Operating Manual

FUJITSUTabletSTYLISTICQ50

System

Contact address in North America

FUJITSU AM

1250 East Arques Avenue, Sunnyvale,

CA 94085-3470, U.S.A.

Telephon

"http://solutions.us.fujitsu.com "

"http://solutions.us.fujitsu.com/contact"

Have a qu

FPC65-7889-01

ERICA INC.

e: 800 831 3183 or 408 746 6000

estion? Email us at: "AskFujitsu@us.fujitsu.com"

ujitsu America, Inc. All rights reserved

FUJITSUTabletSTYLISTIC Q50

Operating Manual

Declarations of conformity 7 Fujitsu Contact Information 8 Notational conventions 9 Ports and controls 10 Important notes 13 First-time setup of your device 18 WorkingwiththeTabletPC 22 Accessories for your Tablet PC

(optional) 45 Security functions 61 Connecting external devices 67 Settings in BIOS Setup Utility 72 Troubleshooting and tips 75 Technical data 82 Manufacturer’s notes 87 FCC and IC Regulatory Information 90 Canadian Notice / Avis pour le Canada 94 Appendix 95 Index 108

Fujitsu America, Incorporated has made every e ffort to ensure the accuracy and completeness of this document; however, as ongoing development efforts are continually improving the capabilities of our products, we cannot guarantee the accuracy of the contents of this document. We disclaim liability for errors, omissions, or future changes.

Fujitsu, the Fujitsu logo and STYLISTIC are registered trademarks of Fujitsu Limited or its subsidiaries in the United States and other countries.

Intel and Intel Core are trademarks or registered trademarks of Intel Corporation or its subsidiaries in the United States and other countries.

Microsoft and Windows are either registered trademarks or trademarks of Microsoft Corporation in the United States and/or other countries.

HDMI and HDMI H igh-De¿nition Multimedia Interface and the HDMI Logo are trademarks or registered trademarks of HDMI Licensing, LLC in the United States and/or other countries.

Google is a trademark or registered trademark of Google Incorporated. Bluetooth is a trademark of Bluetooth SIG, Inc., USA. USB Type-C is a trademark or registered trademark of the USB Implementers

Forum in the USA and other countries. USB Type-C is a trademark or registered trademark of the USB Implementers

Forum in Canada and other countries. Adobe, Acrobat, and Adobe Reader are either registered trademarks or trademarks of Adobe

Systems Incorporated in the United States and/or other countries. All other trademarks speci¿ed here are the property of their respective owners.

Contents

Declarationsof conformity ............................................................. 7

Fujitsu Contact Informatio

Notationalconventions ................................................................ 9

Ports andcontrols ..................................................................... 10

Importantnotes ........................................................................ 13

Safetyinstructions ...................................................................... 13

Additional safety notes for devices with wireless component s . . ............................. 14

Protectingthedisplay screen ............................................................ 14

Energysaving .......................................................................... 14

Energy saving u nder Windows ....................................................... 14

Travelingwith your TabletPC ............................................................ 15

Beforeyou travel ................................................................... 15

Transporting theTabletPC ........................................................... 16

Cleaning theTabletPC .................................................................. 17

Furtherinformationon cleaningtheTabletPC ......................................... 17

First-time setu

Unpacking and ch Choose a locatio Connecting th Switching on t

Installing Bo

Workingwith theTablet PC ............................................................ 22

Statusindicators ........................................................................ 23

SwitchingtheTablet PCon .............................................................. 24

Programming theON/OFFbutton ..................................................... 24

SwitchingtheTablet PCoff .............................................................. 25

Handwriting recognition .................................................................. 25

Touchscreen ............................................................................ 26

Selectdisplayorientation(portraitor landscape format) .................................... 27

Touch commands ....................................................................... 27

Calibrate the Dual Digitizer for ¿nger-based operation of the device. ..................... 27

Using thestylus ......................................................................... 28

Styluslocation ...................................................................... 29

Adjustingthestylus .................................................................. 29

Replacingthestylus tip .............................................................. 30

Calibrating the stylus ................................................................ 30

Securing thestylus .................................................................. 31

Tabletbuttons .......................................................................... 32

Webcam ............................................................................... 33

Rechargeablebattery ................................................................... 33

Charging andmaintainingthebattery ................................................. 34

Using thepower-savingfunctions ......................................................... 35

InsertSDmemoryandSIMcard ......................................................... 36

Insertcards ......................................................................... 37

Removecards ...................................................................... 40

Wireless LAN/Bluetooth/ LTE /4Gwireless components .................................. 43

pof your device .........................................................

eckingthe device ......................................................

n .......................................................................

eAC adapter ..............................................................

he device for the ¿rst time ..................................................

nus Apps ................................................................

n ............................................................

18 19 19 20 21

Fujitsu 3

Contents

Switchingthewireless components onand off ......................................... 43

Con¿guringWLANaccess ........................................................... 43

Furtherinformationon WLAN andBluetooth ........................................... 43

Accessvia 4G/LTE ................................................................. 43

Ethernet and LAN (optional, only with cradle, keyboard cover or adapter cable) . . . ........... 44

Accessories for your Tablet PC (optional) . ............................................. 45

Yourdockingcradle(optional) ............................................................ 46

Cradle components . . ................................................................ 46

Settingup the cradle ................................................................ 47

Connecting the Tablet PC to the cradle . . ............................................. 47

Disconnecting the Tablet PC from the cradle . ......................................... 49

Keyboard cover (opt ional) . . . ............................................................ 50

Componentsofthe keyboardcover ................................................... 50

Connecting the Tablet PC to the keyboard cover . . . . . .................................. 51

Separating the Tablet PC from the keyboard cover . . . .................................. 52

3DJHOHIWLQWHQWLRQDOO\EODQN................................................ 53

Protective TPU cover with shoulder strap (optional) . . . . . . .................................. 54

Components of the protective TPU cover . ............................................. 54

Safetynotes ........................................................................ 54

Insert the Tablet PC into the protective TPU cover with shoulder strap ................... 54

Remove the TabletPC from the protective TPUcover .................................. 57

Folio cover(optional) .................................................................... 59

Adapter cable (optional) . ................................................................ 60

Security functions ..................................................................... 61

Con¿guring the ¿ngerprint sensor (con¿guration dependent) . . .............................. 62

Using theSecurityLock(docking -cradle only) ............................................ 63

Con¿guring passwordprotection inBIOSSetup Utility ...................................... 63

Protecting BIOS Setup Utility (supervisor password and user password) . . ............... 63

Password protection for booting the operating system .................................. 65

Password protection for theharddisk ................................................. 66

Connectingexternaldevices ........................................................... 67

Connecting an external monitor . . ........................................................ 67

HDMIport(dockingcradleonly) ...................................................... 67

VGA monitorport(docking cradle only) ............................................... 68

ConnectingUSBdevices ................................................................ 69

USB port withcharging function(USBType-C) ......................................... 70

How toremoveUSB devicescorrectly ................................................ 70

Headphones/microphone/Line-In/Line-Out/headset-combi port .............................. 71

Settings in BIOS Setu p Utility . . ........................................................ 72

Starting theBIOS SetupUtility ........................................................... 72

BIOS Setup Utility operation . ............................................................ 73

ExitingBIOS SetupUtility ................................................................ 74

Exit Saving Ch anges - save changes and exit BIOS Setup Utility . . . . ................... 74

Exit Discarding Changes - Reject changes and exit BIOS Setup Utility ................... 74

LoadSetup Defaults–load default values ............................................. 74

Discard Changes - Discard Changes without exiting BIOS Setup Utility . . . ............... 74

Save Changes - save changes without exiting the BIOS Setup Utility . ................... 74

Save changes and power off ........................................................ 74

Troubleshooting andtips .............................................................. 75

4 Fujitsu

Contents

Executingareset ....................................................................... 76

Forcedshutdown .................................................................... 76

Execute a complete reset: Reset BIOS Setup t o the standard values . . . . . . .............. 76

Helpif problemsoccur ................................................................... 76

If you need to restore your system . ....................................................... 76

The Tablet PC’s date ortimeisincorrect .................................................. 76

Batterychargingindicatornotlit .......................................................... 77

The Tablet PC’s touchscreenremains dark ................................................ 77

The display on the Tablet PC’s touchscreen is dif¿cult to read. . ............................. 77

The externalmonitor remains blank ...................................................... 78

The externalmonitor isblank orthe imageis unstable ..................................... 78

The cursor does not correctly follow the stylus movements . . . . ............................. 78

Stylusinput notworking ................................................................. 79

The Tablet PC does not startafter switchon ............................................... 79

The Tablet PC stopsworking ............................................................. 79

The printerdoesnotprint ................................................................ 79

The wireless connection to a network does not work . . . .................................... 80

The batterydischargestooquickly ........................................................ 80

Error messageson thescreen ........................................................... 81

Technical data ......................................................................... 82

TabletPC .............................................................................. 82

Screenresolutions forintegrated screen andexternal screens .............................. 83

WLAN speci¿cations .................................................................... 84

Rechargeablebattery ................................................................... 85

AC adapter (36 W) for the Tablet PC only (without cradle) . . . . . ............................. 85

Dockingcradle(optional) ................................................................ 85

AC adapter 90 W for the docking cradle (optional) . .................................... 85

Keyboard cover(optional) ............................................................... 86

ProtectiveTPUcoverwithshoulderstrap(optional) ........................................ 86

Folio cover (optional) . . .................................................................. 86

Adapter cables (optional) . . . . . ........................................................... 86

Manufacturer’s notes .................................................................. 87

Disposal andrecycling .................................................................. 87

Recyclingyourbattery ............................................................... 87

DOC (Industry CANADA) Notices ........................................................ 88

UL Notice ........................................................................... 88

ENERGY STARCompliance ............................................................. 89

FCC andIC RegulatoryInformation .................................................... 90

Regulatory Notes and Statement s . ....................................................... 90

Wireless LAN, Health andAuthorization foruse ........................................ 90

Regulatory Information/Disclaimers ................................................... 90

FederalCommunicationsCommissionandIndustryCanada statement: .................. 91

Déclaration d’Industrie Canada ....................................................... 91

FCC Interference Statement ......................................................... 91

FCC Radio Frequency Exposure statement ............................................ 92

Déclaration de la FCC/d’Industrie Canada sur l’exposition aux radiofréquences . .......... 92

Exportrestrictions ................................................................... 92

Restrictionsconcernant l’exportation .................................................. 93

Canadian Notice/Avispourle Canada ................................................. 94

Fujitsu 5

Contents

Canadian Notice . ....................................................................... 94

Avis pour le Canada . . . . . ................................................................ 94

Appendix .............................................................................. 95

Before Using the Optional Wireless LAN . ................................................. 95

Wireless LANDevices Covered bythisDocument ...................................... 95

Characteristicsof theWLAN Device .................................................. 95

Wireless LAN Modes Using this Device . . ............................................. 95

Deactivating/DisconnectingtheWLANDevice ......................................... 98

Con¿guringthe WirelessLAN ............................................................ 98

Connection to the network . . . ........................................................ 98

Troubleshooting theWLAN ........................................................... 98

Using theBluetoothDevice .............................................................. 100

4G Sierra Wireless AirPrime EM7455B Regulatory and Sa fety Information ............... 101

Image Backup and Recovery Procedures ................................................. 104

Windows 10 Procedures . ............................................................ 104

Creating arecoverydrive ............................................................ 104

Recovery options inWindows10 ..................................................... 104

Downloading driver updates . ............................................................ 107

Index .................................................................................. 108

6 Fujitsu

Declarations of conformity

DeclarationofConformity

DECLARATION OF CONFORMITY

according to FCC Part 15

Declarations of conform ity

Responsible Party Name: Address:

Telephone: Declares that product:

This device complies with Part 15 of the FCC rules. Operations are subject to the following two conditions: (1) This device may not cause harmful interference. (2) This device must accept any interference received, including interference that may cause undesired operation. Model ref. of certification: MQ10A

Fujitsu America, Inc. 1250 E. Arques Avenue Sunnyvale, CA 94085 (408)746-6000

Base Model Configuration: STYLISTIC Q50  Complies with Part 15 of the FCC Rules.

1 = Declaration of conformity

Fujitsu 7

Fujitsu Contact Information

Service and Support

You can contact Fujitsu Service and Support in the f ollowing ways:

• Toll free phone: 1-800-8Fujitsu (1-800-838-5487)

• Website: "

Fujitsu Shopping Online

Please go to "

Maintaining Latest Conﬁguration

To ensure that you always have the most current driver updates related to your system, you should occasionally access the Fujitsu Software Download Manager (FSDM) utility. The FSDM utility is available from the Fujitsu S upport site. FSDM will allow you to view a list of the most current drivers, utilities and applications to determine whether you have the latest versions. If you have a Windows operating system, you will need to go to the Support Site to download the FSDM Utility: "

Limited Warranty

Your STYLISTIC Tablet PC is backed by a Fujitsu International Limited Warranty. Check the Limited Warranty Terms and Conditions Booklet that came with your Tablet PC.

http://solutions.us.fujitsu.com/www/content/support/contact/index.php"

Before you place the call, have the following information ready so that the customer support representative can p rovide you with the fastest possible solution:

• Product name

• Product con¿guration number

• Product serial number

• Purchase date

• Conditions under which the problem occurred

• Any error messages that have occurred

• Type of device connected, if any

http://www.shopfujitsu.com/store/ ".

http://support.fujitsupc.com/CS/Portal/suppor t.do?srch=DOWNLOADS".

8 Fujitsu

Notational conventions

Pay particular attention to text marked with this symbol. Failure to observe this warning will endanger your life, will damage the device or lead to loss of data. The warranty will be invalidated if the device becomes defective through failure to observe these warnings.

Indicates important information which is required to use the device properly.

Notational conventions



This style

"This style" indicates

Key

This styl

indicates an activity that must be performed indicates a result

indicates data entered using the keyboard in a program dialogue or at the command line, e.g. your password (Name123)oracommandusedto start a program (start.exe)

indicates information that is displayed on the screen by a program, e.g.:

Installation is complete.

indicates

• terms and texts used in a software interface, e.g.: Click on Save.

• names of program

• Cross-refere

• cross-references to an external source, e.g. a web address: For m ore information, go to "

• names of CDs e.g.: "CD/D

indicates indicate

switch of

sor¿les, e.g. Windows or setup.exe.

nces to another section, e.g. "Safety information"

http://solutions.us.fujitsu.com/"

, DVDs and titles or designations of other materials,

VD Drivers & Utilities"

a key on the keyboard, e.g:

s terms and text that are emphasized or highlighted, e.g.: Do not

f the dev ice

F10

Fujitsu 9

Ports and controls

This chapter presents the individual hardware components of your device. It gives an overview of the indicators and connections of the device. Please familiarize yourself with these items before you start to work with the device.

Front

1

1 = Speaker 2 = Power-on indicator 3 = Touch screen 4 = $PELHQWOLJKWVHQVRU 5 = )URQWZHEFDP 6 = :HEFDPVWDWXV/('EOXH

7 = Battery charging indicator 8 = Mechanical

9 = Docking port 10 = Center ali

cover or cr

attachment for the keyboard

adle

gnment point

10 Fujitsu

Left side

Ports and controls

1 = Tether eyelet 2 = Combined headphones and microphone

port (audio combo jack)

3 = Combined SIM card slot and microSD

slot (protected by cover)

4 = USB 3.0 port (protected by cover)

Right side

6 7



5 = USB 3.1 port Gen 1 port with charging

function (USB Type C; protected

by the cover) 6 = Battery charging indicator 7 = DC input connector (DC IN, protected

by cover)  = )RUFHGVKXWGRZQEXWWRQ

1 = 7HWKHUH\HOHW

Fujitsu 11

Ports and controls

Rear

Screw holes for securing accessories are device-dependent.

1 = Webcam )ODVK 2 = Rear webcam 3 = Webcam VWDWXV/(' 4 = Fingerprint sensor (depending on

con¿guration)

5 = Tether eye

let

6 = Stylus garage 7 = ON/OFF button 8=Volumeup/do 9 = Shortcut button 10 = Dual microp

wn button

hones

12 Fujitsu

Important notes

Importantnote sNotes

Safety instructions

SafetyinformationInformation,

This chapter co ntains essential safety information which must be followed when working with your Tablet PC. The other notes provide useful information about your Tablet PC.

Please observe the following safety information. Please pay special attention to the sections in the manual marked

with the symbol on the left. When connecting and disconnecting cables, observe the relevant

notes in this operating manual. Read the informa tion on the ambient co nditions in the "

chapter and the "First-time setup of your device", Page 18 chapter before preparing your Tablet PC for use and switching it on for the ¿rst time.

When cleaning the device, please observe the relevant notes in the section "

When handling this device, you will come into contact with lead, a chemical which in California is held to be a possible cause of birth defects and other damage to fertility.

Wash your hands after using the device. Do not place the device on uneven or unstable surfaces. Do not place any objects on the device. Do not apply any pressure to the device. Do not use the corners of the disp lay to move it. Turn the display carefully. In d oing so, do not use excessive force. Lift and carry the device by holding it at the bottom and not just at the display. Prevent harsh impacts, vibrations and shaking of the device and the display. On devices with touchscreen: Use very little pressure to carefully

tap and write on the display. Keep the ventilation slots free. Switch off the device before you put it inside a bag or backpack. In emergencies (e.g. damage to the device or power cable, entry of liquids

or foreign objects), immediately switch off the device and disconnect the AC plug. Short circuit, smoke and/or ¿re may occur as a result. Please contact your sales outlet or our Hotline/Service Desk.

Cleaning the Tablet PC", Page 17.

Important notes

Technical data", Page 82

ablet PC complies with the relevant safety regulations for data processing equipment. If

This T

ave questions as to w hether you can set up the Tablet PC in the intended environment,

you h

se contact your sales outlet or our hotline/service desk.

plea

Fujitsu 13

Important notes

Additional safety notes for devices with wireless components

WirelesscomponentsWirelessLANBluetooth,Safetynotes

If a radio component (Wireless LAN, Bluetooth, 4G) is integrated in your Tablet PC, you must be sure to observe the following safety precautions concerning your Tablet PC:

• Switch off the wireless components when you are in an aircraft or driving in a car.

• Switch off the wireless components when you are in a hospital, an operating room or near a medical electronics system. The transmitted radio waves can impair the operation of medical devices.

• Switch off the wireless components, when you let the device get near Àammable gases or into hazardous environments (e.g. gas station, paint stores), as the transmitted radio waves can cause an explosion or a ¿re.

For further information on how to switch the wireless components on and off, refer to section "

Switching the wireless components on and off", Page 43.

Protecting the display screen

Do not pour liquid any items on top o

During normal u can become embe warranty does

If the Tablet P or if the Tabl the LCD scree the device wi

Energy sav

NotesEnergyPowersaving

If you w ill not be using your Tablet PC, switch it off. Switch off any connected external devices when they are not in use. If you use the energy saving functions, the Tablet PC uses less power. If you do this, you will be able to work longe r with the Tablet PC before having to recharge the battery.

The energy ef¿ciency is increased and environmental pollution is reduced. You save money and help protect the environment.

ing

s onto the device or wash it with a heavily soaked cloth. Do not place

f the display in order to prevent it from being damaged.

se of the device, small particles from the environment

dded in the stylus tip and scratch the screen. The

not cover a scratched screen.

C is connected to the optional keyboard cover and is in Clamshell mode

et PC is connected to the optional cradle, never lift or carry the device by

n. Excessive stress can damage the LCD screen. Always lift or carry

th both hands on the base of the keyboard or cradle base.

Energy saving under Windows

Ź Make use of the available energy-saving functions as described in chapter

Using the power-saving functions", Page 35.

14 Fujitsu

Traveling with your Tablet PC

MobileoperationNotesTransportationTa bletPC

Please follow the instructions below when traveling with your Tablet PC.

Before you travel

Backup any important data that is saved on your hard disk.

Tablet PCTravel,TabletPC

Switch off the radio comp

connection, it is also po

onent for data se curity reasons. With data traf¿c via a wireless

ssible for unauthorized third parties to receive data.

Important notes

Information on activat for your radio componen

ing da ta encryption is provided in the documentation

Ź If you want to use your Tablet PC during a Àight, ask the Àight attendants to see if it is safe to use it.

When traveling in other countries

Ź If you are traveling abroad, check that the AC adapter can be operated with the

local AC voltage. If this is not the case, obtain the appropriate AC adapter for your Tablet PC. Do not use any other converter!

Ź Check whether the local AC voltage and the AC cable a re compatible. If this is not

the case, buy an AC cable that suits the local conditions.

Ź Enquire with the appropriate government of¿ce of the country you will be travelling in as to

whether you may operate the radio component integrated in your Tablet PC there.

Ź Take the necessary travel adapters with you when traveling abroad. Check in the following

table for which travel adapters you will need, or ask your trave l organizer.

Power connection Travel destination

United States, Canada, Mexico, parts of Latin America, Japan, Korea, Philippines, Taiwan

Russia and the Commonwealth of Independent States (CIS), much of Europe, parts of Latin America, the Middle East, parts of Africa, Hong Kong, India, much of south-east Asia

United Kingdom, Ireland, Malaya, Singapore, parts of Africa

China, Australia, New Zealand

Fujitsu 15

Important notes

Transporting the Tablet PC

Protect the Tablet PC from severe shocks and extreme temperatures (e.g. direct sunlight in a car).

• Do not transport your Tablet PC while it is turned on.

• Carry your Tablet PC with you while traveling. Do not check it in as baggage.

• Never put your Tablet PC through a metal detector. Have it hand-inspected by security personnel. You can however put your Tablet PC through a properly tuned X-ray machine. To avoid problems, place it close to the entrance of the machine and remove it as soon as possible or have it hand-inspected by security personnel. Security of¿cials may require you to turn your Tablet PC on. So make su re you have a charged battery on hand for this.

Ź Switch the Tablet PC off Ź Unplug the AC plug of the AC adapter and all external devices from the power outlets. Ź Disconnect the AC ad Ź To protect ag ainst d amaging jolts and bumps, use a suitable Tab let PC

carrying case to transport your Tablet PC.

apter cable and the data cables for all external devices.

16 Fujitsu

Important notes

Cleaning the Tablet PC

• Do not clean any interior parts yourself; leave this job to a service technician.

• Only use detergents designed for computers. Normal household cleaners and polishes can damage the labels on the keyboard and the Tablet PC, the paintwork or the Tablet PC itself.

• Never use ammonia, acidic, or alkaline cleaners or organic chemicals such as paint thinner, acetone or kerosene as these may damage surface

nishes and the coating of the LCD screen.

• Use of incorrect cleaners can result in optical impairment of the LCD display screen and / or damage to the tablet PC. Always refer to the cleaner manufacturer’s guidelines and material safety data sheets for proper handling and use of the products.

• Never use compressed air for cleaning your computer.

• Make sure that no liquid can enter the ports or slots because this can cause damage to the Tablet PC.

Further information on cleaning the Tablet PC

The touchscreen is very sensitive to scratches! Only clean the display surface with a v ery soft, slightly damp cloth.

Ź Switch the Tablet PC off.

CleaningInstructionsTablet PCKeyboardTouchpadTouchscreen

Ź To prevent the device from being switched on unintentionally, remove the AC

plug of the AC adapter from the power outlet.

Ź The surfaces may be cleaned with a dry cloth. If particularly dirty, use a cloth which has

been moistened in mild domestic detergent and then carefully wrung out.

If the Tablet PC is exposed to water or other liquids when its connection-ports are open, liquid can penetrate the Tablet PC and cause a malfunction. Do not continue to use the Tablet PC. Switch it off and contact our hotline / our service desk (see enclosed list of service desks or visit our website at: "

Fujitsu 17

http://www.fujitsu.com/us/support/").

First-time setup of your device

First-time setup of your devic

First-timesetupGettingstarted

The battery must be charged if you want to operate your device using the battery. When used on the move, the built-in battery provides the device with the necessary power. You

can increase the operating time by using the available energy-saving functions. For instructions on how to connect external devices (e.g. mouse, printer) to your Tablet

PC, please refer to the operating manual for your device.

Unpacking and c

Please read the chapter "Important notes", Page 13. If your device is equipped with a Windows operating system, the necessary

hardware drivers and supplied software are alread y pre-installed. Beforeswitchingitonforthe¿rst time, connect the device to th e AC voltage using

the AC adapter, see " remain connected during the whole of the installation process.

A system test is performed when your device is ¿rst switched on. Various messages can appear. The display may remain dark for a short time or may Àicker.

Please follow the instructions on the screen. NEVER switch off your device during the ¿rst-time setup process.

Connecting the AC adapter", Page 19. The AC adapter must

hecking the device

If you ¿nd that damage has occurred during transport, please notify your local sales outlet immediately!

Ź Unpack all the individual parts.

PackagingTransport

Ź Check your d

18 Fujitsu

evice for any visible damage which may have occurred during transportation.

You m ay nee you need t

d to reuse the packaging in the future, for example if

o ship your device.

Choosealocation

ChoosealocationSetupACadapter

Choose a suitable location for the device before setting it up. In doing so, p lease follow these instructions:

• Never place the device or the AC adapter on a heat-sensitive surface. The surface could be damaged as a result.

• Never place the device on a soft surface (e.g. carpeting, upholstered furniture, bed). This can result in damage caused by overheating.

• The back of the device heats up during normal operation. Prolonged contact with skin can become unpleasant or even result in burns.

• Place the device on a stable, Àat, non-slippery surface. Please note that the rubber feet of the device may mark certain types of delicate surfaces.

• Keep other objects at least 100 mm / 3.94 inches away from the device and its AC adapter to ensure adequate ventilation.

• Do not expose the device to extreme environmental conditions. Protect the device against dust, humidity and heat.

Connecting the AC adapter

MakingreadytouseACadapter

Please follow the The supplied AC c

you purchased yo useinthecount

safety notes in section "

able conforms to the requirements of the country in which

ur device. Make sure that the AC cable is approved for

ry in which you intend to use it.

First-time setup of your device

Important notes", Page 13.

Ź Connect the AC cable (1) to the AC adapter. Ź Plug the AC cable (2) into a power outlet. Ź Connect the AC adapter cable (3) to the

DC jack (DC IN) of the device.

Fujitsu 19

First-time setup of your device

Switching on the device for the ﬁrst time

Switchingonforthe¿rsttime

To make it easier to use your device for the¿rst time, the operating system is pre-installed on the hard disk.

Ź Press the ON/O F F button (2) for about one second to switch the device on.

The power-on indicator (1) illuminates when the device is switched on.



Ź During the installation process, follow the on-screen instructions.

You ca n ¿nd information and help on the Windows operating system func tions on the Internet at "

20 Fujitsu

http://windows.microsoft.com".

First-time setup of your device

Installing Bonus Apps

BonusApps

The

Fujitsu Bonus Apps

In the

Start

Double-click on the Double-click on the shortcut In the dialog box Select the applications you wish to install by selecting the checkbox adjacent to your selection.

Ź Click Select All if you would like to install all available applicat ions. Applications that are already installed appear in grey, those that are



available for installation appear in blue.

Ź To c o n ¿rm your selection, click Install.

Note that in some cases (depending upon which application was selected for installation) after installation completes, the system will prompt you to reboot.

There are also cases in which if multiple applications are selected to install but one of them needs a reboot, the system will reboot and continue installing the rest of the selected applications.

utility can be accessed via the

menu, click on

Application

Fujitsu Extras

folder.

Fujitsu BonusApps

User Account Control

by clicking

menu.

Start

con¿rm you wish to enter

Yes

Fujitsu Bonus Apps

Fujitsu 21

Working with the Tablet PC

Tablet,operationTablet

This chapter describes the basics for operating your Tablet PC. You can¿nd instructions on how to connect external devices (e.g. mouse,Àash storage) to the Tablet PC in the chapter "

Connecting external devices", Page 67.

Please refer to the notes in the chapter "Important notes", Page 13.

22 Fujitsu

Status indicators

SSytamtubsoilsndicators

tatusindicators(1,2,3,4)provideinformation

powersupply,thebatteryandtheWebCams.

Working with the Tablet PC

aboutthestatusesofthe



No. Status indicato

Description

1 Power-on indi

• The indicator switched on or

• The indicator is not lit up: The Tablet PC is switched off.

2, 3

WebCam indicators, front and back side

• Indicator lights up blue: The corresponding WebCam is switched on while the Tablet PC is switched on.

• The indicator is not lit up: The corresponding WebCam is switched off.

Batterychargingindicator,leftside

Pleasenote:Ifthe ACadapteris connectedwhenthe stateofchargeofthebatteryismorethan9%,charging willnotbestarted.Whenthestateofchargeofthebattery islessthan9%,thebatterywillbechargedto100 soonas theAC adapteris connected.

• The indicator is lit orange: The battery is being charged.

• Indicator is not lit: The battery is not being charged (the battery is already fully charged or the AC adapter is not connected).

cator

lights up white: The Tablet PC is

in sleep mode.

%as

Fujitsu 23

Working with the Tablet PC

Switching the Tablet PC on

Tablet:SwitchingonPower-onPower-onindicator

Ź Press the ON /OF F button (2) for about one second to switch the device on. For further

information, see section " The power-on indicator illuminates (1) when the device is switched on.



Switching on the device for the ¿rst time", Page 20

Programming the ON/OFF button

You can p

Operating system Menu

Windows 10

24 Fujitsu

rogram the ON /OF F button:

Windows 10 Start - Control Panel - (Browse Control Panel - ) Power Options - Choose what the power buttons do

have assigned a password, you must enter this when requested to

If you

, in order to start the operating system. Detailed information can be

do so

d in the chapter "

foun

Security functions", Page 61.

Working with the Tablet PC

Switching the Tablet PC off

Back up your data and close all applications before you switch off your device. Otherwise data might be lost.

Shut down the operating system correctly.

Switchingoff

If the Tablet PC does not switch itself off automatically, press the ON/OFF

button for approx. 5 seconds.

Ź The reset button (force

device, beneath the US achieve the same effec

d shutdown) is located on the left-hand side of the

B port (USB Type C). Press the small reset button to

t as removing the battery.

Handwriting recognition

For detailed information on handwriting recognition, see the documentation for your operating system. At present, handwriting recognition on Windows supports the following languages: English, German, French, Italian, Japanese, Korean, Chinese (traditional and simpli¿ed), Dutch,

Portuguese, Spanish, Brazilian, Norwegian (Bokmål and Nynorsk), Swedish, Finnish, Danish, Polish, Rumanian, Serbian (Cyrillic and Latin script), Catalan, Russian, Czech and Croatian.

On Windows you can set the required language under Control Panel – Time, Language and Region – Language.

Fujitsu 25

Working with the Tablet PC

Touchscreen

Touchsc reenNotes

High-quality LCD screens (TFT) are installed in Fujitsu Tablet PCs. For technical reasons, these screens are manufactured for a speci¿c resolution. An optimal, clear picture can only be ensured in the resolution intended for the particular monitor. A screen resolution which differs from the speci¿cation can result in a blurred picture.

The screen resolution of your Tablet PC’s touchscreen is optimally set at the factory. As per the current state of production technology, an absolutely error-free screen display cannot be

guaranteed. There may be a few consistently brigh t or dark pixels (image elements).

Background lighting

LCD screens are operated with background lighting. The luminosity of the background lighting can decrease over the period of use of the Tablet PC. However, you can set the brightness of your screen yourself.

If the Tablet PC is connected to the optional keyboard cover and is in Clamshell mode or if the Tablet PC is connected to the optional crad le, never lift or carry the device by the LCD screen. Excessive stress can damage the LCD screen. Always lift or carry the device with both hands on the base of the keyboard or base.

Information on the screen resolution can be found in the section "Screen resolutions

for integrated screen and external screens", Page 83.

Ambient light sensor

If your Tablet PC was shipped with the Windows operating system, the screen brightness is regulated by means of the ambient light sensor and depending on the respective light conditions. This results in optimum readability and longer battery life at the same time.

If your Tablet PC was shipped with Windows 10, the ad aptive brightness setting is activated. To change the ambient light sensor settings, select Control Panel - System and Security - Power Options - Change plan settings - Change advanced power settings - Display - Enable adaptive brightness..

Synchronizing the display on the touchscreen and an external mo n i tor

In Windows 10 you can proceed as follows to set the output type:

Ź Wipe your ¿nger over the screen starting from the right-hand edge. Ź Select All settings. Ź Look for the keyword "project". Ź Select the required function.

26 Fujitsu

Working with the Tablet PC

Select display orientation (portrait or landscape format)

LandscapeformatPortraitformatDisplayorientation

You can choose to use either portrait or landscape for the display, or whether the screen orientation should automatically adjust to the orientation of the tablet PC.

You can change these settings under

- Windows Mobility Center / Rotate screen

In the settings there are pro¿les saved fo r operation with different screen orientations. These pro¿les have preset standard c on ¿gurations that can be modi¿ed as desired.

These settings do not just affect the monitor settings on the Tablet PC, but also on external monitors that are connected.

Control Panel - Hardware a nd Sound

Touch commands

You can execute certain commands by using your ¿nger tip on the touchscreen of your device.

Alternatively, everything which you can select or activate using your ¿nger tip can also be selected or activated using the stylus.

Calibrate the Dual Digitizer for ﬁnger-based operation of t

Before the ¿rst ¿nger-based operation, you must calibrate your Tablet PC via the operating system, so that it recognizes your ¿ngertips as accurately as possible.

As soon as you notice that the accuracy is deteriorating, you must recalibrate the device. Please note: There are separate calibration programs available for calibrating

the stylus and for calibrating ¿nger-based operation. Do not use the calibration tool for the stylus to calibrate ¿nger-based operation.

he device.

Operating system Menu

Windows 10

Fujitsu 27

To calibrate, run the Hardware and Sound / Tablet PC Settings function in the Control Panel. You need to calibrate both portrait and landscape format s.

Working with the Tablet PC

Using the stylus

Pen

You can use the stylus on your Tablet PC as an electronic writing tool, to select menu items and to navigate through the programs. Programs that support handwriting recognition also allow you to write directly on the screen with the stylus. You can also use the stylus as a drawing tool.

The Tablet P C is supplied with a stylus tether which you can attach to the eyelets on the stylus and on the Tablet PC.

Use only the stylus that was provided with your Tablet PC. Do not use any other pointed object as a substitute, that was not specially designed for your Tablet PC . Replace the stylus tip if it is wo rn. The warranty does not cover a scratched screen.

While writing, take care that yo u do not scratch the surface of the display (e.g. with a wristwatch or bracelet).

1 = stylus tip 2 = stylus button (right mouse button) 3 = eyelet for stylus tether

The stylus of th if used imprope

Our recommend

• Do not gestur

e Tablet PC is an electronic instrument that can be damaged rly. Handle the stylus with care.

ations for proper handling of the stylus are as follows:

e with the stylus.

• Do not use the stylus as a pointer.

• Do not use th

e stylus on surfaces other than the screen of the Tablet PC.

• Do not try to turn the grip of the stylus. The grip is used to put the stylus into its garage o r to take it out of its garage.

• Never stor pen conta adverse e this cas To avoid

e the stylus with its weight on the tip (e.g. with the tip pointing down in a iner). If the stylus is stored with the tip pointing down, this may have an ffect on the stylus mechanism (particularly under high te mperat ures). In

e the stylus tip may react as though it is constantly being pressed down.

damage, the stylus should be stored in the garage when not in use.

ThestyluscanbeinÀuenced by electromagnetic ¿elds (cursor quivers or jumps). There may be a few areas on the screen where the cursor quivers slightly in spite of pressing the stylus down ¿rmly.

The screen responds to entries made with the tip of the ¿nger or the stylus when the tip of the ¿nger or the stylus directly touches the screen.

You can use the stylus to perform almost all functions for which you would otherwise use a mouse.

28 Fujitsu

Delete functions are not supported by the stylus.

Action Mouse

Selecting menu items

Starting programs Double-click with the left mouse

Moving an object or window

Opening a context menu

Moving the cursor Move the mouse

Click with the left mouse button. Tap on the menu entry with the tip of

button. Drag with the left mouse bu

pressed.

Click with the right m o u

se button.

Stylus location

To prevent the stylus from jamming in its garage, always make sure that you insert the stylus correctly into its garage (the wide side of the stylus should be parallel to the screen of the Tablet PC).

tton

Working with the Tablet PC

Stylus

the stylus. Tap on the program symbol twice in

rapid succession using the stylus tip. Place the stylus tip directly on the

object or window. Keep the stylus tip held against the screen. Drag the desired object or window.

Tap on the desired element with the stylus and ke ep the stylus pressed against the screen.

Place the tip of the st the screen.

ylus directly on

On delivery, the stylus is located in the stylus garage:

Adjusting the stylus

Operating system Menu

Windows 10 Under System Control - Hardware and Sound - Pen and Touch you can make

various settings for the stylus.

Fujitsu 29

Working with the Tablet PC

Replacing the stylus tip

With use, the stylus tip may become worn or may pick up foreign particles that can scratch the screen. A damaged or worn tip may not move freely, causing unpredictable results when using the stylus.

If your stylus exhibits these problems, replace the stylus tip. To do this, use the supplied tool (1).

To remove the tip, position it in the gap

between the two ends of the tool supplied. Pinch the two ends of the supplied tool

together so that the tip is ¿rmly clasped, then pull it from the barrel.

Ź Replace the tip with one of the new tips

that were supplied with your stylus. Insert the Àat end of the tip into the barrel and exerting gentle pressure, push it in until it is ¿rmly in place.

If the tip is worn or damaged, discard it.

Calibrating the stylus

Before ¿rst use with the stylus, you must calibrate your Tab let PC via the operating system, so that it recognizes the stylus as a ccurately as possible.

You should also always repeat the calibration if the co-ordination between the stylus and the cursor movement deteriorates.

Operating system Menu

Windows 10

30 Fujitsu

To calibrat Control Pa

e, run the Hardware and Sound / Tablet PC Settings function in the

nel. You need to calibrate both portrait and landscape formats.

Working with the Tablet PC

Securing the s tylus

Attach the stylus w ith a stylus tether to prevent accidenta lly dropping it or losing it. You device has one eyelet on the left side and one eyelet on the right side for securing the stylus

tether (see "

Ports and controls", Page 10). The tether eyelet on the right side is shown below.

Ź Attach one end of the stylus cord to the stylus and the other end of the stylus cord to the Tablet PC.

Fujitsu 31

Working with the Tablet PC

Tablet buttons

In addition to the ON/OFF button (1), your Tablet PC is¿tted with three tablet buttons.

No. Symbol Description Functions

2 3 4

+ –

–––

Volume + button Increase volume Volume - button Decrease the volu Shortcut button Call the status area by pressing or start a

screenshot function by a long press (depends on con¿guration)

32 Fujitsu

Webcam

Your device has two WebCams: one on the front of the device and one on the rear.

Working with the Tablet PC

The webcams have their own s when the respective webcam

Depending on the software record video clips or take

• The picture quality depe

tatus indicators. The status indicators light up

sareactive.

used, you can use your webcam to take pictures,

part in web chats.

nds on the lighting conditions and the software being used.

• You can only operate the webcam with a particular application (e.g. an Internet telephony program or a video conferencing program which supports a webcam).

• When using the webcam th

e support of the Tablet PC must not wobble.

• The webcam automatically adjusts itself to the current light level. For this reason, the touchscreen may Àicker while the light level is adjusted.

Further information on use of the webcam and additional settings for your webcam can be found in the help function of the program using the webcam.

Rechargeable battery

BatteryBatteryServicelife,batteryRech argeablebatteryBattery

The built-in battery provides the Tablet PC with the necessary power for use on the move. You can increase the service life of the battery by caring for the battery properly. The average battery service life is around 500 charge/discharge cycles.

You can extend the battery service life by taking advantage of the available energy-saving functions.

Fujitsu 33

Working with the Tablet PC

Charging and maintaining the battery

BatteryBattery

The Tablet PC battery can only be charged when the ambient temperature is between 5°C / 41 °F and max. 35°C / 95°F.

You can charge the battery by connecting the Tablet PC to the AC adapter

Connecting the AC adapter", Page 19).

(see " If the battery is running low you will hear a warning alarm. If you do not connect the AC adapter

within¿ve minutes of hearing the warning alarm, your Tablet PC will switch off automatically.

Monitoring the battery state of charge

Batterybatterychargemeter

A battery symbol for monitoring the battery capacity is displayed in the system bar / status indica tor. The battery sy mbol shows you the battery charge.

Battery storage

tery

tery BatteryBatterySelf-discharge,bat

Chargecapacity,bat

The battery should be stored in a dry enviro nment at a temperature between 0°C / 32°F and 30°C / 86°F. The lower the storage temperature, the lower the rate of self-discharge.

If you will be storing batteries for a longer period (more than two months), the battery charge level should be approx. 30%. To prevent exhaustive discharge which would permanently damage the battery, check the level of charge of the battery at regular intervals.

To be able to make use of the optimum capacity of the battery, you should allow the battery to fully discharge and then recharge it.

If you do not use the batteries for long periods, remove them from the Tablet PC. Never store batteries in the device!

34 Fujitsu

Working with the Tablet PC

Using the power-saving functions

EnergyPowerBattery

The Tablet PC uses less power when the power-saving functions are enabled. You will then be able to work longer when using the battery before having to recharge it.

The energy ef¿ciency is increased and environmental pollution is reduced. By cho osing the best power options, you can make signi¿cant savings and at the same time help protect the environment.

Ź Set the power-saving fun

ctions in your Control Panel.

When the Tablet PC is in a power-saving mode, you m ust remember the following:

During power-saving mode, open data is held in main memory or in a swap ¿le on the hard disk.

Never switch off the Tablet PC while it is in a power-saving mode. If the built-in battery is nearly Àat, close all open ¿les and do not go into po wer-sa ving mode.

If you do not intend to u se your Tablet PC for a long period of time:

Ź Exit the power-sav

ing mode if necessary by touching the screen or by switching the Tablet

PC on.

Ź Close all opened programs and completely shut down the Tablet PC.

Fujitsu 35

Working with the Tablet PC

Insert SD memory and SIM card

Whether your device has a SIM card slot depends on whether you have ordered 4G fun ctionality.

With an applicable device con¿guration, the SIM card slot is located above the SD memory card slot.

SD Memory cards

Slot

Your Tablet PC is equippe memory cards to enlarge

The following formats a

• Micro Secure Digital (

• Micro SDHC

•MicroSDXC

d with an integrated SD memory card reader. Use SD

the storage of your Tablet PC.

re supported:

Card)

Follow the manufac

Memorycard

turer’s instructions when handling the SD memory cards.

SIM cards (optional)

A SIM Card (Subscriber Identity Module) is a chip card which is inserted in a cellular phone or Tablet PC and, together with an integrated 4G/LTE module, enables access to a cellular radio network.

Follow the instructions supplied by the provider of the SIM card. If you do not feel the the SIM card engage as you insert it, use a pointed object to insert the SIM card.

Please note that the SIM card format must be nano-SIM (4FF). Other SIM card formats, such as full-size (1FF) or mini-SIM (2FF) do not ¿t in the SIM card slot of your Tablet PC.

Please do not insert any other format of SIM card as they may become twisted, they could even damage the system.

36 Fujitsu

Insert cards

Working with the Tablet PC

Ź Open the SD memo

ry and SIM card slot cover (1).

Fujitsu 37

Working with the Tablet PC

Inserting SD memory card

Ź Carefully slide the SD memory card into the upper slot (2). The label area must be facing

downward. Do not ap ply any force, otherwise the delicate contact surfaces could be damaged.

Memorycard

Inserting SIM card (optional)

Ź Pull the SIM card carrier out of its lower slot location (2).

ce the SIM card (3) in the SIM card carrier as shown.

Ź Pla Ź Slide the SIM card carrier back into its location (4).

38 Fujitsu

Ź Close the SD memory and SIM card slot cover (5).

Working with the Tablet PC

Fujitsu 39

Working with the Tablet PC

Remove cards

Memorycard

To avoid any loss of data, always follow the correct procedure for removing the cards (see the documentation for your operating system).

Ź Open the SD memory and SIM card slot cover (1).

40 Fujitsu

Working with the Tablet PC

Removing SD memory card

Ź Press the edge of the SD me mory card in ¿rmly and release, so that it

jumps slightly out of the upper slot (2).

Ź Pull the SD mem

Removing SIM card (optional)

ory card out of the slot (3).

Ź Remove the SIM card carrier from its location (2).

Fujitsu 41

Working with the Tablet PC

Remove the SIM card from the SIM card carrier (3).

Push the SIM card carrier back into its lower mounting slot (4).

Ź Close the SD memo ry and SIM card slot cover (5).

42 Fujitsu

Working with the Tablet PC

Wireless LAN / Bluetooth / LTE / 4G wireless components

The installation of radio components not approved by Fujitsu will invalidate the certi¿cations issued for this device.

Switching the wireless components on and off

The wireless componen ts are switched on and off u sing the appropriate functions of the operating system.

Ź To switch wireless components on and off individually, select Settings –

Network & Internet – Airplane Mode.

Conﬁguring WLAN access

• Requirement: A WLAN is available and you have the necessary access data on hand.

Information on con¿guring WLAN access can be found in the documentation for your operating system.

Further information on WLAN and Bluetooth

For further information about WLAN or Bluetooth, please refer to the appendix of this Operating Manual.

For WLAN speci¿cations, see chapter "

Access via

The embedded WWAN module option is not available for all products in all regions and requires network support as well as a separately purchased cellular rad io contract.

Please contact your cellular radio network provider about network coverage and availability. Connection speeds vary according to location, surroundings, network connections and other factors.

You c an ¿nd information on setting up an Internet connection with the 4G network in the hardware documentation (the Quick Start Guide).

The device has a 4G Sierra Wireless Air Prime EM7455B wireless WAN module.

4G / LTE

WLAN speci¿cations", Page 84.

Fujitsu 43

Working with the Tablet PC

Ethernet and LAN (optional, only with cradle, keyboard cover or adapter cab

EthernetLAN

You can use the optionally available accessories to establish a connection to a local network (LAN = Local Area Network).

Your network administrator can help you to con¿gure and use the LAN connections. The network cable is not included in the delivery scope. This type of

cable can be ob tained from a specialist dealer. Use a shielded network cable (CAT 5e).

le)

Connect the network cable to the L AN

port of the accessory (1). Connect the network cable t o your

network connection (2).

44 Fujitsu

Accessories for your Tablet PC (opti

onal)

Accessories for your Tablet PC

The following accessories are available for your Tablet PC:

• DockingcradleforchargingtheTabletPCwithadditionalports

• KeyboardcoverwithLANport

• ProtectiveTPUc

• Foliocover

• Adaptercable(USBType-CtoHDMI,USB Type-CtomicroHDMI,FullUSB toLAN) Thefollowingsectionsprovide more information onhandlingtheaccessories.

overwithshoulderstrap

(optional)

Fujitsu 45

Accessories for your Tablet PC (opti

onal)

Your docking cradle (optional)

As well as fast charging, your docking cradle is a device that also allows you to quickly connect your Tablet PC to you r peripherals such as a monitor, keyboard, mouse, etc. You only need to dock the Tablet PC to be able to work with your peripheral devices.

Cradle components

PortsPortsCradle

1 = Dock release button 2 = Status LED 3 = Connector on the cradle for the docking

port of the Tablet PC 4=USB3.0port 5 = VGA monitor port

ThestatusLED(2)ofthecradlelightsupassoonasitisconnected to the power supply and the Tablet PC is connected to the powered cradle, even if the Tablet PC is switched off.

TheLANportonthecradlesupportsWake-On-LANfortheSTYLISTICQ50(G3 only).

Two additional external monitors can be operated with the STYLISTIC Q50 eitheron the external monitor port (VGA) or on the HDMI port of the cradle. Simultaneous operation of two external monitors is supported (see "Screen

resolutions

forintegratedscreenandexternalscreens",Page83).

6 = HDMI port 7 = LAN port 8 = Security Lock device 9 = DC jack socket (DC IN)

46 Fujitsu

Accessories for your Tablet PC (opti

Settingupthecradle

Select a suitable location for the cradle before setting it up. In doing so, p lease follow these instructions:

• PlacethecradleonaÀat, stable, non-slippery surface.

• Never place the cradle or the AC adapter on a heat-sensitive surface.

• Do not expose the cradle to extreme environmental conditions.

• Protect the cradle from dust, moisture and heat.

Connecting the Tablet PC to the cradle

It is possible to connect the Tablet PC to the cradle while it is running. Disconnect the AC adapter from the Tablet P C before connecting

the Tablet PC to the cradle.

onal)

When the Tablet PC i to the cradle, to be

Cradle

Ź Remove the AC plug of the AC adapter from the power outlet. Ź Remove the AC adapter cable from the DC jack (DC IN) of the Tablet PC.

s connected to the cradle, you must connect the AC adapter

able to use all the cradle’s functions.

Fujitsu 47

Accessories for your Tablet PC (opti

onal)

Ź Position the Tablet PC so that it lies against the storage surface of the cradle. Ź Push the Tablet

on the connect

Your cra dle is sure that you

Ź Plug the AC adapter cable into the DC jack (DC IN) on the cradle (2). Ź Connect the AC cable to the AC adapter (3). Ź Plug the AC cable into the power outlet (4).

PC onto the cradle in the direction of the arrow (1) until you feel it engage

or and until the slide-out position returns to its original position.

supplied with a separate AC adapter (19 V, 4.74 A). Make

only use this AC adapter for the cradle.

48 Fujitsu

Accessories for your Tablet PC (opti

Disconnecting the Tablet PC from the cradle

It is possible to separate the Tablet PC from the cradle while it is running.

onal)

Ź Press the slide-out button in the direction of the arrow ( 1) until it ¿rmly

remains in pressed position (red marking visible).

Ź While holding down the lower part of the cradle, lift the tablet PC f rom

the cradle in the direction of the arrow (2).

Fujitsu 49

Accessories for your Tablet PC (opti

onal)

Keyboard cover (optional)

The keyboard cover is an optimized device for the convenient input of text. It only needs to be docked with the Tablet PC.

Components of the keyboard

KeyboardcoverPorts

1 = Release button 2 = Docking port for the Tablet PC

cover

3 = LAN port

50 Fujitsu

Accessories for your Tablet PC (opti

Connecting the Tablet PC to the keyboard cover

Keyboardcover

To prevent damage to the system, never fold the Tablet PC on the keyboard cover if the Tablet PC is in the protective TPU cover.

Do not attach the optional keyboard cover to the Tablet PC and do not join both components together on the protective TPU cover. The keyboard cover and/or the tablet PC could be damaged.

onal)

Ź Press the s

lide-out button (1) until it remains in the pressed position (red marking visible).

Ź Push the Tablet PC onto the keyboard cover in the direction of the arrow until you feel it engage

on the connector (2) and until the slide-out button returns to its original position.

Fujitsu 51

Accessories for your Tablet PC (opti

onal)

Separating the Tablet PC from the keyboard cover

Ź Press the slide-out button (1) until it remains in the pressed position (red marking visible). Ź Lift the Tablet PC away from the keyboard cover in the direction of the arrow (2).

52 Fujitsu

Accessories for your Tablet PC (opti

7KLVSDJHOHIWLQWHQWLRQDOO\EODQN

onal)

Fujitsu 53

Accessories for your Tablet PC (opti

onal)

Protective TPU cover with s houlder strap (optional)

Components of the protective

The protective TPU Cover accessory options package with shoulder strap contains the following components:

1. Protective TPU cover

2. Shoulder strap

3. Fujitsu warranty document

4. Accessory operating in

TheprotectiveTPUcov keyboard cover and doc

structions

er with shoulder strap is not compatible with the

king cradle accessory compone nts.

TPU cover

Safety notes

• Make sure the device is ¿tted into the TPU cover properly in order to prevent it from falling out.

• Keep the protective TPU cover away from heaters and direct sunlight.

• Do not wash the protective TPU cover. If it gets dirty, remove the protective TPU

cover from the Tablet PC, dampen a cloth with water, squeeze it well, wipe off the dirt using the cloth and then wipe with a dry cloth.

• Do not use solvents such as benzine, thinner, alcohol, household detergents,

or chemically treated cloths.

• If the protective TPU cover gets wet, wipe off the moisture with a dry cloth and

keep it in a shaded area until completely dry.

Insert the Tablet PC into the protective TPU cover with

shoulder strap

Ź If attached, remove the AC plug for the AC adapter from the power outlet and the tablet. Ź Switch th Ź Make sure that the terminal cover and the slot cover are tightly closed. Ź If attac

54 Fujitsu

e Tablet PC off.

hed, remove the pen tether from the tablet

Accessories for your Tablet PC (opti

onal)

Ź Pass the tether through either hole of the TPU cover and re-attach it to the tablet.

Ź Insert the tablet upper left corner (1). Ź Inse

rt the tablet in the direction of the arrow (2) and snap it into the upper right er (3) and the lower right side (4) of the TPU cover.

corn

Fujitsu 55

Accessories for your Tablet PC (opti

onal)

Ź Install the lower left side (5) of the TPU cover onto the tablet.

Ź If required, secure the shoulder strap (6) at two of the protective TPU cover’s four holders (a). Ź Adjust the length of the shoulder strap.

56 Fujitsu

Accessories for your Tablet PC (opti

Remove the Tablet PC from the protective TPU cover

If attached, remove the AC plug for the AC adapter from the power outlet and the tablet.

Switch the Tablet PC off.

If attached, remove the shoulder strap.

onal)

Ź Remove the tablet from the underside of the TPU cover by remo ving the lower

right side ¿rst (1) a nd then the lower left side (2).

Fujitsu 57

Accessories for your Tablet PC (opti

onal)

Ź Hold the tablet and TPU cover vertically and press the upper left side of the TPU cover (3)

and move the upper right side of the tablet (4) in the direction of the arrow.

Ź Once the TPU co

the tether out

ver is removed, the tether can be un-attached from the tablet. Slide

of the TPU cover hole and re-attach it to the tablet.

58 Fujitsu

Folio cover (optional)

The folio cover is not compatible with the keyboard cover and docking cradle accessory components. To prevent damage, do not connect the Tablet PC to these accessories.

• This folio cover contains magnets. Keep it away from objects that may be affected by the inÀuence of magnetism, e.g. pacemakers and magnetic cards.

• Please note that the LCD screen may be accidentally turned on when touched if the device is in its folio cover.

• Make sure the un it is ¿rmly ¿tted into the folio cover fasteners so it will not fall out.

• This folio cover is only designed to safely store and carry this unit. Do not use the folio cover for any other purpose.

• Keep the folio cover away from ¿re or heaters.

• Do not place the folio cover in direct sunlight or exp ose it to high temperature or humidity.

Accessories for your Tablet PC (opti

onal)

Ź Positi

Ź Allow the tablet PC to click into place in the fo lio cover (2).

The fo

Fujitsu 59

on the Tablet PC with the touchscreen (1) facing upwards and with the docking-port acing forwards in the corner of the folio cover.

side f

llowing illustration shows you the many ways in which the folio cover can be used:

Accessories for your Tablet PC (opti

onal)

Adapter cable (optional)

3 adapter cables are available for your device:

• USB Type-C to HDMI

•USBType-Ctomi

• Full-USB-to-LAN: LAN Conversio

For technical speci¿cations, see chapter"

croHDMI

n Cable Kit: 1 x USB-to-LAN (GbE, limited performance)

Adapter cables (optional)", Page 86.

60 Fujitsu

Security functions

Securityfunctions

You r Tablet PC has several security features t hat you can use to secure your system and your personal data from unauthorized access.

This chapter explains how to use these functions, and what the bene¿ts are.

Please remember that in some cases, for example, forgetting your password, you may be locked out of the system and unable to access your data. Therefore, please note the following information:

• Back up your data on external data carriers at regular intervals.

• Some security functio of the passwords and ke

If you forget your passwords you will need to contact our Service Desk. Deletion or resetting of passwords are not covered by your warranty and a charge will be made for assistance.

ns need you to choose passwords. Make a note

eptheminasafeplace.

Fujitsu 61

Security functions

Conﬁguring the ﬁngerprint sensor (conﬁguration dependent)

FingerprintsensorFingerprint s ensor

Whether your device has a¿ngerprint sensor or not depends on the device con¿guration which you ordered.

The¿ngerprint sensor ca software, this image can

Ź Install the ¿ngerprint software to be able to use the ¿ngerprint sensor (1).

n record the image of a¿ngerprint. With additional¿ngerprint

be processed and used instead of a password.

62 Fujitsu

Security functions

Using the Security Lock (docking - cradle only)

SecurityLockAnti-theftprotectionSecurityLock

You r docking cradle (optional) is equipped with a S e curity Lock device for a Kensington Lock Cable. You can use the Kensington Lock Cable, a sturdy steel cable, to protect your docking

- cradle against theft. The Kensington Lock Cable is available as an accessory. Fit the Kensington Lock Cable to the

attachment point on your - docking cradle.

Conﬁguring password protection in BIOSSetup Utility

Before using the various options for password protection in the BIOS Setup Utility, please proceed as follows to increase data security:

Make a note of the passwords and kee p them in a safe place. If you forget your supervisor password you will not be able to access your Tablet PC. Passw ords are not covered by y our warranty and a charge will be made for assistance.

ection

Passwordprot

Your password can be up to 32 characters long and can contain letters, numbers and special characters. A distinction is made between upper and lower case .

Protecting BIOS Setup Utility (supervisor password and user password)

If you ha ve opened these operating instructions on the screen, we recommend that you print them out. You cannot call up the instructions on the screen while you are setting up the password.

tupUtility

BIOSSe

The supervisor password and the user password both prevent unauthorized use of the BIOS

Setup Utility. The supervisor password allows you to access all of the functions of the BIOS Setup Utility, while the user password will only give you access to some of the functions. You can

only set up a user password if a supervisor password has already been assigned.

Calling and using the BIOS Setup Utility is described in the chapter

Settings in BIOS Setup Utility", Page 72.

Fujitsu 63

Security functions

Assigning the supervisor and user passwords

Start the

Select the

With



Enter the password and press the Enter key.

Conﬁrm new Password



Enter the password again and press the Enter key.

Changes have been saved is displayed as a con¿rmation that the new password has been saved.



BIOS Setup Utility

Set Supervisor Password ¿

Enter n ew Password

and go to the

Security

menu.

eld and press the Enter key.

: you are asked to enter a password.

requires you to con¿rm the password.

Ź To set the user password, select Set User Password and proceed exactly as

when con¿guring the supervisor password. If you do no t want to change any other settings, you can exit BIOS Setup Utility.



Ź In the Exi t menu, select the option Save Changes & Exit. Ź Select Yes and press the Enter key.

PasswordSupervisor passwordUserpassword

The Tablet PC is rebooted and the new password is effective. It will now be necessary to



¿rst enter your supervisor or user password in order to open the BIOS Setup Utility. Please note that the user password only provides access to a few of the BIOS settings.

Changing the supervisor password or user password

You can only change the supervisor password when you have logged into the BIOS Setup Utility with the supervisor password.

PasswordSupervisorpasswordUserpassword

Ź Start the BIOS Setup Utility and go to the Security menu. Ź When changing the password, proceed exactly as when assigning a password.

Removing passwords

To re move a password (without setting a new password) perform the following steps:

password

rd PasswordSupervisor

Userpasswo

Ź Start the BIOS Setup Utility and go to the Security menu. Ź Highlight the Set Supervisor Password or Set U ser Password ¿eld and press the Enter key.

You will be requested to enter the current password by the Enter Current Password promp t.



Enter New Password will appear and you will be requested to enter a new password.

Ź Press the Enter key twice at this request. Ź In the Exi t menu, select the option Save Changes & Exit. Ź Select Yes and press the Enter key.

The Tablet PC is rebooted and the password is removed.



Removing the supervisor password simultaneously deactivates the user password.

64 Fujitsu

Security functions

Password protection for booting the operating system

With the supervisor password you have set in the section " also prevent booting of the operating system.

Operatingsystem

Assigning the supervisor and user passwords", Page 64), you can

BIOS Setup Utility

(see

Activating system protection

Start the

Operatingsystem

Select the

BIOS Setup U tility

PasswordonBoot

Ź Select the option you require (Disabled, First Boot or Every Boot) and press the enter key Ź Select the Save Changes & Exit option under Exit.

The Tablet PC reboots. You will be p rompted to enter your password (the supervisor password).



andgotothe

Security

menu.

option and press the Enter key.

Deactivating system protection

Ź Start the BIO S Setup Utility andgototheSecurity menu.

Operatingsystem

Ź Select the PasswordonBootoption and press the Enter key. Ź Select the Disabled option and press the Enter key.

If you do not want to change any other settings, you can exit BIOS Setup Utility.



Ź Select the Save Changes & Exit option under Exit.

The Tablet PC reboots. The system is no longer password-protected.



Fujitsu 65

Security functions

Password protection for the hard disk

Passwordprotection

Activating hard disk protection

The hard-disk password prevents unauth orize d access to the hard disk drives and is checked internally each time the system is booted. The prerequisite condition for this is that you have, as a minimum, assigned the supervisor password.

Call up the

If you have not assigned BIOS passwords yet, de¿ne the supervisor and the user



password now, if desired (see "

Ź Mark the Hard Disk Security ¿eld and press the Enter key. Ź In the area Drive0, mark the ¿eld Set Master Password and press the Enter key.

Enter new Password then appears and you are asked to enter a password.



Ź Enter the password and press the Enter key.

Conﬁrm new Password requires you to con¿rm the password.



Ź Enter the password again and press the Enter key.

With Setup Notice: Changes have been saved you receive con¿rmation that



the new password has been saved.

Ź If you wish to enter a password for a second hard disk (Drive1), in the area

Drive1 mark the ¿eld Set Master Password and proceed in exactly the same way

as for the set up of the ¿rst hard disk (Drive 0). The ¿eld Password Entry on Boot is set to Enabled by default. You can exit the BIOS



Setup once you have ¿nished changing the settings.

Ź From the Exit menu, choose the option Exit Saving Changes. Ź Press the Enter key and select Yes.

The Tablet PC reboots and your hard disk is now protected with a password. The



password prompt is enabled as soon as the Tablet PC has rebooted.

BIOS Setup

and select the

Security functions", Page 61).

Security

menu.

Deactivating hard disk protection

To cancel a password (without setting a new password) proceed as follows:

Ź Call up the BIOS Setup and select the Security menu. Ź Mark the Hard Disk Security ¿eld and press the Enter key. Ź In the area Drive0, mark the ¿eld Set Master Password and press the Enter key.

With the prompt Enter current Password you are ¿rst asked to enter the old password again.



With Enter new Password you are then prompted to enter a new password.

Ź After the request, press the Enter key three times. Ź From the Exit menu, choose the option Exit Saving Changes. Ź Press the Enter key and select Yes.

The Tablet PC reboots and there is no longer any password protection for this hard disk.



Ź Ifyouwishtoremoveapasswordforasecondharddisk(Drive1), in the area

Drive1 mark the ¿eld Set Master Password and proceed in exactly the same way

as for the removal of the ¿rst hard disk (Drive0).

66 Fujitsu

Connecting external devices

Under all circumstances, please observe the safety notes provided in the

Important notes", Page 13 cha pter before connecting or disconnecting

any devices to or from your Tablet PC . Always read the documentation supplied with the device you wish to connect. Never con nect or disconnect cables during a thunderstorm. Never pull a t a cable when disconnecting it. Always grasp the plug.

With some devices, such as USB devices, it is not necessary to switch off the Tablet PC and the device before connecting/disconnecting. For more information about whether or not devices need to be switched off, please refer to the documentation supplied with your external device.

Some of the external devices require special drivers (see the operating system and external device documentation).

Connecting an external monitor

HDMI port (docking cradle only)

HDMIport

The HDMI port of the docking cradle can be used to connect an external ampli¿er, LCD TV or a plasma TV with an HDMI connection.

Ź Connect the data cable to the

external device.

Ź Connect the data cable to the HDMI port.

Fujitsu 67

Connecting external devices

VGA monitor port (docking cradle only)

An analog monitor is connected to the analog VGA monitor port. Screen output is limited to a maximum of two screens at the same time.

MonitorVGA portScreenconnectionMonitorconnection

Switch off the Tablet PC and the

external monitor. Plug the data cable of the external

monitor into the monitor port. First switch on the external monitor and

then switch on the Tablet PC.

You can also switch back and forth between the external monitor and the LCD screen of the Tablet PC, see "

Touchscreen", Page 26.

You can display the same image on the external monitor and on the LCD screen of the Tablet PC at the same time.

68 Fujitsu

Connecting external devices

Connecting USB devices

USBports

On the USB ports you can connect external devices that also have a USB p ort (e.g. a DVD drive, a printer, a scanner or a modem).

USB devices are hot-pluggable. This means you can connect and disconnect the cables of USB devices while the operating system is running.

USB 1.x has a maximum data transfer rate of 12 Mbps. USB 2.0 has a data transfer rate of up to 480 Mbps. USB 3.0 has a data transfer rate of up to 5 Gbps. USB 3.1 generation 1 has a data transfer rate of up to 5 Gbit/s. USB 3.1 generation 2 has a data transfer rate of up to 10 Gbit/s. Additional information can be found in the documentation for the USB devices.

Device drive

USB devices w

Ź Connect the data ca

ble to the

external device.

Ź Connect the data cable to a USB port

on the Tablet PC or cradle.

ill be automatically recognized and installed by your operating system.

Fujitsu 69

Connecting external devices

USBportwithchargingfunction(USBType-C)

USBportwithchargingfunction(USBType-C™)

You can also charge a connected USB device or operate devices without an additional power supply at this USB port.

This is also possible with the Tab let PC switched off, if the function is activated in the how to call up and use the

USB devices are hot-pluggable. This means you can connect and disconnect the cables of USB devices while the operating system is running.

Additional information can be found in the documentation for the USB devices.

Advanced - Miscellaneous Conﬁgurations

BIOS Setup Utility

,seeSection"

USB Type-C Power Delivery on System Off

menu of t he

Settings in BIOS Setup Utility", Page 72.

Ź Connect the data cable to the

external device.

Ź Connect the data cable to a USB port

(USB Type-C) on the Tablet PC.

BIOS Setup Utility

.For

How to remove USB devices correctly

Always correctly remove the device according to the rules described below, to ensure that none of your data is lost.

Ź Tap the symbol for safe removal of the hardware. Ź Select the device you wish to shut down and remove. Ź Tap OK.

Wait for the dialog box which tells you that it is now safe to remove the device.



70 Fujitsu

Connecting external devices

Headphones/microphone/Line-In/Line-Out/headsetcombi port

ConnectingaudiodevicesAudioconnectionsConnectingheadphones

Using the headphone/microphone/Line-In/Line-Out/headset-combi port, you can connect a headset, headphones, a microphone or external loudspeakers to your Tablet PC.

Connect the audio cable to the

external device. Connect the audio cable to the headphone

port of the Tablet PC. The internal speakers are disabled.



If you purchase a cable from a ret ailer, please note the following informa tion: The headphone/microphone/Line-In/Line-Out/headset-combi port on your

Tablet PC is a "3.5 mm jack socket". If you want to connect headpho nes or speakers you will need a "3.5 mm jack plug".

Fujitsu 71

Settings in BIOS Setup Utility

BIOSSetupUtilitySystemsettings,BIOSSetupUtilityCon¿guration,BIOSSetupUtilitySetupCon¿guringsystemCon¿guringhardware

To navigate more easily in the

BIOS Setup Utility

, you can use an external USB keyboard.

The

BIOS Setup Utility

con¿guration for the Tablet PC. When the Tablet PC is delivered, the default settings are effective. You can change

these settings in the menus of the BIOS Se tup Utility. Any changes you make take effect as soon as you save and exit the BIOS Setup Utility.

The BIOS Setup Utility program contains the following menus:

Info System Advanced

Security Boot Exit

allows you to set the system functions and the hardware

Displays information relating to the BIOS, processor and Tablet PC Advanced system settings Con¿guration of various hardware components, such as mouse, keyboard,

processor Password settings and security functions Con¿guration of the start-up sequence Exits the BIOS Setup Utility

Starting the BIOS Setup Utility

Ź Keep the Volume Down button pressed and switch on the Tablet PC.

BIOSSetupUtility

Ź If a password has been assigned, enter the password and press the Enter ke y.

If you have forgotten the password, contact your system administrator or contact our customer service center.

The BIOS Setup Utility starts.

72 Fujitsu

BIOS Setup Utility operation

BIOSSetupUtility

Press theF1key to display help about operation of the of the individual settings is shown in the right-hand window of the

With the

key you can load the default settings of the

Settings in BIOS Setup Utility

BIOS Setup Utility

. The description

BIOS Setup Utility

Use the cursor keys

The menu is displayed on the screen.



Ź Select the option you wa nt to change with the cursor keys

to select the menu you wish to access to make changes.

orĻ.

Ź Press the "Enter" key.

ESC

Ź Press the

key to exit the selected menu.

Ź For future reference, make a note of the change s you have made (for example, in this manual).

Fujitsu 73

Settings in BIOS Setup Utility

Exiting BIOS Setup Utility

BIOSSetupUtility

You need to select the desired option in the

Exit

menu and activate it by pressing the Enter key:

Exit Saving Changes - save ch

To save the current menu settings and exit the

The Tablet PC is rebooted



and the new settings come into effect.

anges and exit BIOS Setup Utility

BIOS Setup Utility

, select

Exit Saving Changes

and

Exit Discarding Changes - Reject chan ges and exit BIOS Setup Utility

Ź To discard the changes, select Exit Discarding Changes and Yes.

The s ettings which were valid when BIOS Setup Utili ty was called remain effective.



The BIOS Setup Utility en ds and the Tablet PC is rebooted.

Load Setup Defaul

Ź To copy the standard entries for all menus of the BIOS Setup Utility,

choose Load Setup Defaults and Yes.

ts – load default values

Discard Changes - Discard Changes without exiting B IOS Setup Utility

Ź To discard the changes you have made, select Discard Changes and Yes.

The settings in place when BIOS Setup Utility was called remain effective.



You can now make additional settings in the BIOS Setup Utility.

Ź IfyouwanttoexittheBIOS Setup Utility with these settings, select Exit Saving Changes and Yes.

Yes

Save Chan

ges - save changes without exiting

the BIOS Setup Utility

Ź To save the changes, select Save Changes an d Yes.

The changes are saved. You can now make additional settings in the BIOS Setup Utility.



Ź If you want to exit BIOS Setup Utility with these settings, choose Exit Saving Changes and Yes.

Save changes and power off

Ź To save the changes and switch off y our device, select Save Changes and Power Off and Yes.

The changes are saved. Your device is shut down.



74 Fujitsu

Troubleshooting and tips

TroubleshootingTipsFaultProblemsolving

If a fault occurs, try to correct it as described. If you fail to correct the problem, proceed as follows:

Make a note of the steps and the circumstances that led to the fault. Also

make a note of any error messages displayed. Switch the Tablet PC off.

Please contact the Hotline/Service Desk.

You can contact Fujitsu Service and Support in the following ways:

• Toll free phone: 1-800-8Fujitsu (1-800-838-5487)

• Website: " Before you place the call, have the following information ready so that the customer

support representative can provide you with the fastest possible solution:

• The model name and serial number of the Tablet PC. The serial number is located on a sticker on the underside of the Tablet PC.

• Notes with the mess information on aco

• All changes you have made to the hardware or software after receiving the Tablet PC.

• All changes you ha

• Your system con¿guration and all peripheral devices connected to your system.

• Your sales cont

http://solu

tions.us.fujitsu.com/www/content/support/contact/index.php"

ages that appeared on the screen and

ustic signals.

ve made to the BIOS Setup settings after receiving the Tablet PC.

ract.

Our Tablet PCs have been designed primarily with mobile applications in mind. This means that considerable effort has been made to optimize components and equipment in terms of weight, space and energy requirements. Depending on the particular con¿guration you have purchased, it is possible that functionality may be slightly reduced compared to a desktop PC if you are running p rocessor-intensive gaming software, e.g. games with intensive 3D graphics. Updating your hardware with drivers which have not been approved by Fujitsu m ay result in performance losses, data losses or malfunction of the equipment. A list of approved drivers and current BIOS versions can be downloaded from: "

http://solutions.us.fujitsu.com"

Fujitsu 75

Troubleshooting and tips

Executing a reset

If the device no longer responds to your inputs, choose one of the following options:

Forced shutdown

Press and hold the ON/OFF button for at least 10 seconds.

The device will be shut down. You can then restart it.



Execute a complete reset

: Reset BIOS Setup

to the standard values

Ź Shut down the device. Ź Ifthedevicedoesnotrespond,youmayhavetoforcethe shutdown,asdescribedabove. Ź PressontheIRUFHGVKXWGRZQEXWWRQuntiltheoperating systemrestarts.

The device will restart when you release the button.



Help if problems occur

Should you encounter a problem with your computer that you cannot resolve yourself: Ź Note the ID number of your device. The ID number is found on the type rating

plate on the back or underside of the casing.

Ź For further clari¿cation of the problem, contact the Fujitsu Service Desk. When you do

this, please have ready the ID number and serial number of your system.

If you need to restore your system

In the event you need to restore your system, please refer to the appendix of this Operating Manual.

The Tablet

SummertimeWintertimeIncorrecttimeTimenotcorrectWrongdate/timeDatenotcorrect

Cause Troublesh

Time and d

Date and time are still set incorrectly after switching on the Tablet PC.

ate are incorrect.

PC’s date or time is incorrect

ooting

Ź With the B

date and t

Ź Please c

hotlin

IOS-Setup-Utility, you can set the

ime in the System menu.

ontact your sales outlet or our

e/service desk.

76 Fujitsu

Troubleshooting and tips

Battery charging indicator not

Cause

The battery is not being charge

Troubleshooting

Note:

when the battery capacity is less than 90%.

lit

Connect the Tablet PC to a power outlet using the AC adapter.

The battery will only be charged again

The Tablet PC’s touchscreen remains dark

Touchsc reendarktouchscreen

Cause Troubleshooting

Touchscreen is switched

External monitor or t

elevision set connected.

off.

Ź Press a key (external key

the touchscreen.

Ź Check whether the graphics driver settings

are correct or whether an external monitor has been detected in "Intel Graphics Media Accelerator Driver for mobile".

board) or tap on

The display on the Tablet PC’s touchscreen is difﬁcult to read.

Touchsc reenTouc hscreen

Cause Troubleshooting

ReÀected glare Ź Move the Tablet PC into a different position.

Ź Increase the brightness of the screen.

Fujitsu 77

Troubleshooting and tips

The external monitor remains bl

Monitor

Cause Troubleshooting

Monitor is switched off. Power saving has been activated (monitor is

blank). Brightness is set to dark. Screen output is set to the Tablet PC

touchscreen.

The external monitor’s AC cable or data cable is not connected properly.

The external mo

MonitorMonitor

Cause Troubleshooti

The wrong exte or the wrong sc the applicat

rnal monitor has been selected

reen resolution has been set for

ion program.

nitor is blank or the image is unstable

Ź Switch off the Tablet PC and the external

Ź Check whether the AC cable is plugged

Ź Check that the data cable is properly

Ź Switch on the external monitor and the

Ź Shut do wn the application program in

Ź Set the screen resolution: Set the screen

Ź Select monitor: Select monitor 1 or 2 as

ank

Switch the external monitor on. Press a key (external keyboard) or tap on

the touchscreen. Adjust the brightness of the Check whether the graphics driver settings

are correct or whether an external monitor has been detected in "Intel Graphics Media Accelerator Driver for mobile".

monitor.

properly into the external monitor and into the power outlet.

connected to the Tablet PC and the external monitor (if it is plugged in with a connector).

Tablet PC.

Windows. If the error persists after shutting down the program, use the key combination for switching the screen output in order to switch to the touchscreen of the Tablet PC. Change the following setting:

resolution as described in the documentation for your operating system.

described in the documentation for your operating system.

monitor.

The cursor does not correctly follow the stylus movements

Cause

Stylus incorrectly calibrated. Ź Calibrate the stylus as described in chapters

78 Fujitsu

Troubleshooting

Adjusting the stylus", Page 29 and

Calibrating the stylus " , Page 30.

Stylus input not working

Troubleshooting and tips

Cause

Incorrect driver installed.

Troubleshooting

Reinstall the driver for the "dual digitizer".

The Tablet PC does not start after switch on

Tablet PC

Cause Troubleshooting

The battery is dead.

The AC adapter is not connected properly. Ź Check whether the AC adapter is properly

Ź Charge the battery.

Ź Connect the AC adapter to the Tablet

PC.

connected to the Tablet PC .

Ź Switch the Tablet PC on.

The Tablet PC stops working

Tablet PCEnding

Cause Troubleshooting

The Tablet PC is in energy saving mode. An application program has caused the

malfunction.

The battery is dead.

Ź End energy saving mode. Ź Close the application program or restart

the Tablet PC (by restarting the operating system or switching the device off and back on again).

Ź Charge the battery.

Ź Connect the AC adapter to the Tablet

PC.

The printer does not print

Printerdoesnotprint

Cause Troubleshooting

The printer is not switched on. Ź Make sure that the printer is switched

The printer is not connected correctly.

The printer driver is faulty or not correctly installed, or it is th e wrong printer driver.

Fujitsu 79

on and ready for operation (refer to the documentation supplied with the printer).

Ź Check t

Ź Check that the data cable between the Tablet

Ź Check whether the correct printer driver is

hat the data cable between the Tablet

PC and t

PC and the printer is properly connected.

loaded (refer to the printer documentation).

he printer is prope rly connected.

Troubleshooting and tips

The wireless connection to a net

Thewirelessconnectiontoan etworkdoesnotwork

Cause Troubleshooting

The wireless component is switched off.

The wireless component is switched on. Despite this, the wireless connection to a n etwork does not work.

The battery discharges

Battery

Cause

The battery is either case the battery indi

You may have an application running that consumes a great deal of power due to frequent accessing of the hard disk or optical drive.

The maximum brightness may have been set for the screen.

too hot or too cold. In this

cator Àashes.

too quickly

Troubleshooting

Ź Bring the Tablet PC up/down to a normal

Ź If the operating time of the battery life is

Ź Use the AC adapter whenever possible.

Ź Reduce the brightness of the screen to

work does not work

Switch the wireless component on (see

Switching the wireless components on and

off", Page 43).

Check whether the wireless connection is enabled by the software.

Further information on using the wireless component can be fou nd in the help ¿les.

operating temperature again.

extremely short, the battery is probably too old. Replace the battery if necessary.

lower energy consumption: You will ¿nd the setting under Control Panel – Hardware and Sounds – Windows Mobility Cent er .

80 Fujitsu

Troubleshooting and tips

Error messages on the screen

ErrormessagesonthescreenErrors

This section de scribes the error messages generated by the BIOS Setup. Error messages displayed by the operating system or programs are described in the documentation for these programs.

If the error message appears repeatedly despite troubleshooting measures, contact the place of purchase or our customer service center.

Error message/cause Troubleshooting

Keyboard error

Bootable device was no

t found

Press <F1> to resume, <F2> to SETUP

This error message appears if an error occurs during the self-test before starting the operating system.

Real time clock erro r

If you use an external keyb Ź Check the connection and

PC.

Ź Check in the BIOS Setup whether your hard

disk has been set correctly.

Ź Make sure that the operating system is

installed on the corresponding drive.

Ź To continue, press the

Ź To start the BIOS Setup Utility,pressthe

/ decrease volume key.

Ź Check the date and time settings.

oard:

reboot the Tablet

/ Windows key.

Fujitsu 81

Technical data

Tablet PC

General

Processor

Mainmemory (RQERDUG)

Electrical data

Safety regulations complied with IEC60950-1 Protection class III Maximum power consumption (when the Tablet

PC is switched on, connected to the keyboard cover and the battery is charged):

Touchscreen

Size 10.1" WUXGA Wide View TFT,

Screen resolution

Brightness control Technology Wide-View High-Bright Display with LED

Digitizer and glass panel Cameras

Graphics card

Chip Intel® HD graphics Maximum resolution of external display: 1920 x 1080 (1080p)

Dimensions

Width x Depth x Height

Weight depending on con¿guration

Input devices

,QWHO&HOHU ,QWHO&HOHURQ13URFHVVRU0%&DFKHXSWR*+]

*%/3''50+]ZLWK,QWHO&HOHURQ1 *%/3''50+]ZLWK,QWHO&HOHURQ1

36 W

Anti-Glare-Display with LED backlight (1920 x 1200 / 16:10), with 160° vertical and horizontal viewing angle

•Internal:

• Simultaneous:

Software controlled, 101 levels

background lighting Dual Dig

• Front:

•Rear:

10.4”(W) x6.7” (D)x0.4”(H)

263.mm(W)x16.mm(D)x1mm(H) Tabletweight:approx.1. lbs.

/7(PRGHOZHLJKWDSSUR[OEV Keyboardcoverweight:DSSUR[ 0.86lbs.

RQ13URFHVVRU0%&DFKHXSWR*+]

1920 x 1200 pixels/16 million colors

1920 x 1080 pixels/16 million colors

itizer (stylus and touch)

2 MP resolution with LED status display

8 MP resolution with autofocus and LED status display

82 Fujitsu

Tablet buttons 3 keys Stylus

Slots

Memory card slot

Ports

Combined headphones and microphone port Docking port 1 x USB (Universal Serial Bu

Ambient conditions

Environment class DIN IEC 721 Mechanism class DIN IEC 721 Operating temperat

Transport temperature (2K2) –15 °C .... 60 °C / 5 °F .... 140 °F

ure

EMRpenwith

1xMicroS

3.5mmstereominijack

1xUSB3.0(TypeA),1xUSB charging function (USB T

7K1 7M2

5 °C .... 35 °C / 41 °F .

'

pressurelevels



card (SD/SDHC/SDXC)

ype C)

... 95 °F

Screen resolutions for integrated screen and external screens

Technical data

3.1(Gen1)with

Only Tablet PC

With docking cradle

Max

no. of

monitors

Number

of external screens

Inte-

grated

display

screen

1920 x

1200

Port on the

Tablet PC

USB Type-C

1920 x 1080p

60 Hz

–

––

Ports on the docking cradle

HDMI

––

1920 x 1080p

60 Hz

VGA

–

1920 x 1080p

60 Hz

Fujitsu 83

Technical data

WLAN speciﬁcations

Type of network Intel®

Transfer rate (Automatic switching) IEEE802.11 a and g: 54

Active frequency • 802.11n: 2.4 GHz / 5 GHz

Number of channels

Security

Maximum recommended number of computers to be connected over wireless LAN (during ad hoc connection)

* “Wi-Fi based” indicates that the interconnectivity test of the organization which guarantees the interconnectivity of wireless LANs (Wi-Fi Alliance) was passed.

** The operating distances given above increase or decrease depending on factors such as the number of walls, reÀecting material or interference by external RF sources.

*** Network key encryption (WEP) occurs with the number of bits given above, after deduction of the ¿xed length of 24 bits the user may however also set 40 or 104 bits.

**** Depending on the particular practical application, the number of computers which can be networked is reduced if necessary.

 -HIIHUVRQ 3HDNAC

b/g/b/nwithintegratedBluetoothv.0,WIFibased*

2.4 GHz min. 2412, max. 2472

5.8 GHz min. 5180, max. 5825

Mbps max. data rate; IEEE802.11n: 300 Mbps max. data rate, IEEE802.11ac: 867 Mbps max. data rate

• 802.11b/g: 2400~2473 MHz

• 802.11a. 4900~5850 M

• 802.11a: 8 indepen

• 802.11b/g: 11 channels, 3 non-overlapping channels

• 802.11n: Channel the non-overlapp combines them in is actually 12 no channel bonding non-overlapp channel bondi

• 802.11ac: 5 independent channels

Encryption types: compatible with WEP, TKIP, AES***, WPA 1.0 and WPA 2.0

Encryption key, lengths supported: 64 bits and 128 bits

10 units or less ****

dent channels

bonding takes two of

ing 20 MHz channels and

to one 40 MHz channel. It

n-overlapping channels with

and 24 without. Also it is 1

ing channel in 2.4GHz when

ng is used.

2x2ac/a/

84 Fujitsu

Rechargeable battery

For information on the batteries used in your device, please see

http://solutions.us.fujitsu.com/www/content/support/".

Technical data

-celllithiumpolymerbattery



Rated voltage Rated capacity Wh





AC adapter (36 W) for the Tablet PC only (without cradle)

Technicaldata

Rated voltage 12 V Max. rated current 3 A

An additional AC adapter or AC cable can be ordered at any time.

Docking cradle (optional)

Electrical data

Safety regulations complied with CE Protection class III

Ports

Docking port 11-pin HDMI port 1 x VGA monitor port USB (Universal Serial Bus) 7\SH&86% 7\SH $ 86%.0 LAN port 1 x Security Lock device

Ambient conditions

Environment class DIN IEC 721 Mechanism class DIN IEC 721 Operating temperature Temperature in transit

7K1 7M2

5 °C .... 35 °C / 41 °F .... 95 °F

mAh

AC adapter 90 W for the docking cradle (optional)

Technicaldata

Rated voltage 19 V Max. rated current 4.74 A

An additional AC adapter or power cable can be ordered at any time.

Fujitsu 85

Technical data

Keyboard cover (optional)

Electrical data

Safety regulations complied with CE Protection class III

Ports

Docking port 7-pin LAN port 1 x Touchpad Yes

Ambient conditions

Environment class DIN IEC 721 Mechanism class DI Operating temperature Temperature in transit

NIEC721

7K1 7M2

5 °C .... 35 °C / 41 °F .... 95 °F

Protective TPU cover with s houlder strap (optional)

Dimensions

Width x Depth x Height 10.in.x in. x.in.

27mm x1mmx mm

Folio cover (optional)

Dimensions

Width x Depth x Height

in xinx0. in mmx  mmxmm

Adapter cables (optional)

B Type-C to HDMI conversion adapter

•US

• USB Type-C to microHDMI conversion adapte r ull-USB-to-LAN conversion adapter

•F

86 Fujitsu

Manufacturer’s notes

Disposal and recycling

Notes

You c an¿nd information on this subject on y our Tablet PC or on our website

http://solutions.us.fujitsu.com/www/content/products/trade-in_program/").

Recycling your battery

Over time, the batteries that run your mobile comp uter will begin to hold a charge for a shorter amount of time; this is a natural occurrence for all batteries. When this occurs, you may want to replace the battery with a brand new one*. If you replace it, it is important that you dispose of the old battery properly because batteries contain materials that could cause environmental damage if disposed of improperly.

Fujitsu is very concerned with environmental protection, and has enlisted the services of the Rechargeable Battery Recycling Corporation (RBRC)**, a nonpro¿t public service organization dedicated to protecting our environment by recycling old batteries at no cost to you.

RBRC has drop-off points at many convenient locations throughout the United States and Canada. To ¿nd the location nearest you, go to "

If there are no convenient RBRC locations near you, you can also go to the EIA Consumer Education Initiative website "

http://EIAE.org/ " and search for a convenient disposal location.

www.RBRC.org" or call 1-800-822-8837.

Remember – protecting the environment is a cooperative effort, and you should make every effort to protect it for current and future generations.

* To order a new battery for your Fujitsu mobile computer, go to the Fujitsu shopping site

www.shopfujitsu.com" in the US or "www.fujitsu.ca/product s/notebooks" in Canada.

at " ** RBRC is an independent third party to which Fujitsu provides funding for

battery recycling; RBRC is in no w ay af¿liated with Fujitsu.

Fujitsu 87

Manufacturer’s notes

DOC (Industry CANADA) Notices

DOC(INDUSTRYCANADA)NOTICES

Radios and Television

ThisClassBdigitalapparatusmeetsallrequirementsofCanadianInterference-CausingEquipment Regulations.

CETappareilnumériquedelaclassBrespectetouteslesexigenceduRéglement surlematérialbrouilleurduCanada.

UL Notice

IMPORTANT SAFETY INSTRUCTIONS

ThisunitrequiresanACadaptertooperate.Only useULListedI.T.E.adapterswithanoutputrating of12 VDC,with aminimumcurrentof3.0A(W).Thecorrectoutputratingisindicatedon theAC adapterlabel. Refertotheillustrationbelowforthecorrect

When using your STYLISTIC tablet accessories, always follow the basic safety instructions, including the following items, to avoid the risk of ¿re, electric shock or injury to persons:

• Do not use this product near water for example, near a bathtub, washbowl, kitchen

sink or laundry tub, in a wet basement or near a swimming pool.

• Use only the

¿re. They ma

SAVE THESE INSTRUCTIONS For Authorized Repair Technicians Only

power cord and b atteries indicated in this manual. Do not dispose of batteries in a y explode. Check with local codes for possible special disposal instructions.

ACadapter outputpolarity:



CAUTION:

For continued protection against risk of ¿re, replace only with the same type and rating fuse.

88 Fujitsu

Manufacturer’s notes

ENERGY STAR Compliance

Your Fujitsu system is an ENERGY STAR quali¿ed mobile PC. By choosing a computer with the latest energy-saving technology, you’re helping to preserve our environment for future generations. ENERG Y STAR is a joint program of the U.S. Environmental Protection Agency, U.S. Department of Energy, Natural Resources Canada, and other governments around the world helping us save money while protecting the environment through energy ef¿cient products and practices. With energy costs and global warming top-of-mind for consumers, Fujitsu is committed to offering solutions that help consumers conserve energy and improve the quality of our environment.

Display sleep mode:

When the AC adapter is connected, the screen will deactivate after 10 minutes. When the AC adapter is disconnected (battery operation), the screen will turn off after 4 minutes.

Energy saving beneﬁts:

Fujitsu ENERGY STAR quali¿ed mobile PCs use about half as much electricity as standard equipment – saving half in utility costs. But more than that, ENERGY STAR also makes a difference for the environment. Did you know that the average house can be responsible for twice the greenhouse gas emissions as the average car? T hat’s be cause every time you Àip on a light switch, run your dishwasher, or turn on your PC, you use energy, which means more greenhouse gas emissions from power plants. So the more energy we can save through energy ef¿ciency, the more we help to reduce greenhouse gases and the risks of global warming.

To learn more about the important ENERGY STAR program, visit:" To read about how Fujitsu is supporting Sustainable Management along with

several other environmental activities, visit the Fujitsu Corporate Citizenship page at:

http://www.computers.us.fujitsu.com/www/content/aboutus/environmental/environm ent.php".

www.energystar.gov".

Fujitsu 89

FCC and IC Regulatory Information

FCC and IC Regulatory Informat

Please note the following regulatory information related to the wireless LAN device.

Regulatory Notes and Stat

ements

ion

Wireless LAN, Health and Authorization for use

Radio frequency electromagnetic energy is emitted from Wireless LAN devices. The energy levels of these emissions, however, are far m uch less than the electromagnetic energy emissions from wireless devices such as mobile phones. Wireless LAN devices are safe for use by consumers because they operate within the guidelin es found in radio frequency safety standards and recommendations. The use of Wireless LAN devices may be restricted in some situations or environments, such as:

• On board an airplane, or

• In an explosive environment, or

• In situations where the interference risk to other devices or services is

perceived or identi¿ed as harmful.

In cases in which the policy regarding use of Wireless LAN devices in spe ci¿c environments is not clear (e.g., airports, hospitals, chemical/oil/gas industrial plants, private buildings), obtain authorization to use these devices prior to operating the equipment.

WARNING: The Fujitsu Tablet when used in dock mode in the cradle will communicate via RF. The device radiates radio frequency energy at a level below the United States FCC and Canada’s ISED radio frequency exposure limits. However, the Tablet in docked mode shall not be used in body worn positions. Human contact during normal operation should be minimized and a body to Tablet distance of >20cms shall be maintained. Use of other accessories may not ensure compliance with FCC RF exposure guidelines. Details o f the authorized con¿gurations can be found on FCC website by entering the FCC ID number that is shown on this device.

Regulatory Information/Disclaimers

Installation and use of this Wire less LAN device must be in strict accordance with the instructions included in the u ser documentation provided with the product. Any changes or modi¿cations made to this device that are not expressly approved by the manufacturer may void the user’s authority to operate the equipment. The manufacturer is not responsible for any radio or t elevision interference caused by unauthorized modi¿cation of this device, or the substitution or attachment of connecting cables and equipment other than those speci¿ed by the manufacturer. It is the responsibility of the user to correct any interference caused by such unauthorized modi¿cation, substitution or attachment. The manufacturer and its authorized resellers or distributors will assume no liability for a ny damage or violation of government regulations arising from failure to comply with these guidelines.

This device must not be co-located or operated in conjunction with any other antenna or transmitter. For IEEE 802.11a Wireless LAN: For operation within 5.15~5.25 GHz frequency range, it is

restricted to indoor enviro nments, and the antenna of this device must be integral.

90 Fujitsu

FCC and I C Regulatory Information

Federal Communications Commission and Industry Canada statement:

This device complies with Part 15 of FCC Rules and Industry Canada license exempt RSS standard(s). Operation is subject to the following two conditions: (1) This device may not cause

interference, and, (2) This device must accept any interference, including interference that may cause undesired operation of this de vice .

Déclaration d’Industrie Canada

This device complies with Industry Canada’s license-exempt devices and RSS standards for Internet updates. Cet appareil est conforme à la R SS concernant les appareils exempts de licence par Industrie C anada. Its operation is subject to the following two conditions: Son fonctionnement est soumis aux deux conditions su ivantes : (1) This d evice may not cause harmful interference; (2) this device must accept any interference received, including interference that may cause undesired operation. (1) cet appareil ne do it pas causer d’interférence nuisible; (2) cet appareil doit accepter toutes les interférences reçues, y compris celles pouvant causer un mauvais fonctionnement de l’appareil.

FCC Interference Statement

This equipment has been tested and found to comply with the limits for a Class B digital device, pursuant to Part 15 of the FCC Rules. These limits are designed to provide reasonable protection against harmful interference in a residential installation. This equipment generates, uses, and can radiate radio freq uency energy. If not installed and used in accordance with the instructions, it may cause harmful interference to radio communications. However, there is no guarantee that interference will not occur in a particular installation.

If this equipment does cause harmful interference to radio or television reception, which can be determined by turning the equipment off and on, the user is encouraged to try and correct the interference by one or more of the following measures:

1. Reorient or relocate the receiving antenna.

2. Increase the distance between the equipment and the receiver.

3. Connect the equipment to an outlet on a circuit different from the one the receiver is connected to.

4. Consult the dealer or an experienced radio/TV technician for help.

Fujitsu 91

FCC and IC Regulatory Information

FCC Radio Frequency Exposure statement

The available scienti¿c evidence does not sh ow that any health problems are associated with using low power wireless devices. There is no proof, however, that these low power wireless devices are absolutely safe. Low power wireless devices emit low levels of radio frequency energy (RF) in the microwave range while being used. Whereas high levels of RF can produce health effects (by heating tissue), exposure to low-level RF that does not pro duce heating effects causes no known adverse health effects. Many studies of low-level RF exposure have not found any biological effects. So me studies have suggested that some biological effects might occur, but such¿ndings have not been con¿rmed by add itional research.

The wireless LAN radio components have been successfully tested for compliance with the FCC radio frequency limit values for unmonitored devices. The radio components comply with the FCC Radio Frequency (RF) Exposure Guidelines in Supplement C to OET65.

The exposure standard for wireless devices employs a unit o f measurement known as the Speci¿c Absorption Rate, or SAR. The SAR limit set by the FCC is 1.6W/kg, and 1.6W/kg by Industry Canada.

This device is compliant with SAR for general population / uncontrolled exposure limits in ANSI/IEEE C95.1-1992 and Canada RSS 102, and had been tested in accordance with the measurement methods and procedures speci¿ed in FCC CFR Rule Part 15.247 and

15.401, and Canada RSS 102. T his device has been tested, and meets the FCC, IC RF

exposure guidelines when tested with the device operating conditions.

Déclaration de la FCC/d’Industrie Canada sur l’exposition aux radiofréquences

La norme régissant l’exposition des appareils sans ¿l aux radiofréquences emploie u ne unité de mesure dénommée Taux d’absorption spéci¿que, ou TAS. La FCC et Industrie Canada ont dé¿ni la même limite de TAS : 1.6 W/kg. Cet appareil est conforme au TAS pour les limites d’exposition générales de la population/non contrôlées dé¿nies par les règles C95.1-1992 de l’ANSI/IEEE et RSS 102 d’Industrie Canada ; il a été testé en conformité avec les méthodes et procédures de mesure spéci¿ées dans le FCC CFR Rule Part 15.247 and 15.401 (O d’ingénierie et de technologie) et la règle RSS 102 d’Industrie Canada. Cet appareil a été testé selon les directives de la FCC et d’IC concernant l’exposition aux radiofréquences et s’est révélé conforme à c es dernières lorsqu’il a été testé en contact direct avec le corps.

Export restrictions

This product or software contains encryption code which may not be exported or transferred from the U S or Canada without an approved US Department of Commerce export license. This device complies with Part 15 of FCC Rules, as well as ICES 003 B / NMB 003 B. Operation is subject to the following two conditions: (1) t his device must not cause harmful interference, and (2) this device must accept any interference received, including interference that may cause undesirable operation. Modi¿cations not expressly authorized by Fujitsu America, Inc. may invalidate the user ’s right to operate this equipment.

92 Fujitsu

FCC and I C Regulatory Information

Restrictions concernant l’exportation

Ce produit ou logiciel contient du code de chiffrement qui ne peut être exporté ou transféré du Canada ou des États-Unis sans un permis d’exportation du département du commerce des États-Unis. Ce matériel est conforme à la Partie 15 des règlements de la FCC, ainsi qu’à la norme ICES 003 B/NMB 003 B. Son fonctionnement est soumis aux deux conditions suivantes : (1) cet appareil ne doit pas causer d’interférence nuisible; (2) cet appareil doit accepter toutes les interférences reçues, y compris celles pouvant causer un mauvais fonctionnement de l’appareil. Toute modi¿cation n’ayant pas été expressément approuvée par la société Fujitsu America Incorporated peut annuler le droit de l’utilisateur de se servir du matériel.

Fujitsu 93

Canadian Notice / Avis pour le Canada

Canadian Notice / Avis pour le C

anada

Canadian Notice

The device for the 5150 - 5250 MHz band is only for indoor usage to reduce the potential for harmful interference to co-channel mobile satellite systems.

The maximum antenna gain of 6 dBi permitted (for devices in the 5250 - 5350 MHz, 5470 - 5725 MHz and 5725 - 5825 MHz bands) to comply with the e.i.r.p. limit as stated in RSS-247.

In addition, users are cautioned to take note that high power radars are allocated as primary users (meaning they have priority) of 5250 - 5350 MHz and 5650 - 5850 MHz and the se radars could cause interference and/or damage to LE-LAN devices.

Avis pour le Canada

Le matériel destin uniquement à l’in systèmes mobiles

Un gain d’antenne

- 5 350 MHz, 5 470 -

p.i.r.e. maxima En outre, les u

sont considér bandes 5 250 - 5 et/ou des dom

é à un usage sur la bande 5 150 - 5 250 MHz doit être ut ilisé

térieur a¿n de réduire les risques de brouillage nuisible causé aux

par satellite fonctionnant sur un même canal.

de 6 dBi est autorisé (pour le matériel utilisant les bandes 5 250

le permise afférent aux périphériques RSS-247.

tilisateurs doivent prendre garde au fait que les radars de grande puissance

és comme des utilisateurs principaux (ce qui signi¿e qu’ils sont prioritaires) des

mages au x appareils de réseau exempts de licence.

AVERTISSEME

lorsqu’ell l’énergie r aux radiofr Toutefo i s contacts minimisé et le note conform sujet de alors le

5 725 MHz et 5 725 - 5 825 MHz), conformément à la limite

350 MHz et 5 650 - 5 850 MHz et qu’ils pourraient causer des interférences

NT – Le notebook Fujitsu communiquera par radiofréquences (RF)

e est utilisée en mode station d’accueil dans le socle. L’appareil émet de

adiofréquence d’une intensité inférieure aux limites d’expo sition humaine

équences établies par la FCC aux États-Unis et par ISDE au Canada.

, en mode station d’accueil, le noteb ook ne doit pas toucher le corps. Les

avec le corps pendant le fonctionnement normal de l’appareil doivent être

s et une distance de plus de 20 cm doit être maintenue entre le corps

book. L’utilisation d’autres accessoires peut conduire à un usage n on e aux limites d’exposition aux radiofréquences de la FCC. Des détails au scon¿gurations autorisées sont fournis sur le site Web de la FCC. Entrez

numéro d’identi¿cation FCC qui apparaît sur cet appareil.

94 Fujitsu

Appendix

Before Using the Optional Wireless LAN

This manual describes the procedures required to properly set up and con¿gure the optional integrated Wireless LAN Mini-PCI device (referred to as "WLAN device" in the rest of the manual). Before using the WLAN device, read this manual carefully to ensure its correct operation. Keep this manual in a safe place for future reference.

Wireless LAN Devices Covered by this Document

This document is applicable to systems containing the following device:

• Intel®DualBand Wireless-AC':(802.11ac/a/b/g/nWLAN)with Bluetoothv.0

Characteristics of the WLAN Device

• The WLAN devices are PCI Express Mini ca rds attached to the main board of the mobile computer.

• The WLAN devices operate in license-free RF bands, eliminating the need to procure an FCC operating license. The WLAN operates in the 2.4GHz Industrial, Scienti ¿c, and Medical (ISM) RF band and the lower, middle, and upper bands of the 5GHz Unlicensed National Information Infrastructure (UNII) bands.

• The WLAN components support ¿ve operating modes: IEEE802.11a, IEEE802.11b, IEEE802.11g, IEEE802.11n und IEEE802.11AC.

• The WLAN device is Wi-Fi certi¿ed and operates (as applicable) at a the maximum data rate of 450 Mbps in IEEE802.11n mode (300 Mbps in this con¿guration); 54 Mbps in IEEE802.11g mode; and 11 Mbps in IEEE802.11b mode.

• The WLAN devices support the following encryption methods - WEP, TKIP, CKIP, and AES encryption.

• The Wireless LAN devices are compliant with the following standards: WPA, WPA2, CCX1.0, CCX2.0, CCX3.0, and CCX4.0.

Wireless

Ad Hoc Mode

"Ad Hoc Mode" refers to a wireless network architecture where wireless network connectivity between multiple computers is established without a central wireless network device, typically known as Access Point(s). Connectivity is accomplished using only client devices in a peer-to-peer fashion. That is why Ad Hoc networks are also known as peer-to-peer networks. Ad Hoc networks are an easy and inexpensive method for establishing network connectivity between multiple computers. Ad Hoc mode requires that the SSID, network authentication, and encryption key settings a re identically con¿gured on all computers in the Ad Hoc network.

Fujitsu 95

LAN Modes Using this Device

Appendix

Access Point (Inf

Infrastructure wireless or wir mode, wireless wireless netwo order to acces

mode refers to a wireless network architecture in which devices communicate with

ed network devices by communicating through an Access Point. In infrastructure

devices can communicate with each other or with a wired network. Corporate

rks operate in infrastructure mode becau se they require access to the WLAN in

s services, devices, and computers (e.g., ¿le servers, printers, databases).

rastructure) Mode

96 Fujitsu

Appendix

* = An optional hub f or a wired LAN may

be required depending upon the type of access point used.

How to Handle This Device

The WLAN device is an optional device t hat may come pre-installed in your mobile computer. Under normal circumstances, it should not be necessary for y ou to remove or re-install it. The Operating System that your mobile computer comes with has been pre-con¿gured to support the WL AN device.

• Integrated Intel Centrino wireless LAN devices support IEEE802.11a, IEEE802.11ac, IEEE802.11b, IEEE802.11g, and IEEE802.11n.

• The WLAN device operates in the 2.4 GHz ISM band and the 5 GHz lower, middle, and upper UNII bands.

• Microwave ovens may interfere with the operation of WLAN devices since they operate in the same 2.4 GHz frequency range as IEEE802.11b/g/n devices. Interference by microwaves does not occur with IEEE802.11a radio which operates in the 5 GHz RF band.

• Wireless devices that transmit in the 2.4 G Hz range may interfere with operation of WLAN devices in IEEE802.11b/g/n modes. Symptoms of interference include reduced throughput, intermittent disconnects, and many frame errors. It is HIGHLY recommended that these interfering devices be powered off to ensure proper operation of the WLAN device.

** = ADSL modem, cable modem, or similar

Fujitsu 97

Appendix

Deactivating/Disconnecting the WLAN Device

Disconnecting the WLAN device may be desired in certain circumstances (to extend battery life) or where certain environments require it (i.e. hospitals, clinics, airplanes, etc.). The WLAN device can be disconnected in Windows using the WLAN icon in the system tray (Note that disconnecting via the icon in the system tray does not turn off the radio; it continues to transmit and receive even though it’s not connected.)

The radio components are switched on and off using the appropriate functions of the operating system.

Ź To switch radio components on and off individually, select Settings Network

& Internet - WiFi - On / Off.

Conﬁguring the Wireless LAN

The optional WLAN device can be con ¿gured to establish wireless network connectivity using the so ftware that is built into Windows. Support for most industry standard security solutions is contained in this software.

Pre-de¿ned parameters will b e required for this procedure. Please consult with your network administrator for these parameters:

Connection to the

After you have con¿gured your computer, you can connect to an active network by performing the following steps:

1. Click on t he WLAN icon in the system tray.

2. Select Connec

3. Select a network from the list that appears, and click the Connect button.

ttoanetwork.

network

Troubleshooting the WLAN

Causes and countermeasures for troubles you may encounter while using your wireless LAN are described in the following ta ble.

98 Fujitsu

Fujitsu EM7455D4 User Manual

Specifications and Main Features

Frequently Asked Questions

User Manual
