Fluke 6000D Impulse Supplement User Manual

Manual Supplement

Manual Title: Impulse 6000D/7000DP Users Supplement Issue: 5 Print Date: August 2007 Issue Date: 4/13 Revision/Date: 1, 1/08 Page Count: 11

This supplement contains information necessary to ensure the accuracy of the above manual. This manual is distributed as an electronic manual on the following CD-ROM:

CD Title: 6000D/7000DP CD Rev. & Date: 1, 2/2008 CD PN: 3028681

Impulse 6000D/7000DP Users Manual Supplement

Change #1, 46470, 46697, 47714, 48007, 49680

Replace pages 31 through 35, with the following:

Defibrillator Analyzer Specifications

Energy Output Measurement

Compatible Defibrillator Waveshapes ................ Lown, Edmark, Trapezoidal, DC Bi-phasic, and AC Pulsed Bi-phasic

Note

AC Pulsed Biphasic waveform has not been approved in the United States.

Autoranged Measurement .................................... 0.1 to 600 J

Accuracy

0.1 to 360 J ..................................................... (1 % of reading + 0.1 J)

360 to 600 J .................................................... (1 % of reading + 0.1 J), typical

Note

For Pulsed Bi-Phasic defibrillator, specified accuracy is (1.5 % of reading + 0.3 J) on both ranges.

Load resistance

Resistance .......................................................... 50 

Accuracy ......................................................... 1 %, non-inductive (<2 H)

Pulse trigger level ................................................. 20 V

Pulse width

Range ................................................................. 1.0 to 50.0 ms

4/08 1

Manual Supplement Impulse 6000D/7000DP Users

Accuracy ............................................................. 0.1 ms

Voltage

Range ................................................................. 20 to 5000 V

Accuracy ............................................................. (1 % of reading + 2 V)

Current

Range ................................................................. 0.4 to 100.0 A

Accuracy ............................................................. (1 % of reading + 0.1 A)

Tilt (biphasic and pulsed biphasic)

Range ................................................................. 1 % to 99 %

Accuracy ............................................................. 1 digit

Interphase delay (biphasic and pulsed biphasic)

Range ................................................................. 0.1 ms to 9.9 ms

Accuracy ............................................................. 0.1 ms

Frequency (pulsed biphasic only)

Range ................................................................. 2000 Hz to 8000 Hz

Accuracy ............................................................. 1 % of reading

Duty cycle (pulse biphasic only)

Range ................................................................. 1 % to 99 %

Accuracy ............................................................. 1 digit

Sample rate ........................................................... 250 kHz (4 s sample)

Maximum Average Power .................................... 12 W, equivalent to 10 defib pulses of 360 J every 5 minutes

2 4/08

Impulse 6000D/7000DP Users Manual Supplement

Scope Output

Autorange ........................................................... 2000:1, 400:1 and 80:1: dependant on the range

Waveform Playback

Output ............................................................. BNC

Output impedance ........................................... 50 

Amplitude Accuracy ........................................ 5 %

Charge Time Measurement

Range ................................................................. 0.1 to 100.0 s

Accuracy ............................................................. 0.05 s, typical

Synchronization Test (Elective Cardioversion)

Delay Time Measurement

Timing window ................................................ ECG R-wave peak to the defib pulse peak

Range ............................................................. -120 to +380 ms; measures timing from 120 ms prior to the R-wave peak to up to 380

ms following the R-wave peak.

Resolution ....................................................... 1 ms

Accuracy ......................................................... 1 ms

ECG waves

Normal Sinus Rhythm (NSR) .......................... 10 to 180 (by 1) BPM

Atrial fibrillation ................................................ Coarse and fine

Monomorphic Ventricular Tachycardia ........... 120 to 240 (by 5) BPM

Asystole .......................................................... Flat line

Automated Defibrillator Test ECG Waves

Normal Sinus ...................................................... 10 to 300 (by 1) BPM

4/08 3
