TWO THOUSAND SIXTEEN
FUSION ENERGI
GE5J 19G217 GA
September 2015
Second Printing
Quick Reference Guide
Fusion Energi
Litho in U.S.A.
This Quick Reference Guide is not intended to replace your vehicle Owner’s Manual which contains more detailed
information concerning the features of your vehicle, as well as important safety warnings designed to help reduce the risk
of injury to you and your passengers. Please read your entire Owner’s Manual carefully as you begin learning about your
new vehicle and refer to the appropriate chapters when questions arise. All information contained in this Quick Reference
Guide was accurate at the time of duplication. We reserve the right to change features, operation and/or functionality of any
vehicle specification at any time. Your Ford dealer is the best source for the most current information. For detailed operating
and safety information, please consult your Owner’s Manual.
United States
Ford Customer Relationship Center
1-800-392-3673 (FORD)
(TDD for the hearing impaired: 1-800-232-5952)
owner.ford.com
@FordService
Canada
Ford Customer Relationship Centre
1-800-565-3673 (FORD)
ford.ca
@FordServiceCA
WARNING
Driving while distracted can result in loss of vehicle
control, crash and injury. We strongly recommend that you
use extreme caution when using any device that may take
your focus o the road. Your primary responsibility is the
safe operation of your vehicle. We recommend against the
use of any hand-held device while driving and encourage
the use of voice-operated systems when possible. Make
sure you are aware of all applicable local laws that may
aect the use of electronic devices while driving.
Quick
Reference
Guide
SMART START
FUSION ENERGI MANAGEMENT
Plug-in Power
» Fusion Energi comes equipped with
a 25-foot, 120-volt convenience
cord that is in your trunk storage
compartment underneath the
carpeted panel. This cord allows
you to charge the battery using a
standard, 120-volt, grounded,
three-pronged household outlet.
See your Owner's Manual for details.
NOTE Do not use the 120-volt
convenience cord with an extension
cord or adapter.
» For faster charge times, the available
240-volt charging station provides
a full charge in approximately
2.5 hours. See your dealer for
more information.
Charge Port/Light Ring
The charge port is between the front le
side door and front le wheel well.
Fusion Energi Charging
1. Put your vehicle in park (P) and
switch o the ignition.
2. Open the charge port door by
pressing the door’s indentation.
The door rotates open.
3. Plug the charging cord into the
wall outlet. Always plug the cord into
the AC outlet before connecting the
charging coupler into the vehicle’s
charge port receptacle.
4. Plug the charging coupler into
the vehicle’s charge port. Make
sure the button clicks to lock it
into the port. When the port detects
the connection, each section of
the light ring flashes in a clockwise
manner two full times (indicating the
beginning of a normal charge cycle).
5. When you are done charging your
vehicle, press the button on the
charging coupler and remove it
from the vehicle.
6. To close the charge port door, press
and hold the indentation on the door
until it rotates and closes.
Choose Your Energy Mode
Your vehicle contains driver-selectable EV
modes controlled through the EV button
on the center console. Choose to drive in
electric-only mode for city driving, save
your plug-in power for later or let the
system adjust your power mode to suit
the current driving conditions.
» Auto EV: automatically selects
between gasoline and electric motor
use, staying in electric mode when
possible and running the engine when
needed. This mode is the only one
available when the vehicle depletes the
plug-in power.
» EV Now: puts your vehicle into an
all-electric driving experience using
plug-in power.
» EV Later: puts the vehicle into hybrid
mode, reserving the plug-in power
for later.
SmartGauge®
with EcoGuide
Dual LCD screens in the instrument panel
provide real-time information to help you
get the most out of your plug-in hybrid.
You can also view traditional information,
such as distance traveled and fuel level.
See page 16 of this guide or your Owner's
Manual for more details.
To make the most of your Fusion Energi
and the electric vehicle lifestyle, visit
www.ford.com/green/fuel-eciency/.
Preconditioning
Get the most miles out of every charge
by conditioning your vehicle while it is
plugged in. Set your planned departure
time (GO Time) to use energy from your
home (or charging station) instead of your
vehicle’s battery. The system limits cabin
conditioning to 15 minutes before your
GO Time.
NOTE Cabin conditioning eectiveness
may be reduced by extreme outside
temperatures or when using
120-volt charging.
MyFord® Mobile App
for Smartphones
Download or view on the Web at
www.MyFordmobile.com, the MyFord
Mobile app lets you know the status of your
charge and upcoming charge schedules at
any time, from anywhere.
You can also use the app to:
» See your charge status.
» Set charging schedules.
» Precondition your vehicle.
» Remote start your Fusion Energi.
» Find charge points and more.
To register your smartphone, visit
www.MyFordmobile.com to download
your free app.
Value Charging
With the Value Charging feature, the
MyFord Mobile app gives you utility
rate data that informs you of when the
cheapest rates are available in your area.
This lets you charge your vehicle during
the least expensive times of day. Please
call your utility company for your rate plan
limitations and details.
Learn More About
Your New Vehicle
Scan the country-appropriate QR code with your
smartphone (make sure you have a scanner
app installed) and you can access even more
information about your vehicle.
6–7 Instrument Panel
ENERGY SAVING TIPS
HELP MAXIMIZE YOUR FUEL ECONOMY BY UTILIZING THESE FEW TIPS
1. Use smooth acceleration
and braking.
According to the United States
Department of Energy, aggressive
driving can lower your gas mileage by
up to 33 percent at highway speeds
and 5 percent in the city.
2. Carry the bare essentials.
The Department of Energy
estimates that an extra 100 pounds
(45 kilograms) in your vehicle could
reduce your fuel economy by up to
2 percent.
3. Seasonal fuel makes a dierence.
Winter fuel contains slightly less
energy than summer fuel, so the fuel
blend you fill up with can impact
your eciency.
4. Idling burns fuel, too.
You can burn up to half a gallon (1.9L)
of fuel per hour while idling. Minimize
your morning warm-up and parking
lot waits to get the most out of filling
your tank.
5. Avoid extreme temperatures.
Find a shady or sheltered spot to
help keep your lithium-ion battery
operating eciently, and minimize
the amount of energy required to
heat or cool your cabin.
6. Use accessories wisely.
Heat and air conditioning reduce
your vehicle's electric range and can
prompt the engine to operate. Use
energy from your home outlet or
charging station by taking advantage
7. Check your tires.
of the preconditioning feature and
setting your GO Times in advance.
When you precondition your vehicle,
you can reduce the amount of
heating or air conditioning you need
at the start of your drive. See page 16
of this guide or your Owner's Manual
for more details.
Proper tire inflation can help you
improve your fuel economy by up
to 3.3 percent, according to the
Department of Energy, while
under-inflation could lower your
fuel economy by 0.3 percent for
every 1 psi drop in pressure of all
four tires. Check your vehicle’s door
sticker for recommended cold
tire inflation pressure.
owner.ford.com ford.ca
(U.S.) (Canada)
8–12 SYNC with MyFord Touch
13 Fusion Energi Features
14 Comfort
15 Convenience
16–17 Function
18–19 Essential Features
Information Displays
Within the information display screens, you can see
how your driving style directly impacts your fuel economy.
Use the steering-wheel-mounted controls to scroll
through options, select content and adjust settings.
Le Vehicle Information Display
Use the le steering-wheel-mounted
controls to access a variety of features:
» The Display/Trip Mode provides Fusion
Energi-specific information through the following screens:
• Engage • Empower • MyView • Energy Use • Trip
MyView lets you choose what information you wish to
display. Select Change MyView in the Options menu
to scroll through choices, including Vehicle Range.
» The Brake Coach appears aer the vehicle has come to
a stop. It coaches you to brake in a manner that maximizes
the amount of energy returned through the regenerative
braking system. The displayed percentage indicates your
regenerative braking eciency, with 100% representing
the maximum amount of energy recovery. You can turn
this feature ON and OFF in the information display.
Right Vehicle Information Display
Use the right steering-wheel-mounted
controls to access a variety of features:
» Fuel Economy provides the following
screens to help you save energy:
• Eciency Leaves • Fuel History • Coach
Eciency leaves show your recent driving
eciency measured over the last few minutes.
More leaves mean better fuel economy!
» Entertainment, Phone, and Navigation* information is
also available. Refer to the MyFord Touch chapter in
your Owner's Manual for more details.
*if equipped
INSTRUMENT PANEL
Service Engine Soon Light
Lights briefly when you switch on the ignition. If it remains on
or is blinking aer you start the engine, the On-Board Diagnostics
(OBD-II) system detects a problem. Drive in a moderate fashion
and contact your authorized dealer as soon as possible.
Steering Wheel Controls
Press the following icons:
VOL + or – to increase or decrease volume levels.
to access the next or previous radio station
preset, CD track or preset satellite radio channel*.
to access voice recognition.
to answer call.
to exit phone mode or end a call.
Tilt and Telescope Steering Column
Unlock the steering wheel by pushing the lever up. Adjust the
steering wheel to your desired position. Pull the lever down to
lock the steering wheel in place.
EV Button
Choose to drive in electric-only mode for city driving, save your
plug-in power for later or let the system adjust your power mode
to suit the current driving conditions.
Fuel Button
Press the fuel button to unlock the fuel door. It may take up to
15 seconds for the fuel door to open. Be sure to close the fuel door
securely aer refueling. See your Owner’s Manual for details.
7
*if equipped
SYNC Is a Hands-free,
Voice Recognition System
Used for Entertainment,
Information and
Communication.
SYNC. Say the Word.
Before You Get Started
1. Set up your owner account at
owner.ford.com (U.S.) or
SyncMyRide.ca (Canada). Register
to see which complimentary services
you are eligible for.
2. SYNC uses a wireless connection
Bluetooth® to communicate
called
with your phone. Switch on
Bluetooth mode in your phone’s
menu options. This lets your phone
find SYNC. If you need more details
on setting up your phone with SYNC,
visit owner.ford.com (U.S.) or
SyncMyRide.ca (Canada), or your
phone manufacturer’s website.
SYNC® WITH MYFORD TOUCH
Pairing Your Cell Phone
with SYNC
In order to use many of the features of
SYNC, such as making a phone call or
receiving a text, you must first connect or
pair your phone with SYNC. Make sure that
your vehicle is in park (P), then switch on
your ignition and radio.
To Pair Your Cell Phone for the First Time
1. Touch Add Phone in the upper le
corner of the touchscreen. Find SYNC
appears on the display, and instructs
you to begin the pairing process from
your device.
2. Make sure that Bluetooth is set to ON
and your mobile phone is in the proper
mode. Select SYNC and a six-digit PIN
appears on your device.
3. If you are prompted to enter a PIN on
your device, it does not support Secure
Simple Pairing. To pair, enter the PIN
displayed on your cellular phone.
4. When prompted on your phone's
display, confirm that the PIN displayed
on the touchscreen matches the PIN on
your phone.
5. The touchscreen indicates when the
pairing is successful.
The System May Prompt You to
» Set your phone as the primary or
favorite (the primary phone receives
messages and voicemail).
» Download your phone book (a
requirement to use the full set of
voice commands).
» Switch on 911 Assist
TIPS
» Make sure you accept the request from
SYNC to access your phone.
» To pair subsequent phones, please
refer to Pairing Subsequent Cell Phones
in the MyFord Touch chapter of your
Owner’s Manual.
» If you experience pairing problems, try
performing a clean pairing by deleting
your services from SYNC, deleting your
phone pairing from SYNC, and then
repeating the Pairing Your Cell Phone
with SYNC process.
®
.
Why Do You Need a SYNC
®
Owner Account?
A SYNC owner account provides you with
the latest soware updates and, if you have
questions, free customer support.
NOTE Your SYNC system may oer
advanced features, such as AppLink™.
Some services may not be available in your
area. Visit the website or call the toll-free
number for more information.
U.S. customers: visit owner.ford.com
or call 1-800-392-3673 (select Option
1 or 2 for language, then Option 3).
Canadian customers: visit SyncMyRide.ca
or call 1-800-565-3673 (select Option
1 or 2 for language, then Option 3).
Using Your Cell Phone
with SYNC
NOTE You must download your phone
book to make phone calls with voice
commands by name.
Making a Phone Call
Use SYNC to make a phone call to anyone
in your phone book by pressing the voice
button
voice command.
and when prompted, give a
For example, you could say “Call Jake Smith
at home”. The system confirms what was
said and then dials the number.
NOTE
You can also make phone calls
by pressing the voice button
prompted, give the voice command “Dial”,
then verbally say the phone number.
Answering Incoming Calls
Whenever you have an incoming call, you
will be able to see the name and number
of the person calling in the display. Press
the phone button
call. You can hang up at any time by
pressing and holding the phone button
Do Not Disturb Mode
This feature blocks incoming calls and text
messages and saves them for later. You still
have access to outgoing calls when this
feature is active.
Say the voice command, “Do not disturb
on” to enable and “Do not disturb o”
to disable.
to answer an incoming
. When
Using SYNC to Access
Digital Media
Plug in your USB media devices such as
phones and MP3 players, and use SYNC to
play all of your favorite music.
Using Voice Commands to Play Music
1. Plug your media player into your
USB port.
2. Press the voice button
When prompted, say “USB”, then
follow-up by saying a voice command.
.
.
9
SYNC® WITH MYFORD TOUCH
Phone
Press this corner
to access the
phone functions.
Entertainment
Press this corner
to access all
available music/
media sources.
Information
Press this to access
SiriusXM Travel Link *
and Trac.
Home
Press this to
return to the
home screen.
A Revolutionary Way to
Connect with Your Vehicle
Use the four-corner, four-color touchscreen
to explore and interact with your vehicle.
The touchscreen works the same way as
traditional controls, knobs and buttons
do. Press the various corners on your
touchscreen to personalize the many
features and settings of your vehicle
all in one place.
EV Info
Press this to
access information
about your
Electric Vehicle.
General Tips
» Press the home icon
» Press the desired icon on the sensitive
» Refer to your Owner’s Manual, visit the
Settings
Press this to access
personalized
system settings.
return to your home screen.
touchscreen accurately.
website or call the toll-free number for
more information. See the Why Do You
Need a SYNC Owner Account? section
in this guide for more details.
Navigation
Press this corner to
access navigation
maps or directions.
Climate
Press this corner
to access all
available climate
functions, including
one-touch access to
heated seats
(if equipped).
at any time to
®
CONTINUED
EV Info
Press the EV Info button to access your
plug-in hybrid-specific screens.
» The Power Flow screen shows you where
your vehicle power is coming from and
where it is being used.
» The Charge Settings screen lets you
schedule GO Times and cabin conditioning,
select charging preferences and more.
» Pair your phone with SYNC before
using MyFord Touch (see the Pairing
Your Phone with SYNC section in this
guide for instructions).
» Make sure you insert your navigation SD
card* into the media port (located in
the center console) or your navigation
features does not work.
*if equipped
Get in Touch Using Your Four-corner Touchscreen
Phone, Navigation*, Climate and Entertainment are the four main features of SYNC® with MyFord Touch®.
Each feature has its own corner represented by its own color.
Phone
Voice-control your phone for hands-free
calling with your phone securely put away.
With SYNC, you do not even need to know
the phone number. Just say the name of the
person you want from your contacts.
Your Phone Connects You with Many
Other Features
» Listen to text messages (phone-
dependent feature).
» Transfer calls seamlessly from SYNC
to phone as you get in or out of
your vehicle.
NOTE Your phone allows you to connect
automatically with a 911 Operator in the
event of an accident (you must switch this
feature ON prior to an event).
Refer to the MyFord Touch chapter of
your Owner’s Manual for complete details.
Navigation
Press the upper-right, green corner to
access the available, voice-activated
navigation system:
» SiriusXM Trac
» Sirius Travel Link*
» GPS (Global Positioning
System) technology
» 3-D mapping
» Turn-by-turn navigation
Some features may require activation.
Refer to the MyFord Touch chapter of your
Owner's Manual for complete details.
Set a Destination
Set a destination by using a street address,
a city center, a place on the map or a point
of interest (POI). The easiest way, however,
is by voice.
1. Press the voice button
When prompted, say
“Destination street address”.
2. The system asks you to say
the full address and displays
an example on screen.
*
.
3. You can then speak the address
naturally, such as: One two three
Main Street, Anytown.
You can also use the touchscreen to enter
a destination and narrow your choices by
city or street as you type.
You can choose from up to three dierent
types of routes:
» Fastest: Uses the fastest
moving roads possible.
» Shortest: Uses the shortest
distance possible.
» Eco (EcoRoute): Uses the
most fuel ecient route.
*if equipped
11
SYNC® WITH MYFORD TOUCH
®
CONTINUED
FUSION ENERGI FEATURES
Climate
SYNC with MyFord Touch controls the
temperature, airflow direction, fan speed,
and adjusts other climate features for you
and your passenger.
Set Your Temperature
» Touch the lower-right, blue corner on
your touchscreen.
» Set your exact, desired temperature
using the + or – buttons.
Heated Steering Wheel*
» Touch the lower-right, blue corner on
your touchscreen.
» Touch the heated steering wheel icon*
to warm the steering wheel.
NOTE If your vehicle comes with a
wood-trimmed steering wheel, it does
not heat between the 10 o'clock and
2 o'clock positions.
Entertainment
No matter how you store your music, SYNC
makes it yours to enjoy when you’re behind
the wheel. Press the lower-le red corner of
the touchscreen. From here, you can easily
go between AM, FM, SiriusXM* and other
media sources.
Set Your Radio Presets
» Touch the Entertainment corner on
the touchscreen.
» Touch FM.
» Touch Direct Tune.
» Enter the desired station and
touch Enter.
» Touch Presets and then touch and
hold one of the memory preset buttons
to save it. The system mutes briefly,
and the sound returns once it saves
the station.
Bring in Your Own Music
Gain access to any audio source by voice
and even control how each operates, like
changing radio stations, CD tracks or music
on one of the following devices:
» Smart-charging USB
» Bluetooth
» SD card*
Refer to the MyFord Touch chapter in your
Owner’s Manual, visit the website or call
the toll-free number. See the Why Do You
Need a SYNC Owner Account? section in
this guide for more details.
®
streaming
Silent Key Start
When starting your vehicle, your
gas engine may not start because
your hybrid-electric vehicle is
equipped with silent key start. This
fuel-saving feature allows your
vehicle to be ready to drive without
requiring your gas engine to be running. Look for the ‘ready to
drive’ indicator light
displays, your vehicle has started and is ready to drive.
Automatic Shutdown
With intelligent access*, this feature automatically shuts down
your vehicle if it has been idling for an extended period of time. The
ignition also turns o in order to save battery power. Before your
vehicle shuts down, a message appears in the information display,
allowing you to temporarily override the shutdown feature.
NOTE You cannot permanently switch o the automatic
shutdown feature. When you switch it o temporarily, it turns on
at the next ignition cycle. See Starting and Stopping the Engine
chapter of your Owner's Manual for more details.
in your information display. When the light
*
High-voltage Lithium-ion Battery System
The battery pack does not require regular service maintenance.
It is in the rear cargo area. Make sure you keep the vented battery
compartment, located on the rear package shelf and between the
rear speakers, free of any potential obstructions.
The battery pack should be serviced only by an authorized
technician. Improper handling can result in personal injury or
death. Refer to your Owner's Manual for more details.
Unique Driving Characteristics
When you charge your vehicle, you add electrical energy that is
then used to propel the vehicle in plug-in power mode. You can
view your estimated electric range on the Energy Use screen on the
le-hand information display. You can also configure MyView to
include detailed vehicle range information.
The system maximizes the use of electric-only operation in plug-in
power mode. System conditions may require engine operation;
however, the system uses plug-in power whenever possible.
When your vehicle depletes its plug-in power, the system
automatically switches to Hybrid mode, using both the gasoline
engine and electric motor, to power your vehicle and maximize
fuel economy.
NOTE It is normal for your electric range estimate to vary from
charge to charge, due to changes in average energy usage. Driving
style, drive route, extreme temperatures and use of the climate
controls can aect your energy usage.
EV+ Mode
Your vehicle recognizes your frequent destinations and allows for
more EV driving as you approach them. For example, when nearing
your home it should be easier to stay in electric mode. The EV
indicator displays EV+ when this mode is active. You should see
this about 1/8 mile (200 m) from a frequent destination.
You can clear your frequent destinations with a Driving History
reset through the Settings menu. You can also switch the EV+
feature o through the Driver Assist section of the Settings menu.
See the Information Display chapter in your Owner's Manual for
more details.
*if equipped
13
*if equipped
COMFORT
CONVENIENCE
Driver Seat with Easy Entry and Exit
With the easy entry and exit feature enabled in the information
display, your driver seat automatically moves rearward up to two
inches (five centimeters) when you switch the ignition o. The
driver seat returns to the previous position when you switch the
ignition on. See the Information Display chapter in your Owner’s
Manual for more details.
Climate Controlled Front Seats
For heated front seats, press repeatedly to cycle through
the various settings and o. More indicator lights mean warmer
settings. For cooled front seats, press
through the various settings and o. More indicator lights mean
cooler settings.
Moonroof
Your moonroof controls are
on the overhead console and
have a one-touch open and
close feature.
To open the moonroof, press
. It stops short of the
fully opened position to help
reduce wind noise.
To close, press
To use the venting feature,
press
*
.
.
repeatedly to cycle
*
*
Tilting Head Restraints
Your vehicle’s front head restraints have
a tilting feature for extra comfort.
To Tilt the Head Restraint
Adjust the seatback to an upright driving
or riding position. Pivot the head restraint
forward toward your head to the desired
position. Once you tilt it into the forwardmost position, tilt it forward once more to
release it to the upright position.
Ambient Lighting
Lights various places, such as the footwells, with a
choice of colors.
Access Using Your Touchscreen and Make Your Adjustments
1. Press the Settings icon > Vehicle > Ambient Lighting.
2. Touch the desired color.
3. Use the scroll bar to increase or decrease the intensity.
To switch o the feature, press the power button.
*
Intelligent Access Transmitter
NOTE Your transmitter must be within 3 feet (1 meter) of the
vehicle for intelligent access to function properly.
This system operates the power locks.
To unlock and open a door, pull the exterior door handle. Make sure
not to touch the lock sensor on top of the handle.
To unlock and open the luggage compartment, press the exterior
release button hidden above the license plate.
To lock the doors, touch the lock sensor on top of the door handle.
The transmitter also contains a mechanical key blade to unlock the
driver’s door, if necessary.
NOTE You must have a valid transmitter inside the vehicle to
switch the power on and start the vehicle.
*
Remote Start
Remote start allows you to start the vehicle from outside using
your remote transmitter.
To start, press and then press twice within three seconds.
Once inside, apply the brake while pressing the START STOP
button. Shi into drive (D) and go.
If you have the integrated keyhead transmitter, insert the key into
the ignition and switch on the ignition as you normally would before
driving. To switch o the vehicle from outside aer using your
remote start, press
Memory Function
Use the memory controls located on the driver’s door to program
and then recall memory positions. Move the seats and mirrors to the
desired positions. To program up to 3 positions, press and hold the
desired pre-set button until you hear a single tone. You can now use
these controls to recall the set positions.
You can also program your memory seats to your transmitter. That
way, when you unlock your door with the transmitter, your memory
features automatically move into your saved position. See the Seats
chapter in your Owner’s Manual for more details.
*
once.
*
*if equipped
15
*if equipped
FUNCTION
Configurable Daytime Running Lamps
When you switch the feature on in the information display,
daytime running lamps turn on when you are driving, the lighting
control is in the autolamps position
You can switch the Configurable Daytime Running Lamps ON or
OFF using the information display controls. See the Lighting chapter
in your Owner’s Manual for complete information.
Active Park Assist
The system detects an available parallel parking
space and automatically steers your vehicle into
the space (hands-free) while you control the
accelerator, gearshi and brakes.
» Press the button
center console near the gearshi lever.
The touchscreen displays a message and
a corresponding graphic to indicate it is
searching for a parking space.
» Use the direction indicator to signal which side of your vehicle
you want the system to search on. If the indicator is not on, the
system automatically searches on the vehicle's passenger side.
» When the system locates a suitable space, the touchscreen
displays a message and a tone sounds. Bring your vehicle to a
complete stop, approximately even with the vehicle in front of
where you wish to park, then follow the instructions on
the touchscreen.
NOTE The driver is always responsible for controlling the vehicle,
supervising the system and intervening, if required.
*
located on the
and the headlamps are o.
*
SmartGauge® with EcoGuide
Use your 5-way steering controls to scroll through your menu
choices. Select the following screens from the Display/Trip and
Fuel Economy menus to help improve your fuel eciency.
Engage: Provides separate gauges for gas and electric power, plus
and instantaneous fuel economy gauge.
Empower: Provides a power demand gauge with an engine on
and o threshold, plus instantaneous fuel economy gauge.
MyView: Lets you choose your preferred information to create your
own custom display.
Energy Use: A green bar indicates a positive eect on your EV range
per full charge estimate. An amber bar indicates a negative eect.
The climate power gauge shows you how much power the climate
control uses.
Eciency Leaves: Shows your short-term fuel economy.
The more leaves you have, the more eciently you are driving!
Fuel History: Tracks your fuel economy over time and helps you try
to improve your average.
Coach: Rates recent acceleration eciency, braking and cruising
behavior. The more blue you see, the better you are driving!
*if equipped
Rear View Camera
Provides a visual display of the area behind the vehicle. The image
automatically appears in the touchscreen when the vehicle is in
reverse (R) and uses green, yellow and red guides to alert you of
your proximity to objects.
Front and Rear Parking Aids
Sounds a warning tone if there is an obstacle near the vehicle's
bumpers. The warning tone increases in frequency as the object
gets closer. The rear sensors are active when the vehicle is in reverse
(R) and is traveling less than 3 mph (5 km/h). The front sensors are
active when the transmission is in any position other than park (P)
or neutral (N), and the vehicle speed is below 6 mph (10 km/h).
Lane Keeping System
Prevents unintentional driing out of your lane
through various driver alerts and steering corrections
toward the center of the lane. Set your system
settings as desired by Mode and Intensity from your
information displays screen.
Driver Alert
Monitors your driving behavior and determines when your alertness is reduced
or insufficient. When the system determines that driving ability is at risk, a tone
sounds and a message appears in the left vehicle information display screen. If
you do not make a correction, warnings continue to alert you. Press OK on the
steering wheel to clear the warning.
*
*
*
Open Window Bueting
You may hear a pulsing noise when just one of the windows is open.
Lower the opposite window slightly to reduce this noise.
BLIS® (Blind Spot Information System)
and Cross Trac Alert
BLIS is designed to aid you in detecting vehicles that may have
entered into your blind spot zone. Cross trac alert warns you of
vehicles approaching from the sides when the transmission is in
reverse (R). BLIS and cross trac turn on an amber indicator light in
the exterior mirror on the side of the vehicle the approaching vehicle
is coming from. Refer to the Driving Aids chapter in your Owner’s
Manual for more information.
NOTE Visibility aids do not replace the need to watch where
the vehicle is moving. Refer to your Owner’s Manual for safety
information, more details and limitations.
*
ECO Cruise Control
This feature saves vehicle energy by relaxing acceleration
compared to standard cruise control. For example, your vehicle
may temporarily lose speed when going uphill. ECO will appear in
the information display when you activate ECO cruise control. You
can switch it on or o in the information display, through the Driver
Assist section of the Settings menu.
*if equipped
17
ESSENTIAL FEATURES
Fuel Tank Capacity
and Fuel Info
Your vehicle has a fuel tank capacity of
14.0 gallons (53 liters). Use only “Regular”
UNLEADED fuel with an octane rating
of 87 or higher, with no more than
15% ethanol. Do not use ethanol (E85),
diesel, fuel-methanol, leaded fuel or any
other fuel because it could damage or
impair the emission control system.
Plug-in Hybrid Transmission
Due to the technologically advanced,
electronically-controlled continuously
variable transaxle, you may not feel shi
changes like those of a non-hybrid vehicle.
Since the transmission controls the engine
speed, your engine's speed may seem
elevated at times. This is normal hybrid
operation and helps deliver fuel eciency
and performance.
Easy Fuel® System
Put your vehicle into park (P) and switch
the ignition o. Unlock the fuel door by
pressing the fuel button located on the
center console to open
the fuel filler door. It
could take up to 15
seconds for the fuel
door to pop open. Insert
the fuel filler nozzle
fully and begin fueling.
Wait five to ten seconds aer pumping fuel
before removing the fuel filler nozzle. Press
the center rear edge of the fuel filler door to
close. The fuel door latches closed.
Make sure you close the fuel door
NOTE
securely aer refueling. If the fuel door
remains open and the vehicle is driven, the
check engine light in the instrument cluster
may come on. Please see your Owner’s
Manual for complete details.
NOTE When using a portable fuel
container, only use the funnel that
comes with your vehicle. Do not use
aermarket funnels as they will not
work with the Easy Fuel system, and
may cause damage. Refer to the Fuel
and Refueling chapter of your Owner's
Manual for more information.
Fuel Freshness Mode
If you mainly operate your vehicle in
plug-in power mode using electricity
from plugging in without refueling, the
gasoline in the fuel tank becomes stale
due to aging. Stale gasoline can damage
the engine and fuel system. Your vehicle
automatically operates in fuel freshness
mode if you do not refill your vehicle with
fresh fuel within an 18-month period.
Refer to the Fuel and Refueling
chapter in your Owner's Manual
for more information.
Towing Your Fusion Energi
Towing your vehicle behind an RV or any
other vehicle may be limited. Refer to
Towing the Vehicle on Four Wheels
section in the Towing chapter of your
Owner's Manual.
Roadside Assistance
Your new Ford vehicle comes with the
assurance and support of 24-hour
emergency roadside assistance.
To receive roadside assistance in the
United States, call 1-800-241-3673.
In Canada, call 1-800-665-2006.
Temporary Mobility Kit
Your vehicle comes with a temporary
mobility kit located under the load floor of
the luggage compartment. It includes an
air compressor to reinflate the tire and a
sealing compound in a canister that seals
most punctures caused by nails or similar
objects. Refer to the Wheels and Tires
chapter in your Owner’s Manual for
more details.
Tire Pressure
Monitoring System
Your vehicle displays a low tire pressure
warning light
cluster when one or more of your tires
are significantly under-inflated. If this
happens, stop and check your tires as soon
as possible, then inflate them to the proper
pressure. Refer to the Wheels and Tires
chapter of your Owner’s Manual for more
information.
in your instrument
Electric Parking Brake
This feature replaces the conventional
handbrake. The operating
switch
center console, to the le
of the gearshi lever. To
apply the electric parking
brake, pull the switch
up. The brake system
warning lamp flashes for
approximately 2 seconds, then stays lit to
confirm that you applied the parking brake.
You can release the electric parking brake
manually by switching the ignition on,
pressing the brake pedal and then pressing
the electric parking brake switch down.
Refer to the Brakes chapter in your Owner's
Manual for more details.
is on the
19
Loading...
