Flymo Electrolux Multi-Trim User Manual

GB

IMPORTANT INFORMATION

Read before use and retain for future reference

D

WICHTIGE INFORMATION

Bitte vor dem Benutzen des Gerätes
durchlesen und gut aufbewahren

F

RENSEIGNEMENTS IMPORTANTS

A lire avant usage et à conserver pour
référence ultérieure

NL

BELANGRIJKE INFORMATIE

Leest u deze informatie voor het gebruik en
bewaar ze voor toekomstige raadpleging

N

VIKTIG INFORMASJON

Les bruksanvisningen nøye før bruk og
oppbevar den for senere bruk

S

VIKTIG INFORMATION

Läs anvisningarna före användningen och
spara dem för framtida behov

DK

VIGTIGE OPLYSNINGER

Du bør læse brugsanvisningen før brug og
gemme til senere henvisning

E

INFORMACIÓN IMPORTANTE

Léase antes de utilizar y consérvela como
referencia en el futuro

P

INFORMAÇÕES IMPORTANTES

Leia antes de utilizar e guarde para consulta
futura

I

INFORMAZIONI IMPORTANTI

Leggere prima dell’uso e conservare per
ulteriore consultazione

SF

TÄRKEÄÄ TIETOA

Lue tämä ennen käyttöä ja säilytä myöhempää
tarvetta varten

SK

Záruka na tento produkt nebude uznaná v
prípade porúch spôsobených nesprávnou
obsluhou alebo používaním výrobku na iný
účel alebo iným spôsobom, ako je uvedené.
Pred začatím práce si prosím dôkladne
prečítajte návod na obsluhu a tento si aj pre
prípad potreby uschovajte

SL

Garancija ne velja ob nepravilni uporabi
proizvoda in/ali ob uporabi za drugi namen
kot je izdelan. Prosimo, da pred uporabo,
preverite pazljivo navodila za obratovanje in
jih shranite za kasnejšo rabo.

HU

Jótállást vállalni csak rendeltetésszerűen
használatba vett gépekre tudunk. Kérjük,
hogy a gép használatba vétele elött
gondosan olvassa el a kezelési utasításokat.

PL

Gwarancja traci ważność w przypadku
używania urządzenia do celów innych niż
wymienione w instrukcji obsługi. Prosimy o
uważne przeczytanie instrukcji oraz o
stosowanie się do zaleceń i wskazówek w
niej zawartych

CZ

Záruka se nebude vztahovat na závady
způsobené nesprávným používáním, nebo
jestliže bude výrobek použit pro jiné účely
než pro jaké byl vyroben, nebo také jinak
než je uvedeno v návodu k obsluze. Tento
návod si přečtěte, prosím, velmi pozorně a
uchovejte jej pro možné budoucí odkazy

GB - CONTENTS

1. Steady Handle

2. Bolt

3. Handle Knob

4. Nut (if applicable)

5. Scraper Tool (Multi Trim 200)

6. Safety Guard

7. Instruction Manual

8. Warning Label

9. Product Rating Label

D - INHALT

1. Haltegriff

2. Bolzen

3. Griffknopf

4. Mutter (falls vorhanden)

5. Reinigungvwerkzeug (Multi
Trim 200)

6. Schutzvorrichtung

7. Bedienungsanweisung

8. Warnetikett

9. Produkttypenschild

F - TABLE DES MATIÈRES

1. Poignée auxiliaire

2. Vis

3. Vis papillon

4. Ecrou (si applicable)

5. Racloir (Multi Trim 200)

6. Carter

7. Manuel d’Instructions

8. Etiquette d’avertissement

9. Plaquette des
Caractéristiques du Produit

NL - INHOUD

1. Tweede handvat

2. Bout

3. Handvatknop

4. Moer (indien van toepassing)

5. Schraper (Multi Trim 200)

6. Beschermplaat

7. Handleiding

8. Garantiekaart

9. Product-informatielabel

N - INNHOLD

1. Håndtaksbøyle

2. Festebolt

3. Mutter for håndtaksbolt

4. Mutter (om relevant)

5. Plast skrape (Multi Trim 200)

6. Trimmerskjerm

7. Bruksanvisning

8. Advarselsetikett

9. Produktmerking

SF - SISÄLTÖ

1. Vakain

2. Pultti

3. Kahvan nuppi

4. Mutteri (jos käytössä)

5. Kaavin (Multi Trim 200)

6. Teränsuojus

7. Käyttöopas

8. Takuukortti

9. Ruohonleikkurin arvokilpi

S - INNEHÅLL

1. Stödhandtag

2. Bult

3. Handtagsratt

4. Mutter (om sådan är
monterad)

5. Skrapare (Multi Trim 200)

6. Trimmersköld

7. Bruksanvisning

8. Varningsetikett

9. Produktmärkning

DK - INDHOLD

1. Støttehåndtag

2. Bolt

3. Håndtagsknop

4. Møtrik (hvis relevant)

5. Skrabeværktøj (Multi Trim

200)

6. Beskyttelsesskærm

7. Brugsvejledning

8. Advarselsmœrkat

9. Produktets mærkeskilt

E - CONTENIDO

1. Manilla del asa

2. Perno

3. Gatillo del Manillar

4. Tuerca (si fuera aplicable)

5. Herramienta de raspar (Multi
Trim 200)

6. Cubierta protectora

7. Manual de instrucciones

8. Etiqueta de Advertencia

9. Placa de Características del
Producto

P - LEGENDA

1. Pega fixa

2. Parafuso

3. Fêmea do parafuso da pega

4. Porca (se aplicável)

5. Ferramenta para raspar (Multi
Trim 200)

6. Protecção de segurança

7. Manual de Instrucções

8. Etiqueta de Aviso

9. Rótulo de Avaliação do
Produto

I - INDICE CONTENUTI

1. Impugnatura

2. Bullone

3. Manopola dell’impugnatura

4. Dado (se pertinente)

5. Raschietto (Multi Trim 200)

6. Protezione testa di taglio

7. Manuale di istruzioni

8. Etichetta di pericolo

9. Etichetta dati del prodotto

HU - TARTALOMJEGYZÉK

1. Alsó fogantyú

2. Csavar

3. Fogantyúgomb

4. Anya (ha van)

5. Kaparószerszám (Multi Trim

200)

6. Biztonsági perem

7. Kezelési útmutató

8. Figyelmeztető címke

9. Termékminősítő címke

PL - ZAWARTOSC KARTONU

1. Uchwyt

2. Śruba

3. Gałka uchwytu

4. Nakrętka (jeżeli jest)

5. Skrobak (Multi Trim 200)

6. Osłona bezpieczeństwa

7. Instrukcja Obsługi

8. Znaki bezpieczeństwa

9. Tabliczka znamionowa

CZ - POPIS STROJE

1. Pevná rukoje:

2. Šroub

3. Křídlová matice

4. Matice (pokud se používá)

5. Škrabka (Multi Trim 200)

6. Ochranný kryt

7. Návod k obsluze

8. Výstražný štĺtek

9. Typový štĺtek výrobku

SK - OBSAH

1. Oporná rukovä:

2. Skrutka

3. Otáčavý gombík rukoväte

4. Matka (ak aplikovatené)

5. Škrabka (Multi Trim 200)

6. ochranny kryt

7. Príručka

8. Varovný štítok

9. Prístrojový štítok

SL - VSEBINA

1. Ravnotežno držalo

2. Vijak

3. Krilna matica

4. Matica (če je priložena)

5. Strgalo (Multi Trim 200)

6. Varnostno vodilo

7. Priročnik

8. Opozorilna oznaka

9. Tipna tablica

(GB) CARTON CONTENTS
(D) KARTONINHALT
(F) CONTENU DU CARTON
(NL) INHOUD
(N) KARTONGEN

INNEHOLDER

(SF) PAKETIN SISÄLTÖ

(S) FÖRPACKNINGENS

INNEHÅLL
(DK) KARTONINDHOLD
(E) CONTENIDO DEL

CARTON
(P) LEGENDAS DOS

DESENHOS

(I) CONTENUTO

(HU) A DOBOZ TARTALMA
(PL) ZAWARTOŚĆ KARTONU
(CZ) OBSAH KRABICE
(SK) OBSAH BALENIA
(SL) VSEBINA ŠKATLE

1

2

3

5

6

7

1

2

3

6

7

8

9

8

9

4

4

A B C

4

2

FD

E

2

1

3

1

G

H

1

J1

a

J2

a

b

Multi Trim 200

L

M

K

3

PN QO

a

a

R1

R2

S1

S3

S4

S2

a

a

e

d

c

b

a

a

b

T1

T3

T2

1

2

a

b

c

d

e

a

b

U

W

Multi Trim 200

V

X

SAFETY PRECAUTIONS

Explanation of Symbols on the Multi Trim

Warning

Read the user instructions carefully to
make sure you understand all the
controls and what they do.

Keep others, including children, pets
and bystanders outside the 10 metre
hazard zone. Stop the trimmer
immediately if you are approached.

The use of eye protection is
recommended to protect against
objects thrown by the cutting line.

To avoid the possibility of electric
shock, do not use in damp or wet
conditions.

Switch off! Remove plug from mains
before adjusting, cleaning or if cable is
entangled or damaged.

Warning

The cutting line continues to rotate after the machine
has been switched off.

General

1. Never allow children or people unfamiliar with these
instructions to use the trimmer. Local regulations
may restrict the age of the operator.

2. Only use the trimmer in the manner and for the
functions described in these instructions.

3. Never operate the trimmer when you are tired, ill or
under the influence of alcohol, drugs or medicine.

4. The operator or user is responsible for accidents or
hazards occurring to other people or their property.

Electrical

1. The use of a Residual Current Device (R.C.D.) with a
tripping current of not more than 30mA is recommended.
Even with a R.C.D. installed 100% safety cannot be
guaranteed and safe working practice must be followed
at all times. Check your R.C.D. every time you use it.

2. Before use, examine cable for damage, replace it if
there are signs of damage or ageing.

3. Do not use the trimmer if the electric cables are
damaged or worn.

4. Immediately disconnect from the mains electricity
supply if the cable is cut, or the insulation is damaged.
Do not touch the electric cable until the electrical
supply has been disconnected. Do not repair a cut or
damaged cable. Replace it with a new one.

5. Your extension cable must be uncoiled, coiled cables
can overheat and reduce the efficiency of your trimmer.

6. Keep the cable clear of the cutting area and
obstacles at all times.

7. Do not pull cable around sharp objects.

8. Always switch off at the mains before disconnecting
any plug, cable connector or extension cable.

9. Switch off, remove plug from mains and examine
electric supply cable for damage or ageing befor

e

winding cable for storage. Do not repair a damaged
cable, replace it with a new one. Use only Flymo
replacement cable.

10. Always wind cable carefully, avoiding kinking.

11. Use only on AC mains supply voltage shown on the
product rating label.

12. Flymo trimmers are double insulated to EN60335.
Under no circumstance should an earth be
connected to any part of the trimmer.

13. Never carry the trimmer by the cable.

14. Never pull on the cable to disconnect any of the
plugs.

Cables

Use only 1.00mm

2

size cable up to 30 metres length
maximum.
Maximum rating:

1.00mm2size cable 10 amps 250 volts AC

1. Mains cables and extensions are available from

your local Electrolux Outdoor Products Approved
Service Centre.

2. Only use extension cables specifically designed for

outdoor use.

Preparation

1. While using your product always wear substantial

footwear and long trousers.

2. Before using the machine and after any impact,

check for signs of wear or damage and repair as
necessary

3. Inspect the area to be cut before each use. Remove

all objects such as stones, broken glass, nails, wire,
string etc, which can be thrown or become
entangled in the trimmer head.

4. Check that the cutting head, spool and cap are fitted

correctly.

Use
AVOID ACCIDENTAL STARTING. REMOVE PLUG
FROM MAINS AND KEEP FEET AWAY FROM THE
SWITCH LEVER WHEN:- CLEANING AROUND THE
INSIDE OF THE SAFETY GUARD, REMOVING OR
REFITTING SPOOL CAP, MANUALLY FEEDING OR
REPLACING NYLON LINE.

1. Use the trimmer only in daylight or good artificial light.

2. Avoid operating your trimmer in wet grass, where

feasible.

3. Take care in wet grass, you may lose your footing.

Walk, never run.

4. On slopes, be extra careful of your footing and wear

non-slip footwear.

5. Do not walk backwards when trimming , you could trip.

6. Keep cutting head below waist level.

7. Switch off before pushing the trimmer over surfaces

other than grass.

8. Never operate the trimmer with damaged guards or

without guards in place.

9. Never fit metal cutting elements.

10. Keep hands and feet away from the cutting means at

all times and especially when switching on the motor.

If not used properly this trimmer can be dangerous! This trimmer can cause serious injury to
the operator and others, the warnings and safety instructions must be followed to ensure
reasonable safety and efficiency in using this trimmer. The operator is responsible for following
the warning and safety instructions in this manual and on the trimmer.

Please note: This manual covers various products. Please read the user instructions
carefully to fully identify, assemble and use the features that apply to your trimmer.

ENGLISH - 1

10m

3

6

0

º

HOW TO TRIM AND EDGE

WARNING
The use of eye protection is recommended. Do not
lean over the trimmer whilst trimming or edging,
objects may be thrown by the cutting line. Do not
allow cutting head to rest on the ground. Do not
overload your trimmer. Overloading can be avoided
by making sure the motor speed does not drop
unduly. Disconnect from the mains electricity supply
before attempting any maintenance or adjustment.
BEFORE USE
Make sure that the line is fed out (if 2 lines are
fitted, make sure both are fed out). Make sure
motor is up to full speed before trimming or edging.
How to trim

1. Hold as illustrated in Fig K.

2. To start, squeeze the switch lever.

3. Cut with nylon line at an angle using the tip. See Fig L

4. Swing trimmer in and out of the cutting area taking
small cuts (M)

5. Line is fed out automatically every time the trimmer
head stops rotating and returns to operating speed.

• Extra line can be fed out manually as described on
page 3.

6. To stop your trimmer release the switch lever.

How to edge

1. T o convert to edging mode, depress locking button and
twist head anti-clockwise until arrow lines up with
"EDGE". An audible "click" will confirm that the head is
locked. Ensure the button has returned to its original
position. See Fig N.

2. Hold as illustrated in Fig K.

3. To start, squeeze the switch lever.

4. Rest edger on roller/skid plate for extra stability and line up
with edge of lawn. see fig O. Edge in direction indicated in
Fig P. so that debris is thrown away from you.

5. To return to trimming mode, depress locking button
and twist head clockwise until arrow lines up with
"TRIM" An audible "click" will confirm that the head is
locked. See Fig Q. Ensure the button has returned to
its original position.

Please note: Depending on which model you have
purchased, your trimmer may be fitted with a roller
or a skid plate.

SAFETY PRECAUTIONS

11. Never pick up or carry a trimmer by the cable.

12. Do not lean over the trimmer guard - objects may be
thrown by the cutting line.

13. Remove the plug from the mains :

- before leaving the trimmer unattended for any period;

- before clearing a blockage;

- before checking, cleaning or working on the appliance;

- if you hit an object. Do not use your trimmer until
you are sure that the entire trimmer is in a safe
operating condition.;

- if the trimmer starts to vibrate abnormally. Check
immediately. Excessive vibration can cause injury.

Maintenance and storage

1. Keep all nuts, bolts and screws tight to be sure the
trimmer is in safe working condition.

2. Replace worn or damaged parts for safety.

3. Only use the replacement cutting line specified for
this product.

4. Only use replacement parts and accessories
recommended by Electrolux Outdoor Products.

5. T o avoid the risk of injury keep fingers and hands clear
of the line cutter on the leading edge of the guard.

6. Inspect and maintain the trimmer regularly. Any
repairs must be carried out by an authorised repairer.

ASSEMBLY INSTRUCTIONS

Safety Guard Assembly (A), (B) & (C)

• If you have a Multi Trim 200 your safety guard
will be fitted with a wire guard as shown in
figure J2.

1. Align the arrow on the top of the safety guard (A1)
with the arrow on the side of the trimmer (A2).

2. Locate the safety guard (A3) over the cutting head
(A4). Ensure the nylon line is fed through the hole
in the safety guard as illustrated in fig A.

Please note: Depending on which model you
have purchased, your trimmer may be fitted with
one line or two lines.

3. Push into location and turn safety guard in the
direction illustrated in Fig B, until a click is heard
and the safety guard is securely locked in position.

• ENSURE THE SAFETY GUARD IS SECURELY IN
PLACE BY ATTEMPTING TO TWIST GUARD (fig C).

Steady Handle Assembly (D), (E) & (F)
D1 - Bolt, D2 - Handle Knob, D3 - Nut (if applicable)

1. Insert the nut into the handle knob. (if applicable)

2. Attach steady handle to product using bolt and
handle knob as shown in Fig D.

3. To adjust steady handle to new position, loosen
handle knob as shown in Fig E. and move handle to
one of the three positions as shown in Fig F.

4. Re-tighten handle knob

Height Adjustment (if fitted)
G1 - Height Adjust Knob
If your trimmer is fitted with Height Adjust, follow
the procedure below.

1. Loosen the height adjust knob. (fig G)

2. Adjust length of the handle to the most comfortable
operating position (fig H).

3. Re-tighten the height adjust knob.

AUTO LINE FEED SYSTEM

J1-a - Line Cutter, J2-a - Line Cutter, J2-b - Wire Guard
If you have a Multi Trim 200, it will be fitted with a
wire guard as shown in figure J2. The wire guard is
not shown throughout the remaining instructions.
How the automatic line feed works (J). Please note:
Depending on which model you have purchased,
your trimmer may be fitted with one line or two lines.

1. When initially switching on the trimmer, a small
length of line is fed out.

2. A‘clattering’ noise will be heard when the nylon line
hits the line cutter. DO NOT BE ALARMED this is
quite normal. After approximately 5 seconds the
line will be cut to the correct length and the noise
will reduce as the motor reaches full speed.

• Make sure the motor is up to full speed before
trimming or edging.

3. If the noise of the nylon line being cut cannot be
heard, more line will need to be fed out.

4. To feed more line, it is first necessary to to allow the
motor to stop completely, then re-start, allowing the
motor to reach full speed.

5. Repeat step 4. until you hear the line hitting against
the cutter. (Do not repeat this procedure more than
6 times)

6. If problems are experienced with the automatic line
feed refer to Fault Finding Chart on page 3.

ENGLISH - 2

FAULT FINDING CHART

WARNING Disconnect from the mains electricity supply before attempting any maintenance or adjustment.

FAULT CHECK ACTION

Is the automatic line feed
working?

Manually feed out line.

SEE “MANUAL LINE FEED”

Is line fed out and visible? (Check
for both lines if 2 lines are fitted)

Remove cap and spool, free line and
re-fit spool and cap.

SEE “SPOOL CAP AND NYLON
LINE”

The line may be jammed on the spool.
Rewind line to remove crossed loops.
(Check that line is in correct section of
spool if 2 lines are fitted)

Is the manual line feed working?

Has the motor reached full speed
before use?

Allow the motor to reach full speed
before use

Has too much line been fed out?

SEE “MANUAL LINE FEED”

Contact your local approved
Service Centre or Electrolux
Outdoor Products Customer
Service.

Is the line cutter missing from the
safety guard?

Are you using the trimmer
correctly?

Contact Electrolux Outdoor Products Customer Service
Telephone : [phone]

Only use tip of nylon line to trim.

SEE “How to trim and edge”

Is the line jamming on the spool?

Rewind the line on the spool, if symptoms
still persist, change spool and line.

No

No

No

No

Yes

Yes

?

Yes

LINE NOT FEEDING

OR

LINE TOO SHORT

OR

TRIMMER VIBRATES

CONTINUOUS

CLATTERING NOISE

LINE SNAPS

CONTINUOUSLY

IF NONE OF THE ABOVE
OR IF FAULT PERSISTS

SPOOL CAP AND NYLON LINE (1 LINE) - S

S1-a - Cap Release Latches, S2-a - Cap,
S2-b - Spool, S2-c - Spoolholder, S2-d - Eyelet,
S2-e - Manual Line Feed Button, S3-a - Eyelet,
S4-a - Hole in Spool, S4-b - Line
To remove spool cap

1. Press and hold in the two cap release latches. See

fig S1.

2. Pull cap away from the spoolholder. See fig S2.
When refitting the spool cap

1. Keep all areas of the cap and spoolholder clean.
Failure to do so may prevent the cap being securely
located in the spoolholder.

2. Align the two latches on the cap with the two
windows in the spoolholder, then press down into
the locked position.

3. Ensure the two cap release latches are clearly visible and
are fully engaged with the windows in the spoolholder.

4. Check that the cap is correctly fitted by trying to
remove it without depressing the two latches.

To replace nylon line. Replacement nylon line is
available from most Electrolux Outdoor Products
stockists. You can buy it either as spool and line
complete, or as nylon line only.

To replace spool and line (complete)

1. Unwind approximately 100mm of line and feed this
through eyelet, see fig S3, then drop the spool into
spoolholder smooth side uppermost.

To replace nylon line on spool.

1. Take line and insert into hole in spool.

2. Turn spool clockwise to wind on required amount of
line, (approx. half = 10m) and cut line to length, see
fig S4. Care should be taken to ensure that the line
is neatly coiled on the spool. Failure to do so will
impair the efficiency of the automatic line feed.

3. Leave approximately 100mm of line unwound and
feed this through eyelet, see fig S3, then drop the
spool into the spoolholder smooth side

uppermost.

• Ensure spool is fully located by gently rotating it
during fitment.

• Remember! Your Flymo Multi-Trim is designed
to use only nylon line with a maximum diameter
of 1.5mm. Use only genuine Flymo nylon line.

MANUAL LINE FEED

To manually feed the nylon line (R)
Please note: Depending on which model you have
purchased, your trimmer may be fitted with one line
or two lines.
R1-a - Manual Line Feed Button
R2-a - Manual Line Feed Button

1. If required line can be fed out manually.

2. To operate, press and release manual line feed
button, whilst gently pulling on the line until it

reaches the line cutter. (If 2 lines are fitted do this to
one line only, then gently pull on the second line,
there is no need to press the manual line feed
button again).

3. If the line extends past the line cutter, too much line
has been fed out.

4. If too much line is fed out, remove the spool cap
and click spool anti-clockwise until the line is at the
desired length.

ENGLISH - 3

CARING FOR YOUR MULTI TRIM

After you have finished using your Flymo Multi-Trim
follow the procedure below:

• AVOID ACCIDENTAL STARTING. REMOVE PLUG
FROM MAINS AND KEEP FEET AWAY FROM THE
SWITCH LEVER WHEN:- CLEANING AROUND
THE INSIDE OF THE SAFETY GUARD, REMOVING
OR REFITTING SPOOL CAP, MANUALLY FEEDING
OR REPLACING NYLON LINE. (SEE FIGS U & V)

1. Disconnect from the mains electricity supply.

2. Never clean your trimmer with water, cleaning
fluids, or solvents, just remove debris with a
suitable tool, a soft brush or dry cloth.

3. Using the scraper provided (Multi Trim 200), clean
around the inside of the safety guard to remove
any grass and debris. (Fig W).

4. Using a soft brush, clean around the inside of the safety
guard, the cutting head and the motor housing. (Fig X).

5. Inspect the trimmer carefully, especially the parts of
the cutting head.

6. If your trimmer is damaged in any way contact your local
Electrolux Outdoor Products approved service centre.

• Never use a damaged trimmer.

7. Wind cable carefully to avoid kinking.

8. Store in a cool, dry place and out of reach of children.

ENVIRONMENTAL INFORMATION

Electrolux Outdoor Products are manufactured under an
Environmental Management System (ISO 14001) using,
where practical, components manufactured in the most
environmentally responsible manner, according to
company procedures, and with the potential for
recycling at the end of the products’ life.

• Packaging is recyclable and plastic components have

been labelled (where practical) for categorised recycling.

• Awareness of the environment must be considered

when disposing of ‘end-of-life’ product.

• If necessary, contact your local authority for disposal

information.

SERVICE RECOMMENDATIONS

• Your product is uniquely identified by a silver and black product rating label.

• We strongly recommend that your product is serviced at least every twelve months, more often in a
professional application.

GUARANTEE AND GUARANTEE POLICY

If any part is found to be defective due to faulty manufacture
within the guarantee period, Electrolux Outdoor Products,
through its Authorised Service Repairers will effect the repair or
replacement to the customer free of charge providing:
(a) The fault is reported directly to the Authorised Repairer.
(b) Proof of purchase is provided.
(c) The fault is not caused by misuse, neglect or faulty

adjustment by the user.

(d) The failure has not occurred through fair wear and tear.
(e) The machine has not been serviced or repaired, taken apart

or tampered with by any person not authorised by Electrolux
Outdoor Products.

(f) The machine has not been used for hire.
(g) The machine is owned by the original purchaser.
(h) The machine has not been used outside of the country for

which it was specified.

(i) The machine has not been used commercially.
* This guarantee is additional to, and in no way diminishes the

customers statutory rights.

Failures due to the following are not covered, therefore it is important
that you read the instructions contained in this Operator's Manual
and understand how to operate and maintain your machine:

Failures not covered by guarantee

* Replacing Nylon Line.
* Failures as a result of not reporting an initial fault.
* Failures as a result of sudden impact.
* Failures as a result of not using the product in accordance

with the instructions and recommendations contained in this

Operator's Manual.
* Machines used for hire are not covered by this guarantee.
* The following items listed are considered as wearing parts

and their life is dependent on regular maintenance and are,

therefore not normally subject to a valid warranty claim:

Nylon Line, Electric Mains cable.
* Caution!

Electrolux Outdoor Products does not accept liability under the

warranty for defects caused in whole or part, directly or indirectly

by the fitting of replacement parts or additional parts that are not

either manufactured or approved by Electrolux Outdoor

Products, or by the machine having been modified in any way.

SPOOL CAP AND NYLON LINE (2 LINES) - T

T1-a - Cap, T1-b - Cap Release Latch, T1-c - Spool,
T1-d - Spoolholder, T1-e - Slot,
T2-a - Upper Section, T2-b - Lower Section
To remove spool cap

1. Press and hold in the two cap release latches. (T1).

2. Pull

cap away from the spoolholder. (T1).

When refitting the spool cap

1. Keep all areas of the cap and spoolholder clean.
Failure to do so may prevent the cap being securely
located in the spoolholder.

2. Replace the cap, pr

essing firmly DOWN towards

the spoolholder to ensure cap is fully located.

3. Check that the cap is correctly fitted by trying to
remove it without depressing the two latches.

To replace nylon line.

For your convenience it is recommended you buy spool
and line complete. Nylon line only is also available. Both
are available from Electrolux Outdoor Products stockists.

To fit spool and line complete:

1. Remove the cap.

2. Remove old spool.

3. Place spool into spoolholder.

4. Release line from cleat (if 2 lines are fitted release
only one line).

5. Secure line into slot (T1).

6. Repeat for second line.

• Ensure spool is fully located by gently rotating it
during fitment, whilst keeping the spoolholder
steady.

7. Refit the cap.

To fit nylon line only:

• Remember! Your Flymo Trimmer is designed to

use only nylon line with a maximum diameter of

1.5mm. Use only genuine Flymo nylon line.

1. IF YOU HAVE TWO LINES FITTED
IMPORTANT - If your trimmer has 2 lines fitted
always wind the line onto the upper section of
the spool first.

Take approximately 5 metres of line. Insert 15mm of
line into one of the holes in the upper section of the
spool (T2) and wind line in the direction of the
arrows on the top of the spool. Leave
approximately 100mm of line unwound and place
into cleat as illustrated in figure T3. Repeat on
lower section of spool.

2. Care should be taken to ensure that the line is
neatly coiled on the spool. Failure to do so will
impair the efficiency of the automatic line feed.

3. Then fit spool as described in ‘To fit spool and line

complete’, section above.

ENGLISH - 4

BELGIQUE/BELGIË Flymo Belgique/België

Tel: [phone], Fax: [phone]

ČESKÁ REPUBLIKA Electrolux, spol. s.r.o., oz Electrolux Outdoor Products,

Na Křečku 365, Praha 10 - Horní Měcholupy.
Tel: [phone], Info-linka: 0800/110 220
Internet: www.partner-flymo.cz E-mail: [e-mail]

DANMARK Electrolux Outdoor Products, Flymo/Partner A/S,

Lundtoftegaardsvej 93A, DK 2800 Kgs.Lyngby
Tel: [phone], Fax: [phone], www.flymo-partner.dk

DEUTSCHLAND Flymo Deutschland

Tel: [phone], Fax:[phone]

ESTONIA Electrolux Estonia Ltd (Electrolux Eesti AS)

Tel: [phone]

FRANCE Flymo France SNC

Tel [phone], Fax [phone]

FINLAND SUOMI Electrolux Outdoor Products Finland

Tel: [phone], Fax: [phone]

ITALIA McCulloch Italiana s.r.l. - Via Como 72, 23868 Valmadrera

(LECCO) - ITALIA
Tel: [phone], Fax: [phone]

IRELAND Flymo Ireland

Tel: [phone], Fax: [phone]

MAGYARORSZÁG Electrolux Lehel Kft

Tel: [phone]

NORGE Flymo/Partner, div. av Electrolux Motor a.s.

Tel: [phone]

NEDERLAND Flymo Nederland

Tel: [phone], Fax: [phone]

ÖSTERREICH Husqvarna-Ges.m.b.H. Nfg. KG, Industriezeile 36, 4010 LINZ,

Tel: [phone], Fax: [phone],
email: [e-mail] Internet: www.husqvarna.at

POLSKA Electrolux Poland Sp. z.o.o. Husqvarna, 01-612 Warszawa

Myslowicka 10/2
Tel:- (22) 8332949

SLOVENIJA Husqvarna-Ges.m.b.H. Nfg. KG, Industriezeile 36, 4010 LINZ,

Tel: [phone], Fax: [phone],
email: [e-mail] Internet: www.husqvarna.at

SLOVENSKA Electrolux Slovakia s.r.o., Borova Sihot 211, 033 01 Lipt. Hradok

Tel: [phone], Fax: [phone], www.flymo-partner.sk

SCHWEIZ/SUISSE/SUIZZERA Flymo Schweiz/Suisse/Suizzera

Tel [phone], Fax [phone]

SVERIGE Electrolux Outdoor Products, Sverige

Tel: 036 – 14 67 00, Fax: 036 – 14 60 70

UNITED KINGDOM Electrolux Outdoor Products United Kingdom

Tel: [phone], Fax: [phone]

5119314-02

Electrolux Outdoor Products

Aycliffe Industrial Park

NEWTON AYCLIFFE

Co.Durham DL5 6UP

ENGLAND

Telephone - (00) 44 1325 300303 Fax - (00) 44 1325 310339

UK Telephone - 01325 300303 Fax - 01325 310339

Our policy of continuous improvement means that the specification of products may be altered from time to time without prior notice.

Electrolux Outdoor Products manufacture products for a number of well known brands under various registered patents, designs and

trademarks in several countries.

© Electrolux Outdoor Products Ltd. Registered Office, Electrolux Works, Oakley Road, Luton LU4 9QQ

Registered number 974979 England

The Electrolux Group is the world’s largest producer of powered appliances for kitchen, cleaning and outdoor use. More than 55 million

Electrolux Group products (such as refrigerators, cookers, washing machines, vacuum cleaners, chain saws and lawn mowers) are

sold each year to a value of approx. USD 14 billion in more than 150 countries around the world.

The Electrolux Group. The world’s No.1 choice.
