
JP18 LIN Master-mode
Jumper Setting Description
open LIN-transceiver is disabled
JP17 (LIN enable)
closed LIN-transceiver is enabled
open LIN Slave-mode
JP18 (LIN Master)
closed LIN Master-mode
Default: JP17=open, JP18=open
By default, UART2 is not used as LIN-interface.
4.9 LIN”B” (JP: 9, 10, 38, 39)
One LIN-transceiver can be used with UART8.
JP9 enable LIN-Transceiver B
JP10 LIN Master-mode
JP38, JP39 connects UART8 to the LIN-transceiver (U4, X6)
Jumper Setting Description
open LIN-transceiver is disabled
JP9 (LIN enable)
closed LIN-transceiver is enabled
open LIN Slave-mode
JP10 (LIN Master)
closed LIN Master-mode
open SIN8 is disconnected from LIN-Transceiver
JP38 (LIN”B”RXD)
closed SIN8 is connected to LIN-Transceiver
open SOT8 is disconnected from LIN-Transceiver
JP39 (LIN”B”TXD)
closed SOT8 is connected to LIN-Transceiver
Default: JP9=open, JP10=open, JP38=open, JP39=open
By default, UART8 is not used as LIN-interface.
FLASH-CAN-64P-350-PMC
Chapter 4 Jumpers and Switches
UG-960008-10 - 16 - © Fujitsu Microelectronics Europe GmbH
4.10 CAN“A” (JP: 25, 26)
One high-speed CAN-transceiver can be connected to CAN1.
JP25, JP26 connects the CAN1-Port to the CAN-transceiver (U7, X10). If the CAN interface is not used, the jumpers should be left open.
Jumper Setting Description
Open TX1 is disconnected from CAN-Transceiver (U7, X10)
JP25 (TX1)
Closed TX1 is connected to CAN-Transceiver (U7, X10)
Open RX1 is disconnected from CAN-Transceiver (U7, X10)
JP26 (RX1)
Closed RX1 is connected to CAN-Transceiver (U7, X10)
Default: JP25=closed, JP26=closed
By default, the CAN”A”-transceiver is connected to CAN1 of the microcontroller
4.11 CAN“B” (JP: 27, 28)
For the MB96350 Series one high-speed CAN-transceiver can be connected to CAN2.
JP27, JP28 connects the CAN2-Port to the CAN-transceiver (U8, X11). Using CAN2 will disconnect LED D3 and D4.
Jumper Setting Description
1-2 Pin 57 (P33) is connected to LED D4
JP27 (TX2)
2-3 TX2 is connected to CAN-Transceiver (U8, X11)
1-2 Pin 56 (P32) is connected to LED D3
JP28 (RX2)
2-3 RX2 is connected to CAN-Transceiver (U8, X11)
Default: JP27=1-2, JP28=1-2
By default, LED D3 and D4 are connected to Port P32 and P33 of the microcontroller.
FLASH-CAN-64P-350-PMC
Chapter 4 Jumpers and Switches
© Fujitsu Microelectronics Europe GmbH - 17 - UG-960008-10
4.12 Reset-Generation (JP: 3, 4, 5, 24, 35)
Additional to the internal Power-On-Reset the microcontroller can be reset by an external Reset-circuit (Voltage-Monitor) and by the UARTs, too.
JP3, JP5 As well the DTR-line as the RTS-Line of UART”A” or UART”B” can be used to generate a system-reset.
JP4 This jumper selects whether the DTR/RTS line from UART”A” or UART”B” will generate a system-reset.
JP24 open this jumper if no external Reset shall be generated. In this case only the internal reset is active (e.g.: power-on)
JP35 The polarity of the DTR/RTS line can be invert by this jumper. Remove the jumper in order to disable the reset logic.
Jumper Setting Description
1-2 DTR of UART”A” is selected
JP3 (DTR / RTS “A”)
2-3 RTS of UART”A” is selected
1-2 UART”A” is used to generate Reset
JP4 (UART”A”/”B”)
2-3 UART”B” is used to generate Reset
1-2 DTR of UART”B” is selected
JP5 (DTR / RTS “B”)
2-3 RTS of UART”B” is selected
closed external Reset generation is active
JP24 (Main Reset)
open no external Reset generation
1-2 No polarity inversion for the DTR/RTS signal
JP35 (Polarity)
2-3 Polarity inversion for the DTR/RTS signal
Default: JP24=closed, JP4, JP5 and JP35 are not set
By default, the external Reset generation is active. The Reset by UART is disabled.
Note:
While a reset signal is asserted the red Reset-LED D14 is lit.
During normal operation, this LED should be off!
If JP35 (Polarity) is set, than JP4 and JP5 have to be set, too.
If the reset LED is steadily on, check the power supply input voltage and the settings for the reset-generation by UART.
FLASH-CAN-64P-350-PMC
Chapter 4 Jumpers and Switches
UG-960008-10 - 18 - © Fujitsu Microelectronics Europe GmbH
4.13 Buttons INT10, INT11, TIN1, IN0, IN1, Reset (JP: 7, 12, 14, 16, 20, 23)
JP7: One Button can be used for manually reset
JP12, JP14: Two push buttons can be used to trigger the ext. interrupts INT10 and INT11
JP16: One button can be used as trigger-input for the Reload-Timer1 (TIN1)
JP20, JP23: Two push buttons can be used for input at Input-Capture 0 / 1 (IN0, IN1)
Jumper Setting Description
1-2 Reset is triggered immediately
2-3 Reset is triggered delayed
JP7 (Reset)
Open no connection
Closed INT10 is connected to Push-button “INT10”
JP12 (INT10)
Open no connection to INT10
Closed INT11 is connected to Push-button “INT11”
JP14 (INT11)
Open no connection to INT11
Closed TIN1 is connected to Push-button “TIN1”
JP16 (TIN1)
Open no connection to TIN1
Closed IN0 is connected to Push-button “IN0”
JP20 (IN0)
Open no connection to IN0
Closed IN1 is connected to Push-button “IN1”
JP23 (IN1)
Open no connection to IN1
Default: JP7, JP12, JP14, JP16, JP20, JP23 =closed
By default, INT10, INT11, TIN1, IN0, IN1 and RSTX of the microcontroller are connected to the Push buttons.
FLASH-CAN-64P-350-PMC
Chapter 5 Programming the internal Flash
© Fujitsu Microelectronics Europe GmbH - 19 - UG-960008-10
5 Programming the internal Flash
All Flash devices have an internal bootloader for asynchronous- as well as synchronous­Flash-programming:
< asynchronous-serial Flash-programming via UART”B”/UART3 (X5)
< synchronous-serial Flash-programming via Serial I/O (SCI3, X17)
5.1 Asynchronous Mode
In order to program the Flash-ROM asynchronously via UART3, the tool “Fujitsu Flash MCU Programmer for FMC16LX” can be used to flash MB90350 series devices or the tool “Fujitsu Flash MCU Programmer for FMC16FX” for MB96350 series devices. These tools are available free on the Fujitsu Micros DVD or Web Site (http://mcu.emea.fujitsu.com/
: select <
Development Tools < Software and Utilities)
The following procedure must be followed to enable Flash Programming:
1. Power off the board
2. Connect the Evaluation Board UART”B” to your serial PC communication port.
A straight cable connection has to be used.
3. Check the Jumper-settings according to the UART as described in chapter 4.6
4. Configure the mode:
5. Power on the board
6. Check that the Reset LED is off. Otherwise change the DTR polarity (JP35) and check
the power supply voltage.
16LX Series
Flash Mode Async. 4MHz
ON
OFF
1 2 3 4 5 6 7 8
MD0 MD1 MD2 nc nc nc P01 P00
16FX Series
Flash Mode Async. 4MHz
ON
OFF
1 2 3 4 5 6 7 8
MD0 MD1 MD2 nc nc nc P01 P00
FLASH-CAN-64P-350-PMC
Chapter 5 Programming the internal Flash
UG-960008-10 - 20 - © Fujitsu Microelectronics Europe GmbH
7. Start the tool “Fujitsu Flash MCU Programmer for FMC16LX” for MB90350 Series or
“Fujitsu Flash MCU Programmer for FMC16FX” for MB96F350 Series software and follow the instructions:
8. After programming the Flash-ROM, switch off the power supply and set back the mode
according to the usage of the application, e.g.:
9. Power on the board. The user application is started directly.
Single-Chip Run Mode
ON
OFF
1 2 3 4 5 6 7 8
MD0 MD1 MD2 nc nc nc P01 P00
UART “B”
RESET
Run Mode:
Flash Mode MB96F350
Flash Mode MB90F350
Set Device Type Select COM Port
Start download
Open Source
(MHX-File)
Select Crystal
MB96F356
FlashCan64P350.mhx
FLASH-CAN-64P-350-PMC
Chapter 5 Programming the internal Flash
© Fujitsu Microelectronics Europe GmbH - 21 - UG-960008-10
5.2 Synchronous Mode
In order to program the Flash-ROM synchronously via Serial I/O (SCI3) special software has to be used, e.g. Galep-4 from Conitec with a serial adapter. This tool is not
available free.
Please contact the following Web Site in order to get more information: http://www.conitec.de
A dedicated Flash programming socket (X17) is provided on the evaluation-board for direct connection to the serial adapter of GalepIV.
X17: Flash programming socket
In case that the Galep-4 with serial adapter is used, all Mode-settings will be done automatically by the Galep-4. This means that all DIP-switch S2 has to be set to the “OFF” position.
Please refer to the manual of Conitec’s Galep-4 for more information how to program a Flash-device by the synchronous-serial mode.
Note
:
In case that another Programming-Tool is used and the Mode-settings have to be done manually then use the following configuration of DIP-switch S2 in order to select the synchronous-serial Flash-programming mode:
P00 1
MD0 3
RST 5
SOT3 7
VCC 9
2 P01
4 MD2
6 SIN3
8 SCK3
10 GND
When using Conitec’s Galep-4
ON
OFF
1 2 3 4 5 6 7 8
MD0 MD1 MD2 nc nc nc P01 P00
synchronous Boot-Mode
ON
OFF
1 2 3 4 5 6 7 8
MD0 MD1 MD2 nc nc nc P01 P00
FLASH-CAN-64P-350-PMC
Chapter 6 Connectors
UG-960008-10 - 22 - © Fujitsu Microelectronics Europe GmbH
6 Connectors
6.1 Power connector (X12)
The following figure shows the power connection jack X12. This connector is used to connect an external unregulated DC power supply voltage (9 V - 12 V DC) to the evaluation board.
Connector X12:
It is recommended to use 9 V to keep the power dissipation to a minimum. Otherwise, an additional heat sink for the linear voltage regulator might be necessary.
6.2 Edge connector (X1, X2)
All pins of the microcontroller are directly connected to X1 and X2 as follows:
Connector MCU Pins
X1 (1 – 32) 1 – 32
X2 (33 – 64) 33 – 64
The odd pin numbers are located on the one side and the even pin numbers are located on the other side of the connector.
On the PCB, the corresponding pin numbers of the IC are written next to the connector pins.
6.3 UART”A”, UART”B” connector (X3, X5)
Two 9-pin D-Sub female connectors are used for the serial interface UART”A” and UART”B”.
TXD is the transmit output, RXD is the receive input.
The DTR or RTS signal can be used to generate a reset.
Please use 1:1 cable for PC-connection.
Connectors X3, X5:
Shield is connected to ground (GND)
Centre is connected to positive voltage (+)
GND DTR RxD TxD
CTS RTS DSR
1
6
5
9
FLASH-CAN-64P-350-PMC
Chapter 6 Connectors
© Fujitsu Microelectronics Europe GmbH - 23 - UG-960008-10
6.4 LIN”A”, LIN”B” Interface connector (X6, X8)
Two 9-pin D-Sub female connectors are used for the LIN-communication.
Connectors X6, X8:
6.5 CAN”A”, CAN”B” Interface connector (X10, X11)
One 9-pin D-Sub male connector is used for the CAN interface.
Connector X10, X11:
6.6 USER-LEDs & LC-Display (optional)
Eight LEDs are reserved for user-application. In order to disconnect the LEDs from the related microcontroller port, the resistor network N1 can be removed.
Instead of the user-LEDs one alphanumeric LC-Display (optional) can be connected.
The following control-signals are reserved:
14 13 12 11 10 9 8 7 6 5 4 3 2 1
LCD
D6 D5 D4 D3 - - - - E R/W RS V0 VCC GND
LED
D8 D7 D6 D5 D4 D3 D2 D1
MCU
61 60 59 58 57 56 55 54
Port
P37 P36 P35 P34 P33 P32 P31 P30
B
US +Ubat
GND
1
6
5
9
GND CANL
CANH
1
6
5
9
FLASH-CAN-64P-350-PMC
Chapter 6 Connectors
UG-960008-10 - 24 - © Fujitsu Microelectronics Europe GmbH
6.7 VG96 connector (X4)
Connector-Pin cross reference table for MB90350 Series:
MB90350
Description
VG (X4)
MB90350
Description
VG (X4)
1
AVss
-33P11/AD09/TOT1
A29
2
A
VRH
-
34P
12/AD10/SIN3
B293
P62/AN2/PPG4(5)
B1335P13/AD11/SOT3
C294P63/AN3/PPG6(7)
C1336P14/AD12/SCK3
A305P64/AN4/PPG8(9)
A1437P15/AD13
B306P65/AN5/PPGA(B)
B1438P16/AD14
C307P66/AN6/PPGC(D)
C1439P17/AD15
A318P67/AN7/PPGE(F)
A1540P20/A16/PPG9(8)
B319P50/AN8/SIN2
A1041P2
1/A17/PPGB(A)
C3110P51/AN9/SOT2
B1042P22/A18/PPGD(C)
A32
11
P52/AN10/SCK2
C1043P23/A19/PPGF(E)
B3212P53/AN11/TIN3
A1144P24/A20/IN0
A413P54/AN12/TOT3
B1145RSTX
A1914P55/AN13
C1146X1-15
P56/AN14
A1247X0-16
P42/IN6/RX1
/INT9RA848Vss
ABC3
17
P43/IN7/TX1
B849Vcc
ABC2
18
Vss
ABC3
50C-19P40/X0A
(A16)
51
P25/A21/IN1
/ADTG
B420P41/X1A
(A17)
52
P44/SDA0/FRCK0
C821MD2
A1853P45/SCL0/FRCK1
A922MD1
B1854P30/ALE/IN4
B523MD0
C1855P31/RDX/IN5
C524P0
0/AD00/INT8
A2656P32/WRX/
INT10R
A625P01/AD01/INT9
B2657P33/WRHX
B626P02/AD02/INT10
C2658P34/HRQ/OUT4
C627P03/AD03/INT11
A2759P35/HAKX/OUT5
A728P04/AD04/INT12
B2760P36/RDY/OUT6
B729P05/AD05/INT13
C2761P37/CLK/OUT7
C730P06
/AD06/INT14
A2862P60/AN0
C1231P07/AD07/INT15
B2863P61/AN1
A1332P10/AD08/TIN1
C2864AVcc
-
-
extVCC
ABC1
FLASH-CAN-64P-350-PMC
Chapter 6 Connectors
© Fujitsu Microelectronics Europe GmbH - 25 - UG-960008-10
Connector-Pin cross reference table for MB96350 Series:
M
B90Description
V
G (X4)
M
B90Description
V
G (X4)
1
AVss
-33P11/AD09/
CKOTX1/
TOT1
A29
2
AVRH
-34P12/AD10/
INT11/
SIN3
B293P62/AN2/PPG2/CS2R
B1335P13/AD11/SOT3
C294P63/AN3/PPG3/CS3R
C1336P14/AD12/SCK3
A305P64/AN4/PPG4/CS4R
A1437P15/AD13
/SIN2R/INT7R
B306P65/AN5/PPG5/CS5R
B1438P16/AD14
/SO
T2R
C307P66/AN6/PPG6
C1439P17/AD15
/SCK2R
A318P67/AN7/PPG7
A1540P20/A16/PPG
12/CKOT1R
B319P50/AN8/SIN2/INT3R
A1041P21/A17/PPG
13
C3110P51/AN9/SOT2
B1042P22/A18/PPG
14/CKOT0R
A3211P52/AN10/SCK2
C1043P23/A19/PPG
15
B3212P53/AN11/T
IN3/WOT
A1144P24/A20/IN0
A413P54/AN12/TOT3/INT2R
B1145RSTX
A1914P55/AN13/INT0R/NMIR
C1146X1-15
P56/AN14/INT4R
A1247X0-16
P42/IN6/RX1/INT9R
A848Vss
ABC3
17
P43/IN7/TX1/TTG7
B849Vcc
ABC2
18
Vss
ABC3
50C-19P40/X0A
(A16)
51
P25/A21/IN1/ADTG
RB420
P41/X1A
(A17)
52
P44/SDA0/FRCK0
/TIN0R
C821MD2
A1853P45/SCL0/FRCK1
/TIN2R
A922MD1
B1854P30/ALE/IN4
/TOT0R
B523MD0
C1855P31/RDX/IN5
/TOT2R
C524P00/AD00/INT8/SCK7R
A2656P32/WRX/
RX2/INT1
0RA625
P01/AD01/INT9/
SOT7R
B2657P33/
TX2/
WRHX
B626P02/AD02/INT10/SIN7R
C2658P34/HRQ/OUT4
C627P03/AD03/INT11/SCK8R
A2759P35/HAKX/OUT5
A728P04/AD04/INT12/SOT8R
B2760P36/RDY/OUT6
B729P05/AD05/INT13/SIN8R
C2761P37/CLK/OUT7
C730P06/AD06/INT14/PPG10R
A2862P60/AN0
/PPG0/CS0R
C1231P07/AD07/INT15
/PPG11R
B2863P61/AN1
/PPG1/CS1R
A1332P10/AD08
/CKOT1
/TIN1
C2864AVcc
-
-
extVCC
ABC1
FLASH-CAN-64P-350-PMC
Chapter 7 Silk-Plot of the Board
UG-960008-10 - 26 - © Fujitsu Microelectronics Europe GmbH
7 Silk-Plot of the Board
Power-
Jack
UART”A”
X3
MAX232
MCU
90F352
4MHz
VG96-male
User-LEDs (P30-P37)
Pin 32
Pin 31
Pin 63
Pin 64
Pin 34
Pin 33
LIN”A”
X8
CAN”A”
X10
MAX232
optional: LCD
INT10 INT 11
TIN1
IN0
IN1
Reset
X4X1X2
X12
FlashKit
X17
LIN”B”
X6
UART”B”
X5
Pin 1
Pin 2
CAN”B”
X11
FLASH-CAN-64P-350-PMC Chapter 8 Related Products
© Fujitsu Microelectronics Europe GmbH - 27 - UG-960008-10
8 Related Products
< FLASH-CAN-64P-350-PMC Evaluation board for MB90350 and MB96350 Series with
FPT-64P-M09 or FPT-64P-M23 package
< FLASH-CAN-64P-350-PMC1 Evaluation board for MB90350 and MB96350 Series with
FPT-64P-M24 package
< NQPack64sb Socket for package FPT-64P-M09/M23
(Tokyo Eletech Corp. www.tetc.co.jp/e_tet.htm
)
< HQPack64sb140 Header for NQPack64sb
16LX Series (MB90350)
< MB2147-01 Emulator debugger main unit
< MB2147-20 Emulation adapter
< MB2147-540 Emulator probe cable for package (FPT-64P-M09 / M23)
< MB90V340xxx Evaluation chip for MB90340 / 350 / 360 Series
< MB90V340A-101 Single-clock version
< MB90V340A-102 Dual-clock version
< MB90F352(C) Flash-Microcontroller with Subclock
< MB90F352(C)S Flash-Microcontroller without Subclock
16FX Series (MB96350)
< MB2198-01 Emulator debugger main unit
< MB2198-500 Emulation adapter
< MB2198-504 Emulator probe cable for package (FPT-64P-M09 / M23)
< MB96V300 Evaluation chip for MB96300 Series
< MB96F356RWAPMC Flash-Microcontroller with Subclock
< MB96F356RSAPMC Flash-Microcontroller without Subclock
FLASH-CAN-64P-350-PMC
Chapter 9 Information in the WWW
UG-960008-10 - 28 - © Fujitsu Microelectronics Europe GmbH
9 Information in the WWW
Information about FUJITSU MICROELECTRONICS Products can be found on the following Internet pages:
Microcontrollers (8-, 16- and 32bit), Graphics Controllers Datasheets and Hardware Manuals, Support Tools (Hard- and Software)
http://mcu.emea.fujitsu.com
Linear Products: Power Management, A/D and D/A Converters
http://www.fujitsu.com/emea/services/microelectronics/linears/
Media Products: SAW filters, acoustic resonators and VCOs
http://www.fujitsu.com/emea/services/microelectronics/saw/
For more information about FUJITSU MICROELECTRONICS
http://www.fujitsu.com/emea/services/microelectronics/
FLASH-CAN-64P-350-PMC
Chapter 9 Information in the WWW
© Fujitsu Microelectronics Europe GmbH - 29 - UG-960008-10
Recycling
Gültig für EU-Länder:
Gemäß der Europäischen WEEE-Richtlinie und deren Umsetzung in landesspezifische Gesetze nehmen wir dieses Gerät wieder zurück.
Zur Entsorgung schicken Sie das Gerät bitte an die folgende Adresse:
Fujitsu Microelectronics Europe GmbH
Warehouse/Disposal
Monzastraße 4a
63225 Langen
Valid for European Union Countries:
According to the European WEEE-Directive and its implementation into national laws we take this device back.
For disposal please send the device to the following address:
Fujitsu Microelectronics Europe GmbH
Warehouse/Disposal
Monzastraße 4a
63225 Langen
Loading...
