ADCS-601-AF™
Air Data Calibration Standard
Operation and Maintenance Manual
NSN 6695-01-534-6087
© 2005 - 2007 DH Instruments, a Fluke Company
ADCS-601-AF™ OPERATION AND MAINTENANCE MANUAL
Pressurized gases are potentially hazardous. Energy stored in these gases can be released
unexpectedly and with extreme force. Pressurized systems should be assembled and operated only by
personnel who have been instructed in proper safety practices.
© 2005 - 2007 DH Instruments, a Fluke Company All rights reserved.
Information in this document is subject to change without notice. No part of this document may be reproduced or transmitted in any
form or by any means, electronic or mechanical, for any purpose, without the express written permission of DH Instruments, a
Fluke Company 4765 East Beautiful Lane Phoenix Arizona 85044-5318 USA.
DH Instruments makes sincere efforts to ensure the accuracy and quality of its published materials; however, no warranty,
expressed or implied, is provided. DH Instruments disclaims any responsibility or liability for any direct or indirect damages
resulting from the use of the information in this manual or products described in it. Mention of any product or brand does not
constitute an endorsement by DH Instruments of that product or brand. This manual was originally composed in English and was
subsequently translated into other languages. The fidelity of the translation cannot be guaranteed. In case of conflict between the
English version and other language versions, the English version predominates.
DH Instruments, DH, DHI, ADCS-601-AF, ADCS Tools, AMH, COMPASS, FPG8601, PG7601, PPC3 and RPM4 and are
trademarks, registered and otherwise, of DH Instruments, a Fluke Company.
Swagelok and Nupro are registered trademarks of the Swagelok Company.
Krytox is a registered trademark of the Dupont de Nemours Company.
Windows, Excel, Word are registered trademarks of the Microsoft Corporation.
Products described in this manual are manufactured under international patents and one or more of the following U.S.
patents: 6,701,791, 5,142,483, 5,257,640, 5,331,838, 5,445,035. Other U.S. and international patents pending.
Document No. 550140d
051222
Printed in the USA
