First Act M2A-110 User Manual

M2A110.M.06
All rights reserved. ©2008 First Act Inc. US Patent No. D487,627 trademarks of First Act Inc. First Act and the First Act logo are
Email: info@firstact.com Phone: 888.551.1115
Customer Assistance
MANUAL
INSTRUCTION
AMPLIFIER
M2A-110
OTHER FIRST ACT
®
PRODUCTS :
10 & 20ft Cables
Books
Auto Tuner
Guitar Strings
First Act Inc.
745 Boylston Street Boston, MA 02116 USA rstact.com
Picks
StringwinderGuitar Case
EARTHING CONNECTION. THE APPARATUS SHALL BE CONNECTED TO MAINS SOCKET OUTLET WITH A PROTECTIVE
SOCKET COMPLETELY. MAINS COMPLETELY, THE MAINS PLUG SHOULD BE DISCONNECTED FROM THE MAINS ABLE DURING INTENTED USE. IN ORDER TO DISCONNECT THE APPARATUS FROM THE MAINS PLUG IS USED AS DISCONNECT DEVICE AND IT SHOULD REMAIN READILY OPER-
APPARATUS TO RAIN OR MOISTURE. WARNING: TO REDUCE THE RISK OF FIRE OR ELECTRIC SHOCK, DO NOT EXPOSE THIS
CAUSE HEARING LOSS. WARNING: EXCESSIVE SOUND PRESSURE FROM EARPHONES AND HEADPHONES CAN
INSTRUCTIONS IN THE LITERATURE ACCOMPANYING THE APPLIANCE. USER TO THE PRESENCE OF IMPORTANT OPERATING AND MAINTENANCE (SERVICING) THE EXCLAMATION POINT WITHIN AN EQUILATERAL TRIANGLE IS INTENED TO ALERT THE
CONSISTITUTE A RISK OF ELECTRIC SHOCK TO PERSONS. VOLTAGE” WITHIN THE PRODUCT’S ENCLOSURE THAT MAY BE OF SUFFICIENT MAGNITUDE TO IS INTENDED TO ALERT THE USER TO THE PRESENCE OF UNINSULATED “DANGEROUS
INSIDE, REFER SERVICING TO QUALIFIED SERVICE PERSONNEL. REMOVE COVER (OR BACK). NO USER-SERVICEABLE PARTS CAUTION: TO REDUCE THE RISK OF ELECTRIC SHOCK, DO NOT
THE LIGHTENIING FLASH WITH ARROWHEAD SYMBOLS, WITH AN EQUILATERAL TRIANGLE
DO NOT OPEN
RISK OF ELECTRIC SHOCK
CAUTION
apparatus. tacles, and the point where they exit from the pinched particularly at plugs, convenience recep-
10. Protect the power cord from being walked on or replacement of the obsolete outlet.
not fit into your outlet, consult an electrician for provided for your safety. If the provided plug does prong. The wide blade or the third prong are ing type has two blades and a third grounding blades with one wider than the other. A ground­ or grounding-type plug. A polarized plug has two
9. Do not defeat the safety purpose of the polarized be placed on the appartus.
naked flame sources such as lighted candles should tus (including amplifiers) that produce heat. No radiators, heat registers, stoves, or other appara-
8. Do not install near any heat sources such as instructions.
Install in accordance with the manufacturer’s does not operate normally, or has been dropped. paratus has been exposed to rain or moisture, or objects have fallen into the apparatus, the ap­ cord or plug is damaged, liquid has been spilled been damaged in any way, such as power-supply Servicing is required when the apparatus has
13. Refer all servicing to qualified service personnel. or when unused for long periods of time.
Unplug this apparatus during lightning storms
12. the manufacturer.
11. Only use attachments/accessories specified by
a minimum distance of 10cm around the appartus.
7. Do not block any ventilation openings, maintaining
6. Clean only with dry cloth.
vases, should be placed on apparatus.
or splashing. No objects filled with liquids, such as
5. The apparatus should not be exposed to dripping
4. Follow all instructions.
3. Heed all warnings.
2. Keep these instructions.
1. Read these instructions.
the risk of electric shock.
Follow these basic precautionary measures to ensure a longer life for your amplifier, and to reduce
Please read carefully before operating your amplier:
IMPORTANT SAFETY INSTRUCTIONS
FACEPLATE
1 5432 6 7 8
BACKPLATE
1211109
1. INPUT JACK
Connect instrument cable here (
2. MASTER VOLUME
Controls the total output level of amplifier.
3. GAIN
Controls the input level. Increasing gain adds distortion, or an overdriven rock tone; decreasing gain produces a cleaner sound. Gain knob is functional when Overdrive button is engaged.
4. OVERDRIVE ON/OFF SWITCH
ON selects the Overdrive (distortion) channel, OFF selects the Clean channel. The GAIN
knob interacts with the overdrive button, allowing the user to add the desired amount of distortion.
5. LED
Indicates power on/off.
6. TREBLE
Adjusts high frequency output.
1
/4 inch jack).
SPECIFICATIONS
Output Power:
10 watts RMS
Frequency Range:
40 Hz ~ 8 kHz
Speaker:
6.5" / 25W / 8 ohms
Input Sensitivity:
26 mV
Power Supply:
Detachable, UL-approved
power cable
7. MIDDLE
Adjusts middle frequency output.
8. BASS
Adjusts low frequency output.
9. POWER
On/off switch.
10. PHONES
Connects to stereo headphones, which cancels speaker output.
11. AUDIO IN
Input jack for external audio device such as CD, MP3, or cassette player (device should have its own volume control).
12. POWER INPUT / FUSE COMPARTMENT
Connection for power cable. Use only the power cable supplied with this amplifier. See instructions below for replacing the fuse.
Dimensions: (LxWxH)
12" x 7.4" x 12"
Weight:
12 lbs.
SPECIFICATIONS SUBJECT TO CHANGE WITHOUT NOTICE
REPLACING THE FUSE
The fuse compartment contains an active fuse. The fuse protects against power surges. If your amplifier does not power up as usual, this fuse may need to be replaced.
If the fuse fails:
1. Turn the amplifier power off.
2. Unplug the amplifier.
3. Detach the power cord and set aside.
4. Carefully insert a flathead screwdriver to open the fuse compartment. Be careful not to break the fuse inside.
5. Remove the blown fuse from the inner (active) slot.
6. Replace with a 250V, 500mA fuse.
7. Close the fuse compartment.
8. Discard the blown fuse.
Note: If you replace the fuse and the amplifier still does not power up, have the unit checked by a qualified repairperson.
REPLACE ONLY WITH SAME
CAUTION
USING ANOTHER TYPE IS A POTENTIAL FIRE HAZARD.
TYPE 250V, 500mA FUSE.
Open the fuse compartment.
ACTIVE FUSE
Remove the blown fuse from the inner (active) slot.
