LIFESTYLE
RANGE
WALL
MOUNTED
STYLISH, SLIM AND ELEGANT
HIGH ENERGY EFFICIENCY
5 YEAR FULL PARTS & LABOUR WARRANTY
WHY CHOOSE FUJITSU?
AUSTRALIA’S FAVOURITE AIR
Fujitsu is a leading supplier of air conditioners in Australia, with a portfolio to suit both residential and commercial applications.
We focus all of our research and manufacturing strengths into air conditioners which has resulted in the extensive range
of world-class, energy efficient, market-leading air conditioners.
That’s why we’re proud to say we are ‘Australia’s Favourite Air
®
®
’.
PEACE OF MIND
Fujitsu believe in the quality and reliability of every air conditioner we sell. This is why we’re
happy to provide a 5 year parts and labour warranty across the entire domestic range.
FUJITSU CHANNEL PARTNER NETWORK
Fujitsu have a comprehensive network of retailers and dealers right across Australia. This ensures there is a local stockist in your
area to assist you in purchasing a Fujitsu air conditioning system for your home.
WHY CHOOSE FUJITSU?
EXCEPTIONAL AFTER SALES SERVICE
At Fujitsu, we pride ourselves on providing exceptional customer service. Fujitsu General Assist is our in-house customer care
and technical support department which was implemented to deliver a high level of support and accessibility to our customers.
Fujitsu General Assist deploys factory trained technicians in Sydney, Melbourne, Brisbane, Adelaide and Perth and provides
access to dedicated Service Agents in all other parts of Australia. These technicians are well equipped with the necessary
tools and spare parts to enable them to resolve issues onsite, promptly. This offers customers a high first time fix rate and
seamless experience.
1300 658 840
4
STATE OF THE ART RESEARCH AND DEVELOPMENT
Our state of the art research and development centre, located at our headquarters in Japan, is equipped
with numerous testing facilities simulating a variety of air conditioning operating conditions.
PERFORMANCE TESTING UNDERTAKEN INCLUDES:
n Evaluating the units heating and cooling capacity under varied temperature and humidity conditions.
n Testing the units air volume and air flow distance.
n Measuring units operating noise.
n Evaluating units durability to withstand outdoor weather extremes.
This rigorous testing is aimed at meeting Fujitsu’s high standard of quality and reliability.
5
LIFESTYLE RANGE
WALL MOUNTED
ASTG09/12KMCA
ASTG07/09/12CMCA
ASTG18/22/24KMCA
ASTG18/24CMCA
ASTG30/34KMTA
ASTG30/34CMTA
6
STYLISH, SLIM AND ELEGANT
90º
100º
7M
7M
MODEL RANGE
Fujitsu General’s KM and CM series have a stylish design across the range, to blend in seamlessly with your home’s decor.
EASE OF USE
The KM and CM ranges are accompanied by a simple and easy to use controller, giving you simple control of your climate, right at your fingertips.
With features such as low noise mode, economy operation and program timers, you can tailor your comfort needs at the touch of a button.
ENERGY EFFICIENCY
The KM and CM series are amongst the most energy efficient air conditioners Fujitsu has designed. With built-in features such as high efficiency
DC componentry, Power Diffusers, and High Density Multi-path Heat Exchangers, these air conditioners use less power than ever before.
With some models reaching a 5 star energy rating, year round comfort can be more affordable for you and your family.
Heating
ASTG09KMCA
ASTG09KMCA
HUMAN SENSOR CONTROL
All models in the KM and CM series contain human sensor control, an intelligent feature which detects movement of people to deliver optimum
efficiency and temperature control. When in operation, if the sensor detects no movement in a room after 20 minutes, the air conditioner will
be switched to energy saving operation, modifying the temperate to minimise energy consumption.
When movement is detected within the room, the air conditioner reverts to its previous setting.
7
AUTOMATIC LOUVRE
AUTO SHUT LOUVRE
ADJUST
LOW NOISE
FEATURES
*
COMFORT
FUNCTIONS
10°C
10º C HEAT OPERATION
HEAT
The room temperature can be set to go no lower than 10°C,
ensuring that the room does not get too cold when not occupied.
UP / DOWN SWING LOUVRE
The up / down louvre automatically swings up and down.
RIGHT / LEFT SWING LOUVRE
LEFT/RIGHT
The right / left louvre automatically swings in either direction.
DOUBLE SWING AUTOMATIC*
Complex swing action of the louvres enables them to swing
automatically in both horizontal and vertical directions.
AUTOMATIC LOUVRE
The position of the louvres is set automatically to match
the operating mode. It is also possible to adjust the louvres
using the remote control.
CONVENIENCE
FUNCTIONS
SLEEP TIMER
The micro-processor gradually changes the room
temperature, allowing youto sleep comfortably at night.
PROGRAM TIMER
This timer allows selection of one of four options; ON, OFF,
ON -> OFF, orOFF -> ON.
FILTER SIGN
Select appropriate intervals for displaying the filter sign on
the indoor unit according to the estimated amount of dust in
the air of the room.
ON
ON-OFF TIMER
OFF
TIMER
ON-OFF timer can be set to operate once every 24 hours.
WEEKLY TIMER
Different ON-OFF times can be set for up to 7 days.
AUTO SHUT LOUVRE
The auto shut louvres close or open automatically when
theunit stops orstarts.
AUTOMATIC AIR FLOW ADJUSTMENT
When auto mode is selected for the fan, the micro-processor
adjusts the airflow to follow changes in room temperature.
AUTO RESTART
Should there be temporary loss of power, the unit will
automatically restart itself in the same operating mode,
once the power is restored.
AUTO-CHANGEOVER
AUTO
CHANGEOVER
The unit automatically switches between heating and
cooling modes based on the temperature setting and room
temperature.
POWERFUL MODE
POWERFUL
This mode will operate the air conditioner at maximum
capacity for 20 minutes, providing comfort faster than
everbefore.
WEEKLY + SETBACK TIMER
Weekly + Setback timer can set temperature for two time
spans and for each day of the week.
LOW NOISE MODE
The compressor speed and the outdoor unit fan speed are
limited to reduce the operational noise.
SUPER QUIET MODE
QUIET
The indoor units fan can operate at a low speed to produce
quieter operation.
8
ENERGY EFFICIENT
ALL
* Note: not all features available on all models,
please refer to features checklist.
FUNCTIONS
HUMANSENSOR
The human sensor detects movement so that when occupants
leave the room, the air conditioner switches into energy saving
mode after 20minutes should no movement be detected. When
occupants reenter theroom, it returns to normal operation.
V-PAM
V-PAM
V-PAM inverter technology increases the maximum output
of the compressor significantly and enables highpower
andhigh efficiency.
i-PAM
i-PAM
i-PAM inverter technology enables high output and
highefficiency performance.
DEMAND CONTROL
DC
This product is designed to be compatible with
Air Conditioning Demand Response program. When your
electricity supplier activates one of the threemodes, the
airconditioner switches over to the appropriate operation.
CLEAN FUNCTIONS
WASHABLE PANEL
Dust which accumulates on the air conditioner can be easily
cleaned with a damp cloth.
APPLE-CATECHIN FILTER
Fine dust, invisible mould spores and harmful
microorganisms are absorbed onto the filter by static
electricity and further growth is inhibited and deactivated
by the polyphenol ingredient extracted from apples.
LONG-LIFE ION DEODORISATION FILTER
ION
The filter deodorises by powerfully decomposing absorbed
odours using the oxidising and reducing effects of ion
generated by the ultra-fine-particle ceramic.
ECONOMY MODE
ECONOMY
The economy operation will save energy in heating,
cooling and drymode. Economy operation is set
by pressing the button on the remotecontrol.
FEATURES CHECKLIST
o Optional feature when using a wired controller and communication kit.
REVERSE CYCLE COOLING ONLY
FEATURES ASTG09/12KMCA ASTG18/22/24KMCA ASTG30/34KMTA ASTG07/09/12CMCA ASTG18/24CMCA ASTG30/34CMTA
COMFORT FUNCTIONS
Up / Down swing louvres
Right / Left swing louvre
Automatic louvre
Auto shut louvre
Double auto swing louvres
Automatic air flow adjustment
Auto restart
Auto-changeover
10°C HEAT operation
Powerful mode
Low noise mode
Super quiet mode
Sleep timer
Program timer
Weekly timer
Weekly + setback timer
On-off timer
Filter sign
i-PAM / V-PAM control models
Demand Control
Human sensor
Economy mode
Long-life ion deodorisation filter
Apple-catechin filter
Washable panel
� � � � � �
� � � �
� � � � � �
� � � � � �
� � � �
� � � � � �
� � � � � �
� � � � � �
� � �
� � � � � �
CONVENIENCE FUNCTIONS
� � � � � �
� � � � � �
� � � � � �
� � � � � �
� � � � � �
o o o o o o
� � � � � �
� � � � � �
ENERGY EFFICIENT FUNCTIONS
� � � � � �
� � � � � �
� � � � � �
� � � � � �
CLEAN FUNCTIONS
� � � � � �
� � � � � �
� � � � � �
SPECIFICATIONS & FEATURES
Products in this brochure contain R32 refrigerant. Please refer to specifications before installation and servicing this product.
Only persons and / or companies qualified and experienced in the installation, service and repair of refrigerant products
should be permitted to do so. The purchaser must ensure that the person and / or company who is to install, service or
repair this air conditioner has qualifications and experience in refrigerant products.
Suitable access for warranty and service is required. Future improvements, specifications, designs of product and availability
are subject to change without notice. Please check with your dealer.
ALL CAPACITY AND ENERGY EFFICIENCY RATINGS ARE BASED ON AS / NZS3823.2.
COOLING
HEATING
Running current is at rated conditions (AS3823) and does not include compressor start-up or variations in power supply and load conditions.
Indoor temperature 27°C DB / 19°C WB
Outdoor temperature 35°C DB
Indoor temperature 20°C DB
Outdoor temperature 7°C DB / 6°C WB
10
INDOOR UNITS
ASTG09/12KMCA and ASTG07/09/12CMCA
with standard controller
ASTG30/34KMTA and ASTG30/34CMTA
with standard controller
OUTDOOR UNITS
ASTG18/22/24KMCA and ASTG18/24CMCA
with standard controller
AOTG09/12KMCA
AOTG07/09/12CMCA
AOTG18/22/24KMCA
AOTG18/24CMCA
AVAILABLE OPTIONAL CONTROLLERS
Backlit Wired Remote Controller*
(High grade)
*Optional Communication Kit required for connection.
#
30 / 34 only.
Simple Wired Controller* Simple Wired Controller*#
AOTG30KMTA
AOTG30CMTA
Wired Remote Controller*
11
AOTG34KMTA
AOTG34CMTA
Wired Touch Controller*
#
(High Grade)
PRODUCT SPECIFICATIONS
REVERSE CYCLE
Model No.
Indoor Unit
Outdoor Unit AOTG09KMCA AOTG12KMCA AOTG18KMCA AOTG22KMCA AOTG24KMCA AOTG30KMTA AOTG34KMTA
Operation Type Reverse Cycle Reverse Cycle Reverse Cycle Reverse Cycle Reverse Cycle Reverse Cycle Reverse Cycle
Power Source V / Ph / HZ 240 / 1 / 50 240 / 1 / 50 240 / 1 / 50 240 / 1 / 50 240 / 1 / 50 240 / 1 / 50 240 / 1 / 50
ASTG09KMCA ASTG12KMCA ASTG18KMCA ASTG22KMCA ASTG24KMCA ASTG30KMTA ASTG34KMTA
Capacity
Input Power
EER Cooling kW / kW 4.90 4.07 4.10 3.77 3.53 3.45 3.38
COP Heating kW / kW 4.92 4.57 4.23 4.07 3.77
Star Rating
Running Current Cooling / Heating Amps 2.7 / 3.3 4.2 / 4.0 5.2 / 6.0 6.7 / 7.5 8.5 / 9.0 10.4 / 10.1 11.7 / 12.9
Moisture Removal L / Hr 1.3 1.8 2.6 2.7 2.7 2.5 3.5
Noise Level
Air Circulation (Indoor - High Fan) l / sec 194 200 258 278 311 389 389
Net Dimensions
HxWxD
Cooling kW 2.5 (0.9-3.6) 3.5 (0.9-4.10) 5.0 (1.00-6.50) 6.0 (1.10-7.50) 7.10 (1.10-8.30) 8.5 (2.9-10.5) 9.4 (2.9-11.2)
Heating kW 3.2 (0.9-5.30) 3.7 (0.9-5.6) 6.00 (1.05-8.30) 7.20 (1.10-9.70) 8.00 (1.10-10.60) 9.00 (2.2-11.2) 10.3 (2.7-11.7)
Cooling kW 0.51 (0.25-1.14) 0.86 (0.25-1.38) 1.22 (0.21-2.20) 1.59 (0.21-2.85) 2.01 (0.21-2.90) 2.46 (0.58-3.85) 2.78 (0.59-4.03)
Heating kW 0.65 (0.25-1.60) 0.81 (0.25-1.70) 1.42 (0.20-3.10) 1.77 (0.20-3.40) 2.12 (0.20-3.68) 2.34 (0.50-4.01) 2.84 (0.6-4.24)
3.84
Cooling 5 3.5 3.5 3 2.5 2 2
Heating 5 4.5 3.5 3.5 3 3 2.5
Indoor Sound Pressure
(High / Quiet)
Outdoor Sound Pressure dBA 47 49 47 49 52 50 50
Outdoor Sound Power dBA 64 67 65 70 70 67 67
Indoor Unit
Outdoor Unit
dBA 40 / 21 42 / 21 46 / 29 48 / 32 49 / 32 51 / 33 52 / 33
mm 268 x 840 x 203 268 x 840 x 203 295 x 940 x 270 295 x 940 x 270 295 x 940 x 270 340 x 1,150 x 280 340 x 1,150 x 280
kgs 8.5 8.5 14 14 14 18 18
mm 540 x 790 x 290 540 x 790 x 290 620 x 790 x 290 620 x 790 x 290 620 x 790 x 290 830 x 900 x 330 914 x 970 x 370
kgs 34 34 40 40 40
61 75
3.63
Piping Connections (Liquid / Suction) mm Ø6.35 / Ø9.52 Ø6.35 / Ø9.52 Ø6.35 / Ø12.70 Ø6.35 / Ø12.70 Ø6.35 / Ø12.70 Ø9.52 / Ø15.88 Ø9.52 / Ø15.88
Max. Pipe Length (Precharged Length) m 20 (20) 20 (20) 30 (20) 30 (20) 30 (20) 75 (20) 75 (30)
Max. Height Difference m 15 15 20 20 20 30 30
Operation Range
Cooling °CDB 10 to 46 10 to 46 -10 to 46 -10 to 46 -10 to 46 -10 to 46 -10 to 46
Heating °CDB -15 to 24 -15 to 24 -15 to 24 -15 to 24 -15 to 24 -15 to 24 -15 to 24
Refrigerant R32 R32 R32 R32 R32 R32
R32
12
COOLING ONLY
Model No.
Indoor Unit
Outdoor Unit AOTG07CMCA AOTG09CMCA AOTG12CMCA AOTG18CMCA AOTG24CMCA AOTG30CMTA AOTG34CMTA
Operation Type Cooling Only Cooling Only Cooling Only Cooling Only Cooling Only Cooling Only Cooling Only
Power Source V / Ph / HZ 240 / 1 / 50 240 / 1 / 50 240 / 1 / 50 240 / 1 / 50 240 / 1 / 50 240 / 1 / 50 240 / 1 / 50
ASTG07CMCA ASTG09CMCA ASTG12CMCA ASTG18CMCA ASTG24CMCA ASTG30CMTA ASTG34CMTA
Capacity
Input Power
EER Cooling kW / kW 5.00 4.9 4.07 4.1 3.53 3.45 3.38
COP Heating kW / kW - - - - - - -
Star Rating
Running Current Cooling / Heating Amps 2.2 2.7 4.2 5.2 8.5 10.4 11.7
Moisture Removal L / Hr 1 1.3 1.8 2.6 2.7 2.5 3.5
Noise Level
Air Circulation (Indoor - High Fan) l / sec 172 194 200 258 311 389 389
Net Dimensions
HxWxD
Cooling kW 2.1 (0.9-3.5) 2.5 (0.9-3.6) 3.5 (0.9-4.1) 5.0 (1.0-6.5) 7.1 (1.1-8.3) 8.5 (2.9-10.5) 9.4 (2.9-11.2)
Heating kW - - - - - - -
Cooling kW 0.42 (0.25-1.04) 0.51 (0.25-1.14) 0.86 (0.25-1.38) 1.22 (0.21-2.20) 2.01 (0.21-2.90) 2.46 (0.58-3.85) 2.78 (0.59-4.03)
Heating kW - - - - - - -
Cooling 5.5 5 3.5 3.5 2.5 2 2
Heating - - - - - - -
Indoor Sound Pressure
(High / Quiet)
Outdoor Sound Pressure dBA 44 47 49 47 52 51 51
Outdoor Sound Power dBA 60 64 67 65 70
Indoor Unit
Outdoor Unit
dBA 38 / 21 40 / 21 42 / 21 46 / 29 49 / 32 51 / 32 51 / 32
66 65
mm 268 x 840 x 203 268 x 840 x 203 268 x 840 x 203 295 x 940 x 270 295 x 940 x 270 340 x 1,150 x 280 340 x 1,150 x 280
kgs 8.5 8.5 8.5 14 14 18 18
mm 540 x 790 x 290 540 x 790 x 290 540 x 790 x 290 620 x 790 x 290 620 x 790 x 290 830 x 900 x 330 914 x 970 x 370
kgs 33 33 33 39 39 61 74
Piping Connections (Liquid / Suction) mm 6.35 / 9.52 6.35 / 9.52 6.35 / 9.52 6.35 / 12.7 6.35 / 12.7
Max. Pipe Length (Precharged Length) m 20 (20) 20 (20) 20 (20) 30 (20) 30 (20) 75 (20) 75 (30)
Max. Height Difference m 15 15 15 20 20 30 30
Cooling °CDB 10 to 46 10 to 46 10 to 46 -10 to 46 -10 to 46 -10 to 46 -10 to 46
Operation Range
Heating °CDB – – – – – – –
Refrigerant R32 R32 R32 R32 R32 R32 R32
9.52 / 15.88 9.52 / 15. 88
13
FUJITSU - COMMUNITY
SPORTING CHANCE
Fujitsu General Australia is extremely proud to be a major sponsor of the Sporting Chance Cancer Foundation.
Established in 1996 by a number of high profile Australian sports men and women, including Fujitsu Generals’
longstanding ambassador Mark Taylor, Sporting Chance is a not-for-profit organisation that helps provide home
support and care to children with cancer.
To date, Fujitsu General has donated more than $6M to this worthy cause, with a percentage of sales from Fujitsu’s
air conditioning units going towards the funding of outreach programs and exploring better ways to treat and
overcome cancer.
This support has enabled the Sporting Chance Cancer Foundation to fund nurses across Australia allowing children
to receive improved cancer care closer to home. This funding also allows for remote treatment and care for families,
and considerably reduces the time spent travelling to and from the nearest hospital, which could be thousands
of kilometres from home.
Sporting Chance initiatives allow families to spend more quality time at home together, while still having access
to the correct care for their child.
Fujitsu General is dedicated to the ongoing support of the Sporting Chance Cancer Foundation and its commitment
to improving the cancer care available for children, as well as research and new treatment developments.
14
FUJITSU GENERAL AUSTRALIA
ABN 55 001 229 554 • A SUBSIDIARY OF FUJITSU GENERAL LIMITED
www.fujitsugeneral.com.au
EMAIL contact@fujitsugeneral.com.au
PHONE 1300 882 201
Proud sponsors of:
For every air conditioner sold, a
donation is made to the Sporting
Chance Cancer Foundation.
FGAL07/17
If you are looking for an air conditioner that you can trust
to keep you comfortable all year round, my advice is to
look no further than a Fujitsu.
They are efficient, effective, and beautifully designed,
I should know, I bought one myself.
So for an air conditioner you can trust, go with the name
you know, Fujitsu, It’s Australia’s Favourite Air®.
Loading...
