Fisher & Paykel RF51RCWX1 User Manual
1
Installation instructions
XXXXX
Installation instructions
and user guide
NZ AU
XXXXX
Wine Chiller
Installation instructions
and user guide
NZ AU
RF51RCWX1
1
Contents
Important!
SAVE THESE INSTRUCTIONS
The model shown in this user guide may not be available in all markets and is subject to change at any time.
For current details about model and specification availability in your country, please go to our website
listed on the back cover or contact your local Fisher & Paykel dealer.
Safety and warnings
2
Your Fisher & Paykel Wine Chiller
3
Installation instructions
4
Power supply
4
Positioning your Wine Chiller
4
Before rst use
5
Energy eciency
5
Operating instructions
6
Storing red and white wine in the Wine Chiller
7
Short-term storage/serving
7
Long-term storage of wine
7
Interior fan
8
Ventilation control
8
Condensation control
8
Shelving
9
Deodoriser
9
Interior light
9
Cleaning and maintenance
10
Replacing the light bulb
11
Normal operating sounds you may hear
11
Transporting your Wine Chiller
11
Problem solving checklist
12
Customer care
13
2
Safety and warnings
Safety and warnings
To reduce the risk of fire, electric shock, or injury to persons, please read the IMPORTANT
SAFETY INSTRUCTIONS before operating this appliance. Use this appliance only for its intended
purpose as described in this User Guide.
Important!
When using this appliance, always exercise basic safety precautions including the following:
This appliance is not intended for use by young children or infirm persons without supervision.
Young children should be supervised to ensure they do not play with the appliance.
Risk of child entrapment. Before you throw away your old refrigerator, freezer or Wine Chiller:
– Take off the door.
– Leave the shelves in place so that children may not easily climb inside.
Do not operate your Wine Chiller in the presence of explosive fumes.
Extreme care must be taken when disposing of your old appliance to avoid hazards. The
refrigerant gas must be safely removed and for the safety of young children, remove doors.
Your Fisher & Paykel Appliances Authorised Service Centre will be able to give advice on
environmentally friendly methods of disposing of your old Wine Chiller.
This appliance must be properly installed in accordance with the installation instructions before
it is used.
Never unplug your Wine Chiller by pulling on the power cord.
Always grip the plug firmly and pull straight out from the outlet.
Repair or replace immediately all electric service cords that have become frayed or otherwise
damaged. Do not use a cord that shows cracks or abrasion along its length at either the plug or
appliance end.
If the power supply cord is damaged, it must only be replaced by your Fisher & Paykel Appliances
Authorised Service Agent.
When moving your appliance away from, or against the wall, be careful not to crush or damage
the power cord.
Unplug your Wine Chiller before cleaning, replacing the light bulb, or making any repairs.
This Wine Chiller should not be recessed or built-in to an enclosed cabinet. It is designed for
freestanding installation only.
Ensure your appliance is positioned free of any obstructions that will prevent air from flowing
around the cabinet sides.
Do not store food in the Wine Chiller. The interior temperature will not be cool enough to prevent
spoilage in food and will promote bacterial growth.
Many commercially available cleaning products contain solvents which may attack plastic
components of your Wine Chiller and cause them to crack.
Please refer to the cleaning care section of this booklet for further advice.
SAVE THESE INSTRUCTIONS
3
Your Fisher & Paykel Wine Chiller
Your Fisher & Paykel Wine Chiller
The storage of wine is important; as wine is a natural, perishable beverage the storage conditions
impact greatly on the overall taste, quality and aroma of wine. It is therefore important to store
and serve wine correctly. The Fisher & Paykel Wine Chiller provides you with all the necessary
storage requirements to ensure your wine is adequately cared for.
Temperature control is important when storing wine. Too high a temperature ages wine
prematurely and prevents it from developing to its full complexity. At temperatures above 20°C
volatile aroma and flavour compounds are lost and oxidation occurs, all contributing to aging
the wine prematurely. Too low a temperature delays maturation and can result in deposits or
suspensions in the wine. The Wine Chiller can be set between 6 and 18°C, depending on the type
of wine and length of storage required.
More important than the actual temperature of wine is the fluctuation in temperature the wine
is subjected to. Changes in temperature can ruin wine, as it causes the wine to expand and
contract in the bottle, damaging the integrity of the cork allowing oxygen to seep in. Daily and
weekly fluctuations in household temperatures will over time cause damage to your wines and
age them prematurely. The Wine Chiller provides a constant temperature storage environment
with minimal fluctuations in temperature, suited to both long and short-term storage of red and
white wine.
(Features may vary with model)
12 3456 7
8
12
9
10
13 14
11
11
Parts and features
1. White wine indicator light
2. White wine button/temperature adjustment down
3. Red wine indicator light
4. Red wine button/temperature adjustment up
5. Condensation control/Demister indicator light
6. Interior light and demister button
7. LED temperature display
8. Interior light
9. Interior shelves
10. Door
11. Interior fan
12. Adjustable levelling legs
13. Ventilation control
14. Deodoriser
Fig 1. Parts and features of Wine Chiller
