First Act MA215 User Manual

MA215
DYNAMIC
BASS
AMPLIFIER
INSTRUCTIO N
MANUAL
745 Boylston Street Boston, MA 02116 USA rstact.com
OTHER FIRST ACT
®
PRODUCTS :
10 & 20ft Cables
Books
Auto Tuner
Guitar Strings
Picks
StringwinderGuitar Case
Customer Assistance
Phone: 888.551.1115
Email: info@firstact.com
1. This unit should be protected from contact
with water, moisture, or liquids of any kind.
2. This amplifier should only be serviced by a
qualified repair technician.
3. This unit should not be placed near a heat
source (permissible operating temperature
range 32–104ºF).
4. Do not set heavy objects on the power cable or
allow the cable to be torn. If the cable needs
repair, do not plug the amplifier in. Have the
amplifier repaired immediately by a qualified
service technician.
5. Unplug your amplifier when not in use for
extended periods of time.
6. Turn amplifier power off when not in use.
7. The outside of the amplifier may be cleaned
with a dry cloth only. Do not use water or
chemicals to clean.
8. This unit contains digital circuitry and may
cause interference if placed too close to radio
or television receivers.
9. Do not operate the amplifier if:
» the unit or main cable has been
visibly damaged
» the unit has been dropped
» the unit has been exposed to
moisture/liquids of any kind
» the unit is not functioning properly
Note: If you suspect that your amp is
defective, have it checked and repaired by
a qualified service technician.
10. Do not expose the unit to:
» Direct sunlight
» Excessive humidity
» Excessive dust
» Strong vibration
11. This unit must be properly grounded.
12. To prevent electric shock hazard, do not open
the cabinet or chassis of the amplifier.
©2006 First Act I nc. All right s res erved .
First Act an d the Firs t Act logos are
trade marks of F irst Act Inc.
US Patent No. D487,627S
MA215 .M.05
IMPORTANT SAFETY INSTRUCTIONS
Please read carefully before operating your amplier:
Follow these basic precautionary measures to ensure a longer life for your amplifier, and to reduce
the risk of electric shock.
RE P LA C IN G T H E F US E
An additional fuse has been enclosed in the fuse compartment of your amplifier, directly below the power input. The fuse compartment contains an active fuse and a replacement. The fuse protects against power surges. If your amplifier does not power up as usual, the fuse may need to be replaced.
If the fuse fails:
1. Turn the amplifier power off.
2. Unplug the amplifier.
3. Detach the power cord and set aside.
4. Carefully insert a flathead screwdriver to open the fuse compartment. Be careful not to break the fuse inside.
5. Remove the blown fuse from the inner (active) slot.
6. Move the new fuse from the outer slot to the inner slot.
7. Close the fuse compartment.
8. Discard the blown fuse.
Note: If you replace the fuse and the amplifier still does not power up, have the unit checked by a qualified repairperson.
SPECIFICATIONS
Output Power:
15 watts RMS
Frequency Range:
75 Hz ~ 10 kHz
Speaker:
8" / 20W / 4 ohms
Input Sensitivity:
26 mV
Power Supply:
See back of amp
Dimensions: (LxWxH)
14" x 13" x 8"
Weight:
13 lbs.
SPECIFI CATIO NS SUBJECT TO CHANGE WI THOUT NOTICE
1. INP UT JA CK
Connect instrument cable here.
2. VOL UME Controls the total output level of amplifier.
3. PRE SENCE Enhances higher frequencies, dampens lower frequencies.
4. LED Indicates power on/off.
5. TRE BLE Adjusts high frequency output.
6. MID DLE Adjusts middle frequency output.
7. BAS S Adjusts low frequency output.
8. POWER INPUT / FUSE COMPARTMENT Connection for detachable UL-approved power cable. Use only the power cable sup­plied with this amplifier. Fuse compartment contains a replacement fuse to protect your amp from power surges, see instructions for Replacing the Fuse.
9. POW ER On/off switch.
10. AUDI O IN Input jack for external audio device such as CD, MP3, or cassette player (device should have its own volume control).
11. PHONES Connect stereo headphones here (speaker output is canceled when headphones are con­nected).
Open the fuse compartment.
Remove the blown fuse from the inner (active) slot. Move the new fuse from the outer slot to the inner slot.
US I N G ANO TH ER TYP E IS A P OT E NT IAL FI R E H AZA R D.
CAUTION
REPLACE ONLY WITH SAME TYP E 250V, 1A FUSE .
1 432 5 6 7
FAC E P L ATE
BACK P L ATE
10 1198
ACTIVE FUSE
REPLACEMENT FUSE
