Install the back cover as described below.

Align 8 tabs of the back cover with concaves of FOMA terminal. While pressing the back cover in the direction of a so that there is no gap between FOMA terminal and back cover, slide the back cover in the direction of b to install, then slide the back cover lever in the direction of c to lock.

Back cover

・

The external connection jack cap and the rubber packing of the inner lid play an important role for keeping waterproof/dustproof performance. Do not remove or scratch it. Also, prevent dust from adhering to it.

To keep the FOMA terminal waterproof/dustproof, replacement of parts is required every 2 years regardless of whether FOMA terminal appears normal or abnormal. DOCOMO replaces the parts as a chargeable service. Bring FOMA terminal to a sales outlet such as a DOCOMO-specified repair office.

Important precautions

Do not perform actions shown in the illustrations below.

Introduction

Lever

Make sure that the back cover is completely closed without slack. Slide the back cover in the direction of the arrow shown on the lever, and then make sure the cover is securely locked before using.

・

Securely lock the back cover and firmly close the external connection jack cap. Even a fine obstacle (one hair, one grain of sand, tiny fiber, etc.) put between contact surfaces may allow water to enter.

・

Do not poke the microphone, earpiece or speaker with a swab or sharp object.

・

Do not let FOMA terminal fall. It may become scratched causing the waterproof/dustproof performance to degrade.

Using Soap/Detergent/

Bath powder

Applying strong

water flow

Washing with brush/sponge

Using in

hot spring

Washing by

laundry machine

Soaking in

ocean water

Observe the following precautions to use FOMA terminal properly.

・

Accessories and optional devices are not waterproof/dustproof. When watching 1Seg etc. with FOMA terminal installed in the desktop holder, do not use it in a bath room, shower room, kitchen or lavatory even if it is not connected to the AC adapter.

F-03B_EN_FCC

Press here

・

Do not apply water flow stronger than allowed (⇒P17) (e.g., such water flow that gives you pain when applied to your skin directly

Introduction

from a faucet or shower). F-03B provides the following waterproof performances of IPX5. However, it causes malfunction.

・

If FOMA terminal gets wet with salt water, seawater, water from the swimming pool or soft drink, or with mud or soil, flush away immediately. When it dries out, it becomes harder to get rid of, causing malfunction.

・

Do not use FOMA terminal before flushing mud or soil away. This damages FOMA terminal.

・

Do not put FOMA terminal in hot water, use it in a sauna or apply hot airflow (from a hair dryer etc.) to it.

・

Do not move in water or slam the terminal against the surface of water with FOMA terminal opened.

・

If you put the terminal in tap water or in water of swimming pool, be sure to have it within 30 minutes.

・

When you use the terminal in swimming pool, obey rules of the facility.

・

FOMA terminal does not float on water.

・

Do not leave water on FOMA terminal. May short-circuit the power jacks, or in a cold region, water may freeze causing malfunction.

・

Do not leave water on the microphone, earpiece or speaker. Such water may interfere with talking.

・

If the back cover is damaged, replace it. Water may enter inside from a damaged section causing troubles such as electric shocks or corrosion of the battery.

・

If FOMA terminal gets wet with water or other liquids with the external connection jack cap or back cover open, the liquid may get inside the terminal causing electric shocks or malfunction. Stop using FOMA terminal, turn the power OFF, remove the battery pack and contact a DOCOMO-specified repair office.

・

If rubber gasket on the external connection jack cap or inner lid is damaged or deformed, replace it at DOCOMO-specified repair office.

DOCOMO does not guarantee actual operations under all states. Malfunctions deemed to be caused by inappropriate operation by the customer are not covered by the warranty.

Washing FOMA terminal

Wash the terminal with tap water while holding the external connection cap. Do not rub the terminal. However, when mud or soil is attached to FOMA terminal, do not open or close the terminal. Instead, rinse the terminal clean by shaking it several times in tap water in a bucket and then flush away with running water.

・

Do not apply water flow stronger than allowed (⇒P17) (e.g., such water flow that gives you pain when applied to your skin directly from a faucet or shower).

F-03B_EN_FCC

To drain water off the speaker, shake FOMA terminal with the speaker upward

・

Wash it using room-temperature tap water with your hand, with FOMA terminal locked, the back cover installed and the external connection jack cap held in position.

・

Do not use any brush, sponge, soap, cleaning material, etc.

・

After flushing away, wipe off water with a dry cloth, drain, and dry naturally as follows.

Draining the water from FOMA terminal

When FOMA terminal is wet, water may flow out after wiping it off; drain the water in the following steps.

Wipe FOMA terminal surface with dry, clean cloth etc.

Shake FOMA terminal approximately 20 times, firmly holding its hinge section, until there is no more water splattering.

Softly press dry, clean cloth etc., against FOMA terminal to wipe off water remaining in the microphone, earpiece, speaker, keys or hinges.

Introduction

F-03B_EN_FCC

Around the inner lid

Rear side of the back cover

Remove the back cover and wipe off any drops of water around the inner lid and the rear side of the back cover. Never open the

Introduction

inner lid. After wiping off the water, install and lock the back cover.

Removing back cover ⇒P23

Wipe off water drained from FOMA terminal with dry, clean cloth etc., and dry naturally.

･

Water, if any, remaining in FOMA terminal may ooze up after wiping off.

･

Do not wipe off water remaining in concaves directly with a cotton swab etc.

Charging

Check the following before and after charging.

・

Check that FOMA terminal is not wet. Never try to charge the battery pack when FOMA terminal is wet.

・

Accessories and optional devices are not waterproof/dustproof.

・

When charging the battery when or after FOMA terminal is wet, adequately drain it and wipe off water with a dry, clean cloth etc., before connecting a desktop holder or opening the external connection jack cap.

・

When the external connection jack cap is opened for charging, close the cap firmly after charging. It is recommended that the desktop holder be used for charging to prevent water from seeping inside from the external connection jack.

・

Do not use the AC adapter or desktop holder in a bathroom, shower room, kitchen, lavatory or other highly humid area. May cause fire or electric shock.

・

Do not touch the AC adapter or desktop holder with wet hands. May cause electric shock.

F-03B_EN_FCC

Lever

Press here with your thumb

Back Cover

Tab

Battery Pack

Concave Part

Convex Part

Before Using

Attaching UIM (FOMA card)/battery pack

After turning power OFF, close FOMA terminal and hold it in your hand so that you can properly attach UIM/battery pack.

✜

Removing Back Cover

Slide the back cover lever in the direction of a to unlock, and then slide the cover in the direction of b by 2 mm with a thumb to remove it. Pinch the tab of the inner cover and open the cover in the direction of c until it stops.

✜

Installing UIM

Pull the tab with your nail and pull out the tray until it clicks (a). Hold UIM with the IC side down, align the beveled corner with the tray (b) and push into the tray until it stops (c).

Tab

Tray

Point

･

UIM (blue) is not available for this FOMA terminal. If you have the UIM (blue), bring it to a docomo Shop.

UIM

Corner cut

✜

Installing battery pack

With the label side of the battery pack upward, align convex parts of the battery pack with concave parts of FOMA terminal and slide the battery pack in the direction of a, press the battery pack in the direction of b to set it in, and then close the inner cover.

✜

Installing back cover

Place the 8 tabs of back cover to the notches, press back cover in the direction of a to avoid forming any clearance between FOMA terminal and back cover, then slide it in the direction of b to install it. Finally, slide the lever in the direction of c to lock.

Back cover

Point

･

The inner cover can be firmly closed for maintaining waterproofness/ dustproofness. Opening the cover forcibly may injure your nails or fingers.

･

To prevent damage due to excessive force, the hinge of the inner cover (the section where FOMA terminal makes contacts) is designed to be removed. If it is detached, align metal pins on the inner cover with the slots on FOMA terminal, and then press the cover until it clicks.

Lever

Basic Operation

F-03B_EN_FCC

Before Using

Charging

The battery pack does not have a full charge at time of purchase. Use AC adapter for FOMA terminal to charge the battery before using FOMA terminal.

Using desktop holder and AC adapter in combination for charging

Basic Operation

Insert the AC adapter to the desktop holder, with the arrow on the AC adapters connector upward.

Unfold the AC adapters power plug and insert it into a 100V AC outlet.

With FOMA terminal closed, insert it into the desktop holder.

Check that the light turns on.

After charging is completed, remove FOMA terminal from the desktop holder.

Light AC adapter 100V AC outlet

Release button

Connector

Desktop holder

Power plug

Insert at the back side

Charging using AC adapter

Open jack cap (a) of FOMA terminal, hold the connector horizontally with the arrow side upward and insert it to the jack. (

Unfold the power plug and insert it into a 100V AC outlet.

When charging is over, pull out the power plug from the outlet, and pull out from FOMA terminal horizontally while pressing the release buttons on both sides of the connector.

Connector

Release button

✜

Operations for charging

When charging starts, a charge start alert sounds. While charging, the light turns on and the battery icons on the display and the sub-display blink. When charging is over, a charge completion alert sounds.

External connection jack

)

Jack cap

Light

Power plug

AC adapter

100V AC outlet
