Instruction Manual Form 5007

January 2016

133 Series Direct-Operated Regulators

Table of Contents

Introduction...................................................................1

Specications...............................................................2

Principle of Operation...................................................2

Installation.....................................................................3

Overpressure Protection..............................................4

Startup..........................................................................5

Adjustment....................................................................6

Shutdown......................................................................6

Maintenance.................................................................6

Parts Ordering.............................................................11

Parts List.................................................................... 11

W1327

TYPES 133H, 133L AND 133Z REGULATORS

133 Series

W6803

TYPE 133HP REGULATOR

WARNING

Failure to follow these instructions or to properly install and maintain this equipment could result in an explosion

and/or re causing property damage and

personal injury or death.

Fisher® regulators must be installed, operated and maintained in accordance with federal, state and local codes, rules and regulations and Emerson Process Management Regulator Technologies, Inc. (Emerson™) instructions.

If the regulator vents gas or a leak develops in the system, service to the unit may be required. Failure to correct trouble could result in a hazardous condition.

Call a gas service person to service the

unit. Only a qualied person must install or

service the regulator.

Figure 1. 133 Series Gas Regulators

Introduction

Scope of the Manual

This manual provides specications, installation, adjustment and maintenance instructions and parts ordering information for the 133 Series regulators.

Only personnel qualied through training or experience should install, operate and maintain this regulator. If there are any questions concerning these instructions, contact your local Sales Ofce before proceeding.

Product Description

The 133 Series direct-operated gas regulators, shown in Figure 1 are primarily designed for industrial and commercial applications supplying gas to furnaces, burners and other appliances. The 133 Series

D100270X012

www.fisherregulators.com

133 Series

Specications

The Specications section lists the specications for the Type 133 Series direct-operated regulators. Factory specication is stamped on the nameplate fastened on the regulator at the factory.

Available Constructions

Type 133H:

High pressure construction for outlet pressure range of 1.5 to 10 psig / 0.10 to 0.69 bar. The Type 133H can also use the 2 in. w.c. to 2 psig / 5 mbar to 0.14 bar springs of the Type 133L. The maximum operating inlet pressure is 60 psig /

4.1 bar with a maximum emergency inlet pressure of 125 psig / 8.6 bar.

Type 133HP:

Extra high pressure construction for outlet pressure range of 2 to 60 psig / 0.14 to 4.1 bar. The maximum operating and emergency inlet pressure rating is 150 psig / 10.3 bar.

Type 133L:

Low pressure construction for outlet pressure range of 2 in. w.c. to 2 psig / 5 mbar to 0.14 bar. The maximum operating inlet pressure is 60 psig /

4.1 bar with a maximum emergency inlet pressure of 125 psig / 8.6 bar.

Type 133Z:

Zero governor construction for outlet pressure range of -1 to 4 in. w.c. / -2 to 10 mbar. The maximum operating inlet pressure is 20 psig /

1.4 bar with a maximum emergency inlet pressure of 125 psig / 8.6 bar.

Body Size and End Connection Styles

BODY SIZE BODY MATERIAL

IN. DN Cast Iron Body WCC Steel Body

2 50 NPT or CL125 FF Flanged NPT or CL150 RF Flanged

Outlet Pressure Ranges

See Table 1

Maximum Inlet Pressures

(1)

See Table 2

Maximum Outlet Pressures

See Table 2

Pressure Registration

External; downstream control line is required.

Temperature Capabilities

(1)

-20 to 150°F / -29 to 66°C

Control Line Connection

Types 133H, 133L and 133Z:

3/4 NPT (internal); connection will be positioned directly over body outlet (standard position) or 90 degrees right or left of standard position if specied.

Type 133HP:

1/4 NPT (internal) connection positioned directly over body outlet.

Vent Connection

Types 133H, 133L and 133Z:

1 NPT (internal) with screen; standard position is in line with control line connection directly over body outlet. Vent will always be positioned over the control

line connection.

Type 133HP:

1/2 NPT (internal) connection positioned directly

over body inlet with a Fisher

Type Y602-7

vent assembly.

Approximate Weight

Types 133H, 133L and 133Z NPT End Connections: 35 lbs / 16 kg

Types 133H, 133L and 133Z Flanged End Connections: 40 lbs / 18 kg

Type 133HP NPT End Connections:

56.5 lbs / 26 kg

Type 133HP Flanged End Connections:

62.5 lbs / 28 kg

1. The pressure/temperature limits in this Instruction Manual or any applicable standard limitation should not be exceeded.

balancing system enables the regulator to provide accurate control gas pressure for maximum combustion efciency despite varying inlet pressure conditions. The single port construction provides bubble-tight shutoff. An external downstream control line is required for the operation of the regulator. A restriction collar is available to reduce the ow capacity of the regulator.

Principle of Operation

Refer to the operational schematics in Figures 2 and 3. In the 133 Series, downstream pressure is registered under the diaphragm via the external control line and is used as the operating medium. Increased demand lowers the downstream pressure and allows the spring to move the diaphragm and stem assembly down, opening the valve disk and supplying more gas to the

INLET PRESSURE OUTLET PRESSURE ATMOSPHERIC PRESSURE BOOST PRESSURE

DIAPHRAGM

CONTROL SPRING

133 Series

DOWNSTREAM CONTROL LINE

STEM

ORIFICE

A6555

INLET PRESSURE OUTLET PRESSURE ATMOSPHERIC PRESSURE BOOST PRESSURE

Figure 2. Operational Schematic of Type 133L Regulator (Also Typical of Type 133H)

VALVE DISK

downstream system. Decreased demand increases the downstream pressure and moves the diaphragm and stem assembly up, closing the valve disk and decreasing the gas supply to the downstream system.

Boosting System

The 133 Series incorporates a balancing diaphragm and a boosting system. When the regulator is locked up, inlet pressure is registered on the top of the valve disk and on the bottom of the balancing diaphragm through registration holes in the top of the cage. Also, downstream pressure is registered on the bottom of the valve disk and on the top of the balancing diaphragm through a passage formed by grooves in the registration disk and an annular space between the stem and stem sleeve.

When the valve disk is open, gas ows from the inlet over the edge of the valve disk to the outlet. Under the valve disk near the registration disk, there is little gas ow. The gas pressure near the registration disk is higher than it is in the ow path where gas velocity

BALANCING DIAPHRAGM

REGISTRATION DISK

tends to lower the pressure. The higher pressure near the disk is registered on the top of the balancing diaphragm through the registration disk and the annular space between the stem and stem sleeve.

This pressure registered on the top of the balancing diaphragm aids downward disk travel and compensates for spring and diaphragm effect. This improves regulator range ability and performance.

Installation

Before installing the 133 Series regulators, inspect it for shipping damage and be certain that the body and orice are clean. Blow out the pipeline to remove pipe scale and other foreign material.

The regulator may be installed in any position as long as the ow through the body is the same as indicated by the ow direction arrow on the body and the vent opening is unobstructed and protected from the entrance of rain, ice and other foreign material.

133 Series

Type 133HP

VENT

ASSEMBLY

DIAPHRAGM

DOWNSTREAM CONTROL LINE

Downstream Control Line

WARNING

Downstream control line is Srequired for proper operation of these regulators.

An external downstream control line must be installed before putting the 133 Series regulators in operation. Without the control line, the regulator will remain wideopen. The downstream control line should be a pipe of at least 1/2 in. / 12.7 mm diameter; connect it to the downstream pipe line at least 5 to 10 pipe diameters from the regulator and in a straight section of pipe.

The external downstream control line connection on the Type 133HP is 1/4 NPT.

A6883

INLET PRESSURE OUTLET PRESSURE ATMOSPHERIC PRESSURE BOOST PRESSURE

Figure 3. Operational Schematic of Type 133HP

If the regulator has threaded end connections, coat external threads with pipe compound. For anged end connections, tighten the ange bolts evenly. Install a three valve bypass around the 133 Series if continuous operation is necessary.

The regulator must be protected from damage by vehicles and other outside sources.

Overpressure Protection

The 133 Series regulators have an outlet pressure rating that is lower than the inlet pressure rating. Some type of overpressure protection is needed if the actual inlet pressure exceeds the outlet pressure rating.

Maximum operating inlet pressure for the 133 Series regulators is given in Table 2. All models must be protected against inlet pressure above their listed maximum.

Regulator operation below these emergency pressure limitations does not preclude the possibility of damage from external sources or from debris in the gas line. The regulator should be inspected for damage after any overpressure condition.

Vent

The 133 Series vent is screened to prevent insects or foreign material from entering. The Types 133H, 133L and 133Z regulators have a 1 NPT (internal) connection and the Type 133HP has a 1/2 NPT internal connection. If a vent to the atmosphere is required for indoor installations, do the following:

• For Types 133H, 133L and 133Z — remove the snap ring and screen (keys 8J and 8H, Figure 10, 11 or 12) and pipe the vent to the outside.

• For Type 133HP — remove the Type Y602-7 screened vent assembly and pipe nipple (keys 50 and 49, Figure 14) from the spring case (key 8) and pipe the vent to the outside.

The vent pipe should be as short as possible with minimum number of bends or elbows. The pipe should also have the largest practical diameter. Install a weather and bug resistant vent assembly on the outside

end of the vent pipe.

For indoor installation that have been piped to the outside and for outdoor installations, the vent opening must be positioned so that water, ice and other foreign material cannot enter the spring case. Use care not to place the vent opening below downspouts and eaves. The vent opening should be checked periodically to be sure that the opening has not been plugged with foreign material. On some installations it may be necessary to provide additional protection from the elements.

Table 1. 133 Series Outlet Pressure Ranges, Control Springs

133 Series

TYPE

(1)

133H

(1)

133HP

(1)

and 133H

133L

(1)

133Z

1. Pressure ranges shown are correct if the regulator is installed with the actuator portion above the body portion. If the regulator is installed with the actuator portion below the body, the pressure ranges will be lowered by approximately 2 in. w.c. / 5 mbar for the Type 133L and by approximately 3 in. w.c. / 7 mbar for the Types 133H and 133Z.

2. If the 2 in. w.c. / 5 mbar to 2 psig / 0.14 bar springs (all 6 ranges) are used in the Type 133H, the pressure ranges will increase by approximately 1 in. w.c. / 2 mbar due to the weight of the Type 133H parts (assuming that the actuator is installed above the body).

OUTLET PRESSURE RANGE

psig bar

1.5 to 3 2 to 5

5 to 10

2 to 5

4.5 to 10

6 to 20

16 to 30

26 to 40 36 to 50 45 to 60

2 to 4 in. w.c.

3.5 to 6 in. w.c. 5 to 9 in. w.c.

(2)

8.5 to 18 in. w.c. 14 to 28 in. w.c.

0.75 to 2

-1 to 1 in. w.c. -3 to 3 mbar

0 to 4 in. w.c. 0 to 10 mbar

0.10 to 0.21

0.14 to 0.34

0.34 to 0.69

0.14 to 0.34

0.31 to 0.69

0.41 to 1.4

1.1 to 2.1

1.8 to 2.8

2.5 to 3.4

3.1 to 4.1

5 to 10 mbar

9 to 15 mbar 12 to 22 mbar 21 to 45 mbar 35 to 70 mbar

0.05 to 0.14

Part Number Color Code

1H975927032 10A9440X012

1J146927142

17B8632X012 17B8633X012 10C1238X012 10C1240X012 10C1241X012 10C1242X012 10C1243X012

1D892527022 1D892627022 1D892727012 1D893227032 1D893327032 1H975827032

1K633427012

(Extension Spring)

1K633427012

(Extension Spring)

and

1D892527022

(Compression Spring)

Unpainted 2.00 50.8 0.075 1.91

Unpainted

CONTROL SPRINGS

Orange

Yellow

Blue

Yellow

Orange

Silver

Red

Blue

Green

White

Brown

Red

Black

White

Green

Blue

Brown

Free Length Wire Diameter

In. mm In. mm

6.91

6.47

6.19

8.50

8.25

6.13

7.53

7.88

7.50

7.25

7.09

2.00

6.13

176

164 157

216 216 210 210 210 210 210

156 191

200

190 184

180

50.8

156

0.250

0.283

0.375

0.282

0.343

0.375

0.438

0.500

0.531

0.109

0.112

0.130

0.156

0.182

0.225

0.075

0.109

6.35

7.19

9.52

7.16

8.71

9.53

11.1

12.7

13.5

2.77

2.85

3.30

3.96

4.62

5.72

1.91

2.77

Table 2. Maximum Inlet and Outlet Pressures

TYPE NUMBER

PRESSURES

Maximum Operating Inlet Pressure 60 4.1

Maximum Emergency Inlet Pressure 125 8.6 125 8.6 125 8.6

Maximum Operating Outlet Pressure

Maximum Outlet Pressure Over

Outlet Pressure Setting

Maximum Emergency Outlet

(Casing) Pressure

1. With highest spring range available only.

(1)

133H 133HP 133L 133Z

psig bar psig bar psig bar psig bar

150 10.5

10 0.69

3 0.21 3 0.21 3 0.21

15 1.0 150 10.5 15 1.0 15 1.0

Setpoint

plus 40

Setpoint

plus 2.8

60 4.1 20 1.4

2 0.14 4 in. w.c. 10 mbar

Startup

WARNING

If the downstream system is already pressured by another regulator or by a manual bypass, then extra precautions must be taken when placing the 133 Series in service. The outlet of the regulator must never be subjected to pressure higher than the inlet pressure or the balancing diaphragm may be damaged. Also, the control line pressure must never exceed the set point dictated by the spring setting by more than 3 psig / 0.21 bar or the valve seat or diaphragm plates can be damaged. The procedure used in putting

the regulator in service must be planned accordingly. Pressure gauges should always be used to monitor downstream and control line pressures during startup.

If the downstream system is not pressured by another regulator or by manual bypass, use the following procedure:

1. Check to see that all appliances are turned off.

2. Slowly open the upstream shutoff valve.

3. Slowly open the downstream shutoff valve.

4. Check all connections for leaks.

5. Make nal control spring adjustments according to the adjustment procedures.

133 Series

Adjustment

To increase the pressure setting, remove the closing cap (key 9, Figures 10, 11, 12 and 14) and turn the adjusting screw (key 11) clockwise; to lower the setting, turn the adjusting screw counterclockwise. A pressure gauge should always be used when adjustments are being made. Do not adjust the spring to produce an outlet pressure setting above the limit stamped on the nameplate (key 38, not shown), located on the casing ange. If the required pressure setting is not within the range of the spring in use, substitute with the correct spring. Ranges of available springs are shown in Table 1. When changing the spring, also change the nameplate, located on the casing ange, to indicate the outlet pressure range.

Shutdown

Isolate the regulator from the pressure system and release pressure from the outlet and the control line. Inlet pressure will then automatically be released as the regulator opens up in response to the lowered pressure on the diaphragm.

W1390/IL

Figure 4. Spring Case Inserted in Body for Disassembly. Note

Proper Method of Holding Stem and Sleeve When Loosening or

Tightening Stem Nut.

Maintenance

This section includes instructions for disassembly and replacement of parts. All key numbers refer to Figures 10, 11, 12 and 14, except where indicated.

WARNING

To avoid personal injury, property damage or equipment damage caused by sudden release of pressure or explosion of accumulated gas, do not attempt any maintenance or disassembly without

rst isolating the regulator from system

pressure and relieving all internal pressure from the equipment.

Do not loosen the diaphragm casing cap screws (keys 35 and 36) when the control spring (key 12) has spring force applied to it. Release the spring compression as described in step 7.

Due to normal wear that may occur in gas regulators, parts must be periodically inspected and replaced if necessary. The frequency of inspection, maintenance and replacement of parts depend upon the severity of service conditions or requirements of local, state and federal regulations.

Types 133H, 133L and 133Z

Disassembly

1. Disconnect the downstream control line from the regulator and disconnect the remote vent pipe if one is used.

Note

Allowing a slight amount of compression to remain in the regulator spring (key 12) will facilitate disassembly of the trim parts.

2. Unscrew the four locknuts (key 34) and lift the actuator portion off the body (key 1). All of the trim parts will come out of the body with the actuator. Inspect the valve disk (key 28), orice (key 2) and restriction collar (key 46, Figure 13), if used.

3. For further eld disassembly and inspection, the actuator may be turned upside down and the spring case (key 8A) inserted into the body cavity (see Figure 4).

CAUTION

Use care in performing step 4 to guard against damage to the balancing diaphragm (key 22).

133 Series

W1372/IL

Figure 5. Inspecting Guide Bushing and Stem Seal O-ring

4. Insert a 1/2 in. / 13 mm open-end wrench between the legs of the cage (key 5) and place the wrench on the stem sleeve wrench ats. Hold this wrench while unscrewing the nut (key 31) to prevent stem and stem sleeve (keys 18 and 25) rotation and diaphragm (key 15) and balancing diaphragm (key 22) damage due to twisting (see Figure 4).

5. Remove the washer, registration disk and valve disk (keys 30, 29 and 28). To remove the restriction collar (key 46, Figure 13) (if used), loosen the set screw (key 47, Figure 13) and slip the E-ring (key 26, Figure 13) and collar off of the stem (key 18). Remove the orice (key 2) by rotating it until the pins (key 5A) in the cage line up with the slots in the orice; then, lift off the orice. Replace the valve disk and orice if necessary.

6. Loosen the set screws (key 39) in the cage (key 5) and remove the roll pin (key 27) from the stem (key 18). Remove the cage and stem sleeve (key 25), the sealing washer (key 17) under the balancing diaphragm (key 22), at washers (key 23), balancing diaphragm and balancing diaphragm plate (key 21). Replace sealing washer and balancing diaphragm if necessary.

WARNING

To avoid personal injury due to the sudden uncontrolled movement of parts, do not loosen the diaphragm casing cap screws (keys 35 and 36) when the

W1371/IL

Figure 6. Installing Balancing Diaphragm. The Side of

Diaphragm Marked Piston Side Must Face Casing.

control spring (key 12) has spring force applied to it.

Release the spring compression as described in step 7.

7. To inspect or replace the upper stem seal O-ring (key 19) or main diaphragm (key 15) on the Type 133L or 133H (Figure 10 or 11), remove the closing cap (key 9) and inspect the closing cap gasket (key 10). Release spring compression by slowly turning the adjusting screw (key 11) counterclockwise and remove the spring (key 12).

For Type 133Z (Figure 12), remove the closing cap (key 9) and inspect the closing cap gasket (key 10). Release any spring compression by slowly turning the adjusting screw (key 11) counterclockwise. Lift the adjusting screw assembly (keys 11, 41, 42, 43 and 45) out of the spring case with pliers. Unhook the extension spring (key 44) from the spring retainer (key 42). Remove the compression spring (key 12) if one is used.

8. Unscrew the cap screws and nuts (keys 35 and 36) and remove the spring case (key 8A).

9. Pull out the diaphragm and stem as assembly; replace diaphragm (key 15) and sealing washer (key 17) if necessary. When removing or replacing the diaphragm, clamp the smallest diameter portion of the stem in a vise while turning the nut (key 20).

10. If necessary, replace the bearing (key 6) and the upper stem seal O-ring (key 19, Figure 5). Before reassembling, coat the O-ring with O-ring sealant and lubricant.

133 Series

Reassembly

Reassemble in reverse order of the above steps. When reassembling, observe the following steps and cautions.

1. If the spring case was disassembled, reassemble it rst. To ensure proper slack in the diaphragm (key 15) and to facilitate reassembly of the trim parts, tighten the casing cap screws and nuts (keys 35 and 36) nger-tight only. Then adjust the spring (key 12) to stroke the diaphragm assembly fully. Final tightening of the casing cap screws and nuts must be done alternately in equal increments to ensure a proper seal without crushing the diaphragm.

2. During reassembly, check all O-rings to be certain they are in good condition; replace if necessary. Lubricate the O-rings (keys 4, 19 and 32) with elastomer sealant and lubricant. Apply anti-seize compound liberally to the adjusting screw threads (key 11), as indicated in Figures 10 to 12.

3. When installing the balancing diaphragm (key 22), be certain the side marked PISTON SIDE is facing the spring case. Carefully tuck the slack diaphragm material into the space between the diaphragm plate (key 21) and the lower casing (key 7) until the diaphragm ts smoothly over the diaphragm plate without wrinkles and the bead ts snugly and evenly in the groove provided in the lower casing. This can be done with a small screwdriver, but be careful not to puncture the diaphragm (see Figure 6).

4. When replacing the cage (key 5), insert the set screws (key 39) only far enough to retain the cage. Do not tighten.

Type 133HP

Disassembly

WARNING

To avoid personal injury, property damage or equipment damage caused by sudden release of pressure or explosion of accumulated gas, do not attempt any maintenance or disassembly without

rst isolating the regulator from system

pressure and relieving all internal pressure from the equipment.

Do not loosen the diaphragm casing cap screws (Figure 9, keys 35 and 36) when the control spring (key 12) has spring force applied to it. Release the spring compression as described in step 6.

This section includes instructions for disassembly and replacement of parts for the Type 133HP. All key numbers refer to Figures 7, 8, 9 and 14, except where indicated.

1. Disconnect the downstream control line from the regulator and disconnect the remote vent pipe if one is used.

5. The registration disk (key 29) is marked for proper placement; be certain it is positioned correctly on the stem (key 18).

CAUTION

Always use the stem sleeve wrench

ats when loosening or tightening the

nuts (key 20 or 31) to prevent twisting of the main and balancing diaphragms (keys 15 and 22).

6. Be certain the Belleville spring washer (key 3) is in good condition and is in place before placing the actuator on the body (key 1).

CAUTION

Use care in performing step 3 to guard against damage to the balancing diaphragm (key 22).

3. Insert a 1/2 in. / 13 mm open-end wrench between the legs of the cage (key 5) and place the wrench on the stem sleeve wrench ats. Hold this wrench while unscrewing the nut (key 31) to prevent stem and stem sleeve (keys 18 and 25) rotation and diaphragm (key 15) and balancing diaphragm (key 22) damage due to twisting.

4. Remove the washer, registration disk and valve disk (keys 30, 29 and 28). To remove the restriction collar (key 46, Figure 13) (if used), loosen the set screw (key 47, Figure 13) and slip the E-ring (key 26, Figure 13) and collar off

133 Series

PROTECT THE O-RING SURFACE FROM DAMAGE

A7007

Figure 7. Stem and Diaphragm Assembly

the stem (key 18). Lift off the orice (key 2) and replace the valve disk and orice if necessary.

5. Loosen the set screws (key 39) in the cage (key 5) and remove the roll pin (key 27) from the stem (key 18). Remove the cage and stem sleeve (key 25), the sealing washer (key 17) under the balancing diaphragm (key 22), at washers (key 23), balancing diaphragm and balancing diaphragm plate (key 21). Replace the sealing washer and balancing diaphragm if necessary.

WARNING

• To avoid personal injury due to the

sudden uncontrolled movement of parts, do not loosen the diaphragm casing cap screws (keys 35 and 36) when the control spring (key 12) has spring force applied to it.

• Release the spring compression as

described in step 6 below.

6. To inspect or replace the upper stem seal O-ring (key 19) or main diaphragm (key 15), remove the closing cap (key 9) and inspect the closing cap gasket (key 10). Release the spring compression completely by loosening the hex nut (key 59) and turning the adjusting screw (key 11) counterclockwise.

7. Remove the six cap screws (key 62) from the spring case (key 8). Lift off the spring case, upper spring seat (key 41) and spring (key 12). Remove

3/4 in. / 19 mm

STEM HEX

the diaphragm casing cap screws and hex nuts (keys 35 and 36) and lift off the upper diaphragm casing (key 52). Remove the cap screws (key 55) and mounting bracket (key 56). Inspect the two mounting bracket gaskets (key 57) and replace if necessary.

8. Remove the hex nut (key 20), lock washer (key 58) and spring seat (key 13) from the stem (key 18).

9. Remove the diaphragm plate (key 14), diaphragm (key 15), diaphragm washer O-ring (key 61) and sealing diaphragm plate (key 16). Replace the diaphragm and diaphragm washer O-ring if necessary.

10. Remove the cap screws (key 53) and lift the lower diaphragm casing (key 7) off the casing adaptor (key 60). If necessary, replace the bearing (key 6) and upper stem seal O-ring (key 19). Before reassembling, coat the O-ring with a O-ring sealant and lubricant.

Reassembly

When reassembling, observe the following steps and cautions. During reassembly, check all O-rings to be certain they are in good condition and replace if necessary. Coat O-rings (keys 4, 19 and 32) with Multi-Purpose Polytetrauoroethylene (PTFE) lubricant or an equivalent elastomer sealant and lubricant.

All key numbers refer to Figures 7, 8, 9 and 14, except where indicated.

133 Series

APPLY PTFE SEALANT TO THREADS AND INSTALL WITH CONTROL LINE CONNECTION POINTING AWAY FROM

A7008/IL

Figure 8. Lower Casing and Casing Adaptor Assembly

THE CASING ADAPTOR

1/4 NPT CONTROL LINE CONNECTION

WHEN ASSEMBLING THE ACTUATOR, THE UPPER CASING AND ADAPTOR SHOULD BE POSITIONED SO THAT TWO HOLES IN THE 5.25 in. / 133 mm BOLT HOLE CIRCLE ARE EQUALLY SPACED OVER THE CONTROL CONNECTION

A7009/IL

Figure 9. Diaphragm Casing Assembly

1. With the Type 133HP completely disassembled, start the reassembly by applying Multi-Purpose PTFE lubricant or an equivalent to the stem threads (key 18) and diaphragm washer O-ring (key 61). Place the sealing diaphragm plate (key 16) on the stem followed by the O-ring (key 61), diaphragm (key 15), diaphragm plate (key 14), spring seat (key 13), lock washer (key 58) and hex nut (key 20) as shown in Figure 7. To prevent diaphragm damage, torque the hex nut (key 20) to 25 to 30 ft-lbs / 34 to 41 N•m, while using 3/4 in. / 19 mm wrench ats on the stem.

2. If the street elbow (key 51) was removed, it must be reassembled before mounting the casing adaptor (key 60). Apply PTFE sealant or equivalent around the external threads of the street elbow and tighten to a torque of 20 to 35 ft-lbs / 27 to 47 N•m. Position the control line

connection (street elbow) so that it points away from the casing adaptor.

3. Lubricate the O-rings (keys 19, 32 and 54) and install as shown in Figure 8. Install the casing adaptor (key 60) to the lower casing (key 7) and tighten the cap screws (key 53) to 20 to 30 ft-lbs / 27 to 41 N•m of torque.

4. Insert the stem bearing (key 6) and carefully insert the stem (key 18) into the lower casing (key 7) and casing adaptor (key 60) assembly.

5. Assemble the upper diaphragm casing (key 52), mounting plate adaptor (key 56) and mounting plate gasket (key 57) as shown in Figure 9. Tighten the cap screws (key 55) to 20 to 30 ft-lbs / 27 to 41 N•m of torque.

6. Assemble the upper and lower casings, noting that two of the holes in the 5-1/4 in. / 133 mm diameter

133 Series

bolt circle in the mounting plate adaptor (key 56) must be spaced (aligned) an equal distance over the downstream control line connection. Install cap screws and hex nuts (keys 35 and 36) with a torque of 20 to 30 ft-lbs / 27 to 41 N•m.

7. Place the balancing plate washer (key 23), balancing diaphragm plate (key 21), balancing diaphragm (key 22) and a second balancing plate washer (key 23), onto the stem (key 18).

Note

When installing the balancing diaphragm (key 22), be certain the side marked PISTON SIDE is facing the spring case. Carefully tuck the slack diaphragm material into the space between the diaphragm plate (key 21) and lower casing (key 7) until the diaphragm

ts smoothly over the diaphragm

plate without wrinkles and the bead

ts snugly and evenly in the groove

provided in the lower casing. This can be done with a small screw screwdriver, but be careful not to puncture the diaphragm (see Figure 6).

8. Apply Multi-Purpose PTFE lubricant or equivalent to the sealing washer (key 17) and carefully slide over the threaded end of the stem (key 18).

9. Insert the guide bushing (key 24) into the cage (key 5) and slide the cage up onto the stem (key 18). Insert the set screws (key 39) only far enough to retain the cage. Do not tighten.

10. Lubricate and install the O-rings (keys 19 and 4) as indicated in Figure 14. Install the orice (key 2) onto the cage (key 5). Install the Belleville spring washer (key 3) so that the concave face of the washer faces away from the orice.

11. Install the E-ring (key 26) on the stem sleeve (key 25) and slide the stem sleeve over the stem (key 18) aligning the slotted end of the stem sleeve so that the roll pin (key 27) can be inserted through the cross-drilled hole in the end of the stem.

CAUTION

Always use the stem sleeve wrench

ats when loosening or tightening the

nuts (key 20 or 31) to prevent twisting of the main and balancing diaphragms (keys 15 and 22).

12. Install the valve disk (key 28), registration disk (key 29), washer (key 30) and hex nut (key 31) onto the stem. The registration disk (key 29) is marked for proper placement; be certain it is positioned correctly on the stem (key 18). Tighten the hex nut (key 31) using the 1/2 in. / 13 mm wrench ats on the stem sleeve.

13. Insert the valve trim assembly into the body and position the downstream control line connection (key 51) so it is pointing directly over the body outlet.

14. Screw the studs (key 33) into the body (key 1). Install and tighten the hex nuts (key 34) to 20 to 35 ft-lbs / 27 to 47 N•m of torque.

15. Apply anti-seize to the adjusting screw (key 11) and upper spring seat (key 41). Install the adjusting screw and hex jam nut (key 59) into the spring case (key 8). Position the control spring (key 12) and upper spring seat on the diaphragm plate (key 14) and lower spring seat (key 13).

16. Install the mounting plate gasket (key 57) and place the spring case on the mounting bracket (key 56). Install the cap screws (key 62) and torque to 20 to 30 ft-lbs / 27 to 41 N•m.

17. Screw in the pipe nipple (key 49) and vent (key 50). Install the closing cap gasket (key 10) and closing cap (key 9).

Parts Ordering

When corresponding with your local Sales Ofce about this equipment, be sure to include the type number and other information stamped on the nameplate.

When ordering replacement parts, reference the key number of each needed part and specify the eleven character part number as found in the following parts list.

Parts List

Key Description Part Number

Parts kit for Types 133H, 133L and 133Z (included are keys 2, 4, 6, 10, 15, 17, 19, 22, 24, 28, 32 and 40) R133HX00012

1 Body

Cast iron 2 NPT 30A3044X012 NPS 2 / DN 50, CL125 FF 30A3045X012

WCC Steel

2 NPT 30B0855X012 NPS 2 / DN 50, CL150 RF 30B0854X012

133 Series

40A3066

APPLY LUBRICANT (L) OR SEALANT (S)

1. Lubricant and sealant must be selected such that they meet the temperature requirements.

(1)

Figure 10. Type 133L Assembly

Key Description Part Number

2* Orice, Aluminum 20A3046X012 3 Belleville Spring Washer, 17-4PH Stainless steel 10A3047X012 4* O-ring Nitrile (NBR) 10A9339X012 Fluorocarbon (FKM) (for Types 133L and 133H only) 10A9339X022 5* Cage/Pin Assembly, Aluminum/Steel (including roll pins, key 5A) 20A3048X012 6* Bearing, Nylon (PA) 10A3049X012 7 Lower Casing Types 133H, 133L and 133Z, Aluminum 40A3050X012 Type 133HP, Steel 32B3499X012 8 Spring Case Type 133HP, Cast iron 2H140619012 Parts 8A through 8J are used on Types 133H, 133L and 133Z only 8A Spring Case, Aluminum 4L142308032 8B Stabilizer Stem, 302 Stainless steel 1H976335022 8C Lower Stabilizer, Nylon (PA) 1H976406992 8D Upper Stabilizer, Polyethylene 1H976506992 8E Orice, Stainless steel T13609T0012 8F Screw, Steel (3 required) 1H976728982 8G Spring, 302 Stainless steel (2 required) 1H976837022 8H Screen, Stainless steel 1E564843122 8J Snap Ring, 302 Stainless steel 1E564937022 9 Closing Cap Types 133H, 133L and 133Z, Aluminum 1L928308012 Type 133HP, Cast iron 00288819012 10* Closing Cap Gasket Types 133H, 133L and 133Z, Neoprene (CR) 1N446206992 Type 133HP, Composition 1R742604022

Key Description Part Number

11 Adjusting Screw Type 133H, Brass 1V9069X0012 Type 133L, Aluminum 1L928608012 Type 133Z, Brass 1K633714012 Type 133HP, Steel 1H139731012 12 Spring Steel

Type 133H

Zinc-plated steel

1.5 to 3 psig / 0.10 to 0.21 bar, Orange 1H975927032

2 to 5 psig / 0.14 to 0.34 bar, Yellow 10A9440X012 17-7 PH Stainless steel 5 to 10 psig / 0.34 to 0.69, Blue 1J146927142 Types 133L and 133H Zinc-plated steel 2 to 4 in. w.c. / 5 to 10 mbar, Brown 1D892527022

3.5 to 6 in. w.c. / 9 to 15 mbar, Red 1D892627022

Plated steel 5 to 9 in. w.c. / 12 to 22 mbar, Black 1D892727012

8.5 to 18 in. w.c. / 21 to 45 mbar, White 1D893227032

14 to 28 in. w.c. / 35 to 70 mbar, Green 1D893327032

0.75 to 2 psig / 0.05 to 0.14 bar, Blue 1H975827032

Type 133Z (Extension spring, key 44, also required) Zinc-plated steel

-1 to 1 in. w.c. / -2 to 2 mbar, see key 44

0 to 4 in. w.c. / 0 to 10 mbar, Brown 1D892527022

Type 133HP

17-7 PH Stainless steel 2 to 5 psig / 0.14 to 0.34 bar, Yellow 17B8632X012 302 Stainless steel

4.5 to 10 psig / 0.31 to 0.69 bar, Orange 17B8633X012

(1)

*Recommended spare parts.

1. If the 2 in. w.c. to 2 psig / 5 mbar to 0.14 bar springs listed under Type 133L are used in the Type 133H, the pressure ranges will increase by approximately 1 in. w.c. / 2 mbar due to the weight of the Type 133H parts (assuming that the actuator is installed above the body).

133 Series

40A3070

APPLY LUBRICANT (L) OR SEALANT (S)

1. Lubricant and sealant must be selected such that they meet the temperature requirements.

(1)

Figure 11. Type 133H Assembly

Key Description Part Number

12 Spring Steel (continued) Type 133HP (continued)

Steel

6 to 20 psig / 0.41 to 1.4 bar, Silver 10C1238X012 16 to 30 psig / 1.1 to 2.1 bar, Red 10C1240X012 26 to 40 psig / 1.8 to 2.8 bar, Blue 10C1241X012 36 to 50 psig / 2.5 to 3.5 bar, Green 10C1242X012 45 to 60 psig / 3.1 to 4.1 bar, White 10C1243X012 13 Spring Seat, Plated steel Types 133H, 133L and 133Z 10A3052X012 Type 133HP 1P787724152 14 Diaphragm Plate, Steel Type 133H (1 required) 1D555725012 Type 133L (1 required) 1J881725072 Type 133Z (2 required) 1J881725072 Type 133HP (1 required) 22B3514X012 15* Diaphragm, Nitrile (NBR) and Nylon (PA) Types 133H, 133L and 133Z 1N150802052 Type 133HP 32B3520X012 Fluorocarbon (FKM) (for Types 133L and 133H only) 1N150802402 16 Sealing Diaphragm Plate, Zinc-plated steel Types 133H, 133L and 133Z 1D475725062 Type 133HP 12B3517X012 17* Sealing Washer, Zinc-plated steel (2 required for Types 133L, 133H and 133Z; 1 required for Type 133HP) 1F990428982 18 Stem, Stainless steel Types 133H and 133L 20A3053X012 Type 133Z 10A3069X012 Type 133HP 37B3942X012

Key Description Part Number

19* O-ring Nitrile (NBR) (2 required for Types 133L, 133H and 133HP; 1 required for Type 133Z) F1367806562 Fluorocarbon (FKM) (2 required for Types 133L and 133H only) 1E5914X0062 20 Hex Nut Types 133H, 133L and 133Z, Aluminum 1D5297X0012 Type 133HP, Zinc-plated steel 1A413224122 21 Diaphragm Plate, Plated steel 10A3054X012 22* Diaphragm Nitrile (NBR) and Nylon (PA) 10A3055X012 Fluorocarbon (FKM) (for Types 133L and 133H only) 10A3055X022 23 Washer, Steel (2 required) 10A3056X012 24* Guide Bushing, Nylon (PA) 10A3057X012 25 Stem Sleeve, 303 Stainless steel 10A3061X012 26 E-ring, Plated steel 1F599428982 27 Roll Pin, 420 Stainless steel 1E954028992 28* Valve Disk Assembly Aluminum / Neoprene (CR) 10A3058X012 Aluminum / Fluorocarbon (FKM) (for Types 133L and 133H only) 10A3058X032 29 Registration Disk, Nylon (PA) 10A3060X012 30 Washer, Zinc-plated steel 1H723125072 31 Hex Nut, Zinc-plated steel 1C121928982 32* O-ring Nitrile (NBR) 1J1079X0012 Fluorocarbon (FKM) (for Types 133L and 133H only) 1J1079X0022 33 Stud, Alloy steel (4 required) 10A3062X012

*Recommended spare parts.

133 Series

40A3071

APPLY LUBRICANT (L) L1 = Anti-Seeze Compound L2 = Silicone Grease

1. Lubricants must be selected such that they meet the temperature requirements.

(1)

Figure 12. Type 133Z Assembly

Figure 13. Optional Restriction Collar Assembly

133 Series

A7011/IL

APPLY LUBRICANT (L)

1. Lubricant must be selected such that they meet the temperature requirements.

(1)

Figure 14. Type 133HP Actuator Assembly

133 Series

Key Description Part Number

34 Locknut, Plated alloy steel (4 required) 10A3063X012 35 Cap Screw, Zinc-plated steel Types 133H, 133L and 133Z (12 required) 1B136324052 Type 133HP (12 required) 1E760324052 36 Hex Nut, Zinc-plated steel Types 133H, 133L and 133Z (12 required) 1A309324122 Type 133HP (12 required) 1A346524122 37 Nameplate (for Types 133L, 133H and 133Z only) (not shown) - - - - - - - - - - 38 Nameplate (for Types 133L, 133H and 133Z only) (not shown) - - - - - - - - - - 39 Set Screw, Alloy steel (2 required) 10A3051X012 40* Thrust Washer, Nylon (PA) Type 133H only 1V9661X0012 41 Upper Spring Seat Type 133Z, Brass 1K633514012 Type 133HP, Zinc-plated steel 1H140124092 42 Spring Retainer, Brass Type 133Z only 1K633814012 43 Ball, 440C Stainless steel (10 required) Type 133Z only 1B793546202 44 Extension Spring, Zinc-plated steel Type 133Z only, Unpainted 1K633427012 45 Retaining Ring, Plated steel Type 133Z only 10A3074X012 46 Restriction Collar, Aluminum 25% capacity 12A7404X012 40% capacity 12A7402X012 60% capacity 12A7403X012 47 Set Screw, Steel 1N830528992 50 Flow Arrow, 18-8 Stainless steel - - - - - - - - - - 51 Drive Screw, 18-8 Stainless steel (2 required) - - - - - - - - - - -

Type 133HP only

Key Description Part Number

49 Pipe Nipple, Zinc-plated steel 1A473526012 50 Vent Assembly Type Y602-7 51 Street Elbow, Malleable iron 1A913221992 52 Upper Diaphragm Casing, Steel 2F581125062 53 Cap Screw, Zinc-plated steel (4 required) 1D529824052 54* Adaptor O-ring, Nitrile (NBR) 1F914106992 55 Cap Screw, Zinc-plated steel (6 required) 1A368424052 56 Mounting Bracket, Steel 1H140025032 57* Mounting Bracket Gasket, Neoprene (CR) (2 required) 1H140404022 58 Lock Washer, Steel 1A487828992 59 Hex Jam Nut, Zinc-plated steel 1A319224122 60 Casing Adaptor, Steel 37B4486X012 61* Diaphragm Washer O-ring, Nitrile (NBR) 1C782206992 62 Cap Screw, Zinc-plated steel (6 required) 1A341824052 63 Nameplate - - - - - - - - - - 64 Drive Screw 1A368228982

*Recommended spare parts.

Industrial Regulators

Emerson Process Management Regulator Technologies, Inc.

USA - Headquarters McKinney, Texas 75070 USA Tel: +1 800 558 5853 Outside U.S. +1 972 548 3574

Asia-Pacic

Shanghai 201206, China Tel: +86 21 2892 9000

Europe Bologna 40013, Italy Tel: +39 051 419 0611

Middle East and Africa Dubai, United Arab Emirates Tel: +971 4811 8100

For further information visit www.fisherregulators.com

The Emerson logo is a trademark and service mark of Emerson Electric Co. All other marks are the property of their prospective owners. Fisher is a mark owned by Fisher Controls International LLC, a business of Emerson Process Management.

The contents of this publication are presented for informational purposes only, and while every effort has been made to ensure their accuracy, they are not to be construed as warranties or

guarantees, express or implied, regarding the products or services described herein or their use or applicability. We reserve the right to modify or improve the designs or specications of such

products at any time without notice.

Emerson Process Management Regulator Technologies, Inc. does not assume responsibility for the selection, use or maintenance of any product. Responsibility for proper selection, use and maintenance of any Emerson Process Management Regulator Technologies, Inc. product remains solely with the purchaser.

Natural Gas Technologies

Emerson Process Management Regulator Technologies, Inc.

USA - Headquarters McKinney, Texas 75070 USA Tel: +1 800 558 5853 Outside U.S. +1 972 548 3574

Asia-Pacic

Singapore 128461, Singapore Tel: +65 6770 8337

Europe Bologna 40013, Italy Tel: +39 051 419 0611 Chartres 28008, France Tel: +33 2 37 33 47 00

Middle East and Africa Dubai, United Arab Emirates Tel: +971 4811 8100

TESCOM

Emerson Process Management Tescom Corporation

USA - Headquarters Elk River, Minnesota 55330-2445, USA Tels: +1 763 241 3238 +1 800 447 1250

Europe Selmsdorf 23923, Germany Tel: +49 38823 31 287

Asia-Pacic

Shanghai 201206, China Tel: +86 21 2892 9499

Fisher 133H, 133L, 133, 133HP Instruction Manual

Specifications and Main Features

Frequently Asked Questions

User Manual
