Stainless Chimney Wall-Mount Hood
RH30WC55G S
30" STAINLESS CHIMNEY WALL-MOUNT HOOD
Features
High-Quality Premium
Stainless Steel
Classic ventilation hood is constructed
of high-quality stainless steel, making it
durable yet attractive and easy to clean.
Nominal Width
Installation Type
Air Discharge
Air Delivery (CFM)
Blower Type
Electronic Controls with LCD Display
Fan Speeds
Sound Level (dBA)
Dual Halogen Lights
Washable Stainless Steel Filters
Exhaust Duct
Duct Required
Accessories
Duct-Free Kit – RHDFW60GS
52" Flue Extension – RHXWC55GS
Specifications
Overall Exterior Dimensions –
Width
Height (With One Cover)
(With Flue Extension)
Depth
Voltage Rating
Connected Load (kW Rating) @120 Volts
Product Weight
Shipping Weight
Sones Rating
* Ventilation is convertible to be either ducted outside, or recirculated inside requiring no ducting.
(Recirculated option requires use of optional Duct-Free Kit.)
‡ For use on adequately wired 120V, dedicated circuit having 2-wire service with a separate
ground wire. Appliance must be grounded for safe operation.
NOTE: Always consult local and/ or national electric codes. Check local building codes for
installation requirements, as they may very per locale. Refer to Product Installation Guide
for detailed installation instructions on the web at www.electroluxappliances.com.
Specifications subject to change.
‡
30"
Wall Mount
Vertical
600
Dual Centrifugal
Yes
4
72.4
Yes
Yes
Convertible*
8" Round
Optional
Optional
29-7/8"
24" min.
24-5/8" min.
42-9/16" max.
19-11/16"
120V/ 60Hz / 15A
0.475
36 Lbs.
39 Lbs.
9.0
Wall OvensWarmer DrawersCooktopsBuilt-In Ranges
Ranges
Freestanding
MicrowavesVent HoodsDishwashersRefrigerators
600 CFMs / 4-Speed Fan
Supplies a maximum of 600 CFM of air
movement using a variable 4-speed dual
centrifugal fan. Removes smoke, vapors
and smells effectively and more quietly
than typical exhaust fans.
Dual Halogen Lights
Dual halogen lights provide ample
illumination of the cooking surface below
with lights located at two different levels.
Electronic Controls
with LCD Display
Easy-to-operate electronic controls
provide convenient access to all fan,
clock and timer settings.
FreezersUnder Counter
electroluxappliances.com
Stainless Chimney Wall-Mount Hood
RH30WC55G S
11
10
/16"
133/16"
49/16"
Top
Controls
Wiring boxAir outlet - 77/8" diam.
Dimensions
from base of
hood to ceiling,
and include
245/8"
min.
9
42
max.
/16"
clearance
required for
installation.
24"
( min.
height
with one
cover)
5"
11
19
/16"
29 7/8"
30" Stainless Chimney Wall-Mount Hood Specifications
•
Product Weight – 36 Lbs.
•
Wall-Mount Installation
•
Ventilation is convertible to be either ducted outside, or recirculated
inside requiring no ducting.
•
Sones Rating – 9.0
•
Voltage Rating –120V /60 Hz/15 Amps
•
Connected Load (kW Rating) @120 Volts = 0.475 kW (For use on
adequately wired 120V, dedicated circuit having 2-wire service with a
separate ground wire. Appliance must be grounded for safe operation.)
•
Amps @120 Volts = 3.84 Amps
•
Always consult local and/or national electric codes. Check local
building codes for installation requirements, as they may vary per locale.
•
Minimum installation height allowed from bottom of hood to cooking
surface is 24"- 30" for electric and 30" for gas. (NOT more than 36"
recommended.)
•
To prepare mounting surface, adequate structure and support must be
provided, capable of supporting 100 lbs.
Ducted Option Specifications
•
For outside ventilation only.
•
Exhaust Duct Required – 8" round
•
For most efficient airflow exhaust, use a straight run or as few elbows
as possible.
•
Use metallic flex ducting only to connect rigid duct directly to transitions
(if allowed by code).
•
Thermal breaks such as short section of nonmetallic duct, should
be used in areas of extreme cold.
•
Cold weather installations should have additional backdraft damper
installed.
•
Refer to web for detailed duct preparation installation instructions.
Ductless (Recirculated) Option Specifications
•
If ducting to outside is not an option, vent hood can be converted to
ductless with use of optional Duct-Free Kit (RHDFW60GS).
•
Refer to web for detailed convertible ventilation installation instructions.
Note: For planning purposes only. Refer to Product Installation Guide
on the web at electroluxappliances.com for detailed instructions.
Optional Accessories
•
Duct-Free Kit – (RHDFW60GS).
•
52" Flue Extension – (RHXWC55GS).
•
USA
250 Bobby Jones Expressway •Augusta, GA 30907 •1-877-4electrolux (1-877-435-3287)
•
CANADA
RH30WC55G 02/08 © 2008 Electrolux Major Appliances, NA Printed in the U.S.A.
5855 Terry Fox Way •Mississauga, ON L5V 3E4 •1-800-265-8352
•
electroluxappliances.ca
•
electroluxappliances.com
High standards of quality at Electrolux Major Appliances mean we are
constantly working to improve our products. We reserve the right to change
specifications or discontinue models without notice.
