Page 1
Product Sheet
Define 7 XL
fractal-design.com
Page 2
3
Overview
Index
4
5-6
7
Key features
General specifications
Package contents
Additional information
fractal-design.com
Page 3
Define 7 XLProduct Sheet
Define 7 XL
Re-defining capacity.
The Define 7 XL sets a new standard for what you should expect from a full
tower case in terms of modularity, flexibility and ease of use.
With its dual-layout interior, industrial sound damping and massively versatile
layout supporting the largest E-ATX and enterprise boards, multi-GPU setups,
outlandish water loops, and almost two dozen storage devices (in Storage
layout), you’ll be hard pressed to find a limit to what you can do with your
build in the Define 7 XL.
3
Page 4
Define 7 XLProduct Sheet
Key features
• Spacious, extensively adaptable dual-layout interior easily accommodates large motherboards up to E-ATX and SSI-EEB
• Mount up to 18 HDD/SSDs plus five SSDs in the Storage Layout (6 HDD/SSD trays + 2 SSD brackets + 2 multi-brackets included)
• Use the Open Layout for more headroom and gargantuan water-cooling with radiators up to 480 mm in front or top and 280 mm in the base
• Two 5.25” ODD bays can be converted to an additional front fan mount with filtered louver covering
• Silence-optimized construction with industrial sound-damped front, top, and side panels
• Top panel effortlessly swaps from sound damped solid steel to filtered ventilation
• New chassis design opens up to fully expose the case interior on three sides for totally unhindered installation and cable routing
• Anodized aluminum front panel with reversible dual-handed hinges opens and closes easily with magnetic latching
• Outstanding cooling capacity with a total of 9 x 140 mm or 11 x 120 mm fan mounts and three preinstalled Dynamic X2 GP-14 fans
• Versatile new multi-brackets convert any unused fan position to an HDD, SSD or pump mount
• Three vertical GPU slots for use with the Flex VRC-25 PCIe riser, available separately
• Five front USB ports including one USB 3.1 Gen 2 Type-C with fast charging support and speeds up to 10Gbps
• Ultra-slim Nexus+ 2 fan hub connects up to three PWM fans and six 3-pin fans directly in line with cable channels along the edge of the case
• Sturdy new HDD cage design with vibration damped trays
• Tool-less, top-latching panels allow quick access while preventing accidental drops
• Bridgeless expansion slots ensure obstruction-free connections for easier installation and hookup
• Ventilated PSU shroud with two-part removable cover
• Easy-to-clean high airflow nylon filters on the front, top, and base with full PSU coverage and convenient front access
• 13 pass-through holes with ten rubber grommets and two removable covers make for clean cable routing regardless of motherboard size
• Detachable PSU cable shield and integrated cable guides with Velcro straps further simplify cable management behind the board
4
Page 5
Product Sheet
Define 7 XL 5
General specifications
3.5"/2.5" drive mounts
Dedicated 2.5" drive mounts
5.25” drive mounts
Expansion slots
Motherboard compatibility
Power supply type
Front interface
Total fan mounts
Front fan
Top fan
Rear fan
Bottom fan
Dust filters
Front radiator
Top radiator
Rear radiator
Bottom radiator
PSU max length
GPU max length
• 6 + 2 included, 18 positions total
• 2 included, 5 positions total
• 2
• 9 + 3
• E-ATX / ATX / mATX / mITX / EE-ATX / SSI-CEB / SSI-EEB
• ATX
• 1 x USB 3.1 Gen 2 Type-C, 2 x USB 3.0, 2 x USB 2.0,
Audio I/O, Power button, Reset button
• 11 x 120 mm or 9 x 140 mm
• 4 x 120 mm or 3 x 140 mm, (2 x Dynamic X2 GP-14 included)
• 4 x 120 mm or 3 x 140 mm
• 1 x 120/140 mm, (1 x Dynamic X2 GP-14 included)
• 2 x 120/140 mm
• Top, 2 x Front, Bottom + PSU
• Up to 480/420 mm
• Up to 480/420 mm
• 120 mm
• Up to 240/280 mm
• 250 mm (both HDD cages installed)
• Storage layout: 359 mm
• Open layout: 549 mm (524 mm w/ front fan)
Page 6
Product Sheet Define 7 XL
General specifications
6
CPU cooler max height
Cable routing space
Cable routing grommets
Fixed Velcro straps
Tool-less push-to-lock
Captive thumbscrews
Left side panel
Right side panel
Case dimensions (LxWxH)
Case dimensions w/o feet/protrusions/screws
Net weight
Package dimensions (LxWxH)
Gross weight
• 185 mm
• 30 mm
• Yes
• Yes
• Both side panels and top
• HDD brackets, SSD brackets, PSU bracket
• Industrial sound-damped steel or Tempered glass
• Industrial sound-damped steel
• 604 x 240 x 566 mm
• 590 x 240 x 548 mm
• TG: 16.64 kg
• Solid: 16.53 kg
• 646 x 357 x 708 mm
• TG: 18.84 kg
• Solid: 18.73 kg
Page 7
Product Sheet Define 7 XL 7
Package contents
• Define 7 XL
• Accessory box
• User manual
• Ventilated top panel
• ODD bracket
• ODD bay cover
• 2 x HDD/SSD trays
Additional information
Product
Define 7 XL Black Solid
Define 7 XL Black TG Light Tint
Define 7 XL Black TG Dark Tint
SKU
FD-C-DEF7X-01
FD-C-DEF7X-02
FD-C-DEF7X-03
EAN
7340172702047
7340172702054
7340172702061
UPC
843276102043
843276102050
843276102067
JAN
4537694274296
4537694274302
4537694275385
