Fostex FE208EZ User Manual [ru]

Features

• HP (Hyperbolic Paraboloid)

shell diaphragm

• ‘ES cone’ paper made of

banaba plant’s fiber

• UDR tangiential edge / damper

•ø 156mm large ferrite magnet

Specifications

&

Thiele/Small Parameters

200 8

Size :

Voice Coil Diameter

:

Cast / Stamped :

Impedance :

Reproduction Frequency Response

:fs -

Sound Pressure Level

:

Rated Input :

Music Power :

Magnet Material :

Magnet Weight

(main) :

(cancel) :

Net Weight

1,408.7 3.106

n/a n/a

4,800 10.58

mm / in

35 1.3

mm / in

Cast

8

Ω

14

kHz

97

dB/W(m)

40

W

120

W

Ferrite

g / lb

g / lb

g / lb

FULL RANGE SPEAKER UNIT

FE208E

Frequency Response / Impedance

110

100

90
80
70
60
50

(dB)

20 50 100 200 500

Hz

1000

2k 5k

10k

16

8
4

20k

a :

D :

Sd :

Zn :

Fs :

Re :

Le :

Qms :

Qes :

Qts :

Mms :

BL :

Vas :

Xmax :

Eff/η0 :

Cms :

EBP :

80

144

0.0201

42

6.4

0.0517

6.191

0.19

0.18

13.3

10.8

60.1

1.25

2.278

1.069

221.05

mm

mm

m

8

Ω

Hz

Ω

mH

g

Telsa/m

L

mm

%

mm/N

Dimensions & Mounting Information

2

8-ø6 hole

ø213

+ TERMINAL
RED MARKING

Overall Diameter :

Baffle Hole Diameter

Depth :

ø230
ø182

ø156

230 9

:

185 7

93.5 4

20

mm / in

mm / in

mm / in

53.5

40

11.1

(107)
