2007 Service & P arts Manual

Room Air Conditioners

60 Hz Models

HG-SVC-PRTS-07 (3-07)

SH15L30-B SH20L30-B

TABLE OF CONTENTS

Speciﬁ cations ...................................................................................................................... ...................................3

Performance Data ..................................................................................................................................................3

Component Operation & Testing ...........................................................................................................................4

Compressors ..........................................................................................................................................................4

Thermal Overload .................................................................................................................................................4

Checking Compresso r Efﬁ cien cy ...........................................................................................................................4

Fan Motor ............................................................................................................................................................... 5

Solid State Relay ....................................................................................................................................................5

System Control Switch ..........................................................................................................................................5

Run Capacitor ........................................................................................................................................................5

Thermostat .............................................................................................................................................................5

Low Ambient Bypass Valve ....................................................................................................................................6

Sealed Refrigeration System Repairs....................................................................................................................6

Hermetic Component Replacement ......................................................................................................................7

Special Procedure in the case of Compressor Motor Burn-Out ..........................................................................7

Rotary Compressor Special Troubleshooting & Service ......................................................................................7

Refrigerant Charge .................................................................................................................................................7

Troubleshooting ................................................................................................................................................8-1 0

Wiring Diagram .................................................................................................................................................... 11

Cabinet Parts Diagram ........................................................................................................................................ 12

Chassis Parts Diagram ....................................................................................................................................... 13

Parts List .........................................................................................................................................................14-1 5

Warranty ...............................................................................................................................................................16

FUSE

60 Hertz

BREAKER

RPM

Motor

CFM

Evap

REF.

R-22

Charge

Locked

Amps

ELECTRICAL RATINGS

Amps

OPERATING

PRESSURES

Sub-

Cooling

Amps

in OZ.

Rotor

Amps

Heat

Cool

Room Side Air

Air Direction

Circulation

Controls

(Lbs.)

Weight

T - D Fuse

Breaker or

Circuit Rating

16 250V - 15A 140 152

/16 250V - 15A 166 179

OPERATING TEMPERATURE CODE T3B

Heat

Super

Temp

Liquid

Temp

Suction

Temp

Discharge

TEMP.

DEG. F

CONDENSER

TEMP. DEG. F

EVAPORATOR

Temp.

TEMP. DEG. F

EVAPORATOR AIR

Discharge

E(in) E(out) Suction Discharge

Drop F.

Air

Moisture

Cooling Capacity Electrical Characteristics (60 Hertz) Energy

Removal

Efﬁ ciency

Ratio AHAM

Amps

(Pints/ Hr.) CFM

AHAM Watts EER

(BTU/Hr . - AHAM ) Volts Rated

16 26

(Inches)

Finished Hole

Thru-The-Wall

(Inches)

Minimum

Extension

Into

Minimum

Extension

Depth

Hood to

Dimensions (Inches) Window Width

Depth

8 42 16

8 42 18

16 27

Outside Min. Max. Height Width Volts - Amps Net Shipping

16 16

Room

16 3

Louvers

8 9

Overall

16 27

16 25

Height Width

60 Hz Models

SH15L30-B 54 26 52 56 206 129 61 108 16 98 76 258 8.2 - - 28.5 363 1100 15

Performance Data: Cooling

SH20L30-B 46 34 46 46 125 196 52 97 8 28 75 271 10.1 - - 39.0 357 1100 20

Product Specifications

Model

SH15L30 15000/15000 230/208 7.9/8.7 1765/1765 8.5/8.5 4.0 8-way 375

SH20L30 19800/19500 230/208 10.0/10.9 2200/2167 9.0/9.0 5.7 8-way 375

Installation Information

Model

SH15L30 15

SH20L30 17

Due to continuing engineering research and technology, specifications are subject to change without notice.

Manufactured under U.S. Design Patent DES 368, 306 decorative front; Utility Patent 5, 622, 058

MAXIMUM outdoor ambient operating temperature is 130°F (54°C).

MAXIMUM TEMPERATURE RATING FOR CLASS I, DIVISION 2, GROUPS A,B,C,D

COMPONENT OPERATION AND TESTING

WARNING

DISCONNECT ELECTRICAL POWER TO THE

UNIT BEFORE SERVICING OR TESTING

COMPRESSORS

Compressors are single phase, 208/23 0 volt. All c ompres sor motors are permanent split capacitor type, using only a running capacitor across the start and run terminal.

All compressor s are internally spr ing mounted and exter nally mounted on rubber isolators.

Line Voltage Overload

The compressor is equipped with an internal line voltage over-

load. This overload is embedded in the windings of the motor to sense the motor temperature. The overload will open and disconnect the power to the motor due to high temperatures cause d b y :

1. A locked rotor.

2. Excessive running amps.

3. High discharge temperature.

4. Low refrigerant charge.

Testing Procedures

1. Ter minal "C" and "S" – no continuity – open w inding – replace compressor.

2. Ter minal "C" and "R" – no continuit y – open winding – replace compressor.

3. Terminal "R" and " S" – no continuity – open winding

- replace compressor.

4. T erminal "C" and the shell of the compressor – continuity – grounded motor – replace compressor.

5. Should continuity exist bet ween terminals "R" and "S", but not between terminals "C" and " S" and " C" and " R", the internal overload may be open. If the compressor is extremely hot, allow it sufﬁ cient time to cool. It may require as long as one hour for the compressor to cool sufﬁ ciently for the internal overload to close.

GROUND TEST

Use an ohmmeter set on its highest scale. Touch one lead to the co mpresso r body ( cle an poin t of co ntact, as a good connection is a must) and the other probe in turn to each compressor terminal. (See Figure 3. ) If a reading is obtained, the compressor is grounded and must be replaced.

FIGURE 3 TYPICAL GROUND TEST

FIGURE 1 INTERNAL OVERLOAD

LINE BREAK INTERNAL OVERLOAD

OHMMETER

COMPRESSOR WINDING TEST (Figure 2.)

Remove the compressor terminal box cover and disconnect the wires from the terminals. Using an ohmmeter, check continuity across the following:

FIGURE 2 COMPRESSOR WINDING TEST

CHECKING COMPRESSOR EFFICIENCY

The reason for compressor inefﬁ ciency is normally due to bro-

ken or damaged suction and/or discharge valves, reducing the ability of the compressor to pump refrigerant gas.

This condition can be checked as follows:

1. Install a piercing valve on the suction and discharge or liquid process tube.

2. Attach gages to the high and low sides of the system.

3. Start the system. Run a "cooling or heating performance test."

If test sh ows:

A. Below normal high side pressure. B. Above normal low side pressure. C. Low temperature difference across the coil.

The compressor valves are faulty - replace the compressor .

FAN MOTOR (Figure 4)

A 230 volt single phase permanent split capacitor motor is

used to drive the evaporator blower and condenser fan. A running capacitor is wired acros s the star t and r un terminals of the motor.

CAPACITOR, RUN

A run capacitor is wired across the auxiliary and main winding of a single phase permanent split capacitor motor such as the compressor and fan motors. A single capacitor can be used for each motor or a dual rated capacitor can be used for both.

The motor is totally enclosed and is protected with a line volt-

age overload located internally of the motor. The motor shaft is stainless steel to resist corrosion.

FIGURE 4 FAN MOTOR

FAN MOTOR – TEST

Disconnect power to the unit.

1. Determine that the capacitor is serviceable.

2. Disconnect the black lead from the circuit board.

3. Apply "live" test cord leads to the common terminal of the capacitor and the black lead. The motor should run at high speed.

SOLID STATE RELAY (Figure 5)

Two 50 amp rated 20 8/230 volt solid state relays are used to

energize the compressor and fan motor. T erminals 3 and 4 are the 208/230 volt line side. Terminals 1 and 2 are load side contacts.

The capacitor’s primary function is to reduc e the line current

while greatly improving the torque characteristic s of a motor.

The capacitor also reduces t he line current to the motor by

improving the power factor of the load. The line side of the capacitor is marked with a red dot and is wired to the line side of the circuit (see Figure 7.)

FIGURE 7 RUN CAPACITOR HOOK–UP

COMPRESSOR

FAN MOTOR

RED DOT

RUN CAPACITOR

CAPACITOR – TEST

1. Remove the capacitor from the unit.

2. Check for visual damage such as bulges, cracks, or leaks.

FIGURE 5

Line side

SOLID STATE RELAY

Load side

LED indicates

contacts closed

when lit

SYSTEM CONTROL SWITCH (Figure 6)

This switch is double pole, single throw. Check for continuity

between terminals 2 and 3, and 5 and 6.

FIGURE 6 SWITCH, ON-OFF

3. For dual rated capacitor s, apply an ohmmeter lead to the common (C) terminal and the other probe to the compressor (HERM) terminal. A satisfactory capacitor will cause a deﬂ ection on the pointer, then gradually move back to inﬁ nity.

4. Reverse the leads of the probe and momentarily touch the capacitor terminals. The deﬂ ection of the pointer sh ould be two times that of the ﬁ rst check if the capacitor is good.

5. Repeat steps 3 and 4 to check the fan motor capacitor.

NOTE: A shorted capacitor will indicate a low resistance and the pointer will move more to the “ 0” end of the scale and remain there as long as the probes are connected. An open capacitor will show no movement of the pointer when placed across the terminals of the capacitor.

THERMOSTAT

A cross ambient thermostat is used to maintain t he desired

comfort level. The thermost at reacts only to a change in temperature at the bulb location. Import ant to the succe ssful operation of the unit is the position of the sensing bulb in relation to the evaporator (see F igure 8 ).

FIGURE 8 SENSING BULB LOCA TION

FIGURE 9 LOW AMBIENT Bypass VALVE

SEALED REFRIGERATION SYSTEM REPAIRS

Equipment R e q ui red:

1. Voltmeter

RANGE: Thermostat

(Part No. 618-225-02)

60° F ( ± 2° ) to 90° F( ± 4° )

TEST

Remove the wires from the thermostat. Turn the thermostat to its coldest position. Check to see if there is continuity between the two terminals. Turn the thermostat to its warme st posit ion. Check continuity to see if the thermostat contacts open.

Note: The temperature must be with in the range listed to check the thermostat. Refer to the troubleshooting sec tion in this manual for additional information on thermostat testing.

LOW AMBIENT BYPASS VALVE (Figure 9)

The HazardGard unit is designed to operate at low outside

ambient temperatures. This is accomplished by the use of a bypass valve installed in the refrigeration circuit. The valve is connected between the discharge line at the c ompressor and the suction process tube. The valve responds to suction pressure which, when reduced in the system, c auses the valve to open and bypass hot gas from the high pressure side to the low pressure side of the system. The hot gas entering the compressor mixes with the cool gas returned through the suction line, thus increasing the suction pressure. The valve is preset to open when the su ction pressure rea ches 50 psig .

This pressure setting cannot be altered. The system can be

operated at outdoor temperatures as low as 45° F before the evaporator coil will begin to accumulate frost.

To determine i f the valve operates, block the return air to the

evaporator coil. Turn on the unit and touch t he tube at the bypass valve outlet which connects to the suction process tube. When the low side pressure reaches approximately 50 psig, the valve will begin to open and the tube will get hot. This method will determine if the valve is responding to the suction pressure change.

2. Ammeter

3. Ohmmeter

4. E.P.A Approved Refrigerant Recovery System

5. Vacuum Pump (capable of 200 microns or less vacuum) .

6. Acetylene Welder

7. Electronic Halogen Leak Detector (G.E. Type H-6 or equivalent ) .

8. Accurate refrigerant charge measuring device such as:

a. Balance Scales - 1/2 oz. accuracy b. Charging Board - 1/2 oz. accuracy

9. High Pressure Gauge - (0-400 lbs.)

10. Low Pressure Gauge - (30" - 150 lbs.) 1 1. Vacuum Gauge - (0-1000 microns)

Equipment Must Be Capable of:

1. Recovering CFC’s as low as 5%.

2. Evacuation from both the high side and low side of the

system simultaneously.

3. Introducing refrigerant charge into the high side of the

system.

4. Accurately weighing the refrigerant charge actually introduced into the system.

5. Facilities for ﬂ owing nitrogen t hrough the refrigeration tubing during all brazing processes.

HERMETIC COMPONENT REPLACEMENT

The following procedure applies when replacing comp onents

in the sealed refrigeration circuit or repairing refrigerant leaks. (Compressor , condenser, evaporator , capillary tube, refrigerant leaks, etc.)

1. Recover the refrigerant from the system at the process tube located on the high side of the system by installing a line tap on the process tube. Apply the gauge from the process tube to EPA approved gauges from the process tube to the EPA approved recovery system. Recover the CFC’s in the system to at least 5 %.

12. Rest art the unit several times after allowing pressures to stabilize. Pinch off the process tube s, cut and solder the ends. Remove the pinch off tool, and leak check the process tube ends.

SPECIAL PROCEDURES IN THE CASE OF COMPRESSOR MOTOR BURNOUT

1. Recover all refrigerant and oil from the system.

2. Remove the compressor, capillary tube and ﬁ lter drier from the system .

2. Cut the process tube below the pinch off in the suction side of the compressor.

3. C onnect the line from the nitrogen tank to the suction process tube.

4. Drift dr y nitrogen through the system and unsolder the more distant connection first. (Filter drier, high side process tube, etc. )

5. Replace the inoperative component, and always install a new ﬁ lter drier. Drift dry nitrogen through the system when making these connections.

6. Pressurize the system to 30 PSIG with proper refrigerant and boost the refrigerant pressure to 150 PSIG with dr y nitrogen.

7. Leak test the complete system with the electric halogen leak detector, correcting any leaks found.

8. Reduce the system to zero gauge pressure.

9. Connect the vacuum pump to the high side and low side of the sys t em wi th d eep v acu u m h oses , o r coppe r t ub ing .

(Do not use regular hoses.)

3. Flush the evaporator , condenser and all connecting tubing with dry nitrogen, or equivalent, to remov e all contamination from the system. Inspect the suction and discharge lines for carbon deposits. Remove and clean if necessary.

4. Reassemble the system, including a new drier -strainer and capillary tube.

5. Proc eed with processing as outlined under hermetic component replacement.

ROTARY COMPRESSOR SPECIAL TROUBLESHOOTING & SERVICE

Basically, troubleshooting and servicing rotary compres sors is the same as on the reciprocating compressor w ith only a few exceptions.

1. Because of the spinning motion of the rotary, the mounts are critical. If vibration is present, check the mounts carefully.

2. The electrical terminals on the rotary are in a different order than the reciprocating compressors. The terminal markings are on the cover gasket. Use your wiring diagram to insure the corr e ct con n ec ti on s .

10. Evacuate the system to an absolute holding pressure of 200 microns or less.

NOTE: This procedure can be sped up by the use of heat lamps, or by breaking the vacuum with refrigerant or dry nitrogen at 5,000 microns. Pressure system to 5 PSIG and leave in the system a minimum of 10 minutes. Recover refrigerant, and proceed with evacuation to a pressure of 200 microns or a minimum of 10%.

11. Break the vacuum by charging the system from the high side with the correct amount of refrigerant speciﬁ ed. This will prevent boiling the oil out of the crankcase.

NOTE: If the entire charge will not enter the high side,

allow the remainder to enter the low side in small increments while operating the unit.

REFRIGERANT CHARGE

1. The refr igerant charge is extremely critical. Measure the charge carefully and as exactly as possible to the nameplate charge.

2. The correct method for charging the rotary is to introduce liquid refrigerant into the high side of the system with the unit off. Then start the compressor and enter the balance of the charge, gas only, in to the low side.

The introduction of liquid into the low side, without the use of

a capillary tube, will cause damage to the discharge valve of the rotary compressor.

NOTE: All inoperative compressors returned to Friedrich must have all lines properly plugged with the plugs from the replacement compressor.

TROUBLESHOOTING

PROBLEM POSSIBLE CAUSE TO CORRECT

Power disconnected. Check power source. System switch in “Off” position. Set switch correctly.

UNIT DOES NOT RUN.

EVAPORATOR COIL FREEZES UP.

Branch circuit fuse blown or circuit breaker tripped.

Inoperative system switch. Test for continuity. Loose or disconnected wiring

at switch. Inoperative switch (On-Off). Test for continuity, 3 and 2, 5 and 6.

Dirty Filter. Clean as recommended in Owner’s Manual. Restricted air ﬂ ow. Check for dirty or obstructed coil - clean as required. Inoperative thermostat. Test for shorted thermostat or stuck contacts. Short of refrigerant. De-ice coil and check for leak.

Partially restricted capillary.

Inoperative fan motor . Test and replace if inoperative.

Replace fuse, reset breaker. If repeats, check fuse or breaker size. Check for shorts in unit wiring and components.

Check wiring and connections. Connect per wiring diagram.

De-ice coil. Check temperature differential across coil. Touch test coil return bends for same temperature. Test for low running current.

COMPRESSOR RUNS CONTINUALLY.

DOES NOT CYCLE OFF.

THERMOSTAT DOES NOT TURN UNIT ON.

THERMOSTAT DOES NOT TURN UNIT OFF .

Excessive heat load. Test cooling performance of unit. Unit undersized. Restriction in line.

Refrigerant leak.

Thermostat contacts stuck.

Loss of charge in thermostat bulb.

Loose or broken parts in thermostat.

Incorrect wiring. Connect per wiring diagram. System switch open. T est for continuity at switch terminals 2 and 3.

Thermostat set at coldest point T urn to highest temperature setting to see of unit will cycle off. Thermostat contacts stuck.

Switch (On - Off) shorted.

Check for partially iced coil. Check temperature split across coil.

Check for presence of oil on silver soldered connections. Check for partially iced coil. Check split across coil. Check for low running amperage.

Check operation of thermostat. Replace if contacts remain closed.

Place jumper across thermostat terminals. If unit operates, replace thermostat.

Check as above.

Disconnect power to the unit. Remove cover of thermostat and check if contact is stuck, if so replace thermostat.

Test switch for open contacts at terminals 2 and 3 with switch in “Off” position.

TROUBLESHOOTING (Continued)

PROBLEM POSSIBLE CAUSE TO CORRECT

COMPRESSOR ATTEMPTS TO START, OR RUNS FOR SHORT PERIODS ONLY.

CYCLES ON OVERLOAD.

Compressor attempts to start before system pressures are equalized.

Low or ﬂ uctuating voltage.

Incorrect wiring. Connect per wiring diagram. Shorted or incorrect capacitor . Restricted or low air ﬂ ow through

conde nser coil. Compressor running abnormally

hot. Overload opens too soon.

Allow a minimum of two (2) minutes to allow pressures to equalize before attempting to start.

Check voltage with unit operating. Check for other appliances on the circuit. Unit should be on separate circuit for proper voltage, and be fused separately.

Check by substituting a known good capacitor of correct rating.

Check for proper fan speed or blocked condenser. Check for kinked discharge line or restricted condenser.

Check amperage. Change compressor if all other corrections above are

normal.

COMPRESSOR DOES NOT START - FAN MOTOR RU NS .

DOES NOT COOL, OR COOLS ONLY SLIGHTLY.

Thermostat contacts not closing. Low voltage supply. Check for nameplate voltage.

Switch (On-Off) inoperative. Test for continuity. Open capacit or.

Internal overload open. Relay open Replace relay

Open or shorted compressor windings

Thermostat open or inoperative. Dirty air ﬁ lter. Clean as recommended in Owner’s Manual.

Dirty or plugged condenser or evaporator coil.

Poor air circulation in area being cooled.

Low capacity - undercharge. Clean, check for leak and make repair. Compressor not pumping properly.

Check continuity of thermostat at coldest setting. Jump contacts, if compressor runs, replace thermostat.

Check by substituting a known good capacitor of correct rating.

Check voltage at compressor terminals. If voltage is satisfactory, replace compressor.

Check windings for continuity and resistance. Direct test compressor. If direct test fails, replace compressor.

Set to coldest position. Test thermostat and replace if necessary.

Use steam or detergents to clean.

Adjust air louvers.

Check amperage draw against nameplate. If not conclusive, make pressure test.

TROUBLESHOOTING (Continued)

PROBLEM POSSIBLE CAUSE TO CORRECT

Defective switch (On-Off). Check continuity across terminals 2 and 3.

Check by substituting a known good capacitor of the same rating.

Adjust motor mount to attain proper fan blade and blower wheel clearance.

Check for deteriorated compressor grommets, or missing mounting parts.

Adjust and tighten as required.

FAN MOTOR DOES NOT RUN.

SWITCH (ON-OFF) DOES NOT CUT FAN MOTOR OFF.

NOISY AND/OR VIBRATION.

Fan capacitor open. Inoperative fan motor . Direct test fan motor.

Incorrect wiring of fan circuit. Connect per wiring diagram. Relay open. Replace Relay . Check for seized motor bearings. Rotate by hand, add oil , if nois y, replace. Bound fan blade or blower wheel. Adjust for proper clearance.

Selector Switch Relay Replace selector switch. Replace relay.

Poor installation. Refer to Installation Instructions for proper installation. Fan blade striking chassis.

Compressor vibrating. Loose cabinet parts, improperly

mounted components, tubing rubbing.

WATER LEAKS INTO ROOM.

OUTSIDE WATER LEAKS.

Evaporator drain pan overﬂ owing. Clean obstructed drain trough. Condensation forming on bottom

of base pan. Water dripping from discharge air

grilles. Evaporator drain pan cracked or

obstructed. Water in center section of base

pan (compressor area). Dirty Condenser coil. Clean with steam or detergent.

Fan blade and slinger ring improperly positioned.

Evaporator drain pan broken or cracked. Reseal or replace.

Dirty evaporator coil, or extremely high humidity conditions. Clean coil with steam or detergent.

Repair and clean, or replace as required. Remove condenser shroud, Clean and remove old sealer

from base pan and shroud. Apply new sealer, reinstall and check.

Adjust fan blade to 1/2" clearance from condenser coil.

WIRING DIA GRAM

MODELS SH15L30-B and SH20L30-B

HAZARDGARD CABINET PARTS

HAZARDGARD CHASSIS PARTS

HAZARDGARD PARTS LIST

REF DESCRIPTION PART NO# MODELS CODE

ELECTRICAL PARTS

SH15L30-B

1 COMPRESSOR 61193549 1 600 1 COMPRESSOR 61193550 1 600 2 MOTOR, FAN 61871426 1110 2 MOTOR, FAN 61871427 1110 5 SWITCH, ON-OFF DPST 60935300 1 1 130

* INSULATOR, ELECTRICAL 61829700 1 1 399

* RELAY, SOLID STATE 61108800 2 2 399 6 THERMOSTAT 61822502 1 1 120 7 CAPACITOR 20/7.5 440 V. 61080546 1 150 7 CAPACITOR 25/7.5 440 V 61080547 1 150

* HARNESS, WIRE, COMP. 61821308 1 1 399

REFRIGERATION PARTS

SH15L30-B

9 EVAPORATOR COIL 61850100 1 400 9 EVAPORATOR COIL 61850001 1 400

10 CONDENSER COIL 62050410 1 410 10 CONDENSER COIL 62050411 1 410

* DRIER, LIQUID 60308101 1 1 480

* CAPILLARY TUBE 01390005 1 471

* CAPILLARY TUBE 03760518 2 471

* VALVE, BY-PASS 60809500 2 520

SH20L30-B

HAZARDGARD PARTS LIST

REF DESCRIPTION PART NO# MODELS CODE

CHASSIS PARTS

SH15L30-B

8 HOLDER, THERMOSTAT 61829800 1 1 999

11 KNOB, CONTROL 61493915 1 1 761 17 DECORATIVE PANEL 61822662 1 1 760 22 FAN BLADE, COND. 60542003 1 710 22 FAN BLADE, COND. 60542004 1 710 23 BLOWER WHEEL, EVAP. 60610616 1 700 23 BLOWER WHEEL, EVAP. 60610617 1 700 25 FAN MOTOR MOUNT 61802500 1 900 25 FAN MOTOR MOUNT 61804100 1 900 26 SHROUD, CONDENSER 61803601 1 720 26 SHROUD, CONDENSER 61804901 1 720 27 BRACE, COND.SHROUD 61802600 3 3 722 29 BLOWER FRONT 61817300 1 742 29 BLOWER FRONT 61817400 1 742 30 SCROLL 61814905 1 743 30 SCROLL 61817505 1 743 32 BASE PAN 61803444 1 1 730 34 BOLT, COMP. MOUNT 91400400 3 3 791 35 PLENUM ASSEMBLY 61831006 1 1 753 36 OUTER SHELL 61825708 1 770 36 OUTER SHELL 61825709 1 770 37 GRILLE, INTAKE 61808906 1 772 37 GRILLE, INTAKE 61811111 1 772 38 WINGBOARD 60294415 1 999 38 WINGBOARD 60294420 1 999 40 ANGLE, WINGBOARD TOP 61819711 1 1 999 41 ANGLE,WINGBORD SIDE 61819811 2 2 999

* LATCH, INTAKE GRILLE 61989000 2 2 752

* FILTER, AIR 60865808 1 754

* FILTER, AIR 60865809 1 754

* HOLDER, FILTER 61823000 2 2 756

* DRAIN PAN, EVAP. 61803800 1 1 840

* GROMMET, COMP. MOUNT 01193549 3 3 790

* REAR GRILLE

* REAR GRILLE 61818501 1 771

* BAG, ASSY . HARDWARE 60846016 1 1 999

* GASKET, CHASSIS 61717301 1 1 780

61818500 1 771

SH20L30-B

OPTIONAL ACCESSORY ITEMS

* DRAIN KIT, DC-2 01900235 11

* START KIT, CAP.\RELAY 01900312 11

Friedrich Air Conditioning Company

P.O. Box 1540

San Antonio, TX 78295

210.357.4400

www.friedrich.com

HAZARDGARD

ROOM AIR CONDITIONERS

LIMITED WARRANTY

LIMITED ONE YEAR PARTS WARRANTY

1. Limited warranty – One year. Friedrich warrants that it will provide a replacement for any part of this HazardGard Room Air

Conditioner found defective in material or workmanship for a period of one (1) year from the date of original purchase.

2. Limited warranty – One year. The Friedrich warranty also covers the cost of labor for repairing any compressor, condenser, evaporator or inter-connecting tubing found defective within the warranty period, providing the unit is returned to an authorized Friedrich Repair Station located within the Continental United States.

The Friedrich warranty does not cover:

(1) Any charges for removal, transportation or reinstallation of the unit; (2) the cost of labor to replace parts other than those described above; and (3) does not apply to any HazardGard Room Air Conditioner that has been subject to (a) accident, misuse, flood, fire, or neglect; (b) repairs or alterations outside of the Friedrich Authorized Dealer or Service Center so as to affect adversely its performance and reliability; or (c) any repairs or servicing as a result of using parts not sold or approved by Friedrich.

LIMITATIONS: This warranty is a LIMITED warranty. Anything in the warranty notwithstanding, IMPLIED WARRANTIES FOR PARTICULAR PURPOSE AND MERCHANTABILITY SHALL BE LIMITED TO THE DURATION OF THE EXPRESS WARRANTY. MANUFACTURER EXPRESSLY DISCLAIMS AND EXCLUDES ANY LIABILITY FOR CONSEQUENTIAL OR INCIDENTAL DAMAGES FOR BREACH OF ANY EXPRESSED OR IMPLIED WARRANTY.

FRIEDRICH AIR CONDITIONING CO.

Post Ofﬁ ce Box 1540 · San Antonio, Texas 78295-1540 4200 N. Pan Am Expressway · San Antonio, Texas 78218-5212 (210) 357-4400 · FAX (210) 357-4480 www.friedrich.com

Printed in the U.S.A.

(10-04)

HG-SVC-PRTS-07 (3-07)

Friedrich SH20L30-B, SH15L30-B User Manual

Specifications and Main Features

Frequently Asked Questions

User Manual
