Fortress Technologies BreadCrumb Wireless Network User Manual

BreadCrumb® Wireless Network User
Guide
For the BreadCrumb® Wireless Network Release 8.4
Rajant Corporation
BreadCrumb® Wireless Network User Guide: For the BreadCrumb® Wireless Network Release 8.4
by Rajant Corporation Copyright © 2005-2006 Rajant Corporation
Revision History Revision 1.1 February 20, 2006
Revision 1.0 October 6, 2005

Table of Contents

Preface .........................................................................................................................................................i
Purpose and Scope ..............................................................................................................................i
User Information.................................................................................................................................i
1. Introduction............................................................................................................................................1
What is a BreadCrumb? .....................................................................................................................1
Mobility through Meshing .................................................................................................................1
Mesh - A Definition..................................................................................................................2
BreadCrumb Devices Mesh by Channel and ESSID................................................................2
Example 1 .......................................................................................................................2
Example 2 .......................................................................................................................3
2. Upgrading to Version 8.4.......................................................................................................................4
New Features......................................................................................................................................4
Performance / Process Improvements................................................................................................4
Issues Resolved..................................................................................................................................4
Known Issues.....................................................................................................................................4
Installing / Upgrading BCAdmin.......................................................................................................5
Upgrading BreadCrumb Firmware ....................................................................................................5
Flash Update Procedure for Version 2 and Version 3 Systems ................................................6
3. Models.....................................................................................................................................................8
BreadCrumb ME................................................................................................................................9
External Connectors ...............................................................................................................10
BreadCrumb WE..............................................................................................................................10
External Connectors ...............................................................................................................10
BreadCrumb SE ...............................................................................................................................11
External Connectors ...............................................................................................................11
BreadCrumb XL...............................................................................................................................12
External Connectors ...............................................................................................................12
BreadCrumb XLV ............................................................................................................................13
External Connectors ...............................................................................................................13
BreadCrumb XLE ............................................................................................................................14
External Connectors ...............................................................................................................14
4. Deployment Considerations................................................................................................................16
Addressing .......................................................................................................................................16
BreadCrumb Device Addresses..............................................................................................16
DHCP .....................................................................................................................................16
Channel Assignments.......................................................................................................................16
Channel Assignment for Single-Radio BreadCrumb Devices (ME and WE)........................17
Channel Assignment for Long-Range BreadCrumb Devices (XL, XLV, XLE) ....................17
Physical Placement and Other Considerations.................................................................................17
Line Of Sight ..........................................................................................................................17
Distance..................................................................................................................................18
Weather...................................................................................................................................19
Interference.............................................................................................................................19
Altitude...................................................................................................................................19
iii
5. Using BCAdmin™ ...............................................................................................................................20
Screen Layout ..................................................................................................................................20
Topology Area........................................................................................................................21
Anatomy of the BreadCrumb Box................................................................................22
Anatomy of the Client Box...........................................................................................23
Anatomy of a Connection Line.....................................................................................24
Asymmetric Connections....................................................................................25
Redundant Connections.......................................................................................25
Info Area.................................................................................................................................26
Configuring Individual BreadCrumbs..............................................................................................27
General Settings......................................................................................................................28
Radio Settings.........................................................................................................................29
Reachback Settings.................................................................................................................31
Forwarding Settings................................................................................................................34
Example: Port Forwarding Configuration for a Web Server.........................................35
Security ............................................................................................................................................35
WEP........................................................................................................................................35
Access Control Lists (ACLs)..................................................................................................36
AES-256 Encryption with AirFortress ...................................................................................38
Registering AirFortress.................................................................................................38
Setting the Access ID....................................................................................................38
Enabling/Disabling AirFortress Encryption .................................................................39
Encrypting Wired Traffic..............................................................................................40
Zeroizing the Access ID................................................................................................40
Harris SecNET11....................................................................................................................40
SecNet11 Key Filling....................................................................................................41
BCAdmin Preferences......................................................................................................................41
Mapping with Fugawi Tracker ...............................................................................................42
6. Configuration Examples......................................................................................................................43
Connecting Remote Wired LANs ....................................................................................................43
Unencrypted Point-to-Multipoint...........................................................................................43
Encrypted Point-to-Point........................................................................................................43
Convoy with UAV-Based Camera for Forward Observation............................................................44
Encrypting a Video Feed..................................................................................................................45
7. Troubleshooting ...................................................................................................................................47
Individual BreadCrumbs..................................................................................................................47
The BreadCrumb Wireless Network................................................................................................47
Sporadic Network Connectivity .............................................................................................47
BreadCrumb Device Cannot Connect to BCWN ...................................................................48
BCAdmin .........................................................................................................................................49
Restoring Default Settings (Factory Reset)......................................................................................49
8. Case Study: Military Exercise in Thailand .......................................................................................51
Glossary....................................................................................................................................................54
A. Status Indicator LED..........................................................................................................................57
B. Radio Frequencies...............................................................................................................................58
C. Customer Service................................................................................................................................59
iv

List of Tables

3-1. Available BreadCrumb Models ............................................................................................................8
4-1. Best-Case Distances by Radio Power.................................................................................................18
5-1. BCAdmin Line Colors Legend...........................................................................................................24
5-2. BCAdmin Line Styles Legend ...........................................................................................................25
7-1. Individual BreadCrumb Issues ...........................................................................................................47
7-2. Sporadic Network Connectivity Issues ..............................................................................................47
7-3. BreadCrumb-BCWN Connectivity Issues..........................................................................................48
7-4. BCAdmin Issues.................................................................................................................................49
A-1. LED Status Indications......................................................................................................................57
B-1. 802.11b Channel Frequency Table ....................................................................................................58

List of Figures

1-1. Meshing Example 1 - Full Connectivity ..............................................................................................2
1-2. Meshing Example 2 - Different ESSIDs Prevent Meshing..................................................................3
2-1. Version 2 Power Input ..........................................................................................................................5
2-2. Version 3 Power Input ..........................................................................................................................5
3-1. BreadCrumb ME - External Connectors ............................................................................................10
3-2. BreadCrumb WE - External Connectors............................................................................................11
3-3. BreadCrumb SE - External Connectors..............................................................................................12
3-4. BreadCrumb XL - External Connector ..............................................................................................13
3-5. BreadCrumb XLV - External Connectors ..........................................................................................14
3-6. BreadCrumb XLE - External Connectors (front)...............................................................................15
3-7. BreadCrumb XLE - External Connectors (back) ...............................................................................15
5-1. BCAdmin Screen at Startup (No Network)........................................................................................20
5-2. The BreadCrumb Box ........................................................................................................................22
5-3. The Client Box ...................................................................................................................................23
5-4. Asymmetric Connection Example......................................................................................................25
5-5. Redundant Connection Example........................................................................................................25
5-6. BreadCrumb Summary Panel.............................................................................................................26
5-7. Link Detail Tabs.................................................................................................................................27
5-8. BreadCrumb Properties - General Tab ...............................................................................................28
5-9. BreadCrumb Properties - Radios Tab.................................................................................................30
5-10. BreadCrumb Properties - Reachback Tab ........................................................................................31
5-11. BreadCrumb Properties - Forwarding Tab.......................................................................................34
5-12. WEP Configuration Window............................................................................................................36
5-13. Access Control List Window............................................................................................................37
5-14. Set Access ID Window.....................................................................................................................39
5-15. BCAdmin Preferences Window .......................................................................................................41
7-1. Factory Reset Button..........................................................................................................................50
8-1. Joint Exercise Network.......................................................................................................................51
8-2. BCAdmin screen during exercise showing BreadCrumb network.....................................................51
8-3. View of beach from command center.................................................................................................52
8-4. Balloon with Camera and BreadCrumb .............................................................................................??
8-5. Soldier communicating over BCWN using Microsoft NetMeeting...................................................53
v

Preface

Purpose and Scope

This manual provides information and guidance to all personnel who are involved with and use Rajant Corporation’s BreadCrumb® Wireless Network devices ("BreadCrumb® devices") in tactical situations.
This manual begins with an introduction to the BreadCrumb Wireless Network and a brief overview of the various BreadCrumb device models available. This is followed by a guide to BCAdmin™, the management application used to configure BreadCrumb devices before or during a deployment. Finally, common deployment scenarios are described and concise step-by-step instructions for each scenario are provided.

User Information

The user of this manual is encouraged to submit comments and recommended changes to improve this manual. Please send any comments or changes to <support@rajant.com>. Be sure to include the version number of the manual you are using and please provide the page numbers related to your comments wherever possible.
i

Chapter 1. Introduction

Rajant Corporation’s (http://www.rajant.com) BreadCrumb Wireless Networks are portable, mobile, battery-powered, automatically-meshing, self-healing, full-duplex, secure, 802.11b access points. Their focus is on flexibility, adaptability, and simplicity.
The BCWN (BreadCrumb Wireless Network) is intended for rapid deployment of a broadband wireless network into a situation or "hot zone."
The BreadCrumb Wireless Network components utilize the 802.11b wireless networking standard to form a wireless mesh network. The network can be deployed as a standalone wireless network or may be connected to other networks (such as the Internet or a LAN in a Tactical Operations Center) utilizing available reachback communication links (satellite modem, DSL, cable modem, etc.).
BreadCrumb devices are available with different configurations designed for specific tasks, described in the next section.

What is a BreadCrumb?

A BreadCrumb device is an 802.11b (Wi-Fi) Access Point specifically designed for the following scenarios:
Temporary Wireless Networks
Networks that must be established quickly and with minimal effort for short-term use. (e.g., a network established to provide First Responder support at the site of a disaster)
Mobile Wireless Networks
Networks in which the network infrastructure itself is mobile, in addition to client devices. (e.g., a convoy viewing a video stream from a UAV)
Wireless Network Extension
Networks in which a wireless network must be quickly extended around or through obstacles that block wireless communications (e.g., urban canyon networks, tunnels/caves, etc.)
Wired Network Extension
Networks in which two or more wired LANs at different locations must be connected wirelessly (e.g., to securely connect combat service support computers with logistics bases)
Any Combination of the Above
Most BreadCrumb deployments include elements from more than one of the above scenarios.
In many cases, BreadCrumb devices will perform all of the above tasks as shipped with no configuration necessary at all, providing an instant TAN - a Tactical Area Network. Moreover, because BreadCrumb devices use industry-standard 802.11b communications, client devices such as laptops or handheld computers require no special hardware, software, or configuration to access a BreadCrumb Wireless Network.
1

Mobility through Meshing

The key component to a BreadCrumb Wireless Network is a technique known as Meshing. While this is generally handled automatically by BreadCrumb devices, complex deployment scenarios require a basic understanding of how BreadCrumb devices establish and maintain a mesh.
Mesh - A Definition
A mesh is a collection of network devices (in our case, BreadCrumb devices), each of which is connected to one or more other BreadCrumb devices. Data can move between BreadCrumb devices via these links, possibly passing through several intermediate BreadCrumb devices before arriving at its final destination.
The intelligence of a BreadCrumb Wireless Network is in how it adapts rapidly to the creation or destruction of the links in the mesh as devices are moved, switched OFF or ON, blocked by obstructions, interfered with by other devices, or otherwise affected. This adaptation takes place automatically and immediately as needed.
Note: Although all BreadCrumb devices can be Access Points, most Access Points do not provide any meshing capabilities. Traditional Access Points simply allow wireless devices within range to connect to a wired network; they do not extend range through other Access Points.
Chapter 1. Introduction

BreadCrumb Devices Mesh by Channel and ESSID

Two BreadCrumb devices establish a mesh link to one another when they share both a radio channel and an ESSID. The 802.11b radios used by BreadCrumb devices support 11 different channels for communication, numbered 1-11. By default, each BreadCrumb device radio is on channel 1, 8, or 11. Most BreadCrumb devices have two radios, using two of those channels.
An ESSID is essentially a name for a wireless network. By default, BreadCrumb devices use the ESSID "breadcrumb".
Example 1
Suppose you have three BreadCrumb devices, called A, B, and C. Each has two radios. BreadCrumb device A’s radios are on channels 1 and 8, B’s are on 8 and 11, and C’s are on 1 and 11. All three BreadCrumb devices are using the default ESSID of "breadcrumb". Assuming that all three BreadCrumb devices are within radio range of one another, the network will be connected like this:
2
Chapter 1. Introduction
Figure 1-1. Meshing Example 1 - Full Connectivity
Example 2
Now suppose that you change the ESSID of BreadCrumb device C to "lonely". The network will adjust to this change, resulting in the following configuration:
Note that BreadCrumb device C can no longer communicate with A or B, and vice versa.
Figure 1-2. Meshing Example 2 - Different ESSIDs Prevent Meshing
3

Chapter 2. Upgrading to Version 8.4

This section is only necessary for BreadCrumb device/BCAdmin users of versions earlier than 8.4. If your entire BCWN is operating at version 8.4 or higher, you may safely skip this chapter.

New Features

Fortress Technologies’ AES-256 encryption is enabled, allowing Fortress encryption to be used on
existing BreadCrumb devices under Rajant’s new licensing terms with Fortress Technologies (http://www.fortresstech.com).

Performance / Process Improvements

Management frames are now capable of using 11Mbps data rates, increasing overall channel
bandwidth.
Enhanced radio frame fragmentation process.

Issues Resolved

A compatibility issue with the latest version of Java® has been resolved. (The problem manifested as
the inability to open a BreadCrumb Properties window).
Fixed Fortress-Only Mode to work correctly over meshed connections.
Mesh-transmit timeout condition resets the radio cards, enhancing mesh healing capabilities.
Radio cards default to "primary antenna only."
Several minor bugs corrected in the radio driver.

Known Issues

Signal strength number in BCAdmin is not translated into dBm.
It is recommended that the mesh feature NOT be disabled. A radio interface with mesh disabled
incorrectly displays a connection in BCAdmin even though no link exists.
4
Selection of a unique ESSID (network name) for the BreadCrumb network is recommended. A
BreadCrumb device equipped with tri-color LED incorrectly indicates a meshed connection (GREEN) when in the presence of an 802.11b access point with the same ESSID.

Installing / Upgrading BCAdmin

1. Install the latest JRE from http://www.java.com
2. Download version 8.4 of BCAdmin for Windows or Linux using the link provided by your Rajant Account Manager.
3. Run the installer (for Windows) or install the rpm (for Linux) and follow any instructions provided on your screen.
Chapter 2. Upgrading to Version 8.4

Upgrading BreadCrumb Firmware

Follow the following procedure for each BreadCrumb device in your network. Be sure to determine each BreadCrumb board version (step 1) individually.
1. Determine the BreadCrumb board version (version 2 or version 3) as follows:
In version 2 units, the power input (where the power wires plug in) are in a straight line, as below:
Figure 2-1. Version 2 Power Input
Version 3 units have the power configuration as below:
5
Chapter 2. Upgrading to Version 8.4
Figure 2-2. Version 3 Power Input
2. Download the correct firmware zip archive for the board determined in the previous step, using the link provided by your Rajant Account Manager.
3. Create a new, empty folder and unzip the archive into it.
4. Copy the unzipped files (and only those files) onto an empty (no pre-existing files) ATA Flash Memory Card (of at least 16MB). The flash card may be directly purchased from http://www.magicram.com/flshcrd.htm
5. Proceed with the flash instructions below.

Flash Update Procedure for Version 2 and Version 3 Systems

Note: BreadCrumb Wireless Network-specific parameters, like name and location, are reset to their default
values after the upgrade. The user should record these and other parameters to reload into the BreadCrumb devices after the software installation procedure is completed.
1. Turn OFF power to the BreadCrumb.
2. Remove the top PCMCIA card, leaving one radio card still installed in the bottom slot.
In dual-radio BreadCrumb products, remove the top radio card.
In single-radio BreadCrumb products, move the radio to the bottom slot.
Plug the flash card, white label side up, into the top slot.
Turn unit ON and observe the amber light ON on the radio card. (The green light sometimes goes
ON, sometimes not.)
Wait for the amber light to go out.
TURN THE POWER OFF to the BreadCrumb.
Remove the flash card, and replace the radio(s) to their original positions.
Power the unit back ON.
6
Chapter 2. Upgrading to Version 8.4
Allow the BreadCrumb to operate FOR NO LESS THAN 5 MINUTES before rebooting or turning
OFF.
Important: After a flash update, you should ensure that at least one client device has the new BCAdmin installed, is "permitted" in the device’s ACL list, and is designated as an administrator. Important settings that were lost in the flash may be re-keyed, but do not reboot the BreadCrumb device until it has run for at least five minutes after its initial power-up after flash.
Rebooting before the end of the five-minute "bake period" can result in a faulty flash update, requiring the flash operation to be performed again.
7

Chapter 3. Models

The following table summarizes the differences between the BreadCrumb models available. Each model is described in greater detail later in this chapter.
ME WE SE XL XLV XLE
Usage Weight/
size-sensitive deployments (UAVs, etc.)
Dimensions 6" x 3.75" x
7.5"
Weight 1.5lbs 3.9lbs (incl.
Number of Radios
Ethernet Yes (via
Input Power 6-15VDC 6-15VDC 6-15VDC 9-15VDC 6-40VDC
1 (2 optional)
RJ-45 dongle)
Worn by mobile individual
7.25" x 4.75" x 2.5"
battery) 1 2 2 2 2
Yes Yes Yes Yes Yes
Placed as necessary, short/ medium range use
8.25" x 6.5" x 3.5"
2.5lbs 9.7lbs 12.0lbs 14.0lbs
Placed as necessary, long range use
9" x 6.5" x4"9" x 6.5" x4"12" x 12" x
Vehicle­mounted, long-range use
(4-amp start)
Placed as necessary, incl. vehicle mount, contains embedded MPEG video encoder, long-range use
2.5"
6-40VDC (4-amp start)
RF Output Power (no antenna gain)
23dBm/ channel +-2dBm
25dBm/ channel +-2dBm
23dBm/ channel +-2dBm
27dBm/ channel +-2dBm
27dBm/ channel +-2dBm
27dBm/ channel +-2dBm
8
ME WE SE XL XLV XLE
Security 256-bit AES
FIPS 140-2 using embedded AirFortress Client; Access Control Lists; WEP; Third-party VPNs
Harris SecNet11 Support
Integrated Antennas
No No Yes (waiver
None 5dBi omnidi-
256-bit AES FIPS 140-2 using embedded AirFortress Client; Access Control Lists; WEP; Third-party VPNs
rectional
256-bit AES FIPS 140-2 using embedded AirFortress Client; Access Control Lists; WEP; Third-party VPNs; Type 1 encryption with Harris SecNet11
required)
4x2dBi dipole
Chapter 3. Models
256-bit AES FIPS 140-2 using embedded AirFortress Client; Access Control Lists; WEP; Third-party VPNs; Type 1 encryption with Harris SecNet11
Yes (waiver required)
None None None
256-bit AES FIPS 140-2 using embedded AirFortress Client; Access Control Lists; WEP; Third-party VPNs; Type 1 encryption with Harris SecNet11
Yes (waiver required)
256-bit AES FIPS 140-2 using embedded AirFortress Client; Access Control Lists; WEP; Third-party VPNs; Type 1 encryption with Harris SecNet11
No
External Antenna Connectors
Managed Networking Features
Table 3-1. Available BreadCrumb Models
Note: A BreadCrumb Wireless Network can include any combination of these models.
SMA (F) None 1xfemale
Bridging, Gateway, DHCP, NAT, Port Forwarding

BreadCrumb ME

The BreadCrumb ME is the smallest and lightest BreadCrumb device offered, making it ideal for deployments with strict size and/or weight constraints. The BreadCrumb ME only contains one radio by default (a second radio is available as an option). Our customers have installed BreadCrumb MEs:
Bridging, Gateway, DHCP, NAT, Port Forwarding
N-type (optional, connected to one radio only)
Bridging, Gateway, DHCP, NAT, Port Forwarding
1xfemale N-type (radios combined internally)
Bridging, Gateway, DHCP, NAT, Port Forwarding
1xfemale N-type (radios combined internally)
Bridging, Gateway, DHCP, NAT, Port Forwarding
1xfemale N-type (radios combined internally)
Bridging, Gateway, DHCP, NAT, Port Forwarding
9
Chapter 3. Models
On UAVs
In portable sensor packages
Important: In a BCWN containing single-radio BreadCrumb devices, all BreadCrumb devices to which the single-radio BreadCrumb device communicates must have one radio on the same channel as the single-radio BreadCrumb device.

External Connectors

Figure 3-1. BreadCrumb ME - External Connectors

BreadCrumb WE

The BreadCrumb WE is functionally identical to a 1-radio BreadCrumb ME, with a higher-gain antenna, integrated battery, and a case more suited to attach to worn gear. Individuals wearing a BreadCrumb WE automatically extend a BCWN wherever they go, provided that they remain within range of at least one other BreadCrumb device.
Important: In a BCWN containing single-radio BreadCrumb devices, all BreadCrumb devices to which the single-radio BreadCrumb device communicates must have one radio on the same channel as the single-radio BreadCrumb device.
10

External Connectors

Chapter 3. Models
Figure 3-2. BreadCrumb WE - External Connectors

BreadCrumb SE

The BreadCrumb SE is the basic building block of most BCWN networks. Its two radios and ethernet interface enable the full suite of BreadCrumb features (with the exception of long range and integrated video encoder), while its size allows it to be easily transported to and placed wherever necessary. BreadCrumb SEs have been rapidly deployed:
On rooftops
In trees or bushes
Hung from balloons
In stairwells
On fences and observation towers
In shipyards
11

External Connectors

Figure 3-3. BreadCrumb SE - External Connectors
Chapter 3. Models

BreadCrumb XL

The BreadCrumb XL is a long-range model, capable of 11Mb communications at distances of 7 miles (11.2km) or more, and lower-speed communications at even greater range. BreadCrumb XLs have been rapidly deployed:
In Air Traffic Control towers
On mountaintops
On ships
Important: The range-extending circuitry within a BreadCrumb XL is permanently tuned to 802.11b channels 1 and 11. Changing these settings may prevent your network from operating properly.
12

External Connectors

Chapter 3. Models
Figure 3-4. BreadCrumb XL - External Connector

BreadCrumb XLV

The BreadCrumb XLV is identical to the BreadCrumb XL, with the exception that it also accepts unfiltered vehicle power (6-40VDC) as a power source. This allows long-range communication within and among vehicle convoys and bases, and enables the bridging of widely spread networks by vehicles. BreadCrumb XLVs have been rapidly deployed:
In HMMWVs
In Bradley Fighting Vehicles
In trucks
13

External Connectors

Chapter 3. Models
Figure 3-5. BreadCrumb XLV - External Connectors

BreadCrumb XLE

The BreadCrumb XLE further builds upon the BreadCrumb XLV by including an MPEG video encoder and an external BNC video connector. A composite video source can be connected to the BreadCrumb XLE and its video stream will be available to other devices on the BCWN. BreadCrumb XLEs have been rapidly deployed to provide video from:
Security cameras
LRASSS (Long-Range Advanced Scout Surveillance System)
14
Loading...
+ 45 hidden pages
