Foster 7321 240, 7322 240 User Manual

USER'S MA

cod. 7321 240, 7322 240

NUAL FOR INDUCTION HOBS

Dea

r client,

Thank you for having chosen our induction ceramic hob.
In order to make the best use of your appliance, we would advise you to read carefully the
following notes and to keep them for a later consulting.

SUMMARY

SAF

ETY.....................................................................................................................................16

PRECAUTIONS BEFORE USING....................................................................................................16

USING THE APPLIANCE ..............................................................................................................16

PRECAUTIONS NOT TO DAMAGE THE APPLIANCE ..........................................................................17

PRECAUTIONS IN CASE OF APPLIANCE FAILURE............................................................................17

OTHER PROTECTIONS ...............................................................................................................17

DESCRIPTION OF THE APPLIANCE.......................................................................................18

TECHNICAL DATA ......................................................................................................................18

CONTROL PANEL ......................................................................................................................18

USE............................................................................................................................................18

SENSITIVE TOUCHES .................................................................................................................18

DISPLAY ..................................................................................................................................19

VENTILATION............................................................................................................................19

STARTING-UP AND APPLIANCE MANAGEMENT.................................................................19

BEFORE THE FIRST USE.............................................................................................................19

INDUCTION PRINCIPLE ...............................................................................................................19

STARTING-UP...........................................................................................................................19

PAN DETECTION .......................................................................................................................20

RESIDUAL HEAT INDICATION ......................................................................................................20

BOOSTER FUNCTION .................................................................................................................20

TIMER .....................................................................................................................................21

CONTROL PANEL LOCKING.........................................................................................................21

COOKING ADVICES.................................................................................................................22

PAN QUALITY ...........................................................................................................................22

PAN DIMENSION........................................................................................................................22

EXAMPLES OF POWER SETTING..................................................................................................22

WHAT TO DO IN CASE OF A PROBLEM................................................................................23

MAINTENANCE AND CLEANING............................................................................................24

ENVIRONMENT PROTECTION................................................................................................24

INSTALLATION INSTRUCTIONS.............................................................................................25

ELECTRICAL CONNECTION ...................................................................................................26

15

SAFETY

e

cautions before using

Pr

 Unpack all the materials.
 The installation and connecting of the appliance have to be done by approved

specialists. The manufacturer can not be responsible for damage caused by building-in
or connecting errors.

 To be used, the appliance must be well-equipped and installed in a kitchen unit and an

adapted and approved work surface.

 This domestic appliance is exclusively for the cooking of food, to the exclusion of any

other domestic, commercial or industrial use.

 Remove all labels and self-adhesives from the ceramic glass.
 Do not change or alter the appliance.
 The cooking plate can not be used as freestanding or as working surface.
 The appliance must be grounded and connected conforming to local standards.
 Do not use any extension cable to connect it.
 The appliance can not be used above a dishwasher or a tumble-dryer: steam may

damage the electronic appliances.

Using the appliance

 Switch the heating zones off after using.
 Keep an eye on the cooking using grease or oils: that may quickly ignite.
 Be careful not to burn yourself while or after using the appliance.
 Make sure no cable of any fixed or moving appliance contacts with the glass or the hot

saucepan.

 Magnetically objects (credit cards, floppy disks, calculators) should not be placed near to

the engaged appliance.

 Do not place any metallic object except heating containers. In case of untimely engaging

or residual heat, this one may heat, melt or even burn.

 Never cover the appliance with a cloth or a protection sheet. This is supposed to become

very hot and catch fire.

 This appliance is not intended for use by persons (including children) with reduced

physical, sensory or mental capabilities, or lack of experience and knowledge, unless
they have been given supervision or instruction concerning use of the appliance by a
person responsible for their safety.

 Children should be supervised to ensure that they do not play with the appliance.
 Metallic objects such as knives, forks, spoons and lids should not be placed on the hob

surface since they can get hot.

16

Pre

cautions not to damage the appliance

 Raw pan bottoms or damaged saucepans (not enamelled cast iron pots,) may damage

the ceramic glass.

 Sand or other abrasive materials may damage ceramic glass.
 Avoid dropping objects, even little ones, on the vitroceramic.
 Make sure that the ventilation of the appliance works according to the manufacturer’s

instructions.

 Do not hit the edges of the glass with saucepans.
 Do not put or leave empty saucepans on the vitroceramic hobs.
 Sugar, synthetic materials or aluminium sheets must not contact with the heating zones.

These may cause breaks or other alterations of the vitroceramic glass by cooling: switch
on the appliance and take them immediately out of the hot heating zone (be careful: do
not burn yourself).

 Never place any hot container over the control panel.
 If a drawer is situated under the embedded appliance, make sure the space between the

content of the drawer and the inferior part of the appliance is large enough (2cm). This is
essential to guaranty a correct ventilation.

 Never put any inflammable object (ex. sprays) into the drawer situated under the

vitroceramic hob. The eventual cutlery drawers must be resistant to heat.

Precautions in case of appliance failure

 If a defect is noticed, switch on the appliance and turn off the electrical supplying.
 If the ceramic glass is cracked or fissured, you must unplug the appliance and contact

the after sales service.

 Repairing has to be done by specialists. Do not open the appliance by yourself.

 WARNING: If the surface is cracked, switch off the appliance to avoid the possibility of

electric shock.

Other protections

 Note sure that the container pan is always centred on the cooking zone. The bottom of

the pan must have to cover as much as possible the cooking zone.

 For the users of pacemaker, the magnetic field could influence its operating. We

recommend getting information to the retailer or of the doctor.

 Do not to use aluminium or synthetic material containers: they could melt on still hot

cooking zones.

DO

NOT USE INTERMEDIATE REMOVABLE ACCESSORIES TO HEAT

PANS WHICH ARE NOT ADAPTED TO INDUCTION.

RISKS OF BURNS AND DETERIORATION OF THE HOB.

17

DESCRI

/

Booster

c

hnical data

Te

PTION OF THE APPLIANCE

Type Total Power Position Nominal Power* Booster Power*

7321240

7322240

3000W

3400W

* The

given power may change according to the dimensions and material of the pan.

Front 2300W 3000W 250 mm

Fro

nt left

Rear right

1200W
2300W

1400W
3000W

Control panel

n

trol light timer

Co

Timer

key

me

r / Power display

Ti

[ - ] key

Loc

k

ing key

[ + ]

ke

y

Locki

On /

Diam

eter

160 mm
200 mm

n

g light

Off

key

USE

Sens

Your ceramic hob is equipped with electronic controls with sensitive touch keys. When your
finger touches the key, the corresponding command is activated. This activation is validated by
a control light, a letter or a number in the display and/or a “beep” sound.
Touch only one key on the same time.

itive touches

18
