FMI LEF36 User Manual

FMI PRODUCTS, LLC

F3610G

36 IN. ELECTIC FIREPLACE

FMI MODEL # LEF36

Mounting Base Feet and Wall Mounting

Bracket Included

FMI Products, LLC

TABLE OF CONTENTS

Safety Information ............................................................................................................................

3

Operating Instructions ......................................................................................................................

4

Installation Instructions .....................................................................................................................

7

Maintenance ....................................................................................................................................

9

Troubleshooting ...............................................................................................................................

Illustrated parts breakdown .................................................................................................................

Warranty ...............................................................................................................................

10
11
12

2

SAFETY INFORMATION

！

Please read and understand this entire manual before attempting to assemble, operate or install
the product.

！

in

When using electrical appliances, basic precautions should always be followed to reduce the risk of fire, electric shock
and injury to persons including the following:

1. Read the manufacturer’s instructions completely before using this appliance.

2. This appliance will become hot when in use. To avoid burns, do not let bare skin touch hot surfaces. The grill at

3. Extreme caution is necessary when the appliance is used by or near children or invalids and whenever the heater

4. Do not operate the heater if the power cord or plug has been damaged or the heater has been damaged or

WARNING: Any use of this appliance other than that recommended by the manufacturer

this owners manual may cause fire, burns, electric shock and/or other serious injuries or death.

the top of this heater in particular will become hot when the heater is active. Take special care not to block the
air intake or exhaust vents.

is left operating and unattended.

malfunctioned in any way. Take the appliance to an authorized service facility for examination, electrical or
mechanical adjustment or repair.

5. Do not use outdoors.

6. This heater is not intended for use in bathrooms, laundry areas and similar indoor locations. Never locate heater
where it may fall into a bathtub or other water container.

7. To disconnect the appliance, turn all controls “OFF”, and then remove the plug from the electrical outlet.

8. The appliance comes equipped with a 3 prong-grounding plug. Do not cut the grounding prong. Connect to
properly grounded 120V outlets only.

9. Do not insert or allow foreign objects to enter any ventilation or exhaust openings as this may cause an electric
shock or fire, or damage the appliance.

10. To prevent a possible fire, do not block air intakes or exhausts in any manner. Do not use on soft surfaces, like a
bed, where openings may become blocked.

11. All electrical heaters have hot and arcing or sparking parts inside. Do not use in areas where gasoline, paint, or
flammable liquids are used or stored or where the appliance will be exposed to flammable vapors.

12. Avoid using the appliance with an extension cord. Extension cords may overheat and cause a risk of fire. If an
extension cord MUST be used, the cord must be No. 16AWG minimum size and rated not less than 1875 Watts.
The extension cord must be a 3-prong cord with grounding type plug and cord connection and should not
exceed 20feet (6m) in length.

13. When transporting or storing the heater, take care to keep both the unit and power cord/plug dry, free from
excessive vibration and away from heat sources.

14. Use the heater only as described in this manual. Any other use not recommended by the manufacturer may
cause fire, electric shock, or injury to persons.

15. Do not attempt to burn wood or other materials in this heater.

3

OPERATING INSTRUCTIONS

Read all instructions and warning prior to operating the appliance.

Ensure that all controls are in the position before plugging the appliance in to a properly grounded
electrical outlet.

The main control panel is located behind the cover at the top right corner on the front (see Figure 1).

Control Panel

Figure 1

This heater is for use on 120 Volts. The heater has a 3-prong grounded plug (Figure 2.A). If your electrical outlet
has only 2 slots (Figure 2.B), you will have to use an adapter (Figure 2.C) to convert from the 3-prong power cord
to a 2-slot receptacle. The green grounding plug extending from the adapter must be securely connected to a
permanent ground such as a properly grounded outlet box. The adapter should only be used if a proper 3-slot
receptacle is not available.

NOTE:

Adapters

are

not allowed

for

use

in

Canada.

Figure 2

A 15 AMP circuit is required to operate this appliance. If the breaker trips when the appliance is running, you may
need to move the appliance to another location or unplug other appliances that are on the same circuit.

4
