FRIGIDAIRE FFEW3025PW User Manual
Drop-In Cooktop
Single Wall Ovens
FPEC3085K S
FFEW3025P S / W / B
30" Electric
30" Electric
Product Dimensions
Height 29"
Width 30"
Depth 24-3/4"
More Easy-To-Use Features
Delay Clean Option
Set the oven to begin cleaning on your
schedule.
Bright Lighting
Our bright lighting makes it easy to see
what’s inside.
Timed Cook Option
Lets you set the oven to begin cooking
at a predetermined time.
Auto Shut-O
As an extra safety measure, the oven
will automatically shut off after 12 hours.
Attractive Stainless
Steel Exterior
Built with American Pride
Appliances that are high-performing,
more accessible, and more innovative
than ever—designed, built, and
engineered in the U.S.A.
1
Signature Features
Even Baking Technology
Our Even Baking Technology ensures
even baking every time.
Vari-Broil™
Temperature Control
Allows you to choose between two
heat levels.
Self-Cleaning
Your oven cleans itself - so you don't
have to. Self clean options available in
2, 3, and 4-hour cycles.
Ready-Select® Controls
Easily select options or control cooking
temperature with our easy-to-use controls.
A.D.A. Compliant
When properly installed, this model
is A.D.A.-qualified based on the United
States Access Board’s A.D.A./A.B.A.
Accessibility Guidelines and the
Department of Justice’s 2010 A.D.A.
Standards for Accessible Design.
Sabbath Mode (Star-K® Certified)
Available in:
Stainless
(S)
1
Select model only.
White
(W)
Black
(B)
frigidaire.com
E
D
B
C
A
Spacer
Features
Oven Control / Timing System
Window
Exterior Door Finish
Handle Design
Oven Cleaning System
Ready-Select®
Extra-Large
Stainless Steel (S),
Color-Coordinated (W/B)
Stainless Steel (S),
Color-Coordinated (W/B)
Self-Clean
Oven Controls
Bake / Broil
Convection Conversion
Convection Bake / Broil / Roast
Quick Bake Convection
PowerPlus® / Quick Preheat
My Favorite
Slow Cook
Eortless™ Temperature Probe
Chicken Nugget Button
Pizza Button
Keep Warm
Add-a-Minute
Delay Start
Self-Clean / Clean Options
Steam Clean
Delay Clean
Kitchen Timer
Timed Cook Option
Control Lock
Auto Oven Shut-O
Oven Lock-Out
Yes / Variable (400 - 550°F)
Yes
Yes
Yes / 2, 3, 4 Hours
Yes
Yes
Yes
Yes
12 Hours
Yes
Oven Features
Capacity (Cu. Ft.)
Convection System
Oven Light
Hidden Bake Element
Rack Configuration
Baking System
Broiling System
Bake / Broil Element (Watts)
4.6
1 Halogen
Yes
2 Handle Racks
Even Baking Technology
Vari-Broil™
2,000 / 3,400
Optional Accessories
3"-High Bottom Trim – Stainless
Steel (S) / White (W) /Black (B)
10'-Long Armored Power Cable
(S) PN # 318259707
(W) PN # 318259703
(B) PN # 318259704
PN # 903056-9010
Certifications
A.D.A. Compliant
Sabbath Mode (Star-K® Certified)
1
Yes
Yes
Specifications
Oven Interior ( H x W x D )
Power Supply Connection Location
Voltage Rating
Connected Load
(kW Rating) @ 240 / 208 Volts
Amps @ 240 / 208 Volts
Minimum Circuit Required (Amps)
Approved for Under-Counter
Installation
Shipping Weight (Approx.)
1
When properly installed, this model is A.D.A.-qualified based on the
United States Access Board’s A.D.A./A.B.A. Accessibility Guidelines and
the Department of Justice’s 2010 A.D.A. Standards for Accessible Design.
2
Single phase 3- or 4-wire cable, 120 / 240 or 120 / 208 Volt, 60 Hertz AC
only electrical supply with ground required on separate circuit fused on
both sides of line.
17-1/2" x 24-1/8" x 18-3/4"
Left Bottom Rear
240V / 208V / 60Hz
3.7 /2.8
2
15.4 / 13.5
20
Yes
140 Lbs.
Single Wall Ovens
FFEW3025P S / W/ B 30" Electric
NOTE: For planning purposes only. Always consult local and national electric codes.
Refer to Product Installation Guide for detailed installation instructions on the web
at frigidaire.com.
Product Dimensions
A - Height
B - Width
C - Depth
D - Height (Wrapper)
E - Width (Wrapper)
Depth with Door Open 90˚
29"
30"
24-3/4"
27-3/16"
28-1/4"
45-3/4"
Cutout Dimensions
Height (Min.)
Height (Max.)
Width (Min.)
Width (Max.)
Depth (Min.)
27-1/4"
28-5/8"
28-1/2"
29"
23-1/2"
•
USA
10200 David Taylor Drive
•
CANADA
FFEW3025P 10/13 © 2013 Electrolux Home Products, Inc.
5855 Terry Fox Way
•
Charlotte, NC 28262
•
Mississauga, ON L5V 3E4
•
1-800-FRIGIDAIRE
•
1-800-265-8352
•
frigidaire.com
•
frigidaire.ca
Accessories information available
on the web at frigidaire.com
Specifications
subject to change.
30" Single Electric Wall Oven
Baseline
Single Wall Ovens
FFEW3025P S / W/ B 30" Electric
Single Wall Oven Specifications
•
Product Shipping Weight (approx.) – 140 Lbs.
•
Single phase 3- or 4-wire cable, 120 / 240 or 120 / 208 Volt, 60 Hertz
AC only electrical supply with ground required on separate circuit
fused on both sides of line.
•
Connected Load (kW Rating) @ 240 / 208 Volts = 3.7 / 2.8 kW
•
Amps @ 240 / 208 Volts = 15.4 / 13.5 Amps
•
Recommended Circuit Breaker – 20 Amps
•
Always consult local and national electric codes.
•
Minimum 21" clearance for oven door depth when open.
•
Suggested distance from floor is 31". Minimum required distance
is 4-1/2".
•
Minimum 23-1/2" deep cutout dimension is critical for proper
installation, to ensure that oven’s faceplate will fit flush against
cabinet front.
•
To adapt oven to fit cutout height greater than 28-1/8", add one
2"-wide wood shim of appropriate height to each side of opening
under oven side rails. Lifting oven will hide larger cutout opening
at top and oven’s 1"-high bottom trim will hide shims at bottom.
(Standard 1"-High Bottom Trim included.)
•
To adapt oven to fit cutout height greater than 28-5/8", optional
3"-High Bottom Trim available.
USA • 10200 David Taylor Drive • Charlotte, NC 28262 • 1-800-FRIGIDAIRE • frigidaire.com
•
CANADA
FFEW3025P 10/13 © 2013 Electrolux Home Products, Inc.
5855 Terry Fox Way • Mississauga, ON L5V 3E4 • 1-800-265-8352 • frigidaire.ca
•
Full oven base of solid plywood or similar material required,
capable of supporting 200 Lbs.
•
Base must be level and cabinet front must be square.
•
Single Wall Oven is NOT approved to be used in stackable or
side-by-side installation.
•
Single Wall Oven is approved to be used alone in under-counter
installation or beneath any approved Frigidaire® gas or electric
cooktop. (Refer to Gas or Electric Cooktop Installation Over 30" / 27"
Electric Single Wall Oven Specifications pages on web.)
•
Single Wall Oven is approved to be used in combination with any
Frigidaire® Warmer Drawer. (Refer to model-specific Warmer Drawer
product page for Combination Installation Specifications.)
•
Single Wall Oven is approved to be used in combination with
any Frigidaire® Built-In Microwave Oven.
Note: For planning purposes only. Refer to Product Installation Guide
on the web at frigidaire.com for detailed instructions.
Optional Accessories
•
3"-High Stainless Steel Bottom Trim – (PN # 318259707).
•
3"-High White Bottom Trim – (PN # 318259703).
•
3"-High Black Bottom Trim – (PN # 318259704).
•
10'-Long Armored Power Cable – (PN # 903056-9010).
Accessories information available
on the web at frigidaire.com
Specifications
subject to change.
