DISHWASHER
Important Safety Instructions .....................2
Product Registration ..................................3
Features at a Glance ..................................4
Operating Instructions ...............................5
Preparing and Loading Dishes ....................9
use
Dishwasher Dispenser & Detergents .........12
Factors Aecting Performance ..................14
Care and Cleaning ................................... 15
Before You Call .......................................17
Major Appliance Warranty ........................19
&
care
117859022 RevC (May 2021)
Frigidaire.com USA 1-800-374-4432 Frigidaire.ca Canada 1-800-265-8352
IMPORTANT SAFETY INSTRUCTIONS
• When loading items to be washed:
WARNING
When using your dishwasher, follow basic
precautions, including the following:
For your Safety
• Use your dishwasher only as instructed in
this Use and Care Manual.
• This Manual does not cover every possible
condition and situation that may occur. Use
common sense and caution when installing,
operating and maintaining any appliance.
• NSF certied residential dishwashers are not
intended for licensed food establishments.
• DISHWASHER MUST BE ELECTRICALLY
GROUNDED. This appliance must be
connected to a ground metal, permanent
wiring system, or an equipment-grounding
conductor must be run with the circuit
conductors and connected to the equipmentgrounding terminal or lead on this appliance.
Read the Installation Instructions for details.
• This dishwasher is designed to operate on
regular house current (120V, 60Hz). Use
a circuit equipped with a 15 ampere fuse
or circuit breaker. Use a 20 ampere fuse if
dishwasher is connected with a food disposer.
• Do not operate dishwasher unless all
enclosure panels are in their proper place.
• Keep young children and infants away from
dishwasher when it is operating.
• Do not let children abuse, sit, stand or play
on door or racks of a dishwasher.
• To reduce the risk of injury, do not allow
children to play in or on the dishwasher.
• Use only detergents and rinse agents
recommended for use in a dishwasher.
• Store dishwasher detergent and rinse agents
out of the reach of children.
• If the dishwasher drains into a food disposer,
make sure disposer is completely empty
before running dishwasher.
• Do not wash plastic items unless marked:
“Dishwasher Safe” or equivalent. Check
with manufacturer for recommendations,
if not marked. Items that are not marked
dishwasher safe may melt and create a
potential re hazard.
- Locate sharp items and knives so that they
are not likely to damage the door seal or
tub.
- Load sharp items and knives with the
handles up to reduce the risk of cut type
injuries.
• Do not tamper with controls.
• Use care unloading the dishware when the
SANITIZE option has been selected. Contents
may be hot to the touch immediately after
the end of cycle.
• Under certain conditions, hydrogen gas may
be produced in a hot water system that
has not been used for 2 weeks or more.
HYDROGEN GAS IS EXPLOSIVE. If hot water
system has not been used for such a period,
before using dishwasher, turn on all hot
water faucets and let water ow from each
for several minutes. This will release any
accumulated hydrogen gas. HYDROGEN GAS
IS FLAMMABLE. Do not smoke or use an
open ame during this time.
• Do not store or use combustible materials,
gasoline or other ammable vapors and
liquids in the vicinity of this or any other
appliance.
• Disconnect electrical power to dishwasher
before servicing.
• Repairs should be done by a qualied
technician.
• To avoid entrapment and/or suocation,
remove door or door latch mechanism from
any dishwasher that is discarded or not in
use.
WARNING
To reduce the risk of re, electrical shock or
injury when using your dishwasher, follow the
above basic precautions .
WARNING
This symbols will help alert you to such dangers
as personal injury, burns, re and electrical
shock.
SAVE THESE INSTRUCTIONS
2
Thank you for choosing Frigidaire
This Use & Care Guide is part of our commitment
to customer satisfaction and product quality
throughout the service life of your new appliance.
We view your purchase as the beginning of a
relationship. To ensure our ability to continue
serving you, please use this page to record
important product information.
_________________________________
Purchase Date
_________________________________
Model Number
_________________________________
Serial Number
Registering your product with Frigidaire enhances
our ability to serve you. You can register online
at www.frigidaire.com or by dropping your
Product Registration Card in the mail.
PRODUCT REGISTRATION
NOTE
Very Important Information - Read Before
Operating Your Dishwasher!
Normal Operating Sounds
This dishwasher does not sound like most dishwashers - IT’S QUIETER.
Your Direct Feed Wash System dishwasher uses
energy ecient motors for the wash and drain
portions of the cycle you select. Each cycle has
a series of water lls and drains for washing
and rinsing dishes. As each cycle begins, you
may-or may not- hear the drain motor. The next
sound you will hear is the splashing water as it
enters the tub.
PLEASE BE ADVISED: If you compare this
dishwasher to previous models, you may be
surprised at what you DON’T hear.
NOTE
The dishwasher is programmed to remember
your last cycle so you do not have to reset each
time. To start the dishwasher using the same
cycle and options selected on the previous
wash, just press the START/CANCEL pad.
NOTE
Not all cycles and options available on all
models.
NOTE
Why Energy Ecient Units run long cycles: Several factors are important to washing dishware.
The energy use of the dishwasher was reduced
by applying more of the factors that don’t use
so much energy and less of the ones that use
more. As a result, you will see that the wash
cycles take longer.
Getting Started
1. Load Dishwasher (See Preparing and Loading
Dishes).
2. Add detergent (See Dishwasher Dispenser &
Detergents).
3. Add Rinse Aid, if needed (See Rinse Aid).
4. Run hot water faucet nearest dishwasher until
water is hot. Turn water o.
5. Select desired CYCLE (See Cycle Chart).
6. Select desired OPTION (See Option
Selections).
7. To start, press START/CANCEL pad and close
door immediately.
3
FEATURES AT A GLANCE
Your dishwasher cleans by spraying a mixture of hot water and detergent through the spray arms
against soiled surfaces. First, the dishwasher drains for a few seconds to remove soils dropped while
loading, then lls with water covering the lter area. Water is then pumped through the spray arms.
Soil particles go through and across the lter and down the drain as the water is pumped out. This
series of steps are repeated as needed. The number of water lls varies with the cycle being used.
Spray Arm
Third level rack
Tub Gasket
Upper Rack
Middle Spray
Arm
Lower Rack
Lower Spray
Arm
Detergent
Dispenser
Rinse Aid
Dispenser
Features may vary according to model.
Silverware
Basket
Filter
Serial Label
(located on
right side of
door)
To Start a Cycle
When cycle and options are selected, LEDs of selected cycle and options are illuminated. The status
window displays the cycle time and then displays ‘Press Start’.
To start the cycle, press START/CANCEL pad and close the dishwasher door immediately.
The status window displays ‘Close’ after the START/CANCEL pad is pressed.
A tone will sound indicating the cycle is successfully started after door is closed.
4
OPERATING INSTRUCTIONS
NOTE
Your dishwasher uses a DishSenseTM Technology to understand how much food is on the dishes and
then adjusts the cycle accordingly.
Wash Temp
CAUTION
Property Damage Hazard
Before starting dishwasher be sure that the
water is connected and turned on. Failure to
do so may cause damage to the pump seal and
result in water leakage.
Wash Cycle Selections
Cycle times are approximate and will vary with
options selected. Hot water is necessary to
activate dishwasher detergent and melt fatty food
soils. An automatic sensor will check the incoming
water temperature and, if it is not hot enough,
the cycle will be lengthened for automatic water
heating in the main wash and nal rinse of all
cycles. This happens even when HI-TEMP WASH
option has not be selected. When HI-TEMP WASH
is selected, an even higher temperature will be
reached to handle heavier soil loads.
Recommended Cycle for typical use:
The Normal cycle with its factory default options
of normal temperature and heated dry together
provide the best all around performance. This cycle
selection is recommended for everyday use and is
suitable for a large range of both dish load sizes
and food quantities remaining on those dishes.
Option Selections
Wash Pressure
The programmed cycles default to the “surge”
pressure option which varies the pressure optimally
for the cycle’s intended normal use. If a very low
“spray” is desired, press the WASH PRESSURE pad.
Due to wash cycle optimization, some pressure
options are not selectable in all wash cycle.
The programmed cycles default to the “normal”
temperature option, to choose HI-TEMP or
SANITIZE press WASH TEMP pad again.
Hi-Temp Wash Option
HI-TEMP WASH option is selected, by pressing
the WASH TEMP pad. The dishwasher heats
water in the main wash to approximately 140°F
(60°C) and increases the temperature higher in
the nal rinse to help with the drying stage.
This helps dishwasher detergent remove food
grease and soil from dishes more eectively and
aids in drying performance by adding additional
rinse aid and increasing the water temperature.
Sanitize Option
To sanitize your dishes and glassware, select
SANITIZE option, by pressing WASH TEMP pad.
When selected, the light will come on and remain
on until end of cycle. The water temperature in
the nal rinse will be raised to 155°F (68°C) and
will maintain that temperature for 9 minutes. This
option is available in Heavy and Normal Cycles.
Only these sanitization cycles have been designed
to meet NSF requirements.
The cycle time will be extended until the proper
water temperature is reached.
continue during the water heating delay. For best
results, the incoming water temperature should be
at least 120°F (49°C).
The sanitize criteria may not be satised if there
is an interruption of the cycle, power failure or if
the incoming water temperature is below 120°F
(49°C).
To turn o the SANITIZE option, press the Wash
Temp pad. The SANITIZE light will turn o.
Washing action will
5
OPERATING INSTRUCTIONS
Heat Dry
The HEAT DRY option in combination with rinse
aid will enhance drying performance. HEAT DRY
option is available on all cycles.
Air Dry
The AIR DRY option will reduce temperature in the
hot rinse of the selected wash cycle. This option
will slightly decrease energy usage but will increase
the likelihood that dishware will not be dry.
Child Lock Controls
To prevent children from accidentally changing the
dishwasher cycle or starting the dishwasher, lock
the dishwasher controls by pressing the DELAY
START pad until the status window displays “loc”.
To unlock the controls, press the DELAY START
pad until “loc” is no longer displayed in the status
window.
To Cancel a Cycle and Delay Start
Both running cycle and delay countdown can be
cancelled at any time.
Open the dishwasher door and press the START/
CANCEL pad until you hear a tone. The running
cycle or delay countdown is cancelled.
If desired, a new cycle can now be selected, by
pressing START/CANCEL pad and closing the door
immediately, the new cycle will begin.
To Cancel a Setting
If you have selected your cycle and options and
decide to cancel, by pressing the START/CANCEL
pad, the unit will go into a stand-by mode, which
all LEDs will go out.
Delay Start
The DELAY START option allows you to
automatically delay starting your dishwasher from
1-24 hours.
Select your desired cycle and options, then press
the DELAY START pad until the desired delay
time displays in the status window. The LEDs of
selected cycle and options are illuminated. The
status window displays the delay time and then
displays ‘Press Start’.
To start the delay countdown, press START/
CANCEL pad and close door immediately.
The status window displays ‘Close’ after the
START/CANCEL pad is pressed.
A tone will sound indicating that the countdown
has started after the door is closed. The selected
cycle starts when the countdown is completed.
Opening the door during cycle
If door is opened while a cycle is running or delay
is counting down, the dishwasher will stop running.
The LEDs of selected cycle and options are
illuminated, the status window displays the
remaining cycle time or delay time and displays
‘Press Start’.
To resume, press START/CANCEL pad and close
the dishwasher door immediately. The status
window displays ‘Close’ after the START/CANCEL
pad is pressed.
A tone will sound indicating that the dishwasher
will begin running from the point of interruption
after the door is closed.
If the dishwasher door is kept open for too
long, or the door is closed without pressing
START/CANCEL pad, the running cycle or delay
countdown will be cancelled.
Status Indicator Lights
The CLEAN light will remain on after door is opened.
When the SANITIZE option is selected and the
criteria is met, the Sanitized indicator will display
and remain on after the door is opened. If the
sanitization criteria is not achieved, the indicator
will not display. This can happen if the cycle is
interrupted or if the sanitization temperature
could not be reached due to incoming water
temperature signicantly below 120°F.
6
OPERATING INSTRUCTIONS
Status Window
The STATUS window, available on some models, indicates the following activity:
1-24h Number of delay start hours.
MINUTES Number of minutes left in cycle
The last hour will count down
in minutes.
(1-199).
User Instruction Code
Instruction
Code
Displayed
Close This indicates the door
PF Soft Power Failure: PF is displayed if a power outage occurs during a wash cycle. The
Problem/Condition Solution
has been left open or not
properly latched.
wash cycle will be paused temporarily and resume once power is restored if the door
has not been opened.
Hard Power Failure: A hard power failure means the unit will not operate until power
is restored. Pressing start within 18 hours of loss of power will resume power at the
point of cycle interruption.
Error Code
CLOSE Close will scroll across the status
window indicating the door needs to
be closed.
L0–L6. Level of Rinse Aid dosage.
Ensuring the door is properly latched will clear the
display. This does not indicate a problem with your
dishwasher and service will not need to be contacted.
Displayed
Error Code*
i10 A low ll has been
i20; i40; iF0 Clogged lters or a
i30 A leak or overow of
i50 A problem has been
i60 A problem has been
iC0 A problem has been
*In all Error Code instances, if Pressing the cancel button or turning power o at the breaker for 5
min. does not resolve the problem, contact the Frigidaire Customer Care Center at 1-800-944-9044.
Problem Solution
detected.
restricted drain line has
been detected.
water has been detected
in the bottom pan.
detected with the drain
or wash motor.
detected with the water
heating system.
detected with the
electronic control system.
Look for a pinched water supply line, or water shuto
is not completely opened.
Check and clean both lters and sump area and check
for a pinched or blocked drain hose. If the drain line is
attached to a disposer, check that the knockout plug
has been removed.
Look for loose connections at the water inlet valve and
ensure the unit is properly leveled.
Pressing the cancel button or turning power o at the
breaker for 5 min. should clear this error code and the
unit can be restarted.
If this does not resolve the problem, service will
need to be called.
7
OPERATING INSTRUCTIONS
Cycle Chart
Cycle Settings Water
Heavy
For pots, pans casseroles and dinnerware
with dried-on or bakedon soils, and silverware
Normal
For regularly soiled
dishes and silverware.
China Crystal
For lightly soiled China
and Crystal
Energy Saver
For lightly soiled
pre-rinsed dishes and
silverware
Rinse Only
For rinsing dishes that
will be washed later.
Default
Surge, Hi-Temp, and Heat
Options
Sanitize, and Air
Default
Surge, Normal, and Heat
Options
Spray, Hi-Temp
Sanitize, and Air
Default
Spray, Normal, and Heat
Options
None Available
Default
Surge, Normal, and Air
Options
Spray
Default
Surge
Options
None Available
(approx.)
7.0 - 7.9 gal.
26.6 - 29.9 liters
2.9 - 7.3 gal.
11.0 - 27.7 liters
5.7 gal.
21.5 liters
4.4 - 7.9 gal.
16.5 - 29.7 liters
2.0 gal.
7.6 liters
Time *
(Hours)
2 1/4 - 3 1/44 Washes
2 - 3 1/
1 1/
4
1 1/4 - 1 3/45 Washes
1
/
4
4
Washes/
Rinses
3 Rinses
5 Washes
2 Rinses
3 Washes
2 Rinses
3 Rinses
2 Rinses
NOTE*
The time remaining may suddenly increase or drop several minutes. This means that the dishwasher
received input from the Smart Sensor concerning the soil load and has automatically adjusted the
cycle length.
8
PREPARING AND LOADING DISHES
Dish Preparation
Scrape away large pieces of food, bones, pits,
toothpicks, etc. The continuously ltered wash
uid will remove remaining food particles.
Burned-on foods should be loosened before
loading. Empty liquids from glasses and cups.
Foods such as mustard, mayonnaise, vinegar,
lemon juice and tomato based products may
cause discoloration of stainless steel and plastics
if allowed to sit for a long period of time. Unless
the dishwasher is to be operated at once, it is
best to pre-rinse or use the rinse only cycle to
rinse o these food soils.
• Load racks so that large items do not
prevent the detergent dispenser from
opening.
• Check manufacturer’s recommendations
before washing items in question.
• If the dishwasher drains into a Food
Disposer, be sure disposer is
completely empty before starting
dishwasher.
8 place settings standard loading pattern
Loading the Upper Rack
Features and appearance of racks and silverware
basket may vary from your model.
The upper rack is designed for exibility in loading
a wide variety of items including cups, glasses,
stemware, small plates, bowls, etc.
Load glasses and plastic items in upper rack only.
Load items with open end facing down for better
cleaning and draining.
Damage may occur if delicate items touch each
other during dishwasher operation.
Long-handled knives and utensils can be placed in
upper rack.
Be sure nothing protrudes through the bottom of
the rack to block rotation of middle spray arm.
10 place settings standard loading pattern
12 place settings standard loading pattern
9
PREPARING AND LOADING DISHES
Loading the Bottom Rack
Features and appearance of racks and
silverware basket may vary from your
model.
The bottom rack is best for plates, saucers, bowls,
and cookware. Large items should be placed
along the edge so they do not block the spray arm
rotation. For best results, place bowls, casseroles,
and sauce pans with soiled surface facing down or
toward the center. Tilt slightly for better drainage.
Make sure tall items do not block spray arm
rotation.
Be sure pan handles do not protrude through
the bottom of the rack and block the spray arm
rotation.
10 place settings standard loading pattern.
8 place settings standard loading pattern.
10
12 place settings standard loading pattern
PREPARING AND LOADING DISHES
Loading the Silverware Basket
CAUTION
Load sharp items (knives, skewers, etc.)
pointing down.
Failure to do so may result in injury.
Features and appearance of racks and silverware
basket may vary from your model.
Load the silverware basket while it is in the
bottom rack or take the basket out for loading on
a counter or table.
In some models small items like baby bottle caps,
jar lids, corn cob holders, etc., can be placed in
a covered section. Close the cover to hold small
items in place.
Use suggested loading patterns, as shown, to
increase washability of the silverware.
• Be sure nothing protrudes through bottom of
basket or rack to block the spray arm.
• Do not mix silver and stainless to avoid
damaging the silver nish
Mix items in each section of the basket with some
pointing up and some down to avoid nesting.
Water spray cannot reach nested items.
Adding an article
To add or remove items after wash cycle starts:
• Unlatch door and wait a few seconds until
wash action stops before opening.
• Add the item and wait a few seconds to allow
cold air to slowly expand inside dishwasher.
• To resume cycle press the START/CANCEL
pad and close the door immediately.
Loading the Cutlery Tray
The Cutlery Tray is designed for atware and
most cooking or serving utensils. Heavily soiled
utensils or items with baked on foods should be
placed in the upper rack or silverware basket for
best washing performance. The separators on the
cutlery tray help keep atware separated to avoid
damage and improve cleaning.
NOTE
Load cutlery as suggested with cutlery
handles placed inwards to optimize cleaning
performance.
11
DISHWASHER DISPENSER & DETERGENTS
Filling the Detergent Dispenser
The detergent dispenser has a main wash cup
where you will add your detergent or detergent
tab.
• Use only fresh automatic dishwashing
detergent. Other detergents may cause
oversudsing.
• When using automatic dishwashing detergent
tablet, place one tablet in main wash cup and
close.
• Add detergent just before starting cycle.
• Store detergent in a cool, dry location. Moist
or caked detergent may not dissolve properly.
To add detergent:
1. Press the dispenser cover latch to open the
main wash detergent cup.
2. Add the recommended amount of detergent to
the main wash cup.
3. Slide the main wash cover back over the main
wash cup to close.
Main Wash Cup
How much Detergent to use
The amount of detergent to use depends on the
water hardness. Water hardness is measured in
grains per gallon. Using too little detergent can
result in poor cleaning and hard water lming or
spotting. Using too much detergent in soft water
can cause etching to some glassware which is
surface damage that appears like a lm but cannot
be wiped o. Your local water company, water
softener company or county extension agent can
tell you the water hardness in your area.
CAUTION
The use of industrial grade detergent can
damage parts of the dishwasher leading to
damage to the unit and surrounding property.
Use only household grade automatic dishwasher
detergents.
NOTE
Hard water may cause lime deposit buildup
on the interior of the dishwasher. For clean-
ing instructions see “Removing Spots and lm”
section.
Cover
Latch
12
Main Wash Cover
NOTE
Detergent tablets and All-In-One packs may not
dissolve completely if used with the QUICK WASH
cycles. If one of these products are used, place
the tab or pack directly on the bottom of the tub
in a corner before starting the dishwasher, rather
than placing these products in the dispenser.
DISHWASHER DISPENSER & DETERGENTS
Dosage of Detergent
Place a single detergent tablet or packet into the detergent dispenser compartment.
Detergent Usage Chart
Water Hardness Soft Water
Amount of detergent
(teaspoons)
Dispenser cup level First Line Second Line Full
NOTE
For very hard water, detergent alone may not be enough. A water softener is recommended to
improve water quality and dishwashing performance. Try adding more detergent at the beginning
of the main wash portion of the cycle. As a rule, use 1 teaspoon for each grain above 12. Unlatch
the door, open slowly and add detergent to the bottom of the tub. Close the door to latch and the
dishwasher will continue through the cycle.
(0-3 grains)
4 teaspoons 6 teaspoons 8 teaspoons
Medium Hard Water
(4-8 grains)
Hard Water
(9-12 grains)
13
FACTORS AFFECTING PERFORMANCE
Rinse Aid
Rinse aid greatly improves drying, reduces
water spots, lming. With it water “sheets” o
dishes rather than forming water droplets that
cling and leave spots.
A dispenser, located next to the detergent cup,
automatically releases a measured amount of
rinse aid during the last rinse. If spotting and poor
drying are problems, increase the amount of rinse
aid dispensed. The indicator will be dark when full
and will show clear when it is time to rell.
To add liquid rinse aid:
1. Lift up the rinse aid cover to open.
2. Fill the rinse aid dispenser with liquid rinse aid
until the liquid reaches the indicated ll level.
DO NOT overll.
3. Press the rinse aid cover down rmly to close.
4. Wipe up any spills with a damp cloth.
Indicator
Rinse Aid
Compartment
Rinse Aid
Cover
The dispenser holds enough for 11 to 66 washes,
depending on setting.
IMPORTANT
Before starting a cycle, run hot water to clear
cool water from pipe.
How to adjust the rinse aid dosage
Press and hold the RINSE ONLY and DELAY START Press and hold the RINSE ONLY and DELAY START
pad for 5 seconds until the status window shows pad for 5 seconds until the status window shows
rinse aid level. Pressing the DELAY START pad rinse aid level. Pressing the DELAY START pad
increases the increment level (L0-L6).increases the increment level (L0-L6).
Once the rinse-aid level reaches L6, the status Once the rinse-aid level reaches L6, the status
window will start back at level L0.window will start back at level L0.
Pressing the START button or just pausing for a
few seconds conrms the rinse aid level setting:
the status window shows the duration of the
cycle.
Water Pressure
The hot water line to dishwasher must provide
water pressure between 20 and 120 psi.
Low water pressure may occur when laundry
or showers are in operation. If you experience
poor wash performance you may need to wait
until water use is reduced before starting the
dishwasher.
Water Temperature
Hot water is needed for best dishwashing and
drying results. Water entering dishwasher should
be at least 120°F (49°C) to give satisfactory
results.
To check water temperature entering dishwasher:
NOTE
The HEAT DRY option in combination with rinse
aid will enhance drying performance. The energy
required to use the HEAT DRY option costs pennies per cycle. You may choose not to select the
HEAT DRY option; however you will have items in
your dish load that will not be completely dry at
the end of the cycle.
• Turn on hot water faucet nearest dishwasher
for several minutes to clear cool water from
pipes.
• Hold a candy or meat thermometer in the
water stream to check the temperature.
• If temperature is below 120°F (49°C), have
a qualied person raise the hot water heater
thermostat setting.
14
Outside
Occasionally wipe with a mild nonabrasive
detergent and water. Rinse and dry.
Care of Drain Air Gap
If a drain air gap was installed for your built-in
dishwasher, check to make sure it is clean so the
dishwasher will drain properly. A drain air gap
is usually mounted on the counter top and can
be inspected by removing the cover. This is not
part of your dishwasher and is not covered by
warranty.
Clean the Cylinder Fine Filter
The Cylinder Fine Filter is designed to collect
some big items such as broken glass, bones and
pits. The Cylinder Fine Filter needs to be cleaned
to maximize wash performance.
Remove the Cylinder Fine Filter as shown, rotate
it counterclockwise, lift it out, empty and clean it
by rinsing under running water and replace. Use
of a sponge or bottle brush may be necessary to
remove all food residue.
CARE AND CLEANING
Clean the Coarse Filter
Take out the Cylinder Fine Filter and remove the
Coarse Filter from the dishwasher tub bottom.
Flush the Coarse Filter by holding it under running
water and replace.
15
CARE AND CLEANING
Winterizing
A dishwasher left in an unheated place should be
protected from freezing. Have a qualied person
do the following:
To Disconnect Service:
1. Turn o electrical power to the dishwasher at
the supply source by removing fuses or tripping
circuit breaker.
2. Shut o water supply.
3. Place a pan under the inlet valve. Disconnect
water line from the inlet valve and drain into
pan.
4. Disconnect drain line from pump and drain
water into pan.
To Restore Service:
1. Reconnect the water, drain, and electrical
power supply.
2. Turn on water and electrical power supply
3. Fill detergent cup and run the dishwasher
through a HEAVY cycle.
4. Check connections to make sure they do not
leak.
CAUTION
Property Damage Hazard
Freezing temperatures may cause water
lines to rupture. Be sure all supply lines to
and circulating lines within dishwasher are
protected.
Failure to do so could result in property
damage.
NOTE
See Installation Instructions for more details
on disconnecting and restoring service to your
dishwasher.
16
BEFORE YOU CALL
Before calling for service, review this list. It
may save you both time and expense. This
list includes common experiences that are
not the result of defective workmanship or
material in your dishwasher.
Food Soils Left on Dishes
• Choose another cycle for longer washing time.
• Choose the Hi-Temp Wash option.
• Check rack loading section for proper loadingavoid nesting items.
• Home water pressure may be too low - should
be 20 to 120 pounds per square inch (psi).
• Check incoming water temperature. It should
be at least 120°F (49°C). (See Factors
Aecting Performance.)
• Check water hardness. For extremely hard
water, it may be necessary to install a water
softener. (See Detergent Chart).
• Use Fresh Detergent.
• Make sure items are not blocking the spray
arms, preventing them from rotating.
Dishes not Dry
• Select heat dry option.
• Make sure the rinse aid dispenser is lled.
• Increase the discharge setting of rinse aid.
(See Rinse Aid).
• Check the incoming water temperature. Be
sure it is at least 120°F (49°C).
• Check for proper loading-avoid nesting items.
• Plastic items may need to be towel dried.
• Cups with a concave bottom will collect water.
Load them at the far left of the upper rack so
they will be held in a tilted position.
Glassware/Flatware Spotted or Cloudy
• Check water hardness. For extremely hard
water, it may be necessary to install a water
softener. (See Detergent Chart).
• Water temperature may be low. Avoid
extremely low or high temperatures. (See
Factors Aecting Performance.
• Avoid overloading and improper loading. (See
Preparing and Loading Dishes).
• Use fresh detergent. Old detergent is
ineective.
• Make sure rinse aid dispenser is lled.
• Check to see that proper amount of detergent
is being used for cycle selected. Also, check
phosphate level. (See Detergent Dispenser.)
• Home water pressure may be too low - it
should be 20 to 120 pounds per square inch
(psi).
Dishware Chipped
• Load with care and do not overload. (See
Preparing and Loading Dishes).
• Place delicate items in top rack.
• Place glasses securely against pins and not
over pins.
• Load items so they are secure and don’t jar
loose when moving racks in and out. Move
racks in and out slowly.
• Make sure tall glasses and stemware will clear
top of tub when rack is pushed in.
• Fine antique china and crystal should be
hand-washed.
Water in Bottom of Tub
• Water left in the tub bottom after the cycle is
complete is not normal. If water remains in
the bottom of the tub, the dishwasher may
not be draining properly. (See Dishwasher
Does not Drain Properly).
Dishware Stained or Discolored
• Tea and coee can stain cups. Remove the
stains by hand washing in a solution of 1/2
cup (120 ml) bleach and one quart (1L) of
warm water. Rinse thoroughly.
• Iron deposits in water can cause a yellow
or brown lm. A special lter installed in the
water supply line will correct this problem.
(See Removing Spots and Film).
• Aluminum utensils can leave gray/black marks
when they rub against other items. Load
Properly.
• Certain high acid foods can cause
discoloration of stainless steel and plastics if
allowed to sit for a long period. Use the Rinse
Only cycle or rinse by hand if not operating
dishwasher at once.
• Mixing stainless steel and silver utensils in
silverware basket can cause pitting of the
stainless steel blades. Avoid mixing stainless
steel and silver.
Cycle Takes a Long Time
• Is cycle in a water heating delay?
• Has the delay start option been selected?
• Has the sanitize option been selected?
Normal Sounds You Will Hear
• Normal sounds include water ll, water
circulation and motor sounds.
17
BEFORE YOU CALL
Dishwasher Leaks
• Use only fresh detergent designed for
automatic dishwashers. Measure detergent
carefully. Try a dierent brand.
Etching
• Using too much detergent especially in soft or
softened water causes damage that looks like
a lm but cannot be removed.
• Adjust the amount of detergent based on the
water hardness. (Check Detergent Chart).
• Lower the water temperature.
Detergent Left in Dispenser Cup
• Detergent may be old. Discard and use fresh
detergent.
• Be sure the dish load doesn’t block spray from
entering the detergent cup.
• Check to see if cycle has been completed.
• Make sure items do not prevent the detergent
dispenser from opening.
Vapor at Vent
• Spilled rinse aid can cause foam and lead to
overowing. Wipe up any spills with a damp
cloth.
• Water vapor escapes from the vent during the
drying part of the cycle. This is normal.
• Check to see that dishwasher is level. (See
Installation Instructions).
Dishwasher Won’t Run
• Check to see if circuit breaker is tripped or if a
fuse is blown.
• Make sure water supply is turned on.
• Check to see if cycle is set correctly. (See
Operating Instructions).
• Is dishwasher set for Delay Start Option?
• Make sure door is closed and latched.
Dishwasher Won’t Fill
• Is water supply turned on?
Dishwasher Does Not Drain Properly
• If unit is hooked up to a food waste disposer,
make sure the disposer is empty.
• Check to see if the knockout plug has been
removed from inside the food waste disposer
inlet.
• Check to see if drain hose is kinked.
• Make sure cycle is complete, not in a pause.
Dishwasher has an Odor
• Soiled dishes left in dishwasher too long can
create an odor. Use Rinse Only cycle.
• There will be a “new” smell when rst
installed. This is normal.
• Check to see if unit is draining properly. (See
Dishwasher Does Not Drain Properly).
Stains on Tub Interior
• Washing large amounts of dishware with
tomato based soil can cause a pink/orange
appearance. This will not aect performance
and will gradually fade over time. Pre-rinsing
or using the Rinse Only cycle will reduce the
chance of staining. Using air dry option will
lessen staining.
Opening the door during cycle
• If the dishwasher door is opened while the
unit is running, the START/CANCEL pad must
be pressed and the door shut immediately
to return the unit to the selected cycle and
option.
Removing Spots and Film
Hard water can cause lime deposit buildup on the
interior of the dishwasher. Dishes and glasses may
also get spots and lm for a number of reasons.
(See Glassware/Flatware Spotted or Cloudy
section). To remove buildup, and lm, clean using
the following instructions:
1. Load clean dishes and glasses in normal
manner. Do not load any metal utensils or
silverware.
2. Do not add detergent.
3. Select the NORMAL cycle. Press START/CANCEL
pad. Close and latch the door.
4. Allow dishwasher to run until it starts the
second water ll (approximately 10 minutes).
5. Unlatch an and open door and pour 2 cups of
white vinegar into the bottom of dishwasher.
6. Close and latch door and allow cycle to nish.
18
NOTES
19
MAJOR APPLIANCE WARRANTY
Your appliance is covered by a one year limited warranty. For one year from your original date of purchase,
Electrolux will pay all costs for repairing or replacing any parts of this appliance that prove to be defective
in materials or workmanship when such appliance is installed, used and maintained in accordance with the
provided instructions.
Exclusions
This warranty does not cover the following:
1. Products with original serial numbers that have been removed, altered or cannot be readily determined.
2. Product that has been transferred from its original owner to another party or removed outside the
USA or Canada.
3. Rust on the interior or exterior of the unit.
4. Products purchased “as-is” are not covered by this warranty.
5. Food loss due to any refrigerator or freezer failures.
6. Products used in a commercial setting.
7. Service calls which do not involve malfunction or defects in materials or workmanship, or for appliances not in
ordinary household use or used other than in accordance with the provided instructions.
8. Service calls to correct the installation of your appliance or to instruct you how to use your appliance.
9. Expenses for making the appliance accessible for servicing, such as removal of trim, cupboards, shelves,
etc., which are not a part of the appliance when it is shipped from the factory.
10. Service calls to repair or replace appliance light bulbs, air lters, water lters, other consumables, or
knobs, handles, or other cosmetic parts.
11. Surcharges including, but not limited to, any after hour, weekend, or holiday service calls, tolls, ferry trip
charges, or mileage expense for service calls to remote areas, including the state of Alaska.
12. Damages to the nish of appliance or home incurred during installation, including but not limited to
oors, cabinets, walls, etc.
13. Damages caused by: services performed by unauthorized service companies; use of parts other than
genuine Electrolux parts or parts obtained from persons other than authorized service companies; or
external causes such as abuse, misuse, inadequate power supply, accidents, res, or acts of God.
DISCLAIMER OF IMPLIED WARRANTIES; LIMITATION OF REMEDIES
CUSTOMER’S SOLE AND EXCLUSIVE REMEDY UNDER THIS LIMITED WARRANTY SHALL BE PRODUCT
REPAIR OR REPLACEMENT AS PROVIDED HEREIN. CLAIMS BASED ON IMPLIED WARRANTIES, INCLUDING
WARRANTIES OF MERCHANTABILITY OR FITNESS FOR A PARTICULAR PURPOSE, ARE LIMITED TO ONE
YEAR OR THE SHORTEST PERIOD ALLOWED BY LAW, BUT NOT LESS THAN ONE YEAR. ELECTROLUX
SHALL NOT BE LIABLE FOR CONSEQUENTIAL OR INCIDENTAL DAMAGES SUCH AS PROPERTY DAMAGE
AND INCIDENTAL EXPENSES RESULTING FROM ANY BREACH OF THIS WRITTEN LIMITED WARRANTY
OR ANY IMPLIED WARRANTY. SOME STATES AND PROVINCES DO NOT ALLOW THE EXCLUSION OR
LIMITATION OF INCIDENTAL OR CONSEQUENTIAL DAMAGES, OR LIMITATIONS ON THE DURATION OF
IMPLIED WARRANTIES, SO THESE LIMITATIONS OR EXCLUSIONS MAY NOT APPLY TO YOU. THIS WRITTEN
WARRANTY GIVES YOU SPECIFIC LEGAL RIGHTS. YOU MAY ALSO HAVE OTHER RIGHTS THAT VARY FROM
STATE TO STATE.
If You Need Service
Keep your receipt, delivery slip, or some other appropriate payment record to establish the warranty
period should service be required. If service is performed, it is in your best interest to obtain and keep all
receipts. Service under this warranty must be obtained by contacting Electrolux at the addresses or phone
numbers below.
This warranty only applies in the USA and Canada. In the USA, your appliance is warranted by Electrolux
Major Appliances North America, a division of Electrolux Home Products, Inc. In Canada, your appliance is
warranted by Electrolux Canada Corp. Electrolux authorizes no person to change or add to any obligations
under this warranty. Obligations for service and parts under this warranty must be performed by Electrolux
or an authorized service company. Product features or specications as described or illustrated are subject
to change without notice.
USA
1.800.374.4432
Frigidaire
10200 David Taylor Drive
Charlotte, NC 28262
20
1.800.265.8352
Canada
Electrolux Canada Corp.
5855 Terry Fox Way
Mississauga, Ontario, Canada
L5V 3E4
Loading...
