Using UIM (FOMA card)

UIM (FOMA card) is a card for storing user information such as phone numbers.

･

If UIM is installed incorrectly or if there is a problem with UIM, you cannot make/ receive a call or send/receive a mail.

･

For details on handling UIM, refer to the UIM manual.

◆

Installing/Removing

･

After turning the power OFF, fold FOMA terminal and hold it with your hand.

･

Take care not to touch or scratch the IC part.

･

Attaching/Removing back cover and battery pack→P43

■

Installing

Pull the tab and pull out the tray until it clicks.

Put UIM to the tray with the IC side down and beveled corner fitted to the tray, and push the tray until it stops.

■

Removing

Perform a of installing operation.

Take out UIM.

✔

INFORMATION

･

Note that forcible installing or removing UIM, or installing battery pack with the tray inserted at a slant may break UIM or the tray.

･

If the tray is removed, press it straight along the guide rail inside the UIM slot with UIM left detached.

◆

Security code

Two security codes, "PIN code" and "PIN2 code", are set for UIM.

･

You can change the security codes yourself.→P106

◆

UIM operation restriction

FOMA terminal is provided with UIM operation restriction for protecting your data/ files or data/files copyrighted by a third party.

･

When files or data are downloaded from websites or data attached to mails are obtained to your FOMA terminal with UIM equipped, UIM operation restriction is automatically set to these data or files.

･

The data types subject to UIM operation restriction are as follows.

- Videophone call message, Movie memo, Screen memo

- i-mode mail attachment files (except ToruCa), images inserted to Deco-mail or signature, Decome-Anime template, MessageR/F, Deco-mail template containing data subject to UIM operation restriction

-i-

ppli (including i-αppli stand-by display), ToruCa (Details) image

- Images (including GIF animations, Flash graphics and images downloaded from Data Center), i-motion, data compatible with contents transfer, melodies, Chara-den, Machi-chara

- Kisekae Tool, Chaku-uta

"Chaku-uta" is a registered trademark of Sony Music Entertainment (Japan) Inc.

･

Data or files with UIM operation restriction set cannot be transferred over infrar ed communication/iC transmission or copied/moved to microSD card.

･

With UIM replaced or no UIM installe d, data or files with UIM operation restriction set cannot be displayed or played. For ino functions except deletion are available.

/Chaku-uta full®, Music&Video Channel programs

ppli with UIM operation restriction set,

Before Using the Handset

F-08A_E1kou

L03.fm Page 42 Friday, March 27, 2009 4:15 PM

✔

INFORMATION

･

When data subject to UIM operation restriction is set as stand-by display, incoming/ outgoing image, ring alert, etc., replacing UIM with another one or using FOMA terminal without UIM installed causes the sound and image settings to be reset to the default state. In this case, sound or image actually generated or displayed may be different from those set. If UIM used when downloading the data is installed, UIM operation restriction of the data is canceled and the original settings are restored (when data is used for Set random image on stand-by display, settings may be canceled).

･

UIM operation restriction is not set to data obtained via infrared communication, iC transmission, microSD card or DOCOMO keitai datalink or still images/moving pictures taken with the built-in camera.

･

The following settings are saved to UIM.

- My phone number

- SMS settings (except "SMS report request")

- DOCOMO Cert/User certificate of Manage certificate

バイリンガル

(Select language), UIM, PLMN setting

◆

Settings when replacing UIM

If replacing the currently installed UIM with another UIM, the following settings are changed.

My phone number , language), SMS settings (except "SMS report request"), "DOCOMO Cert"/"User certificate" of Manage certificate, PIN code and PIN2 code of UIM, PIN1 code ON/OFF, PLMN setting

i-Channel setting, Reset call cost, i-Widget roaming set

FullBrowser usage Set to "No" regardless of the setting before

Cookie setting of i-mode and Full Browser

Set program of Music&Video Channel The setting before replacement is canceled.

Setting Changed contents

バイリンガル

Changed to the contents saved in the inserted

(Select

UIM.

Restored to the default settings.

replacement. Set to "Invalid" regardless of the setting before

replacement. Cookie information is retained, but if setting to "Valid" again, a confirmation screen for deleting Cookie information appears.

Set the program again if necessary.

Before Using the Handset

F-08A_E1kou

Press here with your thumb

Back cover

Lever

L03.fm Page 43 Friday, March 27, 2009 4:15 PM

◆

UIM types

When using UIM (blue) in FOMA terminal, note that it differs in the following items from UIM (green/white).

Number of savable digits of phone numbers in UIM phonebook

User certificate download to use FirstPass

WORLD WING service Service Numbers

Item UIM (blue) UIM (green/white) Page

Up to 20 digits Up to 26 digits P74

Unavailable Available P182

Unavailable Available P360 Unavailable Available P353

WORLD WING

WORLD WING is DOCOMO's FOMA international roaming service that allows you to make/receive calls with the same phone number overseas with UIM (green/ white) and a terminal compatible with the service. *

If you subscribed to FOMA service on or after September 1, 2005, separate subscription is not required to use WORLD WING. Note that, if you declined to use WORLD WING at subscription to FOMA service or canceled it, you need subscription.

If you subscribed to FOMA service on or before August 31, 2005, but not to WORLD WING, separate subscription is required to use WORLD WING.

There are some charging plans unavailable.

If UIM (green/white) is misplaced or stolen overseas, immediately contact DOCOMO and request for suspension of usage. Please see "General Inquiries" on the back of this manual for contact information. Be careful that you are charged also for calls and/or communications, if any, occurring after misplacement or stealage.

Attaching/Removing battery pack

･

After turning power OFF, fold FOMA terminal and hold it in your hand.

･

Removing battery pack may cause reservation of Software update to be canceled. When the date and time are set with Auto time adjust set to "OFF" in Date & time, removing battery pack may delete date and time.

･

Always lock the back cover lever. If you use the terminal without lock, the back cover may come off.

■

Attaching

Slide the back cover lever in the direction of a to unlock, steadily hold FOMA terminal not to slide with one hand, then slide the back cover in the direction of

by 2 mm with a thumb of the other hand to remove it.

When it is difficult to slide a back cover, hold FOMA terminal and slide the back cover with both of your thumbs.

Before Using the Handset

F-08A_E1kou

Tab

L03.fm Page 44 Friday, March 27, 2009 4:15 PM

Pinch the tab of the inner lid and open it in the direction of an arrow. *

The inner lid is designed to be firmly closed to keep the waterproof performance. Note that your nails or fingers may be injured if you try to open it forcibly.

Place the 8 tabs of back cover to the notches, press back cover in the direction of

to avoid forming any clearance between FOMA terminal and back cover, slide it in the direction of of

to lock.

to install, then slide the back cover lever in the direction

Back cover

With the label side of the battery pack upward, align convex parts of the battery pack with concave parts of FOMA terminal and insert the battery pack in the direction of the inner lid.

Before Using the Handset

, press the battery pack in the direction of b to set it in, then close

Convex part

attery pack

Concave part

Lever

■

Removing

Perform a-b of installing operation.

Pinch the tab of battery pack and pick it up in the direction of the arrow to remove.

Tab

F-08A_E1kou

L03.fm Page 45 Friday, March 27, 2009 4:15 PM

✔

INFORMATION

･

Attaching battery pack forcibly into FOMA terminal may damage FOMA terminal jack.

･

FOMA terminal or back cover may be damaged if you install or remove battery pack by a method except the procedures above or if you press too hard.

･

Firmly install the back cover and lock it with the lever to avoid water seepage.

･

The rubber packing of the inner lid play an important role for keeping waterproof performance. Do not remove or scratch it. Also, prevent dust from adhering to it.

❖

For better battery pack performance

･

Do not charge the battery for an extended period (several days) with FOMA terminal turned ON.

After charging has completed with FOMA terminal turned ON, the power is supplied to the terminal from the battery pack. If FOMA terminal is left in that state for a long time, the battery pack may run out causing the low battery alert to sound after using only a short period of time. In this case, remove FOMA terminal from the AC adapter, desktop holder or DC adapter and then reconnect it and charge the battery again.

･

To promote environmental conservation, return your used battery pack to NTT DOCOMO sales outlets, our corporate agencies or the shops that collect used battery in your community.

Charging

The battery pack does not have a full charge at time of purchase. Use AC/DC adapter for FOMA terminal to charge the battery before using FOMA terminal.

･

To get the maximum performance from F-08A, always use battery pack F09.

❖

Charging times (approximate)

The following is the time for charging an empty battery pack with F-08A's power switched OFF. Charging with the terminal ON or under low temperature requires longer time.

AC adapter DC adapter

Approx. Approx.

●●●

min. min.

Before Using the Handset
