Freecom 22767, 25376 Datasheet
Freecom USB Floppy Disk Drive
www.freecom.com
Read and write your 3.5" floppy disks without the fear
of virus infections!
Nowadays, most computers and notebooks
are shipped without a floppy drive. However,
the need for a floppy drive still exists; the old,
trustw
or
thy 3.5" floppy disk is still one of the
most used media types in the world. Small
files like drivers, software updates, patches for
operating systems, anti-virus updates and
boot-diskettes are still being shipped on
floppy disks. Also, a lot of people still have old
text files, spreadsheets, pictures etc saved on
floppy disks. So there will always come a time
when you need a floppy drive for a software
update, to access some of your old data, or
you need a diskette to quickly save a small file
on. The new Freecom External USB Floppy
Drive is all that you need. Affordable, easy to
use, lightweight: very portable and very
convenient. Installing the USB floppy drive
could not be easier: Just plug it into the USB
port
o
f your computer and you're ready to go!
The Freecom External USB Floppy Drive is also
a very cost-effective replacement for when
y
our e
xisting floppy drive is broken.
Powered through your USB port, this USB
floppy drive gets you up and running in
sec
onds.
Keep it simple!
Freecom USB Floppy Disk Drive
• Ultra small, lightweight black design floppy disk drive.
• Low noise, due to high quality materials.
• Hot swappable. No need to restart when connect or disconnect.
• Simple connection via USB cable.
• USB Bus powered. No AC adapter needed.
• Bootable with most notebook and desktop computers.
• Perfect for file transfer and file backup.
• Supports both 720 KB and 1.44 MB floppy formats.
• No driv
er needed f
or
W
indo
w
s ME/
X
P and Mac.
• All F
reecom devices meet the highest industry standards.
• Including 2 3.5" High Density floppy disks.
• Including Roxio's PhotoSuite (promotional version*).
• Including a
w
ar
d winning F-
Secure anti-virus, firewall software
(promotional software**).
• Two years manufacturers warranty.
www.freecom.com
ref. MM/FG/08-07-2005
Freecom USB Floppy Disk Drive
Art. No. EU/UK 22767 25376
EAN Code EU/UK 4021801227676 4021801253767
Color
Black White
Cable Type USB USB
Freecom USB Floppy Disk Drive
Product Specifications P
ortable external USB Floppy Disk Drive
C
apacity
720 kB/1.44 MB
Media standards 3.5’’Floppy Disks, double sided high-density,double-sided density
Interface USB 1.1 (12 Mbit/s)
Performance Spindle speed: 300 U/min
Shock 5G max., non-operating:100G max.
MTBF 30.000 POH
Safety Standards UL standard, CS A standard,TÜV standard, CE standard
Size Height 1.7 cm x Width 10.3 cm x Length 14.2 cm
W
eight
2
80 grams
Environmental specifications Operating +5° to +50°
Storage -20° to 60°
Gradient 20° C/hour (max.)
Humidity Operating 8 - 80% (noncondensing)
Package includes • Freecom USB Floppy Disk Drive
• Two 3.5” floppy disks
• F
reecom Driver (Windows ‘98/2000) and manual on CD
• Roxio's PhotoSuite for Windows (30 days promotional version*)
• F-Secure Internet Security 2004 for Windows (90 days promotional version**)
• Quick Install Guide
• 2 Years manufacturers warranty
System requirements Any PC with a free USB port, running Windows 98SE,Windows 2000, Windows ME,Windows XP or
Mac OS 9/10.x
Power r
equirements
Bus-powered (No AC-adapter needed).
F-Secure Internet Security 2004 includes an award winning anti-virus software,
as well as an easy-to-use personal firewall product that protects your computer
ag
ainst
br
eak
-in a
ttempts when y
ou are connected to the Internet. With
F-
Secur
e y
ou can surf on the Internet, open e-mail attachments and use your
computer without fear of virus infections or hackers.You can also be sure that
you are not sending viruses to others. Just install and forget, F-Secure Internet
Security 2004 will automatically keep viruses and hackers away from your
computer.
** The free promotion bundle works for 90 days. In this period you can clean
your computer and floppy disks, check attachments and surf the internet
without
f
ear
.
A
fter this period you can buy F-Secure Internet Security 2004 via
a c
on
venient upgrade procedure.You will automatically recieve 5% discount !
Floppy Windows Macintosh
XP 2000 ME 98/98SE 9.x X (10.x)
1.44MB (2HD)
••••••
Windows
1.25MB (2HD)
•
x
x
W
indows
720KB (2DD)
•
•
•••
Windows
1.44MB (2HD)
xxxx
•
Macintosh
• R
ead/
W
rite/Format Read/Write x Not Working
C
ompa
tibility Table Freecom USB Floppy Disk Drive
* Roxio's PhotoSuite; for photo editing without the learning curve. Transfer photos from your digital camera, organize them in electronic albums, and share them through
E-mail, print, online services or on CD. This free promotional software works 30 days only. After 30 days you can easily upgrade by selecting the upgrade icon.
