SEC 2.0 Reference Device Driver User’s Guide

SEC2SWUG

1Overview

The SEC2 device driver manages the operation of the SEC 2.0 commonly instantiate d into PowerQUICC pro cessors. It is a fully functional c omponent, meant to ser ve as an example of a pplication interaction with the SEC2 core.

The driver is coded i n ANSI C. In it’s design, an attempt ha s been made to write a devic e driver that is as oper ating system agnostic as practical. Where necessary, ope rating syste m dependenci es are identifi e d a n d Section 8, “Por ting ” addresses them.

Testing has been accomplished on VxWorks 5.5 and LinuxPPC using kernel version 2.4. 27.

Application inter faces to this driver are implement ed through the

ioctl() function cal l. R equests made through this interface can

be broken down into specific compone nts, including miscellaneous reque sts and process requests. The miscellaneou s requests are any requests not related to the direct processing of data by the SEC2 core.

Process requests comprise the majority of the requests and all are executed usi ng the same to compose these reque sts are desc ribed in de tail in Section 3.3.6,

“Process Request Structures.”

ioctl() access point. Structures needed

Contents

1. Overview . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 1

2. Device Driver Components . . . . . . . . . . . . . . . . . . . . 3

3. User Inter f ace . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 5

4. Individual Request Type Descriptions . . . . . . . . . . . 14

5. Sample Code . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 36

6. Linux Environment . . . . . . . . . . . . . . . . . . . . . . . . . . 39

7. VxWorks Environment . . . . . . . . . . . . . . . . . . . . . . . 40

8. Porting . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 41

Throughout the document, the acronyms CHA (crypto hardware accelerator ) and E U (execu t io n unit) are used interch an geab l y.

This document contains information on a new product. Specifications and information herein are subject to change without notice.

PRELIMINARY—SUBJECT TO CHANGE WITHOUT NOTICE

Overview

Both acronyms indicate the devi ce's functional block that performs the crypto functions requested. For furth er details on the device see the Hardwa re Refer ence Manual.

The reader should underst and that the design of this driver is a legacy holdover from two prior generations of security processors. As applications have already been written for those processors, certain aspects of the interface for this drive r have been designed so as t o maintain source-level a pplication portability with prior driver/ processor versions. Where relevant in this document, prior-version compatibility features will be indicated to the reader.

Table 1 contains acronyms and abbreviations that are used in this user’s guide.

Table 1. Acronyms and Abbreviations

Term Meaning

AESA AES accelerator—This term is synonymous with AESU in the

documentation.

AFHA ARC-4 hardware accelerator—This term is synonymous with AFEU in the

and other documentation.

APAD Autopad—The MDHA will automatically pad incomplete message blocks out to 512 bits when APAD

is enabled.

ARC-4 Encryption algorithm compatible with the RC-4 algorithm developed by RSA, Inc.

Auth Authentication

CBC Cipher block chaining—An encryption mode commonly used with block ciphers.

CHA Crypto hardware accelerator—This term is synonymous with ‘execution unit’ in the

Manual

and other documentation.

CTX Context

DESA DES accelerator—This term is synonymous with DEU in the

documentation.

DPD Data packet descriptor

ECB Electronic code book—An encryption mode less commonly used with block ciphers.

EU Execution unit

HMAC Hashed message authentication code

IDGS Initialize digest

MPC18x User’s Manual

and other

MPC18x User’s

and other

IPSec Internet protocol security

ISR Interrupt service routine

KEA Kasumi encryption acceleration

MD Message digest

MDHA Message digest hardware accelerator—This term is synonymous with MDEU in the

Manual

and other documentation.

OS Operating system

PK Public key

PKHA Public key hardware accelerator—This term is synonymous with PKEU in the

Manual

and other documentation.

SEC 2.0 Reference Device Driver User’s Guide, Rev. 0

2 PRELIMINARY—SUBJECT TO CHANGE WITHOUT NOTICE Freescale Semiconductor

MPC18x User’s

Device Driver Components

Table 1. Acronyms and Abbreviations (continued)

Term Meaning

RDK Restore decrypt key—An AESA option to re-use an existing expanded AES decryption key.

RNGA Random number generator accelerator

SDES Single DES

TEA Transfer error acknowledge

TDES Triple DES

VxWorks Operating systems provided by VxWorks Company.

2 Device Driver Components

This section is provided to help users understand the internal struct ure of the dev ice driver.

2.1 Device Driver Structure

Internally, the driver is structured in four basic components:

• Driver Initialization and Setup

• Application Request Processing

• Interrupt Service Routine

• Defe rred Service Ro ut ine

While executing a request , the driver runs in system/kernel state for all components with the exception of the ISR, which runs in the operating syst em's standard interrupt processi ng context.

End-User Application

Prepare Request

(Non-Blocking)

ioctl ( )

Callback Function

ProcessingComplete Task

Sleeps on Queue

Completes the User Request

Execute Callback Function

If no callback function is defined, no callback takes place.

Driver

Invoked

• Tracks Requests

• Queue Request when Channels are Unavailable

• Prepare Descriptors

Driver

Returns

Writing a Message to the Queue Wakes

• Start the descriptor’s execution in a channel

SEC2.x Execution

IsrMsgQId

the ProcessingComplete Task

Driver Code

Operation Starts

Operation Completed/ Interrupt Generated

ISR

SEC 2.0 Reference Device Driver User’s Guide, Rev. 0

Freescale Semiconductor PRELIMINARY—SUBJECT TO CHANGE WITHOUT NOTICE 3

Device Driver Components

2.1.1 Driver Initialization Routine

The driver initializ ation routine includes both OS-specif ic and hardware-specific initi alization. The steps taken by the driver initialization routine are as follows:

• Finds the security engine core and sets the device memory map starting address in

• Initialize the security engin e's registers — Controller regis ters — Channel registers —EU registers

• Initializes driver internal variables

• Initializes the channel assign ment table — The device driver will maintain this structure with state informat ion for each channel and user request.

A mutual-exclusion semaph ore protects this structure so multipl e tasks are prevented from interfering with e ach ot her.

• Initializes the internal reque st queue — This queue holds requests to be dispatche d when channels becom e availa ble. The queue can hold up to

24 requests. The driver will reject requests with an error when the queue is full.

ProcessingComplete() is spawned then pends on the IsrMsgQId which se rve s as th e inter face betwe en

• the interrupt service routine and this deferred task.

IOBaseAddress.

2.1.2 Request Dispatch Routine

The request dispatch routine provides the ioctl() interface to the device driver. It uses the callers request code to identify which function is to e xecute and dispatches the appropriat e handler to process the request. The driver performs a number of tasks that include tracking requests, queuing requests when the requested channel is unavailable, preparing data packet descriptors, and writing said descriptor's address to the appropriate channel; in effect giving the security engine the direction to begin processing the request. The ioctl() f unction returns to the end-user application without waiting for the security engine to complete, assuming that once a DPD (data packet descriptor) is init iated for processi ng by the hardware, int errupt service may invok e a handler to provide completion notification

2.1.3 Process Request Routine

The process req uest routine t ranslates t he reque st into a seque nce of o ne or mor e data pac ket desc riptor s (DPD) and feeds it to the security engi ne cor e to initiate processing. If no channels are availa ble to handle the request, the request is queued.

2.1.4 Interrupt Service Routine

When processing is completed by the security eng ine, an interrupt is generated. The interr upt service routine handles the interrupt and queues the result of the operation in the

ProcessingComplete() deferred service routine.

SEC 2.0 Reference Device Driver User’s Guide, Rev. 0

4 PRELIMINARY—SUBJECT TO CHANGE WITHOUT NOTICE Freescale Semiconductor

IsrMsgQId queue for deferred processing by the

User Interface

2.1.5 Deferred Service Routine

The ProcessingComplete() routine completes the requ est outside of the interrupt servi ce routine, and r uns in a non-ISR context. This routine depends on the IsrMsgQId queue and processes messages written to the queue by the interrupt servi ce routine. This function will determine which reque st is complete, and notify the calling task using any handler specified by that calling task. It will then check the remaining content of the process request queue, and schedule any queued requests.

3 User Interface

3.1 Application Interface

In order to make a request of the SEC2 devic e, the calling appl ication populates a request structur e with information describing the request. These structures are described in Section 4, “Individual Request Type Descriptions,” and include items such as operation ID, channel, callback routines (succe ss and error), and data.

Once the requ est is prep ar ed , the appli cat io n calls system call used by operating system I/O subsystems to implement special-purpo se func tions. It typically follows the format:

int ioctl(int fd, /* file descriptor */

int function, /* function code */

int arg /* arbitrary argument (driver dependent) */

The function code (second ar gument) is defined as the I/O control code. This code will specify the driver-specif ic operation to be performed by the device in question. The third argument is the pointer to the SEC2 user request structure which contains information needed by the driver to perform the function requested.

The following is a list of guideline s to be followed by the end-user application when preparing a request structure:

• The first member of every request structure is an operation ID (opID). The operation ID is used by the device driver to determine the format of the request structure.

• While all requests have a “channel” member, it's presence is a holdover from earlier variations of the security engine. For SEC2, it no longer has a valid use, and is retained solely to maintaining request compatibility for ap plications written for older security engines.

• All process request st ructure s have a status member. This value is f illed i n by the devic e drive r when the interrupt for t he opera tion occurs and it refle cts the statu s of the ope rati on as indi cated by t he inte rrupt. The valid values for this sta tus member are DONE (normal status) or ERROR (error status).

• All process request stru ctures have two not ify members, notify and notify_on_error. These notify members can be used by the device driver to notify the application when its request has been completed. They may be the same function, or diff erent, as required by the caller's operational requirements.

• All process request structures have a process requests tog ether.

• It is the application's choice to use a notifier function or to poll the status member.

ioctl() with the prepared request. This function is a standard

next request member. This allows the application to chain multiple

SEC 2.0 Reference Device Driver User’s Guide, Rev. 0

Freescale Semiconductor PRELIMINARY—SUBJECT TO CHANGE WITHOUT NOTICE 5

User Interface

3.2 Error Handling

Due to the asynchronous nature of the device/driver, there are two primary sources of errors:

• Syntax or logic. These are returned in the

status member of the 'user request' argument and as a return

code from ioctl function. Errors of this type are detected by the driver, not by hardware.

• Prot oco l /p roced u re . The s e errors are ret urn ed on ly in the

status member of the user request argument.

Errors of this type are detected by hardware in the course of their execution.

Consequently, the end-user application needs two levels of error checking, the first one after the return from the

ioctl function, and the second one after the comple tion of the request. The second level is possible only if the

request was done with at least the

notify_on_error member of the user request structure. If the

notification/callback function has not been requested, this level of error will be lost. A code example of the two levels of errors are as follows, using an AES request as an example:

AESA_CRYPT_REQ aesdynReq;

aesdynReq.opId = DPD_AESA_CBC_ENCRYPT_CRYPT;

aesdynReq.channel = 0;

aesdynReq.notify = (void *) notifAes;

aesdynReq.notify_on_error = (void *) notifAes;

aesdynReq.status = 0;

aesdynReq.inIvBytes = 16;

aesdynReq.inIvData = iv_in;

aesdynReq.keyBytes = 32;

aesdynReq.keyData = AesKey;

aesdynReq.inBytes = packet_length;

aesdynReq.inData = aesData;

aesdynReq.outData = aesResult;

aesdynReq.outIvBytes = 16;

aesdynReq.outIvData = iv_out;

aesdynReq.nextReq = 0;

status = Ioctl(device, IOCTL_PROC_REQ, &aesdynReq);

if (status != 0) {

printf ("Syntax-Logic Error in dynamic descriptor 0x%x\n", status); .

SEC 2.0 Reference Device Driver User’s Guide, Rev. 0

6 PRELIMINARY—SUBJECT TO CHANGE WITHOUT NOTICE Freescale Semiconductor

User Interface

/* in callback function notifAes */

if (aesdynReq.status != 0) {

printf ("Error detected by HW 0x%x\n", aesdynReq.status) ;

}

3.3 Global Definitions

3.3.1 I/O Control Codes

The I/O control code is the second argument in the ioctl function. Definitions of these control codes are defined in

Sec2.h.

Internally, these values are used in conjunction with a ba se index to cre ate the I /O control c odes. The macro f or this base index is defined by

SEC2_IOCTL_INDEX and has a value of 0x0800.

Table 2. Second and Third Arguments in the ioctl Function

I/O Control Code (Second Argument in

SEC2_PROC_REQ Pointer to user's request structure

SEC2_GET_STATUS Pointer to a

SEC2_MALLOC Pointer to be assigned to a block of kernel memory for holding

SEC2_FREE Pointer to free a block originally allocated by

SEC2_COPYFROM Pointer to type

SEC2_COPYTO Pointer to type

ioctl Function) Third Argument in ioctl Function

STATUS_REQ

caller data to be operated upon

MALLOC_REQ, which will hold information

about a user buffer that will be copied from user memory space to kernel memory space allocated by

MALLOC_REQ, which will hold information

about a user buffer that will be copied from kernel memory space allocated by

SEC2_MALLOC back to a user's buffer.

SEC2_MALLOC

3.3.2 Channel Definitions

The NUM_CHANNELS definition is used to specify the number of channels implemented in the SEC2 device. If not specified, it will be set to a value of 4 as a default.

SEC 2.0 Reference Device Driver User’s Guide, Rev. 0

Freescale Semiconductor PRELIMINARY—SUBJECT TO CHANGE WITHOUT NOTICE 7

User Interface

Table 3. Channel Defines

Define Description

NUM_AFHAS Number of ARC4 CHAs

NUM_DESAS Number of DES CHAs

NUM_MDHAS Number of MD CHAs

NUM_RNGAS Number of RNG CHAs

NUM_PKHAS Number of PK CHAs

NUM_AESAS Number of AESA CHAs

The NUM_CHAS defini tion conta ins the tot al number of crypt o hardware acc elerator s (CHAs) in SEC2 and is si mply defined as the sum of the individual channels.

The device name is defined as

/dev/sec2.

3.3.3 Operation ID (opId) Masks

Operation Ids can be broken down into two parts, the group or type of request and the request index or descriptor within a group or type. This is provided to he lp unders tand the structur ing of the opIds . It is not speci fically needed within a user applicati on.

Table 4. Request Operation ID Mask

Define Description Value

DESC_TYPE_MASK The mask for the group or type of an opId 0xFF00

DESC_NUM_MASK The mask for the request index or descriptor within that group or type 0x00FF

3.3.4 Return Codes

A complete list of the error status results that may be returned to the callback routine s follows:

Table 5. Callback Error Status Return Code

Define Description Value

SEC2_SUCCESS Successful completion of request 0

SEC2_MEMORY_ALLOCATION Driver can’t obtain memory from the host operating

system

0xE004FFFF

SEC2_INVALID_CHANNEL Channel specification was out of range. This exists for

legacy compatibility, and has no relevance for SEC2

SEC2_INVALID_CHA_TYPE Requested CHA doesn’t exist 0xE004FFFD

SEC2_INVALID_OPERATION_ID Requested opID is out of range for this request type 0xE004FFFC

SEC2_CHANNEL_NOT_AVAILABLE Requested channel was not available. This error

exists for legacy compatibility reasons, and has no relevance for SEC2

SEC 2.0 Reference Device Driver User’s Guide, Rev. 0

8 PRELIMINARY—SUBJECT TO CHANGE WITHOUT NOTICE Freescale Semiconductor

0xE004FFFE

0xE004FFFB

User Interface

Table 5. Callback Error Status Return Code (continued)

Define Description Value

SEC2_CHA_NOT_AVAILABLE Requested CHA was not available at the time the

request was being processed

SEC2_INVALID_LENGTH Length of requested data item is incompatible with

request type, or data alignment incompatible

SEC2_OUTPUT_BUFFER_ALIGNMENT Output buffer alignment incompatible with request

type

SEC2_ADDRESS_PROBLEM Driver could not translate argued address into a

physical address

SEC2_INSUFFICIENT_REQS Request entry pool exhausted at the time of request

processing, try again later

SEC2_CHA_ERROR CHA flagged an error during processing, check the

error notification context if one was provided to the request

0xE004FFFA

0xE004FFF9

0xE004FFF8

0xE004FFF6

0xE004FFF5

0xE004FFF2

SEC2_NULL_REQUEST Request pointer was argued NULL 0xE004FFF1

SEC2_REQUEST_TIMED_OUT Timeout in request processing 0xE004FFF0

SEC2_MALLOC_FAILED Direct kernel memory buffer request failed 0xE004FFEF

SEC2_FREE_FAILED Direct kernel memory free failed 0xE004FFEE

SEC2_PARITY_SYSTEM_ERROR Parity Error detected on the bus 0xE004FFED

SEC2_INCOMPLETE_POINTER Error due to partial pointer 0xE004FFEC

SEC2_TEA_ERROR A transfer error has occurred 0xE004FFEB

SEC2_FRAGMENT_POOL_EXHAUSTED The internal scatter-gather buffer descriptor pool is

full

SEC2_FETCH_FIFO_OVERFLOW Too many DPD's written to a channel (indicates an

internal driver problem)

SEC2_BUS_MASTER_ERROR Processor could not acquire the bus for a data

transfer

SEC2_SCATTER_LIST_ERROR Caller's list describing a scatter-gather buffer is

corrupt

0xE004FFEA

0xE004FFE9

0xE004FFE8

0xE004FFE7

SEC2_UNKNOWN_ERROR Any other unrecognized error 0xE004FFE6

SEC2_IO_CARD_NOT_FOUND Error due to device hardware not being found -1000

SEC2_IO_MEMORY_ALLOCATE_ERROR Error due to insufficient resources -1001

SEC2_IO_IO_ERROR Error due to I/O configuration -1002

SEC2_IO_VXWORKS_DRIVER_TABLE_ ADD_ERROR

SEC2_IO_INTERRUPT_ALLOCATE_ER ROR

SEC2_VXWORKS_CANNOT_CREATE_QU EUE

Error due to VxWorks not being able to add driver to table

Error due to interrupt allocation error -1004

Error due to VxWorks not being able to create the ISR queue in IOInitQs()

-1003

-1009

SEC 2.0 Reference Device Driver User’s Guide, Rev. 0

Freescale Semiconductor PRELIMINARY—SUBJECT TO CHANGE WITHOUT NOTICE 9

User Interface

Table 5. Callback Error Status Return Code (continued)

Define Description Value

SEC2_CANCELLED_REQUEST Error due to canceled request -1010 SEC2_INVALID_ADDRESS Error due to a NULL request -1011

3.3.5 Miscellaneous Request Structures

3.3.5.1 STATUS_REQ Structure

Used to indicate the internal state of the SEC2 core as well as the driver after the occurrence of an event. Returned as a pointer by GetStatus() and embedded in all requests. This structure is defined in Sec2Notify.h

Each element is a copy of the contents of the same register in the

SEC2 driver. This structure is also known as

SEC2_STATUS through a typedef.

unsigned long ChaAssignmentStatusRegister[2];

unsigned long InterruptControlRegister[2];

unsigned long InterruptStatusRegister[2];

unsigned long IdRegister;

unsigned long ChannelStatusRegister[NUM_CHANNELS][2];

unsigned long ChannelConfigurationRegister[NUM_CHANNELS][2];

unsigned long CHAInterruptStatusRegister[NUM_CHAS][2];

unsigned long QueueEntryDepth;

unsigned long FreeChannels;

unsigned long FreeAfhas;

unsigned long FreeDesas;

unsigned long FreeMdhas;

unsigned long FreePkhas;

unsigned long FreeAesas;

unsigned long FreeKeas;

unsigned long BlockSize;

3.3.5.2 SEC2_NOTIFY_ON_ERROR_CTX Structure

Structure returned to the notify_on_error callback routine that was setup in the initial process request. This structure contains the original request structure as well as an error and driver status.

unsigned long errorcode; // Error that the request generated

void *request; // Pointer to original request

SEC 2.0 Reference Device Driver User’s Guide, Rev. 0

10 PRELIMINARY—SUBJECT TO CHANGE WITHOUT NOTICE Freescale Semiconductor

User Interface

STATUS_REQ driverstatus; // Detailed information as to the state of the

// hardware and the driver at the time of an error

3.3.6 Process Request Structures

All process request struc tures contain the a copy of the same request header information, which is defined by the

COMMON_REQ_PREAMBLE macro. The members of this header must be filled in as needed by the user prior to the

issue of the user's request.

unsigned long opId;

unsigned char scatterBufs;

unsigned char notifyFlags;

unsigned char reserved;

unsigned char channel;

PSEC2_NOTIFY_ROUTINE notify;

PSEC2_NOTIFY_CTX pNotifyCtx;

PSEC2_NOTIFY_ON_ERROR_ROUTINE notify_on_error;

SEC2_NOTIFY_ON_ERROR_CTX ctxNotifyOnErr;

int status;

void *nextReq;

opId operation Id which identifies what type of request this is. It is normally associated with

a specific type of cryptographic operation, see Section 4, “Individual Request Type

Descriptions” for all supported request types.

scatterBufs A bitmask that specifies which of the argued buffers are mapped through a

scatter-gather list. The mask is filled out via the driver's helper function

MarkScatterBuffer(), described in Section 3.3.7, “Scatter-Gather Buffer

Management.”

notifyFlags If a POSIX-style signal handler will be responsible for request completion notification,

then it can contain ORed bits of

NOTIFY_IS_PID and/or

NOTIFY_ERROR_IS_PID, signifying that the notify or notify_on_error

pointers are instead the process ID's (i.e. upon request completion.

getpid()) of the task requesting a signal

channel identifies the channel to be used for the request. It exists for legacy compatibility

reasons, and is no longer useful for SEC2.

notify pointer to a notification callback routine that will be called when the request has

completed successfully. May instead be a process ID if a user-state signal handler will flag completion. Refer back to

notifyFlags for more info.

pNotifyCtx pointer to context area to be passed back through the notification routine.

SEC 2.0 Reference Device Driver User’s Guide, Rev. 0

Freescale Semiconductor PRELIMINARY—SUBJECT TO CHANGE WITHOUT NOTICE 11

User Interface

notify_on_error pointer to the notify on error routine that will be called when the request has completed

unsuccessfully. May instead be a process ID if a user-state signal handler will flag completion. Refer back to

ctxNotifyOnErr context area that is filled in by the driver when there is an error.

status will contain the returned status of request.

nextReq pointer to next request which allows for multiple request to be linked together and sent

via a single

ioctl function call.

notifyFlags for more info.

The additional data in the process request structures is specific to each request; refer to the specific structure for this information.

3.3.7 Scatter-Gather Buffer Management

A unique feature of the SEC 2.0 processor is the hardware's abilit y to read and act on a scatter- gather descripti on list for a data buffer. This allows the hardwa re to more efficiently deal with buffers located in memory belonging to a non-privilege d process; memory which may not be contiguous, bu t instead may be at scatt ered locations de termined by the memory management scheme of the host system. Any data buffer in any request may be “marked” as a scattered m emory buffer by the reque sto r as ne ed ed.

For the requestor to do so, two actions must be take n:

• A linked list of structur es of type

EXT_SCATTER_ELEMENT, one per memory f ragment, must be c onstructed

to describe the whole of the buffer's content.

• The buffer pointer shall refer ence the head of this list, not the data itself. The buf fers containing scatter references shall be ma rked in the request's

scatterBufs element. Which bits get marked shall be

determined by a helper function that understands the mapping used on an individual reque st basis.

3.3.7.1 Building the Local Scatter/Gather List with EXT_SCATTER_ELEMENT

Since individual oper ating systems shall have their own internal means def ining memory mapping constructs, the driver cannot be designe d with specific knowledge of one particular mapping method. Therefore, a generic memory fragment definition structure, EXT_SCATTER_ELEMENT is defined for this purpose .

EXT_SCATTER_ELEMENT describes one con tiguous fragment of user memory, and is designed so that multiple

Each fragments can be tied together into a single linked list. It contains these elem ents:

void *next; pointer to next fragment in list, NULL if at end of list.

void *fragment; pointer to contiguous data fragment.

unsigned short size; size of this fragment in bytes.

With this, the caller must construct the lis t of all the fragments neede d to describe the buf fer , of the list, and pass the head as the buff er pointer argument. This li st must rema in intact until completion of the request.

NULL terminate the end

3.3.7.2 Scatter Buffer Marking

For reasons o f legacy compatibilit y , the structur e of all driver r equest type s maintains the same size and form as prior versions, with a minor change in that a size-compatible scatterBufs element was added as a modification to the

channel element in other versions. This allows the caller a means of indicating which buffers in the request are

SEC 2.0 Reference Device Driver User’s Guide, Rev. 0

12 PRELIMINARY—SUBJECT TO CHANGE WITHOUT NOTICE Freescale Semiconductor

User Interface

scatter -composed, as opposed to direct, contiguous memory (for instance, key data could be in contiguous system memory, while ciphertext data will be in fragm ented user memory).

A problem with marking buff ers using this method is that there is no means for the caller to clearly identify which

scatterBufs matches any given pointer in the request, sinc e the data description portion of dif ferent requests

bit in cannot be consistent or of any particular order.

A helper function,

MarkScatterBuffer(), is therefore made available by the driver to make the bit/pointer

association logi c in the driv er ac ces sibl e to th e cal ler. It's form is:

MarkScatterBuffer(void *request, void *buffer);

where request points to the request block being built (the opId element must be set prior to call), and buffer points to the element within the request which references a scattered buffer. It will then mark the necessary bit in

scatterBufs that defines this buffer for this specific request type.

3.3.7.3 Direct Scatter-Gather Usage Example

In order to make this usage clear, an example is presented. Assume that a triple DES encryption operation is to be constructed, where the input and output buffers are loca ted in fragmented user memory, and the cipher keys and IV are contained in system memory. A DES_LOADCTX_CRYPT_REQ is zer o-allocated as encReq, and constructed:

/* set up encryption operation */

encReq.opId = DPD_TDES_CBC_CTX_ENCRYPT;

encReq.notify = notifier;

encReq.notify_on_error = notifier;

encReq.inIvBytes = 8;

encReq.keyBytes = 24;

encReq.inBytes = bufsize;

encReq.inIvData = iv;

encReq.keyData = cipherKey;

encReq.inData = (unsigned char *)input; /* this buffer is scattered */

encReq.outIvBytes = 8;

encReq.outIvData = ctx;

encReq.outData = (unsigned char *)output; /* this buffer is scattered */

MarkScatterBuffer(&encReq, &encReq.input);

MarkScatterBuffer(&encReq, &encReq.output);

Upon completion of the two mark calls, encReq.scatterBufs will have two bits set within it that the driver knows how to interpret as meaning that the inte nded buffers have scatter lists de fined for them, and will process them accordingly as the DPD is built for the hardware .

SEC 2.0 Reference Device Driver User’s Guide, Rev. 0

Freescale Semiconductor PRELIMINARY—SUBJECT TO CHANGE WITHOUT NOTICE 13

Individual Request Type Descriptions

4 Individual Request Type Descriptions

4.1 Random Number Requests

4.1.1 RNG_REQ

COMMON_REQ_PREAMBLE

unsigned long rngBytes;

unsigned char* rngData;

NUM_RNGA_DESC defines the number of descriptor s within the DPD_RNG_GROUP that use this request. DPD_RNG_GROUP (0x1000) defines the group for all descr iptors within this request.

Table 6. RNG_REQ Valid Descriptor (opId)

Descriptor Value Function Description

DPD_RNG_GETRN 0x1000 Generate a series of random values

4.2 DES Requests

4.2.1 DES_CBC_CRYPT_REQ

COMMON_REQ_PREAMBLE

unsigned long inIvBytes; /* 0 or 8 bytes */

unsigned char *inIvData;

unsigned long keyBytes; /* 8, 16, or 24 bytes */

unsigned char *keyData;

unsigned long inBytes; /* multiple of 8 bytes */

unsigned char *inData;

unsigned char *outData; /* output length = input length */

unsigned long outIvBytes; /* 0 or 8 bytes */

unsigned char *outIvData;

NUM_DES_LOADCTX_DESC defines the number of descriptor s within the DPD_DES_CBC_CTX_GROUP that use this

request.

DPD_DES_CBC_CTX_GROUP (0x2500) defines the group for all descriptors within this request.

SEC 2.0 Reference Device Driver User’s Guide, Rev. 0

14 PRELIMINARY—SUBJECT TO CHANGE WITHOUT NOTICE Freescale Semiconductor

Individual Request Type Descriptions

Table 7. DES_CBC_CRYPT_REQ Valid Descriptors (opId)

Descriptors Value Function Description

DPD_SDES_CBC_CTX_ENCRYPT 0x2500 Load encrypted context from a dynamic channel to

encrypt in single DES using CBC mode

DPD_SDES_CBC_CTX_DECRYPT 0x2501 Load encrypted context from a dynamic channel to

decrypt in single DES using CBC mode

DPD_TDES_CBC_CTX_ENCRYPT 0x2502 Load encrypted context from a dynamic channel to

encrypt in triple DES using CBC mode

DPD_TDES_CBC_CTX_DECRYPT 0x2503 Load encrypted context from a dynamic channel to

decrypt in triple DES using CBC mode

4.2.2 DES_CRYPT_REQ

COMMON_REQ_PREAMBLE

unsigned long keyBytes; /* 8, 16, or 24 bytes */

unsigned char *keyData;

unsigned long inBytes; /* multiple of 8 bytes */

unsigned char *inData;

unsigned char *outData; /* output length = input length */

NUM_DES_DESC defines the number of descriptor s within the DPD_DES_ECB_GROUP that use this request. DPD_DES_ECB_GROUP (0x2600) defines the group for all descriptors within this request.

Table 8. DES_CRYPT_REQ Valid Descriptors (opId)

Descriptors Value Function Description

DPD_SDES_ECB_ENCRYPT 0x2600 Encrypt data in single DES using ECB mode

DPD_SDES_ECB_DECRYPT 0x2601 Decrypt data in single DES using ECB mode

DPD_TDES_ECB_ENCRYPT 0x2602 Encrypt data in triple DES using ECB mode

DPD_TDES_ECB_DECRYPT 0x2603 Decrypt data in triple DES using ECB mode

4.3 ARC4 Requests

4.3.1 ARC4_LOADCTX_CRYPT_REQ

COMMON_REQ_PREAMBLE

unsigned long inCtxBytes; /* 257 bytes */

SEC 2.0 Reference Device Driver User’s Guide, Rev. 0

Freescale Semiconductor PRELIMINARY—SUBJECT TO CHANGE WITHOUT NOTICE 15

Individual Request Type Descriptions

unsigned char *inCtxData;

unsigned long inBytes;

unsigned char *inData;

unsigned char *outData; /* output length = input length */

unsigned long outCtxBytes; /* 257 bytes */

unsigned char *outCtxData;

NUM_RC4_LOADCTX_UNLOADCTX_DESC defines the number of descriptors within the DPD_RC4_LDCTX_CRYPT_ULCTX_GROUP that use this request.

DPD_RC4_LDCTX_CRYPT_ULCTX_GROUP (0x3400) defines the group for all descriptors within this request.

Table 9. ARC4_LOADCTX_CRYPT_REQ Valid Descriptor (opId)

Descriptor Value Function Description

DPD_RC4_LDCTX_CRYPT_ULCTX 0x3400 Load context, encrypt using RC4, and store the

resulting context

4.3.2 ARC4_LOADKEY_CRYPT_UNLOADCTX_REQ

COMMON_REQ_PREAMBLE

unsigned long keyBytes;

unsigned char *keyData;

unsigned long inBytes;

unsigned char *inData;

unsigned char *outData; /* output length = input length */

unsigned long outCtxBytes; /* 257 bytes */

unsigned char* outCtxData;

NUM_RC4_LOADKEY_UNLOADCTX_DESC defines the number of descriptors within the DPD_RC4_LDKEY_CRYPT_ULCTX_GROUP that use this request.

DPD_RC4_LDKEY_CRYPT_ULCTX_GROUP (0x3500) defines the group for all descriptors within this request.

Table 10. ARC4_LOADKEY_CRYPT_UNLOADCTX_REQ Valid Descriptor (opId)

Descriptor Value Function Description

DPD_RC4_LDKEY_CRYPT_ULCTX 0x3500 Load the cipher key, encrypt using RC4 then save the

resulting context

SEC 2.0 Reference Device Driver User’s Guide, Rev. 0

16 PRELIMINARY—SUBJECT TO CHANGE WITHOUT NOTICE Freescale Semiconductor

Individual Request Type Descriptions

4.4 Hash Requests

4.4.1 HASH_REQ

COMMON_REQ_PREAMBLE

unsigned long ctxBytes;

unsigned char *ctxData;

unsigned long inBytes;

unsigned char *inData;

unsigned long outBytes; /* length is fixed by algorithm */

unsigned char *outData;

NUM_MDHA_DESC defines the number of descriptor s within the DPD_HASH_LDCTX_HASH_ULCTX_GROUP that use

this request.

DPD_HASH_LDCTX_HASH_ULCTX_GROUP (0x4400) defines the group for all descriptors within this request.

Table 11 . HASH_REQ Valid Descriptors (0x4400) (opId)

Descriptors Value Function Description

DPD_SHA256_LDCTX_HASH_ULCTX 0x4400 Load context, compute digest using SHA-256 hash

algorithm, then save the resulting context

DPD_MD5_LDCTX_HASH_ULCTX 0x4401 Load context, compute digest using MD5 hash

algorithm, then save the resulting context

DPD_SHA_LDCTX_HASH_ULCTX 0x4402 Load context, compute using SHA-1 hash algorithm,

then save the resulting context

DPD_SHA256_LDCTX_IDGS_HASH_ULCTX 0x4403 Load context, compute digest with SHA-256 IDGS

hash algorithm, then store the resulting context

DPD_MD5_LDCTX_IDGS_HASH_ULCTX 0x4404 Load context, compute digest with MD5 IDGS hash

algorithm, then store the resulting context

DPD_SHA_LDCTX_IDGS_HASH_ULCTX 0x4405 Load context, compute digest with SHA-1 IDGS hash

algorithm, then store the resulting context

NUM_MDHA_PAD_DESC defines the number of descriptor s within the DPD_HASH_LDCTX_HASH_PAD_ULCTX_GROUP that use this request.

DPD_HASH_LDCTX_HASH_PAD_ULCTX_GROUP (0x4500) defines the group for all descriptors within this request.

SEC 2.0 Reference Device Driver User’s Guide, Rev. 0

Freescale Semiconductor PRELIMINARY—SUBJECT TO CHANGE WITHOUT NOTICE 17

Individual Request Type Descriptions

Table 12. HASH_REQ Valid Descriptors (0x4500) (opId)

Descriptors Value Function Description

DPD_SHA256_LDCTX_HASH_PAD_ULCTX 0x4500 Compute digest with pre-padded data using an

SHA-256 hash algorithm then store the resulting context

DPD_MD5_LDCTX_HASH_PAD_ULCTX 0x4501 Compute digest with pre-padded data using an MD5

hash algorithm then store the resulting context

DPD_SHA_LDCTX_HASH_PAD_ULCTX 0x4502 Compute digest with pre-padded data using an

SHA-1 hash algorithm then store the resulting context

DPD_SHA256_LDCTX_IDGS_HASH_PAD_ULCTX 0x4503 Compute digest with pre-padded data using an

SHA-256 IDGS hash algorithm then store the resulting padded context

DPD_MD5_LDCTX_IDGS_HASH_PAD_ULCTX 0x4504 Compute digest with pre-padded data using an MD5

IDGS hash algorithm then store the resulting padded context

DPD_SHA_LDCTX_IDGS_HASH_PAD_ULCTX 0x4505 Compute digest with pre-padded data using an

SHA-1 IDGS hash algorithm then store the resulting padded context

4.5 HMAC Requests

4.5.1 HMAC_PAD_REQ

COMMON_REQ_PREAMBLE

unsigned long keyBytes;

unsigned char *keyData;

unsigned long inBytes;

unsigned char *inData;

unsigned long outBytes; /* length is fixed by algorithm */

unsigned char *outData;

NUM_HMAC_PAD_DESC defines the number of desc riptors within the DPD_HASH_LDCTX_HMAC_ULCTX_GROUP that

use this request.

DPD_HASH_LDCTX_HMAC_ULCTX_GROUP (0x4A00) defines the group for all descriptors within this request.

SEC 2.0 Reference Device Driver User’s Guide, Rev. 0

18 PRELIMINARY—SUBJECT TO CHANGE WITHOUT NOTICE Freescale Semiconductor

Individual Request Type Descriptions

Table 13 . HMAC_PAD_REQ Valid Descriptors (opId)

Descriptors Value Function Description

DPD_SHA256_LDCTX_HMAC_ULCTX 0x4A00 Load context, then use an SHA-256 hash algorithm,

then store the resulting HMAC context

DPD_MD5_LDCTX_HMAC_ULCTX 0x4A01 Load context, then use an MD5 hash algorithm, then

store the resulting HMAC context

DPD_SHA_LDCTX_HMAC_ULCTX 0x4A02 Load context, then use an SHA-1 hash algorithm,

then store the resulting HMAC context

DPD_SHA256_LDCTX_HMAC_PAD_ULCTX 0x4A03 Load context, then use an SHA-256 IDGS hash

algorithm, then store the resulting padded HMAC context

DPD_MD5_LDCTX_HMAC_PAD_ULCTX 0x4A04 Load context, then use an MD5 IDGS hash algorithm,

then store the resulting padded HMAC context

DPD_SHA_LDCTX_HMAC_PAD_ULCTX 0x4A05 Load context, then use an SHA-1 IDGS hash

algorithm, then store the resulting padded HMAC context

4.6 AES Requests

4.6.1 AESA_CRYPT_REQ

COMMON_REQ_PREAMBLE

unsigned long keyBytes; /* 16, 24, or 32 bytes */

unsigned char *keyData;

unsigned long inIvBytes; /* 0 or 16 bytes */

unsigned char *inIvData;

unsigned long inBytes; /* multiple of 8 bytes */

unsigned char *inData;

unsigned char *outData; /* output length = input length */

unsigned long outCtxBytes; /* 0 or 8 bytes */

unsigned char *outCtxData;

NUM_AESA_CRYPT_DESC defines the number of descriptor s within the DPD_AESA_CRYPT_GROUP that use this

request.

DPD_AESA_CRYPT_GROUP (0x6000) defines the group for al l descr iptors within this request.

SEC 2.0 Reference Device Driver User’s Guide, Rev. 0

Freescale Semiconductor PRELIMINARY—SUBJECT TO CHANGE WITHOUT NOTICE 19

Individual Request Type Descriptions

Table 14 . AESA_CRYPT_REQ Valid Descriptors (opId)

Descriptors Value Function Description

DPD_AESA_CBC_ENCRYPT_CRYPT 0x6000 Perform encryption in AESA using CBC mode

DPD_AESA_CBC_DECRYPT_CRYPT 0x6001 Perform decryption in AESA using CBC mode

DPD_AESA_CBC_DECRYPT_CRYPT_RDK 0x6002 Perform decryption in AESA using CBC mode with

RDK

DPD_AESA_ECB_ENCRYPT_CRYPT 0x6003 Perform encryption in AESA using ECB mode

DPD_AESA_ECB_DECRYPT_CRYPT 0x6004 Perform decryption in AESA using ECB mode

DPD_AESA_ECB_DECRYPT_CRYPT_RDK 0x6005 Perform decryption in AESA using ECB mode with

RDK

DPD_AESA_CTR_CRYPT 0x6006 Perform CTR in AESA

DPD_AESA_CTR_HMAC 0x6007 Perform AES CTR-mode cipher operation with

integrated authentication as part of the operation

4.7 Integer Public Key Requests

4.7.1 MOD_EXP_REQ

COMMON_REQ_PREAMBLE

unsigned long aDataBytes;

unsigned char *aData;

unsigned long expBytes;

unsigned char *expData;

unsigned long modBytes;

unsigned char *modData;

unsigned long outBytes;

unsigned char *outData;

NUM_MM_EXP_DESC defines the number of descriptor s within the DPD_MM_LDCTX_EXP_ULCTX_GROUP that use

this request.

DPD_MM_LDCTX_EXP_ULCTX_GROUP (0x5100) defines the group for all descriptors within this request.

Table 15. MOD_EXP_REQ Valid Descriptor (opId)

Descriptors Value Function Description

DPD_MM_LDCTX_EXP_ULCTX 0x5100 Perform a modular exponentiation operation

SEC 2.0 Reference Device Driver User’s Guide, Rev. 0

20 PRELIMINARY—SUBJECT TO CHANGE WITHOUT NOTICE Freescale Semiconductor

Individual Request Type Descriptions

4.7.2 MOD_SS_EXP_REQ

COMMON_REQ_PREAMBLE

unsigned long expBytes;

unsigned char *expData;

unsigned long modBytes;

unsigned char *modData;

unsigned long aDataBytes;

unsigned char *aData;

unsigned long bDataBytes;

unsigned char *bData;

NUM_MM_SS_EXP_DESC defines the number of descriptor s within the DPD_MM_SS_EXP_GROUP that use this

request.

DPD_MM_SS_EXP_GROUP (0x5B00) defines the group for all de scriptors within this request.

Table 16. MOD_SS_EXP_REQ Valid Descriptor (opId)

Descriptors Value Function Description

DPD_MM_SS_RSA_EXP 0x5B00 Perform a single-stage RSA exponentiation operation

4.7.3 MOD_R2MODN_REQ

COMMON_REQ_PREAMBLE

unsigned long modBytes;

unsigned char *modData;

unsigned long outBytes;

unsigned char *outData;

NUM_MM_R2MODN_DESC defines the number of descriptor s within the DPD_MM_LDCTX_R2MODN_ULCTX_GROUP

that use this request.

DPD_MM_LDCTX_R2MODN_ULCTX_GROUP (0x5200) defines the group for all descriptors within this request.

Table 17. MOD_R2MODN_REQ Valid Descriptor (opId)

Descriptor Value Function Description

DPD_MM_LDCTX_R2MODN_ULCTX 0x5200 Perform a R2MOD operation upon a public key

SEC 2.0 Reference Device Driver User’s Guide, Rev. 0

Freescale Semiconductor PRELIMINARY—SUBJECT TO CHANGE WITHOUT NOTICE 21

Individual Request Type Descriptions

4.7.4 MOD_RRMODP_REQ

COMMON_REQ_PREAMBLE

unsigned long nBytes;

unsigned long pBytes;

unsigned char *pData;

unsigned long outBytes;

unsigned char *outData;

NUM_MM_RRMODP_DESC defines the number of descriptor s within the DPD_MM_LDCTX_RRMODP_ULCTX_GROUP

that use this request.

DPD_MM_LDCTX_RRMODP_ULCTX_GROUP (0x5300) defines the group for all descriptors within this request.

Table 18. MOD_RRMODP_REQ Valid Descriptor (opId)

Descriptor Value Function Description

DPD_MM_LDCTX_RRMODP_ULCTX 0x5300 Compute the result of an RRMODP operation

4.7.5 MOD_2OP_REQ

unsigned long bDataBytes;

unsigned char *bData;

unsigned long aDataBytes;

unsigned char *aData;

unsigned long modBytes;

unsigned char *modData;

unsigned long outBytes;

unsigned char *outData;

NUM_MM_2OP_DESC defines the number of descriptor s within the DPD_MM_LDCTX_2OP_ULCTX_GROUP that use

this request.

DPD_MM_LDCTX_2OP_ULCTX_GROUP (0x5400) defines the group for all descriptors within this request.

SEC 2.0 Reference Device Driver User’s Guide, Rev. 0

22 PRELIMINARY—SUBJECT TO CHANGE WITHOUT NOTICE Freescale Semiconductor

Individual Request Type Descriptions

Table 19. MOD_2OP_REQ Valid Descriptors (opId)

Descriptors Value Function Description

DPD_MM_LDCTX_MUL1_ULCTX 0x5400 Perform a modular MUL1 operation

DPD_MM_LDCTX_MUL2_ULCTX 0x5401 Perform a modular MUL2 operation

DPD_MM_LDCTX_ADD_ULCTX 0x5402 Perform a modular ADD operation

DPD_MM_LDCTX_SUB_ULCTX 0x5403 Perform a modular SUB operation

DPD_POLY_LDCTX_A0_B0_MUL1_ULCTX 0x5404 Perform a modular A0-to-B0 MUL1 operation

DPD_POLY_LDCTX_A0_B0_MUL2_ULCTX 0x5405 Perform a modular A0-to-B0 MUL2 operation

DPD_POLY_LDCTX_A0_B0_ADD_ULCTX 0x5406 Perform a modular A0-to-B0 ADD operation

DPD_POLY_LDCTX_A1_B0_MUL1_ULCTX 0x5407 Perform a modular A1-to-B0 MUL1 operation

DPD_POLY_LDCTX_A1_B0_MUL2_ULCTX 0x5408 Perform a modular A1-to-B0 MUL2 operation

DPD_POLY_LDCTX_A1_B0_ADD_ULCTX 0x5409 Perform a modular A1-to-B0 ADD operation

DPD_POLY_LDCTX_A2_B0_MUL1_ULCTX 0x540A Perform a modular A2-to-B0 MUL1 operation

DPD_POLY_LDCTX_A2_B0_MUL2_ULCTX 0x540B Perform a modular A2-to-B0 MUL2 operation

DPD_POLY_LDCTX_A2_B0_ADD_ULCTX 0x540C Perform a modular A2-to-B0 ADD operation

DPD_POLY_LDCTX_A3_B0_MUL1_ULCTX 0x540D Perform a modular A3-to-B0 MUL1 operation

DPD_POLY_LDCTX_A3_B0_MUL2_ULCTX 0x540E Perform a modular A3-to-B0 MUL2 operation

DPD_POLY_LDCTX_A3_B0_ADD_ULCTX 0x540F Perform a modular A3-to-B0 ADD operation

DPD_POLY_LDCTX_A0_B1_MUL1_ULCTX 0x5410 Perform a modular A0-to-B1 MUL1 operation

DPD_POLY_LDCTX_A0_B1_MUL2_ULCTX 0x5411 Perform a modular A-to-B MUL2 operation

DPD_POLY_LDCTX_A0_B1_ADD_ULCTX 0x5412 Perform a modular A0-to-B1 ADD operation

DPD_POLY_LDCTX_A1_B1_MUL1_ULCTX 0x5413 Perform a modular A1-to-B1 MUL1 operation

DPD_POLY_LDCTX_A1_B1_MUL2_ULCTX 0x5414 Perform a modular A1-to-B1 MUL2 operation

DPD_POLY_LDCTX_A1_B1_ADD_ULCTX 0x5415 Perform a modular A1-to-B1 ADD operation

DPD_POLY_LDCTX_A2_B1_MUL1_ULCTX 0x5416 Perform a modular A2-to-B1 MUL1 operation

DPD_POLY_LDCTX_A2_B1_MUL2_ULCTX 0x5417 Perform a modular A2-to-B1 MUL2 operation

DPD_POLY_LDCTX_A2_B1_ADD_ULCTX 0x5418 Perform a modular A2-to-B1 ADD operation

DPD_POLY_LDCTX_A3_B1_MUL1_ULCTX 0x5419 Perform a modular A3-to-B1 MUL1 operation

DPD_POLY_LDCTX_A3_B1_MUL2_ULCTX 0x541A Perform a modular A3-to-B1 MUL2 operation

DPD_POLY_LDCTX_A3_B1_ADD_ULCTX 0x541B Perform a modular A3-to-B1 ADD operation

DPD_POLY_LDCTX_A0_B2_MUL1_ULCTX 0x541C Perform a modular A0-to-B2 MUL1 operation

DPD_POLY_LDCTX_A0_B2_MUL2_ULCTX 0x541D Perform a modular A0-to-B2 MUL2 operation

DPD_POLY_LDCTX_A0_B2_ADD_ULCTX 0x541E Perform a modular A0-to-B2ADD operation

DPD_POLY_LDCTX_A1_B2_MUL1_ULCTX 0x541F Perform a modular A1-to-B2 MUL1 operation

SEC 2.0 Reference Device Driver User’s Guide, Rev. 0

Freescale Semiconductor PRELIMINARY—SUBJECT TO CHANGE WITHOUT NOTICE 23

Individual Request Type Descriptions

Table 19. MOD_2OP_REQ Valid Descriptors (opId) (continued)

Descriptors Value Function Description

DPD_POLY_LDCTX_A1_B2_MUL2_ULCTX 0x5420 Perform a modular A1-to-B2 MUL2 operation

DPD_POLY_LDCTX_A1_B2_ADD_ULCTX 0x5421 Perform a modular A1-to-B2 ADD operation

DPD_POLY_LDCTX_A2_B2_MUL1_ULCTX 0x5422 Perform a modular A2-to-B2 MUL1 operation

DPD_POLY_LDCTX_A2_B2_MUL2_ULCTX 0x5423 Perform a modular A2-to-B2 MUL2 operation

DPD_POLY_LDCTX_A2_B2_ADD_ULCTX 0x5424 Perform a modular A2-to-B2 ADD operation

DPD_POLY_LDCTX_A3_B2_MUL1_ULCTX 0x5425 Perform a modular A3-to-B2 MUL1 operation

DPD_POLY_LDCTX_A3_B2_MUL2_ULCTX 0x5426 Perform a modular A3-to-B2 MUL2 operation

DPD_POLY_LDCTX_A3_B2_ADD_ULCTX 0x5427 Perform a modular A3-to-B2 ADD operation

DPD_POLY_LDCTX_A0_B3_MUL1_ULCTX 0x5428 Perform a modular A0-to-B3 MUL1 operation

DPD_POLY_LDCTX_A0_B3_MUL2_ULCTX 0x5429 Perform a modular n A0-to-B3 MUL2 operation

DPD_POLY_LDCTX_A0_B3_ADD_ULCTX 0x542A Perform a modular A0-to-B3 ADD operation

DPD_POLY_LDCTX_A1_B3_MUL1_ULCTX 0x542B Perform a modular A1-to-B3 MUL1 operation

DPD_POLY_LDCTX_A1_B3_MUL2_ULCTX 0x542C Perform a modular A1-to-B3 MUL2 operation

DPD_POLY_LDCTX_A1_B3_ADD_ULCTX 0x542D Perform a modular A1-to-B3 ADD operation

DPD_POLY_LDCTX_A2_B3_MUL1_ULCTX 0x542E Perform a modular A2-to-B3 MUL1 operation

DPD_POLY_LDCTX_A2_B3_MUL2_ULCTX 0x542F Perform a modular A2-to-B3 MUL2 operation

DPD_POLY_LDCTX_A2_B3_ADD_ULCTX 0x5430 Perform a modular A2-to-B3 ADD operation

DPD_POLY_LDCTX_A3_B3_MUL1_ULCTX 0x5431 Perform a modular A3-to-B3 MUL1 operation

DPD_POLY_LDCTX_A3_B3_MUL2_ULCTX 0x5432 Perform a modular A3-to-B3 MUL2 operation

DPD_POLY_LDCTX_A3_B3_ADD_ULCTX 0x5433 Perform a modular A3-to-B3 ADD operation

4.8 ECC Public Key Requests

4.8.1 ECC_POINT_REQ

COMMON_REQ_PREAMBLE

unsigned long nDataBytes;

unsigned char *nData;

unsigned long eDataBytes;

unsigned char *eData;

unsigned long buildDataBytes;

unsigned char *buildData;

unsigned long b1DataBytes;

SEC 2.0 Reference Device Driver User’s Guide, Rev. 0

24 PRELIMINARY—SUBJECT TO CHANGE WITHOUT NOTICE Freescale Semiconductor

Individual Request Type Descriptions

unsigned char *b1Data;

unsigned long b2DataBytes;

unsigned char *b2Data;

unsigned long b3OutDataBytes;

unsigned char *b3OutData;

NUM_EC_POINT_DESC defines the number of descriptor s within the DPD_EC_LDCTX_kP_ULCTX_GROUP that use

this request.

DPD_EC_LDCTX_kP_ULCTX_GROUP (0x5800) defines the group for all descriptors within this request.

Table 20. ECC_POINT_REQ Valid Descriptors (opId)

Descriptors Value Function Description

DPD_EC_FP_AFF_PT_MULT 0x5800 Perform a PT_MULT operation in an affine system

DPD_EC_FP_PROJ_PT_MULT 0x5801 Perform a PT_MULT operation in a projective system

DPD_EC_F2M_AFF_PT_MULT 0x5802 Perform an F2M PT_MULT operation in an affine

system

DPD_EC_F2M_PROJ_PT_MULT 0x5803 Perform an F2M PT_MULT operation in a projective

system

DPD_EC_FP_LDCTX_ADD_ULCTX 0x5804 Perform an FP add operation

DPD_EC_FP_LDCTX_DOUBLE_ULCTX 0x5805 Perform an FP double operation

DPD_EC_F2M_LDCTX_ADD_ULCTX 0x5806 Perform an F2M add operation

DPD_EC_F2M_LDCTX_DOUBLE_ULCTX 0x5807 Perform an F2M double operation

4.8.2 ECC_2OP_REQ

COMMON_REQ_PREAMBLE

unsigned long bDataBytes;

unsigned char *bData;

unsigned long aDataBytes;

unsigned char *aData;

unsigned long modBytes;

unsigned char *modData;

unsigned long outBytes;

unsigned char *outData;

NUM_EC_2OP_DESC defines the number of descriptor s within the DPD_EC_2OP_GROUP that use this request.

SEC 2.0 Reference Device Driver User’s Guide, Rev. 0

Freescale Semiconductor PRELIMINARY—SUBJECT TO CHANGE WITHOUT NOTICE 25

Individual Request Type Descriptions

DPD_EC_2OP_GROUP (0x5900) defines the group for all descriptors within this request.

Table 21. ECC_2OP_REQ Valid Descriptors (opId)

Descriptor Value Function Description

DPD_EC_F2M_LDCTX_MUL1_ULCTX 0x5900 Perform an F2M MULT1 operation

4.8.3 ECC_SPKBUILD_REQ

COMMON_REQ_PREAMBLE

unsigned long a0DataBytes;

unsigned char *a0Data;

unsigned long a1DataBytes;

unsigned char *a1Data;

unsigned long a2DataBytes;

unsigned char *a2Data;

unsigned long a3DataBytes;

unsigned char *a3Data;

unsigned long b0DataBytes;

unsigned char *b0Data;

unsigned long b1DataBytes;

unsigned char *b1Data;

unsigned long buildDataBytes;

unsigned char *buildData;

NUM_EC_SPKBUILD_DESC defines the number of descriptor s within the DPD_EC_SPKBUILD_GROUP that use this

request.

DPD_EC_SPKBUILD_GROUP (0x5a00) defines the group for all descriptors within this request.

Table 22. ECC_SPKBUILD_REQ Valid Descriptor (opId)

Descriptor Value Function Description

DPD_EC_SPKBUILD_ULCTX 0x5A00 Using separate values for a0-a3 and b0-b1, build a

uniform data block that can be used to condense data to a point that allow it to be used with ECC operational requests.

SEC 2.0 Reference Device Driver User’s Guide, Rev. 0

26 PRELIMINARY—SUBJECT TO CHANGE WITHOUT NOTICE Freescale Semiconductor

4.8.4 ECC_PTADD_DBL_REQ

COMMON_REQ_PREAMBLE

unsigned long modBytes;

unsigned char *modData;

unsigned long buildDataBytes;

unsigned char *buildData;

unsigned long b2DataBytes;

unsigned char *b2Data;

unsigned long b3DataBytes;

unsigned char *b3Data;

unsigned long b1DataBytes;

unsigned char *b2Data;

unsigned long b2DataBytes;

unsigned char *b2Data;

Individual Request Type Descriptions

unsigned long b3DataBytes;

unsigned char *b3Data;

Table 23. ECC_PTADD_DBL_REQ Valid Descriptor (opId)

Descriptor Value Function Description

DPD_EC_FPADD 0x5d00 Perform an FP add operation

DPD_EC_FPDBL 0x5d01 Perform an FP double operation

DPD_EC_F2MADD 0x5d02 Perform an F2M add operation

DPD_EC_F2MDBL 0x5d03 Perform an F2M double operation

4.9 IPSec Requests

4.9.1 IPSEC_CBC_REQ

COMMON_REQ_PREAMBLE

unsigned long hashKeyBytes;

unsigned char *hashKeyData;

unsigned long cryptKeyBytes;

unsigned char *cryptKeyData;

unsigned long cryptCtxInBytes;

SEC 2.0 Reference Device Driver User’s Guide, Rev. 0

Freescale Semiconductor PRELIMINARY—SUBJECT TO CHANGE WITHOUT NOTICE 27

Individual Request Type Descriptions

unsigned char *cryptCtxInData;

unsigned long hashInDataBytes;

unsigned char *hashInData;

unsigned long inDataBytes;

unsigned char *inData;

unsigned char *cryptDataOut;

unsigned long hashDataOutBytes;

unsigned char *hashDataOut;

NUM_IPSEC_CBC_DESC defines the number of descriptor s within the DPD_IPSEC_CBC_GROUP that use this

request.

DPD_IPSEC_CBC_GROUP (0x7000) defines the group for al l descr iptors within this request.

Table 24. IPSEC_CBC_REQ Valid Descriptors (opId) Descriptors

Descriptor Value Function Description

DPD_IPSEC_CBC_SDES_ENCRYPT_MD5_PAD 0x7000 Perform the IPSec process of encrypting in single

DES using CBC mode with MD5 padding

DPD_IPSEC_CBC_SDES_ENCRYPT_SHA_PAD 0x7001 Perform the IPSec process of encrypting in single

DES using CBC mode with SHA-1 padding

DPD_IPSEC_CBC_SDES_ENCRYPT_SHA256_PAD 0x7002 Perform the IPSec process of encrypting in single

DES using CBC mode with SHA-256 padding

DPD_IPSEC_CBC_SDES_DECRYPT_MD5_PAD 0x7003 Perform the IPSec process of decrypting in single

DES using CBC mode with MD5 padding

DPD_IPSEC_CBC_SDES_DECRYPT_SHA_PAD 0x7004 Perform the IPSec process of decrypting in single

DES using CBC mode with SHA-1 padding

DPD_IPSEC_CBC_SDES_DECRYPT_SHA256_PAD 0x7005 Perform the IPSec process of decrypting in single

DES using CBC mode with SHA-256 padding

DPD_IPSEC_CBC_TDES_ENCRYPT_MD5_PAD 0x7006 Perform the IPSec process of encrypting in triple DES

using CBC mode with MD5 padding

DPD_IPSEC_CBC_TDES_ENCRYPT_SHA_PAD 0x7007 Perform the IPSec process of encrypting in triple DES

using CBC mode with SHA-1 padding

DPD_IPSEC_CBC_TDES_ENCRYPT_SHA256_PAD 0x7008 Perform the IPSec process of encrypting in triple DES

using CBC mode with SHA-256 padding

DPD_IPSEC_CBC_TDES_DECRYPT_MD5_PAD 0x7009 Perform the IPSec process of decrypting in triple DES

using CBC mode with MD5 padding

DPD_IPSEC_CBC_TDES_DECRYPT_SHA_PAD 0x700A Perform the IPSec process of decrypting in triple DES

using CBC mode with SHA-1 padding

DPD_IPSEC_CBC_TDES_DECRYPT_SHA256_PAD 0x700B Perform the IPSec process of decrypting in triple DES

using CBC mode with SHA-256 padding

SEC 2.0 Reference Device Driver User’s Guide, Rev. 0

28 PRELIMINARY—SUBJECT TO CHANGE WITHOUT NOTICE Freescale Semiconductor

4.9.2 IPSEC_ECB_REQ

COMMON_REQ_PREAMBLE

unsigned long hashKeyBytes;

unsigned char *hashKeyData;

unsigned long cryptKeyBytes;

unsigned char *cryptKeyData;

unsigned long hashInDataBytes;

unsigned char *hashInData;

unsigned long inDataBytes;

unsigned char *inData;

unsigned long hashDataOutBytes;

unsigned char *hashDataOut;

unsigned char *cryptDataOut;

Individual Request Type Descriptions

NUM_IPSEC_ECB_DESC defines the number of descriptor s within the DPD_IPSEC_ECB_GROUP that use this

request.

DPD_IPSEC_ECB_GROUP (0x7100) defines the group for al l descr iptors within this request.

Table 25. IPSEC_ECB_REQ Valid Descriptors (opId)

Descriptors Value Function Description

DPD_IPSEC_ECB_SDES_ENCRYPT_MD5_PAD 0x7100 Perform the IPSec process of encrypting in single

DES using ECB mode with MD5 padding

DPD_IPSEC_ECB_SDES_ENCRYPT_SHA_PAD 0x7101 Perform the IPSec process of encrypting in single

DES using ECB mode with SHA-1 padding

DPD_IPSEC_ECB_SDES_ENCRYPT_SHA256_PAD 0x7102 Perform the IPSec process of encrypting in single

DES using ECB mode with SHA-256 padding

DPD_IPSEC_ECB_SDES_DECRYPT_MD5_PAD 0x7103 Perform the IPSec process of decrypting in single

DES using ECB mode with MD5 padding

DPD_IPSEC_ECB_SDES_DECRYPT_SHA_PAD 0x7104 Perform the IPSec process of decrypting in single

DES using ECB mode with SHA-1 padding

DPD_IPSEC_ECB_SDES_DECRYPT_SHA256_PAD 0x7105 Perform the IPSec process of decrypting in single

DES using ECB mode with SHA-256 padding

DPD_IPSEC_ECB_TDES_ENCRYPT_MD5_PAD 0x7106 Perform the IPSec process of encrypting in triple DES

using ECB mode with MD5 padding

DPD_IPSEC_ECB_TDES_ENCRYPT_SHA_PAD 0x7107 Perform the IPSec process of encrypting in triple DES

using ECB mode with SHA-1 padding

SEC 2.0 Reference Device Driver User’s Guide, Rev. 0

Freescale Semiconductor PRELIMINARY—SUBJECT TO CHANGE WITHOUT NOTICE 29

Individual Request Type Descriptions

Table 25. IPSEC_ECB_REQ Valid Descriptors (opId) (continued)

DPD_IPSEC_ECB_TDES_ENCRYPT_SHA256_PAD 0x7108 Perform the IPSec process of encrypting in triple DES

using ECB mode with SHA-256 padding

DPD_IPSEC_ECB_TDES_DECRYPT_MD5_PAD 0x7109 Perform the IPSec process of decrypting in triple DES

using ECB mode with MD5 padding

DPD_IPSEC_ECB_TDES_DECRYPT_SHA_PAD 0x710A Perform the IPSec process of decrypting in triple DES

using ECB mode with SHA-1 padding

DPD_IPSEC_ECB_TDES_DECRYPT_SHA256_PAD 0x710B Perform the IPSec process of decrypting in triple DES

using ECB mode with SHA-256 padding

4.9.3 IPSEC_AES_CBC_REQ

unsigned long hashKeyBytes;

unsigned char *hashKeyData;

unsigned long cryptKeyBytes;

unsigned char *cryptKeyData;

unsigned long cryptCtxInBytes;

unsigned char *cryptCtxInData;

unsigned long hashInDataBytes;

unsigned char *hashInData;

unsigned long inDataBytes;

unsigned char *inData;

unsigned char *cryptDataOut;

unsigned long hashDataOutBytes;

unsigned char *hashDataOut;

NUM_IPSEC_AES_CBC_DESC defines the n umber of de scr iptors withi n the DPD_IPSEC_AES_CBC_GROUP that use

this request.

DPD_IPSEC_AES_CBC_GROUP (0x8000) defines the group for all descriptors within this request.

Table 26. IPSEC_AES_CBC_REQ Valid Descriptors (opId)

Descriptors Value Function Description

DPD_IPSEC_AES_CBC_ENCRYPT_MD5_APAD 0x8000 Perform the IPSec process of encrypting in AES

using CBC mode with MD5 auto padding

DPD_IPSEC_AES_CBC_ENCRYPT_SHA_APAD 0x8001 Perform the IPSec process of encrypting in AES

using CBC mode with SHA-1 auto padding

DPD_IPSEC_AES_CBC_ENCRYPT_SHA256_APAD 0x8002 Perform the IPSec process of encrypting in AES

using CBC mode with SHA-256 auto padding

SEC 2.0 Reference Device Driver User’s Guide, Rev. 0

30 PRELIMINARY—SUBJECT TO CHANGE WITHOUT NOTICE Freescale Semiconductor

Individual Request Type Descriptions

Table 26. IPSEC_AES_CBC_REQ Valid Descriptors (opId) (continued)

Descriptors Value Function Description

DPD_IPSEC_AES_CBC_ENCRYPT_MD5 0x8003 Perform the IPSec process of encrypting in AES

using CBC mode with MD5

DPD_IPSEC_AES_CBC_ENCRYPT_SHA 0x8004 Perform the IPSec process of encrypting in AES

using CBC mode with SHA-1

DPD_IPSEC_AES_CBC_ENCRYPT_SHA256 0x8005 Perform the IPSec process of encrypting in AES

using CBC mode with SHA-256

DPD_IPSEC_AES_CBC_DECRYPT_MD5_APAD 0x8006 Perform the IPSec process of decrypting in AES

using CBC mode with MD5 auto padding

DPD_IPSEC_AES_CBC_DECRYPT_SHA_APAD 0x8007 Perform the IPSec process of decrypting in AES

using CBC mode with SHA-1 auto padding

DPD_IPSEC_AES_CBC_DECRYPT_SHA256_APAD 0x8008 Perform the IPSec process of decrypting in AES

using CBC mode with SHA-256 auto padding

DPD_IPSEC_AES_CBC_DECRYPT_MD5 0x8009 Perform the IPSec process of decrypting in AES

using CBC mode with MD5

DPD_IPSEC_AES_CBC_DECRYPT_SHA 0x800A Perform the IPSec process of decrypting in AES

using CBC mode with SHA-1

DPD_IPSEC_AES_CBC_DECRYPT_SHA256 0x800B Perform the IPSec process of decrypting in AES

using CBC mode with SHA-256

4.9.4 IPSEC_AES_ECB_REQ

COMMON_REQ_PREAMBLE

unsigned long hashKeyBytes;

unsigned char *hashKeyData;

unsigned long cryptKeyBytes;

unsigned char *cryptKeyData;

unsigned long hashInDataBytes;

unsigned char *hashInData;

unsigned long inDataBytes;

unsigned char *inData;

unsigned char *cryptDataOut;

unsigned long hashDataOutBytes;

unsigned char *hashDataOut;

NUM_IPSEC_AES_ECB_DESC defines the n umber of de scr iptors withi n the DPD_IPSEC_AES_ECB_GROUP that use

this request.

DPD_IPSEC_AES_ECB_GROUP (0x8100) defines the group for all descriptors within this request.

SEC 2.0 Reference Device Driver User’s Guide, Rev. 0

Freescale Semiconductor PRELIMINARY—SUBJECT TO CHANGE WITHOUT NOTICE 31

Individual Request Type Descriptions

Table 27. IPSEC_AES_ECB_REQ Valid Descriptors (opId)

Descriptors Value Function Description

DPD_IPSEC_AES_ECB_ENCRYPT_MD5_APAD 0x8100 Perform the IPSec process of encrypting in AES

using ECB mode with MD5 auto padding

DPD_IPSEC_AES_ECB_ENCRYPT_SHA_APAD 0x8101 Perform the IPSec process of encrypting in AES

using ECB mode with SHA-1 auto padding

DPD_IPSEC_AES_ECB_ENCRYPT_SHA256_APAD 0x8102 Perform the IPSec process of encrypting in AES

using ECB mode with SHA-256 auto padding

DPD_IPSEC_AES_ECB_ENCRYPT_MD5 0x8103 Perform the IPSec process of encrypting in AES

using ECB mode with MD5

DPD_IPSEC_AES_ECB_ENCRYPT_SHA 0x8104 Perform the IPSec process of encrypting in AES

using ECB mode with SHA-1

DPD_IPSEC_AES_ECB_ENCRYPT_SHA256 0x8105 Perform the IPSec process of encrypting in AES

using ECB mode with SHA-256

DPD_IPSEC_AES_ECB_DECRYPT_MD5_APAD 0x8106 Perform the IPSec process of decrypting in AES

using ECB mode with MD5 auto padding

DPD_IPSEC_AES_ECB_DECRYPT_SHA_APAD 0x8107 Perform the IPSec process of decrypting in AES

using ECB mode with SHA-1 auto padding

DPD_IPSEC_AES_ECB_DECRYPT_SHA256_APAD 0x8108 Perform the IPSec process of decrypting in AES

using ECB mode with SHA-256 auto padding

DPD_IPSEC_AES_ECB_DECRYPT_MD5 0x8109 Perform the IPSec process of decrypting in AES

using ECB mode with MD5

DPD_IPSEC_AES_ECB_DECRYPT_SHA 0x810A Perform the IPSec process of decrypting in AES

using ECB mode with SHA-1

DPD_IPSEC_AES_ECB_DECRYPT_SHA256 0x810B Perform the IPSec process of decrypting in AES

using ECB mode with SHA-256

4.9.5 IPSEC_ESP_REQ

COMMON_REQ_PREAMBLE

unsigned long hashKeyBytes;

unsigned char *hashKeyData;

unsigned long cryptKeyBytes;

unsigned char *cryptKeyData;

unsigned long cryptCtxInBytes;

unsigned char *cryptCtxInData;

unsigned long hashInDataBytes;

unsigned char *hashInData;

unsigned long inDataBytes;

unsigned char *inData;

SEC 2.0 Reference Device Driver User’s Guide, Rev. 0

32 PRELIMINARY—SUBJECT TO CHANGE WITHOUT NOTICE Freescale Semiconductor

Individual Request Type Descriptions

unsigned char *cryptDataOut;

unsigned long hashDataOutBytes;

unsigned char *hashDataOut;

unsigned long cryptCtxOutBytes;

unsigned char *cryptCtxOutData;

NUM_IPSEC_ESP_DESC defines the number of descriptor s within the DPD_IPSEC_ESP_GROUP that use this

request.

DPD_IPSEC_ESP_GROUP (0x7500) defines the group for al l descr iptors within this request.

Table 28. IPSEC_ESP_REQ Valid Descriptors (opId)

Descriptors Value Function Description

DPD_IPSEC_ESP_OUT_SDES_ECB_CRPT_MD5_PAD 0x7500 Process an outbound IPSec encapsulated system

payload packet using single DES in ECB mode and MD5 with auto padding

DPD_IPSEC_ESP_OUT_SDES_ECB_CRPT_SHA_PAD 0x7501 Process an outbound IPSec encapsulated system

payload packet using single DES in ECB mode, and SHA1 with auto padding

DPD_IPSEC_ESP_OUT_SDES_ECB_CRPT_SHA256_ PAD

0x7502 Process an outbound IPSec encapsulated system

payload packet using single DES in ECB mode, and SHA256 with auto padding

DPD_IPSEC_ESP_IN_SDES_ECB_DCRPT_MD5_PAD 0x7503 Process an inbound IPSec encapsulated system

payload packet using single DES in ECB mode, and MD5 with auto padding

DPD_IPSEC_ESP_IN_SDES_ECB_DCRPT_SHA_PAD 0x7504 Process an inbound IPSec encapsulated system

payload packet using single DES in ECB mode, and SHA1 with auto padding

DPD_IPSEC_ESP_IN_SDES_ECB_DCRPT_SHA256_ PAD

0x7505 Process an inbound IPSec encapsulated system

payload packet using single DES in ECB mode, and SHA256 with auto padding

DPD_IPSEC_ESP_OUT_SDES_CBC_CRPT_MD5_PAD 0x7506 Process an outbound IPSec encapsulated system

payload packet using single DES in CBC mode, and MD5 with auto padding

DPD_IPSEC_ESP_OUT_SDES_CBC_CRPT_SHA_PAD 0x7507 Process an outbound IPSec encapsulated system

payload packet using single DES in CBC mode, and SHA1 with auto padding

DPD_IPSEC_ESP_OUT_SDES_CBC_CRPT_SHA256_ PAD

0x7508 Process an outbound IPSec encapsulated system

payload packet using single DES in CBC mode, and SHA256 with auto padding

DPD_IPSEC_ESP_IN_SDES_CBC_DCRPT_MD5_PAD 0x7509 Process an inbound IPSec encapsulated system

payload packet using single DES in CBC mode, and MD5 with auto padding

SEC 2.0 Reference Device Driver User’s Guide, Rev. 0

Freescale Semiconductor PRELIMINARY—SUBJECT TO CHANGE WITHOUT NOTICE 33

Individual Request Type Descriptions

Table 28. IPSEC_ESP_REQ Valid Descriptors (opId) (continued)

Descriptors Value Function Description

DPD_IPSEC_ESP_IN_SDES_CBC_DCRPT_SHA_PAD 0x750A Process an inbound IPSec encapsulated system

payload packet using single DES in CBC mode, and SHA1 with auto padding

DPD_IPSEC_ESP_IN_SDES_CBC_DCRPT_SHA256_ PAD

0x750B Process an inbound IPSec encapsulated system

payload packet using single DES in CBC mode, and SHA256 with auto padding

DPD_IPSEC_ESP_OUT_TDES_CBC_CRPT_MD5_PAD 0x750C Process an outbound IPSec encapsulated system

payload packet using triple DES in CBC mode, and MD5 with auto padding

DPD_IPSEC_ESP_OUT_TDES_CBC_CRPT_SHA_PAD 0x750D Process an outbound IPSec encapsulated system

payload packet using triple DES in CBC mode, and SHA1 with auto padding

DPD_IPSEC_ESP_OUT_TDES_CBC_CRPT_SHA256_ PAD

0x750E Process an outbound IPSec encapsulated system

payload packet using triple DES in CBC mode, and SHA256 with auto padding

DPD_IPSEC_ESP_IN_TDES_CBC_DCRPT_MD5_PAD 0x750F Process an inbound IPSec encapsulated system

payload packet using triple DES in CBC mode, and MD5 with auto padding

DPD_IPSEC_ESP_IN_TDES_CBC_DCRPT_SHA_PAD 0x7510 Process an inbound IPSec encapsulated system

payload packet using triple DES in CBC mode, and SHA1 with auto padding

DPD_IPSEC_ESP_IN_TDES_CBC_DCRPT_SHA256_ PAD

0x7511 Process an inbound IPSec encapsulated system

payload packet using triple DES in CBC mode, and SHA256 with auto padding

DPD_IPSEC_ESP_OUT_TDES_ECB_CRPT_MD5_PAD 0x7512 Process an outbound IPSec encapsulated system

payload packet using triple DES in ECB mode, and MD5 with auto padding

DPD_IPSEC_ESP_OUT_TDES_ECB_CRPT_SHA_PAD 0x7513 Process an outbound IPSec encapsulated system

payload packet using triple DES in ECB mode, and SHA1 with auto padding

DPD_IPSEC_ESP_OUT_TDES_ECB_CRPT_SHA256_ PAD

0x7514 Process an outbound IPSec encapsulated system

payload packet using triple DES in ECB mode, and SHA256 with auto padding

DPD_IPSEC_ESP_IN_TDES_ECB_DCRPT_MD5_PAD 0x7515 Process an inbound IPSec encapsulated system

payload packet using triple DES in ECB mode, and MD5 with auto padding

DPD_IPSEC_ESP_IN_TDES_ECB_DCRPT_SHA_PAD 0x7516 Process an inbound IPSec encapsulated system

payload packet using triple DES in ECB mode, and SHA1 with auto padding

DPD_IPSEC_ESP_IN_TDES_ECB_DCRPT_SHA256_ PAD

SEC 2.0 Reference Device Driver User’s Guide, Rev. 0

34 PRELIMINARY—SUBJECT TO CHANGE WITHOUT NOTICE Freescale Semiconductor

0x7517 Process an inbound IPSec encapsulated system

payload packet using triple DES in ECB mode, and SHA256 with auto padding

4.10 802.11 Protocol Requests

4.10.1 CCMP_REQ

COMMON_REQ_PREAMBLE

unsigned long keyBytes;

unsigned char *keyData;

unsigned long ctxBytes;

unsigned char *context;

unsigned long FrameDataBytes;

unsigned char *FrameData;

unsigned long AADBytes;

unsigned char *AADData;

unsigned long cryptDataBytes;

unsigned char *cryptDataOut;

Individual Request Type Descriptions

unsigned long MICBytes;

unsigned char *MICData;

NUM_CCMP_DESC defines the number of descriptor s within the DPD_CCMP_GROUP that use this request. DPD_CCMP_GROUP (0x6500) defines the group for all descriptors within this request.

Table 29 . CCMP_REQ Valid Descriptors (opId)

Descriptors Value Function Description

DPD_802_11_CCMP_OUTBOUND 0x6500 Process an outbound CCMP packet

DPD_802_11_CCMP_INBOUND 0x8101 Process an inbound CCMP packet

4.11 SRTP Protocol Requests

4.11.1 SRTP_REQ

COMMON_REQ_PREAMBLE

unsigned long hashKeyBytes;

unsigned char *hashKeyData;

unsigned long keyBytes;

unsigned char *keyData;

SEC 2.0 Reference Device Driver User’s Guide, Rev. 0

Freescale Semiconductor PRELIMINARY—SUBJECT TO CHANGE WITHOUT NOTICE 35

Sample Code

unsigned long ivBytes;

unsigned char *ivData;

unsigned long HeaderBytes;

unsigned long inBytes;

unsigned char *inData;

unsigned long ROCBytes;

unsigned long cryptDataBytes;

unsigned char *cryptDataOut;

unsigned long digestBytes;

unsigned char *digestData;

unsigned long outIvBytes;

unsigned char *outIvData;

NUM_SRTP_DESC defines the number of descriptor s within the DPD_SRTP_GROUP that use this request. DPD_SRTP_GROUP (0x8500) defines the group for all descriptors within this request.

Table 30 . SRTP_REQ Valid Descriptors (opId)

Descriptors Value Function Description

DPD_SRTP_OUTBOUND 0x8500 Process an outbound SRTP packet

DPD_SRTP_INBOUND 0x8501 Process an inbound SRTP packet

5 Sample Code

The following sections provide sample codes for DES and IPSec.

5.1 DES Sample

/* define the User Structure */

DES_LOADCTX_CRYPT_REQ desencReq;

...

/* fill the User Request structure with appropriate pointers */

desencReq.opId = DPD_TDES_CBC_ENCRYPT_SA_LDCTX_CRYPT ;

desencReq.channel = 0; /* dynamic channel */

desencReq.notify = (void*) notifyDes; /* callback function */

desencReq.notify_on_error = (void*) notifyDes; /* callback in case of

errors only */

SEC 2.0 Reference Device Driver User’s Guide, Rev. 0

36 PRELIMINARY—SUBJECT TO CHANGE WITHOUT NOTICE Freescale Semiconductor

desencReq.status = 0;

desencReq.ivBytes = 8; /* input iv length */

desencReq.ivData = iv_in; /* pointer to input iv */

desencReq.keyBytes = 24; /* key length */

desencReq.keyData = DesKey; /* pointer to key */

desencReq.inBytes = packet_length; /* data length */

desencReq.inData = DesData; /* pointer to data */

desencReq.outData = desEncResult; /* pointer to results */

desencReq.nextReq = 0; /* no descriptor chained */

/* call the driver */

status = Ioctl(device, IOCTL_PROC_REQ, &desencReq);

/* First Level Error Checking */

if (status != 0) {

}

Sample Code

...

void notifyDes (void)

{

/* Second Level Error Checking */

if (desencReq.status != 0) {

}

..)

5.2 IPSEC Sample

/* define User Requests structures */

IPSEC_CBC_REQ ipsecReq;

....

/* Ipsec dynamic descriptor triple DES with SHA-1 authentication */

ipsecReq.opId = DPD_IPSEC_CBC_TDES_ENCRYPT_SHA_PAD;

ipsecReq.channel = 0;

ipsecReq.notify = (void *) notifyFunc;

ipsecReq.notify_on_error = (void *) notifyFunc;

ipsecReq.status = 0;

SEC 2.0 Reference Device Driver User’s Guide, Rev. 0

Freescale Semiconductor PRELIMINARY—SUBJECT TO CHANGE WITHOUT NOTICE 37

Sample Code

ipsecReq.hashKeyBytes = 16; /* key length for HMAC SHA-1 */

ipsecReq.hashKeyData = authKey; /* pointer to HMAC Key */

ipsecReq.cryptCtxInBytes = 8; /* length of input iv */

ipsecReq.cryptCtxInData = in_iv; /* pointer to input iv */

ipsecReq.cryptKeyBytes = 24; /* DES key length */

ipsecReq.cryptKeyData = EncKey; /* pointer to DES key */

ipsecReq.hashInDataBytes = 8; /* length of data to be hashed only */

ipsecReq.hashInData = PlainText; /* pointer to data to be

hashed only */

ipsecReq.inDataBytes = packet_length-8; /* length of data to be

hashed and encrypted */

ipsecReq.inData = &PlainText[8]; /* pointer to data to be

hashed and encrypted */

ipsecReq.cryptDataOut = Result; /* pointer to encrypted results */

ipsecReq.hashDataOutBytes = 20; /* length of output digest */

ipsecReq.hashDataOut = digest; /* pointer to output digest */

ipsecReq.nextReq = 0; /* no chained requests */

/* call the driver */

status = Ioctl(device, IOCTL_PROC_REQ, &ipsecReq);

/* First Level Error Checking */

if (status != 0) {

...

}

...

void notifyFunc (void)

{

/* Second Level Error Checking */

if (ipsecReq.status != 0) {

...

}

..)

SEC 2.0 Reference Device Driver User’s Guide, Rev. 0

38 PRELIMINARY—SUBJECT TO CHANGE WITHOUT NOTICE Freescale Semiconductor

Linux Environment

6Linux Environment

This section describe s the driver's adaptation to and interaction with the Linux operating system as applied to PPC processors

6.1 Installation

6.1.1 Driver Source

The SEC2 driver ins talls into Linux as a loadable module. To build the drive r as a module, it must be installed into the kernel s ource tree to b e include d in the ker nel build proc ess. The makefil e include d with the di stribution as sumes this inclusion. As delivered, this directory is define d as

Once the driver source is i nstalled, and the kerne l sourc e (and modules) a re buil t, module d ependency lis ts up dated, and the built objects are installed in the target filesystem, the driver, (named needed.

6.1.2 Device Inode

Kernel process es may cal l the dr iver' s func tionali ty di rectly. On the other hand, user proc esses mus t use th e kerne l's I/O interface to m ake driver requests. The only way for user processes to do t his it to open the device as a fi le with the open() system call to get a file descriptor , and t hen make reque sts through ioctl(). Thus the system will need a device file created to assign a name to the device.

[kernelroot]/drivers/sec2.

sec2drv.o) is rea dy for loa din g when

The driver functions as a number will be assigned dynamically , and that the minor number will always be zero, since only one instance of the driver is supported.

Creation of the devic e's naming i node may be done manual ly in a de velopment sett ing, or may be driven by a scr ipt that runs after the driver module loa ds, and before any user attempts to open a path to the driver. Assuming the module loaded with a dynamically assigned major number of 254 (look for shell command to accomplish this would normally appear as:

$ mknod c 254 0 /dev/sec2

Once this is done, user tasks can make requests to the driver under the device name /dev/sec2.

char device in the target system. As shipped, the driver assumes that the device major

sec2 in /proc/devices), then the

6.2 Operation

6.2.1 Driver Operation in Kernel Mode

Operation of th e SEC2 device under kernel mode is relatively straightforward. Once the driver module has loaded, which will initialize the device, direct calls to the the first two arguments may effectively be ignored.

In kernel mode, r equest completi on may be handled t hrough the st andard use of not ification c allbacks in the request. The example s uite av ail ab le w ith the dri ver sho w s how this may be acco m p lish ed ; this s uite u se s a mutex tha t the callback will relea se in order to allow the request to complete, although the cal ler may make use of any other type of event mechanism that suits their preference.

ioctl() entry (named SEC2_ioctl in the driver) can be made,

Logical to physical memory space tr an slation is handled internal to the driver.

SEC 2.0 Reference Device Driver User’s Guide, Rev. 0

Freescale Semiconductor PRELIMINARY—SUBJECT TO CHANGE WITHOUT NOTICE 39

VxWorks Environment

6.2.2 Driver Operation in User Mode

Operation of the SEC2 device in user mode is slightly more complex than in kernel mode. In particular , the transitio n from user to kerne l me mo r y sp ace creates two comp l icat i on s for use r mo de operation:

1. User memory buffers can't be passed directly to the driver; instead, in this driver edition, the user must allocate and place data in kernel memory buffer for operation. This can be accomplished via

SEC2_FREE, SEC2_COPYFROM, and SEC2_COPYTO requests (see Section 3.3.1, “I/O Control Codes” for

more information). Note: extreme ca ution must be exer cised by the user in transf errin g memory in this fashi on; ke rnel memory space may easily be corrupted by the caller, causing target system instability.

2. Standard notif ication callbacks cannot work, sinc e the routines to perform the callback are in user memory space, and cannot safely execute from kernel mode. In their place, standard POSIX signals can be used to indicate I/O completion by pla cing the process ID of the user task in the notification members of the request, and flagging indicate normal request completions, and SIGUSR2 to indicate error comp l eti ons .

The example s uite av ail ab le w ith the dri ver ill u stra tes the co ntra s t betw een the two different app lica tio n environments. Within the operations. Building the example testing applicati on with __KERNEL__ on (building a kernel mode test) shows the installation and usage of standard completion callbacks and a mutex used for interlock. Conversely, building the example test in g appl ic ation w ith setup.

NOTIFY_IS_PID in the notifyFlags member. The driver uses SIGUSR1 to

testAll.c file, there is a set of functions that shows the difference between the two

USERMODE turned on shows the installation of signal handlers and their proper

SEC2_MALLOC,

USERMODE, this example also shows one possi ble means for handling the user to ker nel memory transitio n via the

In use of three functions for transferring user buffers to and fr om kernel memory.

6.2.3 Driver Module License Macro

A common necessity of loadab le modul es for Li nux is the inclus ion of a li cense macr o (MODULE_LICENSE) that declares a string defining the type of license terms under which the module's code has been published. In the case of the SEC2 driver module, this code is delivered in sour ce form under the terms of a restricte d license agreement. Therefore, this macro has been passed a name of “Freescale Restricted” to acknowledge the existence of this agreement.

When loading the dr iver object, the e xistence of a non-GPL, non-BSD license string will cause a warning message to be printed to the console, stating that loading a module with a proprietary license will “taint” the kernel. This message is normal, expected, and will not cause any adverse operation of your running system.

7 VxWorks Environment

The following sections describe the installation of the SEC2 security processor software drivers, BSP integration, and distribution archives.

7.1 Installation

T o install the software drivers, extract the archive containing the dr iver source files into a suitable installa tion directory. If you want the driver and tests to be part of a standard VxWor ks source tree, place them in:

SEC 2.0 Reference Device Driver User’s Guide, Rev. 0

40 PRELIMINARY—SUBJECT TO CHANGE WITHOUT NOTICE Freescale Semiconductor

Driver: $(WIND_BASE)/target/src/drv/crypto

Porting

Tes ts :

$(WIND_BASE)/target/src/drv/crypto/test

Once the modules are installed, the driver image may be built per the following instructions.

7.2 Building the Interface Modules

Throughout the remainder of the installation instructions, the variables provided below are used:

Table 31. VxWorks Interface Module Variables

Variable Definition

CpuFamily Specifies the target CPU family, such as PPC85XX

ToolChain Specifies the tools, such as

SecurityProcessor Specifies the target security processor, should be

The followi ng ste ps are used to buil d driv er s and / or the dr ive r test and exercise code:

1. Go to the command prompt or shell

2. Execute

torVars to set up the T ornado command line build environment.

3. Run make in the driver or test installation directory by use of the following command:

make CPU=cpuFamily TOOL=toolChain SP=securityProcessor example: make CPU=PPC85XX TOOL=gnu SP=SEC2)

gnu

SEC2 for this driver

7.3 BSP Integration

Once the modul es are bu ilt, t hey shoul d be l inked di rectly with the u ser' s board suppor t pa ckage, to becom e inte gral part of the board image.

In VxWorks, the file

sysLib.c contains the initialization functions, the memory/address space functions, and the

bus interrupt functions. It is recommended to call the function SEC2DriverInit directly from sysLib.c. In the process of initialization, the driver calls a specialized function name

sysGetPeripheralBase(), which

returns a pointer to the base locati on of the peripheral device block in the processor (often defined by the CCSBAR register in some PowerQUICC I II proc essors) . The driv er uses t his a ddress a nd an of f set to l ocate the SEC2 core on the system bus. This i s not a sta ndard BSP func tion, the int egrator will need to provi de i t, or a subst itute metho d for locating CCSBAR.

The security processor will be initialized at board start-up, with all the other devices present on the board.

8 Porting

This section describe s probable areas of developer concern with respect to porting the driver to other operating systems or environments.

At this time, this driver has been ported to function on both VxWorks and Linux operating systems. Most of the internal functiona lity is independent of the construct s of a specific operating system, but there necessar ily are interface boundaries between them where things must be addressed.

SEC 2.0 Reference Device Driver User’s Guide, Rev. 0

Freescale Semiconductor PRELIMINARY—SUBJECT TO CHANGE WITHOUT NOTICE 41

Porting

Only a few of the files in the driver's source distribution contain specific dependencies on operating system compone nts; this is inten t io nal . Thos e s peci fic fi le s are:

Sec2Driver.h

•

sec2_init.c

•

sec2_io.c

•

8.1 Header Files

Sec2Driver.h

This header file is meant to be loc al (private ) to the driver it self, a nd as such, is r esponsi ble for inc luding a ll needed operating syste m head er files , and cas ts a seri es of m acro s fo r spec if ic sys te m call s

Of particular interest, this header casts local equivalents macros for:

malloc Allocate a block of system memory with the operating system's heap allocation mechanism. free Return a block of memory to the system heap semGive Release a mutex semaphore semTake Capture and hold a mutex semaphore __vpa Translate a logical address to a physical address for hardware DMA (if both are equivalent, does nothing).

8.2 C Source Files

sec2_init.c performs the basic initi alization of the device and the driver. It is responsible for fi nding the base

address of the hardware and savi ng it in IOBaseAddress for later reference. For Linux, this file also contains references to register/unregister the driver as a kernel module, and to manage it's

usage/link count.

sec2_io.c contains functions to establish:

• Channel interlock semaphores (

• The ISR message queue (

• Driver service function registration with the operating system (

• ISR connection/disconnectio n (

IOInitSemaphores)

IOInitQs)

IORegisterDriver)

IOConnectInterrupt)

8.3 Interrupt Service Routine

The ISR will queue proc essing completion r esult messages ont o the IsrMsgQId queue. ProcessingComplete() pends on this messa ge queue. When a message is receiv ed, the compl etion task will e xecute the a ppropriate callback routine based on the result of the processing. When the end-user application prep ares the request to be executed, callback functions can be defined for nominal processing as well as error case processing. If the callback function was set to executed as part of the device driver so any constraints placed on the device driver will also be placed on the callback routines.

NULL when the request was prepared then no callback function will be executed. These routines will be

SEC 2.0 Reference Device Driver User’s Guide, Rev. 0

42 PRELIMINARY—SUBJECT TO CHANGE WITHOUT NOTICE Freescale Semiconductor

Porting

8.4 Conditional Compilation

See the makefile for specifics on the default build of the driver

8.5 Debug Messaging

The driver include s a DBG define that allows for debug messa ge output to the developer's console. If defined in the driver build, debug messages will be sent from various components in the driver to the console.

Messages come from various sections of the driver, and a bitmask is kept in a driver global variable so that the developer can tu rn message s ources on or off as required. This gl obal is na med ORed combination of any of the following bits:

DBGTXT_SETRQ Messages from request setup operations (new requests inbound from the application). DBGTXT_SVCRQ Messages from servicing device responses (ISR/deferred service routine handlers)

outbound to the application.

DBGTXT_INITDEV Messages from the device/driver initialization process. DBGTXT_DPDSHOW Shows the content of a constructed DPD before it is handed to the security core. DBGTXT_INFO Shows a short banner at device initialization describing the driver and hardware version.

In normal driver operation (not in a development setting), the DBG definition should be left undefined for best performance.

SEC2DebugLevel, and contains an

8.6 Distribution Archive

For this release, the dist ributio n archive consists of the source files listed in thi s section. Note tha t the user may wish to reorganize header file locations consistent with the file location conventions appropriate for their system configuration.

Header Description

Sec2.h Primary public header file for all users of the driver Sec2Driver.h Driver/Hardware interfaces, private to the driver itself Sec2Descriptors.h DPD type definitions Sec2Notify.h Structures for ISR/main thread communication sec2_dpd_Table.h DPD construction constants sec2_cha.c CHA mapping and management sec2_dpd.c DPD construction functionality sec2_init.c Device/driver initialization code sec2_io.c Basic register I/O primitives sec2_ioctl.c Operating system interfaces sec2_request.c Request/response management sec2_sctrMap.c Scatter buffer identification and mapping sec2isr.c Interrupt service routine

SEC 2.0 Reference Device Driver User’s Guide, Rev. 0

Freescale Semiconductor PRELIMINARY—SUBJECT TO CHANGE WITHOUT NOTICE 43

How to Reach Us:

Home Page:

www.freescale.com

email:

support@freescale.com

USA/Europe or Locations Not Listed:

Freescale Semiconductor Technical Information Center, CH370 1300 N. Alma School Road Chandler, Arizona 85224 (800) 521-6274 480-768-2130 support@freescale.com

Europe, Middle East, and Africa:

Freescale Halbleiter Deutschland GmbH Technical Information Center Schatzbogen 7 81829 Muenchen, Germany +44 1296 380 456 (English) +46 8 52200080 (English) +49 89 92103 559 (German) +33 1 69 35 48 48 (French) support@freescale.com

Japan: Freescale Semiconductor Japan Ltd. Headquarters ARCO Tower 15F 1-8-1, Shimo-Meguro, Meguro-ku Tokyo 153-0064, Japan 0120 191014 +81 2666 8080 support.japan@freescale.com

Asia/Pacific:

Freescale Semiconductor Hong Kong Ltd. Technical Information Center 2 Dai King Street Tai Po Industrial Estate, Tai Po, N.T., Hong Kong +800 2666 8080 support.asia@freescale.com

For Literature Requests Only:

Freescale Semiconductor

Literature Distribution Center P.O. Box 5405 Denver, Colorado 80217 (800) 441-2447 303-675-2140 Fax: 303-675-2150 LDCForFreescaleSemiconductor

@hibber tgr oup.com

Information in this document is provided solely to enable system and software

implementers to use Freescale Semiconductor products. There are no express or

implied copyright licenses granted hereunder to design or fabricate any integrated

circuits or integrated circuits based on the information in this document.

Freescale Semiconductor reserves the right to make changes without further notice to

any products herein. Freescale Semiconductor makes no warranty, representation or

guarantee regarding the suitability of its products for any part icular purpose, nor does

Freescale Semiconductor assume any liability arising out of the application or use of

any product or circuit, and specifically disclaims any and all liability, including without

limitation consequential or incidental damages. “Typical” parameters which may be

provided in Freescale Semiconductor data sheets and/or specifications can and do

vary in different applications and actual performance may vary over time. All operating

parameters, including “Typicals” must be validated for each customer application by

customer’s technical experts. Freescale Semiconductor does not convey any license

under its patent rights nor the rights of others. Freescale Semiconductor products are

not designed, intended, or authorized for use as components in systems intended for

surgical implant into the body, or other applications intended to support or sustain life,

or for any other application in which the failure of the Freescale Semiconductor product

could create a situation where personal injury or death may occur. Should Buyer

purchase or use Freescale Semiconductor products for any such unintende d or

unauthorized application, Buyer shall indemnify and hold Freescale Semiconductor

and its officers, employees, subsidiaries, affiliates, and distributors harmless against all

claims, costs, damages, and expenses, and reasonable attor ney fees arising out of,

directly or indirectly, any claim of personal injury or death associated with such

unintended or unauthorized use, even if such claim alleges that Freescale

Semiconductor was negligent regarding the design or manufacture of th e part.

Freescale™ and the Freescale logo are trademarks of Freescale Semiconductor, Inc. The PowerPC name is a trademark of IBM Corp. and is used under license. All other product or service names are the p roperty of their respective owners.

SEC2SWUG Rev. 0 02/2005

PRELIMINARY—SUBJECT TO CHANGE WITHOUT NOTICE

Freescale Semiconductor SEC2SWUG User Manual

Specifications and Main Features

Frequently Asked Questions

User Manual

SEC 2.0 Reference Device Driver User’s Guide

1Overview

Table 1. Acronyms and Abbreviations

2 Device Driver Components

2.1 Device Driver Structure

2.1.1 Driver Initialization Routine

2.1.2 Request Dispatch Routine

2.1.3 Process Request Routine

2.1.4 Interrupt Service Routine

2.1.5 Deferred Service Routine

3 User Interface

3.1 Application Interface

3.2 Error Handling

3.3 Global Definitions

3.3.1 I/O Control Codes

Table 2. Second and Third Arguments in the ioctl Function

3.3.2 Channel Definitions

Table 3. Channel Defines

3.3.3 Operation ID (opId) Masks

Table 4. Request Operation ID Mask

3.3.4 Return Codes

Table 5. Callback Error Status Return Code

3.3.5 Miscellaneous Request Structures

3.3.5.1 STATUS_REQ Structure

3.3.5.2 SEC2_NOTIFY_ON_ERROR_CTX Structure

3.3.6 Process Request Structures

3.3.7 Scatter-Gather Buffer Management

3.3.7.1 Building the Local Scatter/Gather List with EXT_SCATTER_ELEMENT

3.3.7.2 Scatter Buffer Marking

3.3.7.3 Direct Scatter-Gather Usage Example

4 Individual Request Type Descriptions

4.1 Random Number Requests

4.1.1 RNG_REQ

Table 6. RNG_REQ Valid Descriptor (opId)

4.2 DES Requests

4.2.1 DES_CBC_CRYPT_REQ

Table 7. DES_CBC_CRYPT_REQ Valid Descriptors (opId)

4.2.2 DES_CRYPT_REQ

Table 8. DES_CRYPT_REQ Valid Descriptors (opId)

4.3 ARC4 Requests

4.3.1 ARC4_LOADCTX_CRYPT_REQ

Table 9. ARC4_LOADCTX_CRYPT_REQ Valid Descriptor (opId)

4.3.2 ARC4_LOADKEY_CRYPT_UNLOADCTX_REQ

Table 10. ARC4_LOADKEY_CRYPT_UNLOADCTX_REQ Valid Descriptor (opId)

4.4 Hash Requests

4.4.1 HASH_REQ

Table 11 . HASH_REQ Valid Descriptors (0x4400) (opId)

Table 12. HASH_REQ Valid Descriptors (0x4500) (opId)

4.5 HMAC Requests

4.5.1 HMAC_PAD_REQ

Table 13 . HMAC_PAD_REQ Valid Descriptors (opId)

4.6 AES Requests

4.6.1 AESA_CRYPT_REQ

Table 14 . AESA_CRYPT_REQ Valid Descriptors (opId)

4.7 Integer Public Key Requests

4.7.1 MOD_EXP_REQ

Table 15. MOD_EXP_REQ Valid Descriptor (opId)

4.7.2 MOD_SS_EXP_REQ

Table 16. MOD_SS_EXP_REQ Valid Descriptor (opId)

4.7.3 MOD_R2MODN_REQ

Table 17. MOD_R2MODN_REQ Valid Descriptor (opId)

4.7.4 MOD_RRMODP_REQ

Table 18. MOD_RRMODP_REQ Valid Descriptor (opId)

4.7.5 MOD_2OP_REQ

Table 19. MOD_2OP_REQ Valid Descriptors (opId)

4.8 ECC Public Key Requests

4.8.1 ECC_POINT_REQ

Table 20. ECC_POINT_REQ Valid Descriptors (opId)

4.8.2 ECC_2OP_REQ

Table 21. ECC_2OP_REQ Valid Descriptors (opId)

4.8.3 ECC_SPKBUILD_REQ

Table 22. ECC_SPKBUILD_REQ Valid Descriptor (opId)

4.8.4 ECC_PTADD_DBL_REQ

Table 23. ECC_PTADD_DBL_REQ Valid Descriptor (opId)

4.9 IPSec Requests

4.9.1 IPSEC_CBC_REQ
