FloatingAir® Series
Ductless Split Systems
THE EXPERTS IN ROOM AIR CONDITIONING
FLEXIBLE, EASY-TO-INSTALL ZONED
COMFORT SOLUTIONS FROM THE LEADER
IN ROOM AIR CONDITIONING
Whether you're heating and cooling a single room or multiple rooms, you won't nd quieter, more
energy-efcient solutions than Friedrich ductless split systems. Choose from sleek wall-mounted
models, ceiling cassettes that mount ush with the ceiling, and ducted units that install out of sight.
RESIDENTIAL
APPLICATIONS
COMMERCIAL
APPLICATIONS
2 | FLOATING AIR® SERIES DUCTLESS
WI-FI CONTROL*
ANYTIME, ANYWHERE.
*Available on Premier and Pro wall-mounted models,
and on Pro ceiling cassette models
ALL OF THE ADVANTAGES OF DUCTLESS SPLIT
SYSTEMS AND FRIEDRICH QUALITY
Zero duct loss
According to the DOE, ducted
systems lose an average of 25-40% in
performance due to leaks, cracks or
disconnections in ductwork.
No ductwork means that ductless systems do not
experience duct loss, saving energy and money.
No dirty air ducts*
With a ductless system, there’s no need to clean
dirty air ducts that can harbor dust,
germs and allergens that are eventually
blown into your home or office.
Zone cooling flexibility
Independently condition up to four separate zones
using only a single outdoor unit. Cool or
heat only the zones that are in use. Set
individual comfort levels for each zone.
Optimized airflow
4-way air swing quickly disperses cool or warm air
to all four corners of the room to provide comfort
throughout.
The 'Surge Air' feature moves air at an
even higher speed for rapid cooling.
Friedrich Precision Inverter® delivers
exceptional energy efficiency and smooth
performance
Precision Inverter technology varies the
compressor, the outdoor and the indoor fan speeds,
eliminating constant compressor start-ups/shut-
downs that traditional systems require to maintain
the set temperature.
Each system can adjust capacity and cooling output
to provide only the amount of cooling needed at a
given time. The result is optimal comfort with low
energy costs.
THE ADVANTAGES OF INVERTER
DUCTLESS SPLIT SYSTEMS
TRADITIONAL SYSTEM INVERTER SYSTEM
At initial start up, a xed capacity
system slowly reaches the set
temperature.
Complete shutdown once set
temperature is achieved.
Temperature within the space
rises until 2nd system start up.
System works at full capacity to
again reach set temperature.
System cycles on and off
continually to maintain the set
temperature.
At initial start up, utilizes
variable capacity to
quickly reach the set
temperature.
Reduces capacity as set
temperature is achieved.
Variable capacity
maintains set
temperature keeping
space comfortable
with reduced energy
consumption.
Available built-in Wi-Fi
Easily adjust settings and power units off and on
with your smartphone. The FriedrichGo™ app is
easy to set up and use. Compatible with
Amazon Alexa or Google Home.
Wi-Fi available on Premier and Pro wall-
mounted models, and on Pro ceiling
cassette models.
Soft start technology
Friedrich soft start technology starts the
compressor with significantly reduced amperage at
start up, saving energy versus compressors utilizing
locked rotor amperage (LRA).
3
A UNIQUE DESIGN MAKES FRIEDRICH—
THE EASIEST DUCTLESS TO
INSTALL, CLEAN & SERVICE
EXCLUSIVELY ON
FLOATING AIR PRO AND
PREMIER SERIES
The Problem
On typical ductless indoor units,
accessing the indoor coils is
extremely difficult and takes so much
time that a thorough cleaning may be
next to impossible.
Access to piping, wire terminal
blocks, the fan and fan components is
also a challenge.
The Solution:
Friedrich FastPro was designed with
the HVAC technician in mind. In a few
easy steps that can be performed
in minutes, the entire blower wheel
assembly can be removed for easier,
faster cleaning and service.
Also, you'll have easy access to the
terminal blocks. FastPro will save you
hours on the job site.
40%
FASTER
TO INSTALL
*
45%
FASTER
TO CLEAN
*
50%
FASTER
TO SERVICE
*
*Faster than similar installation, cleaning and service performed on standard ductless wall-mounted units.
4 | FLOATING AIR® SERIES DUCTLESS
IN A FEW EASY STEPS
You can access the blower wheel assembly and slide it out
for full access to the indoor coil
Back out electrical panel screws Remove electrical access panels (2) Lock the access panel
Unplug the wire harness Remove screws then slide out the blower wheel assembly Complete access to the coils for easy cleaning
• Easy access to the wire terminal
blocks
• Included kickstand tilts unit away
from the wall providing ample
space for your hands to work
• Onboard error codes help to
ensure trouble-free operation
• Advanced corrosion protection
• Auto clean
• Washable, antimicrobial air filters
UNIQUE FEATURES
FOR FASTER
INSTALLATION AND
EASIER SERVICE
• Alignment arrows on the
Friedrich wall bracket help you
mark and drill the hole in the
wall accurately, and with total
confidence
• Easy-to-remove modular drain
pan assembly
• Quick access to tangential blower
and motor makes repairs easier
• Clear access to piping
• Built-in Wi-Fi models available
5
THE CONTRACTOR'S CHOICE FOR DUCTLESS
Friedrich has three exceptional lines of ductless with unique features for easy installation.
For contractors, this means less time on the job, and the opportunity to provide your customer with
maintenance agreements on equipment that is cleaning and service friendly.
FLOATING AIR®
PREMIER
SINGLE ZONE
Wall-mounted
FLOATING AIR®
PRO
SINGLE ZONE
AND MULTIZONE
Wall-mounted
Ceiling Cassettes
®
The Insider
Concealed Ducted
Units
• Highest efficiencies
• FastPro™ design for fast
installation, cleaning
and service
• Available with built-in
Wi-Fi
• Extended operating
ranges, heating and
cooling
• Excellent efficiencies
• FastPro™ design
for fast installation,
cleaning and service
• Available with built-in
Wi-Fi
• Extended operating
ranges, heating and
cooling
• 115V wall-mounted
heat pumps
FLOATING AIR
®
SELECT
SINGLE ZONE
Wall-mounted
6 | FLOATING AIR® SERIES DUCTLESS
• High efficiency
• Moderate pricing
• Exceptional value
• 115V wall-mounted
heat pumps
FEATURE COMPARISON
A feature-by-feature comparision to help you select the best ductless system for your application.
SYSTEM TYPE WALL-MOUNTED CASSETTE CONCEALED DUCTED
Zones SINGLE ZONE MULTIZONE SINGLE ZONE MULTIZONE SINGLE ZONE MULTIZONE
Pro
Floating Air® Series Premier Pro Select Pro Pro Pro
Installation
FastPro™ Design
Heat pump
115 volt models
SEER
Low ambient cooling operation
Low ambient heating operation
Inverter driven compressor
Built-in Wi-Fi models, FriedrichGo app
Google Home/Amazon Alexa compatible
Auto changeover
24- Hr. Programmable timer
Remote control
Wall controller option
7-Day Programmability
(with wall control)
Auto restart
Surge cool/heat
Dry mode
Auto Clean
Advanced Corrosion Protection
4-way auto swing
Washable, antimicrobial air lters
*FastPro not available on FPHSW36A3A. ** (9K/12K/18K -4°F) (18K/24K -13°F)
Wall Wall Wall Wall Ceiling Ceiling Concealed Concealed
—
— — — —
—
Up to 28.0 Up to 23.3 Up to 18.0 Up to 22.0 Up to 19.0 Up to 22.0 Up to 17.6 Up to 21.0
0° F 5° F 0° F 5° F 5° F 14° F 5° F -4° F
-13° F -4° F* -4° F** -13° F -4° F -4° F -4° F -13° F
— — — — —
—
—
—
— — — — — —
—
—
The Insider™
—
Included Included
The Insider™
— —
— —
— —
— —
Pro
—
MODEL
IDENTIFICATION
GUIDE
Model Type:
FR- Floating Air Premier
FP- Floating Air Pro
FS- Floating Air Select
Function:
HS – Heat Pump Single
HM – Heat Pump Multi
HF – Heat Pump Flex Single and
Multizone
Approximate
Cooling
BTU/HR
Voltage
1- 115 Volts
3- 230 Volts
FP HS W 09 A 1 A - A
Application:
W- Wallmounted
D- Ducted (Insider)
C- Cassette
R- Remote Condenser
Model
Introductory
Character:
A- 2019
B- 2020
C- 2021
D- 2022
Marketing Suffix:
A- Standard unit
B- Built-in Wi-Fi
7
PREMIER SERIES | DUCTLESS SPLIT SYSTEMS
PRECISION
SINGLE ZONE • WALL-MOUNTED HEAT PUMPS
Top cooling and heating performance in extreme climates.
28.0 SEER - our highest efficiencies ever!
Features for comfort and
convenience
• Create customizable, 7-day
schedules
• Precision Inverter
(variable speed compressor)
®
design for the fastest
®
Wi-Fi available on select models
for control anytime, anywhere
• Easy to use FriedrichGo™ app
• Control with smartphone
• Compatible with Amazon Alexa
and Google Home
WIRELESS REMOTE
WITH THE ABILITY
TO CHANGE TO A
COOL-ONLY REMOTE
• Fast Pro
access for maintenance of any
wall-mounted ductless system
• Soft start compressor
• BLDC motor
• Our highest efficiencies for the
lowest operating cost
• DiamonBlue Advanced Corrosion
Protection
• Auto Clean indoor coil
• Cooling/Heating/Fan/Auto mode
• Surge Cool/Heat
• Natural air flow
• Ultra quiet operation
• Sleep mode
• Auto restart
• Auto changeover
• 24-hour on/off timer
• ENERGY STAR
• Hidden display (only visible during
operation)
®
technology
®
qualified model
FRHSR09A2A, FRHSR12A2A
8 | FLOATING AIR® SERIES DUCTLESS
Operates in extreme conditions
• Low ambient operation down to
0°F (Cooling mode)
• Low ambient operation down to
-13°F (Heating mode)
• Low temperature compressor
start-up protection
PARTS
COMPRESSOR
WARRANTY
WARRANTY
PREMIER SERIES SPECIFICATIONS
PERFORMANCE RATINGS Single Zone Wall-Mounted - Heat Pumps
9k 12k
SYSTEM MODEL NO.
INDOOR MODELS
FRHW093
FRHW093A Wi-Fi
FRHSW09A3 A
FRHSW09A3B Wi-Fi
OUTDOOR MODEL FRHSR09A3A FRHSR12A3A
SPECIFICATIONS
CAPACITY COOLING (RATED) Btu 9000 12000
CAPACITY COOLING (MIN~MAX) Btu 3600-10000 4000-13500
CAPACITY HEATING@470F (RATED) Btu 10500 13000
CAPACITY HEATING@170F (RATED) Btu 6500 8000
CAPACITY HEATING (MIN~MAX) Btu 3600-10500 4000-14000
SENSIBLE HEAT RATIO 76% 77%
HSPF 12.5 12.0
SEER 28.0 25.0
EER 16.1 15.4
ENERGY STAR YES YES
MOISTURE REMOVAL Pts/h 1.9 2.5
AIRFLOW (QUIET, LOW, MED, HIGH) CFM 416/384/355/279 598/536/446/345
SOUND RATING - INDOOR dB-A 39/34/31 45/41/39
SOUND RATING - OUTDOOR dB-A 55 55
OPERATING RANGE (COOLING) °F 0˚-115˚ 0˚-115˚
OPERATING RANGE (HEATING) °F -13˚-75˚ -13˚-75˚
EST. YEARLY OPERATING COST $ 50 70
ELECTRICAL DATA
POWER SOURCE V-Hz-Phase 230/208-60-1 230/208-60-1
MINIMUM AMPACITY A 10A 12A
COOLING WATTS W 559 779
COOLING AMPS 2.3 4.6
HEATING WATTS W 905 856
HEATING AMPS 3.4 4.8
MAX. TD FUSE/ BREAKER A 15A 15A
POWER AND COMMUNICATION CABLE
No. x AWG
4 x 14AWG 4 x 14AWG
REFRIGERATION SYSTEM
REFRIGERANT R410a R410a
COMPRESSOR TYPE Rotary Rotary
CONNECTIONS Flare Flare
LIQUID LINE O.D. in
SUCTION LINE O.D. in
1
/4
3
/8
FACTORY PRECHARGE ft 25 25
REFRIGERANT CHARGE oz 38.8 45.9
MIN./MAX. LINE LENGTH ft 10-66 10-66
MAX. HEIGHT DIFFERENCE ft 33 33
DIMENSIONS & WEIGHT
INDOOR UNIT
W X H X D in 33
7
/8 x 11 1/8 x 8 1/2 38 1/8 X 13 1/8 X 10
NET WEIGHT lbs 22 28.5
SHIPPING WEIGHT lbs 26.5 34
OUTDOOR UNIT
W X H X D in 31 7/8 x 23 x 11 31 7/8 x 23 x 11
NET WEIGHT lbs 75 84
SHIPPING WEIGHT lbs 81.5 92.5
TOTAL NET WEIGHT lbs 97 112.5
TOTAL SHIPPING WEIGHT lbs 108 126.5
FRHW12 3
FR HW123 A Wi-Fi
FRHSW12A 3A
FRHSW12A3B Wi-Fi
1
/4
3
/8
Your operating costs will depend on your utility rates and use.
The estimated operating cost is based on a electricity cost of $.12 per kWh.
For more information, visit ww w.ftc.gov/energy.
Due to continuing research in new energy-saving technology, specications are
subject to change without notice.
9
PRO SERIES | DUCTLESS SPLIT SYSTEMS
PRECISION
SINGLE ZONE • WALL-MOUNTED HEAT PUMPS
The contractor’s line with extensive features to make installation
and service faster and easier. Exceptional efficiency and dependable
performance.
Features for comfort and
convenience
• Create customizable, 7-day
schedules
®
technology
®
qualified models
Wi-Fi available on select models
for control anytime, anywhere
• Easy to use FriedrichGo™ app
• Control with smartphone
• Compatible with Amazon Alexa
and Google Home
WIRELESS REMOTE
WITH THE ABILITY
TO CHANGE TO A
COOL-ONLY REMOTE
• Precision Inverter
(variable speed compressor)
• Fast Pro
®
design for the fastest
access for maintenance of any
wall-mounted ductless system
• Soft start compressor
• BLDC motor
• Auto Clean indoor coil
• Cooling/Heating/Fan/Auto mode
• LCD remote
• Surge Cool/Heat
• Tangential fan for optimum air flow
• Ultra quiet operation
• Sleep mode
• Auto restart
• Auto changeover
• 24-hour on/off timer
• ENERGY STAR
• Easy-to-read temperature display
10 | FLOATING AIR® SERIES DUCTLESS
Operates in extreme conditions
• Low ambient operation down to 5°F
(Cooling mode)
• Low ambient operation down to
-4°F (Heating mode)
• Low temperature compressor
start-up protection
PARTS
COMPRESSOR
WARRANTY
WARRANTY
PRO SERIES SPECIFICATIONS
PERFORMANCE RATINGS 115 volt models 230/208 volt models
SYSTEM MODEL NO.
INDOOR MODEL
OUTDOOR MODEL
FPHW091
FPHW09A
Wi-Fi
FPHSW09A1A
FPHSW09A1B
Wi-Fi
FPHSR09A1A FPHSR12A1A FPHSR09A3A FPHSR12A3A
SPECIFICATIONS
CAPACITY COOLING (RATED) Btu
CAPACITY COOLING MIN - MAX Btu
CAPACITY HEATING (RATED) @ 47°F Btu
CAPACITY HEATING (RATED) @ 17°F Btu
CAPACITY HEATING MIN - MAX Btu
SENSIBLE HEAT RATIO
COP
HSPF
SEER
EER
ENERGY STAR
MOISTURE REMOVAL Pts/h
AIRFLOW (HIGH/MED/LOW/QUIET) CFM
SOUND RATING - INDOOR (HIGH/MED/LOW/QUIET) dB-A
SOUND RATING - OUTDOOR dB-A
OPERATING RANGE (HEATING) °F
OPERATING RANGE (COOLING) °F
EST. YEARLY OPERATING COST U.S. $
9000 12000 9000 12000
3600-10000 4000-13500 3600-10000 4000-13500
9500 13000 9500 13000
5000 7500
3600-10500 4000-14000 3600-10500 4000-14000
76% 77% 76% 77%
3.56 3.46
10.0 10.5 10.7 10.5
19.5 22.0 22.5 22.0
12.8 13.0 13.7 13.0
YES YES YES
1.9 2.5 1.9 2.5
424/382/323/247 424/382/323/247 424/382/323/247 424/382/323/247
39/32/29/26 39/32/29/26 39/32/29/26 39/32/29/26
53 53 53 53
(-4° – 75°) (-4° – 75°) (-4° – 75°) (-4° – 75°)
(5° – 115°) (5° – 115°) (5° – 115°) (5° – 115°)
$61 $72 $53 $72
ELECTRICAL DATA
POWER SOURCE V-Hz-Phase
MIN. AMPACITY A
COOLING WATTS W
COOLING AMPS
HEATING WATTS W
HEATING AMPS
MAX. TD FUSE/ BREAKER A
POWER AND COMMUNICATION CABLE No. x AWG
115-60-1 115-60-1
13.5 16.5 10 10
700 950 655 960
6.3 8.3 2.9 4.3
780 1100 720 1110
7.0 9.7 3.1 5.0
20 25 15 15
4 x 14AWG 4 x 14AWG 4 x 14AWG 4 x 14AWG
REFRIGERATION SYSTEM
REFRIGERANT
COMPRESSOR TYPE
CONNECTIONS
LIQUID LINE O.D. in
SUCTION LINE O.D. in
REFRIGERANT CHARGE oz.
FACTORY PRECHARGE ft.
MIN. / MAX. LINE LENGTH ft
MAX. HEIGHT DIFFERENCE ft
R410a R410a R410a R410a
Rotary Rotary Rotary Rotary
Flare Flare Flare Flare
1
/4
3
/
8
33.5 40.9 33.5 40.9
25 25 25 25
9.8-50 9.8-50 9.8-50 9.8-50
33 33 33 33
DIMENSIONS & WEIGHT
INDOOR UNIT
W x H x D in
NET WEIGHT lbs
SHIPPING WEIGHT lbs
33 7/8 x 11 1/8 x 8 1/2 33 7/8 x 11 1/8 x 8 1/2
20 20 20 20
24.25 24.25 24.25 24.25
OUTDOOR UNIT
W x H x D in
NET WEIGHT lbs
SHIPPING WEIGHT lbs
TOTAL NET WEIGHT lbs
TOTAL SHIPPING WEIGHT lbs
Your operating costs will depend on your utility rates and use. The estimated operating cost is based on a electricity cost of $ .12 per kWh. For more information, visit www.ftc.gov/energy.
Due to continuing research in new energy-saving technology,
specications are subject to change without notice.
28 1/8 x 19 x 9 1/2 31 7/8 x 23 x 11 28 1/8 x 19 x 9 1/2 31 7/8 x 23 x 11
65 78 59.5 72.5
68 82.5 65 79
85 98 79.5 92.5
92.25 106.75 89.25 103.25
FPHW121
FPHW12A
Wi-Fi
FPHSW12A1A
FPHSW12A1B
1
/4
3
/
8
Wi-Fi
FPHW093
FPHW093A
Wi-Fi
FPHFW09A3A
FPHFW09A3B
Wi-Fi
FPHW123
FPHW123A
FPHFW12A3A
FPHFW12A3B
5000
3.88
230/208-60-1 230/208-60-1
1
/4
3
/
8
7500
3.42
YES
1
/4
3
/
Wi-Fi
Wi-Fi
8
11
PRO SERIES | DUCTLESS SPLIT SYSTEMS
PRECISION
SINGLE ZONE • WALL-MOUNTED HEAT PUMPS
The contractor’s line with extensive features to make installation
and service faster and easier. Exceptional efficiency and dependable
performance.
Features for comfort and
convenience
• Create customizable, 7-day
schedules
®
technology
®
qualified model
FPHFW18A3A, FPHFW24A3A, FPHFW18A3B, FPHFW24A3B
FPHSW36A3A, FPHSW36A3B
Wi-Fi available on select models
for control anytime, anywhere
• Easy to use FriedrichGo™ app
• Control with smartphone
• Compatible with Amazon Alexa
and Google Home
• Precision Inverter
(variable speed compressor)
• Fast Pro
®
design for the fastest
access for maintenance of any
wall-mounted ductless. Feature not
on model
FPHSW36A3A (B)
• Soft start compressor
• BLDC motor
• Auto Clean indoor coil
• Cooling/Heating/Fan/Auto mode
• LCD remote
• Surge Cool/Heat
• Tangential fan for optimum air flow
• Ultra quiet operation
• Sleep mode
• Auto restart
• Auto changeover
• 24-hour on/off timer
• ENERGY STAR
• Easy-to-read temperature display
WIRELESS REMOTE
WITH THE ABILITY
TO CHANGE TO A
COOL-ONLY REMOTE
12 | FLOATING AIR® SERIES DUCTLESS
Operates in extreme conditions
• Low ambient operation down to 5°F
(Cooling mode)
• Low ambient operation down to
-4°F (Heating mode)
• Low temperature compressor
start-up protection
PARTS
COMPRESSOR
WARRANTY
WARRANTY
PRO SERIES SPECIFICATIONS
PERFORMANCE RATINGS 230/208 volt models
SYSTEM MODEL NO.
INDOOR MODEL
OUTDOOR MODEL
FPHW183
FPHW183A
FPHFW18A3A
FPHFW18A3B
Wi-Fi
Wi-Fi
FPHSR18A3A FPHSR24A3A FPHSR36A3A
SPECIFICATIONS
CAPACITY COOLING (RATED) Btu
CAPACITY COOLING MIN - MAX Btu
CAPACITY HEATING (RATED) @ 47°F Btu
CAPACITY HEATING (RATED) @ 17°F Btu
CAPACITY HEATING MIN - MAX Btu
SENSIBLE HEAT RATIO
COP
HSPF
SEER
EER
18000 23500 36000
6500-19500 8000-26500 12000-38000
19000 26000 36000
11600 14500 18700
6500-20000 8000-26500 12000-38000
80% 76% 79%
3.40 3.05
11.6 10.5 8.8
23.3 21.0 16.4
13 12.5 8.6
ENERGY STAR YES YES
MOISTURE REMOVAL Pts/h
AIRFLOW (HIGH/MED/LOW/QUIET) CFM
SOUND RATING - INDOOR (HIGH/MED/LOW/QUIET) dB-A
SOUND RATING - OUTDOOR dB-A
OPERATING RANGE (HEATING) °F
OPERATING RANGE (COOLING) °F
EST. YEARLY OPERATING COST U.S. $
3.2 5.1 6.8
618/565/482/382 735/665/559/441 1030/824/706/588
45/41/37/34 47/42/36/33 50/45/40/38
55 58 60
-4° – 75° -4° – 75° -4° – 75°
5° – 115° 5° – 115° 5° – 115°
$124 $169 $376
ELECTRICAL DATA
POWER SOURCE V-Hz-Phase 230/208-60-1 230/208-60-1 230/208-60-1
MIN. AMPACITY A
COOLING WATTS W
COOLING AMPS
HEATING WATTS W
HEATING AMPS
MAX. TD FUSE/ BREAKER A
POWER AND COMMUNICATION CABLE No.x AWG
15 20 30
1385 1880 4186
6.3 8.3 18.5
1638 2500 3459
7.2 11.1 16
20 30 35
4 x 14AWG 4 x 14AWG 4 x 14AWG
REFRIGERATION SYSTEM
REFRIGERANT
COMPRESSOR TYPE
CONNECTIONS
LIQUID LINE O.D. in
SUCTION LINE O.D. in
REFRIGERANT CHARGE oz.
FACTORY PRECHARGE ft.
MIN. / MAX. LINE LENGTH ft
MAX. HEIGHT DIFFERENCE ft
R410a R410a R410a
Rotary Rotary Rotary
Flare Flare Flare
1
/
4
1
/
2
54.7 66.3 81.2
25 25 25
9.8-66 9.8-66 9.8-66
33 33 33
DIMENSIONS & WEIGHT
INDOOR UNIT
W x H x D in
NET WEIGHT lbs
SHIPPING WEIGHT lbs
45 1/8 x 13 1/8 x 10 50 5/8 X 13 5/8 X 10 1/4
33 33 40
38.5 38.5 48
OUTDOOR UNIT
W x H x D in
NET WEIGHT lbs
SHIPPING WEIGHT lbs
TOTAL NET WEIGHT lbs
TOTAL SHIPPING WEIGHT lbs
33 7/8 x 25 1/2 x 12 1/8 34 7/8 x 31 1/4 x 14 3/8 34 7/8 x 31 1/4 x 14 3/8
99 123.5 141
108 141 152
132 156.5 181
146.5 179.5 200
FPHW243
FPHW243A
FPHFW24A3A
FPHFW24A3B
Wi-Fi
3
/
5
/
Wi-Fi
8
8
FPHW363
FPHW363A
FPHSW36A3A
FPHSW36A3B
3.05
Wi-Fi
—
3
/
3
/
Wi-Fi
8
4
Your operating costs will depend on your utility rates and use. The estimated operating cost is based on a electricity cost of $ .12 per kWh.
For more information, visit www.ftc.gov/energy.
Due to continuing research in new energy-saving technology,
specications are subject to change without notice.
13
PRO SERIES | DUCTLESS SPLIT SYSTEMS
PRECISION
SINGLE ZONE • CEILING CASSETTE HEAT PUMPS
Compact cassette units install in a drop ceiling and mount flush
to the ceiling for a clean look and efficient installation.
Features for comfort and convenience
Wi-Fi available on select models
for control anytime, anywhere
• Create customizable, 7-day
schedules
• 24-hour on/off timer
• Precision Inverter
®
technology
(variable speed compressor)
• Soft start compressor
• Natural air flow
• 4-way cooling
• Surge Cool/Heat
• Cooling/Heating/Fan mode
• Dry mode
• Sleep mode
• Independent vane control
• 3 fan speeds
• Ultra-quiet turbo fan
• Evaporator frost control
• Auto restart
• Auto changeover
• DiamonGold Advanced
Corrosion Protection
• Clean, modern look
• Flexible installation
• ENERGY STAR
®
qualified models
• Precise air distribution
Operates in extreme
conditions
• Built-in low ambient, down to
5°F on 9k/12k/18k models, down
to -4°F on 24k/36k models
(Cooling mode)
• Low ambient operation down to
-4°F (Heating mode)
™
• Easy to use FriedrichGo™ app
• Control with smartphone
• Compatible with Amazon Alexa
and Google Home
WIRELESS REMOTE
WITH THE ABILITY
TO CHANGE TO A
COOL-ONLY REMOTE
14 | FLOATING AIR® SERIES DUCTLESS
NOTE: Cassette grilles
are sold separately.
PARTS
COMPRESSOR
WARRANTY
WARRANTY
PRO SERIES SPECIFICATIONS
PERFORMANCE RATINGS
SYSTEM MODEL NO.
INDOOR MODEL
OUTDOOR MODEL FPHFR09A3A FPHFR12A3A FPHFR18A3A FPHFR24A3A FPHFR36A3A
FPHC093
FPHC093A
FPHFC09A3A
FPHFC09A3B
Wi-Fi
Wi-Fi
FPHC123
FPHC123A
FPHFC12A3A
FPHFC12A3B
Wi-Fi
Wi-Fi
Single Zone Cassette - Heat Pumps
FPHC183
FPHC183A
FPHFC18A3A
FPHFC18A3B
Wi-Fi
Wi-Fi
FPHC243
FPHC243A
FPHFC24A3A
FPHFC24A3B
Wi-Fi
Wi-Fi
FPHC363A
FPHSC36A3B
Wi-Fi
Wi-Fi
SPECIFICATIONS
CAPACITY COOLING (RATED) Btu 9000 12000 18000 24000 36000
CAPACITY COOLING (MIN~MAX) Btu 4850-11600 5800-13100 8000-19200 8600-25200 12600-36800
CAPACITY HEATING @47
CAPACITY HEATING @170 F (RATED) Btu 5120 6800 7500 19600 27300
CAPACITY HEATING (MIN~MAX) Btu 4340-12280 6000-14400 7000-21200 7600-28400 15000-42600
SENSIBLE HEAT RATIO 76% 77% 76% 76% 79%
COP (@47°F) . 4.00 3.80 3.90 3.61 3.31
HSPF 10.00 10.00 10.00 10.00 10.50
SEER 18 19 19 19 19.5
EER 12.5 12.5 12.7 12.5 10.6
ENERGY STAR * YES YES YES YES —
MOISTURE REMOVAL Pts/h 2 3 5 5.1 7.61
AIRFLOW (LOW, MED, HIGH ) CFM 235/285/309 235/294/353 380/457/588 400/530/647 676/794/941
SOUND RATING - INDOOR H/M/L dB(A) 40/33/28 35/32/29 38/35/33 43/39/36 49/43/39
SOUND RATING - OUTDOOR dB(A) 52 54 68 54 61
OPERATING RANGE (COOLING) °FDB 5-118 5-118 5-118 -4-118 -4-118
OPERATING RANGE (HEATING) °FWB -4-75 -4-75 -4-75 -4-75 -4-75
EST. YEARLY OPERATING COST $ 53 72 124 169 376
0
F (RATED) Btu 9000 12000 11942 24000 42600
ELECTRICAL DATA
POWER SOURCE V 230/208-60-1 230/208-60-1 230/208-60-1 230/208-60-1 230/208-60-1
MINIMUM AMPACITY A 23 23 23 23 27
COOLING WATTS W 720 960 1420 1920 3380
COOLING AMPS 3.6 4.3 6.3 8.6 14.6
HEATING AMPS 3.5 4.1 6.5 8.7 14.0
MAX. TD FUSE/BREAKER A 20 30 30 30 50
POWER AND COMMUNICATION CABLE No. x AWG 4 x 14AWG 4 x 14AWG 4 x 14AWG 4 x 14AWG 4 x 14AWG
REFRIGERATION SYSTEM
REFRIGERANT R410a R410a R410a R410a R410a
COMPRESSOR TYPE Rotary Rotary Rotary Rotary Rotary
CONNECTIONS Flare Flare Flare Flare Flare
LIQUID LINE O.D. in 1/4 1/4 1/4 3/8 3/8
SUCTION LINE O.D. in 3/8 3/8 1/2 5/8 3/4
FACTORY PRECHARGE ft 25 25 25 25 25
REFRIGERANT CHARGE oz 33.5 45.9 56.5 75 111
MIN./MAX. LINE LENGTH ft 25 25 25 25 25
MAX. HEIGHT DIFFERENCE ft 82 82 82 164 164
DIMENSIONS & WEIGHT
INDOOR UNIT
W X H X D in
NET WEIGHT lbs
SHIPPING WEIGHT lbs
INDOOR UNIT GRILLE** W X H X D in
INDOOR UNIT GRILLE** NET WEIGHT lbs
INDOOR GRILLE PART NUMBER
OUTDOOR UNIT
W X H X D in
NET WEIGHT lbs
SHIPPING WEIGHT lbs
TOTAL NET WEIGHT lbs
TOTAL SHIPPING WEIGHT lbs
22 1/2 x 8 1/2 x 22 1/2 22 1/2 x 8 1/2 x 22 1/2 33 x 14 1/2 x 33 33 x 14 1/2 x 33 33 x 16 1/2 x 33
32 33 56 59.5 70.5
38.5 39.7 73.9 79.5 90.4
24-1/2 x 24-1/2 x 10 24-1/2 x 24-1/2 x 10 35-7/8 x 35-7/8 x 13 1/2 35-7/8 x 35-7/8 x 13 1/2 35-7/8 x 35-7/8 x 13 1/2
13.2 13.2 22.0 22.0 22.0
FPCG0912 FPCG182436
37 x 25 x 16 1/2 37 x 25 x 16 1/2 39 x 17 3/4 x 28 3/4 43 x 36 1/4 x 18 1/8 43 x 36 1/4 x 18 1/8
75 75 108 155 192
85 82 117 166 215
107 108 164 214.5 262.5
123.5 121 191 245.5 305.4
Your operating costs will depend on your utility rates and use. The estimated operating cost is based on a electricity cost of $ .12 per kWh. For more information, visit
www.ftc.gov/energy. *System meets ENERGY STAR® published minimums. **Models require grille. Sold separately.
Due to continuing research in new energy-saving technology, specications
are subject to change without notice.
15
PRO SERIES | DUCTLESS SPLIT SYSTEMS
SINGLE ZONE • THE INSIDER® CONCEALED DUCTED HEAT PUMPS
Indoor unit is installed in the ceiling or furr down, totally concealed,
for unobtrusive installation.
Features
• Precision Inverter® technology
(variable speed compressor)
• Soft start compressor
• BLDC motor
• Cooling/Heating/Fan mode
• Dry mode
• 3 fan speeds
• Auto restart
• Auto changeover
• DiamonGold Advanced Corrosion
Protection™
• Control lock function on controller
• External Static Pressure Range
0-.40
Operates in extreme conditions
• Built-in low ambient, down to
5°F on 9k/12k/18k models, down
to -4°F on 24k/36k models
(Cooling mode)
• Low ambient operation down to
-4°F (Heating mode)
PRECISION
PARTS
WARRANTY
COMPRESSOR
WARRANTY
16 | FLOATING AIR® SERIES DUCTLESS
PRO SERIES SPECIFICATIONS
PERFORMANCE RATINGS Single Zone - The Insider
SYSTEM MODEL NO.
INDOOR MODEL
OUTDOOR MODEL
SPECIFICATIONS
CAPACITY COOLING (RATED) Btu
CAPACITY COOLING (MIN~MAX) Btu
CAPACITY HEATING @470F (RATED) Btu
CAPACITY HEATING @170F (RATED) Btu
CAPACITY HEATING (MIN~MAX) Btu
SENSIBLE HEAT RATIO
SEER
EER
COP (@47°F) .
HSPF
ENERGY STAR
MOISTURE REMOVAL Pts/h
AIRFLOW (LOW, MED, HIGH ) CFM
SOUND RATING - INDOOR H/M/L dB(A)
SOUND RATING - OUTDOOR dB(A)
OPERATING RANGE (COOLING) °F
OPERATING RANGE (HEATING) °F
EST. YEARLY OPERATING COST $
ELECTRICAL DATA
POWER SOURCE
MINIMUM AMPACITY A
COOLING WATTS W
COOLING AMPS
HEATING AMPS
MAX. TD FUSE/BREAKER A
POWER AND COMMUNICATION CABLE No. x AWG
REFRIGERATION SYSTEM
REFRIGERANT
COMPRESSOR TYPE
CONNECTIONS
LIQUID LINE O.D. in
SUCTION LINE O.D. in
FACTORY PRECHARGE ft
REFRIGERANT CHARGE oz
MIN./MAX. LINE LENGTH ft
MAX. HEIGHT DIFFERENCE ft
DIMENSIONS & WEIGHT
INDOOR UNIT
W X H X D in
NET WEIGHT lbs
SHIPPING WEIGHT lbs
OUTDOOR UNIT
W X H X D in
NET WEIGHT lbs
SHIPPING WEIGHT lbs
TOTAL NET WEIGHT lbs
TOTAL SHIPPING WEIGHT lbs
FPHD093 FPHD123 FPHD183 FPHD243 FPHD363
FPHFD09A3A FPHFD12A3A FPHFD18A3A FPHFD24A3A FPHSD36A3A
FPHFR09A3A FPHFR12A3A FPHFR18A3A FPHFR24A3A FPHFR36A3A
9000 12000 18000 24000 36000
4850-11600 5800-13100 8000-19200 8600-25200 12600-36800
9000 12000 18000 24000 36000
6200 8200 14700 19600 22000
4340-12280 6000-14400 7000-21200 7600-28400 15000-42600
76% 76% 76% 76% 76%
17 19 19 18 18
12 11 12.2 12.5 10.9
3.2 3.2 3.4 3.6 3
10.00 10.00 10.00 10.00 9.50
— — — — —
2 3 5 5.1 7.61
235/285/309 235/285/338 370/440/529 501/574/647 618/735/853
29/27/26 36/33/30 38/35/33 38/36/34 49/43/39
52 54 68 54 61
5-118 5-118 5-118 -4-118 -4-118
-4-75 -4-75 -4-75 -4-75 -4-75
53 72 124 169 376
230/208-60-1 230/208-60-1 230/208-60-1 230/208-60-1 230/208-60-1
23.0 23.0 23.0 23.0 4.6
750 1091 1610 2200 3300
3.7 4.8 7.0 8.6 14.4
4.1 4.8 7.3 8.7 15.2
20 30 30 30 50
4 x 14AWG 4 x 14AWG 4 x 14AWG 4 x 14AWG 4 x 14AWG
R410a R410a R410a R410a R410a
Rotary Rotary Rotary Rotary Rotary
Flare Flare Flare Flare Flare
1/4 1/4 1/4 3/8 3/8
3/8 3/8 1/2 5/8 3/4
25 25 25 25 25
33.5 45.9 56.5 75.3 111
25 25 25 25 25
82 82 82 164 164
42 1/2 x 11 1/4 x 22 1/4 42-1/2 x 22-1/4 x 11-1/4 53 x 22 1/4 x 11 46 x 34 1/4 x 13 3/8 61 x 16-1/8 x 37
39.7 39.7 49.6 70.5 112.5
46.3 47.4 56.2 81.6 132.4
37 x 25 x 16 1/2 37 x 25 x 16 1/2 39 x 17 3/4 x 28 3/4 43 x 36 1/4 x 18 1/8 43 x 36 1/4 x 18 1/8
75 75 108 155 192
85 82 117 166 215
107 108 108 214.5 262.5
123.5 121 158 245.5 305.4
™
Concealed Ducted Heat Pumps
Your operating costs will depend on your utility rates and use. The estimated operating cost is based on a electricity cost of $ .12 per kWh.
For more information, visit w ww.ftc.gov/energy.
Due to continuing research in new energy-saving technology, specications are subject to change without notice.
17
PRO SERIES
| DUCTLESS SPLIT SYSTEMS
Friedrich multizone systems utilize wall-mounted, ceiling cassette
and concealed ducted models in up to 4 zones
MULTIZONE SYSTEMS PROVIDE TOTAL INSTALLATION FLEXIBILITY.
Zone cooling and heating
provides unmatched
customized comfort and
energy savings
Occupants have the ability to
set the temperature of each
zone to their preferred
comfort level*, or turn off
units in unoccupied rooms
without affecting other zones.
That’s the beauty and
efficiency of a Friedrich
Ductless Multizone System.
MULTIZONE CONFIGURATION, AHRI RATINGS
Friedrich
Model
FPHMR18A3A
FPHMR24A3A
FPHMR36A3A
AHRI
Reference
Number IndoorType
Pending
Pending
Pending
204101246
204005731
203999079
204101247
203996910
203999080
Non-ducted Indoor Units
Ducted Indoor Units
Mixed Ducted and Non-ducted
Indoor Units
Non-ducted Indoor Units
Ducted Indoor Units
Mixed Ducted and Non-ducted
Indoor Units
Non-ducted Indoor Units
Ducted Indoor Units
Mixed Ducted and Non-ducted
Indoor Units
System
Capacity EER SEER
18000 12.50 22.00 18000 11.00 20000
18000 12.10 21.00 18000 10.00 20000
18000 12.30 21.50 18000 10.50 20000
24000 12.50 22.00 24000 11.00 15400
24000 12.10 21.00 24000 10.00 15400
24000 12.30 21.50 24000 10.50 15400
32000 12.50 21.0 36000 11.00 23200
32000 12.00 19.50 36000 10.80 22600
32000 12.25 20.25 36000 10.90 22600
High Heat
47 °F HSPF
Low Heat
17°F
18 | FLOATING AIR® SERIES DUCTLESS
MULTIZONE CONFIGURATION GUIDELINES
Select a combination of indoor units that does not exceed the maximum connected capacity,
and is within the recommended parameters:
CEILING CASSETTE WALL-MOUNTED THE INSIDER
9,000 18,000 7,000 18,000 9,000 18,000
12,000 24,000 9,000 24,000 12,000 24,000
12,000
FPHMR18A3A
24,000 Btu MAX.
CONNECTED
CAPACITY
DUAL-ZONE ONLY
FOR (2) ZONES:
MINIMUM combination must be 50% of
nameplate capacity
Combinations SHOULD NOT:
Exceed the maximum allowable total
indoor unit connected capacity of
24,000 Btu.
WORKSHEET EXAMPLE
FPHMR24A3A
33,000 Btu MAX.
CONNECTED
CAPACITY
TRI-ZONE MAX.
FOR (2) ZONES:
MINIMUM combination must be 50% of
nameplate capacity
FOR (3) ZONES:
Select any combination of (3) indoor units.
Combinations SHOULD NOT:
Exceed the maximum allowable total
indoor unit connected capacity of
33,000 Btu.
FPHMR36A3A
48,000 Btu MAX.
CONNECTED
CAPACITY
FOR (2) ZONES:
MINIMUM combination must be 50% of
nameplate capacity
FOR (3) ZONES:
Select any combination of (3) indoor units
with no more than (2) 18,000 Btu indoor
units plus (1) other indoor unit.
FOR (4) ZONES:
Select any combination of (4) indoor units.
Combinations SHOULD NOT:
Exceed the maximum allowable total
indoor unit connected capacity of
48,000 Btu.
MAX.
CONDENSER
CAPACITY
NAMEPLATE
CAPACITY
24,000 12,000
33,000 17,500
48,000 24,000
50% OF
ZONE 1
Unit Btu
ZONE 2
Unit Btu
ZONE 3
Unit Btu
ZONE 4
Unit Btu
DUAL ZONE ONLY
TRI-ZONE MAX.
19
PRO SERIES | DUCTLESS SPLIT SYSTEMS
PRECISION
MULTIZONE HEAT PUMP SYSTEMS
The contractor’s line with extensive features to make installation
and service faster and easier. Exceptional efficiency and dependable
performance.
Features for comfort and
convenience
• Create customizable, 7-day
schedules
®
technology
®
qualified model
Wi-Fi available on select models
for control anytime, anywhere
• Easy to use FriedrichGo™ app
• Control with smartphone
• Compatible with Amazon Alexa
and Google Home
WIRELESS REMOTE
WITH THE ABILITY
TO CHANGE TO A
COOL-ONLY REMOTE
• Precision Inverter
(variable speed compressor)
• Fast Pro
®
design for the fastest
access for maintenance of any
wall-mounted ductless system
• Soft start compressor
• BLDC motor
• Auto Clean indoor coil
• Cooling/Heating/Fan/Auto mode
• Surge Cool/Heat
• Natural air flow
• Ultra quiet operation
• Sleep mode
• Auto restart
• Auto changeover
• 24-hour on/off timer
• ENERGY STAR
• Hidden display (only visible during
operation)
FPHMR18A3A , FPHMR24A3A
20 | FLOATING AIR® SERIES DUCTLESS
FPHMR36A3A
Operates in extreme conditions
• Low ambient operation down to
14°F (Cooling mode)
• Low ambient operation down to
-13°F (Heating mode)
• Low temperature compressor
start-up protection
PARTS
COMPRESSOR
WARRANTY
WARRANTY
PRO SERIES SPECIFICATIONS
PERFORMANCE RATINGS Multizone Wall-Mounted - Heat Pumps
7k 9k 12k 18k 24k
INDOOR MODEL
FPHMW07A3A
FPHMW07A3B
Wi-Fi
FPHFW09A3A
FPHFW09A3B
SPECIFICATIONS
CAPACITY COOLING (RATED)
CAPACITY HEATING (RATED)
MOISTURE REMOVAL
AIRFLOW
SOUND RATING (HIGH/MED/LOW)
Btu 7000 9000 12000 18000 24000
Btu 8500 9500 13000 19000 24200
Pts/h 2.5 2.5 3.2 4.2 5.3
CFM 424/382/323/247 424/382/323/247 424/382/323/247 618/565/482/382 735/665/559/441
dB-A 38/32/29 38/32/29 39/32/29 45/41/37 48/45/40
ELECTRICAL DATA
POWER SOURCE
V-Hz-Phase
230/208~60-1 230/208~60-1 230/208~60-1 230/208~60-1 230/208~60-1
REFRIGERATION SYSTEM
CONNECTIONS
LIQUID LINE O.D.
SUCTION LINE O.D.
in
in
Flare Flare Flare Flare Flare
1
/
4
3
/
8
1
/
4
3
/
8
DIMENSIONS & WEIGHT
W x H x D
NET WEIGHT
SHIPPING WEIGHT
lbs
lbs
in
37 3/8"x 10 3/4"x 8 1/8" 48"x 12 5/8"x 9 1/4"
18.7 18.7 18.7 32 32
24.3 24.3 24.3 37.5 37.5
PERFORMANCE RATINGS Multi Outdoor
18k
OUTDOOR MODEL
FPHMR18A3A
SPECIFICATIONS
POWER SOURCE
EST. YEARLY OPERATING COST
RUNNING CURRENT COOLING RATED
RUNNING CURRENT HEATING RATED
POWER INPUT COOLING MIN. – RATED – MAX.
POWER INPUT HEATING MIN. – RATED – MAX.
POWER AND COMMUNICATION CABLE
DIMENSIONS W x H x D
NET WEIGHT
SHIPPING WEIGHT
$ $90 $172 $259
A
A
W 1440 (510~2610) 1920 (420~2640)
W 1530 (450~3510) 1920 (420~4020)
No. x AWG
in
lbs 108 159 186
lbs 119 170 216
208~230/60/1 208~230/60/1 208~230/60/1
6.5
7.3
4 x 14AWG 4 x 14AWG 4 x 14AWG
33 7/8 x 26 3/8 x 12 1/4 37 3/8 x 33 x 13 3/8
REFRIGERATION SYSTEM
REFRIGERANT
FACTORY PRECHARGE
LIQUID LINE O.D.
SUCTION LINE O.D.
MIN./MAX. LINE LENGTH (EACH)
MIN./MAX. LINE LENGTH (TOTAL)
MAX. HEIGHT DIFFERENCE
SOUND PRESSURE LEVEL COOLING
SOUND PRESSURE LEVEL HEATING
OPERATING RANGE COOLING
OPERATING RANGE HEATING
MINIMUM AMPACITY
MAX. TD FUSE/ BREAKER
oz
in
in
ft
ft
ft
A
A
°F DB
°F WB -13~75 -13~75 -13~75
A
A
R410A R410A R410A
63 81.13 105.82
1
/4
3
/8
82
164
49
55
55
14~115
30A
45A
Wi-Fi
FPHFW12A3A
FPHFW12A3B
Wi-Fi
1
/
4
3
/
8
FPHFW18A3A
FPHFW18A3B
24k 36k
FPHMR24A3A FPHMR36A3A
8.7 11
8.7 13
1
/4
3
/8
66 66
197 197
49 49
59 59
59 59
14~115 14~115
30A 30A
45A 45A
FPHFW24A3A
Wi-Fi
FPHFW24A3B
1
/
4
1
/
2
Wi-Fi
3
/
8
5
/
8
48"x 12 5/8"x 9 1/4"
2520 (700~5000)
3060 (600~6000)
3
37
/8 x 41 3/8 x 13 3/8
1
/4
3
/8
Your operating costs will depend on your utility rates and use. The estimated operating cost is based on a electricity cost of $ .12 per kWh.
For more information, visit w ww.ftc.gov/energy.
Due to continuing research in new energy-saving technology, specications are subject to change without notice.
21
PRO SERIES | DUCTLESS SPLIT SYSTEMS
PRECISION
MULTI ZONE • CEILING CASSETTE HEAT PUMPS
Compact cassette units install in a drop ceiling and mount flush
to the ceiling for a clean look and efficient installation.
Features for comfort and convenience
Wi-Fi available on select models
for control anytime, anywhere
• Easy to use FriedrichGo™ app
• Control with smartphone
• Compatible with Amazon Alexa
and Google Home
• Create customizable, 7-day
schedules
• 24-hour on/off timer
• Precision Inverter
®
technology
(variable speed compressor)
• Soft start compressor
• Natural air flow
• 4-way cooling
• Surge Cool/Heat
• Cooling/Heating/Fan mode
• Dry mode
• Sleep mode
• Independent vane control
• 3 fan speeds
• Ultra-quiet turbo fan
• Evaporator frost control
• Auto restart
• Auto changeover
• DiamonBlue Advanced
Corrosion Protection
• Clean, modern look
• Flexible installation
• ENERGY STAR
®
qualified models
• Precise air distribution
Operates in extreme
conditions
• Built-in low ambient standard,
down to 14°F (Cooling mode)
• Low ambient operation down to
-13°F (Heating mode)
• Low temperature compressor
start-up protection
®
FPHMR18A3A , FPHMR24A3A
22 | FLOATING AIR® SERIES DUCTLESS
FPHMR36A3A
NOTE: Cassette grilles
are sold separately.
PARTS
COMPRESSOR
WARRANTY
WARRANTY
PRO SERIES SPECIFICATIONS
PERFORMANCE RATINGS Multizone Cassette - Heat Pumps
9k 12k 18k 24k
INDOOR MODEL
FPHFC09A3A
FPHFC09A3B Wi-Fi
SPECIFICATIONS
CAPACITY COOLING (RATED) Btu 9000 12000 18000 24000
CAPACITY HEATING (RATED) Btu 10200 13500 20400 27000
MOISTURE REMOVAL Pts/h 1.9 2.5 3.2 5.0
AIRFLOW (HIGH) CFM 306 471 559 1100
SOUND RATING (MAX.-MIN.) dB-A 40/28 40/28 40/28 40/28
ELECTRICAL DATA
POWER SOURCE V-Hz-Phase 230/208-60-1 230/208-60-1 230/208-60-1 230/208-60-1
POWER AND COMMUNICATION CABLE No. x AWG 4 x 14AWG 4 x 14AWG 4 x 14AWG 4 x 14AWG
REFRIGERATION SYSTEM
CONNECTIONS Flare Flare Flare Flare
LIQUID LINE O.D. in
SUCTION LINE O.D. in
1
/4
3
/8
DIMENSIONS & WEIGHT
W X H X D in 22 1/2 x 8 1/2 x 22 33 x 9 3/4 x 33
NET WEIGHT lbs 31.9 34 61.8 59.5
SHIPPING WEIGHT lbs 38.5 40.7 81.6 79.5
PACKAGE DIMENSIONS W X H X D in 28
FPHFC12A3A
FPHFC12A3B Wi-Fi
1
/4
3
/8
3
/4 x 11 1/2 x 26 39 1/4 x 37 x 14 39 1/4 x 37 x 14 1/2
FPHFC18A3A
FPHFC18A3B Wi-Fi
1
/4
1
/2
FPHFC24A3A
FPHFC24A3B Wi-Fi
3
/8
5
/8
PERFORMANCE RATINGS Multi Outdoor
24k 36k
FPHMR24A3A FPHMR36A3A
OUTDOOR MODEL
18k
FPHMR18A3A
SPECIFICATIONS
POWER SOURCE
EST. YEARLY OPERATING COST
RUNNING CURRENT COOLING RATED
RUNNING CURRENT HEATING RATED
POWER INPUT COOLING MIN. – RATED – MAX.
POWER INPUT HEATING MIN. – RATED – MAX.
POWER AND COMMUNICATION CABLE
DIMENSIONS W x H x D
NET WEIGHT
SHIPPING WEIGHT
$ $90 $172 $259
A
A
W 1440 (510~2610) 1920 (420~2640)
W 1530 (450~3510) 1920 (420~4020)
No. x AWG
in
lbs 108 159 186
lbs 119 170 216
208~230/60/1 208~230/60/1 208~230/60/1
6.5
7.3
8.7 11
8.7 13
4 x 14AWG 4 x 14AWG 4 x 14AWG
33 7/8 x 26 3/8 x 12 1/4 37 3/8 x 33 x 13 3/8
REFRIGERATION SYSTEM
REFRIGERANT
FACTORY PRECHARGE
LIQUID LINE O.D.
SUCTION LINE O.D.
MIN./MAX. LINE LENGTH (EACH)
MIN./MAX. LINE LENGTH (TOTAL)
MAX. HEIGHT DIFFERENCE
SOUND PRESSURE LEVEL COOLING
SOUND PRESSURE LEVEL HEATING
OPERATING RANGE COOLING
OPERATING RANGE HEATING
MINIMUM AMPACITY
MAX. TD FUSE/ BREAKER
oz
in
in
ft
ft
ft
A
A
°F DB
°F WB -13~75 -13~75 -13~75
A
A
R410A R410A R410A
63 81.13 105.82
1
/4
3
/8
82
164
49
55
55
14~115
30A
45A
1
/4
3
/8
66 66
197 197
49 49
59 59
59 59
14~115 14~115
30A 30A
45A 45A
2520 (700~5000)
3060 (600~6000)
3
37
/8 x 41 3/8 x 13 3/8
1
/4
3
/8
Your operating costs will depend on your utility rates and use. The estimated operating cost is based on a electricity cost of $ .12 per kWh.
For more information, visit w ww.ftc.gov/energy.
Models require grille. Sold separately.
Due to continuing research in new energy-saving technology, specications are subject to change without notice.
23
PRO SERIES | DUCTLESS SPLIT SYSTEMS
MULTI ZONE • THE INSIDER® CONCEALED DUCTED HEAT PUMPS
Indoor unit installs in the ceiling or furr down for unobtrusive installation.
Conditioned or non-conditioned air can be added to ducting to allow
fresh air into the conditioned space whenever required.
Features
• Precision Inverter® technology
(variable speed compressor)
• Soft start compressor
• BLDC motor
• Cooling/Heating/Fan mode
• Dry mode
• 3 fan speeds
• Auto restart
• Auto changeover
• DiamonBlue Advanced Corrosion
Protection
• Control lock function on controller
• External Static Pressure Range
(ESP)
- 9K/12K/18K (0 – .40) WC
- 24K (0 – .40) WC
®
FPHMR18A3A , FPHMR24A3A
FPHMR36A3A
Operates in extreme conditions
• Built-in low ambient standard,
down to 14°F (Cooling mode)
• Low ambient operation down to
-13°F (Heating mode)
• Low temperature compressor
start-up protection
PRECISION
PARTS
WARRANTY
COMPRESSOR
WARRANTY
24 | FLOATING AIR® SERIES DUCTLESS
PRO SERIES SPECIFICATIONS
PERFORMANCE RATINGS Multizone - The Insider™ Concealed Ducted Heat Pumps
9k 12k 18k 24k
INDOOR MODEL FPHFD09A3A FPHFD12A3A FPHFD18A3A FPHFD24A3A
SPECIFICATIONS
CAPACITY COOLING (RATED) Btu 9000 12000 18000 24000
CAPACITY HEATING (RATED) Btu 10000 12500 19000 24000
MOISTURE REMOVAL Pts/h 1.9 3.2 3.2 5.1
AIRFLOW CFM 235/285/309 235/285/338 370/440/529 501/574/647
SOUND RATING (MAX.-MIN.) dB-A 29/27/26 36/33/30 38/35/33 38/36/34
ELECTRICAL DATA
POWER SOURCE V-Hz-Phase 230/208-60-1 230/208-60-1 230/208-60-1 230/208-60-1
POWER AND COMMUNICATION CABLE No. x AWG 4 x 14AWG 4 x 14AWG 4 x 14AWG 4 x 14AWG
REFRIGERATION SYSTEM
CONNECTIONS Flare Flare Flare Flare
LIQUID LINE O.D. in 1/4 1/4 1/4 3/8
SUCTION LINE O.D. in 3/8 3/8 1/2 5/8
DIMENSIONS & WEIGHT
W X H X D in
35 7/8 x 7 1/2 x 17
NET WEIGHT lbs 45.2 45.2 66.2 70.5
SHIPPING WEIGHT lbs 51.8 51.8 77.2 81.6
46 1/2 x 7 1/2 x 17 1/2 46 x 34 1/4 x 13 1/4
PERFORMANCE RATINGS Multi Outdoor
24k 36k
FPHMR24A3A FPHMR36A3A
OUTDOOR MODEL
18k
FPHMR18A3A
SPECIFICATIONS
POWER SOURCE
EST. YEARLY OPERATING COST
RUNNING CURRENT COOLING RATED
RUNNING CURRENT HEATING RATED
POWER INPUT COOLING MIN. – RATED – MAX.
POWER INPUT HEATING MIN. – RATED – MAX.
POWER AND COMMUNICATION CABLE
DIMENSIONS W x H x D
NET WEIGHT
SHIPPING WEIGHT
$ $90 $172 $259
A
A
W 1440 (510~2610) 1920 (420~2640)
W 1530 (450~3510) 1920 (420~4020)
No. x AWG
in
lbs 108 159 186
lbs 119 170 216
208~230/60/1 208~230/60/1 208~230/60/1
6.5
7.3
4 x 14AWG 4 x 14AWG 4 x 14AWG
33 7/8 x 26 3/8 x 12 1/4 37 3/8 x 33 x 13 3/8
8.7 11
8.7 13
REFRIGERATION SYSTEM
REFRIGERANT
FACTORY PRECHARGE
LIQUID LINE O.D.
SUCTION LINE O.D.
MIN./MAX. LINE LENGTH (EACH)
MIN./MAX. LINE LENGTH (TOTAL)
MAX. HEIGHT DIFFERENCE
SOUND PRESSURE LEVEL COOLING
SOUND PRESSURE LEVEL HEATING
OPERATING RANGE COOLING
OPERATING RANGE HEATING
MINIMUM AMPACITY
MAX. TD FUSE/ BREAKER
oz
in
in
ft
ft
ft
A
A
°F DB
°F WB -13~75 -13~75 -13~75
A
A
R410A R410A R410A
63 81.13 105.82
1
/4
3
/8
82
164
49
55
55
14~115
30A
45A
1
/4
3
/8
66 66
197 197
49 49
59 59
59 59
14~115 14~115
30A 30A
45A 45A
2520 (700~5000)
3060 (600~6000)
3
37
/8 x 41 3/8 x 13 3/8
1
/4
3
/8
Your operating costs will depend on your utility rates and use. The estimated operating cost is based on a electricity cost of $ .12 per kWh.
For more information, visit w ww.ftc.gov/energy.
Due to continuing research in new energy-saving technology, specications are subject to change without notice.
25
SELECT SERIES | DUCTLESS SPLIT SYSTEMS
SINGLE ZONE • WALL-MOUNTED HEAT PUMPS
Superb performance and excellent value, you get both at
exceptional pricing.
Features
• Inverter technology is more energy
efficient and can self-adjust
capacity to match cooling needs
• Multiple operating modes
115 VOLT MODELS
FSHSW09A1A, FSHSW12A1A
230/208 VOLT MODELS
WIRELESS
REMOTE CONTROL
FSHSW18A3A, FSHSW24A3A
FSHSW36A3A
including: auto, cool, dry, fan only
and heat
• TURBO mode operates the unit at
maximum performance to quickly
bring the room to set temperature
• 4 fan speeds heating or cooling:
high, medium, low, “quiet”, plus
auto-fan
• Continuous ‘Air Sweep’ up & down
• LCD remote
• 24-hour timer and sleep timer
• Indoor unit will briefly display set
or room temperature
• Auto-restart after power
interruptions
• Auto-shut flaps close when unit is
off for a sleek appearance
• Washable antimicrobial air filters
• 115V/230V models will provide
cooling in outdoor temperatures
down to 0°F
26 | FLOATING AIR® SERIES DUCTLESS
OPTIONAL ACCESSORY
FOR FLOATING AIR®
SELECT MODELS
DFAC C
LCD remote for cooling only
operation of all Floating Air
Select heat pump models.
SELECT SERIES SPECIFICATIONS
PERFORMANCE RATINGS 115 volt models 230/208 volt models
SYSTEM MODEL NO.
INDOOR MODEL
OUTDOOR MODEL
SPECIFICATIONS
CAPACITY COOLING (RATED) Btu
CAPACITY COOLING MIN - MAX Btu
CAPACITY HEATING (RATED) @ 47°F Btu
CAPACITY HEATING (RATED) @ 17°F Btu
CAPACITY HEATING MIN - MAX Btu
SENSIBLE HEAT RATIO
HSPF
SEER
EER
MOISTURE REMOVAL Pts/h
AIRFLOW (HIGH/MED/LOW/QUIET) CFM
SOUND RATING - INDOOR (HIGH/MED/LOW/QUIET) dB-A
SOUND RATING - OUTDOOR dB-A
OPERATING RANGE (HEATING) °F
OPERATING RANGE (COOLING) °F
EST. YEARLY OPERATING COST U.S. $
ELECTRICAL DATA
POWER SOURCE V-Hz-Phase
MIN. AMPACITY A
COOLING WATTS W
COOLING AMPS
HEATING WATTS W
HEATING AMPS
MAX. TD FUSE/ BREAKER A
REFRIGERATION SYSTEM
REFRIGERANT
COMPRESSOR TYPE
CONNECTIONS
LIQUID LINE O.D. in
SUCTION LINE O.D. in
REFRIGERANT CHARGE oz.
FACTORY PRECHARGE ft
MIN. / MAX. LINE LENGTH ft
MAX. HEIGHT DIFFERENCE ft
DIMENSIONS & WEIGHT
INDOOR UNIT
W x H x D in
NET WEIGHT lbs
SHIPPING WEIGHT lbs
OUTDOOR UNIT
W x H x D in
NET WEIGHT lbs
SHIPPING WEIGHT lbs
TOTAL NET WEIGHT lbs
TOTAL SHIPPING WEIGHT lbs
FSHW091 FSHW121 FSHW183 FSHW243 FSHW363
FSHSW09A1A FSHSW12A1A FSHSW18A3A FSHSW24A3A FSHSW36A3A
FSHSR09A1A FSHSR12A1A FSHSR18A3A FSHSR24A3A FSHSR36A3A
9000 12000 18000 24000 36000
3753-9724 3753-12500 3412-20472 8600-24000 7404-35997
9500 13000 19800 24000 34600
6800 7100 12800 14600 20200
2081-12283 3412-05013 3412-21837 8600-26000 14979-35997
0.79 0.73 0.77 0.77 0.75
9.0 9.0 9.0 10.0 9.0
18.0 18.0 18.0 18.0 18.0
10.0 10.1 9.89 11.0 8.2
1.69 2.96 3.8 4.23 7.4
318/288/241/171 400/318/241/194 500/441/383/294 588/441/306/206 883/765/647/559
43/38/34/28 43/39/35/29 47/44/41/35 49/46/42/36 54/49/44/37
52 53 57 58 65
-4-75 -4-75 -13-75 -13-75 -4-75
0-115 0-115 0-115 0-115 0-115
$67 $113 $146 $198 $368
115-60-1 115-60-1
17 20 16 16 24
900 194 1820 2010 4100
10.87 13.0 8.1 17.0 10.87
870 1250 2090 2130 3800
10.36 13.5 8.5 9.45 16.5
25 30 25 25 40
R410A R410A R410A R410A R410A
Inverter Inverter Inverter Inverter Inverter
Flare Flare Flare Flare Flare
1/4" 1/4" 1/4" 1/4" 1/4"
3/8" 3/8" 1/2" 5/8" 5/8"
24.7 31.8 45.68 56.4 91.71
25 25 25 25 25
7/66 7/98 10/82 10/82 15/98
32.8 49.2 65.0 65.6 32.8
31 1/8 x 10 7/8 x 8 31 1/8 x 11 3/8 x 8 33 1/4 x 11 7/8 x 9 42 1/2 x 12 7/8 x 10 53 1/8 x 12 7/8 x 10
20.9 23.2 30.9 37.5 42.0
25.4 27.6 37.5 45.2 51.8
33 1/2 x 21 1/4 x 12 5/8 37 5/8 x 27 5/8 x 15 5/8
62.8 67.3 97.0 103.6 161
68.4 72.8 106.9 113.5 171.9
83.7 90.5 127.9 141.1 203
93.8 100.4 144.4 158.7 223.7
230/208-60-1 230/208-60-1 230/208-60-1
38 5/8 x 3 1 1/8 x 167/8
Due to continuing research in new energy-saving technology, specications are subject to change without notice.
27
ACCESSORIES
REFRIGERATION LINE SETS (REQUIRED)
OUTSIDE DIMENSIONS
Floating Air® Pro Wall-mounted
SYSTEM MODEL
FPHW091 / FPHW091A 1/4 3/8 T32150 T32350
FPHW121 / FPHW121A 1/4 3/8 T32150 T32350
FPHW093 / FPHW093A 1/4 3/8 T32150 T32350
FPHW123 / PFHW123A 1/4 3/8 T32150 T32350
FPHW183 / FPHW183A 1/4 1/2 T42150 T42350
FPHW243 / FPHW243A 3/8 5/8 T53150 T53350
FPHW363 / FPHW363A 3/8 3/4 T63150 T63350
Floating Air
FPHMR18A3A 1/4 3/8 T32150 T32350
FPHMR24A3A 1/4 3/8 T32150 T32350
FPHMR36A3A 1/4 3/8 T32150 T32350
Floating Air® Premier Wall-mounted
FRHW093 / FRHW093A 1/4 3/8 T32150 T32350
FRHW123 / FRHW123A 1/4 3/8 T32150 T32350
Floating Air
FSHW091 1/4 3/8 T32150 T32350
FSHW121 1/4 3/8 T32150 T32350
FSHW183 1/4 1/2 T42150 T42350
FSHW243 1/4 5/8 T52150 T52350
FSHW363 1/4 5/8 T52150 T52350
Floating Air
FPHC093 / FPHC093A 1/4 3/8 T32150 T32350
FPHC123 / FPHC123A 1/4 3/8 T32150 T32350
FPHC183 /FPHC183A 1/4 1/2 T42150 T42350
FPHC243 / FPHC243A 3/8 5/8 T53150 T53350
FPHC363A 3/8 3/4 T63150 T63350
Floating Air
FPHD093 1/4 3/8 T32150 T32350
FPHD123 1/4 3/8 T32150 T32350
FPHD183 1/4 1/2 T42150 T42350
FPHD243 3/8 5/8 T53150 T53350
FPHD363 3/8 3/4 T63150 T63350
®
Pro Multizone Outdoor
®
Select Wall-mounted
®
Pro Cassette Single Zone
®
Pro The Insider® Single Zone Concealed Ducted
Liquid Suction 15’ Lineset Kit 35’ Lineset Kit
REFRIGERATION LINE SETS
MIN./MAX. LENGTHS
Floating Air® Pro Wall-mounted
SYSTEM MODEL
FPHW091 / FPHW091A 10 50
FPHW121 / FPHW121A 10 50
FPHW093 / FPHW093A 10 50
FPHW123 / PFHW123A 10 50
FPHW183 / FPHW183A 10 66
FPHW243 / FPHW243A 10 66
FPHW363 / FPHW363A 10 66
Floating Air
FPHC093 / FPHC093A 25 82
FPHC123 / FPHC123A 25 82
FPHC183 /FPHC183A 25 82
FPHC243 / FPHC243A 25 164
FPHC363A 25 164
Floating Air
FPHD093 25 82
FPHD123 25 82
FPHD183 25 82
FPHD243 25 164
FPHD363 25 164
Floating Air
FPHMR18A3A 25 82/164
FPHMR24A3A 25 66/197
FPHMR36A3A 25 66/246
Floating Air
FRHW093 / FRHW093A 10 66
FRHW123 / FRHW123A 10 66
Floating Air
FSHW091 10 66
FSHW121 10 66
FSHW183 10 82
FSHW243 10 82
FSHW363 15 98
®
Pro Ceiling Cassette
®
Pro The Insider® Concealed Ducted
®
Pro Outdoor
®
Premier
®
Select
Min. (ft.) Max. Each/Total (ft.)
CEILING CASSETTE GRILLES WALL CONTROLLERS
(REQUIRED) (OPTIONAL)
Decorative Grille
FPCG0912 FPCG182436
Fits
FPHFC09A3A (B)
FPHFC12A3A (B)
Fits
FPHFC18A3A (B)
FPHFC24A3A (B)
FPHFC36A3B
FPWC1 FSWC1
FPWC1
Optional wired wall controller for Floating Air® Pro and Premier, single and multizone models.
FSWC1 Optional wired wall controller for Floating Air
®
Select single zone models.
TORQUE WRENCH SETTINGS
Outside Diameter Torque
mm inch ft-lbs. N·m
6.35
9.52
12.7
15.88
1
/4
13 – 18 17.6 – 24.5
3
/8
25 – 30 33.3 – 41.2
1
/2
40 – 47 53.9 – 64.7
5
/8
45 – 59 61.7 – 80.4
Many Friedrich ductless models qualify for rebates
Many utility companies offer rebates on ductless air conditioners. Contact your local energy provider for information on
ductless rebates or visit: http://www.dsireusa.org
Find a factory trained Friedrich ductless installer at www.friedrich.com
Friedrich Air Conditioning Co. l 10001 Reunion Place, Suite 500 l San Antonio, TX 78216 l 877.599.5665 l www.friedrich.com
BR_DSS_11-11-19 Printed in USA
Loading...
