Data Sheet Fujitsu ESPRIMO P910 E85+ Desktop PC
Page 1 / 10 www.fujitsu.com/fts/ESPRIMO
Fujitsu recommends Windows 8 Pro.
Data Sheet
Fujitsu ESPRIMO P910 E85+
Desktop PC
Excellent Performance, Expandability And Energy Efficiency
Fujitsu ESPRIMO P910 PCs give you the absolute highest PC manageability, performance and
expandability. With the 86% efcient power supply, you’ll also save on energy costs. The use of
identical components within the product family ensures perfect infrastructure compatibility. At
retirement, Fujitsu’s distinctive EraseDisk option wipes your data securely
Microtower
Maximum performance and optimal extendability
Top-quality, high-value microtower, 7 drive bays, 4 PCI/PCI express interfaces
Green technology
Fujitsu’s contribution to environmental protection for the continued existence of our planet
Halogen-free printed circuit of mainboard and power supply, sophisticated product concept for the
entire lifecycle
Quiet
Pleasant working environment due to an extremely quiet system
Innovative hardware design, optimized cooling concept ensures silent operations
System management
Simple system administration for complex IT infrastructures
Intel® vPro™ technology (depending on processor) and DeskView manageability tools
Energy efficiency and intelligent performance
Low power consumption combined with top performance
3rd generation Intel® Core™ processor family and a power supply with up to 86% efciency
N
O
R
D
I
C
E
C
O
L
A
B
E
L
Page 2
Data Sheet Fujitsu ESPRIMO P910 E85+ Desktop PC
Page 2 / 10 www.fujitsu.com/fts/ESPRIMO
Fujitsu recommends Windows 8 Pro.
Components
Processor Intel® Core™ i7-3770 processor (4 Cores / 8 Threads, 3.40 GHz, up to 3.9 GHz, 8 MB, Intel® HD Graphics 4000) *
Intel® Core™ i5-3570 processor (4 Cores / 4 Threads, 3.40 GHz, up to 3.8 GHz, 6 MB, Intel® HD Graphics 2500) *
Intel® Core™ i5-3470 processor (4 Cores / 4 Threads, 3.20 GHz, up to 3.6 GHz, 6 MB, Intel® HD Graphics 2500) *
Intel® Core™ i3-3220 processor (2 Cores / 4 Threads, 3.30 GHz, 3 MB, Intel® HD Graphics 2500)
Intel® Pentium® processor G2120 (2 Cores / 2 Threads, 3.10 GHz, 3 MB, Intel® HD Graphics)
Intel® Pentium® processor G2020 (2 Cores / 2 Threads, 2.90 GHz, 3 MB, Intel® HD Graphics)
Intel® Celeron® processor G1610 (2 Cores / 2 Threads, 2.60 GHz, 2 MB, Intel® HD Graphics)
Intel® vPro™ Logo with Intel® Core i5 and Core i7 processors
*with Intel® Turbo Boost Technology (clock speed and performance will vary depending on workload and other
variables)
Intel® Core™ Processor with Intel® Small Business Advantage - Smart Platform for Unmanaged Small Business
Operating systems
Operating system Windows 8 Pro
Windows 8
Windows 7 Professional 64-bit
Windows 7 Professional 32-bit
Windows 7 Home Premium 64-bit
Windows 7 Home Basic 32-bit (EM)
Operating system compatible openSUSE Linux
Windows® XP
Citrix XenClient™ 2
Operating system notes Limited Windows® XP support. Microsoft discontinued Windows® XP certication on system level, basic drivers via
http://support.ts.fujitsu.com
Memory modules 2 GB (1 module(s) 2 GB) DDR3, unbuffered, non-ECC, 1,600 MHz, PC3-12800, DIMM
4 GB (1 module(s) 4 GB) DDR3, unbuffered, non-ECC, 1,600 MHz, PC3-12800, DIMM
8 GB (1 module(s) 8 GB) DDR3, unbuffered, non-ECC, 1,600 MHz, PC3-12800, DIMM
Hard disk notes Up to 20 GB of HDD space is reserved for system recovery
SSHD (Solid State Hard Disk, Hybrid drive)
SSD (Solid State Disk)
SED (Self-Encrypting Drive)
Hard disk drives (internal) SSD SATA III Premium, 128 GB, 2.5-inch
SSD SATA III, 256 GB, 2.5-inch
SSD SATA III, 128 GB, 2.5-inch, SED
SSD SATA III, 128 GB, 2.5-inch
HDD SATA III, 7,200 rpm, 2,000 GB, 3.5-inch
HDD SATA III, 7,200 rpm, 1,000 GB, 3.5-inch
HDD SATA III, 7,200 rpm, 500 GB, 3.5-inch, business critical
HDD SATA III, 7,200 rpm, 500 GB, 3.5-inch
HDD SATA III, 7,200 rpm, 250 GB, 3.5-inch
HDD SATA II, 7,200 rpm, 320 GB, 2.5-inch
HDD SATA II, 5,400 rpm, 320 GB, 2.5-inch
Page 3
Data Sheet Fujitsu ESPRIMO P910 E85+ Desktop PC
Page 3 / 10 www.fujitsu.com/fts/ESPRIMO
Fujitsu recommends Windows 8 Pro.
Graphics NVIDIA® NVS 300, 512 MB
NVIDIA® GeForce® GT630 DisplayPort 2GB FH “0-Watt”, 2 GB
NVIDIA® GeForce® 605 DisplayPort 1GB FH, 1 GB
LFH59/ 2x DVI-I adapter cable
LFH59/ 2x DP adapter cable
DVI to VGA Adapter
DP to DVI-D (single link) Adapter Cable
ATI Radeon® HD7350 1GB FH, 1 GB
2nd NVIDIA® Quadro® NVS 300, 512 MB
Drives (optional) BD Triple Writer SATA slim (tray)
DVD-ROM
DVD Super Multi
MultiCard Reader 24in1 USB 2.0 3.5”
Interface add on cards/components
(optional)
WLAN III, 802.11g/Draft-n (Windows only, dedicated regions only, not for Indonesia)
Parallel Interface
Gigabit Ethernet PCIe x1, DS
eSATA Interface
Dual serial card PCIe x1, powered
Dual serial card PCIe x1
Base unit
Base unit ESPRIMO P910 E85+
Mainboard
Mainboard type D3162
Formfactor μATX
Chipset Intel® Q77
Processor socket LGA 1155
Processor quantity maximum 1
Memory slots 4 DIMM (DDR3)
Supported capacity RAM (max.) 32 GB
Memory frequency 1,600 MHz
Memory notes Dual channel support.
For dual channel performance, a minimum of 2 memory modules have to be ordered. Capacity per channel has to be
the same.
LAN 10/100/1,000 MBit/s Intel® 82579 LM
BIOS version AMI Aptio 4.6
BIOS features BIOS Flash EPROM update by software
Recovery BIOS
Unied Extensible Firmware Interface (UEFI)
Audio codec Conexant CX20642
Audio features Internal speaker supports audio playback, High Denition audio, 5.1 surround sound
I/O controller on board
Serial ATA total 6
thereof SATA III 2
thereof eSATA 2
Page 4
Data Sheet Fujitsu ESPRIMO P910 E85+ Desktop PC
Page 4 / 10 www.fujitsu.com/fts/ESPRIMO
Fujitsu recommends Windows 8 Pro.
I/O controller on board
Controller functions Serial ATA II (3 Gbit)
Serial ATA III (6 Gbit)
NCQ
AHCI
RAID 0/1/5/10 (Windows XP not supported)
Intel® Smart Response Technology (depending on CPU)
Interfaces
Audio: line-in 1
Audio: line-in / microphone 1
Audio: line-out 1
Front audio: microphone 1
Front audio: headphone 1
USB 2.0 total 10
USB 3.0 total 4
USB front 4x 2.0 or 2x 2.0/ 2x 3.0 (optional)
USB rear 6x 2.0 / 2x 3.0
USB internal 2
VGA 1 (via DVI to VGA adapter, part of shipment)
DisplayPort 1
DVI 1 (DVI-I)
Serial (RS-232) 1 (9pin, 16 byte FIFO, 16550 compatible)
Mouse / Keyboard (PS/2) 2
Ethernet (RJ-45) 1
Parallel 1 (optional) (25pin with EPP and ECP)
eSATA 2 (optional)
Interface Module notes Anytime USB charge functionality
Input device / components
Optical USB wheel mouse
Input devices (optional) Optical USB/PS2 tilt wheel mouse
KBPC PX ECO
Mouse M440 ECO
Drive bays
Drive bays total 7
2.5-inch internal bays 1
3.5-inch internal bays 2
3.5-inch external bays 2
5.25-inch external bays 2
Slots
PCI-Express 3.0 x16 1 x (312 mm / 12.29 inch) Full height
PCI-Express 2.0 x4 (mech. x16) 1 x (312 mm / 12.29 inch) Full height
PCI-Express x1 1 x (312 mm / 12.29 inch) Full height
PCI (32-bit / 33 MHz) 1 x (170 mm / 6.7 inch) Full height
Graphics on board
Graphics brand name Intel® HD Graphics, HD Graphics 2000, HD Graphics 2500, HD Graphics 4000 (depending on CPU)
Shared video memory up to 1,759 MB
Page 5
Data Sheet Fujitsu ESPRIMO P910 E85+ Desktop PC
Page 5 / 10 www.fujitsu.com/fts/ESPRIMO
Fujitsu recommends Windows 8 Pro.
Graphics on board
TFT resolution (VGA) 1,024 x 768 pixel
1,280 x 1,024 pixel
1,360 x 768 pixel
1,440 x 900 pixel
1,600 x 900 pixel
1,600 x 1,200 pixel
1,680 x 1,050 pixel
1,920 x 1,080 pixel
1,920 x 1,200 pixel
TFT resolution (DVI) 1,360 x 768 pixel
1,440 x 900 pixel
1,600 x 900 pixel
1,680 x 1,050 pixel
1,920 x 1,080 pixel
1,920 x 1,200 pixel
TFT resolution (DisplayPort) 1,360 x 768 pixel
1,440 x 900 pixel
1,600 x 900 pixel
1,680 x 1,050 pixel
1,920 x 1,080 pixel
1,920 x 1,200 pixel
2,560 x 1,440 pixel
2,560 x 1,600 pixel
Graphics features Dual display support
DirectX® 10.1 or DirectX® 11 (depending on CPU)
HDCP support
Open GL® 3.3 (depending on CPU)
Open CL® 1.1 (depending on CPU)
For multi monitoring mode, graphics card and integrated graphics run in parallel (Microsoft® Windows® 7 or Windows
8)
Graphics notes Tested resolutions, depending on display type additional resolutions and frequencies possible
Shared memory depending on main memory size and operating system
Resolution (color depth up to 32 Bit/pixel)
For TFT we recommend using 60Hz
Electrical values
Power efciency note power supply efciency (at 230V; 20% / 50% / 100% load) : 83% / 86% / 85%
0-Watt mode with hard-off switch
Rated voltage range 100 V - 240 V
Rated frequency range 50 Hz - 60 Hz
Operating voltage range 90 V - 264 V
Operating line frequency range 47 Hz - 63 Hz
Max. output of single power supply 280 W
Power factor correction/active power active
Monitor outlet No
Power consumption
Power consumption note See white paper Energy Consumption
0-Watt mode with hard-off switch
Link to Energy White Paper http://docs.ts.fujitsu.com/dl.aspx?id=7147c0ba-0825-44a1-bcce-5b9adaf6f3a4
Heat dissipation
Heat dissipation notes See white paper Energy Consumption
Noise emission
Related Processors for noise Core i5-3770
Standard noise emission 2x2 GB, HDD, ODD, Windows
According to ISO 7779:2010, ECMA-74
Page 6
Data Sheet Fujitsu ESPRIMO P910 E85+ Desktop PC
Page 6 / 10 www.fujitsu.com/fts/ESPRIMO
Fujitsu recommends Windows 8 Pro.
Noise emission
Standard noise notes / description A-weighted sound power level Lwad (in B) / Workplace related A-weighted sound pressure level LpAm (in dB(A))
Standard noise operation mode: CPU
50% load
3.6 B / 22 dB(A) Bystander; 26 dB(A) Operator position
Standard noise operation mode: HDD
load
3.6 B / 23 dB(A) Bystander; 26 dB(A) Operator position
Standard noise operation mode: Idle
mode
3.4 B / 19 dB(A) Bystander; 22 dB(A) Operator position
Standard noise operation mode: ODD
load
4.6 B / 32 dB(A) Bystander; 37 dB(A) Operator position
Standard noise operation mode: Ofce
applications 2.0
3.4 B / 19 dB(A) Bystander; 23 dB(A) Operator position
Blue angel noise emission according
certication
for max. possible conguration
According to ISO 7779:2010, ECMA-74
Blue angel noise notes / description A-weighted sound power level Lwad (in B); 1B = 10dB
Bystander position
Blue angel noise operation mode: HDD
load
4.0 B = 40 dB
Blue angel noise operation mode: Idle
mode
3.7 B = 37 dB
Blue angel noise operation mode: ODD
load
4.6 B = 46 dB
Dimensions / Weight / Environmental
Dimensions (W x D x H) 175 x 419 x 395 mm
6.89 x 16.5 x 15.56 inch
Operating position Vertical
Weight 11 kg
Weight (lbs) 24.25 lbs
Weight notes Actual weight may vary depending on conguration
Operating ambient temperature 10 - 35 °C (50 - 95 °F)
Compliance
Product ESPRIMO P910
Model MI5W
Germany TÜV GS
Blauer Engel / Blue Angel
Europe CE
Nordic Swan
USA/Canada FCC Class B
cCSAus
Global RoHS (Restriction of hazardous substances)
WEEE (Waste electrical and electronic equipment)
Microsoft Operating Systems (HCT / HCL entry / WHQL)
ENERGY STAR® 5.0 (dedicated regions)
EPEAT® Gold (dedicated regions)
Compliance link http://globalsp.ts.fujitsu.com/sites/certicates
Compatibility (references)
DMI 2.0
PC 2001
WMI 1.5
USB 2.0
SMBIOS
Page 7
Data Sheet Fujitsu ESPRIMO P910 E85+ Desktop PC
Page 7 / 10 www.fujitsu.com/fts/ESPRIMO
Fujitsu recommends Windows 8 Pro.
Additional Software
Additional software (preinstalled) Adobe® Reader® (pdf reader)
Anti Virus software (60 days trial version)
Win7: Fujitsu Recovery (hard disk based recovery)
Win8: Microsoft Push Button Recovery (hard disk based recovery)
Microsoft Ofce (buy license to activate the pre-installed Microsoft Ofce)
Additional software (optional) Recovery DVD for Windows®
Drivers & Utilities DVD (DUDVD)
CyberLink PowerDVD BD (playback software for Blu-ray Disc™)
CyberLink PowerDVD DVD (playback software for DVD)
Nero Essentials XL
Manageability
Manageability technology DeskUpdate Driver management
PXE 2.1 Boot code
Wake up from S5 (off mode)
Intrusion switch (optional)
iAMT 8.0 (depending on CPU)
WoL (Wake on LAN)
Manageability software DeskView Client
DeskView Instant BIOS Management
DeskView Integration for Symantec Management Platform
DeskView components Inventory Management
BIOS Management
Driver Management
Security Management
Alarm Management
Manageability link http://www.fujitsu.com/fts/manageability
Security
Physical Security Kensington Lock support
Eye for padlock
Integrated cabinet lock (optional)
System and BIOS Security EraseDisk (optional)
Boot sector virus protection
Write protect option for the Flash EPROM
Embedded security (TPM 1.2)
Control of all USB interfaces
External USB ports can be disabled separately
Control of external interfaces
User Security User and supervisor BIOS password
Hard disk password
Access protection via external SmartCard reader (optional)
Access protection via internal SmartCard reader (optional)
Miscellaneous
Keyboard on (Special Fujitsu keyboard required)
Thermal management
Serviceability
EasyFix
EasyChange for HDD
EasyChange for optical drives
Packaging information
Packaging dimension (mm) 516 x 278 x 562 mm
Packaging dimension (inch) 20.31 x 10.94 x 22.13 inch
Max. quantity / pallet 24
Material - Weight (g) Carton 1405 g
Material - Weight (lbs) Carton 3.1 lbs
Page 8
Data Sheet Fujitsu ESPRIMO P910 E85+ Desktop PC
Page 8 / 10 www.fujitsu.com/fts/ESPRIMO
Fujitsu recommends Windows 8 Pro.
Packaging information
Material - Weight (g) EPS / PS 160 g
Material - Weight (lbs) EPS / PS 0.35 lbs
Material - Weight (g) PE 60 g
Material - Weight (lbs) PE 0.13 lbs
Packaging notes printed user documentation is bleached in chlorine free process
Warranty
Standard Warranty 3 years (depending on country)
Service level Bring-In / Onsite Service (for countries within region FTS CEMEA&I, for all other countries depending on local
regulations, minimum: 2 years material warranty)
Warranty Terms & Conditions http://support.ts.fujitsu.com/warranty
Maintenance and Support Services - the perfect extension
Recommended Service 9x5, Response Time: Next Business Day
Spare Parts availability 5 years after end of product life
Service Weblink http://www.fujitsu.com/fts/services/support
Recommended Accessories
Display B23T-6 LED The B23T-6 LED offers best ergonomics and usability for intensive ofce
use with a 4-in-1 stand. High resolution for pin sharp pictures with modern
applications
Order Code:
S26361-K1388-V140
Display P24W-6 LED
Enjoy perfect picture quality, outstanding ergonomics and usability as well
as comfortable energy saving solutions of this Fujitsu P Line widescreen
display.
Order Code:
S26361-K1428-V140
Mouse M440 ECO
Fujitsu Mouse M440 ECO is made from 100% bio material and has a
completely PVC free cable. The elegant M440 ECO works on nearly every
surface and follows all your hand movements smoothly and precisely.
It features two main buttons and as well as a scroll wheel providing
comfortable computing to both right and left-handed users.
Order Code:
S26381-K450-L200
SOUNDSYSTEM DS E2000 Air
The new more powerful SOUNDSYSTEM DS E2000 Air gives you impressive,
well-balanced sound throughout the frequency band. It is an unbeatable
USB speaker set with a surprisingly small form factor. The robust satellite
speakers are decorated with a deluxe piano nish and the base is adorned
with warm ambient lighting.
Order Code:
S26391-F7128-L600
Page 9
Data Sheet Fujitsu ESPRIMO P910 E85+ Desktop PC
Page 9 / 10 www.fujitsu.com/fts/ESPRIMO
Fujitsu recommends Windows 8 Pro.
HS E2000 Communicator
Headset
The Fujitsu HS E2000 Communicator headset allows you to use your
personal computer for Voice over IP (VoIP) in stereo audio quality. This
premium headset is designed to provide superb audio quality and comfort
for the telephony, internet chat, speech recognition, video conferencing and
multimedia applications.
Order Code:
S26391-F7139-L5
Keyboard KBPC PX ECO
Fujitsu’s KBPC PX ECO keyboard is the perfect contribution to Green IT. The
keyboard is made out of 45% renewable raw material and comes with a PVC
free USB cable. In addition, the KBPC PX ECO offers rst class comfort and
ergonomics. It attracts attention with its impressive modern design and
useful extras.
S26381-K341-L1** (**:
country specic variation)
Page 10
Data Sheet Fujitsu ESPRIMO P910 E85+ Desktop PC
Page 10 / 10 www.fujitsu.com/fts/ESPRIMO
Fujitsu recommends Windows 8 Pro.
Contact
FUJITSU Technology Solutions
Website: www.fujitsu.com/fts
2014-03-25 CE-EN
Fujitsu OPTIMIZATION Services
In addition to Fujitsu ESPRIMO P910 E85+,
Fujitsu provides a range of platform solutions.
They combine reliable Fujitsu products with
the best in services, know-how and worldwide
partnerships.
Fujitsu Portfolio
Build on industry standards, Fujitsu offers a full
portfolio of IT hardware and software products,
services, solutions and cloud offering, ranging
from clients to datacenter solutions and
includes the broad stack of Business Solutions,
as well as the full stack of Cloud offering. This
allows customers to leverage from alternative
sourcing and delivery models to increase
their business agility and to improve their IT
operation’s reliability.
Computing Products
www.fujitsu.com/global/services/computing/
Software
www.fujitsu.com/software/
More information
Learn more about Fujitsu ESPRIMO P910
E85+, please contact your Fujitsu sales
representative or Fujitsu Business partner, or
visit our website.
www.fujitsu.com/fts/ESPRIMO
Fujitsu green policy innovation
Fujitsu Green Policy Innovation is our
worldwide project for reducing burdens on the
environment.
Using our global know-how, we aim to
contribute to the creation of a sustainable
environment for future generations through IT.
Please nd further information at http://www.
fujitsu.com/global/about/environment
Copyrights
All rights reserved, including intellectual
property rights. Changes to technical data
reserved. Delivery subject to availability. Any
liability that the data and illustrations are
complete, actual or correct is excluded.
Designations may be trademarks and/or
copyrights of the respective manufacturer,
the use of which by third parties for their
own purposes may infringe the rights of such
owner.
For further information see www.fujitsu.com/
terms
Copyright © Fujitsu Technology Solutions
Disclaimer
Technical data are subject to modication and
delivery subject to availability. Any liability
that the data and illustrations are complete,
actual or correct is excluded. Designations
may be trademarks and/or copyrights of the
respective manufacturer, the use of which
by third parties for their own purposes may
infringe the rights of such owner.
More information
All rights reserved, including intellectual property rights. Changes to technical data reserved. Delivery subject to availability.
Any liability that the data and illustrations are complete, actual or correct is excluded.
Designations may be trademarks and/or copyrights of the respective manufacturer, the use of which by third parties for their
own purposes may infringe the rights of such owner.
For further information see www.fujitsu.com/terms
Copyright © Fujitsu Technology Solutions
Loading...
