Product Sheet
Flex B-20
fractal-design.com
3
Overview
Index
4
5
Key features
Specifications
Package contents
Additional information
fractal-design.com
Flex B-20Product Sheet
Flex B-20
The Rise of the GPU
The Flex B-20 bracket is a great supplement to your case, allowing you to
mount your GPU vertically. This makes Flex B-20 an attractive companion to
select Fractal cases like the Define 7 and the Define 7 XL.
3
Flex B-20Product Sheet
Key features
• Fits ATX cases with bridgeless expansion slot covers (no bars between slots), such as the Define 7, the Define 7 XL and many others
• Supports full-length GPUs with single or dual-slot brackets and coolers of any size
• Places the GPU away from the side panel
• Mounts easily with included captive thumbscrews
• Full PCIe 3.0 x16 support offering uncompromised performance
• Heavy-duty double-sided wiring delivers up to 3x the power of traditional riser cables (auxiliary power connections are recommended for devices over 40W TDP)
Specifications
4
GPU support
Case requirements
Captive thumbscrews
PCIe standard
Cable length
Cable width
Cable color
Bracket color
Product dimensions (LxWxH)
Dimensions w/o protrusions/screws
Net weight
Package dimensions (LxWxH)
Package weight
Warranty
＊ If you wish to use the Flex B-20 PCIe 3.0 riser cable together with a PCIe 4.0
compatible motherboard and graphics card, make sure you first set the PCIe
Slot Configuration in your motherboard BIOS or UEFI to PCIe Gen3 for best
system stability.
• Any PCIe compatible card with single or dual-slot bracket (no maximum cooler height)
• 7 available bridgeless expansion slots (no bars between slots when covers are removed)
• Two, for installation of the riser into the case
• PCIe Gen 3.0 x16*
• 200 mm
• 57 mm
• Matte Black
• Black powder coated steel
• 182 x 134 x 145 mm
• 182 x 125 x 145 mm
• 248 g
• 230 x 168 x 56 mm
• 360 g
• 2 years
Product Sheet Flex B-20 5
Package contents
• Vertical GPU bracket with 2 x captive thumbscrews
• PCIe Riser cable 200 mm
• 2x (M3) screws (for riser cable)
• 2x (6-32) thumbscrews (for GPU)
• 2x (6-32*5 mm) screws (to mount brackets together)
• User manual
Additional information
Product
Flex B-20
SKU
FD-A-FLX1-001
EAN
7340172702689
UPC
843276102685
JAN
4537694280112
