Product Sheet
Define R5 - Definition of Silence
The Fractal Design Dene R5 is the next evolution in the widely popular Dene Series. Packed with intelligently designed enthusiast-oriented features delivering a silent case with powerful and expansive air and
liquid cooling support, presented in a stunning Scandinavian inspired construction.
The Dene R5 case reaches the highest level of silent computing through strategically placed dense soundabsorbing material, ModuVent™ fan vent covers and nely tuned Dynamic Series fans.
The Dene R5 was designed with congurability in mind, accommodating up to 8 hard drives and all modern
graphics cards. Should you wish to expand your system with water cooling components or more fans the
layout can easily be congured to meet your demand.
Key features
• Optimally designed for silent computing with high density noise-reducing material throughout the case for
maximum sound absorption, while not compromising on airow and cooling capabilities.
• Extensive water cooling support for a case of this size; housing radiators up to 420mm in the top and
360mm in the front.
• Equipped with new tool-less ModuVent™ fan slot covers allowing the user to install more fans if desired
or keep fan slots covered to maximize sound absorption.
• Including two Fractal Design Dynamic GP14 140mm
fans developed for superlative airow while still maintaining low noise levels.
• Maintaining a dust-free interior with the help of dust
lters that cover front and bottom air intakes that are
easy to access from the front on the case.
• Newly congured front door with dual side mounting to
better t your work space.
• Three-speed fan controller is strategically integrated in
the front panel and supports up to 3 fans.
Fractal Design brings you Scandinavian design and quality
www.fractal-design.com
Product Sheet
• Highlighting 2 dedicated SSD mounts cleanly placed behind the motherboard tray that feature innovative
new brackets delivering a tool-free installation and removal
• The HDD cage system holds up to eight 3.5” or 2.5” drives and is more adaptable than ever, allowing the
user to modify the case layout according to personal preference with more places to relocate the cages
• The ODD cage can easily be removed to gain additional interior space; the area can be freed up to allow
for increased airow, to provide a new place for HDD cage mounting or to make more room for water
cooling components.
• Sturdy metal HDD trays provide excellent dampening features for the hard drives while providing better
airow through the cage with an updated, more open design
• The new and innovative Quick Release System on the left side of the case provides secure mounting of
the left side panel, yet grants quick and easy access to the system.
• Dene R5 model is available with window side panel
Description Art. Number EAN Code UPC Code
Fractal Design Dene R5 Black FD-CA-DEF-R5-BK 7350041082583 817301012584
Fractal Design Dene R5 Black Window FD-CA-DEF-R5-BK-W 7350041082590 817301012591
Fractal Design Dene R5 Titanium FD-CA-DEF-R5-TI 7350041082606 817301012607
Fractal Design Dene R5 Titanium Window FD-CA-DEF-R5-TI-W 7350041082613 817301012614
Fractal Design Dene R5 White FD-CA-DEF-R5-WT 7350041082620 817301012621
Fractal Design Dene R5 White Window FD-CA-DEF-R5-WT-W 7350041082637 817301012638
Fractal Design brings you Scandinavian design and quality
www.fractal-design.com
Product Sheet
General Specifications
Drive bay capacity • 2 - 5.25” bays (removable)
• 8 - 3.5" HDD positions (can also accommodate 2.5"
units)
• 2 - additional 2.5" dedicated SSD unit positions
Expansion slots • 7
Motherboard compatibility • ATX
• Micro ATX
• Mini ITX
Cooling / Ventilation • 9 - Fan positions (2 Fractal Design Dynamic GP14
140mm fans included)
• Filtered fan slots in front and bottom
• CPU coolers up to 180 mm in height
Front interface • 2 USB 3.0 + 2 USB 2.0
• Audio in/out
• Power button with LED (blue)
• HDD activity LED (blue)
• Reset button
Power supply compatibility • ATX PSUs up to 190/170 mm with a bottom
120/140mm fan installed
• When not using any bottom fan location longer PSUs
up to 300mm can be used
Graphics card compatibility • Graphics cards up to 310 mm in length with the top
HDD cage installed
• With the top cage removed, graphics cards up to 440
mm in length may be installed
Additional information • 20 to 35 mm of space for cable routing behind the
motherboard plate
• Velcro straps included for easy cable management
• Front door can switch opening direction
• Left side panel has a Quick Release System for easy
access and provides a secure closure of side panel
• Right side panel features smart captive thumbscrews
Colors Available • Black
• Titanium (Black case, Titanium front panel)
• White
Case dimensions - W x H x D (mm) • 232 x 451 x 521
Case dimensions - with feet/protrusions/screws
(mm)
Net weight (kg) • 11.2 kg
Package dimensions - W x H x D (mm) • 327 x 615 x 540
Package weight – (Kg) • 12.8 kg
• 232 x 462 x 531
Fractal Design brings you Scandinavian design and quality
www.fractal-design.com
Product Sheet
Cooling System
Front • 2 – 120/140 mm fans (included is 1 Fractal Design Dynamic GP14 fan, 1000
RPM speed)
Rear • 1 – 120/140 mm fan (included is 1 Fractal Design Dynamic GP14 fan, 1000 RPM
speed)
Top • 3 - 120/140 mm fan (not included)
Bottom • 2 – 120/140 mm fan (not included)
Side • 1 – 120/140 mm fan (not included)
Water cooling compatibility • Front – 360, 280, 240, 140 and 120 mm radiators of all thicknesses
(requires removal of drive bays)
• Top – 420, 360, 280, 240, 140 and 120 mm radiators.
(A thickness limitation of 55mm for both radiator+fan applies on 420, 280 and
140 mm radiators)
(420 and 360 mm radiators require removal of the ODD bay)
• Bottom – 120 or 240 mm radiator (Use of radiators in the bottom position limits
the PSU length to 165 mm)
• Rear – 120 or 140 mm radiator
Fan controller • 3 step fan controller for up to 3 fans
Dust lters • Bottom and front intakes
Fractal Design brings you Scandinavian design and quality
www.fractal-design.com
