DQD 507 Rev. 2019-04-30 © 2018 CSA Group. All rights reserved. Page 1
Certificate of Compliance
Certificate:
2607380
Master Contract:
203213
Project:
80126332
Date Issued:
2022-11-25
Issued To:
Fronius International GmbH
Guenter Fronius Strasse 1
Wels-Thalheim, Upper Austria, 4600
Austria
Attention: Josef Feichtinger
The products listed below are eligible to bear the CSA Mark shown with
adjacent indicators 'C' and 'US' for Canada and US or with adjacent
indicator 'US' for US only or without either indicator for Canada only.
Issued by:
Sven Renke
Sven Renke
PART A:
PART A1:
Model “WF 25i” followed with suffixes, Wire Feeders for MIG/MAG process, Input rated: 60Vdc -
1.2A, 24Vdc - 0.5 A, supplied from a certified welding power source specified by Fronius. Weld rated:
450A at 60% Duty Cycle, 360A at 100% Duty Cycle; IP23.
PART A2:
Model “WF 15i” followed with suffixes, Wire Feeders for MIG/MAG process, water-cooled, Input rated:
60Vdc - 1A, 24Vdc - 0.5 A, supplied from a certified welding power source specified by Fronius. Weld
rated: 650A at 40% Duty Cycle, 600A at 60% Duty Cycle and 500A at 100% Duty Cycle; IP23.
Certificate: 2607380
Project: 80126332
Master Contract: 203213
Date Issued: 2022-11-25
DQD 507 Rev. 2019-04-30 © 2018 CSA Group. All rights reserved. Page 2
PART A3:
Model “WF 30i” followed with suffixes, Wire Feeders for MIG/MAG process, water-cooled, Input rated:
60Vdc – 1.4A, 24Vdc - 0.5 A, supplied from a certified welding power source specified by Fronius. Weld
rated: 650A at 40% Duty Cycle, 600A at 60% Duty Cycle and 500A at 100% Duty Cycle; IP23.
PART B
PART B1:
Model “WF 25i Case” followed with suffixes, Wire Feeders for MIG/MAG process, wire spool diameter
max 200mm (D200) Input rated: 60Vdc - 1.2A, 24Vdc - 0.5 A, supplied from a certified welding power
source specified by Fronius. Weld rated: 450A at 60% Duty Cycle, 360A at 100% Duty Cycle; IP23.
PART B2:
Model “WF 25i Case/D300” followed with suffixes, Wire Feeders for MIG/MAG process, wire spool
diameter max 300mm (D300) Input rated: 60Vdc - 1.2A, 24Vdc - 0.5 A, supplied from a certified
welding power source specified by Fronius. Weld rated: 450A at 60% Duty Cycle, 360A at 100% Duty
Cycle; IP23.
PART C
Model “WF 25i Dual” followed with suffixes, Wire Feeders for MIG/MAG process, wire spool diameter
300 - 450mm Input rated: 60Vdc - 1.2A, 24Vdc - 0.5 A, supplied from a certified welding power source
specified by Fronius. Weld rated: 450A at 60% Duty Cycle, 360A at 100% Duty Cycle; IP23.
PART D
Model “CWF 25i ” followed with suffixes, Wire Feeders for TIG process, wire spool diameter max
300mm Input rated: 60Vdc - 1.2A, 24Vdc - 0.5 A, supplied from a certified welding power source
specified by Fronius. Weld rated: 450A at 60% Duty Cycle, 360A at 100% Duty Cycle; IP23.
APPLICABLE REQUIREMENTS
CAN/CSA-E60974-1-19 - Arc Welding Equipment – Part 1: Welding Power Sources
CAN/CSA-E60974-5:09 - Arc Welding Equipment – Part 5: Wire feeders
ANSI/IEC 60974-1: 2019 - Arc Welding Equipment – Part 1: Welding Power Sources
ANSI/IEC 60974-5: 2009 - Arc Welding Equipment – Part 5: Wire feeders
