FORD Explorer 2014 User Manual v.2

fordowner.com ford.ca

2014 EXPLORER Owner’s Manual

fordowner.com ford.ca

2014 EXPLORER Owner’s Manual

Table of Contents 1

Introduction 10

Child Safety 18

Child seat positioning ...................................20

Booster seats .........................................22

Installing child seats ....................................25

Child safety locks ......................................38

Safety Belts 39

Fastening the safety belts ................................41

Safety belt height adjustment .............................44

Safetybeltwarninglightandindicatorchime..................45

Safety belt-minder .....................................45

Rear inflatable safety belt ................................48

Child restraint and safety belt maintenance ...................49

Personal Safety System 50

Supplementary Restraints System 51

Driver and passenger airbags .............................53

Front passenger sensing system ...........................55

Side airbags ..........................................57

Safety canopy curtain airbags .............................59

Crash sensors and airbag indicator .........................60

Airbag disposal........................................62

Keys and Remote Control 63

General information on radio frequencies.....................63

Remote control .......................................64

Keys ...............................................64

Replacing a lost key or remote control.......................70

2014 Explorer (exp) Owners Guide gf, 2nd Printing, September 2013 USA (fus)

2 Table of Contents

MyKey 71

Settings, MyKey .......................................71

Creating.............................................72

Clearing.............................................73

System status.........................................73

Remote start, MyKey ...................................74

Troubleshooting, MyKey .................................74

Locks 76

Locking and unlocking ..................................76

SecuriCode™ keyless entry keypad .........................85

Security 88

SecuriLock® passive anti-theft system.......................88

Anti-theft alarm .......................................91

Steering Wheel 93

Adjusting the steering wheel ..............................93

Steering wheel controls .................................95

Pedals 98

Adjustable pedals ......................................98

Wipers and Washers 99

Windshield wipers .....................................99

Rain-sensing wipers ....................................99

Windshield washers ...................................100

Rear-window wiper and washer ...........................100

2014 Explorer (exp) Owners Guide gf, 2nd Printing, September 2013 USA (fus)

Table of Contents 3

Lighting 101

Lighting control ......................................101

Autolamps ..........................................102

Instrument lighting dimmer ..............................102

Headlamp exit delay ...................................103

Daytime running lamps .................................103

Automatic high beam control.............................104

Front fog lamps ......................................106

Directionindicators ...................................106

Interior lamps........................................107

Windows and Mirrors 110

Power windows ......................................110

Exteriormirrors......................................112

Interior mirrors ......................................114

Sun visors ..........................................115

Moonroof ...........................................116

Instrument Cluster 118

Gauges.............................................118

Warning lamps and indicators ............................119

Audible warnings and indicators ..........................125

Information Displays 126

Controls............................................126

Trip computer .......................................130

Information messages ..................................136

Climate Control 148

Manual heating and air conditioning........................148

Dual automatic temperature control........................150

Rear window defroster .................................156

Cabin air filter .......................................156

2014 Explorer (exp) Owners Guide gf, 2nd Printing, September 2013 USA (fus)

4 Table of Contents

Seats 159

Sitting in the correct position ............................159

Head restraints.......................................160

Manual seats ........................................163

Power seats .........................................164

Memory function .....................................166

Heated seats ........................................167

Heated and ventilated seats..............................168

Rear seats ..........................................170

Universal Garage Door Opener (If Equipped) 182

HomeLink® wireless control system .......................183

Auxiliary Power Points 187

Storage Compartments 190

Center console .......................................190

Overhead console .....................................191

Starting and Stopping the Engine 192

Ignition switch .......................................193

Engine block heater ...................................197

Fuel and Refueling 199

Fuel quality .........................................200

Running out of fuel....................................202

Refueling...........................................203

Fuel consumption .....................................206

Transmission 211

Automatic transmission.................................211

Hill start assist .......................................218

2014 Explorer (exp) Owners Guide gf, 2nd Printing, September 2013 USA (fus)

Table of Contents 5

Four-Wheel Drive (If Equipped) 219

Four wheel drive .....................................219

Brakes 227

Brakes .............................................227

Hints on driving with anti-lock brakes ......................228

Parking brake........................................228

Traction Control 229

TractionControl™....................................229

Stability Control 230

AdvanceTrac® .......................................231

Terrain Response 232

Hill descent control ...................................233

Parking Aids 235

Sensing system.......................................235

Active park assist .....................................237

Rear-view camera system ...............................241

Cruise Control 246

Using cruise control ...................................246

Using Adaptive Cruise Control............................247

Driving Aids 256

Driveralert .........................................256

Lane keeping system...................................258

Blind Spot Information System (BLIS) with Cross Traffic Alert

(CTA).............................................262

Collision warning system ................................268

Steering ............................................271

2014 Explorer (exp) Owners Guide gf, 2nd Printing, September 2013 USA (fus)

6 Table of Contents

Load Carrying 273

Cargonet...........................................273

Roof racks and load carriers .............................273

Vehicle loading .......................................274

Towing 283

Trailertowing........................................283

Wrecker towing ......................................290

Recreational towing ...................................291

Driving Hints 293

Economical driving ....................................293

Floormats..........................................295

Roadside Emergencies 296

Getting roadside assistance ..............................296

Hazard warning flashers ................................297

Fuel cut-off switch ....................................297

Jump-starting the vehicle ...............................298

Customer Assistance 301

Reporting safety defects (U.S. only) .......................308

Reporting safety defects (Canada only) .....................308

Fuses 309

Changing a fuse ......................................309

Fuse specification chart ................................310

2014 Explorer (exp) Owners Guide gf, 2nd Printing, September 2013 USA (fus)

Table of Contents 7

Maintenance 319

General information ...................................319

Opening and closing the hood ............................320

Under hood overview ..................................321

Engine oil dipstick ....................................324

Engine oil check......................................324

Engine coolant check ..................................325

Automatic transmission fluid check ........................331

Brake fluid check .....................................336

Fuel filter...........................................336

Washer fluid check ....................................337

Battery ............................................337

Checking the wiper blades ..............................340

Air filter(s) .........................................341

Adjusting the headlamps ................................343

Changing a bulb ......................................345

Bulb specification chart.................................349

Vehicle Care 351

Cleaning products.....................................351

Cleaning the exterior ..................................351

Waxing.............................................353

Repairing minor paint damage ............................353

Cleaning the engine ...................................353

Cleaning the windows and wiper blades .....................354

Cleaning the interior ...................................355

Cleaning the instrument panel and instrument cluster lens .......355

Cleaning leather seats ..................................356

Cleaning the alloy wheels ...............................357

Vehiclestorage.......................................357

2014 Explorer (exp) Owners Guide gf, 2nd Printing, September 2013 USA (fus)

8 Table of Contents

Wheels and Tires 360

Tirecare ...........................................362

Using snow chains ....................................378

Tire Pressure Monitoring System (TPMS) ...................379

Changing a road wheel .................................383

Technical specifications.................................391

Wheel lug nut torque ..................................391

Capacities and Specifications 392

Engine specifications ..................................392

Part numbers ........................................398

Vehicle identification number ............................399

Vehicle certification label ...............................400

Transmission code designation............................400

Accessories 401

Accessories .........................................401

Ford Extended Service Plan 403

Audio System 406

MyFord™ system .....................................408

Satellite radio information ...............................419

Auxiliary input jack ...................................421

USB port ...........................................423

SYNC® 423

Pairing your phone for the first time .......................428

911 Assist™ .........................................443

Vehicle Health Report ..................................446

2014 Explorer (exp) Owners Guide gf, 2nd Printing, September 2013 USA (fus)

Table of Contents 9

MyFord Touch® (If Equipped) 469

Infotainment display ...................................476

Voice recognition .....................................477

Listening to music ....................................481

Phone features .......................................503

Information Menu .....................................510

Settings............................................522

Climatefeatures......................................534

Navigation system.....................................537

Appendices 549

Scheduled Maintenance 567

Normal scheduled maintenance and log .....................572

Index 584

The information contained in this publication was correct at the time of going to print. In the interest of continuous development, we reserve the right to change specifications, design or equipment at any time without notice or obligation. No part of this publication may be reproduced, transmitted, stored in a retrieval system or translated into any language in any form by any means without our written permission. Errors and omissions excepted.

2014 Explorer (exp) Owners Guide gf, 2nd Printing, September 2013 USA (fus)

10 Introduction

ABOUT THIS MANUAL

Thank you for choosing Ford. We recommend that you take some time to get to know your vehicle by reading this manual. The more that you know about it, the greater the safety and pleasure you will get from driving it.

WARNING: Always drive with due care and attention when using and operating the controls and features on your vehicle.

Note: This manual describes product features and options available throughout the range of available models, sometimes even before they are generally available. It may describe options not fitted to your vehicle.

Note: Some of the illustrations in this manual may be used for different models, so may appear different to you on your vehicle. However, the essential information in the illustrations is always correct.

Note: Always use and operate your vehicle in line with all applicable laws and regulations.

Note: Pass on this manual when selling your vehicle. It is an integral part of the vehicle.

This manual may qualify the location of a component as left-hand side or right-hand side. The side is determined when facing forward in the seat.

A. Right-hand side B. Left-hand side

Protecting the Environment

You must play your part in protecting the environment. Correct vehicle usage and the authorized disposal of waste, cleaning and lubrication materials are significant steps toward this aim.

2014 Explorer (exp) Owners Guide gf, 2nd Printing, September 2013 USA (fus)

Introduction 11

SYMBOL GLOSSARY

WARNING: You risk death or serious injury to yourself and others if you do not follow the instruction highlighted by the

warning symbol.

These are some of the symbols you may see on your vehicle.

Symbol Description Symbol Description Symbol Description

Safety alert See Owner’s

Manual

Avoid smoking, flames, or sparks

Brake fluid – non petroleum base

Check fuel cap

Child seat tether anchor

Battery Battery acid

Brake system Cabin air filter

Child Safety Door Lock and Unlock

Cruise control Do not open

Anti-lock braking system

Child seat lower anchor

when hot

Engine air filter

Engine oil Explosive gas Fan warning

Fasten safety belt

Fuel pump reset

Engine coolant

Front airbag Front fog

Fuse compartment

2014 Explorer (exp) Owners Guide gf, 2nd Printing, September 2013 USA (fus)

Engine coolant temperature

lamps

Hazard warning flasher

12 Introduction

Symbol Description Symbol Description Symbol Description

Heated rear window

Lighting control

Panic alarm Parking aid

Power steering fluid

Service engine soon

Interior luggage compartment release

Low tire pressure warning

system Power

windows front and rear

Side airbag Stability

Jack

Maintain correct fluid level

Parking brake system

Power window lockout

control

Windshield defrost and demist

DATA RECORDING

Service Data Recording

Service data recorders in your vehicle are capable of collecting and storing diagnostic information about your vehicle. This potentially includes information about the performance or status of various systems and modules in the vehicle, such as engine, throttle, steering or brake systems. In order to properly diagnose and service your vehicle, Ford Motor Company, Ford of Canada, and service and repair facilities may access or share among them vehicle diagnostic information received through a direct connection to your vehicle when diagnosing or servicing your vehicle. Additionally, when your vehicle is in for service or repair, Ford Motor Company, Ford of Canada, and service and repair facilities may access or share among them data for vehicle improvement purposes. For U.S. only (if equipped), if you choose to use the SYNC® Vehicle Health Report, you consent that certain diagnostic information may also be accessed electronically by Ford Motor Company and Ford authorized service facilities, and that the diagnostic information may be used for any purpose. See the SYNC® chapter for more information.

Windshield washer and wiper

2014 Explorer (exp) Owners Guide gf, 2nd Printing, September 2013 USA (fus)

Introduction 13

Event Data Recording

This vehicle is equipped with an event data recorder (EDR). The main purpose of an EDR is to record, in certain crash or near crash-like situations, such as an airbag deployment or hitting a road obstacle; this data will assist in understanding how a vehicle’s systems performed. The EDR is designed to record data related to vehicle dynamics and safety systems for a short period of time, typically 30 seconds or less. The EDR in this vehicle is designed to record such data as:

• How various systems in your vehicle were operating;

• Whether or not the driver and passenger safety belts were

buckled/fastened;

• How far (if at all) the driver was depressing the accelerator and/or the brake pedal;

• How fast the vehicle was travelling;

• Where the driver was positioning the steering wheel.

This data can help provide a better understanding of the circumstances in which crashes and injuries occur.

Note: EDR data is recorded by your vehicle only if a non-trivial crash situation occurs; no data is recorded by the EDR under normal driving conditions and no personal data or information (e.g., name, gender, age, and crash location) is recorded (see limitations regarding 911 Assist and Traffic, Directions and Information privacy below). However, parties, such as law enforcement, could combine the EDR data with the type of personally identifying data routinely acquired during a crash investigation.

To read data recorded by an EDR, special equipment is required, and access to the vehicle or the EDR is needed. In addition to the vehicle manufacturer, other parties, such as law enforcement, that have such special equipment, can read the information if they have access to the vehicle or the EDR. Ford Motor Company and Ford of Canada do not access event data recorder information without obtaining consent, unless pursuant to court order or where required by law enforcement, other government authorities or other third parties acting with lawful authority. Other parties may seek to access the information independently of Ford Motor Company and Ford of Canada.

Note: Including to the extent that any law pertaining to Event Data Recorders applies to SYNC® or its features, please note the

2014 Explorer (exp) Owners Guide gf, 2nd Printing, September 2013 USA (fus)

14 Introduction

following: Once 911 Assist (if equipped) is enabled (set ON), 911 Assist may, through any paired and connected cell phone, disclose to emergency services that the vehicle has been in a crash involving the deployment of an airbag or, in certain vehicles, the activation of the fuel pump shut-off. Certain versions or updates to 911 Assist may also be capable of being used to electronically or verbally provide to 911 operators the vehicle location (such as latitude and longitude), and/or other details about the vehicle or crash or personal information about the occupants to assist 911 operators to provide the most appropriate emergency services. If you do not want to disclose this information, do not activate the 911 Assist feature. See your SYNC® chapter for more information.

Additionally, when you connect to Traffic, Directions and Information (if equipped, U.S. only), the service uses GPS technology and advanced vehicle sensors to collect the vehicle’s current location, travel direction, and speed (“vehicle travel information”), only to help provide you with the directions, traffic reports, or business searches that you request. If you do not want Ford or its vendors to receive this information, do not activate the service. Ford Motor Company and the vendors it uses to provide you with this information do not store your vehicle travel information. For more information, see Traffic, Directions and Information, Terms and Conditions. See your SYNC® chapter for more information.

CALIFORNIA PROPOSITION 65

WARNING: Some constituents of engine exhaust, certain vehicle

components, certain fluids contained in vehicles and certain products of component wear contain or emit chemicals known to the State of California to cause cancer and birth defects or other reproductive harm.

PERCHLORATE MATERIAL

Note: Certain components in your vehicle, such as airbag modules, safety belt pretensioners, and remote control batteries, may contain perchlorate material. Special handling may apply for service or vehicle end of life disposal. See www.dtsc.ca.gov/hazardouswaste/perchlorate for more information.

2014 Explorer (exp) Owners Guide gf, 2nd Printing, September 2013 USA (fus)

Introduction 15

FORD CREDIT (U.S. ONLY)

Ford Credit offers a full range of financing and lease plans to help you acquire your vehicle. If you have financed or leased your vehicle through Ford Credit, thank you for your business.

For your convenience, we offer a number of ways to contact us, as well as help manage your account.

Phone: 1-800-727-7000 For more information regarding Ford Credit, as well as access to

Account Manager, please go to www.fordcredit.com.

REPLACEMENT PARTS RECOMMENDATION

Your vehicle has been built to the highest standards using quality parts. We recommend that you demand the use of genuine Ford and Motorcraft parts whenever your vehicle requires scheduled maintenance or repair. You can clearly identify genuine Ford and Motorcraft parts by looking for the Ford, FoMoCo or Motorcraft branding on the parts or their packaging.

Scheduled Maintenance and Mechanical Repairs

One of the best ways for you to make sure that your vehicle provides years of service is to have it maintained in line with our recommendations using parts that conform to the specifications detailed in this owner’s manual. Genuine Ford and Motorcraft parts meet or exceed these specifications.

Collision Repairs

We hope that you never experience a collision, but accidents do happen. Genuine Ford replacement collision parts meet our stringent requirements for fit, finish, structural integrity, corrosion protection and dent resistance. During vehicle development, we validate that these parts deliver the intended level of protection as a whole system. A great way to know for sure you are getting this level of protection is to use genuine Ford replacement collision parts.

Warranty on Replacement Parts

Genuine Ford and Motorcraft replacement parts are the only replacement parts that benefit from a Ford Warranty. Damage caused to your vehicle as a result of the failure of non-Ford parts may not be covered by the Ford Warranty. For additional information, see the terms and conditions of the Ford Warranty.

2014 Explorer (exp) Owners Guide gf, 2nd Printing, September 2013 USA (fus)

16 Introduction

SPECIAL NOTICES

New Vehicle Limited Warranty

For a detailed description of what is covered and what is not covered by your vehicle’s New Vehicle Limited Warranty, see the warranty information that is provided to you along with your owner’s manual.

Special Instructions

For your added safety, your vehicle is fitted with sophisticated electronic controls.

WARNING: Please read the Supplementary Restraints System

chapter. Failure to follow the specific warnings and instructions could result in personal injury.

WARNING: Front seat mounted rear-facing child or infant seats

should NEVER be placed in front of an active passenger airbag.

Notice to owners of pickup trucks and utility type vehicles

WARNING: Utility vehicles have a significantly higher rollover

rate than other types of vehicles.

Before you drive your vehicle, please read this Owner’s Manual carefully. Your vehicle is not a passenger car. As with other vehicles of this type, failure to operate your vehicle correctly may result in loss of vehicle control, vehicle rollover, personal injury or death.

Using your vehicle with a snowplow

Do not use this vehicle for snowplowing.

Your vehicle is not equipped with a snowplowing package.

Using your vehicle as an ambulance

Do not use this vehicle as an ambulance.

Your vehicle is not equipped with the Ford Ambulance Preparation Package.

2014 Explorer (exp) Owners Guide gf, 2nd Printing, September 2013 USA (fus)

Introduction 17

MOBILE COMMUNICATIONS EQUIPMENT

Using mobile communications equipment is becoming increasingly important in the conduct of business and personal affairs. However, you must not compromise your own or others’ safety when using such equipment. Mobile communications can enhance personal safety and security when appropriately used, particularly in emergency situations. Safety must be paramount when using mobile communications equipment to avoid negating these benefits.

Mobile communication equipment includes, but is not limited to, cellular phones, pagers, portable email devices, text messaging devices and portable two-way radios.

WARNING: Driving while distracted can result in loss of vehicle

control, crash and injury. We strongly recommend that you use extreme caution when using any device that may take your focus off the road. Your primary responsibility is the safe operation of your vehicle. We recommend against the use of any handheld device while driving and encourage the use of voice-operated systems when possible. Make sure you are aware of all applicable local laws that may affect the use of electronic devices while driving.

EXPORT UNIQUE (NON–UNITED STATES/CANADA) VEHICLE SPECIFIC INFORMATION

For your particular global region, your vehicle may be equipped with features and options that are different from the features and options that are described in this owner’s manual. A market unique supplement may be supplied that complements this book. By referring to the market unique supplement, if provided, you can properly identify those features, recommendations and specifications that are unique to your vehicle. This owner’s manual is written primarily for the U.S. and Canadian Markets. Features or equipment listed as standard may be different on units built for Export. See this owner’s manual for all other required

information and warnings.

2014 Explorer (exp) Owners Guide gf, 2nd Printing, September 2013 USA (fus)

18 Child Safety

GENERAL INFORMATION

See the following sections for directions on how to properly use safety restraints for children.

WARNING: Always make sure your child is secured properly in a

device that is appropriate for their height, age and weight. Child safety restraints must be bought separately from your vehicle. Failure to follow these instructions and guidelines may result in an increased risk of serious injury or death to your child.

WARNING: All children are shaped differently. The

recommendations for safety restraints are based on probable child height, age and weight thresholds from NHTSA and other safety organizations, or are the minimum requirements of law. Ford recommends checking with a NHTSA Certified Child Passenger Safety Technician (CPST) and consulting your pediatrician to make sure your child seat is appropriate for your child, and is compatible with and properly installed in your vehicle. To locate a child seat fitting station and CPST, contact the NHTSA toll free at 1-888-327-4236 or on the internet at http://www.nhtsa.dot.gov. In Canada, check with your local St. John Ambulance office for referral to a CPST or for further information, contact your provincial ministry of transportation, or locate your local St. John Ambulance office by searching for St. John Ambulance on the internet, or Transport Canada at 1–800–333–0371 (http://www.tc.gc.ca). Failure to properly restrain children in safety seats made especially for their height, age, and weight may result in an increased risk of serious injury or death to your child.

2014 Explorer (exp) Owners Guide gf, 2nd Printing, September 2013 USA (fus)

Child Safety 19

Recommendations for Safety Restraints for Children

Child size, height, weight, or age

Infants or toddlers

Small children

Larger children

• You are required by law to properly use safety seats for infants and toddlers in the United States and Canada.

• Many states and provinces require that small children use approved booster seats until they reach age eight, a height of 4 feet 9 inches (1.45 meters) tall, or 80 pounds (36 kilograms). Check your local and state or provincial laws for specific requirements about the safety of children in your vehicle.

• When possible, always properly restrain children twelve (12) years of age and under in a rear seating position of your vehicle. Accident statistics suggest that children are safer when properly restrained in the rear seating positions than in a front seating position. See Front Passenger Sensing System in the Supplementary Restraints System chapter for more information.

Children weighing 40 lb (18 kg) or less (generally age four or younger).

Children who have outgrown or no longer properly fit in a child safety seat (generally children who are less than 4 ft. 9 in. (1.45 m) tall, are greater than age four (4) and less than age twelve (12), and between 40 lb (18 kg) and 80 lb (36 kg) and upward to 100 lb (45 kg) if recommended by your child restraint manufacturer).

Children who have outgrown or no longer properly fit in a belt-positioning booster seat (generally children who are at least 4 ft. 9 in. (1.45 m) tall or greater than 80 lb (36 kg) or 100 lb (45 kg) if recommended by child restraint manufacturer).

Recommended restraint type

Use a child safety seat (sometimes called an infant carrier, convertible seat, or toddler seat).

Use a belt-positioning booster seat.

Use a vehicle safety belt having the lap belt snug and low across the hips, shoulder belt centered across the shoulder and chest, and seat back upright.

2014 Explorer (exp) Owners Guide gf, 2nd Printing, September 2013 USA (fus)

20 Child Safety

CHILD SEAT POSITIONING

WARNING: Airbags can kill or injure a child in a child seat.

Never place a rear-facing child seat in front of an active airbag. If you must use a forward-facing child seat in the front seat, move the vehicle seat upon which the child seat is installed all the way back. When possible, all children age 12 and under should be properly restrained in a rear seating position. If all children cannot be seated and restrained properly in a rear seating position, properly restrain the largest child in the front seat.

WARNING: Always carefully follow the instructions and

warnings provided by the manufacturer of any child restraint to determine if the restraint device is appropriate for your child’s size, height, weight, or age. Follow the child restraint manufacturer’s instructions and warnings provided for installation and use in conjunction with the instructions and warnings provided by your vehicle manufacturer. A safety seat that is improperly installed or utilized, is inappropriate for your child’s height, age or weight, or does not properly fit the child, may increase the risk of serious injury or death.

WARNING: Never let a passenger hold a child on his or her lap

while your vehicle is moving. The passenger cannot protect the child from injury in a crash, which may result in serious injury or death.

WARNING: Never use pillows, books, or towels to boost a child.

They can slide around and increase the likelihood of injury or death in a crash.

WARNING: Always restrain an unoccupied child seat or booster

seat. These objects may become projectiles in a crash or sudden stop, which may increase the risk of serious injury.

2014 Explorer (exp) Owners Guide gf, 2nd Printing, September 2013 USA (fus)

Child Safety 21

WARNING: Never place, or allow a child to place, the shoulder

belt under a child’s arm or behind the back because it reduces the protection for the upper part of the body and may increase the risk of injury or death in a crash.

WARNING: To avoid risk of injury, do not leave children or pets

unattended in your vehicle.

Use any attachment method as indicated

below by X.

Combined

weight of Restraint Ty pe

Rear-facing child seat

Forwardfacing child seat

Note: The child seat must rest tightly against the vehicle seat upon which it is installed. It may be necessary to lift or remove the head restraint. See the Seats chapter for information on head restraints.

child and

child

restraint

seat

Up to 65 lb (29.5 kg)

Over 65 lb (29.5 kg)

Up to 65 lb (29.5 kg) XXX

Over 65 lb (29.5 kg) XX

LATCH (lower anchors and top tether anchor)

LATCH (lower anchors only)

Safety belt and top tether anchor

Safety belt and LATCH (lower anchors and top tether anchor)

Safety belt only

2014 Explorer (exp) Owners Guide gf, 2nd Printing, September 2013 USA (fus)

22 Child Safety

BOOSTER SEATS

WARNING: Never place, or allow a child to place, the shoulder

belt under a child’s arm or behind the back because it reduces the protection for the upper part of the body and may increase the risk of injury or death in a crash.

Note: Some booster seat safety belt guides may not accommodate the shoulder portion of the inflatable safety belt.

Use a belt-positioning booster seat for children who have outgrown or no longer properly fit in a child safety seat (generally children who are less than 4 feet 9 inches (1.45 meters) tall, are greater than age four (4) and less than age twelve (12), and between 40 pounds (18 kilograms) and 80 pounds (36 kilograms) and upward to 100 pounds (45 kilograms) if recommended by your child restraint manufacturer). Many state and provincial laws require that children use approved booster seats until they reach age eight, a height of 4 feet 9 inches (1.45 meters) tall, or 80 pounds (36 kilograms).

Booster seats should be used until you can answer YES to ALL of these questions when seated without a booster seat.

• Can the child sit all the way back against their vehicle seat with knees bent comfortably at the edge of the seat cushion?

• Can the child sit without slouching?

• Does the lap belt rest low across the hips?

• Is the shoulder belt centered on the shoulder and chest?

• Can the child stay seated like this for the whole trip?

Always use booster seats in conjunction with your vehicle lap and shoulder belt.

2014 Explorer (exp) Owners Guide gf, 2nd Printing, September 2013 USA (fus)

Child Safety 23

Types of Booster Seats

• Backless booster seats

If your backless booster seat has a removable shield, remove the shield. If a vehicle seating position has a low seat back or no head restraint, a backless booster seat may place your child’s head (as measured at the tops of the ears) above the top of the seat. In this case, move the backless booster to another seating position with a higher seat back or head restraint and lap and shoulder belts, or consider using a high back booster seat.

• High back booster seats

If, with a backless booster seat, you cannot find a seating position that adequately supports your child’s head, a high back booster seat would be a better choice.

2014 Explorer (exp) Owners Guide gf, 2nd Printing, September 2013 USA (fus)

24 Child Safety

Children and booster seats vary in size and shape. Choose a booster that keeps the lap belt low and snug across the hips, never up across the stomach, and lets you adjust the shoulder belt to cross the chest and rest snugly near the center of the shoulder. The following drawings compare the ideal fit (center) to a shoulder belt uncomfortably close to the neck and a shoulder belt that could slip off the shoulder. The drawings also show how the lap belt should be low and snug across the child’s hips.

If the booster seat slides on the vehicle seat upon which it is being used, placing a rubberized mesh sold as shelf or carpet liner under the booster seat may improve this condition. Do not introduce any item thicker than this under the booster seat. Check with the booster seat manufacturer’s instructions.

2014 Explorer (exp) Owners Guide gf, 2nd Printing, September 2013 USA (fus)

Child Safety 25

INSTALLING CHILD SEATS

Child Seats

Use a child safety seat (sometimes called an infant carrier, convertible seat, or toddler seat) for infants, toddlers or children weighing 40 pounds (18 kilograms) or less (generally age four or younger).

Using Lap and Shoulder Belts

WARNING: Airbags can kill or injure a child in a child seat.

Never place a rear-facing child seat in front of an active airbag. If you must use a forward-facing child seat in the front seat, move the seat upon which the child seat is installed all the way back.

WARNING: Airbags can kill or injure a child in a child seat.

Children 12 and under should be properly restrained in the rear seat whenever possible.

WARNING: Depending on where you secure a child restraint,

and depending on the child restraint design, you may block access to certain safety belt buckle assemblies or LATCH lower anchors, rendering those features potentially unusable. To avoid risk of injury, occupants should only use seating positions where they are able to be properly restrained.

When installing a child safety seat with combination lap and shoulder belts:

• Use the correct safety belt buckle for that seating position.

• Insert the belt tongue into the proper buckle until you hear a snap

and feel it latch. Make sure the tongue is securely fastened in the buckle.

2014 Explorer (exp) Owners Guide gf, 2nd Printing, September 2013 USA (fus)

26 Child Safety

• Keep the buckle release button pointing up and away from the safety seat, with the tongue between the child seat and the release button, to prevent accidental unbuckling.

• Place the vehicle seat upon which the child seat will be installed in the upright position.

• For second-row seating positions, the recliner may be adjusted slightly to improve child seat fit. If needed, the head restraints may be removed.

• For third-row seating positions, the head restraints may be stowed to improve child seat fit. See the Seats chapter for information on folding the head restraints.

• Put the safety belt in the automatic locking mode. See Step 5 below. This vehicle does not require the use of a locking clip.

Perform the following steps when installing the child seat with combination lap and shoulder belts:

Note: Although the child seat illustrated is a forward-facing child seat, the steps are the same for installing a rear-facing child seat.

Note: The lock-off device on some child restraints may not accommodate the shoulder portion of the inflatable safety belt. Follow all instructions provided by the manufacturer of the child restraint regarding the necessary and proper use of the lock-off device. In some instances these devices have been provided only for use in vehicles with safety belt systems that would otherwise require a locking clip.

1. Position the child safety seat in a seat with a combination lap and shoulder belt.

2014 Explorer (exp) Owners Guide gf, 2nd Printing, September 2013 USA (fus)

Child Safety 27

2. After positioning the child safety seat in the proper seating position, do the following:

• Standard safety belt: pull down on the shoulder belt and then grasp the shoulder belt and lap belt together behind the belt tongue.

• Inflatable safety belt: grasp the shoulder belt and lap belt together behind the belt tongue.

3. While holding the shoulder and lap belt portions together, route the tongue through the child seat according to the child seat manufacturer’s instructions. Be sure the belt webbing is not twisted.

2014 Explorer (exp) Owners Guide gf, 2nd Printing, September 2013 USA (fus)

28 Child Safety

4. Insert the belt tongue into the proper buckle (the buckle closest to the direction the tongue is coming from) for that seating position until you hear a snap and feel the latch engage. Make sure the tongue is latched securely by pulling on it.

• Standard safety belt buckle

• Inflatable safety belt buckle

2014 Explorer (exp) Owners Guide gf, 2nd Printing, September 2013 USA (fus)

+ 563 hidden pages
