8-port KVM Switch Integrated Console Drawer
[FD-1008AT]
[FD-1016AT]
User’s Manual
Declaration of Conformity
Model Number : FD-1000 ATseries
Trade Name : Console Drawer
Responsible party : FUJITSU COMPONENT AMERICA, INC. Address : 250 East Caribbean Drive, Sunnyvale,CA94089
Telephone number : (408) 745-4900
This device complies with Part 15 of the FCC Rules. Operation Is subject to the following
two conditions : (1) this device may not cause harmful Interference, and (2) this device
must accept any Interference received, Including Interference that may cause undesired
operation. DOC Class A
This Product is designed, developed and manufactured as contemplated for general use, including without limitation, general office use, personal use, household use, and ordinary industrial use, but is not designed, developed and manufactured as contemplated for use accompanying fatal risks or dangers that, unless extremely high safety is secured, could lead directly to death, personal injury, severe physical damage or other loss (hereinafter "High Safety Required Use"), including without limitation, reaction core control in nuclear power facilities, aircraft autopilot flight control, air traffic control, operation control in mass transport control systems, medical instruments for life support systems, missile launching control in weapon systems. You shall not use this Product without securing the sufficient safety required for the High Safety Required Use. If you wish to use this Product for High Safety Required Use, please consult with our sales person
representatives in charge before such use.
Other names such as product names are the registered trademarks or trademarks of their
respective companies.
All Rights Reserved, Copyright
I
© FUJITSU COMPONENT LIMITED2003
II
Contents
PREFACE...................................................................................................................................................... 2
Conventions .................................................................................................................................. 2
Packing List................................................................................................................................... 2
IMPORTANT NOTICES................................................................................................................................. 4
Safety............................................................................................................................................ 4
Disposal ........................................................................................................................................ 6
Moving Console Drawer................................................................................................................ 6
INSTALLATION.............................................................................................................................................7
Installing the Guide Rails (when using a tapped guide rail) .......................................................... 7
Installing Console Drawer ............................................................................................................. 9
NAMES AND FUNCTIONS OF PARTS.......................................................................................................10
CONNECTING AND REMOVING CABLES................................................................................................. 13
Connecting Cables...................................................................................................................... 13
Removing Cables........................................................................................................................ 15
OPERATION................................................................................................................................................ 16
Operating the Console Drawer ................................................................................................... 16
Adjusting the Monitor .................................................................................................................. 18
Basic Adjustment Procedure....................................................................................................... 19
Resolution and Refresh Rate...................................................................................................... 21
Hot-Key SW operations .............................................................................................................. 22
Keyboard Operation, LED Indicators and the Reset SW ............................................................ 22
Pointing Device Operation .......................................................................................................... 23
Switching the Server ................................................................................................................... 24
Selecting the Server when the Power is ON............................................................................... 24
Selecting the Hot Key Mode ....................................................................................................... 24
Setting/Changing Server Names ................................................................................................ 30
Constant Server Name Display Function.................................................................................... 31
EDID Setting Mode ..................................................................................................................... 32
Storing Console Drawer.............................................................................................................. 33
Cleaning Console Drawer ........................................................................................................... 34
TECHNICAL SPECIFICATIONS.................................................................................................................. 35
TROUBLESHOOTING................................................................................................................................. 37
1
N
Preface
Congratulations on your purchase of a server rack-mountable KVM Switch Integrated Console Drawer. Using this product will greatly improve the efficiency and server switching functionality of the workspace around your racks. Space that was used in previous layouts can now be used more freely due to our compact sliding module design. The 15-inch TFT monitor has a resolution of 1024 to 768 dots with 16,770,000 colors. Also, it is equipped with a keyboard and 3-button pointing device.
Console Drawer is compatible with DOS/V (PC/AT compatible) devices. This user’s manual applies to both the 8-port and 16-port KVM Switches. However, unless otherwise mentioned, all descriptions in this manual refer to the 8-port KVM Switch.
*KVM Switch: Keyboard Video Mouse Switch
Conventions
Symbols and terminology that are used in this manual are described below.
This symbol indicates the possibility of physical damage (to this
CAUTIO
Text that is preceded by a number (such as 1.) indicates that the order of operation.
Reference to important chapter titles and terminology are in brackets [ ].
Packing List
Make sure that the items in the following list were included in the shipping package.
KVM Switch Integrated Console Drawer x 1
Operation manual (this manual) x 1
If something is missing from the package, contact your place of purchase or a Fujitsu maintenance person.
product, or server) or physical injury, which may result through
improper operation.
This symbol indicates supplemental information, comments or hints.
2
N
CAUTIO
Please note the safety information in [Important Notices].
1. Check the package delivered and whether the Console Drawer has been damaged
when unpacking.
2. Remove the rubber stabilizer from the front left side of the Console Drawer.
The rubber stabilizer is inserted to prevent the Console Drawer from sliding when installing or moving it. Be sure to keep it after finishing the installation
for when it needs to be used again.
3
N
Important Notices
This chapter contains cautions that must be taken when operating the Console Drawer and information related to safety. Carefully read this chapter to use the Console Drawer correctly.
Safety
CAUTIO
This device adheres to the safety regulations related to information processing equipment such as electronic office machines that are used in an office environment. If you have any questions, please contact your place of purchase or a Fujitsu maintenance person.
To prevent extreme bumping or shaking when moving the Console Drawer use the original shipping container or a box similar to it.
During installation and before using the Console Drawer, carefully read [Installation] and the section about environmental conditions in [Technical Specifications] to use the Console Drawer correctly.
Moving the Console Drawer from a cold environment to the installation location may cause condensation to occur. Before using the Console Drawer allow it to dry out completely and to reach the ambient temperature of the installation location.
Make sure that the local power supply voltage is within the acceptable range of the Console Drawer. Make sure that the rated voltage meets the specifications of this device (Refer to [Technical Specifications] and the model plate on this device).
The power cable for the Console Drawer is specially certified. Do not connect it to any place other than a grounded wall outlet.
Arrange the immediate area around the Console Drawer's power socket and the rack's power outlet so that the plug can be removed quickly in the case of an emergency.
Lay all the cables so that they will not be damaged. Refer to the relevant sections in “Connecting and Removing Cables”.
Do not connect or remove the data transmission cables during thunderstorms.
Do not allow foreign substances or liquids inside the Console Drawer.
In an emergency (device or parts failure:damage caused by liquid or a foreign objects
into the Console Drawer) remove all cables from the Console Drawer as soon as possible and contact your place of purchase or a Fujitsu maintenance person.
Only licensed engineers can repair the Console Drawer. Any unlicensed user that opens the Console Drawer and makes incorrect repairs may cause electric shock or fire.
Always hold the connector portion and do not jerk the cables when removing them.
Avoid operating the Console Drawer with wet hands.
Do not unplug connectors with wet hands.
Do not place such unnecessary items on the top of the Console Drawer.
Do not modify or repair the Console Drawer.
Precautions
4
N
Only licensed personal can uncouple, remove or switch parts (such as electro-magnetic wave devices) which bear a warning mark (such as a lightening bolt).
Only the resolution and refresh rate specified in the monitor explanation in [Technical Specifications] can be used as incorrect settings may damage the monitor. Contact your place of purchase or a Fujitsu maintenance person if you have any questions.
To prevent interference it is necessary to adequately isolate the data cables connected to peripheral equipment.
Unplug the power plug from the grounded power outlet if there is a power outage.
Follow the instructions in the appropriate section in [Operation] when cleaning server.
Do not use the Console Drawer as a foot rest or lean against it with it drawn out. Doing
so may unbalance the rack, causing it to fall over.
Keep this manual handy for reference with the Console Drawer at all times.
CAUTIO
Safety Instructions
Read the “Safety Instructions” before use to ensure proper use of this product. Safety
Instructions contained in this section are written for the user to avoid any damage to property or self-injury. Please read the following carefully:
Verify that the power to the server is off before handling any connectors. Also, be sure to discharge any static electricity. Connecting or disconnecting the connectors while carrying a static charge or while the power to the server is on may damage the server or this device. Note that damage of this kind is not covered by the warranty.
Only PC/AT compatible servers can be hooked up to this device, and each server must be equipped with the following type of keyboard, mouse and monitor connectors. Other types are not supported. Additionally, a PS/2 keyboard and mouse can not be connected at the same time as a Sun keyboard.
Compatible PC/AT connectors:
- Mini DIN 6P female (1 each for PS/2 keyboard and PS/2 mouse)
- USB A-type connector
- Mini D-SUB 15P female (monitor)
Connecting the server requires special optional cables (for PS/2, and 1.8 m, 3 m and 5 m USB cables). The maximum cable length is 5 meters. Use a 1.8 meter cable for cascaded connections. Please note that cables longer than specified are not covered by the warranty.
Use of standard equipment is recommended because special keyboards (programmable, wireless) and mice (wireless or that require a special driver) may not be supported/operate
The keyboard connector for this switch device is a PS/2 type (Mini DIN 6P female), but you can connect an AT-type (DIN 5P male) keyboard by using a PS/2 <-> AT adapter. A USB type keyboard may not be used as the console keyboard.
The mouse connector for the switch device is exclusively for PS/2 connection (Mini DIN 6P female). A serial or USB-type mouse may not be used as the console mouse.
5
N
When using a mouse with a scroll function such as a mouse with PS/2 wheel, scrolling outside of the support sometimes does not function properly. Also, the scroll mice may fail to function properly depending on the software used.
The keyboard and mouse connectors are the same shape. Be sure the colors match to connect them correctly. If they are forced in or connected incorrectly, the switch device may not only function improperly but also may malfunction.
Set up the console’s keyboard and mouse with each server correctly. If they are not set correctly they will not operate normally.
Hook up the cables for each port to the same server. If the monitor, keyboard, and mouse port numbers are wrong, you will not be able to select the server correctly.
A DVI (Digital Video Interface) compatible display can not be connected.
When connecting a monitor other than the one for Console Drawer, use one that is
multi-scan compatible, and set the correct resolution. KVM Switch supports a resolution of 1600 x 1200 with a refresh rate of 75 Hz. Also, the display may be off center after switching depending on the monitor and resolution settings. Adjust the monitor or video card if this happens.
Degradations in high resolution screen quality, such as ghosts or blurring, may be due to the monitor cable or video card. Also, the screen may not display normally sometimes, depending on the particular combination of display and video card. Try changing the settings of the environment in which the video card, for example, is connected.
The monitor cable connector is a Mini D-SUB 15P type. Make sure you connect it in the correct orientation and use the fixing screws to hold it in place. It may cause trouble if it is not connected properly.
Cascaded connections must be setup exclusively with our KVM switches only. You can not make these connections with switches produced by other manufacturers.
A maximum of two levels of cascaded connections are allowed (including the ma ster). Attempting to cascade three or more levels will not work.
Disposal
This device is manufactured with metal and plastic parts. Dispose of it according the relevant government regulations.
Moving Console Drawer
When moving the Console Drawer to a different location, use
CAUTIO
the box in which it was purchased or a box that protects the product from bumping and shaking. Do not unpack the Console Drawer until the move has been completed.
6
N
Installation
Please note the safety information in [Important Notices].
CAUTIO
Installing the Guide Rails (when using a tapped guide rail)
* These guide rails are optional.
Install the guide rails with the guides toward the front so that the Console
Drawer can be mounted on them. When using a tapped guide rail, install them on the inside of the rack supports. A screw holder may be required depending on the guide rail specifications. See the installation drawing using tapped guide rails on page 9.
1. Adjust the length of the guide rails on the inner side of the rack supports. Place the
screw gaskets in the holes on the rack, and then fix the screws in the upper and lower holes on the guide rails. (Set the left and right guide rails at the same height.)
For details on installing other guide rails, refer to their respective user’s manual.
Maintain the area around the equipment when using the Console Drawer (See [Technical Specifications] for more information). Avoid dust, humidity and extreme temperatures. Installation may re-quire more than two people in some situations. Be careful not to pinch your fingers or hands between the guide rails and the Console Drawer.
7
Installing tapped guide rails diagram
8
N
Installing Console Drawer
Be careful that the latch lever (see page 17) does not come loose. If
CAUTIO
the latch lever becomes loose, the Console Drawer may slide open. When installing the Console Drawer on the guide rails, make sure that at least two personnel are holding the Console Drawer. Do not connect the power cable at this point.
1. After installing the guide rails, mount the Console Drawer from the front side.
2. Push the Console Drawer in until it stops, and then tighten the two screws on the front
of the Console Drawer to fix it in place.
Installing the Console Drawer diagram
9
Names and Functions of Parts
Overview
Console switches
The five buttons and two LEDs on the monitor are explained in order from left to right.
Power button: Push this button to turn on the power to the monitor. Also, pushing this
button while the monitor is on cuts the power to the monitor.
Power lamp (green): This lamp lights when the power to the monitor is on and goes out
when the power to the monitor is off.
Indicator lamp (orange): This lamp lights when the monitor is in energy-saving mode.
Menu button: Push this button to adjust the monitor.
Button: Selects OSD (On Screen Display) menu items (downward).
Button: Selects OSD menu items (upward).
Button: Push this button to select or enter things.
Hot-key: Push this button to display the OSD for switching servers.
10
Rear Panel
8-Port KWM Switch
(1) (2) (3) (4) (5) (6) (7)
8-port KVM Switch rear panel
(1) Power cable connector
Connect to a 100 V AC electric outlet.
(2) Connectors for servers [1 through 8]
Connect each port (1 through 8) on this device to the relevant host’s keyboard, mouse and monitor connectors with the special cable.
(3) DIP Switches
Use for a variety of settings. Numbered from left side while facing the switches starting from 1, 2…8; up is on and down is off.
(4) Connector for [Sun]
Connect to a SUN keyboard/mouse. (Do not connect to the Console Drawer.)
(5) Keyboard connector
Connect a PS/2 keyboard connector (purple).
(6) Mouse connector
Connect a PS/2 mouse connector (green).
(7) Monitor Connector
Connect a monitor.
16-Port KVM Switch
11
16-port KVM Switch rear panel
