INSTRUCTION MANUAL

B/W CCD Camera

About this manual

Before installing and using the camera, please read this manual
carefully. Be sure to keep it handy for later reference.

VCB-3424

SANYO INDUSTRIAL VIDEO

B/W VIDEO CAMERA LIMITED WARRANTY

In order to obtain warranty service, the product must be delivered to and picked up from an Authorized Sanyo Service Center at the user’s expense, unless specifically stated otherwise in this warranty. The names and
addresses of Authorized Sanyo Service Centers may be obtained by writing to SFS Corporation, SFC’s warranty administrator, at any of the addresses listed below, or by calling (toll-free) 1-800-421-5013.

New Jersey Office
210 Riser Road
Little Ferry, NJ 07643
201-641-3000

THIS WARRANTY IS VALID ONLY ON SANYO PRODUCTS PURCHASED OR RENTED IN THE UNITED STATES OF AMERICA, EXCLUDING HAWAII AND ALL U.S. TERRITORIES AND PROTECTORATES. THIS
WARRANTY APPLIES ONLY TO THE ORIGINAL RETAIL USER. THE ORIGINAL DATED BILL OF SALE, SALES SLIP OR RENTAL AGREEMENT MUST BE SUBMITTED TO THE AUTHORIZED SANYO SERVICE CENTER
AT THE TIME WARRANTY SERVICE IS REQUESTED.
Subject to the OBLIGATIONS above and EXCLUSIONS below, SANYO FISHER (USA) CORPORATION warrants this SANYO product against defects in materials and workmanship for the periods specified below. SFC
will repair or replace (at its option) the product and any of its parts which fail to conform to this warranty. The warranty period commences on the date the product was first purchased or rented at retail.

California Office
1200 W. Artesia Blvd.
Compton, CA 90220
310-537-5830

LABOR PARTS IMAGE DEVICE

3 YEARS 3 YEARS 3 YEARS

This warranty does not cover (A) the adjustment of customer-operated controls as explained in the appropriate model’s instruction manual, or (B) the repair of any product whose serial number has been altered, defaced
or removed.
This warranty shall not apply to the cabinet or cosmetic parts, antenna, knobs, batteries or image burns to projection or picture tubes caused by electronic devices or games.
This warranty does not apply to uncrating, setup, installation, removal of the product for repair or reinstallation of the product after repair.
This warranty does not apply to repairs or replacements necessitated by any cause beyond the control of SFC including, but not limited to, any malfunction, defect or failure caused by or resulting from unauthorized
service or parts, improper maintenance, operation contrary to furnished instructions, shipping or transit accidents, modification or repair by the user, abuse, misuse, neglect, accident, incorrect power line voltage, fire,
flood or other Acts of God, or normal wear and tear.
The foregoing is in lieu of all other expressed warranties and SFC does not assume or authorize any party to assume for it any other obligation or liability.
THE DURATION OF ANY WARRANTIES WHICH MAY BE IMPLIED BY LAW (INCLUDING THE WARRANTIES OF MERCHANTABILITY AND FITNESS) IS LIMITED TO THE TERM OF THIS WARRANTY. IN NO EVENT
SHALL SFC BE LIABLE FOR SPECIAL, INCIDENTAL OR CONSEQUENTIAL DAMAGES ARISING FROM OWNERSHIP OR USE OF THIS PRODUCT, OR FOR ANY DELAY IN THE PERFORMANCE OF ITS OBLIGATIONS
UNDER THIS WARRANTY DUE TO CAUSES BEYOND ITS CONTROL.
SOME STATES DO NOT ALLOW LIMITATIONS ON HOW LONG AN IMPLIED WARRANTY LASTS AND/OR DO NOT ALLOW THE EXCLUSION OR LIMITATION OF CONSEQUENTIAL DAMAGES, SO THE ABOVE
LIMITATIONS AND EXCLUSIONS MAY NOT APPLY TO YOU.
THIS WARRANTY GIVES YOU SPECIFIC LEGAL RIGHTS. YOU MAY HAVE OTHER RIGHTS, WHICH VARY FROM STATE TO STATE.

For your protection in the event of theft or loss of this product, please fill in the information below for you own perso nal records.

Model No._____________________________________________________________________ Serial No. _____________________________________________________________________

Date of Purchase _______________________________________________________________ Purchase Price_________________________________________________________________

OBLIGATIONS

EXCLUSIONS

ATTENTION

(Located on back or bottom side of unit.)

Illinois Office
900 N. Arlington Heights Rd.
Itasca, IL 60143
708-775-1414

Where Purchased _________________________________________________________________________________________________________________________________________________

14 English

Depending on the conditions of use, installation and environment,
please be sure to make the appropriate settings and adjustments. If
you need help with installation and/or settings, please consult your
dealer.

CONTENTS

INFORMATION TO USER.................................................................... 2

PRECAUTIONS..................................................................................... 3

PARTS NAMES..................................................................................... 4

MOUNTING THE LENS........................................................................ 7

CONNECTIONS.................................................................................... 9

SETTINGS............................................................................................. 10

TROUBLESHOOTING........................................................................... 12

SPECIFICATIONS.................................................................................. 13

ACCESSORIES

1 C mount adaptor (5 mm).....................1 pc.

The C mount adaptor must be used to be able to install a C mount
lens on the camera.

2 Lens iris plug (4-pin).............................1 pc.

12

FEATURES

• Built-in interline transfer method 1/3" CCD, approx. 270,000

picture elements

• Low smear, anti-blooming, low lag, no burning and no geometric

distortion using the CCD solid state image device.

• 100% solid state components giving excellent immunity to shock

and vibration

• Not subject to interference from magnetic or electrostatic fields

• High sensitivity, minimum required illumination of 0,07 lux with

F1.2 lens

• Horizontal resolution, more than 400 TV lines

• New backlight compensation function (Active when using an

auto-iris lens)

• Externally adjustable flange back (mechanical focus)

• Low power consumption and quick start

• 24 V AC operation

(Commarcially available 24 V AC adaptor)

• Built-in Mirror image effect function.

English 1

INFORMATION TO USER

Safety Guard

THIS SYMBOL INDICATES THAT THERE ARE
IMPORTANT OPERATING AND MAINTENANCE
INSTRUCTIONS IN THE LITERATURE ACCOMPANYING
THIS UNIT.

WARNING:

TO PREVENT THE RISK OF FIRE OR ELECTRIC SHOCK , DO NOT
EXPOSE THIS APPLIANCE TO RAIN OR MOISTURE.

For the customers in Canada

This Class B digital apparatus complies with Canadian ICES-003.

Pour la clientèle canadienne

Cet appareil numerique de la Classe B est conforme a la norme
NMB-003 du Canada.

This installation should be made by a qualified service person and
should conform to all local codes.

This equipment has been tested and found to comply with the limits
for a Class B digital device, pursuant to Part 15 of the FCC Rules.

These limits are designed to provide reasonable protection against
harmful interference in a residential installation. This equipment
generates, uses, and can radiate radio frequency energy and, if
not installed and used in accordance with the instructions, may
cause harmful interference to radio communications.

However, there is no guarantee that interference will not occur in
a particular installation. If this equipment does cause harmful
interference to radio or television reception, which can be
determined by turning the equipment off and on, the user is
encouraged to try to correct the interference by one or more of
the following measures:

– Reorient or relocate the receiving antenna.
– Increase the separation between the equipment and receiver.
– Connect the equipment into an outlet on a circuit different

from that to which the receiver is connected.

– Consult the dealer or an experienced radio/TV technician for help.

This device complies with Part 15 of the FCC Rules. Operation is
subject to the following two conditions: (1) This device may not
cause harmful interference, and (2) this device must accept any
interference received, including interference that may cause
undesired operation.

Changes or modifications not expressly approved by Sanyo may
void the user’s authority to operate this camera.

2 English

PRECAUTIONS

In case of problem

Do not use the camera if smoke or a strange odour comes from the
unit, or if it seems not to function correctly. Disconnect the power
cord immediately, and consult your dealer (or a Sanyo Authorized
Service Centre).

Do not open or modify

Do not open the cabinet, as it may be dangerous and cause damage
to the unit. For internal settings and repairs, consult your dealer (or a
Sanyo Authorized Service Centre).

Do not put objects inside the unit

Make sure that no metal objects or flammable substance get inside
the camera. If used with a foreign object inside, it could cause a fire,
short-circuits or damages.

If water or a liquid gets inside the camera, disconnect the power cord
immediately, and consult your dealer (or a Sanyo Authorized Service
Centre). Be careful to protect the camera from rain, sea water, etc.

Be careful when handling the unit

To prevent damages, do not drop the camera or subject it to strong
shock or vibration.

Install away from electric or magnetic fields

If installed close to a TV, radio transmitter, magnet, electric motor,
transformer, audio speakers the magnetic field they generate will
distort the image.

English 3

Protect from humidity and dust

To prevent damages to the camera, do not install it where there is
greasy smoke or steam, where the dampness may get too high, or
where there is a lot of dust.

Protect from high temperatures

Do not install close to stoves, or other heat generating devices, such
as spotlights, etc., or where it could be subject to direct sunlight, as
that could cause deformation, discoloration or other damages.

Be careful when installing close to the ceiling, in a kitchen or boiler
room, as the temperature may raise to high levels.

Install where the temperature range will stay between –10˚C and 50˚C.
(no condensation)

Cleaning

• Dirt can be removed from the cabinet by wiping it with a soft

cloth. To remove stains, wipe with a soft cloth moistened with a
soft detergent solution and wrung dry, then wipe dry with dry soft
cloth.

• Do not use benzine, thinner or other chemical product on the

cabinet, as that may cause deformation and paint peeling. Before
using a chemical cloth, make sure to read all accompanying
instructions. Make sure that no plastic or rubber material comes in
contact with the cabinet for a long period of time, as that may
cause damage or paint peeling.
