F-04D

INSTRUCTION MANUAL

’11.X

F-04D_EN_ninshou

Thank you for purchasing "docomo STYLE series F-04D" mobile terminal.
Before using F-04D, read this manual to ensure safe use and handling.

About manuals for F-04D

The operations of F-04D are described in this manual, "
terminal) and "Instruction manual (detailed version)" (in pdf format).

Instruction manual
(this manual)

"

使いかたガイド

(Guide) "(installed
in FOMA terminal)

"Instruction manual
(detailed version)"
(in pdf format)

･

In this "F-04D INSTRUCTION MANUAL", "F-04D" mobile terminal is usually referred to as "FOMA terminal".

･

The images or illustration used in this manual are examples. They may differ from the actual displays.

･

The images used in this manual assume that Kisekae Tool is set to "White" and Color theme setting is set to
"White".

･

In this manual, "authenticate" indicates the operating procedure for entering the terminal security code in 4-

⇒

8 digits (

P40) or performing fingerprint authentication.

This manual provides information about screens and operations of basic
functions.

This guide provides overviews and operations of frequently-used functions.
(In Japanese only)
In F-04D Stand-by display,
method

This manual provides detailed information and operations of all the functions.
(In Japanese only)
<From a PC> This manual can be downloaded from NTT DOCOMO website.
http://www.nttdocomo.co.jp/support/trouble/manual/download/index.html

*

The URL and contents are subject to change without prior notice.

使いかたガイド

mef

(Guide)” (installed in FOMA

Toole# GuideeSelect a search

Basic package

F-04D

(including Back
Cover F66 and
warranty)

･

Unauthorized copying of parts of or this entire manual is prohibited.

･

The contents in this manual, URL and contents are subject to change without prior notice.

Battery Pack F19 Desktop Holder F33

Instruction manual 電子辞書データ DVD

(Electronic dictionary
data DVD) (Sample)

F-04D_EN_ninshouF-04D_EN_ninshouF-04D_EN_ninshou

Contents

FOMA terminal .................................

What you can do with F-04D...........

Part names and functions ...............

Usage styles .....................................

Before Using .....................................

Screen Explanation ..........................

Character Entry ................................

Call Telephone..................................

Mail....................................................

Phonebook........................................

i-mode/Full Browser/Smart Browser

....................................................... 75

i-Channel ...........................................

Camera ..............................................

1Seg...................................................

Music .................................................

Osaifu-Keitai .....................................

i-concier.............................................

Convenient tools ..............................

Support .............................................

Appendix...........................................

Index..................................................

2

Precautions (Always follow these

3

directions) .....................................

4

Handling precautions.......................

6

Waterproofness/Dustproofness .....

26

Sound/Screen Setting .....................

29

Lock/Security ...................................

34

59
68
71

Map/GPS...........................................

77

83

i-αppli ................................................

85

i-motion/Movie ................................

87

93

Data Management ...........................

94
95

110
119
136

7
16
21

36
40

78

89
90

99

Introduction

Basic
Operation

Connect

Search

Enjoy

More
Convenient

Others

1

F-04D_EN_ninshou

FOMA terminal

･

F-04D supports W-CDMA, GSM/GPRS, Wireless LAN System.

･

Because your FOMA terminal uses wireless transmission, it may not function in locations where it is
difficult for radio waves to penetrate, such as tunnels, underground passages and some buildings, in areas

Introduction

where radio waves are weak, or out of service area. Even when you are high up in a tall building or
condominium and nothing blocks your view outside, your FOMA terminal may not be able to receive or
transmit signals. Also, communication may be interrupted even when the signal meter on your FOMA
terminal indicates there are strong radio waves and you are not moving (traveling).

･

Because your FOMA terminal uses radio waves to communicate, it is possible that a third party may
attempt to tap your calls. However, the W-CDMA, GSM/GPRS automatically applies a confidential
communication function to all calls, so even if a third party could somehow tap a call, they only hear noise.

･

Your FOMA terminal encodes voice communication as digital data. When you are operating your FOMA
terminal while moving to a location subject to weaker radio wave conditions, the transmitted digital data
may not be correctly decoded and as a result the decoded voice may differ somewhat from the actual voice.

･

Maintain a separate record of the data (Phonebook, Schedule, Memo, Recorded messages, Voice memos,
Moving picture memos, etc.) you registered in your FOMA terminal. Note that DOCOMO assumes no
responsibility for any loss of saved contents of data resulting from malfunction, repair, changing of the
model or other handling of FOMA terminal.

･

You are recommended to save important data to microSD card. Using DOCOMO keitai datalink, you can
transfer and save phonebook, mail, schedule and other data to a PC.

･

The user hereby agrees that the user shall be solely responsible for the result of the use of SSL/TLS.
Neither DOCOMO nor the certifier as listed herein makes any representation and warranty as for the
security in the use of SSL/TLS. If the data should be erased, DOCOMO assumes no responsibility for the
loss of any data.
Certifier : VeriSign Japan K.K., Cybertrust Japan Co., Ltd., GlobalSign K.K., RSA Security Japan Ltd.,
SECOM Trust Systems Co., Ltd., Comodo CA Ltd., Entrust, Inc., Go Daddy, Inc.

･

This FOMA terminal supports FOMA Plus-Area and FOMA HIGH-SPEED Area.

■

SIM unlock

This FOMA terminal supports SIM unlock. If you release SIM lock, you can use UIM by a carrier other than
NTT DOCOMO.

･

The SIM unlock service is provided at a docomo Shop.

･

A SIM unlock charge is separately required.

･

If you use a UIM other than by DOCOMO, available services and functions will be limited. DOCOMO is not
liable to any failures or malfunctions.

･

For details of SIM unlock, refer to NTT DOCOMO website.

2

F-04D_EN_ninshou

What you can do with F-04D

Waterproofness/Dustproofness

Waterproofness of IPX5 and IPX8 and dustproofness of IP5X
are provided by firmly closing the external connection jack
cap and installing the back cover in a locked state.

MyFACE

You can pin up to 12 MyFACEs on the stand-by
screen (portrait view) and flick from side to side to
switch them one after another.

Voice quick start

Just speaking a keyword of function you want to
use activates the function. It is useful when you do
not know where is a desired function in the menu
or when you want to activate the function
immediately. (In Japanese only)

使いかたガイド

Without the instruction manual at your hand, you
can check readily the operations of function. (In
Japanese only)

eco mode

The eco mode allows you to save the battery
power by adjusting the display backlight, etc. And
you can set to automatically switch eco mode to
ON according to the battery level.

Koe-no-Takuhaibin

Koe-no-Takuhaibin takes voice messages using
voice call and notifies existence of message to the
party by SMS. And notify you by SMS when the
party plays a message. You can record and play
messages as easily as you make a call.

(Guide)

21

31

33

33

39

60

Smart Browser

WebKit, adopted by Smartphone etc., enables to view
contents on the Internet comfortably by touch operation.

AUTO-GPS

The AUTO-GPS function provides you useful services
that deliver information about the weather or shops
around where you are, or sightseeing information.
(In Japanese only) You can also enjoy a game using
your location or the distance you moved.

High functionality camera

Camera offers approximately 16,3 million pixels
(effective pixels) and high functionality such as
HDR (High Dynamic Range) synthesis, Art camera
function, etc., which enable to shoot 3D still
images and Full HD moving pictures. You can also
view images on wide-screen by connecting the
FOMA terminal to a TV with HDMI cable.

i-concier

It is a service that Machi-chara (a character on the stand-by
display) supports your life like a butler or concierge. It stores
your various information (area of residence, memo,
schedule, ToruCa, phonebook, etc.) and offers you
information that matches contents of Memo or Schedule,
your living area or current location, or preferences and
interest at the right time. (In Japanese only)

Wi-Fi

You can perform Internet connection with connecting
the access point for home network or Public wireless
LAN service (Client mode), and use the FOMA
terminal as access point (Base unit) of Wi-Fi to enjoy
a versus game etc. on Wi-Fi device (Sub unit).

75

79

83

94

97

Introduction

3

F-04D_EN_ninshou

Part names and functions

Part names of F-04D and major functions assigned to each part are as follows.

Introduction

4

F-04D_EN_ninshou

To use the function with *, press the key for 1
second or more.

a

Earpiece

b

Display

c

Light sensor for sensing the ambient
lightness to adjust the brightness of the
display

d

Microphone

e

Bluetooth/Transmitter/Wi-Fi antenna
section

f

1Seg antenna used for 1Seg watching

g

Light that turns on when receiving a call or
message or while charging

h

Sub-display

i

GPS antenna is built-in

Covering around the antenna by the hand may
affect the quality.

j

FOMA antenna is built-in

Covering around the antenna by the hand may
affect the quality.

k

Camera

l

Fingerprint sensor for registering
fingerprint and authentication

m

Infrared data port for infrared
communication or infrared remote control
function

n

Speaker

o

mark for placing over IC card reader for

Osaifu-Keitai and iC transmission

p

Light/Shooting light

q

Back cover

To access miniUIM slot and the microSD card
slot, remove the back cover and the battery
pack.

r

Charging jack

s

Back cover lever

t

Open assist button

u

Strap opening

v

External connection jack for charger,
earphone, etc.

am

Display the menu

b a

Display the mail menu, switch text input

modes or check new mail/message

c c

Display i-Channel or return to the previous

screen

d n

Start voice call, switch to hands-free call or

perform quick voice activation

e 0

- 9 Enter phone number or characters, or
select menu item, perform function assigned to
shortcut (eco mode ON/OFF is assigned to

*

default)

f *

Enter "*" or voiced/semi-voiced sound, or

start/cancel Public mode (Drive mode)

g T

Start/Exit i-Widget, or start 1Seg

h U

(Search key) Activate Quick search/Shabette-

*

Kensaku

i k

(Multi-cursor key) Move the cursor

g

Perform an operation

u

Display Phonebook, adjust sound volume or

add a phonebook entry.

d

Display shortcuts list or adjust sound volume.

l

Display MyFACE, switch screen or display
Received calls when MyFACE usage setting is
"OFF"

r

Display MyFACE, switch screen or display
Redial when MyFACE usage setting is "OFF",
activate/deactivate IC card lock

*

*

*

*

*

*

5

Introduction

by

5

F-04D_EN_ninshou

j C

Start the still camera shooting

k I

Display iMenu or i-αppli folder

l f

Exit a running function, or turn ON/OFF the

FOMA terminal by pressing for 2 seconds or more

m #

Enter "#" or punctuation, or start/cancel

Silent mode

n s

a call or operation, or switch between 3D and 2D

Introduction

o

(Side key) Light sub-display, switch display

Z

record video during 1Seg watching

SD
S

message
conducts mail/message inquiry

Connection of Stereo Earphone Set 01 (Optional)
for external connection jack

*

 AC adapter uses a common jack.

*

(Multitask key) Start another function during

(Side camera key) Activate movie shooting,

Adjusting volume

stops ring alert, alarm, vibrator or activate quick

*

, activate voice/video memo*, D

Stereo Earphone Set 01

*

, etc.

*

Usage styles

There are 3 styles for use : "Closed style" allows you
to get information from the sub-display such as time,
received calls, "Opened style" is compatible with key

*

operation and touch operation, and "Flip style" is

*

dedicated to the touch operation.

Point

･

Make sure to hold the FOMA terminal when operating
the open assist button. And when opening, be careful
not to hit the FOMA terminal to your face, someone or
something, or not to drop the terminal with its rebound.

･

Do not rotate the display by 180 degrees or more
clockwise or by 90 degrees or more counter
clockwise. When rotating, be careful not to hit the
corner of the display against the face of the keypad.

･

When you carry the FOMA terminal in the close style,
press and hold
Side key hold for preventing from erroneous side key
operation. When you carry the FOMA terminal in flip
style, make Display off lock setting in Auto-key lock
to avoid erroneous touch panel operation and save
battery consumption.

m

for 1 second or more to activate

AC adapter

External connection
jack

6

F-04D_EN_ninshou

Precautions (Always follow these directions)

・

Before using your FOMA terminal, or when
necessary, read the precautions below to
ensure safe use and handling. After reading this
manual, keep it carefully.

・

These precautions are intended to protect you
and others around you. Read and follow them
carefully to avoid injury, damage to the product
or damage to property.

・

The signs below differentiate between the
levels of danger that can occur if the product is
not used within the specified guidelines.

This sign denotes that
death or serious injury

DANGER

may directly result from
improper use.

This sign denotes that
death or serious injury

WARNING

may result from
improper use.

This sign denotes that
minor injury or damage

CAUTION

・

The symbols below show specific directions.

Don’t

No disassembly

to property may result
from improper use.

This symbol denotes that the action
is prohibited.

This symbol denotes that
disassembling the phone or its
components is not allowed.

No wet hands

No liquids

Unplug

■

Precautions contain the description below.

Handling FOMA terminal, battery pack, adapter,

desktop holder and miniUIM (common)..................8

Handling FOMA terminal ..............................................9

Handling battery pack .................................................11

Handling adapter and desktop holder .......................12

Handling miniUIM .......................................................13

Handling mobile phones near electronic medical

equipment.................................................................14

Viewing 3D images......................................................14

Material list ..................................................................15

This symbol denotes that using the
phone or its components with wet
hands is not allowed.

This symbol denotes that using the
phone or its components in a
bathroom or other highly humid
area is not allowed.

This symbol denotes that an
instruction must be obeyed at all
times.

Do

This symbol denotes that the
equipment should be unplugged.

Introduction

7

F-04D_EN_ninshou

Handling FOMA terminal, battery
pack, adapter, desktop holder and
miniUIM (common)

DANGER

Introduction

Do not use, store, or leave the
equipment in hot areas such as near
flames or in areas under strong direct

Don’t

sunlight such as inside a vehicle.

May cause fire, burns or injuries.

Do not put the terminal into heating
cooking device such as microwave oven
or high-pressure container.

Don’t

May cause fire, burns, injuries, electric shock.

Do not disassemble or remodel the
equipment.

May cause fire, burns, injuries, electric shock.

No disassembly

Do not let the terminal get wet with
water, drinking water, urine of pet
animals, etc.

No liquids

May cause fire, burns, injuries, electric shock.
For waterproofness, refer to the page.⇒P21

Use the battery pack and adapter
specified by NTT DOCOMO for your
FOMA terminal.

Do

May cause fire, burns, injuries, electric shock.

WARNING

Do not throw the equipment or give
hard shock to it.

May cause fire, burns, injuries, electric shock.

Don’t

Keep conductive materials (metal
pieces, pencil lead, etc.) from coming in
contact with the charging jack or

Don’t

external connection jack. Do not put
those materials inside the terminal.

May cause fire, burns, injuries, electric shock.

Do not cover or wrap the terminal with
a blanket, etc while using or charging.

May cause fire or burns.

Don’t

Turn FOMA terminal OFF and stop
charging before entering a place such as
a gas station where flammable gases

Do

are generated.

The gas may catch fire.
When using Osaifu-Keitai in a place as a gas
station, turn OFF the terminal before using it.
(When IC card lock is activated, deactivate it
before turning OFF the terminal.)

If the equipment starts giving off a
strange smell, overheats, becomes
discolored or deformed during use,

Do

charging or in storage, immediately
perform the following operations.

･

Remove the power plug from the wall outlet
or cigarette lighter socket.

･

Turn FOMA terminal OFF.

･

Remove the battery pack from FOMA
terminal.

May cause fire, burns, injuries, electric shock.

CAUTION

Do not leave the equipment on unstable
or sloping surfaces.

May cause injuries.

Don’t

Do not store the equipment in
extremely humid, dusty or hot areas.

May cause fire, burns, electric shock.

8

Don’t

F-04D_EN_ninshou

Children using the equipment should be
instructed in proper operation by an
adult. Do not allow them to use the

Do

equipment without adult supervision.

May cause injuries.

Store the equipment out of reach of
small children.

May be accidentally swallowed or cause

Do

injuries.

Be careful especially when using FOMA
terminal connected to the adapter
continuously for a long time.

Do

If you use i-αppli, a videophone call or 1Seg
watching while charging the battery for a long
time, FOMA terminal, battery pack and adapter
may be heated.
Directly touching a hot part for a long time, you
may have redness, itching or rash on your skin,
or it may result in low-temperature burns
depending on your constitution and/or health
condition.

Handling FOMA terminal

WARNING

Do not direct the infrared data port
toward your eye and transmit signals.

May cause harmful effect on eyes.

Don’t

Do not direct the infrared data port
toward home electric appliances etc.
equipped with infrared device when

Don’t

using infrared communication.

May cause an accident because of malfunction
of infrared device.

Do not turn on the light by getting the
lighting part closer to other person's
eyes. When shooting infants, keep at

Don’t

least 1 m away from the object.

May impair eyesight. And may cause accidents
like injury etc., by dazzling or astounding other
people.

Do not put foreign objects such as liquid
like water, metal pieces or burnable
things into miniUIM or microSD card

Don’t

slot.

May cause fire, burns, injuries, electric shock.

Do not turn on the light aiming directly
at the driver of the car etc.

May disturb driving and cause an accident.

Don’t

Turn FOMA terminal OFF in areas where
use is prohibited, such as in airplanes
and hospitals.

Do

May cause electronic equipment or electronic
medical equipment to fail or malfunction. If the
function which automatically turns the power
ON is set, cancel the setting before turning the
power OFF.
When using the phone in a medical facility, be
sure to observe the regulations of the facility.
If you do prohibited act such as using the phone
in an airplane, you will be punished according to
law.
If usage of mobile phones in an aircraft is
admitted by setting airplane mode, etc., use the
terminal under the direction of the airline.

Introduction

9

F-04D_EN_ninshou

Introduction

When you talk by setting handsfree or
ring alert is sounding, keep FOMA
terminal away from your ear.

Do

And, when connecting the earphone/
microphone etc. to the FOMA terminal
and play a game or music, adjust the
volume moderately.

Too loud volume may cause a hearing loss.
And, if you cannot hear the sound around you
clearly, it may cause an accident.

If you have weak heart, be careful when
setting the Vibrate alert (vibration) or
alert volume setting.

Do

May cause harmful effect on heart.

When you use electronic medical
equipment, check with the equipment
manufacturer to determine how the

Do

device is affected by radio waves before
using.

May cause harmful effect on electronic medical
equipment etc.

Turn FOMA terminal OFF near high­precision electronic control equipment
or electronic equipment using low-

Do

power signals.

May cause the equipment to fail or malfunction.

* Examples of electronic equipment to avoid.

Hearing aids, implanted pacemakers or defibrillators,
other electronic medical equipment, fire alarms,
automatic doors and other automatic control
equipment.
Users wearing implanted pacemakers or defibrillators
or other electronic medical equipment should check
with the manufacturer or sales outlet about the effect
of radio frequencies on the equipment.

When the display or camera lens is
accidentally broken, be careful of
broken glass or exposed internal parts

Do

of FOMA terminal.

Surfaces of display and camera lens are made of
plastic panels and they are structured for the
glass not to scatter, however, if you mistakenly
touch broken or exposed parts, you may be
injured.

To sound the high-pitched alarm,
always keep FOMA terminal away from
your ears.

Do

May cause hearing defect.

CAUTION

Do not swing FOMA terminal by
antenna or its strap.

May cause accident such as injury to yourself or

Don’t

others by hitting.

Do not use damaged FOMA terminal.

May cause fire, burns, injuries, electric shock.

Don’t

When using the motion sensor, check
the safety around you, hold FOMA
terminal firmly, and do not shake it

Don’t

unnecessarily.

May cause accident such as injuries.

10

F-04D_EN_ninshou

If the display part is accidentally broken
and the liquid crystal leaks out, do not
make the substance contact with your

Don’t

skin of face or hands.

May cause loss of sight or skin problems.
If the liquid crystal gets into your eyes or mouth,
rinse it with clean water and see a doctor
immediately.
And, if the liquid adheres to skin or clothing, use
alcohol etc. to wipe it off, then wash with soap.

To use the terminal in car, check with
automobile manufacturer or dealer to
determine how the device is affected by

Do

radio waves before using.

In rare cases, using the phone in some vehicle
models can cause the vehicle's electronic
equipment to malfunction. In that case, stop
using the terminal immediately.

Mobile phones can give some users skin
problems such as itching, allergic
reactions or rashes. If you develop skin

Do

problems, stop using the phone
immediately, and see a doctor.

"Material list (P15)"

When opening or closing FOMA
terminal, take care not to have your
fingers or strap caught by the terminal.

Do

May cause accident such as injuries.

When watching the display, take a
certain distance from the display in a
fully bright place.

Do

May reduce visual acuity.

Handling battery pack

■

Check that the battery type matches the type

displayed on the battery pack label.

Display Battery type

Li-ion 00 Li-ion battery

DANGER

Do not connect a wire or other metal
objects to the jack. And, do not carry or
store FOMA terminal with objects like a

Don’t

metal necklace.

May cause the battery pack to ignite, burst, heat
or leak.

Check the orientation of battery pack to
install it to FOMA terminal, and do not
try to force the battery pack onto FOMA

Don’t

terminal if you are having trouble
installing it.

May cause battery pack to ignite, burst, heat or

⇒

leak.

Do not throw the battery pack into the
fire.

May cause battery pack to ignite, burst, heat or

Don’t

leak.

Do not nail the battery pack, hit with a
hammer or step on it.

May cause battery pack to ignite, burst, heat or

Don’t

leak.

If the battery pack's fluid etc. contacts
eyes, immediately flush the eyes with
clean water and see a doctor right

Do

away. Do not rub the eyes.

May cause loss of sight.

Introduction

11

F-04D_EN_ninshou

Don’t

Don’t

Introduction

Don’t

Don’t

12

WARNING

If the battery pack seems to have
abnormalities such as deformation or
scratches due to falling, never use it.

May cause battery pack to ignite, burst, heat or
leak.

If the battery pack leaks or gives off a
strange smell, immediately remove it
from the vicinity of open flames.

Do

The vapors from leaking battery pack fluid may
ignite or explode.

Be careful not to let your pet bite the
battery pack.

May cause battery pack to ignite, burst, heat or

Do

leak.

CAUTION

Do not discard old battery packs
together with other garbage.

May cause igniting or environmental
destruction. Tape the terminals of old battery
packs to insulate them, and then bring them into
a sales outlet such as docomo Shop. If your local
municipality has a battery recycling program,
dispose of them as provided for.

Do not use or charge a wet battery pack.

May cause battery pack to ignite, burst, heat or
leak.

If fluid etc. leaks out from the battery
pack, do not make the fluid contact with
your skin of face or hands.

Do

May cause loss of sight or skin problems.
If the fluid etc. put into your eyes or mouth, or
contacts skin or clothes, immediately flush the
contacted area with clean water.
If the fluid put into the eyes or mouth,
immediately see a doctor after flushing.

Handling adapter and desktop
holder

WARNING

Do not use the adapter cord if it gets
damaged.

May cause fire, burns, electric shock.

Don’t

Do not use the AC adapter or desktop
holder in a bathroom or other highly
humid area.

May cause fire, burns, electric shock.

Always use the DC adapter with a
negative-ground vehicle. Do not plug it
into a positive-ground vehicle.

Don’t

May cause fire, burns, electric shock.

When it starts to thunder, do not touch
adapter.

May cause electric shock.

Don’t

Do not short the charging jack while it is
connected to the outlet or cigarette
lighter socket. Do not touch the

Don’t

charging jack with a part of your body
such as your hand or finger.

May cause fire, burns, electric shock.

Do not place heavy objects on the
adapter cord.

May cause fire, burns, electric shock.

Don’t

When you insert and remove AC
adapter from power outlet, do not
contact a metal strap or other metal

Don’t

objects with the jack.

May cause fire, burns, electric shock.
