What type of air conditioner do you need?

WINDOW AIR CONDITIONERS THRU-THE-WALL PORTABLE HAZARDOUS LOCATION

Kühl

PERMANENT INSTALLATION Y Y Y Y — Y

SEASONAL INSTALLATION Y Y — — Y —

CAN BE INSTALLED THRU-THE-WALL

Chill

Y -except

CP05

WallMaster

Y Y — Y

Uni-Fit

ZoneAire

Hazardgard

specifications 16 specifications 25

Portable Air Conditioners Hazardous Location Air Conditioners

page

specifications 28 specifications 31

ENERGY STAR

POWER SUPPLY

115V Y Y Y Y Y —

230V Y Y Y Y — Y

COOLING W/ HEAT

HEAT PUMP Y — Y — Y —

ELECTRIC HEAT Y Y Y Y — —

EXTRA LARGE CAPACITY

>17,000 Btu Y Y — — — Y

>25,000 Btu Y — — — — —

SPECIAL FEATURES

ROLLS FROM ROOM TO ROOM

SMARTGRID READY Y* — — — — —

ENHANCED FILTRATION Y — — — — —

OPTIONAL FEATURES

WI-FI CONTROL Y* — — — — —

CREATE CUSTOM SCHEDULES

GROUP UNITS FOR CENTRALIZED CONTROL

DECORATOR COLORS Y — — — — —

Y Y Y Y NA NA

— — — — Y —

Y* — — — — —

*Requires FriedrichLink® adapter accessory (sold separately).

Window Air Conditioner Selector Guide

COMMERCIAL GRADE RESIDENTIAL GRADE

Kühl

Bold design and

exclusive features.

Description

Room size (sq. ft.) 100-2700 350-2700 100-1500 100-1500

OVERVIEW

Functions

Applications

Electronic controls Y Y Y Y

Timer

Remote control LCD LCD LCD LCD

Control with smart phone or computer with FriedrichLink

Auto-restart w/setting retention Y Y Y Y

Auto temp/ fan speed adjustment Y Y — —

Auto-changeover — All except EQ08 — —

COMFORT & CONVENIENCE

Air ow directions 8 8 4 4

Auto swing louvers — — All except CP05 Y

Optional color fronts Y Y — —

Steel inner wall and extra dense insulation Y Y — —

Vibration isolating design and components

TECHNOLOGY

Superior airflow design Y Y — —

SOUND REDUCTION

ENERGY STAR® models Y Y Y —

Smart Grid capable Y Y — —

(accessory required)

Programmability to rival

central systems. Trusted

Friedrich durability.

Designer colors.

COOL

COMMERCIAL AND

RESIDENTIAL

7-day with up to 4 settings per day*;

24 hr. timer

Y Y — —

All the performance and

durability of Kühl, plus

heating. Choose efcient

heat pump or toasty

HEAT/COOL

COMMERCIAL AND

7-day with up to 4 settings per day*;

Kühl

+ Chill

electric heat.

RESIDENTIAL

24-hr. timer

Good value. Available

in a large range of cooling capacities.

24-hr. timer.

COOL

RESIDENTIAL AND LIGHT

COMMERCIAL

24 hr. 24-hr.

Chill

Good value. Four models

with electric heat.

24-hr. timer.

HEAT/COOL

RESIDENTIAL AND LIGHT

COMMERCIAL

Product Selection Tools

These tools are only a guide. Due to variations in room design, local climate and occupancy, larger areas may require the use of multiple units to provide the optimal cooling solution. Please consult your local authorized Friedrich distributor or the Friedrich Technical Assistance team for sizing or application assistance.

COOLING SIZING GUIDE The cooling guide to the right is based on normal room insulation, average

number of sun-exposed windows and two-person occupancy.

HEATING SIZING INFORMATION

In heating mode, an energy efcient heat pump will generate slightly less

heating Btus than it would in cooling mode. However, in heating mode, heat pumps use approximately 1/3 the energy of resistance heat, making them an

excellent high-efciency alternative. Back-up resistance heat ensures heat operation below 40� F outdoor temperatures for year ‘round comfort.

Common Window Types

Traditional wooden windows are typical in many residences built before 1965, but more modern windows are often constructed of aluminum or vinyl.

Many newer energy efcient windows like double-glazed windows actually

sandwich low conductance gas between two panes of glass. While Friedrich air conditioners may be used with this type of window, care should be taken not to break the seal between the two panes of glass during installation.

Depending on the style of window in the application, you may want to consider the cooling solutions in the adjacent chart. Professional installers may be able

to make eld adaptations, including removing all or part of a window to support

alternative types of air conditioning units. Professional installers should also be able to tell you about any local codes that may apply to your installation.

THRU-THE-WALL INSTALLATION Many models may be installed through a wall so long as the unit’s side vents are not blocked or covered in any way. See page 17, In-wall Installation max. depth.

COOLING SIZING GUIDE

Area to be conditioned

in sq. ft. Cooling Btu

100 - 150 5000

150 - 250 6000

250 - 300 7000

300 - 350 8000

350 - 400 9000

400 - 450 10000

450 - 550 12000

550 - 700 14000

700 - 1000 18000

1000 - 1200 21000

1200 - 1400 23000

1400 - 1600 25000

1600 - 1900 28000

1900 - 2700 36000

WHICH AIR CONDITIONER

IS RIGHT FOR YOU?

Window Type Air Conditioner

Single/double hung Window, portable,

ductless

Slider Window*, portable,

ductless

Casement Portable, ductless

Vertical Casement Portable, ductless

Environmentally friendly R-410A Y Y Y Y

Energy saver switch Y Y Y Y

EARTH FRIENDLY

RoHS compliant Y Y — —

Washable, antimicrobial air lter Y Y Y Y

Optional carbon lter Y Y — —

Check lter reminder Y Y Y Y

HEALTH

Superior fresh air intake/stale air exhaust All except SQ All except EQ08

EntryGard™ anti-intrustion protection Y Y Y Y

Insect barrier All except SQ All except EQ08 — —

SAFETY

Slideout chassis Y Y All except CP05 Y

Power cord direction Left or right Left or right Left or right Left or right

Thru-the-wall installation option Y Y All except CP05 Y

INSTALLATION

Window installation hardware Heavy duty

*Requires internet connection and FriedrichLink

accessory.

Heavy duty,

available as accessory

Stale air exhaust only,

all except CP05

Standard Standard

Awning Portable, ductless

Hopper Portable, ductless

Picture (non-opening) Thru-the-wall,

ductless

*May require additional modifications

Stale air exhaust only

Single/double hung Slider

(Opens up or down) (Opens left to right, or right to left)

Awning Hopper Casement

(Cranks out) (Opens in) (Cranks out)

Kühl Construction.

For over 125 years, Friedrich products have been renowned for their commercial-grade, built-to-last design.

Advanced engineering, high- end materials and components, and rigorous product testing are just a few examples of Friedrich's commitment to quality. When designing Kühl, our engineers challenged convention to develop the very best window air conditioner on the market.

Kühl incorporates high-end materials like heavy-gauge

galvanized steel, ried

copper tubing, and high-tech

aluminum ns.

Kühl also uses the most durable components to extend the life of your air conditioner, including fully -enclosed fan motors that seal out dirt, and

powerful, energy-efcient

compressors, which make Kühl as tough an air conditioner as we’ve ever built.

Kühl Quiet.

Kühl Comfort.

KÜHL. BUILT TOUGH FOR THE

MOST DEMANDING APPLICATIONS

Kühl has been engineered for quiet operation. Materials have been chosen because of their soundabsorption properties and every moving part has been braced and insulated. For example, extra thick rubber grommets absorb vibration and reduce noise inside, while steel inner walls and extra dense insulation block outdoor noise.

Rugged hardboard side panels help reduce noise and keep out light. The unique air path is more streamlined, drawing air through the sides, away from moving parts. And our larger discharge vents allow for smoother

airow, delivering maximum

conditioned air quietly.

The most comfortable temperature is the one you never notice. Kühl uses multiple builtin environmental sensors to more accurately monitor indoor and outdoor temperatures so that it can maintain your ideal settings.

Kühl+ models have the ability to cool or heat as needed so units can operate year-round. And, like the most advanced central systems, Kühl+ automatically switches between air conditioning and heating functions to maintain the desired comfort level. You won't have to

lift a nger.

Plus, Kühl's air ow systems are

tested for powerful and precise air distribution which means faster cooling when you need it most.

C APABLE

SMART GRID

Control

Deep Red

COLOR YOUR WORLD

with one of six Kühl colors.

Change your Kühl's appearance to complement your color scheme or to make a bold statement.

Built-in controls

Wi-Fi control

Wireless thermostat

SIMPLE OPERATION

Turn the unit on, select ‘MODE’ and make simple up/down

temperature adjustments either at the control panel or with included remote.

BUILT-IN 7 DAY SCHEDULES

Kühl units include two 7-day energy management schedules which can be accessed and selected from the unit’s controls.

The '

Residential

temperature temporarily during the hours when most people are away at work and lower them again prior to the time when most people will return home.

The '

Commercial

after typical working hours and on weekends when commercial spaces are typically unoccupied.

CUSTOM 7-DAY SCHEDULE (

separately

Create up to 5 custom programs that you can use to operate your Kühl air conditioner for maximum comfort and efficiency. Each 7-day program allows up to 4 setting changes per day.

WIRELESS CONTROL

Control Kühl units with a smartphone, tablet or computer. You can even group units to operate as a single system for central air-like control.

KWW WIRELESS THERMOSTAT (

separately.

Connect up to 8 Kühl units* with 1 KWW thermostat. Each unit requires 1 communication module (KCM). KWW thermostat ships with 1 KCM module.

’ schedule causes Kühl to raise the room

' schedule tells the unit to raise temperatures

requires optional accessory sold

)

requires optional accessory sold

)

Control Kühl with a smartphone, tablet or computer.

FriedrichLink

Wi-Fi allows monitoring and control of one or all of your Kühl air conditioners remotely.

Connect Kühl* to a Building Management System.

Kühl’s streamlined modern design in Neutral Gray can blend in with any décor.

Or coordinate a look that complements your space by using any of the six colored front covers.

Neutral Gray

(STANDARD)

Pink Diamond Cobalt Blue Classic Beige Black Onyx Designer White

Kühl units* can be connected to a Building Management System with a KCM module (1 for each Kühl unit) and a KJD. KEG may also be required depending on Building Management System. Contact your Friedrich sales representative for more information.

*Wireless thermostat and Building Management Systems are not compatible Kühl SQ and EQ models.

Smart Grid Capable

Kühl is the rst room air conditioner that can tie into a power company’s smart grid.

A grid is a network that brings electricity from power stations to consumers. New technologies allow power companies to adjust

electrical loads of residential users based on their specic needs

- this is called a ‘smart grid’. Smart grid helps consumers to be

better informed about their electricity usage and allows electric

utility companies to serve customer demand in the most efcient

way.

For example, during a hot summer afternoon when AC units are running at full capacity, the smart grid can send information to recalibrate other loads, which helps to alleviate stress on the system as a whole.

Source: SGIC (Smart Grid Information Clearinghouse)

Window Air Conditioners

Ultra Premium Line

Experience the control and convenience of a central air conditioning system in ways you never thought possible. Control Kühl units via FriedrichLink

If you have a room that is too cold in winter, too hot in summer, adding a Kühl+ model is the perfect solution.

You’ll nd more

options, features and ways to customize your cooling experience than you ever thought possible in a window air conditioning solution.

Full LCD display shows MODE, FAN SPEED, SET TEMPERATURE and SCHEDULE. Adjust TEMPERATURE and FAN SPEEDS, set AUTO MODE and turn the SCHEDULE ON/OFF.

FITS WINDOWS FROM

22" TO 42" WIDE

Neutral Gray

(STANDARD)

FITS WINDOWS FROM

27 3/8" TO 42" WIDE

Neutral Gray

(STANDARD)

COOL

COOL & HEAT

Kühl

5200-9600 Btu

Up to 11.2 EER

Kühl®+

Electric Heat

COOLING 7900 Btu

Up to 11.2 EER

ELECTRIC HEAT 4000 Btu

Kühl®

8000-36000 Btu

Up to 11.5 EER

Kühl®+

Electric Heat

COOLING 12000-36000 Btu

Up to 11.3 EER

ELECTRIC HEAT 8900-17300 Btu

Kühl®+

Heat Pump

COOLING 9500-24000 Btu

Up to 10.4 EER

HEATING 8000-22000 Btu

Up to 2.7 COP
