Foxconn A7GM-S User Manual

A7GM-S 2.0 Motherboard

User’s Manual

Statement:

This manual is the intellectual property of Foxconn, Inc. Although the information

in this manual may be changed or modied at any time, Foxconn does not obligate

itself to inform the user of these changes.

Trademark:

All trademarks are the property of their respective owners.

Version:

User’s Manual V1.0 for A7GM-S 2.0 motherboard.

P/N: 3A2216200-000-G

Symbol description:

Caution: refers to important information that can help you to use motherboard

better, and tells you how to avoid problems.

Warning: indicating a potential risk of hardware damage or physical injury may

exist.

WEEE:

The use of this symbol indicates that this product may not be treated as household

waste. By ensuring this product is disposed of correctly, you will help prevent potential

negative consequences for the environment and human health, which could other-

wise be caused by inappropriate waste handling of this product. For more detailed

information about recycling of this product, please contact your local city ofce, your

household waste disposal service or the shop where you purchased this product.

More information:

If you want more information about our products, please visit Foxconn’s

website: http://www.foxconnchannel.com

All trade names are registered trademarks of respective manufacturers listed.

All images are for reference only, please refer to the physical motherboard for specic features.

Declaration of conformity

HON HAI PRECISION INDUSTRY COMPANY LTD

66 , CHUNG SHAN RD., TU-CHENG INDUSTRIAL DISTRICT,

TAIPEI HSIEN, TAIWAN, R.O.C.

declares that the product

Motherboard A7GM-S 2.0

is in conformity with

(reference to the specication under which conformity is declared in

accordance with 89/336 EEC-EMC Directive)

■ EN 55022:1998/A2:2003 Limits and methods of measurements of radio

disturbance characteristics of information technology equipment

■ EN 61000-3-2/:2000

Electromagnetic compatibility (EMC)

Part 3: Limits Section 2: Limits for harmonic current emissions (equipment input current <= 16A per phase)

■ EN 61000-3-3/A1:2001

Electromagnetic compatibility (EMC)

Part 3: Limits

Section 2: Limits of voltage uctuations and icker in low

voltage supply systems for equipment with rated current <= 16A

■ EN 55024/A2:2003 Information technology equipment-Immunity

characteristics limits and methods of measurement

Signature :

Place / Date : TAIPEI/2008

Printed Name : James Liang

Declaration of conformity

Trade Name: FOXCONN

Model Name:

A7GM-S 2.0

Responsible Party: PCE Industry Inc.

Address: 458 E. Lambert Rd.

Fullerton, CA 92835

Telephone: 714-738-8868

Facsimile: 714-738-8838

Equipment Classication: FCC Class B Subassembly

Type of Product: Motherboard

Manufacturer: HON HAI PRECISION INDUSTRY

COMPANY LTD

Address: 66 , CHUNG SHAN RD., TU-CHENG

INDUSTRIAL DISTRICT, TAIPEI HSIEN,

TAIWAN, R.O.C.

Supplementary Information:

This device complies with Part 15 of the FCC Rules. Operation is subject to the following

two conditions : (1) this device may not cause harmful interference, and (2) this device

must accept any interference received, including interference that may cause undesired

operation.

Tested to comply with FCC standards.

Signature : Date : 2008

Installation Precautions

Please carefully read the following procedures to install your computer :

■ It is suggested to select high-quality, certied fans in order to avoid damage

to the motherboard and CPU due to high temperature. Never turn on the

computer if the CPU fan is not properly installed.

■ We cannot guarantee that your system can operate normally when your

CPU is overclocked. Normal operation depends on the overclocking capac-

ity of your device.

■ If there is any, when connecting USB, audio, 1394a, RS232 COM, IrDA or

S/PDIF cables to the internal connectors on the motherboard, make sure

their pinouts are matching with the connectors on the motherboard. Incorrect

connections might damage the motherboard.

■ When handling the motherboard, avoid touching any metal leads or connec-

tors.

■ If there is a PCI Express x16 graphics card installed in your system, we

recommend using a 24-pin ATX power supply to get the best performance.

■ Before turning on the power, please make sure the power supply AC input

voltage setting has been congured to the local standard.

■ To prevent damage to the motherboard, do not allow screws to come in contact

with the motherboard circuit or its components. Also, make sure there are no

leftover screws or metal components placed on the motherboard or within the

computer casing.

■ If you are uncertain about any installation steps or have a problem related to

the use of the product, please consult a certied computer technician.

■ Electrostatic discharge (ESD) is the sudden and momentary electric current

that ows between two objects at different electrical potentials. Normally it

comes out as a spark which will quickly damage your electronic equipment.

Please wear an electrostatic discharge (ESD) wrist strap when handling

components such as a motherboard, CPU or memory.

■ Ensure that the DC power supply is turned off before installing or removing

CPU, memory, expansion cards or other peripherals. It is recommended to

unplug the AC power cord from the power supply outlet. Failure to unplug

the power supply cord may result in serious damage to your system.

TABLE OF CONTENTS

Chapter 1 Product Introduction

Product Specications ..................................................................

Layout ...........................................................................................

Back Panel Connectors ................................................................ 5

Chapter 2 Hardware Install

Install the CPU and CPU Cooler ..................................................

Install the Memory ......................................................................10

Install an Expansion Card .......................................................... 12

Install other Internal Connectors ................................................ 13

Jumpers ......................................................................................17

Chapter 3 BIOS Setup

Enter BIOS Setup ....................................................................... 20

Main Menu ..................................................................................20

System Information .................................................................... 22

Advanced BIOS Features ........................................................... 24

Fox Central Control Unit ............................................................. 26

Advanced Chipset Features .......................................................31

Integrated Peripherals ................................................................35

Power Management Setup ......................................................... 40

PC Health Status ........................................................................

BIOS Security Features .............................................................. 43

Load Optimal Defaults ................................................................ 44

Save & Exit Setup ...................................................................... 44

Exit Without Saving ....................................................................44

Chapter 4 CD Instruction

Utility CD content ........................................................................46

Install driver and utility ................................................................ 47

FOX ONE

Main Page ............................................................................. 49

CPU Control .......................................................................... 53

Frequency Control ................................................................55

Limit Setting ..........................................................................56

Voltage Control .....................................................................58

Fan Control ...........................................................................59

FOX LiveUpdate

Local Update ......................................................................... 60

Online Update ....................................................................... 62

Congure .............................................................................65

About & Help ......................................................................... 67

FOX LOGO .................................................................................68

FOX DMI .................................................................................... 69

Chapter 5 RAID Conguration

RAID Conguration Introduction ................................................. 72

FastBuild Driver .......................................................................... 74

Create a RAID Driver Diskette ................................................... 76

RAID Enable in BIOS .................................................................78

Select a RAID Array for Use .......................................................78

Install a New Windows XP.......................................................... 91

Setting Up a Non-Bootable RAID Array ...................................... 95

Technical Support :

Website :

http://www.foxconnchannel.com

Support Website :

http://www.foxconnsupport.com

Worldwide online contact Support :

http://www.foxconnchannel.com/support/online.aspx

CPU, Memory, VGA Compatibility Supporting Website :

http://www.foxconnchannel.com/product/Motherboards/compatibility.aspx

Support

Thank you for buying Foxconn A7GM-S 2.0 motherboard. Foxconn

products are engineered to maximize computing power, providing

only what you need for break-through performance.

With advanced overclocking capability and a range of connectivity

features for today multi-media computing requirements, A7GM-S 2.0

enables you to unleash more power from your computer.

This chapter includes the following information:

■ Product Specications

■ Layout

■ Back Panel Connectors

1-1 Product Specications

CPU Support AMD socket AM2+ Phenom

series processors

Support AMD socket AM2 series processors :

Athlon

64 FX / Athlon

64X2 Dual-Core / Athlon

X2 Dual-Core /

Athlon

64 / Sempron

HyperTransport 2000/1600MT/s for AM2 CPU

Up to 5200MT/s (HT3.0) for AM2+ CPU

Chipset North Bridge: AMD 780G

South Bridge: AMD SB700

Memory 4 x 240-pin DDR2 DIMM sockets

Support up to 8GB of system memory

Dual channel DDR2 1066(oc*)/800/667/533/400MHz architecture

(oc*: overclocking)

Audio Realtek 8-channel audio chip

High Denition Audio

2/4/5.1/7.1-channel

Support for S/PDIF Out

Support Jack-Sensing function

LAN Realtek Gigabit LAN chip

Expansion Slots 1 x PCI Express x16 slot

1 x PCI Express x1 slot

2 x PCI slots

Onboard Serial ATA 6 x SATA connectors

300MB/s data transfer rate

Support hot plug and NCQ (Native Command Queuing )

USB Support hot plug

Support up to 10 x USB 2.0 ports (4 rear panel ports, 3 onboard USB

headers supporting 6 extra ports)

Supports USB 2.0 protocol up to 480Mb/s

Internal Connectors 1 x 24-pin ATX main power connector

1 x 4-pin ATX 12V power connector

1 x Floppy disk drive connector

1 x IDE connector

6 x SATA connectors

3 x USB 2.0 connectors (supporting 6 x USB devices)

1 x CPU fan header (4-pin)

1 x System fan header (4-pin)

1 x Front panel connector

1 x CD_IN connector

1 x Front Audio connector

1 x Speaker connector

1 x COM1 connector

1 x IrDA connector

1 x Chassis intrusion alarm header (INTR)

1 x S/PDIF OUT connector

1 x TPM connector

Back Panel 1 x PS/2 keyboard port

Connectors 1 x PS/2 mouse port

1 x VGA port

1 x HDMI port

1 x DVI-D port

4 x USB 2.0 ports

1 x RJ-45 LAN port

8-channel Audio ports

Hardware Monitor System voltage detection

CPU/System temperature detection

CPU/System fan speed detection

System voltage warning

CPU/System overheating warning

CPU/System fan speed control

PCI Express x1 Support 500MB/s (1GB/s concurrent) bandwidth

Low power consumption and power management features

PCI Express x16 Support 8GB/s (16GB/s concurrent) bandwidth

Low power consumption and power management features

Green Function Support ACPI (Advanced Conguration and Power Interface)

Support S0 (normal), S1 (power on suspend), S3 (suspend to RAM), S4

(suspend to disk), and S5 (soft - off)

Bundled Software FOX ONE

FOX LiveUpdate

FOX LOGO

FOX DMI

Operating System Support for Microsoft

Windows® Vista/XP only

Form Factor Micro ATX Form Factor, 9.6 inches x 9.6 inches (24.4cm x 24.4cm)

The chipset driver of this motherboard does not support Windows® 2000.

1-2 Layout

16 17

2019

1. 4-pin ATX 12V Power Connector

2. Speaker Connector

3. USBPWR3 Jumper

4. PCI Express x1 Slot

5. PCI Express x16 Slot

6. PCI Slots

7. CD_IN Connector

8. Front Audio Connector

9. S/PDIF OUT Connector

10. USBPWR2 Jumper

11. Front USB Connectors

12. USBPWR1 Jumper

13. Chassis Intrusion Alarm Header

14. Front Panel Connector

15. SATA Connectors

16. System fan Header

17. COM1 Connector

18. Clear CMOS Jumper

19. IDE Connector

20. Floppy Connector

21. 24-pin ATX Power Connector

22. TPM Connector

23. IrDA Connector

24. DDR2 DIMM Slots

25. South Bridge: AMD SB700

26. North Bridge: AMD 780G

27. CPU Socket

28. CPU fan Header

Note : The above motherboard layout is for reference only, please refer to the physical

motherboard for detail.

1-3 Back Panel Connectors

1. PS/2 Mouse Port

Use the upper port (green) to connect a PS/2 mouse.

2. PS/2 Keyboard Port

Use the lower port (purple) to connect a PS/2 keyboard.

3. VGA Port

To connect with external display devices, such as monitor or LCD display.

4. DVI-D Port

The DVI-D port supports DVI-D specication. Connect a monitor that supports DVI-D connection

to this port.

5. HDMI Port

The HDMI (High-Denition Multimedia Interface) provides an all-digital audio/video interface

to transmit the uncompressed audio/video signals and is HDCP compliant. Connect the HDMI

audio/video device to this port. The HDMI Technology can support a maximum resolution of

1920x1080p but the actual resolutions supported depend on the monitor being used.

6. USB Ports

The USB port supports the USB 2.0/1.1 specication. Use this port for USB devices such as an

USB keyboard/mouse, USB printer, USB ash drive and etc.

7. Audio Connectors

For the denition of each audio port, please refer to the table below :

Port 2-channel 4-channel 5.1-channel 7.1-channel

Blue Line In Line In Line In Line In

Green Line Out Front Speaker Out Front Speaker Out Front Speaker Out

Pink Microphone In Microphone In Microphone In Microphone In

Orange - - Center/Subwoofer Out Center/Subwoofer Out

Black - Rear Speaker Out Rear Speaker Out Rear Speaker Out

Grey - - - Side Speaker Out

USB Ports

LAN PortVGA Port

PS/2 Keyboard Port

PS/2 Mouse Port

DVI-D Port Audio Ports

Line Out

Microphone

Subwoofer

Rear Speaker

Side Speaker

Line In

HDMI Port

8. RJ-45 LAN Port

The Ethernet LAN port provides Internet connection at up to 10/100/1000Mb/s data rate.

LAN Type

Left: Active Right: Link

Status Description Status Description

1000M

Off No Link Off No Link

Green

Blinking

Data

Activity

Off 10Mb/s Connection

Green 100Mb/s Connection

Orange 1000Mb/s Connection

Active

LED

Link

LED

Please visit this website for more supporting information about CPU, Memory and

VGA for your motherboard :

http://www.foxconnchannel.com/product/Motherboards/compatibility.aspx

This chapter introduces the hardware installation process, including

the installation of the CPU, memory, power supply, slots, pin headers

and the mounting of jumpers. Caution should be exercised during

the installation of these modules. Please refer to the motherboard

layout prior to any installation and read the contents in this chapter

carefully.

This chapter includes the following information :

■ Install the CPU and CPU Cooler

■ Install the Memory

■ Install an Expansion Card

■ Install other Internal Connectors

■ Jumpers

2-1 Install the CPU and CPU Cooler

Install the CPU

Locate the Pin-1 CPU triangle mark and the Pin-1 corner of the CPU socket.

Pin-1 triangle

marking of CPU

Pin-1 corner of the

CPU socket

Read the following guidelines before you begin to install the CPU :

■ Make sure that the motherboard supports the CPU.

■ Always turn off the computer and unplug the power cord from the power supply before

installing the CPU to prevent hardware damage.

■ Locate the pin one of the CPU. The CPU cannot be inserted if oriented incorrectly.

■ Apply an even and thin layer of thermal grease on the surface of the CPU.

■ Do not turn on the computer if the CPU cooler is not installed, otherwise overheating

and damage of the CPU may occur.

■ Set the CPU host frequency in accordance with the CPU specications. It is not

recommended that the system bus frequency be set beyond hardware specications

since it does not meet the standard requirements for the peripherals. If you want to

set the frequency beyond the standard specications, please do so according to your

hardware specications including the CPU, graphics card, memory, hard drive, etc.

1. Release the CPU socket lever.

2. Align pin one of the CPU with the

CPU socket, and gently put the

CPU onto the socket.

3. When CPU is properly seated,

push the CPU socket lever back

to its locked position.

Install the CPU Cooler

Follow the steps below to correctly install the CPU cooler. (The following procedures use Foxconn cooler as the example.)

1. Apply and spread an even thermal

grease on the surface of CPU.

2. Buckle the heatsink rmly at one side of the stand.

3. Buckle the heatsink at another

side, and press the fasten lever

down to tightly seat the cooler.

4. Attach t he 3-wire C PU cooler

connector to the CPU fan header

on the motherboard .

Use extreme care when removing the CPU cooler because the thermal grease may adhere to the CPU. Inadequately removing the CPU cooler may damage the CPU.

2-2 Install the Memory

Dual Channel Memory Conguration

This motherboard provides four DDR2 memory sockets and supports Dual Channel Technology.

When memory is installed, the BIOS will automatically check the memory in your system.

Four DDR2 memory sockets are divided into two channels :

Channel 0 : DIMM1, DIMM3

Channel 1 : DIMM2, DIMM4

The combinations of DIMM modules are :

It is recommended that memory of the same capacity, brand, speed, and chips be

used and please select dual channel rst to achieve optimum performance.

Read the following guidelines before you begin to install the memory :

■ Make sure that the motherboard supports the memory. It is recommended that memory

of the same capacity, brand, speed, and chips be used.

■ Always turn off the computer and unplug the power cord from the power outlet before

installing the memory to prevent hardware damage.

■ Memory modules have a foolproof design. A memory module can be installed in only

one direction. If you are unable to insert the memory, switch the direction.

DIMM1 DIMM2 DIMM3 DIMM4

Single Channel DS/SS - - -

Single Channel DS/SS - DS/SS -

Single Channel - - DS/SS -

Single Channel - DS/SS - DS/SS

Dual Channel DS/SS DS/SS - -

Dual Channel - - DS/SS DS/SS

Dual Channel DS/SS DS/SS DS/SS DS/SS

(DS : Dual Side, SS : Single Side, - : No Memory)

Installing a Memory

If you take a look at front side of memory module, it has asymmetric pin counts on both sides separated

by a notch in the middle, so it can only t in one direction. Follow the steps below to correctly install

your memory modules into the sockets.

Step 1: Spread the clips at both ends of the memory socket. Place the memory module onto the socket, then put

your ngers on top edge of the module, and push it down rmly and seat it vertically into the memory

socket.

Step 2: The clips at both ends of the socket will snap into place when the memory module is securely inserted.

Before installing a memory module, make sure to turn off the computer and unplug the

power cord from the power outlet to prevent damage to the memory module. Be sure

to install DDR2 DIMMs on this motherboard.

112-Pin128-Pin

Notch

2-3 Install an Expansion Card

Follow the steps below to correctly install your expansion card in the expansion slot.

1. Locate an expansion slot that supports your card. Remove the metal slot cover from the chassis

back panel.

2. Align the card with the slot, and press down on the card until it is fully seated in the slot.

3. Make sure the metal contacts on the card are completely inserted into the slot.

4. Secure the card's metal bracket to the chassis back panel with a screw.

5. After installing all expansion cards, replace the chassis cover.

6. Turn on your computer. If necessary, go to BIOS Setup to make any required BIOS changes for

your expansion card(s).

7. Install the driver provided with the expansion card in your operating system.

Installing and Removing a PCI Express x16 Graphics Card :

• Installing a Graphics Card:

Gently insert the graphics card into the PCI Express x16 slot.

Make sure the graphics card is locked by the latch at the end of

the PCI Express x16 slot.

• Removing the Card:

Push the latch at the end of the PCI Express x16 slot to release the card and then pull the card straight up from the slot.

PCI

PCI Express x1

PCI Express x16

■ Make sure the motherboard supports the expansion card. Carefully read the manual

that came with your expansion card.

■ Always turn off the computer and unplug the power cord from the power outlet before

installing an expansion card to prevent hardware damage.

2-4 Install other Internal Connectors

Power Connectors

This motherboard uses an ATX power supply. In order not to damage any device, make sure all the devices have been installed properly before applying the power supply.

24-pin ATX power connector : PWR1

PWR1 is the ATX power supply connector. Make sure that the power supply cable and pins are properly aligned with the connector on the motherboard. Firmly plug the power supply cable into the connector and make sure it is secure.

4-pin ATX 12V Power Connector : PWR2

Connect the 4-pin ATX 12V power supply to PWR2 and provides power to the CPU.

We recommend you using a 24-pin power supply.

If you are using a 20-pin power supply, you need to align the ATX power connector according to the picture.

20-Pin Power

Pin No. 24

Pin # Denition

1 GND

2 GND

3 +12V

4 +12V

3 1

GND

+12V

4 2

PWR2

Pin # Denition Pin # Denition

1 3.3V 13 3.3V

2 3.3V 14 -12V

3 GND 15 GND

4 +5V 16 PS_ON(Soft On/Off)

5 GND 17 GND

6 +5V 18 GND

7 GND 19 GND

8 Power Good 20 NC

9 +5V SB(Stand by +5V) 21 +5V

10 +12V 22 +5V

11 +12V 23 +5V

12 3.3V 24 GND

PWR1

Front Panel Connector : FP1

This motherboard includes one connector for connecting the front panel switch and LED Indicators.

Hard Disk LED Connector (HDD-LED)

Connect to the chassis front panel IDE indicator LED. It indicates the active status of the hard disks. This 2-pin connector is directional with +/- sign.

Reset Switch (RESET-SW)

Attach the connector to the Reset switch on the front panel of the case; the system will restart when the switch is pressed.

Power LED Connector (PWR-LED)

Connect to the power LED indicator on the front panel of the chassis. The Power LED indicates the system’s status. When the system is in operation (S0 status), the LED is on. When the system gets into sleep mode (S1) , the LED

is blinking; When the system is in S3/S4 sleep state or power off mode (S5), the LED is off. This 2-pin connector

is directional with +/- sign.

Power Switch Connector (PWR-SW)

Connect to the power button on the front panel of the chassis. Push this switch allows the system to be turned on and off rather than using the power supply button.

Serial ATA Connectors : SATA_1/2/3/4/5/6

The Serial ATA connector is used to connect with SATA Hard Disk or CD devices which supporting this feature. The current Serial ATA II interface allows up to 300MB/s data transfer rate.

COM Connector : COM1

This motherboard supports one serial RS232 COM port for legacy compatibility. User must purchase another RS232 cable with a 9-pin D-sub connector at one end to connect with the external RS232 device and another end with 10-pin female con-

nector to connect with COM1 connector in the motherboard.

IrDA Connector : IR

This connector supports infrared wireless transmitting and receiving device.

+5V

EMPTY

IRRX

GND

IRTX

EMPTY

HDD-LED

RESET-SW

PWR-SW

PWR-LED

FP1

SATA_1/2/3/4/5/6

GND TX+ TXGND RXRX+

GND

COM1

RLSD

SOUT

GND

RTS

DSR

DTR

CTS EMPTY

SIN

Audio Connector : CD_IN

CD_IN is a Sony standard audio connector, it can be connected to a CD/DVD-ROM drive through a CD/DVD audio cable.

Audio Connector : F_AUDIO

The audio connector supports HD Audio standard. It provides the Front Audio output choice.

S/PDIF OUT Connector : SPDIF_OUT

The connector is used for S/PDIF output.

USB Connectors : F_USB1/2/3

In addition to the four USB ports on the rear panel, this product also provides three 10-pin USB headers on its motherboard. By connecting through USB cables with them, user can quickly expand another six USB ports on the front panel.

IDE Connector : PIDE

With the provided Ultra DMA IDE ribbon cable, you can connect to any IDE type of hard disk and CD/DVD ROM/RW drive.

Floppy Disk Drive Connector : FLOPPY

This motherboard includes a standard oppy disk drive

(FDD) connector, supporting 360KB, 720KB,1.2MB,

1.44MB, and 2.88MB FDDs.

Speaker Connector : SPEAKER

The speaker connector is used to connect speaker of the chassis.

CD_IN

CD_L GND CD_R

PORT1_L

PORT1_R

PORT2_L

SENSE_SEND

SENSE1_RETURN

PRESENCE_J

EMPTY SENSE2_RETURN

AUD_GND

1 2

109

F_AUDIO

PORT2_R

1 2

109

GND

VCC

D+

D-

D+

GND

D-

VCC

EMPTY

F_USB 1/2/3

SPKJ

EMPTY

SPEAKER

SPKJ

SPDIF_OUT

+5V

EMPTY

SPDIF_OUT

GND

Chassis Intrusion Alarm Header : INTR

The connector can be connected to a security switch on the chassis. The system can detect the chassis intrusion through the function of this connector. If eventually the chassis was closed, the system will send a message out.

Fan Headers : CPU_FAN, SYS_FAN

There are two main fan headers on this motherboard. The fan speed can be controlled and monitored in “PC Health Status” section of the BIOS Setup. These fans can be automatically turned off after the system enters

S3, S4 and S5 sleeping states.

TPM Connector : TPM

The TPM (Trusted Platform Module) provides the ability to the PC to run applications more secure and to make transactions and communication more trustworthy. To utilize this function, you should purchase additional device and install it.

INTR

GND

INTRUDERJ

CPU_FAN / SYS_FAN

GND POWER SENSE CONTROL

LCLK

LFRAMEn

LRESETn

LAD3

VDD

LAD0

NC_2

NC_1

GND

LPCPDn

GND

EMPTY

LAD2

NC_3

LAD1

GND

NC_4

SERIRQ CLKRUNin

NC_5

1 2

19 20

TPM

2-5 Jumpers

For some features needed, users can change the jumper settings on this motherboard to modify them. This section explains how to use the various functions of this motherboard by changing the jumper settings. Users should read the following content carefully prior to modifying any jumper setting.

Description of Jumpers

1. For any jumper on this motherboard, pin 1 can be identied by the bold silkscreen next to it.

However, in this manual, pin 1 is simply labeled as “1”.

2. The following table explains different types of the jumper settings. "Closed" means placing a jumper

cap on the two pins to temporarily short them. The shorting can also be done by touching two

pins by a screwdriver for a few seconds, but using jumper cap is recommended. It can prevent

hazardous ESD (Electrical Static Discharge) problem.

Clear CMOS Jumper: CLR_CMOS

The motherboard uses CMOS RAM to store the basic hardware information (such as BIOS data, date, time information, hardware password...etc.). Clear CMOS data is the fast way to go back to

factory default when the BIOS settings were mistakenly modied.

The steps to clear CMOS data are :

1. Turn off the computer, unplug the power cord from the power outlet.

2. Remove jumper cap from pins 2-3, put it onto pins 1-2 to short them. This will clear CMOS data.

3. Return the setting to its original with pins 2-3 closed.

4. Plug in the power cord to your computer and turn it on.

5. Go to BIOS Setup to congure new system as described

in next chapter.

Jumper Diagram Denition Description

1-2 Set Pin 1 and Pin 2 closed

2-3 Set Pin 2 and Pin 3 closed

Clear

Normal (Default)

CLR_CMOS

■ Disconnect the power cable before adjusting the jumper settings.

■ Do not clear the CMOS while the system is turned on.

USB device wake-up Jumpers: USBPWR1 / 2 / 3

1. Set the jumper to pins 1-2 (+5V) to wake up the computer from S1 sleep mode using the

connected USB devices.

2. Set the jumper to pins 2-3 (+5VSB) to wake up the computer from S3 and S4 sleep modes

using the connected USB devices. At the same time, a corresponding setting must be set in BIOS as below:

Set -> “Power Management Setup” -> “Resume by USB Devices” to “Enabled”.

USBPWR1/2/3

+5V

(Default)

+5VSB

■ USBPWR1/ USBPWR2 is for the internal USB connectors, USBPWR3 is for the rear

USB ports.

■ The USB device wake-up feature requires a power supply that can provide 500mA

on +5VSB lead for each USB port; otherwise, the system will not power up.

■ The total current consumed must not exceed the power supply capability (+5VSB)

whether under normal condition or in sleep mode.

Since BIOS could be updated some other times, the BIOS information described

in this manual is for reference only. We do not guarantee the content of this

manual will remain consistent with the newly released BIOS at any given time in

the future. Please visit our website for updated manual if it is available.

This chapter tells how to change system settings through the BIOS

Setup menus. Detailed descriptions of the BIOS parameters are

also provided.

You have to run the Setup Program when the following cases oc-

cur:

1. An error message appears on the screen during the system

Power On Self Test (POST) process.

2. You want to change the default CMOS settings.

This chapter includes the following information :

■ Enter BIOS Setup

■ Main Menu

■ System Information

■ Advanced BIOS Features

■ Fox Central Control Unit

■ Advanced Chipset Features

■ Integrated Peripherals

■ Power Management Setup

■ PC Health Status

■ BIOS Security Features

■ Load Optimal Defaults

■ Save & Exit Setup

■ Exit Without Saving

Enter BIOS Setup

The BIOS is the communication bridge between hardware and software, correctly setting up the BIOS parameters is critical to maintain optimal system performance. Power on the computer, when the message "Press <DEL> to enter Setup, <ESC> to boot menu". appears at the bottom of the screen, you can press <DEL> key to enter SETUP.

Main Menu

The main menu allows you to select from a list of setup functions together with two exit choices.

Use the arrow keys to select a specic item and press <Enter> to go to the sub-menu.

Each item in the main menu is explained below:

► System Information

It displays the basic system conguration, such as BIOS ID, CPU Name, memory size plus

system date, time and Floppy drive. They all can be viewed or set up through this menu.

► Advanced BIOS Features

The advanced system features can be set up through this menu. There are boot up settings.

► Fox Central Control Unit

Some special proprietary features (such as overclocking) can be set up through this menu.

► Advanced Chipset Features

The values for the chipset can be changed through this menu, and the system performance

can be optimized.

► Integrated Peripherals

All onboard peripherals can be set up through this menu. There are IDE devices, Super I/O

devices such as Serial I/O and other USB devices... etc.

► System Information ► PC Health Status

► Advanced BIOS Features ► BIOS Security Features

► Fox Central Control Unit Load Optimal Defaults

► Advanced Chipset Features Save & Exit Setup

► Integrated Peripherals Exit Without Saving

► Power Management Setup

↑↓←→:Move Enter:Select +/-/:Value F10:Save ESC:Exit

F1:General Help F9:Optimized Defaults

Configure Time and Date. Display System Information...

► System Information

We do not suggest that you change the default values in the BIOS Setup, and we shall not be responsible for any damage which resulted from the change you made.

UTI

► Power Management Setup

All the items related with Green function features can be set up through this menu.

► PC Health Status

This setup enables you to read/change Fan speeds, and displays temperatures and voltages

of your CPU/System.

► BIOS Security Features

The Supervisor/User password can be set up through this menu to prevent unauthorized use

of your computer. If you set a password, the system will ask you to key in correct password

before boot or access to Setup.

► Load Optimal Defaults

The optimal performance settings can be loaded through this menu. However, it may offer bet-

ter performance in some ways (such as less I/O cards, less memory ...etc.), still, it may cause

problem if you have more memory or I/O cards installed. It means, if your system loading is

heavy, set to optimal default may sometimes come out an unstable system. What you need

now is to adjust BIOS setting one by one, trial and error, to nd out the best setting for your

current system.

► Save & Exit Setup

Save setting values to CMOS and exit.

► Exit Without Saving

Do not change anything and exit the setup.

System Information

This sub-menu is used to set up the standard BIOS features, such as the date, time, oppy drive

and so on. Use the arrow up/down keys to select an item, then use the <+> or <-> keys to change

the setting.

System Information

Date (mm:dd:yy) [Wed , 01/02/2008] Help Item

Time (hh:mm:ss) [11 : 59 : 49]

► Primary IDE Master

[Not Detected] Use [Enter], [TAB]

► Primary IDE Slave [Not Detected]

or [SHIFT-TAB] to

► Secondary IDE Master [Not Detected]

select a eld.

► Secondary IDE Slave

[Not Detected]

► Third IDE Master [Not Detected] Use [+] or [-] to ► Third IDE Slave

[Not Detected] change system Date.

► Fourth IDE Master

[Not Detected]

► Fourth IDE Slave

[Not Detected]

Floppy A [1.44 MB 3

/2]

Halt On

[All Errors, But ...]

Keyboard [Disabled] Mouse [Disabled] Floppy [Disabled]

Model Name : A7GM-S 2.0

↑↓←→:Move Enter:Select +/-/:Value F10:Save ESC:Exit

F1:General Help F9:Optimized Defaults

► Date (mm:dd:yy)

<weekday><month><date> <year> format.

Day—weekday from Sun. to Sat., this message is automatically displayed by BIOS (Read

Only).

Month—month from 1 to 12.

Date—date from 1 to 31.

Year—year, set up by users.

Use [ENTER], [TAB] or [SHIFT-TAB] to select a eld. Use [+] or [-] to input the value.

► Time (hh:mm:ss)

This item allows you to congure the desired time. Use [ENTER] to enter the setting, then use

[TAB] to move forward a eld. Use [+] or [-] to input the value.

The three elds of the setting are <hour> : <minute> : <second> respectively.

► Primary/Secondary/Third/Fourth IDE Master/Slave

While entering setup, BIOS automatically detects the presence of IDE devices. This item

displays the drive information of IDE devices. Please refer to mapping table in next page.

► Floppy A

This option allows you to select which kind of the Floppy Disk Drive is installed in your system.

It can be [Disabled], [360KB, 51/4"], [1.2MB, 51/4"], [720KB, 31/2"], [1.44MB, 31/2"] and [2.88

MB, 31/2"].

► Halt On

This category determines whether or not the computer will stop if an error is detected during

powering up.

[All Errors] : All errors can result in system halt.

[All Errors But...] : All errors but keyboard or mouse or oppy can result in system halt. The

halt condition can be enabled/disabled in the next three settings.

► Keyboard

The system boot will not stop for a keyboard error if you enabled this item.

► Mouse

The system boot will not stop for a mouse error if you enabled this item.

► Floppy

The system boot will not stop for a floppy error if you enabled this item.

► Model Name

Model name of this product.

► BIOS ID / BIOS Version

It displays the current BIOS ID/version. User can check this information and discuss with the

eld service people if a BIOS upgrade is needed.

► CPU Name

It displays the current CPU name.

► Memory

This item displays the current memory size. The size is depending on how many memory mod-

ules were installed in your system before powering on.

► MAC Address

This item shows the onboard LAN MAC address.

Mapping Table :

With PATA IDE drives Without PATA IDE drives RAID/

AHCI

Onchip SATA Channel Enabled

Onchip SATA Channel Disabled

Onchip SATA Channel Enabled

Onchip SATA Channel Disabled

SATA Combined Mode Enabled

SATA Combined Mode Disabled

SATA Combined Mode Enabled

SATA Combined Mode Disabled

SATA as Secondary

SATA as Primary

SATA as Secondary

SATA as Primary

SATA as Secondary

SATA as Primary

Primary IDE Master IDE0 SATA 5 IDE0 - SATA 5 - SATA 5 - SATA 5 IDE0

Primary IDE Slave IDE1 SATA 6 IDE1 - SATA 6 - SATA 6 - SATA 6 IDE1

Secondary IDE Master SATA 5 IDE0 - IDE0 IDE0 SATA 5 - - - -

Secondary IDE Slave SATA 6 IDE1 - IDE1 IDE1 SATA 6 - - - -

Third IDE Master SATA 1 SATA 1 SATA 1 SATA 1 - SATA 1 SATA 1 SATA 1 - -

Third IDE Slave SATA 3 SATA 3 SATA 3 SATA 3 - SATA 3 SATA 3 SATA 3 - -

Fourth IDE Master SATA 2 SATA 2 SATA 2 SATA 2 - SATA 2 SATA 2 SATA 2 - -

Fourth IDE Slave SATA 4 SATA 4 SATA 4 SATA 4 - SATA 4 SATA 4 SATA 4 - -

+ 77 hidden pages
