Fostex FW167 User Manual

Features

• Kenaf-Cellgaia hybrid cone

• Reasonable Qts value for easy

bass-reflex enclosure design

• Newly designed aluminum die-

cast frame

• Ferrite magnet & repulsion type

magnet shielded circuit

Specifications

&

Thiele/Small Parameters

160 6

Size :

Voice Coil Diameter

:

Cast / Stamped :

Impedance :

Reproduction Frequency Response

:fs -

Sound Pressure Level

:

Rated Input :

Music Power :

Magnet Material :

Magnet Weight

(main) :

(cancel) :

Net Weight

440 0.970

330 0.728

2,659 5.862

mm / in

35.5 1.4

mm / in

Cast

8

Ω

8

kHz

89

dB/W(m)

34

W

100

W

Ferrite

g / lb

g / lb

g / lb

Low Flux Leakage Woofer

FW167

Frequency Response / Impedance

110

100

90
80
70
60
50

(dB)

20 50 100 200 500

Hz

Impedance

1K

2k 5k

10k

Ω

64

32

16

8
4

20k

a :

Sd :

Zn :

Fs :

Re :

Le :

Qms :

Qes :

Qts :

Mms :

BL :

Vas :

Xmax :

Eff/η0 :

Cms :

EBP :

64

0.0128

40

7.1

0.071

2.6

0.4

0.36

14.9

8.2

25.22

1.5

0.43

0.0011

100

mm

m

8

Ω

Hz

Ω

mH

g

Telsa/m

L

mm

%

mm/N

2

Dimensions & Mounting Information

5-ø4.2 hole

(11.9)

(96.2)

Overall Diameter :

Baffle Hole Diameter

Depth :

ø186

ø118.5

ø143
ø180

186 7.3

:

151 5.9

108.1 4.2

10

(108.1)

mm / in

mm / in

mm / in
