Fisher & Paykel WH8060J, WH8060P, WH7060J, W7060P User Manual

INSTALLATION INSTRUCTIONS
USER GUIDE
Front loading clothes washer
WH8060P, WH7060P, WH8060J
and WH7060J models
GB
CONTENTS
Installation instructions 6
European Directive 2012/19/EU on Waste Electrical 45 and Electronic Equipment (WEEE)
ImpORTANT!
SAVE THESE INSTRUCTIONS
The models shown in this user guide may not be available in all markets and are subject to change at any time. For current details about model and specification availability in your country, please go to our website www.fisherpaykel.com or contact your local Fisher & Paykel dealer.
Registration
Register your product with us so we can provide you with the best service possible.
To register your product visit our website: www.fisherpaykel.com
1
INTRODUCTION
Welcome
Thank you for buying a Fisher & Paykel clothes washer. We are proud of this washer and trust it will serve you well for many years.
At Fisher & Paykel we aim to provide innovative products that are simple to use, ergonomic and kind to the environment. Your washer has numerous wash cycles and options so you can perform every wash task with ease and the knowledge your clothes are receiving the best possible care.
Please take the time to read these instructions carefully before you begin using your machine.
Following the advice in this user guide will ensure you get the performance you expect from your machine and that you get the best possible wash results. Keep these instructions for future reference.
We hope you enjoy your new washer. We have certainly enjoyed designing it for you.
Front loading washer models
3
SAFETY AND WARNINGS
IMPORTANT SAFETY INSTRUCTIONS
WARNING!
When using this appliance always exercise basic safety precautions including the following:
• This clothes washer is not intended for use by persons (including children aged below 8years) with reduced physical, sensory, or mental capabilities, or lack of experience and knowledge, unless they are supervised or given instructions on how to use the washer by someone responsible for their safety and they understand the hazards involved.
• The washer should only be used for washing and rinsing of textiles where this is indicated on the care label.
• The door will be locked from the start of the cycle until the cycle is complete for safety reasons. It is possible to open the door during the cycle under certain conditions (refer to page19).
• Never force the door open.
• Keep children away from the washer while it is in
operation.
• Children of less than 3years should be kept away unless continuously supervised.
• Cleaning and user maintenance shall not be made by children without supervision.
• Supervise children to ensure they do not play with the washer or climb inside the drum.
• Do not touch the glass part of the door during a cycle as the door can become hot.
• Do not open the detergent dispenser during the cycle as hot water may come out of it.
4
SAFETY AND WARNINGS
• The only user-removable parts of the washer are the inlet hoses, detergent dispenser and the pump filter. No other parts are designed to be removed by anyone other than a Fisher&Paykel service technician.
• When disposing of the washer, it is recommended that the door is removed to avoid children getting trapped inside, and that the electrical cable is cut off close to the washer.
5
INSTALLATION INSTRUCTIONS
Accessories
Please check you received the following accessories with your Fisher & Paykel washer. You will find them inside the drum:

2 x Inlet hoses

1 x Drain hose guide

1 x Installation instructions and user guide

1 x Spanner

1 x Installation leaflet (attached to the top of the washer)

1 x Inlet valve cap
Unpacking
To ensure the best performance from your new washer please follow the instructions below.
Removing the packaging
Remove the outer packaging (including the polystyrene packer and plastic wrapping). All
1
packaging must be removed prior to use. Ensure these materials are kept out of reach of children. Note: a small amount of water may be seen inside the packaging and inside the washer. This is the result of factory testing and is normal.
Tilt the machine backwards and ‘walk’ it off the base one foot at a time. Not doing so
2
may cause damage to your floor and washer.
Remove all packaging and accessories from inside the drum.
3
Removing the transit bolts
The clothes washer is fitted with 4 transit bolts at the rear to avoid damage during transportation.
ImpORTANT!
The 4 transit bolts MUST be removed prior to operation of the machine. Failure to remove these will result in damage to the machine.
To remove the bolts:
Use a spanner or socket to unscrew and remove all four transit bolts at the back of the
1
washer (C).
Pull the black rubber grommets to remove the bolt, grommet and white plastic spacers
2
from the machine. Keep the transit bolts in case they are required for future transit of the machine. Never transport the machine without the transit bolts properly fixed in place.
Cover the bolt holes with the white plastic plugs which are attached to the machine and
3
located near each hole (p). Push to clip into place.
P
C
Removing the transit safety bolts
6
Product dimensions
INSTALLATION INSTRUCTIONS
A
B
C
WH7060P
WH7060J
WH8060P
WH8060J
PRODUCT DIMENSIONS mm mm
Overall height of product 850 850
A
Overall width of product 600 600
B
Overall depth of product
C
Depth to door open
570
1010
620
1065
MAXIMUM CAPACITY kg kg
7.0 8.0
Note: the exact height of your washer is dependent on how far the feet are extended from the base of the machine. The space where you install your washer needs to be at least 40mm wider and 20mm deeper than its dimensions.

Electrical supply: 220–240V, 50Hz Sinusoidal, minimum 10A

Inlet water static pressure: Max. 1MPa (150psi), Min. 30kPa (4.5psi)

Inlet water flow rate at tap: Min. 6litres/min

Standpipe/tub height: 800–1200mm
7
INSTALLATION INSTRUCTIONS
Location
ImpORTANT!
Install the machine on a solid and level floor surface ensuring it has at least 20mm clearance on each side. The washer must not be installed on any textured floor coverings (eg carpet, rugs).
Levelling the machine
It is IMPORTANT to level the machine to ensure good spin performance, and to minimise noise, vibrations and wear and tear on the washer.
Before positioning the machine in its final position, check
1
that the machine is level, front to back and side to side.
Manoeuvre the product into its final position (we suggest a
2
minimum clearance of 20mm each side).
Use a spirit level to check that the machine is correctly
3
level. If needed, pull the machine out and wind the feet up or down to correctly level the machine.
Using the spanner provided, tighten the lock nuts against
4
Locking the feet
the base of the machine to lock the feet in position.
Connecting to the water supply
Inlet hoses
ImpORTANT!

New hose sets provided with the washer should be used to connect the washer to the water mains.

Old hose sets should not be re-used.

We recommend the inlet hoses are changed every 5 years. WARNING: Failure to do so may result in a flood and damage to property.
Connect the straight ends of the inlet hoses to the taps
1
and the elbow ends to the corresponding machine inlet
Straight
(tap) end
valves. The hot valve is colour coded orange to make this easier. Make sure there are no kinks in the hoses.
Turn the taps on and check for leaks. Check for leaks
2
Inlet hose ends
again after 24hours.
ImpORTANT!
The hot water temperature should not exceed 65°C and the cold water temperature not exceed35°C. Temperatures above these may cause the machine to fault or cause damage to the machine.
8
Elbow
(machine) end
INSTALLATION INSTRUCTIONS
If you have an uncontrolled water heating source (eg a wet back or solar heating system) you should fit a Hot ‘N’ Safe Valve. This will ensure the hot water temperature remains within safe limits.
Hot ‘N’ Safe Valves available are:
RMC TVA 50HF
RMC TVA 75HFS
Adjustable between 35°C – 55°C
RMC TVA 50HP
For instantaneous gas hot water supply
Water supply requirements:

Inlet water pressure: Maximum 1MPa (150psi), Minimum 30kPa (4.5psi)

Inlet water flow rate: Minimum 6litres/minute
Cold supply only:
If you only have a cold water supply, the inlet valve cap (blanking cap) which came with your washer must be connected to the hot inlet valve. The cap prevents water leaking out of the hot valve. This appliance incorporates backflow protection complying with AS3500.1. No further backflow protection is required for connection to the water supply.
Note: your washer has an internal heater to heat water. If you do not connect a hot water inlet hose, your washer will automatically recognise there is no hot water supply and its internal heater will heat the cold water to the required cycle temperature.
9
INSTALLATION INSTRUCTIONS
Draining
Drain hose placement in a stand pipe or tub
To guide the drain hose over the tub or
1
standpipe the hose guide must be fitted to the drain hose. The height of the standpipe or tub should be between 800–1200mm.
Secure the hose guide so it cannot become
2
dislodged from the standpipe or tub.
ImpORTANT!

If the drain hose is placed on the ground or if the standpipe or tub is less than 800mm high, the washing machine will continuously drain while being filled (siphon).

Regularly check that your standpipe or tub is free from lint or other obstructions, which may affect how your machine works or may cause flooding.
Attaching drain hose to spigot
Guide drain hose through hose guide
1
Secure hose guide to back wall of cupboard
2
using a screw. The height of the drain hose should be between 500–800mm from ground level.
Attach drain hose to spigot and secure using
3
a hose clamp ensuring the blanking insert is cleared from spigot.
Check for leaks.
4
Pull hose through guide
(20 mm) maximum
Standpipe 800 – 1200 mm
Fitting the drain hose guide
Height 500 – 800 mm from ground

The drain hose should be checked from time to time and replaced if any damage (egwear, cuts, bulges, kinks, leaks, etc) is found. Do not bend the drain hose sharply, as this may cause it to split.

In multi-storey apartments or any upper floor, the machine should be installed on a floor equipped with a drain.

Draining must comply with local by-laws.
10
Attaching drain hose to spigot
INSTALLATION INSTRUCTIONS
Electrical connection
This appliance must be connected to a 220V–240V, 50 Hz, sinusoidal, minimum 10A
1
electricalsupply.
Uncoil the power cord, remove and discard the plastic pin cover and plug into a
2
wallsocket.
Connect the appliance to an earthed outlet protected by a fuse of suitable capacity.
3

Check the power cord for damage and make sure it is not squashed or twisted when installing the washer.

Always remove the power cord from a socket by the plug, not by the cord.
ImpORTANT!

If you are using an extension cord or a portable electrical outlet device (eg multi-socket outlet box), ensure that it is positioned so that it does not come into contact with water or moisture. FAILURE TO DO SO MAY RESULT IN DEATH OR ELECTRICAL SHOCK.

Do not touch or operate the machine with wet hands or with bare-feet.

A damaged power cord must be replaced by a Fisher & Paykel service technician, in order to avoid a hazard. The appliance must not be operated until it is repaired, as there is risk of electric shock.

Do not operate this machine if it has been damaged during transport. Contact your Fisher & Paykel dealer or Fisher & Paykel service technician.
SPARE PARTS
Available from your Fisher & Paykel dealer or a Fisher & Paykel service technician.
Hose Inlet Long (2m) Part No. 422680P
Hose Inlet Large Bore Part No. 426123P
Drain Hose Extension Part No. 425627P
11
INSTALLATION INSTRUCTIONS
Completing the installation
Installation test cycle
ImpORTANT!
Do this before you wash any items in your washer. This is to check that your washer is installed correctly and that it is functioning correctly prior to use.
Turn your washer on by pressing the button.
1
Select the ‘Quick’ cycle. Ensure the drum is empty and the door closed.
2
Touch the button. The machine will start to fill.
3

Observe the machine for any problems (eg leaking from the hoses, excess noise or vibrations).

The washer will beep and display any faults on the screen if there are any problems. Refer to pages33 to34.
Wait until you see water in the bottom of the drum.
4
Touch to stop the cycle, then press to turn the machine off.
5
Press again, select the ‘Spin’ cycle and touch .
6

Check the drain hose is firmly secured to the standpipe or tub, or spigot.

Observe that the machine pumps out the water, and spins.
ImpORTANT!
If there are any problems, you must address these before proceeding with normal use. The washer will automatically turn off at the end of the cycle if there are no problems.
12
BEFORE YOU DO YOUR FIRST WASH
Before you start, it is a good idea to go through the following checklist:
Have the packaging and transit bolts been removed?
1
Is the drain hose threaded through the ‘Ubend’ (with no more than 20mm extended)
2
and hooked into your standpipe or tub, or attached to a spigot?
Is the hot hose connected to the hot valve (colour-coded orange)? Is the cold hose
3
connected to the cold valve (colour-coded white)? Have the taps been turned on?
Is the machine correctly levelled, feet are locked and cabinet corners clear of the floor
4
and walls?
Has the power cord been connected to an appropriate power supply and the power
5
turned on?
Have you performed the installation test cycle?
6
We recommend you complete your first cycle with a half-load amount of detergent
7
and without a load in order to remove any residues remaining in the machine from the manufacturing process.
ImpORTANT!
You must ensure all 4transit bolts have been removed from your washer before you start using it. If the transit bolts are not removed, they will damage your washer and YOUR MANUFACTURER’S WARRANTY WILL BE COMPROMISED.
13
