ESPRIMO E3500
Value Line
Small Form Factor PC
The ESPRIMO E3500 is the gateway to professional computing. The Small Form factor PC extends the Fujitsu Siemens
Computers’ Value Line product portfolio with an additional form factor.
The basic professional PC is the ultimate balance of valuable performance at very attractive prices. The ESPRIMO
E3500 is aimed towards the large enterprises that are looking fo r a price-conscious professional PC with longer
lifecycle.
Reliable i945G chipset with Intel Core2 Duo support
Excellent resolution with on board graphics
High quality and function stability
Convenient front access to USB and audio
Pages 4
Issue February 2007
Page 2
Data Sheet ⏐ Issue: February 2007⏐ ESPRIMO Edition E3500 Page 2 / 4
E3500
Mainboard
Chipset i945G Express
Mainboard Number D2610
Mainboard form factor µBTX
Processor socket LGA 775
Front side bus resp. system bus support 533/800/1066 MHz
BIOS version Phoenix Vers.5.0
Flash EPROM BIOS update by software x
Recovery BIOS x
Processor
Intel® Core™ 2 Duo up to E6600
Second level cache 4MB
Front side bus (FSB) 1066MHz
Intel® Pentium® D9xx up to D945
Second level cache 2x2MB
Front side bus (FSB) 800MHz
Intel® Pentium® D8xx up to D820
Second level cache 2x1MB
Front side bus (FSB) 800 MHz
Intel® P4 6xx up to 651
Second level cache 2MB
Front side bus (FSB) 800 MHz
Intel® P4 5xx Second level cache Front side bus (FSB) Intel® Celeron D up to D360
Second level cache 512 KB
Front side bus (FSB) 533 MHz
Memory
Memory support 533/667 MHz
DIMM slots 4
dual channel support x
Max. capacity DDR2 SDRAM 667 MHz 4GB
for dual channel performance, a minimum of 2 memory modules have to be
ordered. Capacity per ch annel has to be the same
Interfaces
Mouse/keyboard (PS2) x/x
Serial (9pi, 16 byte FIFO, 16550 compatible) x
Second serial port Parallel (25pin with EPP and ECP) Display (15 pin, VGA) x
DVI optional
Micro (mono) rear x
Line in (stereo) rear x
Line out (stereo) rear x
Micro (mono) front x
Headphone in front x
LAN RJ45 x
Universal Serial Bus (USB 2.0) in total 8
therefore USB rear 4
USB front 2
USB internal 2
Interfaces add on cards
Dual port RS232 , serial LAN on board
10/100/1000 MBit/s Realtek RTL8110
Wake up on LAN (WOL) x
PXE x
BootP LAN add on cards
Gigabit Ethernet, SysKonnect Audio on board
Internal speaker supports audio playback no, buzzer only
High definition audio Realtek ALC260
I/O controller onboard
Serial ATA 3
Serial ATA II / 3GBit x/x
Drive bays 3
internal 3,5'' 1
external 3,5'' 1
external 5,25'' 1
Floppy disk drive 1.44 MB standard optional
Hard disk drives
Serial ATA II 80 / 160 / 250 GB x/x/x
supporting NCQ and 3GBit (if chipset support is available)
Optical drives (SATA)
16/48-speed DVD ROM optional
48/24/48/16-speed CD-RW / DVD ROM optional
DVD SuperMulti writer double layer support optional
Slots
PCI 2 (190 mm) low profile
PCI Express x16 1 (190mm) low profile
PCI Express x1 Graphic on board Intel® GMA950
4GB address space thereof, max. 3.0GB usable for physical main
memory
Page 3
Data Sheet ⏐ Issue: February 2007⏐ ESPRIMO Edition E3500 Page 3 / 4
Shared memory depending on driver up to 224MB
Resolution (color depth up to 32 Bit/pixel)
* refresh rates reflect the max. graphics capabilities. Video quality can be
deteriorated when using maximum settings.
For TFT we recommend to use 60Hz.
Graphic add on cards
NVIDIAGeForce FX 7300LE 128MB, LP optional
NVIDIAGeForce FX 7300LE 256MB, LP optional
NVIDIAGeForce FX 7300LE 128MB NVIDIAGeForce FX 7300LE 256MB DVI adapter incl. Dual Monitoring (DVI/VGA) optional
Dual-DVI adapter incl. Dual Monitoring (D V I/D V I) optional
Electrical values
Rated voltage range, AC 100 - 127 / 200 - 240 V
Rated frequency range 50-60 Hz
Operating voltage range, AC 90 - 137 / 180 - 264 V
Operating line frequency range 47 - 63 Hz
Max. output of power supply 275 W
PFC (power factor correction) passive
Monitor outlet no
Power consumption for standard configuration (W) / CPU P4 651 / E6400
Peak (S0, running app. CD in use) 158W / 106W
Average (S0, running OS, Idle mode) 80W / 53W
Stand by (S3, energy saving modus, WOL enabaled) 2 W
Minimum (ACPI status S5, soft off, WOL enabled)
Minimum (ACPI status S5, soft off, wake up power button only)
Minimum "low power soft off" (FSC patent pending)
(ACPI S5, soft off, wake up power button only) Heat dissipation (kJ/h / BTU/h) / CPU E6400
Peak (S0, running app. CD in use) 382kJ/h / 362BTU/h
Average (S0, running OS, Idle mode) 191jK/h / 181BTU/h
Stand by (S3, energy saving modus, WOL enabled) 7,2kJ/h / 6,8BTU/h
Minimum (ACPI status S5, soft off, WOL enabled)
1W = 3,6kJ/h, 1W = 3,4121BTU/h
Noise for standard configuration (HDD, ODD, FDD)
A weighted sound power level Lwad (in B) / Workplace related A-weighted
sound pressure level LpAm (in dB(A)), (bystander position) (ISO9296)
Operation mode 1: ODD load (Blue angel requirement) 5,0B / 35dB(A) (36dB(A))
Operation mode 2: HDD load (Blue angel requirement) 4,0B / 25dB(A) (26dB(A))
Operation mode 3: CPU 90% load (Blue angel requirement) 4,9B / 25dB(A) (30dB(A))
Operation mode 4: High load 4,2B / 26dB(A) (30dB(A))
Operation mode 5: Office applications 4,0B / 25dB(A) (28dB(A))
Idle mode (Blue angel requirement) 3,7B / 22 dB(A) (24dB(A))
Ambient temperature (IEC 721) 15°C'- 35°C
Dimensions (H x W x D) 106 x 389 x 344 mm
Operating position (vertical/horizontal) x/x ( optional, feet needed)
Weight (depending on config) approx. 10 kg
Approvals and standards
CE certification x
according to EU Directives 89/336/EEC (EMC) and 06/95/EC (Product
Ergonomics x
Product safety x
Electromagn. compatibility x
Environmental compatibility
RoHS (Restriction of hazardous substances) x
WEEE (Waste electrical and electronical equipment) x
Software (compatibility / preinstalled)
Microsoft Windows XP Professional x64 Edition - / -
Additional Software
Recovery DVD (Microsoft Windows XP / Vista) x / optional
Drivers and Utility DVD (DUDVD) (Microsoft Windows XP / Vista) x / optional
Altiris Local Recovery Pro (only for XP) Others
1024 x 768 (recommended / max*) 85 / 120 Hz
1280 x 1024 (recommended / max*) 85 / 120 Hz
1600 x 1200 (recommended / max*) 85 Hz
1440 x 900 widescreen TFT (VGA / DVI) - / x
1680 x 1050 widescreen TFT (VGA / DVI) x / x
1920 x 1200 widescreen TFT (VGA / DVI) x / x
5,1kJ/h / 4,8BTU/h
(P4 651 in dB(A) only)
safety)
ISO9241 (GS mark)
IEC60950, EN60950,
EN55022/B, EN55024, EN61000-3-2/3
Energy Star -
Blue Angel -
Nordic Swan -
Microsoft Windows 2000 - / -
Microsoft Windows XP Home x / -
Microsoft Windows XP Professional x / optional
Microsoft Windows Vista x / optional
Microsoft Windows Vista™ capable
(min. 512MB RAM necessary)
Microsoft Windows Vista™ Premium Ready
(min. 1GB RAM / DVD reader necessary) x
Linux certified -
1,4W
0,9W
E6400
x
Page 4
Data Sheet ⏐ Issue: February 2007⏐ ESPRIMO Edition E3500 Page 4 / 4
Spare part availability 3 years
Compatibility (references)
Microsoft Operating Systems (HCT / HCL entry) x
PC 2001, DMI 2.0, WMI 1.5, USB 2.0 x
Manageability
DeskView 10.x client management including:
On/Offline remote client management -
Detailed system inventory management and reports -
BIOS Management -
Remote power management -
System notifications -
Advanced alerts (ASF implementation) -
Security Remote Control -
DeskView Helpdesk Integration DeskUpdate Driver management DeskView Migrate optional
DeskView Control optional
PXE 2.1 Boot code x
BootP Boot Code including Bootmanage Administrator Software Wake up from S5 (off mode) x
Intrusion switch Security
Physical Security implemented in the cabinet
Prepared for Kensington lock, eye for padlock x
Integrated cabinet lock System Security
Boot sector virus protection x
Write protect option for the Flash EPROM Embedded security (TPM1.2) Norton Internet Security (NIS) x
Boot protection for floppy disk/CD drive and write protection for floppy disk
drive Control of external interfaces x
User Security
User and supervisor BIOS password x
SystemLock BIOS SmartCard Security SystemLock 2 BIOS SmartCard Security Hard disk password Access protection via external Smart Card reader optional
Access protection via internal SmartC ard re ad er Fujitsu Siemens Computers MEMORYBIRD BIOS lock Serviceability
FlexySlot EasyFix EasyChange (for HDD / for optical drives) EasyPull -
